Wallenstein WHS12000 User manual

PRINTED IN CANADA
REV 020216 PART NUMBER: Z97098
Keep this manual with the Generator at all times
EMB Manufacturing Inc.
4144 Boomer Line · St. Clements, On · N0B 2M0 · Canada
Ph: [phone] · Fax: [phone]
www.embmfg.com
HEAVY DUTY PORTABLE
GENERATORS
PS
C
®
CERTIFIED.
ELECTRICAL SAFETY
WHS12000
WHS12000R
WHS14000
WHS14000R
OPERATOR'S MANUAL
WCS12000
WCS12000R
WCS14000
WCS14000R
WHS12000
WHS12000R
WCS14000
WCS1400R
WHS12000
WHS12000R
WCS12000
WCS12000R
FIRST USE: DO NOT attempt to crank or start the engine
before it has been properly lled with the recommended amount and type of oil.
Damage to the generator as a result of failure to follow these instructions will void your
warranty. See the engine owners manual for detailed instructions.
U1 Lawn & Garden 250 CCA battery is not included
Thoroughly review this manual and the engine manual for
safe and proper operation.

2
TABLE OF CONTENTS
WARRANTY............................................................... 3
WALLENSTEIN.......................................................... 4
LABEL INFORMATION ............................................. 5
SERIAL NUMBER LOCATION .................................. 5
1 INTRODUCTION........................................... 6
2 SAFETY ........................................................ 7
2.1 SAFETY DO'S & DON'TS' ......................... 8
2.2 EQUIPMENT SAFETY GUIDELINES ........ 9
2.3 SAFETY TRAINING ................................. 10
2.4 PREPARATION ........................................ 10
2.5 MAINTENANCE SAFETY .........................11
2.6 BATTERY SAFETY ...................................11
2.7 REFUELING SAFETY ............................. 12
2.8 OPERATING SAFETY ............................. 12
2.9 TRANSPORT SAFETY ............................ 13
2.10 STORAGE SAFETY................................. 13
2.11 ELECTRICAL SAFETY ............................ 13
2.12 GAS MOTOR SAFETY ............................ 14
2.13 SIGN-OFF FORM .................................... 15
3 SAFETY SIGNS.......................................... 16
3.1 HOW TO INSTALL SAFETY SIGNS: ....... 16
3.2 SAFETY SIGN EXPLANATIONS: ............ 16
4 OPERATION & FEATURES ....................... 18
4.1 TO THE NEW OPERATOR OR OWNER 18
4.1.1 SAFE CONDITION ................................. 18
4.2 MACHINE COMPONENTS ...................... 19
4.3 MACHINE BREAK-IN .............................. 20
4.4 PREOPERATION CHECKLIST................ 20
4.5 CONTROLS ............................................. 21
4.5.1 ENGINE CONTROLS .............................. 21
4.5.2 ELECTRICAL PANEL............................... 22
4.5.3 ELECTRICAL PANEL............................... 23
WHS12000 & WHS12000R ................. 23
WHS14000 & WHS14000R ................. 23
WCS12000 & WCS12000R ................. 24
WCS14000 & WCS14000R ................. 24
CIRCUIT BREAKERS:......................... 25
OPERATING HINTS: ........................... 25
4.6 ELECTRICAL LOAD ...........................26
4.6.1 WATTAGE AND LOAD .........................26
REACTIVE LOAD ............................26
RESISTIVE LOAD ...........................26
CONTINUOUS WATTAGE ..............26
MAXIMUM WATTAGE .....................26
4.6.2 CALCULATING LOAD .........................26
4.6.4 WATTAGE CHART ...............................27
5 FIELD OPERATION................................28
5.1 PREPARE ............................................28
5.2 START ..................................................29
5.2.1 STARTING THE GENERATOR:...........29
5.2.2 STOPPING: .........................................29
5.2.3 EMERGENCY STOPPING: .................29
5.2.4 TERRAIN: ...........................................29
5.2.5 WEATHER: ..........................................29
5.2.6 ELECTRICAL LOADS: .........................29
5.2.7 COMPONENT CONDITION: ...............29
5.2.8 ELECTRICAL HAZARDS: ....................29
5.3 RESIDENTIAL......................................30
5.4 MOVING ..............................................30
5.4.1 TRANSPORTING: ...............................30
5.4.2 LIFTING HOOK: ...................................30
5.4.3 FOLDING HANDLE: ............................31
5.5 STORAGE ...........................................32
5.5.1 PLACING IN STORAGE ......................32
5.5.2 REMOVING FROM STORAGE ...........32
6 SERVICE AND MAINTENANCE ............33
6.1 SERVICE .............................................33
6.1.1 FLUIDS AND LUBRICANTS ................33
6.2 MAINTENANCE ...................................34
6.2.1 GENERAL MAINTENANCE .................34
6.2.2 ENGINE MAINTENANCE ....................34
6.2.3 ALTERNATOR MAINTENANCE ..........34
6.2.4 BATTERY MAINTENANCE .................35
7 SPECIFICATIONS ..................................36
7.1 MECHANICAL......................................36
7.2 BOLT TORQUE ....................................37
8 TROUBLE SHOOTING...........................38
9 ACCESSORIES ......................................39
10 INDEX..........................................................40

