Webb WEV20TIL User manual

v
Sales & Support: 01793 333212
Before use please read & understand this manual; paying particular attention to the safety instructions before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every eff ort has been made to ensure the accuracy of information contained in this manual, our policy of continuous improvement
determines the right to make modifi cations without prior warning.
Images are used for illustration purposes only.
en - Original Instructions
ASSEMBLY REQUIRED
Minimum Two Persons
20V Cordless Lithium-Ion Tiller
WEV20TIL
1938262001
Battery must be fully charged before use.

CONTENTS
INTENDED USE
SAFETY INSTRUCTIONS
SPECIFICATION
KNOW YOUR MACHINE
COMPONENTS
ASSEMBLY
BATTERY & CHARGER
OPERATION
MAINTENANCE
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
DECLARATION OF CONFORMITY
WARRANTY
Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without
written permission from Handy Distribution.
In all cases this copyright notice must remain intact.
INSTRUCTION MANUAL
21 May 2020

CONTENTS
INTENDED USE
SAFETY INSTRUCTIONS
SPECIFICATION
KNOW YOUR MACHINE
COMPONENTS
ASSEMBLY
BATTERY & CHARGER
OPERATION
MAINTENANCE
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
DECLARATION OF CONFORMITY
WARRANTY
Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without
written permission from Handy Distribution.
In all cases this copyright notice must remain intact.
INSTRUCTION MANUAL

SAFETY INSTRUCTIONS
Read and understand the owner’s manual and labels affixed to the machine. Learn its application and
limitations as well as the specific potential hazards. Retain these instructions for future reference. The
operator is responsible for following the warnings & instructions in this manual and on the product.
Read & understand operator’s
manual before using the machine.
Failure to follow instructions could
result in death or serious injury.
Please keep in a safe place for future
reference.
Always wear safety eye
and ear protection when operating this
machine.
DANGER
Keep all bystanders & animals away
from the machine during operation.
If approached, stop the machine
immediately.
Always wear gloves to protect your
hands. Wear foot protection or
sensible shoes when using the machine
Keep hands & feet out of the way of
all moving parts. Do not place any
part of your body or any tool in the
tines during operation.
DANGER —THROWN DEBRIS
Remove objects that can be thrown by
the machine in any direction. Wear
safety glasses.
DANGER —SLOPES
Use extra caution on slopes. Do not
tiller on slopes greater than 15°.
Noise Level - See label on machine
No smoking
Do not expose to rain or damp
conditions.
Keep guards in place and in working
order. Replace damaged, missing or
failed parts before using it.
Do not use near a flame, or sparks
Remove the electrical plug for
charger from the power source or
the battery from the tool before
undertaking checks, servicing or
repairs.
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your Local Authority or
retailer for recycling advice.
CE Marking - the product meets
demand and regulations set by the
EU
Safety alert symbol. Used to alert you
to potential personal injury hazards.
Obey all safety messages that follow
this symbol to avoid possible injury.
DANGER
Indicates an imminently hazardous
situation which, if not avoided, will
result in serious injury
WARNING
Indicates a potentially hazardous
situation which, if not avoided, could
result in serious injury
CAUTION
Indicates a potentially hazardous
situation which, if not avoided, may
result in minor or moderate injury.
CAUTION
Used without the safety alert symbol
indicates a potentially hazardous
situation which, if not avoided, may
result in property damage.
INTENDED USE
The basic version of the equipment is a cordless garden tiller intended for private use, i.e. for use in home and
gardening environments. It is designed to turn soil and vegetation in small to medium gardens or allotments.
The tiller is for private use, whose annual operating time generally does not exceed 25 hours. Public facilities,
sporting fields, and agricultural / forestry applications are excluded.
Please read this entire manual prior to operating the equipment. It instructs you how to safely and easily set
up, operate and maintain your machine. Please be sure that you, and any other persons who will operate the
machine, carefully follow the recommended safety practices, at all times. Failure to do so could result in
personal injury or property damage.
TO THE OWNER
All information in this manual is relative to the most recent product information available at the time of
printing. Review this manual frequently to familiarise yourself with the machine, its features and operation.
Please be aware that this Instruction Manual may cover a range of product specifications for various models.
Characteristics and features discussed and/or illustrated in this manual may not be applicable or exact to all
models.
We reserve the right to change product specifications, designs and equipment without notice and without
incurring obligation. If you have any problems or questions concerning the machine, phone your local
authorised service dealer or ourselves. Throughout this manual, all references to right and left side of the
machine are observed from the operating position.
WARNING
For safety reasons, the tiller may not be used as a drive unit for other equipment or toolkits of any kind,
unless specifically advised to do so by the manufacturer. The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of misuse. The user/operator and not the manufacturer will
be liable for any damage or injuries of any kind caused as a result of this.
Please note that our equipment has not been designed for use in commercial, trade or industrial
applications. Our warranty will be 90 days from the original date of sale for commercial, trade or industrial
businesses or for equivalent purposes.
INSTRUCTION MANUAL

