942-101 Switch Machine © 2017 Wm K Walthers Inc Milwaukee WI 53218 rinted in China 10
1) Temporarily mount turnout using the centering yoke to lock points at center.
2) Use #57 bit (from 942-140 Drill Set) and drill hole in center of throwbar through
roadbed and benchwork.
3) Drill two alignment holes on throwbar centerline. For Walthers Code 83, Shinohara,
Atlas Code 83, and eco Code 83 use the two outer holes in the throwbar as a
guide. These holes are used to transfer the throwbar alignment to the bottom of the
benchwork and later will be covered with ballast or scenery.
4) Remove the turnout, then from under the benchwork, draw a center line between
and beyond the alignment holes drilled earlier.
5) Using the #57 bit, a small nail or a map pin, poke a hole thru the center point of the
supplied mounting template. eel the backing from the template and use the pin to
locate the center point with the center hole drilled in step two. Orient the template
so the alignment line matches the center line drawn in step 4 and press into place.
6) Use #43 bit (from the 942-140 Drill Set) drill pilot holes for the four mounting
screws. You may also drill out the center hole with the 3/16” drill from the drill set to
facilitate the next step.
7) Drill up from the bottom with the stepped bit from the 942-140 Drill Set to enlarge
the center hole to sufficient clearance (3/8 ” / 9 mm for HO) at the top surface.
The hole may be larger on the bottom due to the steps in the bit.
8) Clean up the center hole on the top of the benchwork, then reinstall the turnout
leaving the centering yoke in place. (Continued on other side)
942
942942
942-
--
-101 SWITCH MACHINE
101 SWITCH MACHINE 101 SWITCH MACHINE
101 SWITCH MACHINE
MOUNTING INSTRUCTIONS
MOUNTING INSTRUCTIONSMOUNTING INSTRUCTIONS
MOUNTING INSTRUCTIONS
WALTHERS® !
!!
!

WALTHERS® !
!!
!
REMOVE CENTER
REMOVE CENTER REMOVE CENTER
REMOVE CENTER
JUM ER FOR NORMAL
JUM ER FOR NORMAL JUM ER FOR NORMAL
JUM ER FOR NORMAL
O ERATION
O ERATIONO ERATION
O ERATION
USE 942
USE 942USE 942
USE 942-
--
-113 EXTENSION CABLES (U TO 4) TO EXTEND
113 EXTENSION CABLES (U TO 4) TO EXTEND 113 EXTENSION CABLES (U TO 4) TO EXTEND
113 EXTENSION CABLES (U TO 4) TO EXTEND
OWER AND FASCIA CONNECTIONS AS NEEDED
OWER AND FASCIA CONNECTIONS AS NEEDEDOWER AND FASCIA CONNECTIONS AS NEEDED
OWER AND FASCIA CONNECTIONS AS NEEDED
For complete details on mounting, electrical connections, switch machine adjustments,
For complete details on mounting, electrical connections, switch machine adjustments, For complete details on mounting, electrical connections, switch machine adjustments,
For complete details on mounting, electrical connections, switch machine adjustments,
options and warranty information, see the Switch Machine Reference Guide at
options and warranty information, see the Switch Machine Reference Guide at options and warranty information, see the Switch Machine Reference Guide at
options and warranty information, see the Switch Machine Reference Guide at
walthers.com/products/walthers
walthers.com/products/waltherswalthers.com/products/walthers
walthers.com/products/walthers-
--
-control
controlcontrol
control-
--
-system
systemsystem
system.
..
.
(continued from other side)
9) With switch machine in center position, insert actuator wire though subroadbed and
up thru the center hole in the throwbar. Center the machine, align with template
and secure with screws supplied.
10) With power off, connect power input and fascia control cables to the switch machine
as shown. Remove the center jumper. See Switch Machine Reference Guide for
complete information on electrical connections.
11) Remove the centering yoke from the turnout and apply power. Switch machine will
stay at center on first power up after center jumper is removed.
12) Use the fascia control to cycle the switch machine from Normal to Reverse.
13) Check turnout points for proper travel and holding tension. Adjust output arm as
detailed in the Switch Machine Reference Guide if required. The actuator travel is
infinitely adjustable from 2 mm to 13 mm (1/16” to 1/2“) to accommodate a wide
variety of scales, turnouts, and roadbed dimensions.
14) When satisfied with switch machine operation, finish the turnout mounting. Wear
proper eye protection and remove any excess actuator wire above the throwbar
with a cut-off disk or hard wire cutting pliers.
15) Make electrical connections to aux switches as desired to complete installation.
CONNECT IN UT OWER
CONNECT IN UT OWER CONNECT IN UT OWER
CONNECT IN UT OWER
FROM 942
FROM 942FROM 942
FROM 942-
--
-111
111 111
111
DISTRIBUTION BLOCK
DISTRIBUTION BLOCKDISTRIBUTION BLOCK
DISTRIBUTION BLOCK
942
942942
942-
--
-101 SWITCH MACHINE
101 SWITCH MACHINE 101 SWITCH MACHINE
101 SWITCH MACHINE
ELECTRICAL CONNECTIONS
ELECTRICAL CONNECTIONSELECTRICAL CONNECTIONS
ELECTRICAL CONNECTIONS
CONNECT 942
CONNECT 942CONNECT 942
CONNECT 942-
--
-121,
121,121,
121,
942
942942
942-
--
-122, or 942
122, or 942122, or 942
122, or 942-
--
-123
123 123
123
FASCIA CONTROLLERS
FASCIA CONTROLLERS FASCIA CONTROLLERS
FASCIA CONTROLLERS
TO STD IN UT
TO STD IN UTTO STD IN UT
TO STD IN UT
