Watec W-01CDB3 (NTSC) User manual

Danger
Danger
Color Board CCD Camera
W-01CDB3
Operation Manual
This Operation Manual covers safety, camera functions, installation and the
correct operating procedure for the W-01CDB3. First, we ask you to read
this Operation Manual thoroughly, then install and operate the W-01CDB3
as advised. In addition, for future reference, we also advise safekeeping of
this manual.
Please contact the distributor or dealer from which the W-01CDB3 was
purchased, if you do not understand the installation, operation or safety
instructions laid out in this manual. Not understanding the contents of the
Operation Manual sufficiently may cause damage to the camera.
GuidetotheSafetySymbols
The meanings of the symbols used in this operation manual are:
When you do not adhere to or take notice of the “Danger”
sign, it may lead to serious accident such as death or injury
caused by fire or electric shock.
When you do not adhere to or take notice of the “Warning”
sign, it may cause severe damage such as a physical injury.
When you do not adhere to or take notice of the “Caution”
sign, it may incur injury and cause damage to peripheral objects
in the immediate surroundings.
CautionsforSafety
The W-01CDB3 is designed to be used safely; however, it may lead to
physical accident caused by fire and electric shock if not used correctly.
Therefore, please keep and read the“Cautions for safety”for protection
against accidents.
•Do not disassemble and/or modify the W-01CDB3.
•Do not operate the W-01CDB3 with wet hands.
•Use only the AD901 or equivalent power adaptor for the
W-01CDB3.
The recommended voltage is DC+12V±10%
•Do not expose the W-01CDB3 to wetness or high moisture
conditions.
The W-01CDB3 is designed and approved for indoor use
only. The W-01CDB3 is not water-resistant or waterproof. If
the location of the camera is outdoors or in an outdoor like
environment, we recommend that you use an outdoor camera
housing.
•Protect the W-01CDB3 from condensation.
Keep the W-01CDB3 dry at all times, during storage and
operation.
•Should the camera not work properly, switch off the power
immediately. Then, check the camera according to the
“Trouble Shooting”section.
•Avoid the striking of hard objects or dropping the
W-01CDB3.
The W-01CDB3 uses high quality electrical parts and
precision components.
•Do not connect any power supply directly to the video out
terminaloftheunit.
Do not connect the W-01CDB3 with any monitor using a
video/power single transmission terminal. The W-01CDB3
is not designed for use with this type of equipment. We also
advise you to read the operation manual of the monitor you
plan to use before any connections are made.
•Do not install the W-01CDB3 in a position subject to direct
sunlight.
Sunlight shinning directly onto the W-01CDB3 lens can
cause damage to the CCD.
•Select a stable place for installation of the W-01CDB3.
Always fix the camera securely.
See【Mounting Holes】section.
•Do not move the W-01CDB3 with the cables connected.
Before moving the W-01CDB3, always remove the video
cable and power cable from the rear of the camera first.
•Avoid using the W-01CDB3 near any strong electromagnetic
field.
After installing into main equipment, if the W-01CDB3 is
exposed to electromagnetic waves causing the monitored
image to become distorted, we recommend the camera be
shielded by appropriate protective casing.
Problems and Trouble Shooting
If any of the following problems occur when using the W-01CDB3,
•An optimal picture cannot be obtained, after checking that all the cables
and connections are correctly in place
•Smoke or any unusual odor emerges from the W-01CDB3.
• An object becomes embedded or a quantity of liquid seeps into the
camera housing
• More than the recommended voltage or/and amperage has been applied
to the W-01CDB3 by mistake
• Anything unusual occurring to any equipment connected to the
W-01CDB3.
Disconnect the camera immediately according to the following procedures:
①Switch off the main power supply to the camera.
②Remove the power and video cables connected to the W-01CDB3.
③Contact the distributor or dealer from which the W-01CDB3 was
purchased.
Contents
Using the contents figures below, check to make sure all parts are present
before use.
W-01CBD3 Connector with cables Hex.Wrench
DescriptionofParts
①CCD FRONT FACE
・The light receiving face of the CCD camera
(Dirt, water or oil deposits on the CCD will cause an unclear picture on the
monitor. Attach the lens cap to protect the lens and CCD from
contamination and damage.)