SAFETY INSTRUCTIONS
Read and understand the owner’s manual and labels affixed to the machine. Learn its application and
limitations as well as the specific potential hazards. Retain these instructions for future reference. The
operator is responsible for following the warnings & instructions in this manual and on the product.
Read & understand operator’s
manual before using the machine.
Failure to follow instructions could
result in death or serious injury.
Please keep in a safe place for future
reference.
Always wear safety eye
and ear protection when operating this
machine.
DANGER
Keep all bystanders & animals away
from the machine during operation.
If approached, stop the machine
immediately.
Always wear gloves to protect your
hands. Wear foot protection or
sensible shoes when using the machine
Keep hands & feet out of the way of
all moving parts. Do not place any
part of your body or any tool in the
tines during operation.
DANGER —THROWN DEBRIS
Remove objects that can be thrown by
the machine in any direction. Wear
safety glasses.
DANGER —SLOPES
Use extra caution on slopes. Do not
tiller on slopes greater than 15°.
Noise Level - See label on machine
No smoking
Do not expose to rain or damp
conditions.
Keep guards in place and in working
order. Replace damaged, missing or
failed parts before using it.
Do not use near a flame, or sparks
Remove the electrical plug for
charger from the power source or
the battery from the tool before
undertaking checks, servicing or
repairs.
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your Local Authority or
retailer for recycling advice.
CE Marking - the product meets
demand and regulations set by the
EU
Safety alert symbol. Used to alert you
to potential personal injury hazards.
Obey all safety messages that follow
this symbol to avoid possible injury.
DANGER
Indicates an imminently hazardous
situation which, if not avoided, will
result in serious injury
WARNING
Indicates a potentially hazardous
situation which, if not avoided, could
result in serious injury
CAUTION
Indicates a potentially hazardous
situation which, if not avoided, may
result in minor or moderate injury.
CAUTION
Used without the safety alert symbol
indicates a potentially hazardous
situation which, if not avoided, may
result in property damage.
INTENDED USE
The basic version of the equipment is a cordless garden tiller intended for private use, i.e. for use in home and
gardening environments. It is designed to turn soil and vegetation in small to medium gardens or allotments.
The tiller is for private use, whose annual operating time generally does not exceed 25 hours. Public facilities,
sporting fields, and agricultural / forestry applications are excluded.
Please read this entire manual prior to operating the equipment. It instructs you how to safely and easily set
up, operate and maintain your machine. Please be sure that you, and any other persons who will operate the
machine, carefully follow the recommended safety practices, at all times. Failure to do so could result in
personal injury or property damage.
TO THE OWNER
All information in this manual is relative to the most recent product information available at the time of
printing. Review this manual frequently to familiarise yourself with the machine, its features and operation.
Please be aware that this Instruction Manual may cover a range of product specifications for various models.
Characteristics and features discussed and/or illustrated in this manual may not be applicable or exact to all
models.
We reserve the right to change product specifications, designs and equipment without notice and without
incurring obligation. If you have any problems or questions concerning the machine, phone your local
authorised service dealer or ourselves. Throughout this manual, all references to right and left side of the
machine are observed from the operating position.
WARNING
For safety reasons, the tiller may not be used as a drive unit for other equipment or toolkits of any kind,
unless specifically advised to do so by the manufacturer. The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of misuse. The user/operator and not the manufacturer will
be liable for any damage or injuries of any kind caused as a result of this.
Please note that our equipment has not been designed for use in commercial, trade or industrial
applications. Our warranty will be 90 days from the original date of sale for commercial, trade or industrial
businesses or for equivalent purposes.
INSTRUCTION MANUAL

17. The trigger is a safety device. Never attempt to bypass its operation. Doing so makes the safety device
inoperative and may result in personal injury through contact with the rotating tines. The trigger must
operate easily in both directions and automatically return to the disengaged position when released.
18. Always be sure of your footing. A slip and fall can cause serious personal injury. If you feel you are losing
your footing, release the trigger immediately and the tines will stop rotating within immediately.
19. Operate only in daylight or good artificial light. Walk, never run.
20. Stop the tines when crossing gravel drives, paths or roads.
21. If the machine starts to vibrate abnormally, stop the motor and check immediately for the cause. Vibration
is generally a warning of trouble.
22. Shut the motor off and wait until the tines comes to a complete stop before cleaning. Never place any part
of the body in the tine area until you are sure they have stopped rotating and the battery removed from
the handle.
23. Never operate the tiller without proper safety protective devices in place and working. Never operate with
damaged safety devices. Failure to do so can result in personal injury.
24. Only use parts and accessories made for this machine by the manufacturer. Failure to do so can result in
personal injury.
25. If situations occur which are not covered in this manual, use care and good judgement. Contact your
nearest Approved Service Dealer or ourselves for assistance
SLOPE OPERATION
Slopes are a major factor related to slip and fall accidents, which can result in severe injury. Operation on
slopes requires extra caution. If you feel uneasy on a slope, do not till on it. If the slope is greater than 15
degrees, do not till on it.
Do:
1. Till across the face of slopes; never up and down. Exercise extreme caution when changing direction on
slopes.
2. Watch for holes, ruts, rocks, hidden objects, or bumps which can cause you to slip or trip. Tall grass can
hide obstacles.
3. Always be sure of your footing. A slip and fall can cause serious personal injury. If you feel you are losing
your balance, release the trigger immediately and the tines will stop rotating immediately.
Do Not:
1. Do not till near drop-offs, ditches or embankments, you could lose your footing or balance.
2. Do not till on slopes greater than 15 degrees.
3. Do not till on saturated soil. Unstable footing could cause slipping.
CHILDREN
Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted
to the tiller and the tilling activity. They do not understand the dangers. Never assume that children will
remain where you last saw them.
1. Keep children out of the tilling area and under care of a responsible adult other than the operator.
2. Be alert and turn the tiller off if a child enters the area.
3. Before and while moving backwards, look behind and down for small children.
4. Use extreme care when approaching blind corners, doorways, shrubs, trees, or other objects that may
obscure your vision of a child who may run into the tiller.
5. Never allow children under 16 years of age to operate this machine. Children 16 and over should read and
understand the instructions and safe operation practices in this manual and on the machine and be
trained and supervised by an adult.
SERVICE
Electrical/Battery safety:
1. The mains voltage must correspond to the one marked on the technical data plate (230V-50Hz). Do not
use any other source of power when charging your battery.
2. Only use batteries supplied by the manufacturer at all times.
3. Do NOT use the machine in the rain and do NOT leave it outside overnight. Try to prevent it getting wet or
being exposed to humidity. Check the power cable regularly to ensure it is not damaged.
4. Allow the machine and battery to cool down for 5 minutes, prior to storing.
GENERAL SAFETY RULES
WARNING
Before you put the machine into operation, you must read this instruction manual.
When using this machine, observe the following safety instructions to exclude the risk of personal injury or
material damage. Please also observe the special safety instructions in the respective chapters. Where
applicable, follow the legal directives or regulations for the prevention of accidents in relation to the use of
this machine.
When using petrol tools, basic safety precautions, including the following, should always be followed to
reduce the risk of serious personal injury and/or damage to the unit.
GENERAL OPERATION
1. Read this instruction manual carefully in its entirety before attempting to assemble this machine. Read,
understand, and follow all instructions on the machine and in the manual(s) before operation. Keep this
manual in a safe place for future and regular reference and for ordering replacement parts.
2. Be completely familiar with the controls and the proper use of this machine before operating it.
3. This machine is a precision piece of power equipment, not a plaything. Therefore, exercise extreme
caution at all times. This machine has been designed to perform one job: to turn soil and vegetation. Do
not use it for any other purpose.
4. Never allow children under 16 years of age to operate this machine. Children 16 and over should read and
understand the instructions and safe operation practices in this manual and on the machine and should be
trained and always supervised by an adult.
5. Only responsible individuals who are familiar with these rules of safe operation should be allowed to use
this machine.
6. Thoroughly inspect the area where the equipment is to be used. Remove all stones, sticks, wire, bones,
toys and other foreign objects, which could be tripped over or picked up and thrown by the tiller. Thrown
objects can cause serious personal injury.
7. Plan your tilling pattern to avoid discharge of material toward roads, pathways, bystanders and the like.
Also, avoid discharging material against a wall or obstruction, which may cause discharged material to
ricochet back toward the operator.
8. To help avoid tiller contact or a thrown object injury, stay in operator zone behind handles and keep
children, bystanders, helpers and pets at least 20 metres from tiller while it is in operation. Stop machine
if anyone enters area.
9. Always wear safety glasses or safety goggles during operation and while performing an adjustment or
repair to protect your eyes. Thrown objects which ricochet can cause serious injury to the eyes.
10. Wear sturdy, rough-soled work shoes and close-fitting trousers and shirts. Shirts and trousers that cover
the arms and legs and steel-toed shoes are recommended. Never operate this machine in bare feet,
sandals, slippery or light- weight (e.g. canvas) shoes.
11. Do not put hands or feet near or under rotating parts. Always keep clear of discharge area, as the rotating
tines can cause injury.
12. Never operate the tiller without proper shields, guards, trigger or other safety protective devices in place
and working.
13. Never operate the tiller with damaged safety devices. Failure to do so, can result in personal injury.
14. Many injuries occur as a result of the tiller being pulled over the foot during a fall caused by slipping or
tripping. Do not hold on to the tiller if you are falling; release the handle immediately.
15. Never pull the tiller back towards you while you are walking. If you must back the tiller away from a wall
or obstruction, first look down and behind to avoid tripping and then follow these steps:
A. Step back from the tiller to fully extend your arms.
B. Be sure you are well balanced with sure footing.
C. Pull the tiller back slowly, no more than halfway towards you.
D. Repeat these steps as needed.
16. Do not operate the tiller while under the influence of alcohol or drugs.
INSTRUCTION MANUAL

