WebDT 515A Assembly instructions

ENGLISH
BASIC OPERATION GUIDE
WebDT 515A/ 517A
WebDT 515A/ 517A
ENGLISH 4
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 hp://www.dtresearch.com
Copyright © 2011, DT Research, Inc. All Rights Reserved. DT Research and WebDT are registered trademarks of DT Research, Inc.
INTRODUCTION
Thank you for acquiring the DT Research WebDT 515A/
517A, a 15-inch (WebDT 515A) or 17-inch (WebDT 517A)
TFT display-integrated, thin compung plaorm, offering
adaptability to mounng configuraons and applicaon
paradigms, including informaon appliance, thin client for server
compung, and disk drive-equipped opons.
Please take a few moments to review the contents of this document to ensure that the setup and
startup proceed smoothly. The WebDT 515A/ 517A is ready for use, out of the box, in its default
configuraon when powered by the power source provided. The following discussion offers
guidance on the hardware elements and features of the WebDT 515A/ 517A. Please refer to your
device provider for informaon pertaining to the soware operang system or soware applica-
ons.
Package Contents
O
•ne WebDT 515A or 517A with desktop stand
A
•C/DC power adapter with power cord
Documentaon•
Precauons
Always exercise care when operang and handling the WebDT 515A/ 517A.•
Never disassemble any poron of the enclosure, as this will void any product warranty on the•
WebDT 515A/ 517A.
Do not use any AC/DC adapter other than the one provided with the device or a replacement•
acquired from the manufacturer.
I
•n the unlikely event that smoke, abnormal noise, or strange odor is present, immediately power
down the WebDT 515A/ 517A and disconnect all power sources. Please report the problem to
your device provider immediately.
Opons
The WebDT 515A/ 517A has a number of oponal configuraons in both soware and hardware.
These include:
HDD or SSD storage1.
IR Touch screen display2.
Magnec card reader3.
Built-in 802.11a/b/g/n WLAN support4.
Smart card reader; supports ISO 7816 T=0, T=1 smart card,5. 3V/ 5V smart card and memory card
* Specications subject to change without notice.
BOG031411DT515A517AENG
SPECIFICATIONS WebDT 515 WebDT 517
System
Processor Intel® Atom™ Z530, 1.6GHz
Memory (RAM) 2GB
Storage 2GB to 16GB Flash, 32GB to 64GB SSD, or HDD
Operang Systems Microso® Windows® XP Embedded or Windows® XP Pro
Display 15”TFT-LCD 17”TFT-LCD
Display Resoluon 1024 x 768 1280 x 1024
Touch Screen IR touch (oponal)
Network Interface Ethernet 10/ 100/ 1000 MB Base-T LAN;
802.11a/b/g/n WLAN (oponal)
Control Buons 5 side buons : 1 power buon and 4 programmable buons
Stereo Speaker Built-in speaker
Input/Output Ports 4 USB 2.0 ports; 2 COM ports; 1 Microphone-in jack; 1 Audio-out
jack; 1 RJ45 connector for Ethernet
Power
AC/DC Adapter Input: 100 – 240V AC; Output: 18.5V DC, 3.5A
Mechanical
Enclosure ABS + PC plascs ABS + PC plascs•
Bacteria-free plascs (oponal)•
Base or Pedestal Detachable aluminum construcon; VESA- compliant mounng
Dimensions (H x W x D)
(With base stand)
14 x 13.9 x 6.7 in/
356 x 354 x 171 mm
16.1 x 15.3 x 6.7 in/
409 x 388 x 171 mm
Dimensions (H x W x D)
(Without base stand)
10.9 x 13.9 x 2.5 in/
278 x 354 x 63 mm
12.6 x 15.3 x 2.7 in/
320 x 388 x 68 mm
Weight (With base stand) 13.2 lbs/ 6 kg 15.4 lbs/ 7 kg
Weight (Without base stand) 10.6 lbs/ 4.8 kg 12.8 lbs/ 5.8 kg
Environmental
Water and Dust Resistance IP65 sealed front IR touch panel (not applicable for non-IR SKU)
Regulatory FCC Class B, CE, C-Tick, RoHS compliant
Temperature Operaon: 0°C - 40°C; Storage: -20°C - 60°C
Humidity 0% – 90% non–condensing
* Specificaons subject to change without noce.
Integrated LCD Systems

WebDT 515A/ 517A
ENGLISH 23ENGLISH
Packaging
The WebDT 515A/ 517A is packaged with recyclable materials•
and designed for maximum protecon in transportaon and
handling.
When possible, please save the packaging carton and protecve•
inserts for re-use if there is ever a need to ship the WebDT
515A/ 517A.
I/O Panels
Lower I/O Panel
The WebDT 515A/ 517A has a comprehensive set of I/O ports. The following ports are located
along the lower rear edge of the display unit.
Two (2) USB 2.0 ports1.
COM ports2.
Microphone-in jack3.
Audio-out jack4.
Two (2) USB 2.0 ports5.
Ethernet port (RJ45)6.
18.5V/ 3.5A DC-in jack7.
Side Panel Funcon Buons
The side panel of the WebDT 515A/ 517A features
power, and programmable buons.
Buon Descripon
8. Programmable The three buons are intended to be user programmable via soware in
applicable operang systems.
9. Power
M
•ay be configured to perform different funcons, depending on the
soware operang system.
D
•epending on the OS, a brief, firm push will trigger soware-enabled
entry into Shutdown or Standby modes. Push in similar manner to Restart
or to exit Standby mode.
P
•ush and hold for over 4 seconds to forcefully shut down the device.
This method of powering offshould only be used when proper
shutdown through soware is not possible.
Rear Mounng
The WebDT 515A/ 517A is designed to be secured to VESA-compliant mounng arms or stands.
This is accomplished by detaching the standard metal base from the rear of the display unit. The
VESA-compliant mounng holes at the rear of the device will mate with VESA mounts or arms to
meet the requirements of the deployment.
Remove the detachable base by pressing1.
upward to remove the cover, then unscrewing
the four screws aaching the base to the
display.
Aach the new VESA-compliant mounng3.
device or stand to the display.
The display without the base.2.
The display successfully mounted on a4.
VESA-compliant mounng arm.
8
9
1 52 3 4 6 7
