HP FlexNetwork 5140 EI Series User manual

HPE FlexNetwork 5140 EI Switch Series
Installation Guide
P
art number: 5200-7780a
Document version: 6W101-20210706

© Copyright 2021 Hewlett Packard Enterprise Development LP
The information contained herein is subject to change without notice. The only warranties for Hewlett Packard
Enterprise products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett
Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or
copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software
Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under vendor’s
standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard
Enterprise has no control over and is not responsible for information outside the Hewlett Packard Enterprise
website.
Acknowledgments
Intel®, Itanium®, Pentium®, Intel Inside®, and the Intel Inside logo are trademarks of Intel Corporation in the
United States and other countries.
Microsoft® and Windows® are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
Adobe® and Acrobat® are trademarks of Adobe Systems Incorporated.
Java and Oracle are registered trademarks of Oracle and/or its affiliates.
UNIX® is a registered trademark of The Open Group.

i
Contents
Preparing for installation················································································1
Safety recommendations ···································································································································2
Examining the installation site····························································································································2
Temperature/humidity································································································································2
Cleanliness·················································································································································3
Corrosive gas limit······································································································································3
EMI·····························································································································································4
Laser safety················································································································································4
Installation tools ·················································································································································5
Installation accessories······································································································································5
Installing the switch························································································7
Installing the switch in a 19-inch rack·················································································································8
Mounting brackets······································································································································8
Attaching the mounting brackets to the switch···························································································9
Rack-mounting the switch························································································································10
Mounting the switch on a workbench···············································································································12
Mounting the switch on a wall··························································································································12
Grounding the switch ·······································································································································14
Grounding the switch with a grounding strip····························································································14
Grounding the switch with a grounding conductor buried in the earth ground·········································15
Installing and removing power supplies···········································································································16
Installing a power supply··························································································································17
Removing a power supply························································································································17
Connecting the power cord······························································································································18
Connecting the AC power cord for the fixed AC power supply································································18
Connecting the DC power cord for the fixed DC power supply································································19
Connecting the power cord for a PSR150-A1 power supply····································································20
Connecting the power cord for a PSR150-D1 power supply····································································21
Verifying the installation···································································································································22
Accessing the switch for the first time··························································23
Setting up the configuration environment ········································································································23
Connecting the serial console cable ················································································································23
Connecting the micro USB console cable········································································································24
Setting terminal parameters·····························································································································26
Powering on the switch····································································································································26
Setting up an IRF fabric···············································································28
IRF fabric setup flowchart ································································································································28
Planning IRF fabric setup·································································································································29
Planning IRF fabric size and the installation site······················································································29
Identifying the master switch and planning IRF member IDs···································································29
Planning IRF topology and connections···································································································29
Identifying IRF physical ports on the member switches···········································································30
Planning the cabling scheme···················································································································31
Configuring basic IRF settings·························································································································32
Connecting the IRF physical ports···················································································································33
Verifying the IRF fabric setup···························································································································33
Maintenance and troubleshooting································································34
Fixed power supply failure ·······························································································································34
Symptom··················································································································································34
Solution····················································································································································34
Removable power supply failure······················································································································34
Symptom··················································································································································35
Solution····················································································································································35