17. The trigger is a safety device. Never attempt to bypass its operation. Doing so makes the safety device
inoperative and may result in personal injury through contact with the rotating tines. The trigger must
operate easily in both directions and automatically return to the disengaged position when released.
18. Always be sure of your footing. A slip and fall can cause serious personal injury. If you feel you are losing
your footing, release the trigger immediately and the tines will stop rotating within immediately.
19. Operate only in daylight or good artificial light. Walk, never run.
20. Stop the tines when crossing gravel drives, paths or roads.
21. If the machine starts to vibrate abnormally, stop the motor and check immediately for the cause. Vibration
is generally a warning of trouble.
22. Shut the motor off and wait until the tines comes to a complete stop before cleaning. Never place any part
of the body in the tine area until you are sure they have stopped rotating and the battery removed from
the handle.
23. Never operate the tiller without proper safety protective devices in place and working. Never operate with
damaged safety devices. Failure to do so can result in personal injury.
24. Only use parts and accessories made for this machine by the manufacturer. Failure to do so can result in
personal injury.
25. If situations occur which are not covered in this manual, use care and good judgement. Contact your
nearest Approved Service Dealer or ourselves for assistance
SLOPE OPERATION
Slopes are a major factor related to slip and fall accidents, which can result in severe injury. Operation on
slopes requires extra caution. If you feel uneasy on a slope, do not till on it. If the slope is greater than 15
degrees, do not till on it.
Do:
1. Till across the face of slopes; never up and down. Exercise extreme caution when changing direction on
slopes.
2. Watch for holes, ruts, rocks, hidden objects, or bumps which can cause you to slip or trip. Tall grass can
hide obstacles.
3. Always be sure of your footing. A slip and fall can cause serious personal injury. If you feel you are losing
your balance, release the trigger immediately and the tines will stop rotating immediately.
Do Not:
1. Do not till near drop-offs, ditches or embankments, you could lose your footing or balance.
2. Do not till on slopes greater than 15 degrees.
3. Do not till on saturated soil. Unstable footing could cause slipping.
CHILDREN
Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted
to the tiller and the tilling activity. They do not understand the dangers. Never assume that children will
remain where you last saw them.
1. Keep children out of the tilling area and under care of a responsible adult other than the operator.
2. Be alert and turn the tiller off if a child enters the area.
3. Before and while moving backwards, look behind and down for small children.
4. Use extreme care when approaching blind corners, doorways, shrubs, trees, or other objects that may
obscure your vision of a child who may run into the tiller.
5. Never allow children under 16 years of age to operate this machine. Children 16 and over should read and
understand the instructions and safe operation practices in this manual and on the machine and be
trained and supervised by an adult.
SERVICE
Electrical/Battery safety:
1. The mains voltage must correspond to the one marked on the technical data plate (230V-50Hz). Do not
use any other source of power when charging your battery.
2. Only use batteries supplied by the manufacturer at all times.
3. Do NOT use the machine in the rain and do NOT leave it outside overnight. Try to prevent it getting wet or
being exposed to humidity. Check the power cable regularly to ensure it is not damaged.
4. Allow the machine and battery to cool down for 5 minutes, prior to storing.
GENERAL SAFETY RULES
WARNING
Before you put the machine into operation, you must read this instruction manual.
When using this machine, observe the following safety instructions to exclude the risk of personal injury or
material damage. Please also observe the special safety instructions in the respective chapters. Where
applicable, follow the legal directives or regulations for the prevention of accidents in relation to the use of
this machine.
When using petrol tools, basic safety precautions, including the following, should always be followed to
reduce the risk of serious personal injury and/or damage to the unit.
GENERAL OPERATION
1. Read this instruction manual carefully in its entirety before attempting to assemble this machine. Read,
understand, and follow all instructions on the machine and in the manual(s) before operation. Keep this
manual in a safe place for future and regular reference and for ordering replacement parts.
2. Be completely familiar with the controls and the proper use of this machine before operating it.
3. This machine is a precision piece of power equipment, not a plaything. Therefore, exercise extreme
caution at all times. This machine has been designed to perform one job: to turn soil and vegetation. Do
not use it for any other purpose.
4. Never allow children under 16 years of age to operate this machine. Children 16 and over should read and
understand the instructions and safe operation practices in this manual and on the machine and should be
trained and always supervised by an adult.
5. Only responsible individuals who are familiar with these rules of safe operation should be allowed to use
this machine.
6. Thoroughly inspect the area where the equipment is to be used. Remove all stones, sticks, wire, bones,
toys and other foreign objects, which could be tripped over or picked up and thrown by the tiller. Thrown
objects can cause serious personal injury.
7. Plan your tilling pattern to avoid discharge of material toward roads, pathways, bystanders and the like.
Also, avoid discharging material against a wall or obstruction, which may cause discharged material to
ricochet back toward the operator.
8. To help avoid tiller contact or a thrown object injury, stay in operator zone behind handles and keep
children, bystanders, helpers and pets at least 20 metres from tiller while it is in operation. Stop machine
if anyone enters area.
9. Always wear safety glasses or safety goggles during operation and while performing an adjustment or
repair to protect your eyes. Thrown objects which ricochet can cause serious injury to the eyes.
10. Wear sturdy, rough-soled work shoes and close-fitting trousers and shirts. Shirts and trousers that cover
the arms and legs and steel-toed shoes are recommended. Never operate this machine in bare feet,
sandals, slippery or light- weight (e.g. canvas) shoes.
11. Do not put hands or feet near or under rotating parts. Always keep clear of discharge area, as the rotating
tines can cause injury.
12. Never operate the tiller without proper shields, guards, trigger or other safety protective devices in place
and working.
13. Never operate the tiller with damaged safety devices. Failure to do so, can result in personal injury.
14. Many injuries occur as a result of the tiller being pulled over the foot during a fall caused by slipping or
tripping. Do not hold on to the tiller if you are falling; release the handle immediately.
15. Never pull the tiller back towards you while you are walking. If you must back the tiller away from a wall
or obstruction, first look down and behind to avoid tripping and then follow these steps:
A. Step back from the tiller to fully extend your arms.
B. Be sure you are well balanced with sure footing.
C. Pull the tiller back slowly, no more than halfway towards you.
D. Repeat these steps as needed.
16. Do not operate the tiller while under the influence of alcohol or drugs.
INSTRUCTION MANUAL

