Watcher XL Series Assembly instructions

IP Camera Installation and Setup Guide
XL Series DVR/NVR Models
Watcherproducts.com Watcher Products 877-289-2824 1

Watcherproducts.com Watcher Products 877-289-2824 2

Watcherproducts.com Watcher Products 877-289-2824 3

Read First
**Note** Before beginning the setup process for IP cameras on your new DVR, make sure that you
have the DVR connected to the internet. This will allow our Technical Support Team to establish a
remote desktop session to help you if further assistance is needed for IP camera setup.
When installing IP cameras, you should have a proper layout of where the cameras are going to be
installed before you begin. Once the layout has been determined, finding the best location for your PoE
switches could save in time and money in cabling. Depending on the number of cameras and switches
you are installing, you can mount them in a “central” location of the cameras you want on that switch.
When using Watcher Preferred Power Switches, the switches must be connected together (or to the
DVR) using the Gigabit uplink ports on the right-hand side of the switch. Our 16-port switches have
two uplink ports and they can be linked to another switch. The 8- and 4-port switches only have one
uplink, so these would be better suited for an endpoint that is not connecting to any other switches. It
would also be a great idea to get a full gigabit 16-port switch (each port is gigabit speed) and utilize it
as a central hub for connecting other switches. Refer to the camera network diagram on page 2.
If you are using full gigabit PoE switches (each port has gigabit speed), you can run the camera
network according the diagram on page 3.
The DVR system will have 2 Network Interface Ports (RJ-
45) on the back to allow for the separation of Store Network
and Camera etwork. This is important because you will not
want the store's bandwidth to be bogged down by the video
data sent on the Camera network.
Before mounting any cameras, it is best practice to set them up, one at a time, at the DVR using one of
your PoE switches and a short CAT5 cable run.
1. Connect a PoE switch to the DVR in the camera network port with a short CAT5 cable.
2. Connect a short CAT5 cable to the switch to connect to the camera.
3. Connect a camera to the CAT5 cable yo j st connected to the switch.
Watcherproducts.com Watcher Products 877-289-2824 4
Dual Network Ports (Back of DVR)

4. Follow the IP camera set p instr ctions beginning on page 4.
5. Once set p is completed, disconnect the camera.
6. Repeat steps 1-5 for each camera that yo have.
**Note** For p blic view monitor (PVM) set p, please call o r technical s pport team.
DVR Setup (must be completed before setting up cameras)
Close the DVR software and, in the bottom right-hand corner, find the Networking icon( ) and
right-click on it and go to Open Network and Sharing Center. In upper left-hand corner, click Change
adapter settings.
Then double-click the corresponding connection that corresponds to the camera network. It will be the
one that does not have an internet connection (it also may say unidentified network).
Watcherproducts.com Watcher Products 877-289-2824 5

This will open the Local Area Connection Status window. Click on the Properties button on the bottom
left.
This will bring up the Local Area Connection Properties. Double-click the Internet Protocol Version 4
(TCP/IPv4).
Watcherproducts.com Watcher Products 877-289-2824 6

This will bring up the Internet Protocol Version 4 Properties. In here, click on the bubble next to Use
the following IP address and enter the IP address that you would like to use for the DVR. Our
recommended default is 192.168.4.100 and no Defa lt Gateway is needed. The DNS server addresses
are not used with the camera network. Make sure that this address does not conflict with any other
addresses on the store network.
Once done, hit OK. Then hit OK again and, finally, Close. Close out of the Local Area Connections
window to get back to the Desktop. Now you are ready to begin setting up your IP cameras.
Watcherproducts.com Watcher Products 877-289-2824 7

IP Camera Setup
Step 1:
Once you have your first camera ready to be setup (connected to the switch), open the DVR software.
Once open, from the bottom menu options, click on the “ADD/DEL IPC”.
Step 2:
This will bring up the IP Camera Device List which will be empty for your first camera. From here you
want to click on the IPC Search button in the lower right.
** Note ** For each additional camera, once it is plugged in, please allow the camera to power up for
roughly 1 min.
Watcherproducts.com Watcher Products 877-289-2824 8

This will bring up a menu for which type of camera that you would like to
search for. You may need to try several of the options from this menu. The
most common types are NV Series, DT Series, or DH Series. For third party
cameras, you will have to use the ONVIF_V2.3 selection.
**IMPORTANT** Third Party cameras are not registered by Watcher
Products and will require a $50 registration fee per camera to allow them to
record video.
Step 3:
Once you have chosen the series you want to search for, the IP Cameras List in Local network window
will open.
Watcherproducts.com Watcher Products 877-289-2824 9