②LENS MOUNT
・Mount for the lens (Thread type)
③FOCUSING ADJUSTMENT SCREWS
・There are 3 hex. adjustment screws each placed at intervals of 120゜for
fine focusing of the lens.
④TERMINAL FOR AUTO-IRIS LENS (VIDEO CONTROL)
・The terminal for a Video-driven auto-iris lens. Do not connect a DC-
driven auto-iris lens to this terminal.
⑤TERMINAL FOR AUTO-IRIS LENS (DC CONTROL)
・The terminal for a DC-driven auto-iris lens. Do not connect a Video-
driven auto-iris lens to this terminal.
⑥IRIS LEVEL VOLUME
・By controlling the volume, the iris level of a DC iris lens can be adjusted.
⑦AE MODE CONTROL SWITCH
・The switch for selecting either electronic iris or electronic shutter.
⑧SHUTTER SPEED CONTROL SWITCH
・The switch for the electronic shutter speed control according to the
object.
⑨POWER IN/VIDEO OUT
・The terminal for power input and video signal output. Use the attached
connector with cables for this purpose.
⑩FUNCTION SWITCHES
・Functional switches for setting video level, mirror image and white balance.
⑪MOUNTING HOLES
・Four φ2.2mm diameter holes in each corner for mounting the camera.
PowerSupplyandWiring
If any other power adaptor besides the AD901 is used, please use a
stabilized power adaptor designed for DC+12V±10%, with a current
capacity of more than 250mA. Use the optional DC plug if the shape or
polarity of the DC plug of the power adaptor to be used is not compatible
with the camera.
The wiring on the connector must be exact.
Warning
Caution
Warning
Caution
①②③④
⑥
⑦
⑧
⑨
⑩
⑤
⑪

•
Design and specifications are subject to change without notice.
•Watec is not responsible for any inconvenience or the attendant damages
to the video and monitoring recording equipment caused by misuse, mis-
operation or improper wiring of our equipment.
•If for any reason the W-01CDB3 does not work properly, or if you have
any questions regarding installation or operation, please contact the
distributor or dealer from which it was purchased.
1353Z00-Y2100002
Be careful not to touch the other terminal while wiring. Protect the wiring
portion by using insulation tape after wiring. If the above care and attention
is not adhered to, damage to the W-01CDB3 and power adaptor may
occur or may cause fire.
Auto-irisLens
There are two output terminals on the W-01CDB3.
One for Video auto-iris lenses and one for DC
auto-iris lenses. Please pay attention to the correct
wiring configuration, as shown in the figure on the
right.
NB. Damage will occur if the correct wiring
configurations are not adhered to.
MountingHoles
As shown in the figure on the right. The W-01CDB3
provides four mounting holes, one in each corner of the
circuit board. Fix the unit securely using M2 screws.
Once the board is secured proceed with the following
steps below.
Set-upandOperation
1) Ensure that the power to the W-01CDB3 and the peripheral
equipment is turned off before making any connections.
2) Remove the lens mount cap from the W-01CDB3 and attach the
CS-mount lens. Use the optional C-mount adaptor (34CMA-R) when a
C-mount lens is used.
3) Connect the iris cable to the W-01CDB3 as shown above in
【Auto-iris Lens】section, when an auto-iris lens is being used.
4) Connect the attached cable to ⑨POWER IN/VIDEO OUT. See the
【Power Supply and Wiring】section.
5) Connect a coaxial cable with 75Ω impedance, such as an RG-58/U or
an RG-6/U to the monitor. Select a monitor with the same television
system as the W-01CDB3: NTSC or PAL. A monitor with more than
500TV lines is recommended.
6) Turn on the power to the W-01CDB3, monitor and all other allied
equipment. When a picture cannot be obtained on the monitor, or a
strong smell of burning is present, or smoke is visible, check and follow
the procedure mentioned in the Problems and Trouble Shooting section.
7) Focusing: Follow the operations mentioned below while looking at the
screen on the monitor. When focusing is not possible, loosen
③FOCUSING ADJUSTMENT SCREWS with the hexagonal wrench, then,
move the ②LENS MOUNT backwards or forwards to focus.