3
WARRANTY
WARRANTY
Effective on products retailed on or after January 1, 2015.
Register your product online at www.embmfg.com
within 30 days of purchase to activate warranty.
This product is warranted to be free of defects in materials and workman-
ship under normal use and service, for a period of
from the date of purchase, when operated and maintained in accordance with the Operating and Maintenance Instructions
supplied with this unit. Warranty is limited to the repair of the product and/or replacement of parts.
This warranty does not cover the following items:
1) Machines or parts lost or damaged during shipment,
2) Normal maintenance or adjustments after initial pre-service and set up is completed
3) Normal replacement of service items.
4) Accessory items / parts not supplied by EMB MFG INC.
5) Damages resulting from:
• misuse, negligence, accident, theft or re
• use of improper or insufcient fuel, uids or lubricants
• use of parts or after market accessories other than genuine EMB MFG INC. parts
• modications, alteration, tampering or improper repair performed by parties other than an authorized dealer
• any device or accessories installed by parties other than an authorized EMB dealer or distributor
Engines are covered by the manufacturer of the engine and covered by the warranty period specied by that manufacturer.
Engine warranty must be registered at the engine manufactures website. For service contact your local engine dealer.
Under no circumstances will the manufacturer be liable for any consequential damage or expense of any kind, including loss
of prots. The manufacturer is under no circumstances liable for tow vehicle of any kind. The manufacturer is not liable for
the maintenance of the product.
This warranty is extended only to the original purchaser and is not transferable. Warranty is void if repairs are attempted by
anyone other than a Wallenstein Authorized Service Centre.
If a difculty develops with the product, contact the local dealer from which you purchased the unit. Only Wallenstein author-
ized dealers are authorized to make repairs to the product or affect the replacement of defective parts, which will be done at
no charge within a reasonable time after the receipt of the product. Unit or parts shall be returned at the customer’s expense
to the Authorized Service Centre. Damage in transit is not covered by warranty. Include the original purchase receipt with
any claim (keep a copy of the receipt for your les).
The distributor’s liability under warranty is limited to the repair of the product and/or replacement of parts and is given to the
purchaser in lieu of all other remedies including incidental and consequential charges. There are no warranties, expressed
or implied, other than those specied herein.
EMB MFG Inc
4144 Boomer Line, St Clements, ON N0B 2M0 Canada
Phone: [phone] Fax: [phone] : attention to Warranty Dept
Email: [email protected]
WARRANTY IS VOID IF NOT REGISTERED
Five (5) Years for Consumer
Two (2) Year for Commercial/Rental
rev.230115

4
Wallenstein
Backup Power Series: WHS12000, WHS12000R,
WHS14000, WHS14000R
Jobsite Rated Series: WCS12000, WCS12000R,
WCS14000, WCS14000R
DELIVERY INSPECTION REPORT
Pre-Delivery Inspection
Inspect for damage from shipping, immediately contact
the shipping company if damage is found.
Portable Generator
Check Electrical Connecons
Check Funcon of Generator
Check that Fasteners are ght
Check Engine Fluid Levels
Review Operang and Safety Instrucons
Safety Checks
All Safety Decals Installed
Guards and Shields Installed and Secured
Test GFCI oulets
Review Operang and Safety Instrucons
To activate warranty, register your product online at
www.embmfg.com
_________________________________________
Customer’s Name
_________________________________________
Contact Name
_________________________________________
Dealer Name
(_________)_______________________________
Phone Number
_________________________________________
Serial Number
__________ /__________ /__________
Delivery Date
I have thoroughly instructed the buyer on the equipment care, adjustments, safe operation and applicable warranty
policy and reviewed the manual.
_________________________________________
Dealer’s Rep. Signature
__________ /__________ /__________
Date
The product manuals have been received by me and I have been thoroughly instructed as to care, adjustments,
safe operation and applicable warranty policy.
_________________________________________
Owner's Signature
__________ /__________ /__________
Date

5
SERIAL NUMBER LOCATION
Always reference the serial number of your Wallenstein generator when ordering parts or requesting service
or other information.
The serial number plate is located where indicated. Please mark the numbers in the spaces provided for
easy reference. (Serial label location is the same for ALL models)
SERIAL NUMBER LOCATION
Backup Power Series or Jobsite Rated Series Portable Gas Generator
Model Number ____________________________________________________
Serial Number ____________________________________________________
Serial Number
Location
LABEL INFORMATION
As you begin to get familiar with your Wallenstein product, you will notice that there are numerous labels located
on the machine. Here is a brief explanation of what they are for and how to read them.
There are three different types of labelling: safety, informative and product labels.
Safety Labels are pictorial with a yellow background and generally 2 panel.
The top panel shows the safety alert (the potential hazard) and the bottom
panel shows the message (how to avoid the hazard).
Safety Notice Labels are pictorial with a blue background and generally
rectangular with single or multiple symbols. The label illustrates requirements
for safe operation (safety equipment, housekeeping etc). These labels are
accompanied by detailed instructions in the owners manual, with the label
illustrated along side.
Informative Labels are generally pictorial with a white background and can vary to the number of panels. The
label will illustrate the function of a feature and is accompanied by detailed instructions in the owners manual,
with the label illustrated along side.
Product Labels are associated with the product and carry various messages (model, serial, etc).
Maintenance Labels are associated with the product and carry various messages. They are generally pictorial.
They may be round or rectangular, have a green background and can vary to the number of panels. The label
may illustrate the type maintenance and frequency in time between services. Labels are accompanied by detailed
instructions in the owners manual, with the label illustrated along side.
See the section on safety signs for safety label denitions. For a complete illustration of labels and label locations,
download the parts manual for your model product at www.embmfg.com.
Z94207
safety alert
message
safety label

