Waterware Brugman UNI6 Series User manual

Warranty
If any fault arising from the manufacturing processes is found in a new radiator and if after consultation with Waterware, the product is
returned, within 10 YEARS for inspection and or testing, Waterware will repair or exchange the product at its sole discretion.
Any costs associated with the removal, replacement and return of any faulty product are not accepted without prior arrangement with
Waterware. Under no circumstances will such costs be accepted by Waterware for products purchased and installed in remote, rural
and or locations greater than 50km’s from the point of purchase. Also included is a 25 year Functional Warranty; covers structural and
functional failure of steel components incl. welding but excludes the paint finish and is in addition to the existing 10 year Conditional
Guarantee
Warranty does not apply where faults arise from;
• normal wear and tear to surface finishes
• normal maintenance, cleaning or tuning requirements or faults that are a result of minimum maintenance requirements not being
followed.
• foreign matter in the water supplies.
• water supplies that do not meet normal expected municipal water quality standards.
• installation in a manner not in accordance with the manufacturers recommendations or relevant NZ and or Australian Standards and
local plumbing codes including G12.
• environment operating conditions that are outside the minimum and or maximum recommendations
Evidence must be produced which confirms the relevant product was purchased from a known customer of Waterware to validate any
claim.
Obligations accepted by Waterware are....
In addition to all other rights and remedies had by the Purchaser in law in respect of the product and does not limit the right the
Consumer may have under the Consumers Guarantee Act 1993.
Subject to the exceptions and conditions previously listed, all expressed or implied conditions, statements warranties as to the quality
of fitness on any purpose of a product or otherwise are hereby expressly excluded to the fullest extent permitted by law except under
conditions and warrants which cannot be legally excluded by law and which are intended in the contract for the supply of the valve by
the Trade Practises and any other Act of Law.
UNI6 & Centric Verti Steel Panel Radiator Installation Manual
Types: 21, 22
Heights: 400, 600, 1800, 2000mm
6 Port Connections: 2 x ¾” external thread euroconus bottom connections
4 x ½” internal thread side connections
Brackets: J-bracket
Colour: RAL 9016
Max. Operating Pressure: 10 bar (tested at 13 bar)
Max. Operating Temp: 120 °C
Type 21 Single Convector
82mm
Type 22 Double Convector
102mm
Radiator Valve Options
Valve kits are available separately with 1/2” copper or 16x2mm multilayer pipe specific connectors.
Caleffi Multi-layer
Kit contains polished chrome
radiator and lock-shield valves,
multi-layer pipe connectors and
thermostatic head.
Caleffi H-pattern bottom entry
Caleffi high style polished chrome
H-pattern bottom entry angle
valve kit containing valve, 16x2mm
multi-layer pipe connectors.
Project bottom entry
Under mounted chrome
monoblock valve and
thermostatic head.
Specifications Height(B) Width Type 21 Output(W) Type 22 Output(W)
RSB**400600 400 600 726 NA
RSB**400800 400 800 968 NA
RSB**400100 400 1000 1210 1567
RSB**400120 400 1200 1453 1831
RSB**400140 400 1400 NA 2137
RSB**400160 400 1600 1937 2442
RSB**400180 400 1800 NA 2748
RSB**400200 400 2000 2421 3053
RSB**600600 600 600 1007 1283
RSB**600800 600 800 1344 1709
RSB**600100 600 1000 1679 2137
RSB**600120 600 1200 2014 2565
RSB**600140 600 1400 2351 2992
RSB**600160 600 1600 2686 3420
RSB**600180 600 1800 3023 3847
RSB**600200 600 2000 3358 4275
RSB**600240 600 2400 N/A 5130
RSB**180400 1800 400 N/A 1979
RSB**180600 1800 600 N/A 2969
RSB**180800 1800 800 N/A 3959
RSB**200400 2000 400 N/A 2129
RSB**200600 2000 600 N/A 3193
RSB**200800 2000 800 N/A 4257
Outputs calculated with 85ºC flow, 75ºC return, room temp 20ºC
09 273 9191
[email protected]
waterware.co.nz

400mm / 600mm UNI6 Horizontal Models
The UNI6 horizontal model has a bottom connection and four side connections. By using the J-bracket it
is possible to mirror reverse the radiator, so that the thermostat knob can be mounted on the left or right.
1800mm / 2000mm Centric Verti Vertical Models
The Centric Verti vertical model has a middle connection (underneath) and two bottom connections
(side). The two top connections are for installing the air vent.
