520-143-000 8/00 Models EB3-M/EB4-M/EB80M Page 1
IMPORTANT
Read these instructions completely,
beforeinstallationandstart-up.Itisthe
responsibilityofthepurchasertoretain
this manual for reference. Failure to
comply with the recommendations
stated in this manual will damage the
pump, and void factory warranty.
HAZARD WARNING
POSSIBLE EXPLOSION HAZARD can
result if 1, 1, 1,-Trichloroethane,
Methylene Chloride or other
HalogenatedHydrocarbonsolventsare
used in pressurized fluid systems
havingAluminumorGalvanizedwetted
parts.Death,seriousbodilyinjuryand/
or property damage could result.
Consult with the factory if you have
questions concerning Halogenated
Hydrocarbonsolvents.
DANGER
Before doing any maintenance on the
pump, be certain all pressure is com-
pletely vented from the pump, suction,
discharge, piping, and all other open-
ingsandconnections.Becertaintheair
supply is locked out or made non-
operational,sothatitcannotbestarted
while work is being done on the pump.
Becertainthatapprovedeyeprotection
and protective clothing are worn at all
timesinthevicinityofthepump.Failure
to follow these recommendations may
result in serious injury or death.
CAUTION
In the event of diaphragm rupture,
pumped material may enter the air end
ofthepump,andbedischargedintothe
atmosphere.Ifpumpingaproductwhich
is hazardous or toxic, the air exhaust
mustbepipedtoanappropriateareafor
safedisposition.
CAUTION
Before maintenance or repair, shut off
thecompressedairline,bleedthepres-
sure, and disconnect the air line from
the pump. The discharge line may be
pressurized and must be bled of its
pressure. When used for toxic or ag-
gressive fluids, the pump should
always be flushed clean prior to
disassembly.
PRINCIPLE OF PUMP OPERATION
The SandPIPER pump is powered by compressed air which alternately pressur-
izes the inner sides of the two diaphragm chambers while simultaneously exhausting
theoppositeinnerchamberscausingthediaphragms,whichareconnectedbyashaft,
to move endwise. Since air pressure is applied over the entire surface of the
diaphragm which is forcing liquid to be discharged by its other side, the diaphragm is
operatingunderabalancedcondition during the discharge stroke. This allows the unit
to be operated at discharge heads over 200 feet (61 meters) of water head.
Alternate pressurizing and exhausting of the diaphragm chamber is performed by
an externally mounted, pilot-operated, four way, spool type air distribution valve.
When the spool is at one end of the valve body, inlet air pressure is connected to one
diaphragm chamber and the other diaphragm chamber is connected to the exhaust.
When the spool is removed to the opposite end of the valve body, the porting of
chambers is reversed. The air distribution valve spool is moved from one end position
to the other in the valve body by means of an internal pilot valve which alternately
pressurizes the ends of the air distribution valve spool while simultaneously exhaust-
ing the other ends. The pilot valve is positively shifted at each end of the diaphragm
stroke by the diaphragm plate’s coming in contact with the end of the pilot valve spool
and pushing it into position for shifting of the air distribution valve. The chambers are
manifolded together with a suction and discharge check valve for each chamber to
maintain flow in one direction through the pump.
INSTALLATION PROCEDURES
Position the pump as close as possible to the source of the liquid to be pumped.
Avoid long or undersize suction lines and use the minimum number of fittings.
For permanent installation involving rigid piping, install short flexible sections of
hose between the pump and piping. This reduces strains and permits easier removal
of the pump for service when required. At time of installation, inspect all external
gasketed fasteners for looseness caused by gasket creep. Tighten loose
fittings securely to prevent leakage.
AIR SUPPLY
Do not connect the unit to an air supply in excess of 125 PSI (8.61 bars). Install
a shutoff valve in the air supply line to permit removal of the unit for servicing. When
connecting an air supply of rigid piping, mount a section of flexible line to the pump
to eliminate piping strain. In permanent installations, an air line filter is recommended.
The weight of the air supply line and of the filter must be supported by some
means other than the air valve cap. Failure to provide support may result in
damage to the pump.
AIR INLET & PRIMING
Your SandPIPER pump has been tested prior to shipment and is ready for use as
received. It is completely self-priming and no initial filling with fluid is required.
If the unit is to be totally submerged, the air exhaust must be piped above liquid
level to prevent the liquid and foreign material from entering the air distribution valve
mechanism.