ii
Fan tray failure·················································································································································35
Symptom··················································································································································35
Solution····················································································································································35
Configuration terminal issues···························································································································35
No display on the configuration terminal··································································································35
Garbled display on the configuration terminal··························································································36
Technical specifications···············································································37
Non-PoE switch models···································································································································37
PoE switch models···········································································································································39
Chassis views······························································································42
HPE 5140 8G 2SFP 2GT Combo EI················································································································42
HPE 5140 24G 4SFP+ EI ································································································································42
HPE 5140 48G 4SFP+ EI ································································································································43
HPE 5140 24G SFP w/8G Combo 4SFP+ EI ··································································································44
HPE 5140 24G 2SFP+ 2XGT EI······················································································································45
HPE 5140 24G PoE+ 4SFP+ EI ······················································································································45
HPE 5140 48G PoE+ 4SFP+ EI ······················································································································46
HPE 5140 24G PoE+ 2SFP+ 2XGT EI············································································································47
HPE 5140 48G PoE+ 2SFP+ 2XGT EI············································································································47
Removable components··············································································49
Ports and LEDs ···························································································49
Ports·································································································································································49
Console port·············································································································································49
Management Ethernet port ······················································································································50
10/100/1000BASE-T autosensing Ethernet port······················································································50
10/5/2.5/1GBASE-T autosensing Ethernet port·······················································································51
SFP port···················································································································································51
SFP+ port·················································································································································54
Combo interface·······································································································································55
LEDs ································································································································································55
System status LED···································································································································55
Management Ethernet port LED ··············································································································56
Power supply status LED·························································································································56
RPS status LED·······································································································································56
Mode LED (MODE)··································································································································57
SFP/SFP+ port LED·································································································································57
Ethernet port LEDs···································································································································57
Support and other resources ·······································································59
Accessing Hewlett Packard Enterprise Support·······························································································59
Accessing updates···········································································································································59
Websites ··················································································································································59
Customer self repair·································································································································60
Remote support········································································································································60
Documentation feedback ·························································································································60
Index············································································································61

1
Preparing for installation
Table 1 describes the HPE FlexNetwork 5140 EI switches, power supplies,and interface cards
available for the switches.
Table 1 HPE 5140 EI switch models and power supplies
Product code
HPE description
Alias
HPE 5140 EI switches
JL828A HPE FlexNetwork 5140 24G 4SFP+ EI Switch HPE 5140 24G 4SFP+ EI
JL826A HPE FlexNetwork 5140 24G SFP w/8G Combo
4SFP+ EI Switch HPE 5140 24G SFP w/8G Combo 4SFP+ EI
JL829A HPE FlexNetwork 5140 48G 4SFP+ EI Switch HPE 5140 48G 4SFP+ EI
JL827A HPE FlexNetwork 5140 24G PoE+ 4SFP+ EI
Switch HPE 5140 24G PoE+ 4SFP+ EI
JL824A HPE FlexNetwork 5140 48G PoE+ 4SFP+ EI
Switch HPE5140 48G PoE+ 4SFP+ EI
JL823A HPE FlexNetwork 5140 24G PoE+ 2SFP+ 2XGT
EI Switch HPE 5140 24G PoE+ 2SFP+ 2XGT EI
JL825A HPE FlexNetwork 5140 48G PoE+ 2SFP+ 2XGT
EI Switch HPE 5140 48G PoE+ 2SFP+ 2XGT EI
R8J41A HPE FlexNetwork 5140 24G 2SFP+ 2XGT EI
Switch HPE 5140 24G 2SFP+ 2XGT EI
R8J42A
HPE FlexNetwork 5140 8G 2SFP 2GT Combo EI
Switch HPE 5140 8G 2SFP 2GT Combo EI
Power supplies
JD362B HPE X361 150W AC Power Supply PSR150-A1
JD366B HPE X361 150W DC Power Supply PSR150-D1
For regulatory identification purposes, the HPE FlexNetwork 5140 EI switches are assigned
Regulatory Model Number (RMN), which are listed in the following table. These regulatory numbers
should not be confused with the marketing name HPE FlexNetwork 5140 EI, or the product codes.
Product code
RMN
HPE description
JL826A BJNGA-AD0088 HPE FlexNetwork 5140 24G SFP w/8G Combo 4SFP+ EI
Switch
JL829A BJNGA-AD0091 HPE FlexNetwork 5140 48G 4SFP+ EI Switch
JL828A BJNGA-AD0090 HPE FlexNetwork 5140 24G 4SFP+ EI Switch
JL827A BJNGA-AD0089 HPE FlexNetwork 5140 24G PoE+ 4SFP+ EI Switch
JL824A BJNGA-AD0086 HPE FlexNetwork 5140 48G PoE+ 4SFP+ EI Switch
JL823A BJNGA-AD0085 HPE FlexNetwork 5140 24G PoE+ 2SFP+ 2XGT EI Switch
JL825A BJNGA-AD0087 HPE FlexNetwork 5140 48G PoE+ 2SFP+ 2XGT EI Switch
R8J41A BJNGA-AD0100 HPE FlexNetwork 5140 24G 2SFP+ 2XGT EI Switch
R8J42A BJNGA-AD0099 HPE FlexNetwork 5140 8G 2SFP 2GT Combo EI Switch

