WBOX Technologies 0E-4CHNVR2TB User manual

Network Video Recorder(NVR)
User Manual
0E-4CHNVR1TB
0E-4CHNVR2TB
0E-8CHNVR2TB
0E-16CHNVR2T
0E-16CHNVR4T
If you have any questions, please call
W Box Tech Support 1-833-574-9124
for assistance.
E-mail：[e-mail]

Network Video Recorder(NVR)
User Manual
Precautions
Issue V1.0 (2018-05-11)
i
Precautions
Precautions
Fully understand this document before using this device, and strictly observe rules in
this document when using this device. If you install this device in public places,
provide the tip "You have entered the area of electronic surveillance" in an eye-
catching place. Failure to correctly use electrical products may cause fire and severe
injuries. To prevent accidents, carefully read the following context:
Symbols
This document may contain the following symbols whose meanings are described
accordingly.
Symbol
Description
It alerts you to fatal dangers which, if not avoided, may
cause deaths or severe injuries.
It alerts you to moderate dangers which, if not avoided,
may cause minor or moderate injuries.
It alerts you to risks. Neglect of these risks may cause
device damage, data loss, device performance
deterioration, or unpredictable results.
It provides a tip that may help you resolve problems or
save time.
It provides additional information.
To prevent electric shocks or other dangers, keep power plugs dry and clean.
Strictly observe installation requirements when installing the device. The
manufacturer shall not be held responsible for device damage caused by users' non-
conformance to these requirements.

Precautions
Network Video Recorder(NVR)
User Manual
ii
Issue V1.0 (2018-05-11)
Strictly conform to local electrical safety standards and use power adapters that are
marked with the LPS standard when installing and using this device. Otherwise,
this device may be damaged.
Use accessories delivered with this device. The voltage must meet input voltage
requirements for this device.
If this device is installed in places with unsteady voltage, ground this device to
discharge high energy such as electrical surges in order to prevent the power supply
from burning out.
When this device is in use, ensure that no water or any liquid flows into the device.
If water or liquid unexpectedly flows into the device, immediately power off the
device and disconnect all cables (such as power cables and network cables) from
this device.
Do not focus strong light (such as lighted bulbs or sunlight) on this device.
Otherwise, the service life of the image sensor may be shortened.
If this device is installed in places where thunder and lightning frequently occur,
ground the device nearby to discharge high energy such as thunder strikes in order
to prevent device damage.
Avoid heavy loads, intensive shakes, and soaking to prevent damages during
transportation and storage. The warranty does not cover any device damage that is
caused during secondary packaging and transportation after the original packaging
is taken apart.
Protect this device from fall-down and intensive strikes, keep the device away from
magnetic field interference, and do not install the device in places with shaking
surfaces or under shocks.
Clean the device with a soft dry cloth. For stubborn dirt, dip the cloth into slight
neutral cleanser, gently wipe the dirt with the cloth, and then dry the device.
Do not jam the ventilation opening. Follow the installation instructions provided in
this document when installing the device.
Keep the device away from heat sources such as radiators, electric heaters, or other
heat equipment.
Keep the device away from moist, dusty, extremely hot or cold places, or places
with strong electric radiation.
If the device is installed outdoors, take insect- and moisture-proof measures to
avoid circuit board corrosion that can affect monitoring.
Remove the power plug if the device is idle for a long time.
Before unpacking, check whether the fragile sticker is damaged. If the fragile
sticker is damaged, contact customer services or sales personnel. The manufacturer
shall not be held responsible for any artificial damage of the fragile sticker.

Network Video Recorder(NVR)
User Manual
Precautions
Issue V1.0 (2018-05-11)
iii
Special Announcement
All complete products sold by the manufacturer are delivered along with nameplates,
operation instructions, and accessories after strict inspection. The manufacturer shall
not be held responsible for counterfeit products.
This manual may contain misprints, technology information that is not accurate enough,
or product function and operation description that is slightly inconsistent with the
actual product. The manufacturer will update this manual according to product function
enhancement or changes and regularly update the software and hardware described in
this manual. Update information will be added to new versions of this manual without
prior notice.
This manual is only for reference and does not ensure that the information is totally
consistent with the actual product. For consistency, see the actual product.