Openthe inletairvalve atleastone turn toallow sufficient cyclingratefor thepump
to prime (30 to 60 cycles per minute). After pumping starts, adjust the inlet air valve
forthe desiredpumpingcapacity. Whenfurtheropening ofthe inlet airvalve increases
cycling rate without increasing the flow rate, the pump is being starved of liquid due
to suction limitations. Further opening of the air inlet valve will waste compressed air.
WARRENRUPP®,INC.,AUnit of IDEX Corporation • P.O. Box1568•Mansfield,Ohio44901-1568USA•[phone]•Fax[phone]•www.warrenrupp.com
SERVICE AND OPERATING MANUAL
Models EB3-M/EB4-M/EB80M
Type 2
®

Page 2 Models EB3-M/EB4-M/EB80M 520-143-000 8/00
Set the inlet air valve for lowest cycling rate that does not decrease flow rate for most
efficient operation.
A NOTE ABOUT AIR VALVE LUBRICATION
The SandPiper pump’s pilot valve and main air valve assemblies are designed to
operate WITHOUT lubrication. This is the preferred mode of operation. There may be
instances of personal preference, or poor quality air supplies when lubrication of the
compressed air supply is required. The pump air system will operate with properly
lubricated compressed air supplies. Proper lubrication of the compressed air supply
would entail the use of an air line lubricator set to deliver one drop of 10 wt., non-
detergent oil for every 20 SCFM of air the pump consumed at its point of operation.
Consult the pump’s published Performance Curve to determine this.
It is important to remember to inspect the sleeve and spool set routinely. It should
move back and forth freely. This is most important when the air supply is lubricated.
If a lubricator is used, oil accumulation will, over time, collect any debris from the
compressed air. This can prevent the pump from operating properly.
Water in the compressed air supply can create problems such as icing or freezing
of the exhaust air causing the pump to cycle erratically, or stop operating. This can
be addressed by using a point of use air dryer to supplement a plant’s air drying
equipment.Thisdevicewillremove excess water from the compressed air supply and
alleviate the icing or freezing problem.
ESADS: EXTERNALLY SERVICEABLE AIR
DISTRIBUTION SYSTEM
Please refer to the exploded view drawing and parts list in the Service Manual
supplied with your pump. If you need replacement or additional copies, contact your
local Warren Rupp Distributor, or the Warren Rupp factory Literature Department at
the number shown below. To receive the correct manual, you must specify the
MODEL and TYPE information found on the name plate of the pump.
MODELS WITH 1" SUCTION/DISCHARGE OR LARGER,
AND METAL CENTER SECTIONS:
The main air valve sleeve and spool set is located in the valve body mounted on
the pump with four hex head capscrews. The valve body assembly is removed from
the pump by removing these four hex head capscrews.
With the valve body assembly off the pump, access to the sleeve and spool set
ismadebyremovingfourhexheadcapscrews(each end)onthe endcapsof thevalve
body assembly. With the end caps removed, slide the spool back and forth in the
sleeve. The spool is closely sized to the sleeve and must move freely to allow for
proper pump operation. An accumulation of oil, dirt or other contaminants from the
pump’s air supply, or from a failed diaphragm, may prevent the spool from moving
freely. This can cause the spool to stick in a position that prevents the pump from
operating. If this is the case, the sleeve and spool set should be removed from the
valve body for cleaning and further inspection.
Remove the spool from the sleeve. Using an arbor press or bench vise (with an
improvised mandrel), press the sleeve from the valve body. Take care not to damage
thesleeve. At this point, inspect the o-rings onthesleevefor nicks, tears or abrasions.
Damage of this sort could happen during assembly or servicing. A sheared or cut o-
ring can allow the pump’s compressed air supply to leak or bypass within the air valve
assembly, causing the pump to leak compressed air from the pump air exhaust or not
cycleproperly.This is most noticeable at pump dead head or high discharge pressure
conditions. Replace any of these o-rings as required or set up a routine, preventive
maintenance schedule to do so on a regular basis. This practice should include
cleaning the spool and sleeve components with a safety solvent or equivalent,
inspecting for signs of wear or damage, and replacing worn components.
Tore-installthe sleeveandspoolset,lightly lubricatethe o-ringsonthesleevewith
an o-ring assembly lubricant or lightweight oil (such as 10 wt. air line lubricant). Press
theset into the valvebodyeasily,without shearing the o-rings.Re-installoneend cap,
gasket and bumper on the valve body. Using the arbor press or bench vise that was
usedindisassembly,pressthesleevebackintothevalvebody.Youmayhavetoclean
WARNING
Take action to prevent static sparking.