6
1 INTRODUCTION
Congratulations on your choice of the Wallenstein Generator. This equipment has been designed and
manufactured to meet the needs of a home owner, business operator or industry that needs electric power
during power outage, at a remote location or any time remote power is needed.
Safe, efcient and trouble free operation of your Wallenstein Generator requires that you and anyone
else who will be using or maintaining the generator, review this Wallenstein Operators manual and
read and understand the Safety, Operation, Maintenance and Trouble Shooting information contained
within this Manual.
All Wallenstein generators are CSA certied and are "neutral bonded to frame" this is a safety feature
that means that the neutral line of the electrical circuit has been bonded to the frame of the generator. The
purpose is to make full advantage of the overcurrent protection device to prevent shocks & electrocution
due to a short circuit from a defective cord or device. In effect this will cause the current from a short circuit
to travel back to the generator and activate the breaker, instead of through a person to ground
The Wallenstein Backup Power Series generator is designed to be a reliable
source of continuous power for the home owner, or recreational use. Utilizing
robust gas powered engines to provide a steady and dependable source of
power, in case of power outage, or when the need arises. The Backup Power
series is intended to be connected directly to the appliance/equipment
requiring electrical power. It is not recommended to connect these
generators to a home electrical system without appropriate equipment and
a qualied electrician to make the connections.
The Wallenstein Jobsite Rated Series generator are designed with the
contractor in mind. Equipped with GFCI protected outlets, these generators
are a safe and dependable source of continuous power on the job site. Small
and portable, the gas powered engines produce a steady and dependable
source of power, for all your power tools. As well having the neutral
conductor bonded to the frame, Jobsite Rated generators feature GFCI
outlet protection, an OSHA requirement when using portable electrical
equipment on job sites.
From home owners, recreational use campers, hunters, snowmobil-
ers, to jobsite contractors, decks, docks, & fence builders, rugged roll-cage frame to stand-up to
jobsite demands, the Wallenstein line-up of generators will get you up and running.
Use the Table of Contents or Index as a guide to locate required information. Keep this manual handy for
frequent reference and to pass on to new operators or owners. Call your Wallenstein dealer or the Distributor
if you need assistance, information or additional copies of the manuals.
OPERATOR ORIENTATION - The directions left, right, front and rear, as mentioned throughout this
manual, are determined when facing the control panel
WHS12000
WHS12000R
WCS14000
WCS1400R
WHS12000
WHS12000R
WCS12000
WCS12000R

7
2 SAFETY
SAFETY ALERT SYMBOL
Why is SAFETY important to you?
The Safety Alert symbol identies
important safety messages on the
Wallenstein Generator and in the
manual. When you see this symbol,
be alert to the possibility of personal
injury or death. Follow the instructions
in the safety message.
This Safety Alert symbol means
ATTENTION! BECOME ALERT!
YOUR SAFETY IS INVOLVED!
Accidents Disable and Kill
Accidents Cost
Accidents Can Be Avoided
3 Big Reasons
If you have any questions not answered in this manual or require additional copies or the manual is damaged,
please contact your dealer or Wallenstein, 4144 Boomer Line, St. Clements, ON, N0B 2M0. Phone (519)
699-9283 or Fax [phone].
DANGER - Indicates an imminently hazardous
situation that, if not avoided, will
result in death or serious injury. This
signal word is to be limited to the
most extreme situations typically
for machine components which,
for functional purposes, cannot be
guarded.
WARNING - Indicates a potentially hazardous
situation that, if not avoided, could
result in death or serious injury, and
includes hazards that are exposed
when guards are removed. It may
also be used to alert against unsafe
practices.
CAUTION - Indicates a potentially hazardous
situation that, if not avoided, may result
in minor or moderate injury. It may
also be used to alert against unsafe
practices.
SIGNAL WORDS:
Note the use of the signal words DANGER,
WARNING and CAUTION with the safety
messages. The appropriate signal word for
each message has been selected using the
following guide-lines:

8
SAFETY
YOU are responsible for the SAFE operation
and maintenance of your Wallenstein Portable
Generator. YOU must ensure that you and anyone
else who is going to use, maintain or work around the
generator be familiar with the use and maintenance
procedures and related SAFETY information
contained in this manual. This manual will take you
step-by-step through your working day and alerts
you to all good safety practices that should be used
while using the Generator.
Remember, YOU are the key to safety. Good
safety practices not only protect you but also
the people around you. Make these practices a
working part of your safety program. Be certain
that EVERYONE using this equipment is familiar
with the recommended use and maintenance
procedures and follows all the safety precautions.
Most accidents can be prevented. Do not risk injury
or death by ignoring good safety practices.
2.1 SAFETY DO'S & DON'TS'
• DO give operating instructions to operators or
employees before allowing them to operate the
machine, and REVIEW annually thereafter.
• DO NOT run a generator indoors, a generator’s
exhaust contains toxic carbon monoxide, which
you cannot smell or see. Breathing carbon
monoxide can be lethal.
• DO read and understand
ALL Safety and Operating
instructions in the manual and
follow them. Most accidents
can be avoided. The most important safety
device on this equipment is a SAFE operator.
• DO NOT expect a person who has not read
and understood all use and safety instructions
to operate the machine. An untrained operator
is not qualified and exposes himself and
bystanders to possible serious injury or death.
It is the owners responsibility to the operator
to ensure familiarity and understanding of the
machine.
• DO NOT modify the equipment in any way.
Unauthorized modification may impair the
function and/or safety and could affect the life
of the equipment.
• DO NOT risk injury or death by ignoring good
safety practices.
• DO review safety related items annually with
all personnel who will operating or maintaining
the generator
• DO have a rst-aid kit available
for use should the need arise
and know how to use it.
• DO read and understand all
safety signs located on the
machine before using, maintaining, adjusting
or cleaning the generator
• DO have a re extinguisher suitable
for electrical res available, should
the need arise and know how to use it.
• DO inspect and secure all guards
before starting.
• DO wear appropriate protective gear. This list
includes but is not limited to:
• Heavy gloves
•Hearing
protection
•Protective shoes
with slip resistant
soles
•Protective
glasses, goggles
or face shield
• DO prepare before servicing, adjusting,
repairing or unplugging:
•stop the machine, disconnect load
•shut off the engine,
•wait for all moving parts to stop
•clear the area of people, especially small
children.
• DO wear suitable ear protection for prolonged
exposure to excessive noise.
• DO operate on dry level ground
away from combustibles.
• DO NOT touch hot engine
parts, mufer, mufer cover,
engine body, engine oil, etc.
during operation and after the engine has been
shut off. Contact may cause burns.
• DO NOT modify the control panel wiring or any
grounding on the generator
• DO think SAFETY! Work SAFELY!