2
NOTE:
The available chassis models and
accessories
vary by country and region. This document describes
only the preceding models. For the chassis models and
accessories available in your country or
region, contact the local HPE marketing personnel.
Safety recommendations
To avoid equipment damage or bodily injury, read the following safety recommendations before
installation. Note that the recommendations do not cover every possible hazardous condition.
•
Before cleaning the switch, remove all power cords from the switch. Do not clean the switch
with wet cloth or liquid.
•
Do not place the switch near water or in a damp environment. Prevent water or moisture from
entering the switch chassis.
•
Do not place the switch on an unstable case or desk.
•
Ensure good ventilation at the installation site and keep the air inlet and outlet vents of the
switch free of obstruction.
•
Connect the yellow-green protection grounding cable before power-on.
•
Make sure the power source voltage is as required.
•
To avoid electrical shocks, do not open the chassis while the switch is operating or when the
switch is just powered off.
•
To avoid ESD damage, wear an ESD wrist strap to hot-swap a power supply.
Examining the installation site
The switch must be used indoors. You can mount your switch in a rack or on a workbench, but make
sure:
•
Adequate clearance is reserved at the air inlet and exhaust vents for ventilation.
•
The rack or workbench has a good ventilation system.
•
The rack is sturdy enough to support the switch and its accessories.
•
The rack or workbench is reliably grounded.
To ensure correct operation and long service life of your switch, install it in an environment that meets
the requirements described in the following subsections.
Temperature/humidity
Maintain temperature and humidity in the equipment room at acceptable ranges.
•
Lasting high relative humidity can cause poor insulation, electricity leakage, mechanical
property change of materials, and metal corrosion.
•
Lasting low relative humidity can cause washer contraction and ESD and cause problems
including loose mounting screws and circuit failure.
•
High temperature can accelerate the aging of insulation materials and significantly lower the
reliability and lifespan of the switch.
For the temperature and humidity requirements of different switch models, see technical
specifications in Hardware Information and Specifications.

3
Cleanliness
Dust buildup on the chassis might cause electrostatic adsorption and dust corrosion, resulting in
poor contact of metal connectors and contact points. This might shorten the device's lifetime and
even cause device failure in the worst case. Table 2 describes the dust concentration limits in the
equipment room.
Table 2 Dust concentration limits in the equipment room
Substance
Particle diameter
Concentration limit
Dust particles ≥ 0.5 µm ≤ 3.5 × 106 particles/m3
Dust particles ≥ 5 µm ≤ 3 × 104 particles/m3
Dust (suspension) ≤75 µm ≤0.4 mg/m3
Dust (sedimentation) 75 µm to 150 µm ≤15 mg/(m2h)
Sand ≥ 150 µm ≤300 mg/m3
To maintain cleanliness in the equipment room, follow these guidelines:
•
Keep the equipment room away from pollution sources. Do not smoke, eat, or drink in the
equipment room.
•
Use double-layer glass in windows and seal doors and windows with dust-proof rubber strips.
Use screen doors and window screens for doors and windows open to the outside and make
sure the external windows are air tight.
•
Use dustproof materials for floors, walls, and ceilings and use wallpaper or matt paint that does
not produce powders.
•
Clean the equipment room regularly and clean the air filters of the rack each month.
•
Wear ESD clothing and shoe covers before entering the equipment room, keep the ESD
clothing and shoe covers clean, and change them frequently.
Corrosive gas limit
Corrosive gases can accelerate corrosion and aging of metal components. Make sure the corrosive
gases in the equipment room do not exceed the concentration limits as shown in Table 3.
Table 3 Corrosive gas concentration limits in the equipment room
Gas
Average concentration (mg/m3)
Maximum concentration (mg/m3)
SO20.3 1.0
H2S 0.1 0.5
Cl20.1 0.3
HCI 0.1 0.5
HF 0.01 0.03
NH31.0 3.0
O30.05 0.1
NOX0.5 1.0

