Water Process Solutions Encore 700 Manual

ENCORE®700
PLUNGER METERING PUMP
Operation & Maintenance Manual

ENCORE 700 PLUNGER PUMP
Encore® Plunger Metering Pump
IM.ENC.PLUNGER
Unit 10
Mill Hall Business Estate
Aylesford
Kent
ME20 7JZ
UK
+44 (0) 1622 719945
www.waterprocesssolutions.com
enquiries@waterprocesssolutions.com
ISSUE 2 - 18/8/2016

Unit 10
Mill Hall Business Estate
Aylesford
Kent
ME20 7JZ
www.waterprocesssolutions.com
Phone: +44 (0) 1622719945
email: enquiries@waterprocesssolutions.com
Directives covered by this declaration
89/336/EEC Electromagnetic Compatibility Directive, amended by 92/31/EEC & 93/68/EEC
73/23/EEC Low Voltage Equipment Directive, amended by 93/68/EEC
89/392/EEC Machinery Directive, amended by 91/368/EEC, 93/44/EEC & 93/68/EEC
Products Covered by this declaration
ENCORE® 700 Plunger Metering Pumps [6P, 12P, 24P and 32P]
The products identified above comply with the requirements of the EMC Directive and with the principle elements of
the safety objectives of the Low Voltage and Machinery Directives. The following standards have been applied:
EMC Emissions:
EMC Immunity:
Electrical Safety:
Machinery Safety:
The CE mark was first applied in 1996
EC-DECLARATION OF CONFORMITY
EN 50 081 Parts 1 & 2
EN 50 082 Parts 1& 2
EN 60034
BS EN 292
BS EN 294
Date of Declaration: 09/02/99
.......................................................
C.B. Dean
Managing Director

ENCORE 700 PLUNGER PUMP
PLEASE NOTE: THIS EQUIPMENT HAS BEEN DESIGNED TO PROVIDE
RELIABLE SERVICE. HOWEVER BEFORE ATTEMPTING TO INSTALL,
OPERATE OR SERVICE THE EQUIPMENT, THIS INSTRUCTION MANUAL
SHOULD BE READ, UNDERSTOOD AND OBSERVED. FAILURE TO D0 SO
CAN RESULT IN IMPROPER OPERATION WITH POSSIBLY HAZARDOUS
RESULTS.
INTRODUCTION
This book provides installation, operating and maintenance instructions for the Encore
Plunger Metering Pumps; here-in-after referred to as the pump or metering pump. The
pump provides accurate metering and transfer of a wide variety of chemicals. It is
available in four head sizes, four gear ratios, direct or pulley drive configurations and a
single and double simplex configuration. A non-loss-of motion, stroke adjustment is
used to vary the stroke for a more smooth pumping action. Non-loss-of motion is
achieved through the use of a variable eccentric mechanism. Stroke adjustment is done
either manually or with an optional electric stroke lengthpositioner.
An optional variable speed drive controls drive motor speed variations through signals
received from external sources.
When an electric stroke length positioner or variable speed drive is used with the pump,
a separate instruction manual covering the particular equipment used will befurnished.
WARNING
: TO AVOID POSSIBLE SEVERE PERSONAL INJURY OR DAMAGE
TO THE EQUIPMENT, THIS EQUIPMENT SH0ULD BE INSTALLED,
OPERATED AND SERVICED ONLY BY TRAINED, QUALIFIED PERSONNEL
WHO ARE THOROUGHLY FAMILIAR WITH THE ENTIRE CONTENTS OF THIS
INSTRUCTION BOOK. WHEN DEALING WITH HAZARDOUS MATERIAL, IT IS
THE RESPONSIBILITY OF THE EQUIPMENT USER TO BECOME FAMILIAR
WITH THE SAFETY PRECAUTIONS LISTED IN THE SAFETY SUMMARY ON
PAGES X & Y AND FOLLOW ALL SAFETY PRECAUTIONS RECDMMENDED
BY THE MATERIAL MANUFACTURER / SUPPLIER. AVOID CONTACTING
ELECTRICALLY HOT METER POSTS AND CIRCUIT BOARD COMPONENTS
WHILE MAKING METER ADJUSTMENTS.
When submitting correspondence or ordering material, always specify model and serial
number of equipment.