9
2.2 EQUIPMENT SAFETY GUIDELINES
Safety of the operator and bystanders is one of the main concerns in designing and developing equipment.
However, every year many accidents occur which could have been avoided by a few seconds of thought and
a more careful approach to handling equipment. You, the operator, can avoid many accidents by observing
the following precautions in this section. To avoid personal injury or death, study the following precautions
and insist those working with you, or for you, follow them.
1. In order to provide a better view, certain
photographs or illustrations in this manual may
show an assembly with a safety shield removed.
However, equipment should never be used in
this condition. Keep all shields in place. If shield
removal becomes necessary for repairs, replace
the shield prior to use.
2. Replace any safety sign or instruction sign that
is not readable or is missing. Location of such
safety signs is indicated in this manual.
3. Never use alcoholic beverages or drugs which
can hinder alertness or coordination while using
this equipment. Consult your doctor about
using this machine while taking prescription
medications.
4. Under no circumstances should young
children be allowed to work with this
equipment. Do not allow persons to use
this until they have read this manual and
have developed a thorough understanding of
the safety precautions and of how it works.
Review the safety instructions with all users
annually.
5. This equipment is dangerous to children and
persons unfamiliar with its operation. The
operator should be a responsible, properly
trained and physically able person familiar with
machinery and familiar with this equipment's
operations. If the elderly are assisting with work,
their physical limitations need to be recognized
and accommodated.
6. Never exceed the limits of a piece of machinery.
If its ability to do a job, or to do so safely, is in
question - DON'T TRY IT.
7. Never run a generator indoors,
a generator’s exhaust contains
toxic carbon monoxide, which you
cannot smell or see. Breathing
carbon monoxide can be lethal.
8. Do not modify the equipment
in any way. Unauthorized
modication may result in serious
injury or death and may impair the
function and life of the equipment.
9. In addition to the design and conguration
of this equipment, including Safety Signs
and Safety Equipment, hazard control and
accident prevention are dependent upon the
awareness, concern, prudence, and proper
training of personnel involved in the operation,
transport, maintenance, and storage of the
machine. Refer also to Safety Messages and
operation instruction in each of the appropriate
sections of the engine and machine manuals.
Pay close attention to the Safety Signs afxed
to the machine.
10. Safe condition involves the following procedure:
•Flip main switch "off" or disconnect all loads
•Shut off the engine.
•Ensure all components have stopped moving.
Safe Condition procedure should be performed
before any service, maintenance work or
storage preparation.
Z94216

10
2.3 SAFETY TRAINING
1. Train all new personnel and review instructions
frequently with existing workers. Safety is a
primary concern in the design and manufacture
of our products. Unfortunately, our efforts to
provide safe equipment can be wiped out by a
single careless act of an operator or bystander.
2. In addition to the design and conguration
of equipment, hazard control and accident
prevention are dependent upon the awareness,
concern, prudence and proper training of
personnel involved in the operation, transport,
maintenance and storage of this equipment.
3. It has been said, "The best safety feature is an
informed, careful operator."
We ask you to be that kind
of an operator. It is the
operator's responsibility to
read and understand ALL
Safety and Use instructions in the manual and
to follow these. Accidents can be avoided.
4. Working with unfamiliar equipment can
lead to careless injuries. Read this manual
before assembly or using, to acquaint
yourself with the machine. If this machine
is used by any person other than yourself,
or is loaned or rented, it is the machine
owner's responsibility to make certain that
the operator, prior to using:
• Reads and understands the operator's
manuals.
• Is instructed in safe and proper use of
the equipment.
• Understands and knows how to perform
the "safe condition" procedure:
• Flip main switch "off" or disconnect all
loads
• Shut off the engine.
• Ensure all components have stopped
moving.
5. Know your controls and how to stop the engine
and machine quickly in an emergency. Read this
manual and the one provided with your engine.
6. Be certain only a properly trained and physically
able person will use the machinery. A person who
has not read and understood all using and safety
instructions is not qualied to use the machine.
An untrained operator exposes himself and
bystanders to possible serious injury or death.
If the elderly are assisting with the work, their
physical limitations need to be recognized and
accommodated.
2.4 PREPARATION
1. Never use the engine and machine until the
operators have been adequately trained in the
safe operation of the machine and have read
and completely understand:
• Safety, Operation and Feature sections of
this manual,
• Engine Operator's Manual
• Each of the Safety Messages found on the
safety signs on the engine and machine.
2. Personal protection equipment including:
• safety glasses
• safety shoes
• gloves
• hearing protection
are recommended
during assembly,
installation, operation,
adjustment, maintaining, repairing, removal,
cleaning, or moving the generator. Do not allow
long hair, loose tting clothing or jewellery to be
around equipment.
3. PROLONGED EXPOSURE TO LOUD NOISE
MAY CAUSE PERMANENT HEARING LOSS!
Power equipment can often be noisy enough
to cause permanent, partial hearing loss. We
recommend that you wear
hearing protection on a full-
time basis. Noise over 85dB
on a long-term basis can
cause severe hearing loss.
Noise over 90db adjacent to
the Operator over a long-term
basis may cause permanent,
total hearing loss.
4. Clear working area of stones, branches or hidden
obstacles that might be hooked or snagged,
causing injury or damage.
5. Use only in daylight or good articial light.
6. Be sure machine is properly mounted, adjusted
and in good operating condition.
7. Ensure that all safety shielding and safety signs
are properly installed and in good condition.
8. If fuel is on site, store it well away from the
machine and ammable materials.
9. Perform the "PreOperation Checklist" procedure
before starting work.

