WAVEE W-1 User manual


Model: W-1
Toothbrush Speaker System

Thank you for purchasing the W-1, the world's rst electric toothbrush speaker system with Alexa
built-in!
The W-1 works double duty in the bathroom through a seamless integration of two devices that
perform important functions within a person’s daily routine. The electric toothbrush is built with
leading technology to provide eective teeth cleaning through a powerful 4-speed motor and
sonic wave brush head. The accompanying water-resistant bluetooth speaker delivers full and
rich-sounding audio, allowing users to consume their favorite audio content and more - while
getting ready in the bathroom.
With Amazon Alexa, your personal virtual assistant, use your voice to initiate your music player,
create a to-do list, set an alarm, stream a podcast, play audiobooks, report on the weather, trac,
sports and news.
We advise you to read and keep the following instructions in order to correctly setup your new
device and enjoy all of its features to the fullest.
The Wavee Team
Introduction

Important Safeguards
When using electrical products, basic safety precautions should always be followed. You can
reduce your risk of injury by following these guidelines. Please read (and save) all instructions
before using your W-1.
WARNINGS/CAUTIONS (To reduce the risk of burns, electrocution, re or injury):
1. Do NOT drop, hit or shake the device.
2. Do NOT place heavy objects on top of the speaker.
3. Do NOT expose the speaker or toothbrush to sources of excessive of heat, or direct sunlight for
prolonged periods of time.
4. Never submerge the speaker in water or other liquid. Do not use the speaker or charger if it has.
5. Do not expose speaker to water while using the charging cable. Ensure the USB port is sealed
using the rubber cover at all other times.
6. Never touch the power plug with wet hands.
7. Only use brush heads specied by the manufacturer.
8. Unplug the speaker during lightning storms or when unused for long, extended periods of time.
9. Discontinue use if the toothbrush, charging cable or speaker appears damaged in any way
(brush head, handle, speaker, charger), does not operate normally, or has been dropped. Do NOT
disassemble, repair or modify the speaker or toothbrush.
10. When using external adapter, the output voltage/current of the external adapter should not
exceed 5V/3A.
11. Never drop or insert any object into the charging cradle
12. Keep out of reach of children.
13. When disposing of the product, carefully hand over to an ocially designated recycling center
for environmental protection.
14. If your toothpaste includes peroxide, baking soda or other bicarbonate (common in whitening
toothpastes), be sure to thoroughly rinse the brush head and handle to avoid chemical damage to
the plastic.
15. Clean the product with water. Do NOT use cleaning products that contain benzene, solvents
or alcohol.
16. To prolong battery lifespan, fully charge at least once every 3 months. Battery life will vary due
to usage patterns and environmental conditions.

MEDICAL WARNING
1. If you have a pacemaker or other implanted device, consult your physician prior to using
your W-1.
2. Consult your physician prior to using your W-1 if you have any medical concerns.
3. Consult your dental professional before you use your W-1 if you have had oral or gum surgery
in the previous six months.
4. This product is designed to clean your teeth, gums and tongue only. Discontinue use of this
product and contact a physician/dentist if discomfort or pain occurs.
REGULATORY INFORMATION
FCC ID
Toothbrush: FCC ID: 2AW2XW1ETB
Bluetooth Speaker: FCC ID: 2AW2XW1BTS
IC ID
Toothbrush: IC: 26328-W1ETB
Bluetooth Speaker: IC: 26328-W1BTS
iPhone 11 Pro Max iPhone 8
iPhone 11 Pro iPhone 7 Plus
iPhone 11 iPhone 7
iPhone XS Max iPhone SE
iPhone XS iPhone 6s Plus
iPhone XR iPhone 6s
iPhone X iPhone 6 Plus
iPhone 8 Plus iPhone 6
IPX7
TOOTHBRUSH
SPEAKER
IPX5

Package Contents
Toothbrush Handle Toothbrush Head
Bluetooth Speaker Detachable Wall
Mount Plate
USB-C Charging
Cable & Adaptor

To charge the toothbrush, place it inside the speaker's charging cradle while connected to a power
source. The brush is in the correct position when the toothbrush's bristles are pointing towards
you.
When the toothbrush's battery is low the battery status light will ash 3 times, indicating that it
needs to be charged. While charging, the battery status LED will ash red. When charging is
complete, the LED surrounding the Power button will illuminate to a solid white. It typically takes
24 hours for a drained battery to fully recharge.
Note: The toothbrush cannot be powered on while it is charging.
To charge the speaker, connect it to a power source using the provided USB-C charging cable. You
can use the provided power adaptor or any USB-compatible input that provides USB power. When
the speaker's battery is low, its LED light will ash red for 10 seconds every 3 minutes.
When rst connected to a power source, the speaker's LED light will ash white for 10 seconds to
indicate charging. It typically takes 3 hours for a fully drained battery to recharge. The speaker's
LED light will illuminate white for 10 seconds when charging is complete.
It is possible to charge the toothbrush while using the speaker wirelessly. Please note, charging
time and eectiveness will vary based on the battery level of the speaker and whether it is in use.
Charging the Toothbrush & Speaker