4
CAUTION:
As a best practice, control the
corrosive gas concentrations in the equipment room at their
average
values
. Make sure the corrosive gas concentrations do not exceed 30 minutes per day at their
maximum values.
To control corrosive gases, use the following guidelines:
•
As a best practice, do not build the equipment room in a place with a high concentration of
corrosive gases.
•
Make sure the equipment room is not connected to sewer, vertical shaft, or septic tank pipelines
and keep it far away from these pipelines. The air inlet of the equipment room must be away
from such pollution sources.
•
Use environmentally friendly materials to decorate the equipment room. Avoid using organic
materials that contains harmful gases, such as sulfur or chlorine-containing insulation cottons,
rubber mats, sound-proof cottons, and avoid using plasterboards with high sulfur concentration.
•
Place fuel (diesel or gasoline) engines separately. Do not place them in the same equipment
room with the device. Make sure the exhausted air of the engines will not flow into the
equipment room or towards the air inlet of the air conditioners.
•
Place batteries separately. Do not place them in the same room with the device.
•
Employ a professional company to monitor and control corrosive gases in the equipment room
regularly.
EMI
All electromagnetic interference (EMI) sources, from outside or inside of the switch and application
system, adversely affect the switch in the following ways:
•
A conduction pattern of capacitance coupling.
•
Inductance coupling.
•
Electromagnetic wave radiation.
•
Common impedance (including the grounding system) coupling.
To prevent EMI, use the following guidelines:
•
If AC power is used, use a single-phase three-wire power receptacle with protective earth (PE)
to filter interference from the power grid.
•
Keep the switch far away from radio transmitting stations, radar stations, and high-frequency
devices to make sure the EMI levels do not exceed the compliant range.
•
Use electromagnetic shielding when necessary. For example, use shielded interface cables.
•
To prevent signal ports from getting damaged by overvoltage or overcurrent caused by lightning
strikes, only route interface cables indoors.
Laser safety
WARNING!
Disconnected optical fibers or
transceiver modules might emit invisible laser light. Do not stare into
beams or view directly with optical instruments when the switch is operating.
The switch is a Class 1 laser device.

5
Installation tools
No installation tools are provided with the switch. Prepare the following tools yourself as required.
•
Flat-blade screwdriver
•
Phillips screwdriver
•
ESD wrist strap
•
Needle-nose pliers
•
Diagonal pliers
•
Crimping tool
•
Marker
•
Heat gun
Installation accessories
All the installation accessories except the following installation accessories are provided with the
switch:
•
M6 screws and floating nuts.
•
PSR150-A1 (JD362B) AC power supply.
•
PSR150-D1 (JD366B) DC power supply.
Table 4 Installation accessories
Product code
Description
Quantity
Applicable models
5380-0493
1 U two-hole mounting bracket kit
(including one pair of mounting brackets
and four M4 countersunk screws)
1 kit
HPE 5140 24G 4SFP+ EI
HPE 5140 48G 4SFP+ EI
HPE 5140 24GPoE+ 4SFP+ EI
HPE 5140 48GPoE+ 4SFP+ EI
R8M91A
HPE 5140 Rack Mount Kit (including
one pair of mounting brackets and four
M4 countersunk screws)
1 kit HPE 5140 8G 2SFP 2GT
Combo EI
5066-0850
1 U four-hole mounting bracket kit
(including one pair of mounting brackets
and eight M4 countersunk screws)
1 kit
HPE 5140 24G SFP w/8G
Combo 4SFP+ EI
HPE 5140 24G PoE+ 2SFP+
2XGT EI
HPE 5140 48G PoE+ 2SFP+
2XGT EI
HPE 5140 24G 2SFP+ 2XGT
EI
N/A
M6 screw and floating nut (user
supplied)
As required All HPE 5140 EI switches