11
12. When performing
maintenance on this
equipment always have at
least 2 workers present. Do
not work alone in case an
emergency should arise.
13. When cleaning any parts, do not use gasoline
but use regular cleanser.
14. Always use proper tools, that are in good
condition. Make sure you understand how to
use them, before performing any service work.
2.6 BATTERY SAFETY
1. Wear gloves and safety glasses or face shield
when working on or near batteries.
2. Use a battery carrier to lift the battery or place
hands at opposite corners to avoid spilling
acid through the vents.
3. Avoid contact with battery electrolyte:
External Contact: Flush immediately with
water.
Eye Contact: Flush with water for 15 minutes.
Get prompt medical attention. Clean up any
spilled electrolyte immediately.
4. Avoid contact with battery posts, terminals
and related accessories, they contain lead
and lead compounds, chemicals known to
cause harm. Wash hands immediately after
handling battery.
5. Keep all sparks and ames away from batter-
ies, as gas given off by electrolyte is explo-
sive.
6. To avoid injury from spark or
short circuit, disconnect battery
ground cable before servic-
ing any part of the electrical
system.
7. FROZEN BATTERIES CAN
EXPLODE and result in death
or serious injury. DO NOT jump
start / charge a frozen battery.
Let battery thaw before charg-
ing.
8. DO NOT use or charge the battery if its uid
level is below the LOWER mark.
2.5 MAINTENANCE SAFETY
1. Good maintenance is your responsibility. Poor
maintenance is an invitation to trouble.
2. Follow good shop
practices.
• Keep service area
clean and dry.
• Be sure electrical
outlets and tools are
properly grounded.
• Use adequate light for
the job at hand.
3. Make sure there is plenty of ventilation. Never
operate the machine or the towing vehicle in a
closed building. The exhaust fumes may cause
asphyxiation.
4. Put the machine in safe condition before
working on this machine:
•Flip main switch "off" or disconnect all loads
•Shut off the engine.
•Ensure all components have stopped moving.
5. Allow the engine to cool before performing
maintenance, engine components and oil may
be hot enough to cause injury.
6. Never work under equipment unless it is blocked
securely.
7. When performing any service or maintenance
work always use personal protection devices
such as
• safety glasses,
• hand protection - gloves
• hearing protectors
• safety shoes
8. Where replacement parts are necessary for
periodic maintenance and servicing, genuine
factory replacement parts must be used to restore
your equipment to original specications. The
manufacturer will not be responsible for injuries
or damages caused by use of unapproved parts
and/or accessories.
9. An appropriate re extinguisher (electrical res)
and rst aid kit should be kept readily accessible
while performing maintenance on this equipment.
10. Inspect and tighten all bolts, nuts and screws
and check that all electrical and fuel connections
are properly secured to ensure generator is in
a safe condition.
11. When completing a maintenance or service
function, make sure all safety shields and devices
are installed before placing the generator in
service.
Caution: Poison / Danger - Causes
Severe Burns. The battery contains
sulphuric acid. Avoid contact with skin,
eyes or clothing. Keep out of reach of
children.

12
2.8 OPERATING SAFETY
1. Please remember it is important that you read
and heed the safety signs on the generator.
Clean or replace all safety signs if they cannot
be clearly read and understood. They are there
for your safety, as well as the safety of others.
The safe use of this machine is strictly up to
you, the operator.
2. All things with moving parts are potentially
hazardous. There is no substitute for a cautious,
safe-minded operator who recognizes potential
hazards and follows reasonable safety practices.
The manufacturer has designed this generator
to be used with all its safety equipment properly
attached, to minimize the chance of accidents.
Read and understand operator's manual before
starting, to make sure you have all safety
equipment attached and operational.
3. Close and secure all covers, guards, deectors
and shields before starting and
operating.
4. Never run a generator indoors,
a generator’s exhaust contains
toxic carbon monoxide, which you
cannot smell or see. Breathing
carbon monoxide can be lethal.
5. Do not operate near openings to
any building that can be occupied
in order to help avoid the exhaust
hazard.
6. Personal protection equipment including hearing
protection, safety glasses, safety shoes, and
gloves are recommended during assembly,
installation, operation, adjustment, maintaining,
repairing, removal, or moving.
7. Inspect electrical harness, and controller to
ensure they are in good condition before
operating to maintain control.
8. Keep the generator dry. Operate on a dry surface
under an open well ventilated, covered structure.
9. Never use alcoholic beverages or drugs which
can hinder alertness or coordination while
operating this equipment. Consult your doctor
about operating this machine while taking
prescription medications.
10. Never allow children or unauthorized people to
operate or be around this machine.
11. Plug appliances directly into generator or use a
heavy-duty outdoor-rated extension cord. Make
sure entire extension cord is free of cuts or
tears and the plug has all 3 prongs, especially
a grounding pin.
12. If necessary to connect generator
to house wiring to power
appliances, have a qualified
electrician install appropriate
equipment. Or, your utility
company may be able to install
an appropriate transfer switch.
13. Keep the working area clean and
free of debris to prevent tripping.
Operate only on level ground.
14. Parts of a generator become very hot during
operation and remain hot for a time after
stopping the engine. Be careful not to touch the
mufer while it is hot. Let the engine cool before
storing the generator indoors.
15. To prevent a possible re, keep the generator at
least 3 feet (1 meter) away from building walls
and other equipment during operation. Do not
place ammable objects close to the engine.
16. NEVER plug the generator into a wall outlet.
This practice, known as backfeeding, can cause
an electrocution risk to utility workers and others
served by the same utility transformer.
Z94216
Z94222
2.7 REFUELING SAFETY
1. Allow the engine to cool if the
generator has been in operation.
2. Refuel only outdoors in a well-
ventilated area with the engine off.
3. Never smoke near fuel, and keep
other ames and sparks away.
4. Do not overll the fuel tank.
5. Always store fuel in an approved container.
Make sure that any spilled fuel has been wiped
up before starting the engine.