Toothbrush Overview
Toothbrush Head -------------------------
Toothbrush Handle --------------------
Power Button /
Brushing Mode --------------------------
Selector
Battery Status Light -------------------
-------------------- Clean Brushing Mode
------------------- White Brushing Mode
--------------- Sensitive Brushing Mode
------------ Face Clean Mode (Requires
Atthachment)

1. Assembly
Mount the included brush head on top of the toothbrush handle's metal shaft with the bristles
facing forward. Apply gentle pressure downwards until you hear a click. There should be a small
gap between the brush head and handle.
To replace a brush head, grip from the top and pull directly away from the toothbrush handle
until it detaches. Attach a new brush head following the instructions above.
2. Rinsing
Before every brushing, rinse the brush head with fresh water to moisten the bristles. Apply your
desired amount of toothpaste on the head.
3. Select Brush Mode
Your W-1 toothbrush features 4 brushing modes to adjust to your needs:
Clean - 41,000 rpm - Standard mode for superior daily cleaning
White - 48,000 rpm - Deep cleaning mode for surface stains, polishing and vigorous cleaning
Sensitive - 33,000 rpm - Gentle cleaning along the gumline
Attachment - 33,000 rpm - Gentle face cleaning (requires an external attachment)
To begin brushing, press the power button. Select the brush mode by pressing the power button
again until your desired mode's LED light is illuminated. By default, Clean mode is selected when
the toothbrush is powered on for the rst time.
Note: Mode selections can be made within 5 seconds of each other. After 5 seconds, the current
mode will lock and the next press of the power button will shutdown the toothbrush.
To power down the toothbrush, wait at least 5 seconds after turning it on and
then press the power button.
Brushing

Toothbrush Features
1. Mode Memory
Once a mode is locked it becomes the default mode when the toothbrush is powered back on.
This allows for quick one-touch operation of your toothbrush each use.
2. 30-Second Quadrant Timer
While the toothbrush is powered on, it will quickly pause every 30 seconds, signalling you to
switch over to another quadrant of your mouth (top right, top left, bottom right, bottom left),
allowing for an even clean each time.
3. 2-Minute Duration Timer
For an eective daily cleaning, dental professionals recommend brushing your teeth for at least
2 minutes, twice a day. The W-1 is congured to automatically shut down after 2 minutes, allowing
for eective and convenient brushing with minimal eort. The external attachment mode is
congured to automatically shut o after 3 minutes.
4. Extended Battery Life
The W-1's lithium ION battery typically provides 28 days of brushing on one charge, allowing for
convenient travel packing and tidy bathroom setups.

Speaker Overview
Volume Decrease -------
Action / Alexa
Button ------------------------
Power
--------------
---------- Volume Increase
Bluetooth
---------------------- Pairing
Toothbrush Charging Cradle
--------------

USB-C Charging Port
----------------
Detachable Wall Mount Plate Slot
--------------

Using The Speaker
Button Operation
Button Symbol Short Press Function Long Press Function
Power Enable or disable ECO Mode (2 short presses) Turn speaker ON/OFF (2 secs), Force Reboot (8 secs)
Bluetooth None Pair a new device (3 secs), Factory Reset (10 secs)
Action Access Alexa from speaker Enable or disable Mute
Action Pick up an incoming phone call Hang up an active phone call
Volume Up Increase speaker volume - Level 0 to 16 Increase speaker volume - Level 0 to 16 continuous
Volume Down Decrease speaker volume - Level 16 to 0 Decrease speaker volume - Level 16 to 0 continuous
Status Indicators
Speaker Status Behaviour LED Colour
Idle None None
Battery Charging Flashing - 10 seconds
Battery Fully Charged Solid - 10 seconds Solid White for 10 seconds
Battery Low Flashing - 10 seconds every 3 minutes Flashing Red for 10 seconds every 3 minutes
Bluetooth Pairing Mode Active Flashing Flashing Blue
Bluetooth Connected Solid Solid Blue
Muted Solid Solid Red
Voice Input / Listening Solid Solid Cyan
Thinking Colours alternating (100ms) Cyan / Blue
Alexa Talking Colours Pulsing (500ms) Cyan / Blue
Exception Flashing - 3 times Red
Notication Slow pulsing (2000ms) Yellow
1. Eco-Mode & Auto Shut O
Your W-1 speaker is congured with two features to help conserve battery power when it is not in
charging mode:
i. Eco-Mode: When Eco-Mode is on, the LED ring light will turn o after 5 seconds of user operation.
When set to o, LED brightness remains constant at 50%.
ii. After 15 minutes of idle operation (no outgoing / incoming audio, user actions or requests), the
speaker will automatically shut o.
+
_