Fireor explosion canresult, especially
when handling flammable liquids. The
pump,piping,valves,containersorother
miscellaneous equipment must be
grounded.
BEFORE OPERATION
Before pump operation, inspect all
gasketedfastenersforloosenesscaused
bygasketcreep.Retorqueloosefasten-
ers to prevent leakage. Follow recom-
mended torques stated in the card at-
tached to the new pump.
DANGER
Before doing any maintenance on the
pump, be certain all pressure is com-
pletely vented from the pump, suction,
discharge, piping, and all other open-
ingsandconnections.Becertaintheair
supply is locked out or made non-
operational,sothatitcannotbestarted
while work is being done on the pump.
Becertainthatapprovedeyeprotection
and protective clothing are worn at all
timesinthevicinityofthepump.Failure
to follow these recommendations may
result in serious injury or death.

520-143-000 8/00 Models EB3-M/EB4-M/EB80M Page 3
the surfaces of the valve body where the end caps mount. Material may remain from
the old gasket. Old material not cleaned from this area may cause air leakage after
reassembly. Take care that the bumper stays in place allowing the sleeve to press in
all the way. Reinstall the spool the opposite end cap, gasket and bumper on the valve
body. After inspecting and cleaning the gasket surfaces on the valve body and
intermediate,reinstallthevalvebodyonthe pumpusing newgaskets. Tightenthe four
hex head capscrews evenly and in an alternating cross pattern.
PILOT VALVE ACTUATOR
The bushings for the pilot valve actuators are threaded into the intermediate
bracket from the outside. The plunger may be removed for inspection or replacement
fromtheinsidebyremovingtheairdistributionvalvebodyandthepilotvalvebodyfrom
the pump. The plungers should be visible through the intermediate from the top.
Depending on their position, you may find it necessary to use a fine piece of wire to
pull them out. Under rare circumstances, it may become necessary to replace the o-
ring seal.
When reinserting an externally serviceable pilot valve, push both plungers out of
the path of the pilot valve. This will prevent damage to the plungers and pilot valve.
Service Note: If a problem arises with the pilot valve, it is usually corrected by
replacing only o-rings. Always grease the spool prior to inserting into the sleeve. If the
sleeve is removed from the body, reinsertion must be from the same side it was
removed from, the chamfered side. Again, grease the o-rings so that it slides into the
body. Make sure the retaining ring has securely been inserted around the sleeve.
AIR EXHAUST
If a diaphragm fails, the pumped liquid or fumes can enter the air end of the pump,
and be exhausted into the atmosphere. When pumping hazardous or toxic materials,
pipe the exhaust to an appropriate area for safe disposition.
This pump can be submerged if materials of construction are compatible with the
liquid. The air exhaust must be piped above the liquid level. Piping used for the air
exhaust must not be smaller than 1" (2.54 cm). Reducing the pipe size will restrict air
flowandreduce pump performance. When the product source is at a higher level than
the pump (flooded suction), pipe the exhaust higher than the product source to
prevent siphoning spills.
Freezing or icing-up of the air exhaust can occur under certain temperature and
humidity conditions. Use of an air dryer unit should eliminate most icing problems.
BETWEEN USES
When the pump is used for materials that tend to settle out or transform from liquid
to solid form, care must be taken after each use or during idle time to remove them
and flush the pump as required to prevent damage.
In freezing temperatures the pump must be completely drained when idle. This
model must be tilted to allow the liquid from the chambers to run out of the discharge
port.
CHECK VALVE SERVICING
Need for inspection or service is usually indicated by poor priming, unstable
cycling, reduced performance or the pump’s cycling but not pumping.
DIAPHRAGM SERVICING
Remove the twelve bolts (six each side) securing the manifold assemblies to the
outer chambers. Remove the eight bolts securing the outer chamber to the inner
chamber. Remove the diaphragm assembly (outer plate, diaphragm, inner plate) by
turning the assembly counterclockwise using a 11/8" (3.17 cm) wrench on the outer
plate lugs. To disassemble the diaphragm assemblies, screw into the inner plates two
threaded pins, place the pins in a vise and turn the outer plate counterclockwise using
the 11/8" wrench. The interior components consisting of shaft seals, sleeve bearings
and bearing retainers are now accessible for service.