If the list is empty, you may need to go back and search for a different series. If your camera does not
show up in any of the searches, check the connection. Once the camera has been found, you will see it
in the list with it's default IP address. Single-click to select the camera (the background will turn blue,
for that camera, across the table row).
Step 4:
Now, it is time to change the IP address of the camera. This is done in the IP Address field in the lower-
right.
Watcherproducts.com Watcher Products 877-289-2824 10

**Note** Make sure that the camera is on the same IP scheme as the camera network you setup at the
beginning of this guide. If the recommended DVR IP address was used (192.168.4.100), it is
recommended to start the cameras at IP address 192.168.4.150 and continue up for each additional
camera.
Example: Camera 1 = 192.168.4.150
Camera 2 = 192.168.4.151
Camera 3 = 192.168.4.152
…
…
Camera 10 = 192.168.4.159
Select the first set of numbers in the IP Address field (192) by double-clicking it. The background will
turn blue and you can begin typing the IP address of the camera. Whenever you hit period (.), the
selection will automatically change to the next set of numbers in the address. This makes it easier to
type the IP sequentially using the number keys on the keypad. Leave the port on it's default value. It
may be 37777, 8000, etc. but the software correctly puts the proper port number for each version of
camera (NV Series, DH Series, DG Series, etc.). You will also have to change the password (on the
left) to admin123.
The Mask Address should be at 255.255.255.0
Watcherproducts.com Watcher Products 877-289-2824 11

The NetGate Address should be 192.168.4.254 if using the recommended IP addressing scheme.
Once all the correct parameters have been entered in each field, click the Modify IP button.
After a short delay, the camera should be listed in the IP Cameras List with the new IP address. Click
the Update IP List button to change the Server Name to the new IP address.
Watcherproducts.com Watcher Products 877-289-2824 12

Next, add it to the DVR software by clicking the Add to NDVR button at the bottom then click the Exit
button. The IP Camera Device List should now have your connected camera.
**Note** If your camera is not registered and you purchased it from Watcher Products, please contact
our Technical Support for camera registration.
Watcherproducts.com Watcher Products 877-289-2824 13

Step 5:
If you know where your camera is going to be mounted (from your layout), you can name the camera at
this time as well.
To name your camera, from the IP Camera Device List, select the camera with a single-click (the
background will turn blue) and hit the Mod Cam button below the list and to the left. Change the Server
Name to what ever you wish to call the camera then hit OK, then hit Save
Watcherproducts.com Watcher Products 877-289-2824 14

** Important ** Please do not change the Login User ID and Login Pass for the cameras. They need
this password to be left on default to connect to the software.
Now in the IP Camera Device List, the camera should have the camera name in the Device Name
column.
Watcherproducts.com Watcher Products 877-289-2824 15

Watcherproducts.com Watcher Products 877-289-2824 16

Step 6
Once the IP cameras have been added, they need to be added to the recording schedule in Camera
Setup.
To get to Camera Setup, click on the Setup button, then the Camera Setup button. Then, under Group
Setup, turn the corresponding camera on in the schedule. It will turn from gray to blue.
Watcherproducts.com Watcher Products 877-289-2824 17

Step 7
Finally, motion may need to be turned on in the camera itself. This can be done by right-clicking on the
camera and going to IP Camera Setup. Then click on the Motion tab at the top. You should see a screen
similar to the one below.
1. Sensitivity - This will adjust the sensitivity of the motion detection. Usually the higher the number
the more sensitive the detection. You may have to adjust accordingly depending on the camera type.
2. Handling Motion Alarm - This turns motion detection on for the camera. Check this tick box to
enable motion detection.
3. Motion Detection Area B ttons – These buttons will clear the motion area completely (Clear) or
select the entire screen for motion detection (All). You can also use customized areas by dragging
boxes around the areas that you would like to have motion detection. This is done by holding the left
mouse button and dragging. In the example below, the register is the only area that would detect motion
Watcherproducts.com Watcher Products 877-289-2824 18

and record.
4. Upload to Center / Report to Center– This sends the motion detection signal to the DVR. It should
also be checked.
Once you have configured the motion settings, click the Save button in the bottom right and then Exit.
Your camera should now be detecting and recording motion in the DVR. This is apparent by the little
“running man” icon in the upper-right hand corner of the camera window.
Repeat steps 1 – 7 for each IP camera that you would like to add to the DVR.