2. Pair with a Smart Device
To pair the speaker with a smart device for the rst time, follow the steps below:
i. To begin, ensure the speaker is powered OFF.
ii. Enable Bluetooth on your smart device to make it discoverable.
iii. Press and hold the POWER button to turn on the speaker. It will begin searching for a device to
pair with by default.
iv. Locate and select your WAVEE W-1 speaker from the device list.
v. Once paired, the speaker will play, "Bluetooth Connected" and the LED indicator will glow solid
blue.
To pair the speaker with a smart device at any other time, press and hold the bluetooth button to
enable pairing mode. Locate the speaker on your smart device and connect.
3. Connect to Alexa
To connect the speaker with Alexa, Amazon's virtual personal assistant, follow the steps below:
i.To begin, ensure that you have the Amazon Alexa app installed on your smart device. To
download, search using 'Amazon Alexa' in either the Apple App Store or Google Play Store,
depending on your device and operating system.
Note: Amazon Alexa requires the use of bluetooth to function on the speaker. If necessary, toggle
to your smart device's settings menu and allow Amazon Alexa to access bluetooth.
ii. Open the app and sign into your Amazon Account. If you do not have an existing Amazon
account, follow the on-screen instructions to create a New Account before proceeding.
iii. If this is the rst time opening up the app, you will be prompted to setup a new device. Select
'Yes' to proceed. If this is not your rst time, select 'Add new Device' from the Devices menu.
iv. When prompted to select a device to setup, select 'Other Device'.
v. When prompted to select what type of device to setup, select 'Bluetooth
Speaker'.

vi. Allow the Alexa app to access your microphone by selecting, 'Continue'.
vii. Make sure the speaker is powered on and is ready to connect.
viii. Alexa app will begin searching for devices. Select WAVEE-001 from the list.
ix. Allow the Alexa app to setup your W-1 by selecting 'Continue'.
x. Follow the on-screen prompts to complete the setup.
To speak to Alexa, press the Action button once. The speaker will chime once and show a cyan ring
as it waits for your voice.
When Alexa responds or carries out your request, the speaker will glow blue and cyan
intermittently.
4. Sample Alexa Commands
The list of Alexa commands continues to grow as more third party devices join the Amazon
network. Below are some sample commands to help improve your morning routine:
Ask the time: "Alexa, what time is it?"
Learn your Calendar: "Alexa, what does my day look like?"
Get trac information: "Alexa, what's my commute look like?" or "Alexa, what's
trac like?"
Create a list on the spot: "Alexa, create a list"
Check dates: "Alexa, when is [holiday] this year?"
Track packages from Amazon: "Alexa, where's my stu?" or "Alexa, track my order."
Full a full list of commands, visit www.amazon.com/meetalexa.
5. Wall Mount (Optional)
For bathrooms with limited space or for additional convenience, your W-1 can be mounted on a
wall using the included wall mount. Using 3M double-sided command stripes is recommended
for safe and sturdy installation. Simply apply at least 2 command strips to the wall mount and
then fasten to your mirror or wall of choice.

Frequent Questions & Troubleshooting
1. Q: How should I clean the speaker?
A: Clean the surface of the speaker with a soft, damp cloth (water only). Do not use any sprays
near the speaker. Do not use any solvents, chemicals or cleaning solutions containing alcohol,
ammonia or abrasives.
2. Q: Does the speaker need to be plugged into a power outlet to operate?
A: No. The speaker is powered by a lithium ion battery that provides a playback time of 8 hours
when fully charged. Charging through the provided USB-C cable will take approximately three
hours. Note: Continuous wireless playback time will be aected if the toothbrush is charging.
3. Q: No power from Speaker?
A: Battery may be discharged. Connect the USB charging cable.
4. Q: Speaker Battery does not charge
A: Possible Solutions:
o Make sure you are using a USB cable provided by Wavee or one from a qualied manufacturer.
o Connect the USB cable to a dierent USB power supply.
o Use a dierent USB cable.
o Connect to a dierent AC power source.
5. Q: Speaker does not pair with mobile device
A: Possible Solutions:
o For best Bluetooth® performance, place your smart device within 33 ft. (10 m) of the speaker,
and make sure there is a clear line of sight between you and the speaker.
o On your mobile device, turn the Bluetooth feature o and then on.
o Remove your speaker from the Bluetooth list on your device. Pair your device again.
o Pair a dierent device
6. Q: No sound from Speaker
A: Possible Solutions
o Increase the volume on your speaker, your device and music source.
o Make sure you are using the correct device.
o Use a dierent music source.