SPECIFICATIONS
Model
WEV20TIL
Product Number
1938262001
Voltage
20v max
Battery
2.0Ah
Charging Time
Up to 90 mins
Run Time
Up to 30 mins
Idle Speed
160rpm
Working Width
19cm
Max. Working Depth
15.5cm
Protection
IPX1
Sound Power Level LWA:
93 dB(A)
Weight
4.36kg
The manufacturer reserves the right to change the product specification and livery according to continued
product improvements.
General Service:
1. Before cleaning, repairing, or inspecting, make certain the tines and all moving parts have stopped.
Disconnect the battery to prevent unintended starting.
2. Check the tines and bolts at frequent intervals for proper tightness. Also, visually inspect tines for damage.
Replace with the original equipment manufacture’s (O.E.M.) parts only, listed in this manual. “Use of parts
which do not meet the original equipment specifications may lead to improper performance and
compromise safety!”
3. Keep all nuts, bolts, and screws tight to be sure the equipment is in safe working condition.
4. Never tamper with safety devices. Check the correct operation regularly.
5. After striking a foreign object, stop the motor, disconnect the battery. Thoroughly inspect the tiller for any
damage. Repair the damage before starting and operating the tiller.
6. Tiller components, guards and shields are subject to wear and damage which could expose moving parts
or allow objects to be thrown. For safety protection, frequently check components and replace
immediately with original equipment manufacturers (O.E.M.) parts only, listed in this manual. “Use of
parts which do not meet the original equipment specifications may lead to improper performance and
compromise safety!”
7. Maintain or replace safety and instruction labels, as necessary.
8. Observe proper disposal laws and regulations. Improper disposal of fluids and materials can harm the
environment.
DO NOT MODIFY THE MOTOR
To avoid serious injury or death, do not modify the motor in any way. Tampering with the motor could cause it
to operate at unsafe speeds. Never tamper with factory settings.
PERSONAL SAFETY
1. This machine is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the machine by a person responsible for their safety.
2. Children should be supervised to ensure that they do not use or play with the machine.
3. Stay alert, watch what you are doing and use common sense when operating this machine.
4. Do not use this machine while you are tired, ill or under the influence of drugs, alcohol, or medication. A
moment of inattention while operating this machine can cause you to lose control & may result in series
personal injury.
5. Use safety equipment. Always wear eye protection. Safety equipment such as a dust mask, non-skid safety
shoes, hard hat, or hearing protection used for appropriate condition will reduce personal injuries.
6. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing & gloves away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
7. Prolonged use of the machine may lead to disorders of blood circulation in hands caused by vibration.
These effects can be worsened by low ambient temperatures and/or by gripping the handgrips excessively
tightly. Period of use you can extend with appropriate gloves or regular breaks. Take frequent work
breaks. Limit the amount of exposure per day.
WARNING
Keep hands away from moving parts. Tines do not stop immediately after the tiller is turned off. Do not put
hands, feet or any body part or clothing near the rotating tines.
The tiller may bounce upward and/or jump forward if the tines strike extremely hard packed soil, frozen
ground, or buried obstacles such as large stones, roots or stumps.
DANGER
Wear gloves and use caution when cleaning or performing maintenance on the tiller.
INSTRUCTION MANUAL

SPECIFICATIONS
Model WEV20TIL
Product Number 1938262001
Voltage 20v max
Battery 2.0Ah
Charging Time Up to 90 mins
Run Time Up to 30 mins
Idle Speed 160rpm
Working Width 19cm
Max. Working Depth 15.5cm
Protection IPX1
Sound Power Level LWA: 93 dB(A)
Weight 4.36kg
The manufacturer reserves the right to change the product specification and livery according to continued
product improvements.
General Service:
1. Before cleaning, repairing, or inspecting, make certain the tines and all moving parts have stopped.
Disconnect the battery to prevent unintended starting.
2. Check the tines and bolts at frequent intervals for proper tightness. Also, visually inspect tines for damage.
Replace with the original equipment manufacture’s (O.E.M.) parts only, listed in this manual. “Use of parts
which do not meet the original equipment specifications may lead to improper performance and
compromise safety!”
3. Keep all nuts, bolts, and screws tight to be sure the equipment is in safe working condition.
4. Never tamper with safety devices. Check the correct operation regularly.
5. After striking a foreign object, stop the motor, disconnect the battery. Thoroughly inspect the tiller for any
damage. Repair the damage before starting and operating the tiller.
6. Tiller components, guards and shields are subject to wear and damage which could expose moving parts
or allow objects to be thrown. For safety protection, frequently check components and replace
immediately with original equipment manufacturers (O.E.M.) parts only, listed in this manual. “Use of
parts which do not meet the original equipment specifications may lead to improper performance and
compromise safety!”
7. Maintain or replace safety and instruction labels, as necessary.
8. Observe proper disposal laws and regulations. Improper disposal of fluids and materials can harm the
environment.
DO NOT MODIFY THE MOTOR
To avoid serious injury or death, do not modify the motor in any way. Tampering with the motor could cause it
to operate at unsafe speeds. Never tamper with factory settings.
PERSONAL SAFETY
1. This machine is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the machine by a person responsible for their safety.
2. Children should be supervised to ensure that they do not use or play with the machine.
3. Stay alert, watch what you are doing and use common sense when operating this machine.
4. Do not use this machine while you are tired, ill or under the influence of drugs, alcohol, or medication. A
moment of inattention while operating this machine can cause you to lose control & may result in series
personal injury.
5. Use safety equipment. Always wear eye protection. Safety equipment such as a dust mask, non-skid safety
shoes, hard hat, or hearing protection used for appropriate condition will reduce personal injuries.
6. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing & gloves away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
7. Prolonged use of the machine may lead to disorders of blood circulation in hands caused by vibration.
These effects can be worsened by low ambient temperatures and/or by gripping the handgrips excessively
tightly. Period of use you can extend with appropriate gloves or regular breaks. Take frequent work
breaks. Limit the amount of exposure per day.
WARNING
Keep hands away from moving parts. Tines do not stop immediately after the tiller is turned off. Do not put
hands, feet or any body part or clothing near the rotating tines.
The tiller may bounce upward and/or jump forward if the tines strike extremely hard packed soil, frozen
ground, or buried obstacles such as large stones, roots or stumps.
DANGER
Wear gloves and use caution when cleaning or performing maintenance on the tiller.
INSTRUCTION MANUAL