13
2.11 ELECTRICAL SAFETY
1. The generator produces enough
electric power to cause a serious
shock or electrocution if misused.
2. Using a generator or electrical
appliance in wet conditions
(rain or snow), or near a pool
or sprinkler system, or when
your hands are wet, could
result in electrocution. Keep the
generator and the immediate
area dry.
3. If the generator has been outdoors, unprotected
from the weather, check all of the electrical
components on the control panel before
each use. Moisture can cause a short circuit
in electrical components that could result in
electrocution.
4. Do not connect to a building’s electrical system
unless an transfer / isolation switch has been
installed by a qualied electrician.
5. NEVER tamper with the factory settings of
the engine or engine governor. Engine speed
controls the frequency portion of the electrical
output (60hZ). Personal injury or damage to the
engine or equipment can result if operating in
speed ranges above the maximum or below the
minimum allowable.
2.10 STORAGE SAFETY
1. Store the unit in a well vented area away from
human activity.
2. If possible, store in a dry area, avoid storage
areas with high humidity, because that promotes
rust and corrosion.
3. Avoid any area where power tools are operated
or spark-producing electric motors.
4. Do not allow children to play on or around the
stored machine.
5. Place the generator on a level surface. Tilting or
laying it on its side can cause fuel or oil leakage.
Support the frame with planks if required.
6. Allow the engine / exhaust to cool. A hot engine
and exhaust system can ignite or melt some
materials.
7. With the engine and exhaust system cool, cover
the generator to keep out dust.
8. Do not use a nonporus sheet as a dust cover. A
nonporous cover will trap moisture around the
generator, promoting rust and corrosion.
Z94221
2.9 TRANSPORT SAFETY
1. Comply with Provincial / state and local laws
governing safety and transporting of machinery
on public roads.
2. Do not exceed a safe travel speed. Slow down
for rough terrain and cornering.
3. Do not transport or move the generator with the
engine running.
4. Inspect all access panels and guards to ensure
they are secured.
5. If the generator has been running, allow the
engine to cool for at least 15 minutes before
loading the generator on the transport vehicle.
A hot engine and exhaust system can burn you
and may ignite some materials.
6. Ensure the fuel tank cap is on tight and keep the
generator level when transporting to reduce the
possibility of fuel leakage.
7. Move the fuel valve lever to the OFF position.
8. When using ropes or tie-down straps to secure
the generator for transportation, be sure to only
use the frame bars as attachment points. Do
not fasten ropes or straps to any portions of the
generator body.
9. Do not drink and drive.
10. Just before transport, perform a circle check to
ensure everything is safe and secure.

14
2.12 GAS MOTOR SAFETY
BEFORE STARTING ENGINE, READ
AND UNDERSTAND THE OPERATING
AND MAINTENANCE INSTRUCTIONS
THAT CAME WITH YOUR ENGINE.
WARNING: DO NOT
1. DO NOT run engine in an enclosed area.
Exhaust gases contain carbon monoxide, an
odourless and deadly poison.
2. DO NOT place hands or feet near moving or
rotating parts.
3. DO NOT store, spill, or use gasoline near an
open ame, or devices such as a stove, furnace,
or water heater which use a pilot light or devices
which can create a spark.
4. DO NOT refuel indoors where area is not well
ventilated. Outdoor refuelling is preferred.
5. DO NOT refuel while engine is running. Allow
engine to cool for 5 minutes before refuelling.
Store fuel in approved safety containers.
6. DO NOT remove fuel tank cap while engine is
running.
7. DO NOT operate engine if gasoline is spilled.
Move machine away from the spill and
avoid creating any ignition until gasoline has
evaporated.
8. DO NOT smoke while lling fuel tank.
9. DO NOT choke carburetor to stop engine.
Whenever possible, gradually reduce engine
speed before stopping.
10. DO NOT run engine above rated speeds. This
may result in injury.
11. DO NOT tamper with governor springs,
governor links or other parts which may
increase the governed speed.
12. DO NOT tamper with the engine speed selected
by the original equipment manufacturer.
13. DO NOT check for spark with spark plug or
spark plug wire removed.
14. DO NOT crank engine with spark plug removed.
If engine is ooded, crank until engine starts.
15. DO NOT strike ywheel with a hard object or
metal tool as this may cause ywheel to shatter
in operation. Use proper tools to service engine.
16. DO NOT operate engine without a mufer.
Inspect periodically and replace, if necessary.
If engine is equipped with a mufer deector,
inspect periodically and replace, if necessary
with correct deector.
17. DO NOT operate engine with an accumulation
of grass, leaves, dirt or other combustible
materials in the mufer area.
18. DO NOT use this engine on any forest covered,
brush covered, or grass covered unimproved
land unless a spark arrester is installed on
the mufer. The arrester must be maintained
in effective working order by the operator. In
the state of California the above is required
by law (Section 4442 of the California Public
Resources Code). Other states may have
similar laws. Federal laws apply on federal land.
19. DO NOT touch hot mufer, cylinder or ns
because contact may cause burns.
20. DO NOT run engine with air cleaner or air
cleaner cover removed.
WARNING: DO
1. ALWAYS DO remove the wire from the spark
plug when servicing the engine or equipment
to prevent accidental starting. Disconnect
the negative wire from the battery terminal if
equipped with a 12 volt starting system.
2. DO keep cylinder ns and governor parts free of
grass and other debris which can affect engine
speed.
3. DO examine mufer periodically to be sure it is
functioning effectively. A worn or leaking mufer
should be repaired or replaced as necessary.
4. DO use fresh gasoline. Stale fuel can gum
carburetor and cause leakage.
5. DO check fuel lines and ttings frequently for
cracks or leaks. Replace if necessary.