Contents
Network Video Recorder(NVR)
User Manual
iv
Issue V1.0 (2018-05-11)
Contents
Precautions.................................................................................................................... i
1 Specifications............................................................................................................ 1
2 Hard Disk .................................................................................................................. 3
2.1 Precautions..................................................................................................................... 3
2.2 Hard Disk Recommendation .......................................................................................... 3
2.3 Approximate Video Storage Duration............................................................................. 3
2.4 Hard Disk Installation .................................................................................................... 4
3 Operation Instruction.............................................................................................. 8
3.1 Front panel ..................................................................................................................... 8
3.2 Rear panel....................................................................................................................... 8
3.3 Startup.......................................................................................................................... 10
3.4 Shutdown ......................................................................................................................11
3.5 Adjusting the Screen Resolution of the Monitor........................................................... 12
3.6 Login............................................................................................................................ 13
3.7 Changing password ...................................................................................................... 14
3.8 Adding Webcams.......................................................................................................... 15
4 Quick Setup ............................................................................................................ 16
5 Live Video ............................................................................................................... 20
6 Video Playback....................................................................................................... 25
6.1 Video Playback............................................................................................................. 25
6.2 Video Backup............................................................................................................... 26
7 Alarm Search .......................................................................................................... 29
8 Setting ...................................................................................................................... 31
8.1 NVR Setup................................................................................................................... 31
8.1.1 Device Information .......................................................................................... 31
8.2 Device .......................................................................................................................... 32
8.2.1 Network............................................................................................................ 32
8.2.2 System.............................................................................................................. 34
8.2.3 Device Port....................................................................................................... 35
8.2.4 Date and Time.................................................................................................. 36

Network Video Recorder(NVR)
User Manual
Contents
Issue V1.0 (2018-05-11)
v
8.3 Channel ........................................................................................................................ 39
8.3.1 Manage Channel .............................................................................................. 39
8.3.2 Camera Information ......................................................................................... 39
8.3.3 Stream.............................................................................................................. 40
8.3.4 Network............................................................................................................ 44
8.3.5 OSD ................................................................................................................. 46
8.3.6 Privacy Masking .............................................................................................. 49
8.3.7 Motion Alarm................................................................................................... 50
8.3.8 Intelligence Analyse Alarm.............................................................................. 52
8.3.9 Video Lost Alarm............................................................................................. 53
8.3.10 Alarm Input.................................................................................................... 55
8.3.11 Camera Maintenance...................................................................................... 56
8.4 Live Video Layout........................................................................................................ 56
8.5 Record.......................................................................................................................... 59
8.5.1 Record Policy................................................................................................... 59
8.5.2 Storage ............................................................................................................. 61
8.6 Network Service........................................................................................................... 62
8.6.1 DDNS............................................................................................................... 62
8.6.2 PPPoE .............................................................................................................. 64
8.6.3 SMTP............................................................................................................... 66
8.6.4 IP Filter ............................................................................................................ 67
8.7 External Device............................................................................................................ 69
8.7.1 Display screen.................................................................................................. 69
8.8 Alarm............................................................................................................................ 70
8.8.1 Alarm Input...................................................................................................... 70
8.8.2 .Alarm Out ....................................................................................................... 70
8.8.3 Disk Alarm....................................................................................................... 71
8.9 Privilege ....................................................................................................................... 72
8.10 Device Log................................................................................................................. 76
8.10.1 Alarm Log ...................................................................................................... 76
8.10.2 Operation Log................................................................................................ 78
8.11 Scheduled Reboot....................................................................................................... 80
8.12 System........................................................................................................................ 81
8.13 Maintenance............................................................................................................... 82
9 Web Access.............................................................................................................. 84
9.1 Login............................................................................................................................ 84
9.2 Live Video.................................................................................................................... 85
9.3 Video Playback............................................................................................................. 85

Contents
Network Video Recorder(NVR)
User Manual
vi
Issue V1.0 (2018-05-11)
9.4 Alarm Search................................................................................................................ 86
9.5 NVR Setup................................................................................................................... 87
10 FAQ ........................................................................................................................ 89