COMPONENTS
This product must be assembled correctly before use.
Carefully remove the product and any accessories from the carton. Make sure all items listed below are included.
If you require assistance with regards to the contents or operation of the machine, please contact us:
TEL: [phone]
EMAIL: [e-mail]
(MON –FRI 8.00AM TO 5.30PM EXCL. BANK HOLIDAYS)
Inspect the product carefully to make sure there are no breakages or damage occurred during shipping.
Do not discard the packing material and carton until you have carefully inspected and satisfactorily operated the
product.
WARNING
If any parts are damaged or missing do not operate this product until the parts are replaced. Failure to heed
this warning could result in serious personal injury.
Do not attempt to modify this product or create accessories not recommended for use with this product. Any
such alteration or modification is misuse and could result in a hazardous condition leading to possible
serious personal injury.
Do not connect to power supply until assembly is complete. Failure to comply could result in accidental
starting and possible serious personal injury.
2x Wing Nuts
1x Side Cover
1x Upper & Lower Shafts
1x M6x45 Hex
Carriage Bolt
1x M6x50 Hex
Head Bolt
2x 3.9x16
Screws
1x Motor & Tines
1x 18v 2Ah Battery
1x Battery Charger
1x Front Handle
KNOW YOUR MACHINE
1.
Trigger
2.
Safety Button
3.
Front Handle
4.
Upper Shaft
5.
Wing Nut Fixing
6.
Lower Shaft
7.
Side Cover
8.
Motor Housing
9.
Tine 1 (Right)
10.
Tine 2 (Left)
11.
18v 2Ah Battery
12.
Battery Charger
INSTRUCTION MANUAL

COMPONENTS
This product must be assembled correctly before use.
Carefully remove the product and any accessories from the carton. Make sure all items listed below are included.
If you require assistance with regards to the contents or operation of the machine, please contact us:
TEL: [phone]
EMAIL: [e-mail]
(MON –FRI 8.00AM TO 5.30PM EXCL. BANK HOLIDAYS)
Inspect the product carefully to make sure there are no breakages or damage occurred during shipping.
Do not discard the packing material and carton until you have carefully inspected and satisfactorily operated the
product.
WARNING
If any parts are damaged or missing do not operate this product until the parts are replaced. Failure to heed
this warning could result in serious personal injury.
Do not attempt to modify this product or create accessories not recommended for use with this product. Any
such alteration or modification is misuse and could result in a hazardous condition leading to possible
serious personal injury.
Do not connect to power supply until assembly is complete. Failure to comply could result in accidental
starting and possible serious personal injury.
2x Wing Nuts
1x Side Cover
1x Upper & Lower Shafts
1x M6x45 Hex
Carriage Bolt
1x M6x50 Hex
Head Bolt
2x 3.9x16
Screws
1x Motor & Tines
1x 18v 2Ah Battery
1x Battery Charger
1x Front Handle
KNOW YOUR MACHINE
1.
Trigger
2.
Safety Button
3.
Front Handle
4.
Upper Shaft
5.
Wing Nut Fixing
6.
Lower Shaft
7.
Side Cover
8.
Motor Housing
9.
Tine 1 (Right)
10.
Tine 2 (Left)
11.
18v 2Ah Battery
12.
Battery Charger
INSTRUCTION MANUAL

WARNING
DO NOT attempt to start this machine without it first being FULLY assembled.
When connecting the tilling head and lower handle using the two self-tapping screws supplied, make sure
the screws are securely tightened. Screw heads should be recessed below the surface.
DO NOT START THE UNIT UNTIL TILLING HEAD AND LOWER HANDLE ARE SECURELY CONNECTED.
BATTERY INSTALLATION & REMOVAL
Hold the tool and the battery carriage firmly when installing or removing battery cartridge.
Failure to hold the tool and the battery cartridge firmly may cause them to slip off your hands and result in
damage to the tool and battery cartridge and a personal injury.
TO REMOVE
Depress release button (A) on the back of battery cartridge (B) to release the battery. Pull the battery cartridge
out of tool.
TO INSTALL
Align the battery with the cavity in the handle. Insert the battery into the handle until the battery release
button locks into place. You should hear a “click” once the battery is installed. Note: The battery can only be
installed one way.
ASSEMBLY
Remove the machine and contents from the carton. Be sure the carton is empty before discarding.
If you require assistance with regards to the contents or operation of the machine, please contact us:
Tel: [phone] - Email: [e-mail]
Opening hours weekdays: February to October 8:30am - 5:30pm / November to January 8:30am - 5:00pm
(Closed Bank Holidays)
UPPER & LOWER SHAFT (FIG. 3A)
Slide the lower handle section into the upper handle section.
Line up the holes on each tube, and make sure the cable is clear of the mounting holes. Secure the two
sections together with the M6x45 carriage bolt and wing nut.
LOWER SHAFT AND MOTOR (FIG. 3B)
Align the notch on the lower handle with the rib on the tilling head and push the lower handle into the tilling
head. Align the side cover with the holes on the lower handle shaft and push the cover into place. Secure with
the two ST3.9x16 screws.
AUXILIARY HANDLE (Fig. 3C)
Position the auxiliary handle so that the holes are in alignment with the holes in the handle support bracket.
Insert the M6X50 hex head bolt into the hex shaped bolt hole of the bracket. Secure by tightening the wing nut
onto the bolt.
Loosen the wing nut and adjust the angle and height of the handle to a safe and comfortable position. Secure
into place by tightening the wing nut onto the bolt
Front Handle
M6x50
Wing Nut
Handle
Support
Bracket
M6x45
Upper Shaft
Lower Shaft
Wing Nut
Lower Shaft
Side
Cover
2x 3.9x16
INSTRUCTION MANUAL