ENCORE 700 PLUNGER PUMP
GUARANTEE & WARRANTY
Water Process Solutions Ltd (WPS) guarantees that equipment manufactured or
represented by the Company is free from defect in workmanship and materials under
normal use and service. The Company will make good, by repair, or at its option, by
replacement, defects which, under proper use, in the Company's opinion, appear in the
equipment within a period of 12 months after shipment by the Company from our
works. The Company's responsibility is limited to the replacement of defective parts
whether the work is carried out on site or at the Company's works.
Equipment will be repaired under guarantee, free of charge, at our works providing that
it is returned to the Company, freight paid. Alternatively, any necessary repairs may be
carried out on site providing that any travel and accommodation costs incurred are paid
at ruling rates. Should the Company be called to carry out work under guarantee and
find that the fault lies outside the Company's responsibility, then any cost involved will
be charged to the Purchaser'saccount.
This guarantee is in lieu of all other guarantees and warranties expressed or implied and
does not apply to replacement or repairs which are required as a result of improper
installation, misuse, maladjustment, modification or lack of routine maintenance by
others. The Company does not guarantee the overall performance of any plant or the
result of any process on which the Company's equipment isused.
Equipment included which is not manufactured or represented by the Company is
specifically excluded from the obligation given above. Such equipment will be repaired
or replaced under guarantee only to the guarantee (if any) which the Company may
have received from the supplier or manufacturer of such equipment in respect thereof,
but not so as to impose on the Company in respect of such equipment a liability greater
than that set out herein.
The guarantee does not extend to, and the Company accepts no liability for,
consequential secondary damages or losses of any kind sustained directly or indirectly
as a result of a defect in any products, materials orinstallation.
NOTE
Minor part number changes may be incorporated into WPS products from time to time
that are not immediately reflected in the Instruction Book. If such a change apparently
has been made in your equipment and does not appear to be reflected in your
Instruction Book, contact WPS for information.
Please include the equipment serial number in all correspondence. It is essential for
effective communication and proper equipmentidentification.

ENCORE 700 PLUNGER PUMP
TABLE OF CONTENTS
Reordering of Preventive Maintenances Kits PM-1
Very Important Safety Precautions SP-1
Protective Equipment and Clothing SP-2
Technical Data Section 1
Installation Section 2
Operation Section 3
Service Section 4
Illustrations Section 5

ENCORE 700 PLUNGER PUMP
PM -1 : Preventive Maintenance
Protect Your Equipment Investment
Minimize Downtime
Reorder a Preventive Maintenance Kit Now. Keep One OnHand
Quality
+Preventive
=Dependable Operation
Equipment
Maintenance
Minimum Downtime
There's no question about it
Equipment that is properly maintained is dependableequipment.
It will give optimum performance with minimum unscheduled downtime.
WPS manufactures quality equipment designed for performance and reliability. Each
product is carefully tested and inspected before shipment, to ensure that it meets our high
standards.
Our equipment is engineered for easy maintenance. To ensure maximum service life and
minimize unscheduled repairs, we recommend a program of regular preventive
maintenance, as described in the Service section of this book. To support this program,
we developed standard service kits. These kits’s can also be used for minor emergency
repairs to minimize downtime.
We recommend that these kits be available in your stock at all times. When the complete
kit or any of its pads are used, the kit should be replacedimmediately.
Preventive maintenance kits may be ordered directly from the company which supplied
your equipment, or they may be ordered directly from WPS. For ordering numbers, refer
to the parts list at the rear of this book.

ENCORE 700 PLUNGER PUMP
PREVENTIVE MAINTENANCE SCHEDULE AND RECORDOF
PERFORMANCE
This equipment should receive scheduled preventive maintenance on a one year cycle*.
It is recommended that the following table be used to plan, schedule and record this
important work.
DATE OF INSTALLATION
PREVENTIVE MAINTENANCE LOG
SCHEDULE DATE
DATE PERFORMED
*NOTE: This is the recommended cycle. Your local operating conditions may call for
more frequent preventive maintenance.