Procedures for reassembling the diaphragms are the reverse of the above. The
diaphragms must be installed with their natural bulge to the outside, toward the outer
CAUTION
In the event of diaphragm rupture,
pumped material may enter the air end
ofthepump,andbedischargedintothe
atmosphere.Ifpumpingaproductwhich
is hazardous or toxic, the air exhaust
mustbepipedtoanappropriateareafor
safedisposal.

Page 4 Models EB3-M/EB4-M/EB80M 520-143-000 8/00
RECOMMENDED
WARREN RUPP
ACCESSORIES
TO MAXIMIZE PUMP
PERFORMANCE:
• Tranquilizer®SurgeSuppressor:
For nearly pulse-free flow.
• Warren Rupp Filter/Regulator:
For modular installation and
service convenience.
• Warren Rupp Speed Control:
For manual or programmable
process control. Manual
adjustmentor4-20mAreception.
For more detailed information on
these accessories,
contact your local Warren Rupp
Factory-Authorized Distributor,
or Warren Rupp corporate
headquarters.
diaphragm plate. Install the inner plate with the flat face against the diaphragm.
After all components are in position in a vise and hand tight, tighten with a wrench
to approximately 50 ft. lbs. (67.79 Newton meters) torque. After both diaphragm
assemblies have been assembled, thread one assembly into the shaft (hold the shaft
near the middle in a vise with soft jaws, to protect the finish). Install this sub assembly
intothepumpandsecurebyplacingtheouterchamberontheendwiththediaphragm.
This holds the assembly in place while the opposite side is installed. Torque the last
diaphragm assembly to 40 ft. lbs. (54.23 Newton meters). This final torquing will lock
the diaphragm assemblies together. Place the remaining outer chamber on the open
end and loosely tighten the bolts. Replace the manifold assemblies to square the
flanges before final tightening of the remaining bolts. Alternating for progressive
tightening, the eight capscrews that secure outer chamber to inner chamber.
TROUBLESHOOTING
1. Pump will not cycle
A. Check to make sure the unit has enough pressure to operate and that the air inlet
valve is open.
B. Check the discharge line to insure that the discharge line is neither closed nor
blocked.
C. If the spool in the air distribution valve is not shifting, check the main spool. It must
slide freely.
D. Excessive air leakage in the pump can prevent cycling. This condition will be
evident. Air leakage into the discharge line indicates a ruptured diaphragm. Air
leakage from the exhaust port indicates leakage in the air distribution valve. See
further service instructions.
E. Blockage in the liquid chamber can impede movement of diaphragm.
2. Pump cycles but will not pump
A. Suction side of pump pulling in air. Check the suction line for air leaks and be sure
that the end of the suction line is submerged. Check flange bolting. Check valve
flanges and manifold to chamber flange joints.
B. Make certain the suction line or strainer is not plugged. Restriction at the suction
isindicated by ahighvacuum reading whenavacuum gauge isinstalledin the suction
line.
C. Check valves may not be seating properly. To check, remove the suction line and
coverthesuctionportwithyourhand.Ifthe unitdoesnot pullagood suction(vacuum),
the check valves should be inspected for proper seating.
D. Staticsuctionliftmaybetoohigh.Primingcanbeimprovedbyelevatingthesuction
and discharge lines higher than the check valves and pouring liquid into the unit
through the suction inlet. When priming at high suction lifts or with long suction lines
operate the pump at maximum cycle rate.
3. Low performance
A. Capacity is reduced as the discharge pressure increases, as indicated on the
performance curve. Performance capability varies with available inlet air supply.
Check air pressure at the pump inlet when the pump is operating to make certain that
adequate air supply is maintained.
B. Check vacuum at the pump suction. Capacity is reduced as vacuum increases.
Reducedflow rate duetostarved suction willbeevident when cycleratecan be varied
without change in capacity. This condition will be more prevalent when pumping
viscous liquids. When pumping thick, heavy materials the suction line must be kept
as large in diameter and as short as possible, to keep suction loss minimal.
C. Low flow rate and slow cycling rate indicate restricted flow through the discharge
line. Low flow rate and fast cycling rate indicate restriction in the suction line or air
leakage into suction.
D. Unstable cycling indicates improper check valve seating on one chamber. This
condition is confirmed when unstable cycling repeats consistently on alternate
exhausts. Cycling that is not consistently unstable may indicate partial exhaust
restriction due to freezing and thawing of exhaust air. Use of an anti-freeze lubricant
in an air line lubricator should solve this problem.