WARNING
DO NOT attempt to start this machine without it first being FULLY assembled.
When connecting the tilling head and lower handle using the two self-tapping screws supplied, make sure
the screws are securely tightened. Screw heads should be recessed below the surface.
DO NOT START THE UNIT UNTIL TILLING HEAD AND LOWER HANDLE ARE SECURELY CONNECTED.
BATTERY INSTALLATION & REMOVAL
Hold the tool and the battery carriage firmly when installing or removing battery cartridge.
Failure to hold the tool and the battery cartridge firmly may cause them to slip off your hands and result in
damage to the tool and battery cartridge and a personal injury.
TO REMOVE
Depress release button (A) on the back of battery cartridge (B) to release the battery. Pull the battery cartridge
out of tool.
TO INSTALL
Align the battery with the cavity in the handle. Insert the battery into the handle until the battery release
button locks into place. You should hear a “click” once the battery is installed. Note: The battery can only be
installed one way.
ASSEMBLY
Remove the machine and contents from the carton. Be sure the carton is empty before discarding.
If you require assistance with regards to the contents or operation of the machine, please contact us:
Tel: [phone] - Email: [e-mail]
Opening hours weekdays: February to October 8:30am - 5:30pm / November to January 8:30am - 5:00pm
(Closed Bank Holidays)
UPPER & LOWER SHAFT (FIG. 3A)
Slide the lower handle section into the upper handle section.
Line up the holes on each tube, and make sure the cable is clear of the mounting holes. Secure the two
sections together with the M6x45 carriage bolt and wing nut.
LOWER SHAFT AND MOTOR (FIG. 3B)
Align the notch on the lower handle with the rib on the tilling head and push the lower handle into the tilling
head. Align the side cover with the holes on the lower handle shaft and push the cover into place. Secure with
the two ST3.9x16 screws.
AUXILIARY HANDLE (Fig. 3C)
Position the auxiliary handle so that the holes are in alignment with the holes in the handle support bracket.
Insert the M6X50 hex head bolt into the hex shaped bolt hole of the bracket. Secure by tightening the wing nut
onto the bolt.
Loosen the wing nut and adjust the angle and height of the handle to a safe and comfortable position. Secure
into place by tightening the wing nut onto the bolt
Front Handle
M6x50
Wing Nut
Handle
Support
Bracket
M6x45
Upper Shaft
Lower Shaft
Wing Nut
Lower Shaft
Side
Cover
2x 3.9x16
INSTRUCTION MANUAL

OPERATION
THE BATTERY MUST BE FULLY CHARGED BEFORE THE FIRST USE OF THE PRODUCT. SEE STARTING & STOPPING
WARNING
The tines start rotating immediately after the tiller is switched on. Keep hands and feet away from the tines.
1. To switch ON, hold the tiller firmly with two hands. One hand should be placed on the top trigger handle,
with your other hand firmly holding the front handle. Always ensure the tines are not touching any surface
when starting the machine.
2. Press the safety button, then squeeze the trigger. The tines will then rotate. Once the tiller has started, you
can release the safety button, whilst still holding the trigger.
3. To switch OFF, simply release the trigger.
USAGE
Before use, remove any visible stones or other foreign bodies from the area.
Use the tiller for breaking sod, preparing seed beds and for cultivating gardens and flower beds. The
tiller can also dig small holes for planting saplings or potted plants.
For breaking sod or deep tilling, allow the tines to pull the tiller forward to the end of your arm’s reach, then
firmly pull it back toward yourself. You will achieve the best results by repeatedly allowing it to move forward
and pulling it back. By pulling the tiller back towards yourself, the tines will dig deeper and more aggressively.
WARNING
To prevent tripping, take extra precautions when moving backwards and when pulling the tiller back towards
yourself.
If the tiller digs deep enough to stay in one spot, gently rock it side to side until it starts moving forward again.
When working on inclines, always stand diagonally to the incline to retain a firm, safe footing. Do not work on
extremely steep slopes.
SAFETY BUTTON
TRIGGER
BATTERY & CHARGER
By pressing the button on the battery, the LED display will show the battery capacity.
LED LIGHTS
BATTERY STATUS
LED x4
Battery is 75-100% charged
LED x3
Battery is 50-75% charged
LED x2
Battery is 25-50% charged
LED x1
Battery is 0-25% charged
BATTERY CHARGER
WARNING
Risk of electric shock and short circuiting. Use approved and intact wall sockets. Make sure that the cable is
not damaged. Replace cable if it appears to be damaged in any way
CONNECTING CHARGER TO POWER SOURCE
Connect the battery charger to the voltage
and frequency specified in this manual and
on the rating plate. Put the electric plug in an
earthed socket-outlet. The LED on the
battery charger lights up green.
CONNECTING CHARGER TO BATTERY
⚫
The battery must be charged before using it
the first time.
⚫Install charger on the top of battery and
push until the charger connects firmly with
the battery.
⚫The LED will turn RED on the charger, when
the battery is connected to the battery
charger.
⚫When the LED on the charger turns to
GREEN, the battery is fully charged.
⚫Disconnect the power plug. Never pull the
power cable of the charger to disconnect it
from the wall socket.
⚫
Remove battery from battery charger.
NOTE:
Lithium-ion batteries can be charged at whatever charging level. The charging process can be cancelled or
started whatever the battery’s charge level is.
INSTRUCTION MANUAL