15
2.13 SIGN-OFF FORM
Wallenstein follows the general Safety Standards specied by the American Society of Agricultural and
Biological Engineers (ASABE) and the Occupational Safety and Health Administration (OSHA). Anyone
who will be using and/or maintaining the Portable Generator must read and clearly understand ALL Safety,
Usage and Maintenance information presented in this manual.
Do not use or allow anyone else to use this generator until such information has been reviewed. Annually
review this information before the season start-up.
Make these periodic reviews of SAFETY and OPERATION a standard practice for all of your equipment.
We feel that an untrained operator is unqualied to use this machine.
A sign-off sheet is provided for your record keeping to show that all personnel who will be working with the
equipment have read and understand the information in the Operator’s Manual and have been instructed
in the operation of the equipment.
EMPLOYEES SIGNATURE EMPLOYERS SIGNATURE
SIGN-OFF FORM
DATE

16
3 SAFETY SIGNS
1. Keep safety signs clean and legible at all times,
2. Replace safety signs that are missing or have become illegible.
3. Replaced parts that displayed a safety sign should also display the current sign.
4. Safety signs in Section 3 each have a part number displayed with it. Use this part number when ordering
replacement parts.
5. Safety signs are available from your authorized Distributor or Dealer Parts Department or the factory.
Z94222
Z94221
Danger: Never run a
generator indoors, a
generator’s exhaust contains
toxic carbon monoxide,
which you cannot smell
or see. Breathing carbon
monoxide can be lethal.
Caution: Parts of a generator become
very hot during operation and remain hot
for a time after stopping the engine. Be
careful not to touch the mufer while it is
hot. Let the engine cool before storing the
generator indoors.
Caution: A generator produces enough
electrical power to cause serious shock
or electrocution. Using a generator in
wet conditions such as in rain or snow,
, or with wet hands could result in
electrocution. Keep the generator dry.
Caution: Do not refuel the machine
while smoking or when near open ame
or sparks. Fuel is highly ammable,
handle with care.
Caution: Read and understand ALL
safety and operating instructions in
the manual, read and understand ALL
safety labels located on the machine.
The most important safety device on this
equipment is an informed SAFE operator.
3.2 SAFETY SIGN EXPLANATIONS:
3.1 HOW TO INSTALL SAFETY SIGNS:
• Be sure that the installation area is clean and dry.
• Be sure temperature is above 50°F (10°C).
• Determine exact position before you remove the backing paper.
• Remove the smallest portion of the split backing paper.
• Align the sign over the specied area and carefully press the small portion with the exposed sticky
backing in place.
• Slowly peel back the remaining paper and carefully smooth the remaining portion of the sign in place.
• Small air pockets can be pierced with a pin and smoothed out using the piece of sign backing paper.
NEVER use inside a home or
garage, EVEN IF doors and
windows are open.
N'employerJAMAIS dans la
maisonoudans dessecteurs
partiellement inclustelsque des
garages,MÊMESIles portes et
lesfenetressoientouvertes.
Only use OUTSIDE and far
away from windows, doors,
and vents.
Employer seulemer DEHORS
et loin de fenêtres, desporte
et des ventilateurs.
DANGER!
Using a generator indoors CAN KILL YOU IN MINUTES. Generator
Exhaust contains carbon monoxide. This is a poison you cannot see
or smell.
L'utilisation d'un générateur àl'intérieur PEUT VOUS FAIRE MOURIR
EN MINUTES. L'échappement contient le monoxyde de carbone,
Ceci est un toxiqueque vous ne pouveznivoirni sentir.
Z94225
NEUTRAL BONDED TO FRAME
NEUTRE RACCORDÉ AU BÂTI
Z94170
Note: This is a
safety feature and
indicates that the
neutral line of the electrical circuit has been
bonded to the frame of the generator.

17
REMEMBER - If safety signs have been damaged, removed, become illegible or parts replaced without
safety signs, new signs must be applied. New safety signs are available from your authorized dealer.
3 SAFETY SIGN LOCATIONS
The types of safety signs and locations on the equipment are shown in the illustrations that follow. Good
safety requires that you familiarize yourself with the various safety signs, the type of warning and the area,
or particular function related to that area, that requires your SAFETY AWARENESS.
• Think SAFETY! Work SAFELY!
Z94221
Z94216
Z94222
Z94215
!
0°
NEVER use inside a home or
garage, EVEN IF doors and
windows are open.
N'employerJAMAIS dans la
maisonoudans dessecteurs
partiellement inclustelsque des
garages,MÊMESIles portes et
les fenetressoientouvertes.
Only use OUTSIDE and far
away from windows, doors,
and vents.
Employer seulemer DEHORS
et loin de fenêtres, desporte
et des ventilateurs.
DANGER!
Using a generator indoors CAN KILL YOU IN MINUTES. Generator
Exhaust contains carbon monoxide. This is a poison you cannot see
or smell.
L'utilisationd'ungénérateur àl'intérieur PEUT VOUS FAIRE MOURIR
EN MINUTES. L'échappement contient le monoxyde de carbone,
Ceci est un toxiqueque vous ne pouvez ni voir ni sentir.
Z94225
Z94252
Z94252 On Both Sides