ENCORE 700 PLUNGER PUMP
SP-1: VERY IMPORTANT SAFETYPRECAUTIONS
This page, titled "Very Important Safety Precautions "provides, in brief, information of
urgent importance relative to SAFETY, INSTALLATION, OPERATION, and
MAINTENANCE of this equipment.
WARNING
TO AVOID POSSIBLE SEVERE PERSONAL INJURY OR EQUIPMENT DAMAGE,
OBSERVE THE FOLLOWING:
THIS EQUIPMENT SHOULD BE INSTALLED, OPERATED AND SERVICED
ONLY BY TRAINED, QUALIFIED PERSONNEL WHO ARE THOROUGHLY
FAMILIAR WITH THE ENTIRE CONTENTS OF THIS INSTRUCTION BOOK.
AV0ID CONTACTING ELECTRICALLY HOT METER POSTS AND CIRCUIT
BOARD COMPONENTS WHILE MAKING METER ADJUSTMENTS.
WHEN DEALING WITH HAZARDOUS MATERIAL, IT IS THE RESPONSIBILITY
OF THE EQUIPMENT USER TO OBTAIN AND FOLLOW ALL SAFETY
PRECAUTIONS RECOMMENDED BY THE MATERIAL MANUFACTURER /
SUPPLIER.
CONSULT YOUR WPS REPRESENTATIVE IF THE PUMP IS TO BE USED
UNDER CONDITIONS OTHER THAN ORIGINALLY SPECIFIED AND IF THERE
IS ANY QUESTION REGARDING THE SIZE OF THE DISCHARGE LINE.
USE RIGID PIPE WHEN HAZARDOUS CHEMICALS ARE PUMPED AND / OR
ELEVATED PRESSURE / TEMPERATURES ARE ENCOUNTERED.
USE EXTREME CARE TO AVOID CONTACT WITH THE MATERIAL AND
POSSIBLE SEVERE PERSONAL INJURY. CONSULT YOUR CHEMICAL
SUPPLIER FOR INSTRUCTIONS IN THE PREPARATION OF SOLUTIONS AND
THE HANDLING OF CHEMICALS. OBSERVE ALL RECOMMENDED SAFETY
PRECAUTIONS.
DO NOT SPILL SOLUTION. IF ANY SOLUTION IS SPILLED, DILUTE OR WASH
AWAY WITH WATER IMMEDIATELY OR FOLLOW SUPPLIER'S
INSTRUCTIONS FOR HAZARDOUS MATERIALS.
AVOID BEING SPRAYED WITH LIQUID UNDER PRESSURE. PRIOR TO
DISASSEMBLY OF PPPE CONNECTIONS REFER TO DETAILED
INSTRUCTIONS ON RELIEVING PRESSURE AND DRAINING. ALLOW
SYSTEM TO DRAIN FULLY BEFORE ATTEMPTING TO DISASSEMBLE PIPING
AND REMOVING VALVES AND / OR HEAD.

ENCORE 700 PLUNGER PUMP
SINCE THE STORAGE AND HANDLING OF SODIUM CHLORITE PRESENTS
VERY SPECIFIC HAZARDS, THE USER MUST SEEK THE ADVICE Of HIS
SUPPLIER WlTH REFERENCE TO STORAGE FACILITIES, HANDLING
PRECAUTIONS AND HEALTH HAZARDS.
SODIUM CHLORITE, WHEN FINELY DIVIDED IN THE PRESENCE OF
ORGANIC COMPOUNDS, IS A POSSIBLE FIRE HAZARD. FOR THIS REASON,
EXTREME CARE MUST BE EXERCISED TO PREVENT SOLUTIONS FROM
DRYING OUT IN THE THREADED PORTIONS OF THE PUMP BODY AND
RELATED PARTS. OBSERVE CAREFULLY THE MANUFACTURER /
SUPPLIERS RECOMMENDED SAFETY PROCEDURES AND THE HANDLING
AND STORAGE PROCEDURES IN THIS BOOK.
WHEN SERVICING HEADS FOR DISASSEMBLY AND / OR VALVES, FOLLOW
PROCEDURES IN THE SECTION FOR DISASSEMBLY.
USE EXTREME CARE TO AVOID CONTACT WITH THE MATERIAL AND
POSSIBLE SEVERE PERSONAL INJURY. WHEN USING HAZARDOUS
MATERIAL, OBSERVE ALL SAFETY PRECAUTIONS RECOMMENDED BY THE
MATERIAL MANUFACTURE / SUPPLIER. USE APPROPRIATE PROTECTIVE
CLOTHING AND EYE PROTECTION WHEN HANDLING HAZARDOUS
MATERIAL.
USE EXTREME CARE TO AVOID CONTACT WITH LIQUID PRESENT IN HEAD.
ALLOW SUCTION VALVE TO FALL INTO SUITABLE CONTAINER AND
CATCH LIQUID,
USE EXTREME CARE TO AVOID CONTACT BECAUSE LIQUID IS PRESENT
BETWEEN DISCHARGE DRAIN VALVE AND UNION ELBOW. FLUSH SPILLED
LIQUID IMMEDIATELY.
TURN POWER OFF BEFORE SERVICING.
DO NOT RUN THE PUMP WITH THE BELT GUARD REMOVED,
USE ONLY WPS LISTED PARTS EXCEPT FOR COMMERCIALLY AVAILABLE
PARTS WHICH ARE IDENTIFIED BY COMPLETE DESCRIPTION ON PARTS
LIST. THE USE OF UNLISTED PARTS CAN RESULT IN EQUIPMENT
MALFUNCTIONS HAVING HAZARDOUS CONSEQUENCES.
THIS EQUIPMENT SHOULD BE INSTALLED, OPERATED AND SERVICED
ONLY BY TRAINED, QUALIFIED PERSONNEL, WHO ARE THOROUGHLY
FAMILIAR WITH THE ENTIRE CONTENTS OF THE INSTRUCTION BOOK.
DO NOT DISCARD THIS INSTRUCTION BOOK UPON COMPLETION OF
INSTALLATION. INFORMATION PROVIDED IS ESSENTIAL TO PROPER &