For more information, consult the Warren Rupp Industrial Troubleshooting Guide. ©2000 Warren Rupp, Inc. All rights reserved.
®WarrenRupp,SandPIPER,andTranquilizerare
registered tradenames of Warren Rupp, Inc.
Printed in U.S.A.
IMPORTANT
Before pump operation, all external
gasketed fasteners must be inspected
for looseness caused by gasket creep
afterleavingthefactory.Retorqueloose
fasteners to insure against leakage.
Follow recommended torques where
called out. (A card is attached to each
new pump stating this fact.)
Thispumpispressurizedinternallywith
air pressure during operation. Always
make certain that all bolting is in good
condition and that all of the correct
boltingis reinstalled during assembly.
WARRANTY
This unit is guaranteed for a period of
five years against defective material
and workmanship.

520-143-000 8/00 Models EB3-M/EB4-M/EB80M Page 5
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
1 070-006-170 Bearing, Sleeve 2
2 114-002-010 Bracket, Intermediate 1
114-002-156 Bracket, Intermediate 1
3 720-004-360 Seal, U-Cup 2
4 135-008-000 Bushing,Threaded,witho-ring 2
5 620-004-114 Plunger, Actuator 2
6 095-073-000 Pilot Valve Body Assy.11
6-A 095-070-551 Pilot Valve Body 1
6-B 755-025-000 Sleeve with o-ring 1
6-C 560-033-360 O-Ring (Sleeve) 4
6-D 775-026-000 Spoolwitho-ring 1
6-E 560-023-360 O-Ring(Spool) 2
6-F 675-037-080 RetainingRing 1
7 360-041-425 Gasket, Valve Body 1
8 560-001-360 O-Ring 2
9 095-043-010 Body, Valve 1
095-043-156 Body, Valve 1
10 132-014-358 Bumper, Valve Spool 2
11 165-011-010 Cap, End 2
165-011-157 Cap, End 2
12 360-048-425 Gasket, Valve Body 1
13 360-010-425 Gasket, End Cap 2
14 560-020-360 O-Ring 6
15 031-018-000 Sleeve & Spool Set 1
16 170-032-330 Capscrew, Hex Head 8
17 170-045-330 Capscrew, Hex Head 4
18 132-002-360 Bumper, Diaphragm 2
19 196-100-015 Chamber, Inner 2
20 132-022-360 Bumper 2
21 560-022-360 O-Ring 2
22 685-041-120 Rod, Diaphragm 1
24 170-024-330 Capscrew, Hex Head 8
25 530-008-000 Muffler, Exhaust 1
26 900-006-330 Washer, Lock 8
27 545-008-330 Nut, Hex 16
28 900-003-330 Washer, Lock 32
29 612-124-010 Plate, Inner Diaphragm 2
30 286-098-365 Diaphragm 2
286-098-354 Diaphragm 2
286-098-360 Diaphragm 2
286-098-363 Diaphragm 2
286-098-364 Diaphragm 2
31 722-041-110 Seat, Valve 24
722-041-080 Seat, Valve 24
722-041-365 Seat, Valve 4
722-041-360 Seat, Valve 4
722-041-363 Seat, Valve 4
722-041-364 Seat, Valve 4
722-041-600 Seat, Valve 4
31-1 560-008-611 O-Ring 8
560-008-360 O-Ring (Use with metal seat only) 8
Repair Parts shown in bold face (darker)
typeare more likely to need replacement
afterextended periods of normal use.
Theyarereadily available from most
WarrenRuppdistributors.Thepump
ownermayprefertomaintainalimited
inventory of these parts in his own stock to
reducerepairdowntimeto aminimum.
IMPORTANT:Whenorderingrepairparts
alwaysfurnish pumpmodelnumber, serial
numberandtypenumber.