6
Product code
Description
Quantity
Applicable models
5185-9292
Grounding cable (tin-plated at one end
and with a ring terminal at the other end)
1 All HPE 5140 EI switches
5185-9443
5080-0120
DC power cord (supplied with the
PSR150-D1 (JD366B) DC power
supply)
The power cord colorcode scheme is for
illustration only. The cable delivered for
your country or region might use a
different color scheme.
1 PSR150-D1 (JD366B) DC
power supply
5184-7298
Rubber feet
4 All HPE 5140 EI switches

7
Installing the switch
CAUTION:
Keep the tamper
-
proof seal on a mounting screw on the chassis cover intact, and if you want to open
the chassis, contact HPE for permission. Otherwise, HPE shall not be liable for any consequence.
Figure 1 Hardware installation flow
Start
Install the switch
Ground the switch
Connect the power cords
Verify the installation
Turn on the circuit
breakers
Operating correctly? Turn off the circuit
breakers
Troubleshoot the
switch
No
Has power supply slots?
Yes
Select and install power
supplies
Yes
No
End
Connect interface cables

8
Installing the switch in a 19-inch rack
Mounting brackets
Table 5 describes the mounting brackets applicable to the switch.
Table 5 Mounting brackets applicable to the switch
Switch model
Mounting brackets
Views
HPE 5140 24G 4SFP+ EI
HPE 5140 48G 4SFP+ EI
HPE 5140 24G PoE+ 4SFP+ EI
HPE 5140 48G PoE+ 4SFP+ EI
Mounting brackets A
(provided) See A in Figure 2.
HPE 5140 24G SFP w/8G Combo 4SFP+ EI
HPE 5140 24G PoE+ 2SFP+ 2XGT EI
HPE 5140 48G PoE+ 2SFP+ 2XGT EI
HPE 5140 24G 2SFP+ 2XGT EI
Mounting brackets B
(provided) See B in Figure 2.
HPE 5140 8G 2SFP 2GT Combo EI Mounting brackets C with
product code R8M91A
(optional) See C in Figure 2.
Figure 2 Mounting brackets
(1) Screw hole for attaching the bracket to the switch
(2 ) Screw hole for attaching the bracket to the rack post
1
2
(A)
(C)
1
2
(B)
1
2

9
Attaching the mounting brackets to the switch
1. Determine the installation position for the mounting brackets.
The HPE 5140 24G SFP w/8G Combo 4SFP+ EI, HPE 5140 24G PoE+ 2SFP+ 2XGT EI,
and HPE 5140 48G PoE+ 2SFP+ 2XGT EI switches provide two installation positions for the
mounting brackets: port side mounting position and power supply side mounting position.
The other HPE 5140 EI switches provide only the port side mounting position for the
mounting brackets.
2. Align one mounting bracket with the screw holes at the mounting position. Use M4 screws to
attach the mounting bracket to the chassis. See Figure 3 for installing mounting bracket A,
Figure 4 and Figure 5 for installing mounting bracket B, and Figure 6 for installing mounting
bracket C.
M4 screws are provided only for switches shipped with mounting brackets.
An optional mounting bracket kit contains M4 screws.
3. Repeat step 2to attach the other mounting bracket to the chassis.
Figure 3 Attaching mounting bracket A (HPE 5140 24G PoE+ 4SFP+ EI)
Figure 4 Attaching mounting bracket B to the port side mounting position (HPE 5140 24G
SFP w/8G Combo 4SFP+ EI)