Network Video Recorder(NVR)
User Manual
1Specifications
Issue V1.0 (2018-05-11)
1
1 Specifications
Model
0E-4CHNVR1TB
0E-4CHNVR2TB
0E-8CHNVR2TB
0E-16CHNVR2T
0E-16CHNVR4T
VIDEO/AUDIO INPUT
Video Input
4ch
8ch
16ch
Incoming
Bandwidth
40Mbps ,(main
stream 32Mbps ,sub
stream 8Mbps)
80Mbps ,(main
stream 64Mbps ,sub
stream 16Mbps)
160Mbps ,(main
stream
128Mbps ,sub
stream 32Mbps)
Outgoing
Bandwidth
Total 80Mbps
Total 128Mbps
Total 128Mbps
Audio Input
G711_A/G711_U
VIDEO/AUDIO OUTPUT
Live
View/Playback/
Recording
Resolution
6MP/5MP/4MP/3MP/1080P/960P/720P/D1/VGA/CIF/QCIF
Frame Rate
6MP/5MP/4MP/3MP@15fps; 1080P@30fps
Live View/Playback
Resolution
Live View: 4ch
1080P/1ch
6MP,@30fps
Playback:4ch
1080P/1ch 6MP
Live View: 8ch
D1/4ch 1080P/1ch
6MP,@30fps
Playback: 4ch
1080P/1ch 6MP
Live View: 16ch
D1/4ch 1080P/1ch
6MP,@30fps
Playback:4ch
1080P/1ch 6MP
HDMI/VGA Output
1920x1080/60Hz,1280x720/60Hz,1024x768/60Hz
Audio Output
1ch,Line out
Hard Disk
SATA HDD
1 SATA interface
for 1HDD
2SATA interface for
2HDD
4SATA interface for
4HDD
Mounting Mode
Embedded
Capacity
Up to 6TB for each disk
NETWORK
Network Interface
1 RJ45 10M/100M/1000M network interface

1Specifications
Network Video Recorder(NVR)
User Manual
2
Issue V1.0 (2018-05-11)
Model
0E-4CHNVR1TB
0E-4CHNVR2TB
0E-8CHNVR2TB
0E-16CHNVR2T
0E-16CHNVR4T
Protocol
RTP/RTCP,TCP/UDP,HTTP,DHCP,DNS,NTP
POE Interface
4ch
100Mbps ,IEEE802.
3af
8ch
100Mbps ,IEEE802.
3af
16ch
100Mbps ,IEEE802.
3af
POE Max Power
36W
120W
160W
INTERFACE
HDMI/VGA
1ch HDMI, 1ch VGA
USB
USB 2.0 x2
USB 2.0 x2, USB
3.0 x1
Audio I/O
1ch MIC in,1ch audio line out
Alarm I/O
2ch Alarm output, 2ch Alarm input
Reset Button
Yes
GENERAL
Power Supply
DC48V-DC52V,
Max Input 70W
AC110/220V Max
input180W
AC110/220V,47-
63Hz ,Max input
300W
Power Consumption
Max 10W(without HDD,USB,POE)
Max 15W(without
HDD,USB,POE)
Operating
Temperature
-10°C ~ 45°C (14°F ~ 113°F )
Operating Humidity
0% - 90% RH
Chassis
Smart 1U
1.5U
Product Dimensions
255x235x47.5mm
372x311x44.5mm
440x376x67mm
Product Weight
930g
2.8kg
4kg

Network Video Recorder(NVR)
User Manual
2Hard Disk
Issue V1.0 (2018-05-11)
3
2 Hard Disk
2.1 Precautions
Formatting will clear all video data on the hard disk. Use this function only when
necessary.
Be sure to uninstall the hard disk before removing it from the NVR during runtime;
otherwise, the hard disk may be damaged or data may be lost.
The NVR must be connected to a stable power supply during runtime; otherwise,
the hard disk may be damaged or data may be lost.
The maximum capacity of a single hard disk cannot exceed 6 TB.
2.2 Hard Disk Recommendation
Seagate or Western Digital hard disks which are highly stable and inexpensive are
recommended.
2.3 Approximate Video Storage Duration
Table 2-1 Approximate Video storage duration
Maximum Hard Disk
Capacity
Maximum Bit Rate
Approximate Video
Storage Duration
1 ×6 TB
18 Mbps
28 days
2×6 TB
36 Mbps
28 days
4 ×6 TB
72 Mbps
28 days
Formulae for calculating the approximate video storage duration:
Step 1 Use the following formula to calculate the storage capacity q(unit: MBybte) required
to record a single video per hour:
q = d/8×3600/1024