REPAIR PARTS LIST and DRAWING
Models EB3-M/EB4-M/EB80M
Type 2
MATERIALCODES
The Last 3 Digits of Part Number
000... Assembly,sub-assembly;andsome
purchaseditems
010... CastIron
015... DuctileIron
025... Music Wire
080... CarbonSteel,AISIB-1112
110... AlloyType316StainlessSteel
112... Alloy “C”
114... 303StainlessSteel
115... 301/302/304StainlessSteel
120... 416StainlessSteel(WroughtMartensitic)
148... HardcoatAnodizedAluminum
150... 6061-T6Aluminum
151... 6063-T6Aluminum
154... Almag35Aluminum
155or156...356-T6Aluminum
157... DieCastAluminumAlloy#380
159... AnodizedAluminum
162... Brass,Yellow,ScrewMachineStock
170... Bronze,BearingType,OilImpregnated
180... CopperAlloy
330... PlatedSteel
331... ChromePlatedSteel
332... ElectrolessNickelPlated
335... GalvanizedSteel
354... InjectionMolded#203-40Santoprene—
Duro40D +/-5;Color: RED
356... Hytrel
357... Rupplon(UrethaneRubber)
360... Buna-NRubber.Colorcoded:RED
363... Viton(Fluorel).Colorcoded:YELLOW
364... E.P.D.M.Rubber.Colorcoded:BLUE
365... NeopreneRubber.Colorcoded:GREEN
366... FoodGradeNitrile.Colorcoded:WHITE
375... FluorinatedNitrile
405... CelluloseFibre
408... CorkandNeoprene
425... CompressedFibre
440... VegetableFibre
500... Delrin500
501... Delrin570
520... InjectionMoldedPVDF,NaturalColor,
FoodGrade/USDAAcceptable
540... Nylon
550... Polyethylene
551... Polypropylene
555... PVC(PolyvinylChloride)
580... Ryton
600... Teflon (virginmaterial)Tetrafluoroethylene(TFE)
603... BlueGylon
604... Teflon—Diaphragm
610... EncapsulatedSilicon
611... TeflonEncapsulatedViton
Delrin,Teflon,Hytrel,andVitonare
registeredtradenamesofE.I.DuPont.
GylonisaregisteredtradenameofGarlock,Inc.
WarrenRupp,RupplonandSandPIPERareregistered
tradenamesofWarrenRupp,Inc.
RytonisaregisteredtradenameofPhillips
ChemicalCompany.
LoctiteisaregisteredtradenameofLoctiteCorporation.
1Available in kit form. Order P/N 031-055-000
which also includes Items 5, 7, 12, & 20.
2Discharge Side only — when pump is used in a filterpress system
requires 4 O-Rings (P/N 560-008-XXX) to be used with seats.
®

Page 6 Models EB3-M/EB4-M/EB80M 520-143-000 8/00
Repair Parts shown in bold face (darker)
typeare more likely to need replacement
afterextended periods of normal use.
Theyarereadily available from most
WarrenRuppdistributors.Thepump
ownermayprefertomaintainalimited
inventory of these parts in his own stock to
reducerepairdowntimeto aminimum.
IMPORTANT:Whenorderingrepairparts
alwaysfurnish pumpmodelnumber, serial
numberandtypenumber.
MATERIALCODES
The Last 3 Digits of Part Number
000... Assembly,sub-assembly;andsome
purchaseditems
010... CastIron
015... DuctileIron
025... Music Wire
080... CarbonSteel,AISIB-1112
110... AlloyType316StainlessSteel
112... Alloy “C”
114... 303StainlessSteel
115... 301/302/304StainlessSteel
120... 416StainlessSteel(WroughtMartensitic)
148... HardcoatAnodizedAluminum
150... 6061-T6Aluminum
151... 6063-T6Aluminum
154... Almag35Aluminum
155or156...356-T6Aluminum
157... DieCastAluminumAlloy#380
159... AnodizedAluminum
162... Brass,Yellow,ScrewMachineStock
170... Bronze,BearingType,OilImpregnated
180... CopperAlloy
330... PlatedSteel
331... ChromePlatedSteel
332... ElectrolessNickelPlated
335... GalvanizedSteel
354... InjectionMolded#203-40Santoprene—
Duro40D +/-5;Color: RED
356... Hytrel
357... Rupplon(UrethaneRubber)
360... Buna-NRubber.Colorcoded:RED
363... Viton(Fluorel).Colorcoded:YELLOW
364... E.P.D.M.Rubber.Colorcoded:BLUE
365... NeopreneRubber.Colorcoded:GREEN
366... FoodGradeNitrile.Colorcoded:WHITE
375... FluorinatedNitrile
405... CelluloseFibre
408... CorkandNeoprene
425... CompressedFibre
440... VegetableFibre
500... Delrin500
501... Delrin570
520... InjectionMoldedPVDF,NaturalColor,
FoodGrade/USDAAcceptable
540... Nylon
550... Polyethylene
551... Polypropylene
555... PVC(PolyvinylChloride)
580... Ryton
600... Teflon (virginmaterial)Tetrafluoroethylene(TFE)
603... BlueGylon
604... Teflon—Diaphragm
610... EncapsulatedSilicon
611... TeflonEncapsulatedViton
Delrin,Teflon,Hytrel,andVitonare
registeredtradenamesofE.I.DuPont.