7. Q: No response or slow response to Alexa commands
A: Alexa voice recognition is activated when the microphone button is depressed on the
speaker and Amazon’s Alexa app is open and running in the background of your smart phone.
Possible Solutions:
o Make sure you downloaded and installed correct Amazon Alexa App.
o Make sure have the latest app version.
o Make sure you do not have any network issues.
o Make sure to speak to the microphone within 1 meter.
o Uninstall then reinstall the APP, power the speaker O, then On, and restart setup.
8. Q: Speaker powers o unexpectedly
A: If the speaker is powered on and not connected to a power source, it will shut o
automatically after 10 minutes of idle activity to conserve battery power. To avoid this shuto,
connect to a power source.
9. Q: Toothbrush is not as powerful
A: Possible Cause:
o A dierent default mode was selected
o Worn brush head or gunk buildup in handle shaft/charge
Solution:
o Press power button and change brush mode to your desired setting
o Replace brush head and clean handle and charger with damp cloth. Make sure shaft is clear
of any gunk, then charge unit for at least 24 hours.
10. Q: For electric toothbrush which is not used for a period of time, indicator light does not
shine when charging.
A: If the toothbrush is not used for a period of six months or longer, the battery will enter a
dormant state and needs 6-15 minutes after re-charging to wake up, which is a normal behavior.
11. Q: Do you oer replacement heads?
A: Replacement heads are available through the Wavee Subscription program or as a one-time
purchase on our website, www.waveeworks.com.
12. Q: If I have comments/questions about my Wavee W-1, what should I do?
A: For any additional questions or comments you have, please visit our website
at www.waveeworks.com or email our support team at [email protected]om

Our Promise & Limited Warranty
Wavee is committed to providing professional quality products for its customers. If your W-1 is
not working properly or you begin to experience any issues, please refer to our frequently asked
questions section for quick help. If this does not solve your issue, please email our support team
at [email protected]om. We are pleased to help resolve any issues you may have in a
timely manner.
Limited Warranty
Your W-1 Toothbrush is protected by a two year warranty against manufacturing defects and
malfunction. The same warranty applies to the speaker, for one year.
Our warranty does not cover brush heads, normal wear and tear or damage caused by misuse.
Please contact us at [email protected]om if you have any questions or concerns with
your product.

TOOTHBRUSH
Modes: White: 48,000 vibrations per min
Clean: 41,000 vibrations per min
Sensitive: 33,000 vibrations per min
Controls and Settings: 2-min shutdown timer
30 sec quadrant-interval timer
LED Display Mode Indicator
Power: Power Source:
Rechargeable Lithium ION Battery
Approx. 25-day battery life / 240 mins
continuous
Charging Type: Inductive
Physical Features: Dimensions: 180 millimetres length (7.08 inches)
22 millimetres diameter (0.88 inches)
Weight: 97 grams
Colour: Cool Grey
Waterproof Rating: IPX7
Noise: < 67 db
Brush Head Dimensions: 78 millimetres total length (3.07 inches)
22 millimetres bristle coverage
(0.88 inches)
Wavee W-1 Technical Specs

SPEAKER
Wireless Connectivity: Bluetooth 5.0
Amazon Alexa Compatible
Inputs: USB Connection:
USB-C port
On-Board Microphone: Yes
Power: Power Source:
Rechargeable Lithium ION Battery
12 hours continuous playback time
USB-C Device Charging Cable
Physical Features: Dimensions:
120 millimetres high (4.72 inches)
115 millimetres diameter (4.52 inches)
Weight: 800 grams (1.67 pounds)
Color: Cool Grey
Water Resistance:
IPX5 Rating:
Splash-Proof

For updates, promotions and experience sharing, join our user communities:
[e-mail]
www.waveeworks.com
FCC ID: 2AW2XW1ETB
FCC ID: 2AW2XW1BTS
IC: 26328-W1ETB
IC: 26328-W1BTS

@waveeworks