18
4 OPERATION & FEATURES
The Wallenstein Portable Generators are designed
to provide portable electrical power to equipment
that is not connected to the electrical grid system.
It is the responsibility of the owner or operator
to read this manual and to train all other
operators before they start working with the
machine. Follow all safety instructions exactly.
Safety is everyone's business. By following
recommended procedures, a safe working
environment is provided for the operator,
bystanders and the area around the work site.
Untrained operators are not qualied to use the
machine.
Many features incorporated into this machine are
the result of suggestions made by customers like
you. Read this manual carefully to learn how to use
the Generator safely and how to set it to provide
maximum field efficiency. By following these
instructions in conjunction with a good maintenance
program, your Portable Generator will provide many
years of trouble-free service.
4.1.1 SAFE CONDITION
Ensure all operators understand how to put the
machine in safe condition before working with
this machine,
•Flip main switch "off" or disconnect all loads.
•Shut off the engine.
•Ensure all components have stopped moving.
4.1 TO THE NEW OPERATOR OR OWNER
OPERATING SAFETY
• Read and understand operator's manual before
starting. Review safety instructions annually.
• Stop and disable engine, and wait for all moving
parts to stop before servicing, adjusting or
repairing.
• To prevent electrical shocks, do not operate
this generator in the rain or with wet hands.
Generator should be kept dry and not operated
on wet or damp surfaces.
• Close and secure all guards, deectors and
shields before starting and operating.
• Do not connect the generator to a commercial
power line.
• Do not operate with damaged or defective
extension cords, or power cords. Protect
the cord from getting pinched or crushed if it
passes through a window or doorway.
• Use properly rated, grounded 3-prong
extension cords, tools, and appliances.
• Do not operate this generator indoors, or
in areas with poor ventilation. The exhaust
fumes contain carbon monoxide, a poisonous,
odourless, invisible gas. Prolonged exposure
can lead to unconsciousness and death.
• Do not refuel the engine while it is in operation
or still hot. Do not refuel the engine near
open ames, pilot lights or sparking electrical
devices (e.g. power tools, welders or grinders).
• To prevent a possible re, keep the generator
at least 1 meter (3 feet) away from building
walls and other equipment during operation.
• Do not place ammable objects close to the
engine.
• The engine should be refuelled in a well-lit,
adequately vented area. Avoid fuel spillage.
• Never allow children or unauthorized people
to operate or be around this machine.
• Keep the working area clean and free of
debris to prevent tripping. Operate only on
level ground.
• Do not cover the generator while in operation.
Overheating can result in damaged equipment.
• For storage, do not cover the generator until
it has cooled down completely.
• The ambient temperature should not exceed
100° F/40° C.
DO NOT attempt to crank or start the engine
before it has been properly lled with the recommended amount and type of oil.

19
4.2 MACHINE COMPONENTS
Wallenstein Portable Generators consists of several
models of generators. Although slightly different
for each model, controls and power outlets are
mounted in similar locations for convenient access
and operation.
The unit is designed to provide electrical power
for work (Jobsite Rated series) or home (Backup
Power series). Each outlet is designed with a circuit
breaker to protect against overload. For protection
against electrical shocks from short circuits, the
machine is neutral bonded to the frame. The entire
assembly is mounted within the frame for added
protection and convenient access.
Series Model
Engine
cc
Alternator
kW
Continuous
wattage
Maximum
wattage
WHS12000 688cc 12 1000012000
WHS12000R 688cc 12 1000012700
WHS14000 688cc 14.4 1200012800
WHS14000R 688cc 14.4 1200013900
WCS12000 688cc 12 1000012000
WCS12000R 688cc 12 1000012700
WCS14000 688cc 14.4 12000 12800
WCS14000R 688cc 14.4 1200013900
Note:
All Wallenstein generators are CSA certied and have the safety feature
of the neutral conductor bonded to the frame, an OSHA requirement when
using portable electrical equipment on job sites.
Circuit
Breaker
Outlets
Frame
Engine
See "Controls" section
and engine owners
manual for more
engine information.

20
4.3 MACHINE BREAK-IN
Although there are no operational restrictions on the
portable generator when used for the rst time, it is
recommended that the following mechanical items
be checked:
A. After operating for 1 hour:
1. Ensure the machine is in safe condition
before checking any components. (see
4.1.1)
2. Review the engine operators manual for
break-in.
3. Inspect the axle, tires, and wheels.
4. Torque all fasteners and hardware.
5. Check that the alternator cooling air intake
and discharge openings are free and
unblocked
6. Check condition of electrical components
and connectors. Keep all components /
connectors in good condition.
B. After operating for 8 hours:
1. Repeat steps 1 through 6 listed above.
(Section A)
2. Go to the normal servicing and maintenance
schedule as dened in the Maintenance
Section.
4.4 PREOPERATION CHECKLIST
Efcient and safe operation of the Wallenstein
Portable Generator requires that each operator
reads and understands the use procedures and all
related safety precautions outlined in this section.
A PreOperation checklist is provided for the
operator. It is important for both the personal safety
and maintaining good mechanical condition that this
checklist is followed.
Before operating the Wallenstein Portable Generator
and each time thereafter, the following areas should
be checked off:
Pre-Operation Checklist P
Check and lubricate the machine per the schedule outline
in the Maintenance Section.
Exhaust gas contains poisonous carbon monoxide. Never
run the generator in an enclosed area. Be sure there is
adequate ventilation in the work area.
Check all electrical connections. Replace, repair or clean
as required.
Make sure that all lids, guards and shields are in place,
secured and functioning as designed.
Check condition of the battery and other electrical
components. Keep all components in good condition.
Check the fuel level, Starting with a full tank will help to
eliminate or reduce operating interruptions for refueling.
Check engine fluid levels. Top up as required. Refer to the
engine operators manual.
Check the air filter
Check all power cords that will be used, ensure they are in
good repair.
Check that the alternator cooling air intake and discharge
openings are free and unblocked
Air Discharge
Air Intake
Ensure alternator openings
are free and unblocked
DO NOT attempt to crank or start the engine
before it has been properly lled with the
recommended amount and type of oil.