2Hard Disk
Network Video Recorder(NVR)
User Manual
4
Issue V1.0 (2018-05-11)
dindicates the bit rate (unit: Kbit/s).
Step 2 Use the following formula to calculate the approximate video storage duration t (unit:
day)
windicates the capacity (unit: Mbyte) of a single hard disk.
nindicates the number of disks.
hindicates the recording duration per day.
cindicates the number of video inputs of the NVR.
Table 2-2 shows examples of approximate video storage duration (his 24 hours).
Table 2-2 Examples of approximate video storage duration
Hard Disk
Capacity
Bit Rate
Video Count
Approximate Video
Storage Duration
1×6TB
D1, 1.5Mbps
4
85 days
1×6TB
720p, 3Mbps
4
47 days
1×6TB
1080p, 4.5Mbps
4
28 days
2×6TB
D1, 1.5Mbps
8
85 days
2×6TB
720p, 3Mbps
8
47 days
2×6TB
1080p, 4.5Mbps
8
28 days
4×6TB
D1, 1.5Mbps
16
85 days
4×6TB
720p, 3Mbps
16
47 days
4×6TB
1080p, 4.5Mbps
16
28 days
The data listed in the preceding table is only for your reference. The recording time estimate
may be different from the actual recording time. The user shall be liable for any loss
incurred as a result thereof.
2.4 Hard Disk Installation
Take the following steps to install a hard disk:
Step 1 Unscrew the four fixing screws on both sides and one fixing screw on the back, then
remove the upper cover, as shown in Figure 2-1.

Network Video Recorder(NVR)
User Manual
2Hard Disk
Issue V1.0 (2018-05-11)
5
Figure 2-1 Removing the upper cover
Step 2 Take out the hard disk fixing screws and silicone cushion included in the accessory
package, route the fixing screw through the silicone cushion, and install it to the screw
holes, as shown in Figure 2-2.
Figure 2-2 Installing the hard disk fixing screw
Step 3 Route the hard disk fixing screws through the holes on the base, push the hard disk to
the appropriate position according to the direction of arrow, as shown in Figure 2-3.

2Hard Disk
Network Video Recorder(NVR)
User Manual
6
Issue V1.0 (2018-05-11)
Figure 2-3 Inserting the hard disk
Step 4 Turn the device over, and fasten two hard disk fixing screws, as shown in Figure 2-4.
Figure 2-4 Fixing the hard disk
Step 5 Install the other hard disk according to Step 2, Step 3, and Step 4, then insert the hard
disk data cable and power cable, as shown in Figure 2-5.

Network Video Recorder(NVR)
User Manual
2Hard Disk
Issue V1.0 (2018-05-11)
7
Figure 2-5 Inserting the cable
Step 6 Put on the upper cover, and fasten the fixing screws, as shown in Figure 2-6.
Figure 2-6 Put on the upper cover
----End

3Operation Instruction
Network Video Recorder(NVR)
User Manual
8
Issue V1.0 (2018-05-11)
3 Operation Instruction
3.1 Front panel
Figure 3-1 shows the front panel of NVR. Table 3-1 shows the description of front
panel.
Figure 3-1 Front panel
Table 3-1 Elements of the front panel
NO.
Element
Description
1
KB/MOUSE
Supports connection to a USB mouse and
keyboard.
2
BACKUP
Supports connection to a USB flash drive or
USB removable hard disk.
3.2 Rear panel
Figure 3-2 shows the rear panel of 0E-8CHNVR2TB and the interfaces on it.
Figure 3-2 Rear panel of 0E-8CHNVR2TB

