Warrior Table Soccer SOCCER TABLE User manual

Updated: 5/4/16 www.WarriorTableSoccer.com
SOCCER TABLE
Assembly Instructions

Table of Contents
Parts Identifier .......................................... 3
Hardware Identifier…………………………. 4
Table Assembly Instructions ..................... 5
Table Assembly Pictures ………..….…….. 6, 7, 8
www.WarriorTableSoccer.com 2 | Page

Parts Identifier
Box A
A1. Side panels (2)
A2. Assembled rods with bearings (8), Rod guards (8)
A3. Balls (2), Extra Men (2), Bearing wrench (1) Silicone
Box B
B1. Leg panels (2)
B2. Goal boxes (2)
B3. Top Cap (2)
Box C
C1. Table top (1)
C2. Leg levelers (4)
C3. Ball Catch (1)
C4. Score beads (2)
C5. Corner insert (4)
C6. Ball Return Hose (2)
C7. Metal Plate (2)
C8. Bolts & washers (all nuts pre-installed in cabinet)
C9. Allen wrench with Phillips head.
If you have missing parts please call 866-436-6722 extension 6803
www.WarriorTableSoccer.com 3 | Page

Hardware Identifier
Description Qty Purpose
5/16” x 1 ¾” 14 (8) Side Panels / Legs,
(6) Play Field
1/4" x 1 ¾” 14 (4) Corner Blocks
(4) Goal Boxes
(2) Ball Catch
(4) Top Plate
3/16” x 1 ½” 4 (4) Score Beads
If purchased with light bracket
1/4” x 1 ¾” 4 (4) Light Bracket
www.WarriorTableSoccer.com 4 | Page

Table Assembly Instructions
Note: No additional tools required for assembly, all nuts are pre-installed in the table. It is
recommended to get all bolts “Started” only. Once all bolts have been started check alignment of “top
plates”, “leg panels” & “side panels” before tightening bolts completely. No Impact or Power tools.
1. Make sure the leveler inner nut and boltare tight before installing leg levelers (leave top nut
loose) Attach to legs by twisting in clockwise direction until they are all the way in.( do not
overtighten) then standboth legs in upright position.
2. Position both side panels (2) on each side of the leg panels (make sure the 5 predrilled holes
are on the top ), using (8) 5/16” x 1-3/4”bolts with washers attach side panels to leg panels
(Do not tighten yet)
3. Attach goal boxes (2), using (4) 1/4”x 1-3/4”bolts and washers.
4. Insert metal plate into precut slots in goal box.
5. Attach ballcatch (1) using (2) 1/4” x 1-3/4”bolts with washers.
6. Install ball return runners (2)
a. With goal boxes mounted attach “ball return runner” on to white collar
b. Make sure runner completely covers the collar
c. Install collars into ball catch
d. Make sure runner completely cover ball catch collars
7. Place table top onto cabinet and secure using (6) 5/16” x 1-3/4”bolts with washers.
8. Attach corners blocks (4) to side of table using (4) 1/4”x 1-3/4” bolts with washers
(Align all side panels to legs and tighten all bolts securely.)
9. Attach topplate (2) using (4) 1/4” x 1-3/4” bolts.
10. Attach score beads (2) on to top plate using (4) #10 x 1-1/2” bolts.
11. (a) Remove nut from Rod Guards and (b) install into round holewith nut inside table
12. Remove Nut from Inner bearing insert rod into Rod Guard Bearing drop in opening and tighten
13. Wipe down rods with cloth or napkin. Lubricate rod outside of men with 1 or 2 drops of
silicone.
14. Level tto raise or lower eachcorner then raise TOP nut to secure.
1 man goalie rods use 10" rod guard and are closest to goal
2 man rods use 15" rod guard and are second rod from goal
5man rods use 5" rod guard and are in the middle position of table
3 man rods use 10" rod guards and are furthest from goal
www.WarriorTableSoccer.com 5 | Page
ROD and Guard Locations (view picture on cover for refrence)

Assembly Pictures
1. Make sure bolt and inner nut are TIGHT
Leave TOP nut about ¼” (6mm) from
bottom to allow for leveling. When table is
level raise TOP nut to meet leg and
secure
2. Leg Panels w/ 1 Side Panel
3. Attach Goal Box and collar
4. Insert Metal Plate
5. Attach Ball Catch
6a – install ball return runner to goal box
collar
www.WarriorTableSoccer.com 6 | Page

Assembly Pictures
6b – Install runner completely over collar 6c – Install collars into ball catch
6d – Install runner completely over collars
7. Place tabletop into cabinet
8. Install Corner Block with black finished
sides exposed as shown
9. Attach Top Plate
www.WarriorTableSoccer.com 7 | Page

Assembly Pictures
10. Attach Score Beads to Top Plate
11a. Remove Nut from Rod Guard
11b. Install Rod Guard into Round Holes
12.Remove inner nut install rod, tighten
13. Wipe rods down with cloth or napkin
then add 1 or 2 drops of silicone
Level table by turning leg levelers to raise
or lower legs as needed then raise Top
Nut to secure
www.WarriorTableSoccer.com 8 | Page