10
Figure 5 Attaching mounting bracket B to the power supply side mounting position (HPE
5140 24G SFP w/8G Combo 4SFP+ EI)
Figure 6 Attaching mounting bracket C (HPE 5140 8G 2SFP 2GT Combo EI)
Rack-mounting the switch
This task requires two people. To mount the switch in the rack:
1. Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded.
2. Verify that the mounting brackets have been securely attached to the switch chassis.
3. Install cage nuts in the mounting holes in the rack posts.
No cage nuts are provided with the switch. Prepare them yourself.
4. One person holds the switch chassis and aligns the mounting brackets with the mounting holes
in the rack posts, and the other person attaches the mounting brackets to the rack with M6
screws.
M6 screws are provided only for switches shipped with mounting brackets. For switches not
shipped with mounting brackets, prepare M6 screws yourself.
5. Verify that the switch chassis is horizontal and secure.

11
Figure 7 Mounting an HPE 5140 24G SFP w/8G Combo 4SFP+ EI switch in the rack (port side
mounting position for the mounting brackets)
Figure 8 Mounting an HPE 5140 24G SFP w/8G Combo 4SFP+ EI switch in the rack (power
supply side mounting position for the mounting brackets)

12
Figure 9 Mounting an HPE 5140 8G 2SFP 2GT Combo EI switch in the rack
Mounting the switch on a workbench
IMPORTANT:
•
Ensure 10 cm (3.9 in) of clearance around the chassis for heat dissipation.
•Do not place heavy objects on the switch.
If a standard 19-inch rack is not available, you can place you switch on a workbench.
To mount the switch on a workbench:
1. Verify that the workbench is sturdy and reliably grounded.
2. Place the switch with bottom up, and clean the round holes in the chassis bottom with dry cloth.
3. Attach the rubber feet to the four round holes in the chassis bottom.
4. Place the switch with upside up on the workbench.
Mounting the switch on a wall
CAUTION
:
•
Before drilling holes in a wall, make sure no electrical lines exist in the wall.
•Leave a minimum clearance of 10 mm (0.39 in) around the chassis for heat dissipation.
Table 6 describes the switch models that support wall mounting and installation holes distances
required for wall-mounting the switch.
Table 6 Installation hole distances for switch models that support wall mounting
Switch
Hole distance
HPE 5140 8G 2SFP 2GT Combo EI 170 mm (6.69 in)
20 mm (0.79 in) long screws and screw anchors as shown in Figure 10 are provided with these
switches for wall-mounting.

13
Figure 10 Screw anchor and screw
To mount the switch on a wall:
1. Mark two installation holes on the wall. Make sure the two holes are on the same horizontal line.
See Table 6 for the distance requirement between the two holes.
Figure 11 Installing the switch on a wall (1)
2. Drill two holes with a diameter of 6 mm (0.24 in) and a depth of 25 mm (0.98 in) at the marked
locations. Hammer the screw anchors into the wall and use a Phillips screwdriver to fasten the
screw into the screw anchor. Leave 1.5 mm (0.06 in) between the screw head and the wall for
hanging the switch.
Figure 12 Installing the switch on a wall (2)
3. Align the installation holes in the switch rear with the screws on the wall and hang the switch on
the screws. Make sure the port side faces down and the left and right sides are perpendicular to
the ground.