Network Video Recorder(NVR)
User Manual
3Operation Instruction
Issue V1.0 (2018-05-11)
9
Figure 3-3 shows the rear panel of 0E-4CHNVR1TB & 0E-4CHNVR2TB and the
interfaces on it.
Figure 3-3 Rear panel of 0E-4CHNVR1TB & 0E-4CHNVR2TB
Table 3-2 shows the description of rear panel of 0E-8CHNVR2TB, 0E-4CHNVR1TB
& 0E-4CHNVR2TB.
Table 3-2 Elements of the real panel
NO.
Name
Description
1
Ground screw
Safe ground screw of the device
2
PoE network
interface
PoE network interfaces
3
LAN
RJ45 10 /100/1000 Mbps adaptive
Ethernet interface
4
Reset
Factory reset button
5
Line In/ Line Out
Audio input/ Audio output
6
VGA
Video output interface
7
HD-OUT
8
Alarm In/Out
2 alarm input, 2 alarm output
9
Power interface
AC 110V/220V power input interface of the
device
Figure 3-3 shows the rear panel of 0E-16CHNVR2T & 0E-16CHNVR4T and the
interfaces on it.
Table 3-3shows the description of rear panel of 0E-16CHNVR2T & 0E-16CHNVR4T.

3Operation Instruction
Network Video Recorder(NVR)
User Manual
10
Issue V1.0 (2018-05-11)
Table 3-3 Elements of the real panel of 0E-16CHNVR2T & 0E-16CHNVR4T
NO.
Name
Description
1
PoE network
interface
PoE network interfaces
2
LAN
RJ45 10 /100/1000 Mbps adaptive
Ethernet interface
3
Reset
Factory reset button
4
Line In/ Line Out
Audio input/ Audio output
5
VGA
Video output interface
6
HD-OUT
7
USB 3.0
Connect to mobile storage devices
8
Alarm In/Out
2 alarm input, 2 alarm output
9
Ground screw
Safe ground screw of the device
10
Power switch
--
11
Power interface
AC 110V/220V power input interface of the
device
3.3 Startup
Before starting the NVR, ensure that the NVR is connected to a power supply.
When the NVR is connected to a power supply, it starts automatically upon the initial
power-on.
Ensure that a power supply is connected to the NVR correctly.
Before starting the NVR, ensure that a monitor is connected to the HDMI or VGA
interface of the NVR correctly.
The NVR may not operate normally when a power supply exception occurs, likely
causing damage to the NVR in serious conditions. In such a circumstance, you are
advised to use a regulated power supply.
When the NVR is started, the power indicator becomes steady on and the NVR starts a
self-test and displays the test result on the screen, as shown in Figure 3-4.The startup
process takes about 2 minutes.

Network Video Recorder(NVR)
User Manual
3Operation Instruction
Issue V1.0 (2018-05-11)
11
Figure 3-4 NVR self-test
When the hardware abnormality is detected, the self-test screen stays on. You can click
continue or shutdown in the lower right corner of the screen. If you click continue,
the NVR enters the login screen.
The hard disk of the NVR must be provided by the user. Hard disk detection is performed
during startup. If the detection fails, possible causes include：
The hard disk is new and unformatted. The hard disk is formatted, but the file system is
inconsistent with the one supported by the NVR.
The hard disk is damaged.
3.4 Shutdown
To shut down the NVR after logging in to the main interface, click and choose
Exit System in the upper right corner. The shutdown interface appears, as shown in
Figure 3-5.

3Operation Instruction
Network Video Recorder(NVR)
User Manual
12
Issue V1.0 (2018-05-11)
Figure 3-5 Shutdown interface
Enter the correct password and click Shutdown. When authentication is successful, the
shutdown successful page is displayed, then cut off the power.
3.5 Adjusting the Screen Resolution of the Monitor
You need to adjust the display of the monitor in the case of incomplete or skewed
display (the icon in the four corners of the screen is out of view). (You are
advised to use the automatic adjustment function of the monitor first.)
Take the following steps to adjust the screen resolution of the monitor:
Step 1 Click Adjust in the lower left corner, the Monitor Setup interface appears, as shown
in Figure 3-6.
