Warmlite WL28005A Mounting instructions

www.warmlite.co
1200W
18L ELECTRIC
ASH VACUUM
MODEL WL28005A
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY

2
CUSTOMER SUPPORT TEAM: [phone]
TECHNICAL DATA
Description: Electric Ash Vacuum
Model: WL28005A
Rated Voltage: 220V-240V ~50Hz
Power Consumption: 1200 Watts
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
RKW Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RKW has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.
The lter is not covered by the warranty. Spare lters can be ordered from the Customer Service
Department. Should you encounter problems or require a replacement part, contact the Pifco
Customer Support Team on: [phone]

3
www.warmlite.co
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the terminals
in your plug, please
proceed as follows:
The wires in the mains lead are coloured in
accordance with the following code:
Blue neutral [N] Brown live [L]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral and must be
connected to the terminal marked [N] or coloured
black.
The wire coloured brown is the live wire and
must be connected to the terminal marked [L] or
coloured red.
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal .
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable
plug tted to the mains lead and should the fuse
need replacing, you must use an ASTA approved
one (conforming to BS 1362 of the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - and then cut it o the mains
lead and immediately dispose of its safely. Never
attempt to reuse the plug or insert it into a socket
outlet as there is a danger of an electric shock.
WARNING:
This appliance is double insulated. Do not connect any wire to the earth terminal.

4
CUSTOMER SUPPORT TEAM: [phone]
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Please ensure that the appliance
is used on a stable, level, and
heat resistant surface.
• Do not immerse cords, plugs
or any part of the appliance in
water or any other liquid.
• Do not leave the appliance
unattended while it is operating.
• Close supervision is necessary
when any appliance is used by
or near children or pets.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved.
• Children shall not play with the
appliance.
• Cleaning and user maintenance
shall not be made by children
without supervision.
• Switch o at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• If the supply cord or appliance
is damaged, stop using the
appliance immediately and seek
advice from the manufacturer
or its service agent or a similarly
qualied person.
• Do not let the cord hang over
the edge of a table or counter or
let it come into contact with any
hot surfaces.
• The use of accessory
attachments is not
recommended by the appliance
manufacturer, apart from those
supplied with this product.
• Do not pull the plug out by the
cord as this may damage the
plug and/or the cable.
• Do not use this product for
anything other than its intended
use.
• This appliance is for household
use only.
• Do not carry the appliance by
the power cord.
• Do not use the appliance
outdoors.

5
www.warmlite.co
HIGH VOLTAGE
• Do not vacuum the following
objects: liquid, inammable and
explosive dangerous material,
corrosive material and burning
ash, matches or cigarette.
• Do not use the appliance to
vacuum dust that may be
harmful to your health.
• Keep the appliance in a dry
environment.
• Do not touch the live parts in
appliance.
• Pay more attention when
cleaning the stairs.
• Use the accessories and spare
parts only supplied by the
manufacturer or its authorised
service agent.
• Do not vacuum glowing or
burning embers, or any ash
above 50oC
• Do not vacuum ash or other
objects that are burning.
• Do not use the appliance if the
lter is not installed! Do not use
other lters except the ones
attached to the appliance by
manufacturer.
• In the unlikely event the
appliance develops a fault,
stop using it immediately and
seek advice from the Customer
Support Team.

6
CUSTOMER SUPPORT TEAM: [phone]
WHAT’S IN THE BOX
Instruction Manual
1. Power switch (not shown)
2. Handle
3. Cover
4. Tank
5. Soft hose
6. Aluminium tube
7. Filter housing
8. Filter
3
4
5
6
1 2
BEFORE YOUR FIRST USE:
1. Remove the parts from the packaging.
2. Assemble as instructed in the assembly page.
3. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
7
8

7
www.warmlite.co
ASSEMBLY
1. Loosen the two retaining clips and remove
the motor and cover from the tank.
2. Attach the lter to the lter housing.
3. Place into the vacuum cleaner tank.
4. Place the motor and cover back on top
of the tank and fasten both clips down,
locking the cover in to place.
5. Twist the exi pipe into the opening on the
side of the vac and insert the aluminium
pipe on to the end of the exi pipe.
6. Your vacuum is now ready for use.
USING YOUR APPLIANCE
1. Plug your vacuum in at the wall socket
and turn on.
2. Turn the power switch to on.
3. Use the hose to suck up any ash.
Important: Ensure the re is fully extinguished
and there are no glowing or hot embers before
vacuuming ash. Only vacuum ash with a
temperature of below 50°C.
4. Once you have nished vacuuming, run
the unit for 30 seconds to ensure all
debris is safely in the container and none
remains in the hose.
5. When the container is full or it feels dicult
to vacuum more dust, the lter needs to
be taken out and cleaned.
Note: Only use the lter supplied with the
appliance.
CLEANING AND CARE
Cleaning The Filter
1. Turn o the vacuum cleaner and remove
the cover.
2. Empty the dust container and wash it.
3. Take out the lter, clean and wash it
carefully, and air dry before re-installing on
the vacuum cleaner.
• The container, outer shell & cover need to
be cleaned frequently.
• The dirty container and lter should be
washed with clean water.
• If the appliance is not working properly, it
is usually the result of a blockage in the
soft tube, pipes or accessories. Please
clean the parts concerned
WARNING:
DO NOT IMMERSE THE UNIT IN WATER
Brush

8
CUSTOMER SUPPORT TEAM: [phone]
NOTES

9
www.warmlite.co
NOTES

10
CUSTOMER SUPPORT TEAM: [phone]
NOTES

11
www.warmlite.co
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.

We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are giving you an extra year peace of mind.
To receive your extra year guarantee, register your appliance online by visiting
www.warmlite.co
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
[phone]
Distributed throughout the UK by RKW LTD
0617.V3
