WaterRower WRM6500 User manual

In order to ensure the correct use of Bluetooth
speaker and the good performance of Bluetooth
speaker, please read it carefully and comply with it：
Do not seriously impact.
Do not touch benzene, diluents or other
chemicals.
Keep away from strong magnetic fields and
electric fields.
Avoid direct light or heaters.
Do not disassemble, repair or transform by
yourself.
Do not use Bluetooth Speakers when riding a
bike, driving a car or motorcycle.
Do not listen at a high volume to avoid adverse
effects on hearing.
Waste packaging, batteries and electronic
products should be properly sorted and
disposed of.
This product takes product number and factory
date as the proof, executes one year free
warranty, every because of the mechanical
collision, the voltage is too high, the operation is
improper, opens the sound box privately to
cause the damage and so on is not in the free warranty.
Bluetooth speaker
Other description

1pc Bluetooth speaker
1pc Line in cable
1pc User mannal
power supply：lithium battery
Output power：30W
Product size：163mm×91mm×92mm
N.W.:0.8KG
Speaker unit：Two speakers
Speaker impedance：8Ω*2
Connection method：3.5mm Audio interface OR
Bluetooth
Shell material：walnut
FM Frequeny：87.5MHz~108MHz
Speaker Frequeny：70Hz-18KHz
Battery life：over 12 hours
connection distance：40m
If you are iPhone user ,please enter your PIN
for Bluetooth connection：0000。
1. Small knob (left)
-Adjust the volume.
2. Small knob (right)
-Function mode switch, clockwise to
Bluetooth mode, FM mode, AUX mode.
3. The big knob
-In FM mode, FM selects the preset
broadcast station.
4. Indicator light (left)
-Green: Lights up when you lock the FM
broadcast channel in FM mode.
5. Indicator light (right)
-Blue: Switch to bluetooth mode.
-Green: Switches to AUX mode.
-Orange: Switches to the FM mode.
-Green: The indicator blinks when charging.
The indicator is steady on when it is full.
-Red: The indicator blinks when the battery is
low.
6. Gestures
-Hand cut song: wave left/right horizontally
over the speaker to switch to up/next song.
-Gesture tuning: wave forward/backward
vertically over the speaker to increase/
decrease volume.。
-Tap the top of the speaker to pause/play.
Common function description
Packaging included
Technical parameters
Description

-Gesture controls do not work while charging.
7. AUX-IN
-Use 3.5mm audio cable to connect the audio
source device.
8. DC IN
-Use the Type-C interface adapter to charge
the speaker.
Use the Type-C interface adapter to connect to the
Type-C interface on the back of the speaker.
Warning: Unplug the charger when you go out.
Charger
-Charging: The green indicator on the right is
blinking.
-Charged: The green indicator on the right is
steady on.
-Using a Bluetooth Speaker while charging is
not recommended.
Auto sleep
-BLE mode: If bluetooth is not connected,
no operation is performed in five minutes.
-FM mode: Rotate the volume knob on the
left counterclockwise to the lowest, and
enter hibernation after five minutes without
performing any operation.
-AUX mode: NOT sleep.
Wake up
-BLE mode：Turn the left volume knob or tap
the top of the speaker.
-FM mode：Turn the left volume knob or tap
the top of the speaker.
LOW battery
-When the power is low, the speaker
automatically issues a prompt sound of
"beep -beep", and the red indicator light
flashes on the right side.
-When the indicator light on the right side is
off, the speaker cannot work. Please charge
it immediately.
Power on
-Turn the small knob on the right to the
desired mode, you will hear a "power on"
prompt.
volume adjustment
-Knob tuning: Turn the small knob on the left
to increase/decrease the volume.
-Gesture tuning: wave forward/backward
vertically over the speaker to
increase/decrease volume.
PLAY
-Wave horizontally to the left/right over the
speaker to switch to the previous/next
song; Tap the top of the speaker to control
pause/play.
FM mode
1. Rotate the small knob on the right to FM m
ode, and the indicator on the right is steady ora
nge.
2. Rotate the big knob on the right to adjust F
M frequency. After the broadcast channel is lock
ed, the light indicator on the left is steady gree
n.
Directions for use
FM mode
Power supply

3. In FM mode, the backlight behind the big kn
ob on the right is steady on.
4. Increase/decrease volume by waving forward/b
ackward vertically over the speaker.
BLE mode
You can transfer audio from the device to this s
peaker using a Bluetooth connection.
Instruction
Before pairing, be sure to turn on the speaker s
o that Bluetooth is turned on and the device ca
n be found. Bluetooth devices can be found wit
hin 40 meters of accessibility. Make sure you ha
ve enough power. If you cannot connect Bluetoo
th, un-pair the Bluetooth speaker, restart the Blu
etooth speaker, and try again.
1. Rotate the small knob on the right to select
Bluetooth mode. When thebluetooth mode
is disconnected, the blue indicator on the
right blinks.
2. Select Watermate on the device.
3. After the pairing is complete, the blinki
ng blue indicator turns to steady blue.
4. Operate the device and start playing mu
sic
Disconnect
-Power-off
Connect external audio sources
Use the 3.5mm audio interface to connect the
audio source device to the Bluetooth speaker.
Instruction
With the AUX-in jack on the back of the speaker,
connect to the external audio source using the
included 3.5mm audio interface.
5. Rotate the small knob AUX on the right
to select AUX mode.
6. After AUX mode is selected, the indicat
or on the right is steady green.
7. Press the play button on the device to
start playing music.
PLAY
PLAY
-Turn the small knob on the left to
increase/decrease the volume.
NO voice
-Wave forward/backward vertically over the
speaker to increase/decrease volume.
-Adjust volume knob.
-Reinsert the 3.5mm audio cable.
-Restart the speaker.
Poor broadcast signal
-Increase the distance between a Bluetooth
speaker and a TV or other radiation source.
BLE mode
AUX-IN
Solutions of common problem

-Move to an area with better reception, such
as a balcony or window.
Even when Bluetooth is connected, the
speakers still can't play music
-The device cannot play music wirelessly
through the speaker.
Poor audio quality when connected to
Bluetooth-enabled devices
-Bluetooth reception is not good, move the
device closer to the speaker or remove the
barrier between the two.
Can-not connect to speaker
-The device does not support the
configuration file required by the speaker.
-The Bluetooth function of the speaker is
disabled. Refer to the speaker's user manual
for information on how to enable Bluetooth.
-This speaker is connected to other Bluetooth
devices. Disconnect the device and try again.
FCC Statement
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the
equipment and receiver.
-Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced
radio/TV technician for help.
Caution: Any changes or modifications to
this device not explicitly approved by
manufacturer could void your authority to
operate this equipment.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not
cause harmful interference, and (2) this
device must accept any interference
received, including interference that may
cause undesired operation.
RF Exposure Information
The device has been evaluated to meet
general RF exposure requirement. The
device can be used in portable exposure
condition without restriction.