ENCORE 700 PLUNGER PUMP
SAFE OPERATION AND MAINTENANCE.
ADDITIONAL OR REPLACEMENT COPIES OF THIS INSTRUCTION BOOK ARE
AVAILABLE FROM:
Unit 10
Mill Hall Business Estate
Aylesford
Kent
ME20 7JZ
UK
NOTE
Minor part number changes may be incorporated into WPS products from time to time
that are not immediately reflected in the instruction book. If such a change has
apparently been made in our equipment and does not appear to be reflected in your
instruction book, contact your local WPS Sales Office forinformation.
Please include the equipment serial number in all correspondence. It is essential for
effective communication and proper equipmentidentification.

ENCORE 700 PLUNGER PUMP
SP-2: NOTES ON PROTECTIVE EQUIPMENT ANDCLOTHING.
The following Warning appears in several locations in this book. It is general in nature
due to the variety of hazardous liquids this pump is capable ofhandling.
WARNING: WHEN DEALING WITH HAZARDOUS MATERIAL,
IT IS THE RESPONSIBILITY OF THE EQUIPMENT USER TO OBTAIN AND
FOLLOW ALL SAFETY PRECAUTIONS RECOMMENDED BY THE MATERIAL
MANUFACTURER / SUPPLIER.
It is good general practice to make use of the following types of protective equipment
when handling any hazardous liquid.
IT IS RECOMMENDED THAT SUCH PROTECTIVE EQUIPMENT BE USED BY
ALL PERSONS SERVICING THIS PUMP, ASSOCIATED PIPING, TUBING,
VALVES, AND ACCESSORIES, WHEN THE PUMP IS HANDLING ANY
HAZARDOUS LIQUID.
1.
Goggles, flexible fitting, hooded ventilation
2.
Face Shield
3.
Chemical Apron
4.
Chemical Gloves

ENCORE 700 PLUNGER PUMP
SECTION 1 - TECHNICAL DATA
Pump Type
Variable Eccentric, Plunger type metering
pump. Simplex, Duplex and double
Simplex capabilities
Plunger / Gland
Ceramic Plunger, PTFE / Glass chevron
packing. Single or doublechevrons
Service
Metering of mild to very corrosive (water
like viscosity) chemicals.
Drive Unit
Directly coupled or pulley coupled motor.
Four stroking speeds 30,60,120,144SPM
Variable Speed
AC and DC speed control available.
Capacity Range
Up to 145 l/hr with single head.
Pressure Range
Up to 200 BAR. Refer to chart for
additional information.
Stroke length
10 turn stroke control. Adjustable over
10:1 range.
Accuracy
+/- 1% full scale over 10:1 range under
constant suction and discharge conditions.
Suction Lift
Up to 1M water lift
Motor Voltage
240 VAC, 50 Hz, 1 ph
415 VAC, 50 Hz, 3 ph
Ambient temperature limits
35-125 degF (2 -52 degC)
Lubrication
Gear oil, SAE90 with antifoam agent or
shell OMALA
Weight
50 kg (110 ibs) – average.