OPERATION
THE BATTERY MUST BE FULLY CHARGED BEFORE THE FIRST USE OF THE PRODUCT. SEE STARTING & STOPPING
WARNING
The tines start rotating immediately after the tiller is switched on. Keep hands and feet away from the tines.
1. To switch ON, hold the tiller firmly with two hands. One hand should be placed on the top trigger handle,
with your other hand firmly holding the front handle. Always ensure the tines are not touching any surface
when starting the machine.
2. Press the safety button, then squeeze the trigger. The tines will then rotate. Once the tiller has started, you
can release the safety button, whilst still holding the trigger.
3. To switch OFF, simply release the trigger.
USAGE
Before use, remove any visible stones or other foreign bodies from the area.
Use the tiller for breaking sod, preparing seed beds and for cultivating gardens and flower beds. The
tiller can also dig small holes for planting saplings or potted plants.
For breaking sod or deep tilling, allow the tines to pull the tiller forward to the end of your arm’s reach, then
firmly pull it back toward yourself. You will achieve the best results by repeatedly allowing it to move forward
and pulling it back. By pulling the tiller back towards yourself, the tines will dig deeper and more aggressively.
WARNING
To prevent tripping, take extra precautions when moving backwards and when pulling the tiller back towards
yourself.
If the tiller digs deep enough to stay in one spot, gently rock it side to side until it starts moving forward again.
When working on inclines, always stand diagonally to the incline to retain a firm, safe footing. Do not work on
extremely steep slopes.
SAFETY BUTTON
TRIGGER
BATTERY & CHARGER
By pressing the button on the battery, the LED display will show the battery capacity.
LED LIGHTS
BATTERY STATUS
LED x4
Battery is 75-100% charged
LED x3
Battery is 50-75% charged
LED x2
Battery is 25-50% charged
LED x1
Battery is 0-25% charged
BATTERY CHARGER
WARNING
Risk of electric shock and short circuiting. Use approved and intact wall sockets. Make sure that the cable is
not damaged. Replace cable if it appears to be damaged in any way
CONNECTING CHARGER TO POWER SOURCE
Connect the battery charger to the voltage
and frequency specified in this manual and
on the rating plate. Put the electric plug in an
earthed socket-outlet. The LED on the
battery charger lights up green.
CONNECTING CHARGER TO BATTERY
⚫The battery must be charged before using it
the first time.
⚫Install charger on the top of battery and
push until the charger connects firmly with
the battery.
⚫The LED will turn RED on the charger, when
the battery is connected to the battery
charger.
⚫When the LED on the charger turns to
GREEN, the battery is fully charged.
⚫Disconnect the power plug. Never pull the
power cable of the charger to disconnect it
from the wall socket.
⚫Remove battery from battery charger.
NOTE:
Lithium-ion batteries can be charged at whatever charging level. The charging process can be cancelled or
started whatever the battery’s charge level is.
INSTRUCTION MANUAL

BATTERY & CHARGER
By pressing the button on the battery, the LED display will show the battery capacity.
LED LIGHTS
BATTERY STATUS
LED x4
Battery is 75-100% charged
LED x3
Battery is 50-75% charged
LED x2
Battery is 25-50% charged
LED x1
Battery is 0-25% charged
BATTERY CHARGER
WARNING
Risk of electric shock and short circuiting. Use approved and intact wall sockets. Make sure that the cable is
not damaged. Replace cable if it appears to be damaged in any way
CONNECTING CHARGER TO POWER SOURCE
Connect the battery charger to the voltage
and frequency specified in this manual and
on the rating plate. Put the electric plug in an
earthed socket-outlet. The LED on the
battery charger lights up green.
CONNECTING CHARGER TO BATTERY
⚫The battery must be charged before using it
the first time.
⚫Install charger on the top of battery and
push until the charger connects firmly with
the battery.
⚫The LED will turn RED on the charger, when
the battery is connected to the battery
charger.
⚫When the LED on the charger turns to
GREEN, the battery is fully charged.
⚫Disconnect the power plug. Never pull the
power cable of the charger to disconnect it
from the wall socket.
⚫Remove battery from battery charger.
NOTE:
Lithium-ion batteries can be charged at whatever charging level. The charging process can be cancelled or
started whatever the battery’s charge level is.
For preparing seed beds, we recommend using one of these tilling patterns:
Tilling Pattern A – Make two passes over area to be tilled, the second at a right angle to the first.
Tilling Pattern B – Make two passes over area to be tilled, the second overlapping the first.
Clearing foreign objects:
During operation, a stone or root could become lodged in the tines, or tall grass or weeds may become wrapped
around the tine shaft. To clear the tines or tine shaft release the trigger lever, wait for the tines to come to a
complete stop and remove the battery from the tiller. Dislodge or remove the foreign matter from the tines or
tine shaft. To simplify removal of tall grass or weeds from the tine shaft, remove one or more of the tines. See
Tine Removal and Installation.
CAUTION
Before moving the tiller from one area to another, switch off the motor, wait for the tines to come to a
complete stop and remove the battery. Be careful not to let the tines touch the ground while moving the
tiller. The tines as well as the unit itself may be damaged even if the motor is switched off.
INSTRUCTION MANUAL

BATTERY & CHARGER
By pressing the button on the battery, the LED display will show the battery capacity.
LED LIGHTS
BATTERY STATUS
LED x4
Battery is 75-100% charged
LED x3
Battery is 50-75% charged
LED x2
Battery is 25-50% charged
LED x1
Battery is 0-25% charged
BATTERY CHARGER
WARNING
Risk of electric shock and short circuiting. Use approved and intact wall sockets. Make sure that the cable is
not damaged. Replace cable if it appears to be damaged in any way
CONNECTING CHARGER TO POWER SOURCE
Connect the battery charger to the voltage
and frequency specified in this manual and
on the rating plate. Put the electric plug in an
earthed socket-outlet. The LED on the
battery charger lights up green.
CONNECTING CHARGER TO BATTERY
⚫
The battery must be charged before using it
the first time.
⚫Install charger on the top of battery and
push until the charger connects firmly with
the battery.
⚫The LED will turn RED on the charger, when
the battery is connected to the battery
charger.
⚫When the LED on the charger turns to
GREEN, the battery is fully charged.
⚫Disconnect the power plug. Never pull the
power cable of the charger to disconnect it
from the wall socket.
⚫
Remove battery from battery charger.
NOTE:
Lithium-ion batteries can be charged at whatever charging level. The charging process can be cancelled or
started whatever the battery’s charge level is.
For preparing seed beds, we recommend using one of these tilling patterns:
Tilling Pattern A – Make two passes over area to be tilled, the second at a right angle to the first.
Tilling Pattern B – Make two passes over area to be tilled, the second overlapping the first.
Clearing foreign objects:
During operation, a stone or root could become lodged in the tines, or tall grass or weeds may become wrapped
around the tine shaft. To clear the tines or tine shaft release the trigger lever, wait for the tines to come to a
complete stop and remove the battery from the tiller. Dislodge or remove the foreign matter from the tines or
tine shaft. To simplify removal of tall grass or weeds from the tine shaft, remove one or more of the tines. See
Tine Removal and Installation.
CAUTION
Before moving the tiller from one area to another, switch off the motor, wait for the tines to come to a
complete stop and remove the battery. Be careful not to let the tines touch the ground while moving the
tiller. The tines as well as the unit itself may be damaged even if the motor is switched off.
INSTRUCTION MANUAL