14
Figure 13 Installing the switch on a wall (3)
Grounding the switch
WARNING
!
Correctly connecting the switch grounding cable is crucial to lightning protection and EMI protection.
The power input end of the switch has a noise filter, whose central ground is directly connected to the
chassis to form the chassis ground (commonly known as PGND). You must securely connect this
chassis ground to the earth to minimize the potential for system damage, maximize the safety at the
site, and minimize EMI susceptibility of the system.
You can ground the switch in one of the following ways, depending on the grounding conditions
available at the installation site:
•
Grounding the switch with a grounding strip
•
Grounding the switch with a grounding conductor buried in the earth ground
NOTE:
The
chassis views and power supply and grounding terminal positions in the following figures
are for
illustration only.
Grounding the switch with a grounding strip
WARNING
!
Connect the grounding cable to the grounding system in the equipment room. Do not connect it to a
fire main or lightning rod.
If a grounding strip is available at the installation site, use the grounding strip to ground the switch.
To ground the switch by using a grounding strip:
1. Attach the ring terminal end of the grounding cable to the grounding hole in the switch.
a. Remove the grounding screw from the grounding hole in the rear panel of the switch.
b. Attach the grounding screw to the ring terminal of the grounding cable.
c. Use a screwdriver to fasten the grounding screw into the grounding screw hole.

15
Figure 14 Attaching the grounding cable to the grounding hole of the switch (HPE 5140
24G PoE+ 4SFP+ EI)
(1) Grounding screw
(2) Ring terminal
(3) Grounding sign
(4) Grounding hole
(5) Grounding cable
2. Connect the other end of the grounding cable to the grounding strip.
a. Cut the grounding cable to a length according to the distance between the switch and the
grounding strip.
b. Peel 20 mm (0.79 in) of insulation sheath by using a wire stripper.
c. Use the needle-nose pliers to bend the bare wire.
d. Hook the grounding cable to the post on the grounding strip, and use the hex nut to secure
the cable to the post.
Figure 15 Connecting the grounding cable to a grounding strip
(1) Grounding post
(2) Grounding strip
(3) Grounding cable
(4) Hex nut
Grounding the switch with a grounding conductor buried in
the earth ground
If the installation site has no grounding strips, but earth ground is available, hammer a 0.5 m (1.64 ft)
or longer angle iron or steel tube into the earth ground to serve as a grounding conductor.
The dimensions of the angle iron must be at least 50 × 50 × 5 mm (1.97 × 1.97 × 0.20 in). The steel
tube must be zinc-coated and its wall thickness must be at least 3.5 mm (0.14 in).
5
1
2
3
4
1 2
34

16
Weld the yellow-green grounding cable to the angel iron or steel tube and treat the joint for corrosion
protection.
Figure 16 Grounding the switch by burying the grounding conductor into the earth ground
(1) Grounding screw
(2) Grounding cable
(3) Earth
(4) Joint
(5) Grounding conductor
(6) Chassis rear panel
Installing and removing power supplies
CAUTION:
Provide a circuit breaker for each
power supply and make sure the circuit breaker is off before
installation.
This section applies only to the switch models that support removable power supplies.
The HPE 5140 24G SFP w/8G Combo 4SFP+ EI switches each provide two power supply slots.
They come with power supply slot 1 empty and power supply slot 2 installed with a filler panel. You
can install one power supply, or two power supplies for redundancy. For information about power
supplies available for the HPE 5140 24G SFP w/8G Combo 4SFP+ EI switches, see removable
components in Hardware Information and Specifications.
When two power supplies are installed, you can hot-swap a power supply. To avoid device damage
and bodily injury, follow the procedures in Figure 17 and Figure 18 to install and replace a power
supply.
Figure 17 Installation procedure
Figure 18 Removal procedure
The installation and removal procedures are the same for power supplies. This guide uses the
PSR150-A1 power supply as an example.
1
2
5
4
3
6
安装电源模块 连接电源线 给电源模块加电安装电源模块 连接电源线 给电源模块加电
安装电源模块 连接电源线 给电源模块加电
Install the power supply Connect the power cord Turn on the circuit
breaker
将电源模块断电 拆卸电源线 拆卸电源模块将电源模块断电 拆卸电源线 拆卸电源模块将电源模块断电 拆卸电源线 拆卸电源模块
Turn off the circuit
breaker Remove the power cord Remove the power
supply