ENCORE 700 PLUNGER PUMP
1.2
Material Identification / Composition
The chemical composition of materials (these include optional variable materials) used in
the manufacture of the Metering Pump are listed in Table 1.2below.
Common Term
Composition
Ceramic
99% Aluminium Oxide
Hypalon
A Chlorosulphonated polyethylene
Kynar (PVDF)
Polyvinylidene fluoride
Stainless 316
AISI 316 – Cr 16 -18%
Ni 10 -14 %, C 0.08%, Mn 2%
Si 1%, P 0.045%, S 0.03%
Mo 2-3%
TFE
Fluorocarbon resin of tretrafluoroethylene
polymer
Viton
Copolymer of vinylidene and
perfluoropropylene or hexafluoropropylene
PVC
Polyvinyl Chloride
1.3
PUMP COMPATIBILITY
The compatibility of the Encore Plunger Metering Pump with various liquid materials
are listed in Dwg. 440.050.190.010A-F located at the end of this section. The table
identifies the various materials that can enter and come in contact with component
materials in the wetted end of the pump and its effect on pumpperformance.

ENCORE 700 PLUNGER PUMP

ENCORE 700 PLUNGER PUMP
440.050.190.010A-F

ENCORE 700 PLUNGER PUMP
440.050.190.010A-F
440.050.190.010A-F

ENCORE 700 PLUNGER PUMP

ENCORE 700 PLUNGER PUMP
440.050.190.010A-F
440.050.190.010A-F

ENCORE 700 PLUNGER PUMP
1.
WARNING: DRIED RESIDUE OF SPILLED
30.
HYPALONTO130°F
SOLUTIONSISEXPLOSIVE.
31.
PVC TO 100°F, 50%, SS TO 100°F, 50%
3.
SSTO180°F
32.
PVC TO 70°F, 10%, SS TO 70°F, 10%
5.
PVC TO 125°F
34.
SS TO 70°F, 5%, PVC 125°F SAT
6.
HYPALONTO180°F
35.
PVC TO 100°F, SS TO 70°F
7.
SS TO 125°F 10%, PVC TO 125°F
36.
VITON TO 100°F
8.
PVC TO 125°F, 29%, SS TO 180°F, 29%
37.
HYPALONTO150°F
9.
SS TO 70°F, 5%
38.
SS TO 70°F,10%
10.
PVC TO 105°F, 40%, SS TO 180°F SAT
39.
PVC TO 125°F, 80%, SS TO 70°F, 80%
11.
VITON TO 180°F
40.
PVC TO 100°F, SAT, SS TO 180°F, 50%
12.
PVC TO 100°F PURE
41.
SS TO 180°F, 5%
13.
VITON TO 158°F
42.
PVC TO 70°F, 50% OR TO 125°F, 30%, SS TO
14.
SS TO 140°F
180°F,50%
15.
USE SLURRY VALVES
43.
SS TO 140°F, 10%
16.
PVC TO 105°F, SS TO 180°F
44.
SS TO 180°F, 50%
17.
PVC TO 100°F, SS TO 100°F
45.
PVC TO 105°F
18.
SS TO 70°F DILUTE, PVC TO 125°F
46.
PVC TO 125°F, 4%, SS TO 70°F, 5%
19.
PVC TO 100°F, 50%, SS TO 70°F, 5%
47.
PVC TO 125°F, 15%, SS TO 70°F, 5%
20.
PVC TO 100°F, 25%, SS TO 180°F, 50%
48.
SS TO 125°F
21.
PVC TO 100°F, SS TO 160°F
49.
PVC TO 125°F, 41 Be, SS TO 140°F, 41 Be
22.
VITON TO 120°F
50.
PVC TO 125°F, 30%
24.
PVC TO 125°F, 36%, SS TO 180°F 10%
51.
PVC TO 125°F, 50%, SS TO 70°F, 50%
25.
FLUORIDATION REQUIRES AN ANTI-SYPHON
52.
PVC TO 100°F, 10%, SS TO 150°F
PUMP INSTALLATION CONSULT LOCALREGU-
53.
PVC TO 100°F, SS TO 180°F, 70%
LATIONS FOR DETAILS.
57.
KYNAR TO 70°F
26.
PVC TO 30%
58.
KYNAR TO 120°F
27.
PVC TO 125°F, 50%, SS TO 70°F, 5%
59.
KYNAR TO 120°F, 30%
28.
MAY CAUSE SURFACE PITTING TO SS
60.
KYNAR TO 100°F
29.
PVC TO 125°F, 48%