TINE INSTALLATION
1. Install the new tine by pressing it onto the hub. The side with stamped part number must face outward. Be
sure to install tines in the same sequence as shown in Fig 7. Position the hub so that the larger diameter
whole is facing outward. Make sure the two tines on the same hub are installed symmetrically with the end
of the tine blades facing downward (Fig. 8).
2. Install the tines with hub onto the shaft. Ensure the larger diameter whole of the hub is facing outward. The
left and right tine assemblies must be installed symmetrically (Fig. 8).
3. Install the end caps.
4. Install the M8x170 bolt. Secure the assembly by tightening the M8 hex locknut with a hex head wrench.
5. Replace worn or damaged parts with original replacement parts only. Parts from another tiller may not fit
properly causing an unsafe situation.
6. Make sure all protective devices are secure and in good condition. Repair or replace if necessary.
STORAGE
Store the tiller in a dry, clean area out of reach of children.
During extended periods of storage, ensure that the tiller is protected against corrosion and frost.
Winter storage - Fully recharge before storage and then again, every 90 days.
At the end of the season, or if the tiller is not being used for longer than a month, wipe over all metal surfaces
with an oil impregnated cloth to protect them from corrosion or spray with a fine coat of oil.
Remove the battery from the tiller. Cover the terminals with heavy duty adhesive tape. Do not attempt to
destroy or disassemble the battery or remove any components. This product contains lithium-ion batteries
which must be recycled or disposed of properly.
Symmetrically
install the blades,
facing downwards
Larger diameter
hub to face
outwards
MAINTENANCE
WARNING
Before carrying out maintenance operations, disconnect power supply (Remove Battery).
Before each use of the charger, check the cable for signs of damage or ageing. Replace the cable if it is cracked,
split or otherwise damaged. Check the condition of the tines and ensure that all threaded connections are
securely tightened. If the tines become dull or blunt, sharpen or replace them. Call 01793 333212 for
assistance.
At the end of the season, check the tiller for damage prior to storing. Repair or replace damaged or broken
parts.
CAUTION
Always clean the tiller after each use. Failure to carry out proper cleaning can result in damage to the tiller or
result in poor performance.
To remove soil and debris from the tines, use a stiff brush or a soft cloth dampened with a mild soap and water
mixture. Never use a water hose or pressure washer to clean the tiller!
Clean the vents on the motor housing removing any remaining grass or dirt with a soft bristled brush. Never
use water! Once cleaned, wipe the tines dry and apply a light coat of oil to prevent rust.
WARNING
Injury can occur while working on the tines. Wear protective gloves.
Worn tines invite poor performance and overload of the motor. Check tines before each use. Sharpen or
replace the tine assemblies with new ones when necessary. Call 01793 333212 for assistance.
Replace only the tines with the identical part number.
TINE REMOVAL
1. Remove the M8 hex locknut with a hex head wrench, and then remove the M8x170 bolt.
2. Remove the end caps.
3. Remove the tines and hubs at either end of the shaft.
Blade 1
Blade 1
Blade 2
Blade 2
End Cap
M8 Hex Locknut
M8x170
Bolt
End Cap
Hub
Hub
Bushing
Bushing
Shaft
INSTRUCTION MANUAL

TINE INSTALLATION
1. Install the new tine by pressing it onto the hub. The side with stamped part number must face outward. Be
sure to install tines in the same sequence as shown in Fig 7. Position the hub so that the larger diameter
whole is facing outward. Make sure the two tines on the same hub are installed symmetrically with the end
of the tine blades facing downward (Fig. 8).
2. Install the tines with hub onto the shaft. Ensure the larger diameter whole of the hub is facing outward. The
left and right tine assemblies must be installed symmetrically (Fig. 8).
3. Install the end caps.
4. Install the M8x170 bolt. Secure the assembly by tightening the M8 hex locknut with a hex head wrench.
5. Replace worn or damaged parts with original replacement parts only. Parts from another tiller may not fit
properly causing an unsafe situation.
6. Make sure all protective devices are secure and in good condition. Repair or replace if necessary.
STORAGE
Store the tiller in a dry, clean area out of reach of children.
During extended periods of storage, ensure that the tiller is protected against corrosion and frost.
Winter storage - Fully recharge before storage and then again, every 90 days.
At the end of the season, or if the tiller is not being used for longer than a month, wipe over all metal surfaces
with an oil impregnated cloth to protect them from corrosion or spray with a fine coat of oil.
Remove the battery from the tiller. Cover the terminals with heavy duty adhesive tape. Do not attempt to
destroy or disassemble the battery or remove any components. This product contains lithium-ion batteries
which must be recycled or disposed of properly.
Symmetrically
install the blades,
facing downwards
Larger diameter
hub to face
outwards
INSTRUCTION MANUAL

Notes
TROUBLE SHOOTING
PROBLEM
POSSIBLE CAUSE
SOLUTION
Motor does not start
Safety lock button not fully
depressed
Check that safety lock button on handle is fully
depressed before pulling the trigger.
Battery not installed properly
Check battery installation.
Battery has low charge
Charge the battery.
Battery is either defective or will
not take a charge.
Replace the battery
Overheat protection activated
1. Working depth too large, set to a shorter
depth.
2. Tines blocked, remove the blockage.
3. Soil too hard, select correct work depth &
move forward and backward several times
while slowing down the operation speed.
4. Wait until the motor cools down for about
15 minutes before further use.
Abnormal noise
Tines are jammed
Switch off. Wait till tines come to a complete
stop and remove battery. Remove jammed
material.
Lubrication running out
Tiller must be repaired. Contact local approved
service dealer for assistance.
Bolts, nuts or other components
are loose.
Tighten all components. Arrange for repair if
noise continues.
Abnormal vibration
Blades damaged or worn
Replace damaged or worn blades
Working depth too large
Set to correct working depth
Poor results
Working depth too small
Set to correct working depth
Worn blades
Replace damaged or worn blades.
INSTRUCTION MANUAL