GylonisaregisteredtradenameofGarlock,Inc.
WarrenRupp,Rupplon,andSandPIPER areregistered
tradenamesofWarrenRupp,Inc.
RytonisaregisteredtradenameofPhillips
ChemicalCompany.
LoctiteisaregisteredtradenameofLoctiteCorporation.
SantopreneisaregisteredtradenameofMonsantoCorp.
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
32 050-014-365 Ball, Check Valve 4
050-014-354 Ball, Check Valve 4
050-014-360 Ball, Check Valve 4
050-014-364 Ball, Check Valve 4
050-015-600 Ball, Check Valve 4
36 518-034-010 Manifold, Suction (ANSI) 1
518-034-010E Manifold, Suction (DIN) (EB80M) 1
518-034-110 Manifold, Suction (ANSI) 1
518-034-110E Manifold, Suction (DIN) (EB80M) 1
518-034-112 Manifold, Suction (ANSI) 1
518-034-112E Manifold, Suction (DIN) (EB80M) 1
518-034-156 Manifold, Suction (ANSI) 1
518-034-156E Manifold, Suction (DIN) (EB80M) 1
37 518-035-010 Manifold, Discharge (ANSI) 1
518-035-010E Manifold, Discharge (DIN) (EB80M) 1
518-035-110 Manifold, Discharge (ANSI) 1
518-035-110E Manifold, Discharge (DIN) (EB80M) 1
518-035-112 Manifold, Discharge (ANSI) 1
518-035-112E Manifold, Discharge (DIN) (EB80M) 1
518-035-156 Manifold, Discharge (ANSI) 1
518-035-156E Manifold, Discharge (DIN) (EB80M) 1
38 170-055-330 Capscrew, Hex Head 12
39 326-002-080 Mounting Foot 2
40 286-098-604 Overlay Diaphragm 2
41 170-034-330 Capscrew, Hex Head 4
42 807-046-330 Stud 2
43 196-052-010 Chamber, Outer 2
196-052-110 Chamber, Outer 2
196-052-156 Chamber, Outer 2
44 612-090-010 Plate, Outer Diaphragm Assembly 2
612-090-110 Plate, Outer Diaphragm Assembly 2
612-090-156 Plate, Outer Diaphragm Assembly 2
51 618-003-330 Plug, Pipe 2
618-003-110 Plug, Pipe 2
52 170-082-330 Capscrew, Hex Head 16
Not Shown: 031-021-010 Main Air Valve Assembly 1
(Inc. Items 9, 10, 11, 13, 14, 15, 16)
031-021-156 Main Air Valve Assembly 1
(Inc. Items 9, 10, 11, 13, 14, 15, 16)
EB4-M:
41 170-066-330 Capscrew, Hex Hd. 4
45 770-018-080 Spacer, Foot 2
46 334-037-010 Flange, Adapter 2
47 807-005-330 Stud 8
48 900-007-330 Washer, Lock 8
49 545-009-330 Nut, Hex 8
50 360-036-426 Gasket, Flange 2
476-102-000 AIR END KIT
Seals, Gaskets, air Valve Sleeve and Spool,
Pilot Valve Assembly
476-047-360 WETTED END KIT
Buna Diaphragms, Check Balls and Seats
476-047-363 WETTED END KIT
Viton Diaphragms and Seats, Teflon Check Balls
476-047-364 WETTED END KIT
EPDM Diaphragms, Check Balls and Seats
476-047-365 WETTED END KIT
Neoprene Diaphragms, Check Balls and Seats
476-047-635 WETTED END KIT
Neoprene Backup Diaphragms, Teflon Overlay
Diaphragms, Check Balls and Seats

520-143-000 8/00 Models EB3-M/EB4-M/EB80M Page 7
OVERLAY UNITS ONLY.
©2000 Warren Rupp, Inc. All rights reserved.
®Warren Rupp, SandPIPER, and Tranquilizer are registered tradenames of Warren Rupp, Inc.
Printed in U.S.A.