Manual Lens Adjust the focus and iris to the best position
on the lens.
Video Auto-iris Lens Adjust the focus on the lens.
DC Auto-iris Lens Adjust the iris level on the camera, then
adjust the focus on the lens. See below.
※When an auto-iris lens is used, set ⑦AE MODE CONTROL SWITCH to
ON and select any required shutter speed. (recommended shutter
speed setting is position 0 or 1)
8) Select any required shutter mode by ⑦AE MODE CONTROL SWITCH to
suit your preferences. When electronic iris (OFF) is selected, the shutter
operation is automatically stepped in a range between 1/60-1/100000
(NTSC), 1/50-1/100000(PAL). When electronic shutter (ON ) is
selected, select any required shutter speed from ⑧SHUTTER SPEED
CONTROL SWITCH.
9) Select any required shutter speed by the ⑧SHUTTER SPEED CONTROL
SWITCH to one of its 10 positions.
Shutter Speeds (Sec.)
No. Mode NTSC PAL
0 OFF 1/60 1/50
1 FL 1/100 1/120
2 ES 1/250
3 ES 1/500
4 ES 1/1000
5 ES 1/2500
6 ES 1/5000
7 ES 1/100000
8 ES 1/200000
9 ES 1/500000
11) Set the ⑩FUNCTION SWITCHES according to your requirements.
Switch Setting Effective Condition (Example)
ATW
【1=OFF】
【2=OFF】
Automatically follows and adjusts to the
changing color temperature of the
illumination.
3200K
【1=OFF】
【2=ON】
Color correction to give natural color
renditions under incandescent lighting.
5100K
【1=ON】
【2=OFF】
Color correction to give natural color
renditions under bluish fluorescent light.
1. & 2.
White
Balance
8200K
【1=ON】
【2=ON】
Color correction to give natural color
renditions under bluish fluorescent light
more than 5100K.
ON When a mirror image such as back
monitoring of a car is required.
3.
Mirror
Image OFF When a normal image is required.
ON
【100】
When dark areas on an object with
contrasting light and dark area are
monitored.
4.
Video
Level OFF
【75】 When a standard video output level is required
Specifications
Model W-01CDB3 (NTSC) W-01CDB3 (PAL)
Pick-up Element 1/3 inch interline transfer CCD image sensor
Number of
Total Pixels 811(H)×508(V) 795(H)×596(V)
Number of
Effective Pixels 768(H)×494(V) 752(H)×582(V)
Unit Cell Size 6.4um(Ｈ)×7.5um(V) 6.5um(Ｈ)×6.3um(V)
Scanning System 2:1 interlace
Sync. System Internal
Video Output Composite video, 1.0V(p-p) 75Ω (Unbalanced)
AGC 3〜24dB
Back Light
Compensation Full-screen
Resolution (H) 450TVL (Center)
Minimum
Illumination 1.5 lx. F1.2
S/N50dB
Gamma
Characteristics γ≒0.45
EI 1/60〜1/100000 sec. 1/50〜1/100000 sec.
AE
Mode ES 1/60(50)、1/100(120)、1/250、
1/500、1/1000、1/2000、1/5000、
1/10000、1/20000、1/50000 sec.
Power Supply DC12V±10%
Power
Consumption 1.2W (=100mA)
Operating
Temperature -10〜40℃
Operating Humidity Less than 95% RH (Without condensation)
Storage
Temperature -30〜70℃
Storage Humidity Less than 95% RH (Without condensation)
Size 42(W)×42(H)×20.7(L) (mm)
Lens Mount CS-mount
Weight 35g
/Contact information
Watec Co., Ltd.
Add.: 254-2 Nihonkoku, Daihoji, Tsuruoka- Shi,
Yamagata-Ken, 997-0017 Japan
/TEL: [phone] FAX: [phone]
/Email: [email protected]
URL: http://www.watec.net
Red: DC+12V
Black: Common GND
Blue: Video out
To power supply（DC+12V）
Black: Common GND
To power supply（GND）
To 75Ωcoax. cable
for monitor
