Weed Eater WE165T42A User manual

l
OWNER'S MANUAL
MODEL NO.WE165T42A
16.5 HP42 Inch
LawnTractor
Assembly
• Operation
•Maintenance
•Service and Adjustments
•Storage
•Troubleshooting
•Repair Parts
For Parts and Service, contact our authorized distributor: call 1-800-849-1297
For Technical Assistance: call 1-800-829-5886
EATER
186073 12.2.02 RD
PRINTED IN U.S.A,

SAFETY RULES
_lb SAFE OPERATION PRACTICES FOR RIDE-ON MOWERS _b
IMPORTANT: THIS CUFFING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS. FAILURE
TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH.
I. GENERAL OPERATION
Read, understand, and follow all instructions in the
manual and on the machine before starting.
Only allow responsible adults, who are familiar with the
instructions, to operate the machine.
• Clear the area of objects such as rocks, toys, wire, etc.,
which could be picked up and thrown by the blade.
Be sure the area is clear of other people before mow-
ing. Stop machine if anyone enters the area.
•Never carry passengers.
• Do not mew in reverse unless absolutely necessary.
Always look down and behind before and while back-
ing.
Be aware of the mower discharge direction and do not
point it at anyone. Do not operate'the mower without
either the entire grass catcher or the guard in place.
• Slow down before turning.
Never leave a running machine unattended. Always
turn off blades, set parking brake, stop engine, and
remove keys before dismounting.
• Turn off blades when not mowing.
• Stop engine before removing grass catcher or un-
clogging chute.
• Mow only in daylight or good artificial light.
Do not operate the machine while under the influence
of alcohol or drugs.
• Watch for traffic when operating near or crossing road-
ways.
• Use extra care when loading or unloading the machine
into a trailer or truck.
• Data indicates that operators, age 60 years and above,
are involved in alarge percentage of riding mower-re-
lated injuries. These operators should evaluate their
ability to operate the riding mower safely enough to
protect themselves and others from serious injury.
• Keep machine free of grass, leaves or other debris
build-up which can touch hot exhaust /engine parts
and burn. Do not allow the mower deck to plow leaves
or other debris which can cause build-up to occur.
Clean any oil or fuel spillage before operating or
storing the machine. Allow machine to cool before
storage.
Ih SLOPE OPERATION
Slopes are a major factor related to loss-of-control and tipover
accidents, which can result in severe injury or death. All slopes
require extra caution. If you cannot back up the slope or if you
feel uneasy on it, do not mowit.
DO: Mow up and clown slopes, not across.
• Remove obstacles such as rocks, tree limbs, etc.
Watch for holes, ruts, or bumps. Uneven terrain could
overturn the machine. Tall grass can hide obstacles.
• Use slow speed. Choose a low gear so that you will
not have to stop or shift while on the slope.
• Follow the manufacturer's recommendations for wheel
weights or counterweights to improve stability.
•Useextra care with grass catchers or other attachments.
These can change the stability of the machine.
Keep all movement on the slopes slow and gradual
Do not make sudden changes in speed or direction.
Avoid starting or stopping on a slope. If tires lose trac-
tion, disengage the blades and proceed slowly straight
down the slope.
DO NOT:
•Do not turn on slopes unless necessary, and then,
turn slowly and gradually downhill, if possible.
Do notmow near drop-offs, ditches, or embankments.
The mower could suddenly turn over ifa wheel is over
the edge of a cliff or ditch, or if an edge caves in.
•Do not mow on wet grass. Reduced traction could
cause sliding.
Do not try to stabilize the machine by putting your foot
on the ground.
•Do not use grass catcher on steep slopes.
III. CHILDREN
Tragicaccidents can occur ifthe operatorisnot alert tothe pres-
ence of children. Children are often attracted to the machine
and the mowingactivity. Neverassumethat children will remain
where you last saw them.
• Keep children out of the mowing area and under the
watchful care of another responsible adult.
• Be alert and turn machine off if children enter the
area.
• Before and when backing, look behind and down for
small children.
•Never carry children. They may fall off and be seriously
injured or interfere with safe machine operation.
• Never allow children to operate the machine.
Use extra care when approaching blind corners, shrubs,
trees, or other objects that may obscure vision.
IV. SERVICE
• Use extra care in handling gasoline and other fuels.
They are flammable and vapors are explosive.
- Use only an approved container.
- Never remove gas cap or add fuel with the engine
running. Allow engine to cool before refueling. Do
not smoke.
- Never refuel the machine indoors.
- Never store the machine orfuel container inside where
there is an open flame, such as a water heater.
• Never run a machine inside a closed area.
• Keep nuts and bolts, especially blade attachment bolts,
tight and keep equipment in good condition.
•Never tamper with safety devices. Check their proper
operation regularly.
• Keep machine free of grass, leaves, or other debris
build-up. Clean oil or fuel spillage. Allow machine to
cool before storing.
• Stop and inspect the equipment if you strike an object.
Repair, if necessary, before restarting.
Never make adjustments or repairs with the engine
running.
Grass catcher components are subject to wear, dam-
age, and deterioration, which could expose moving
parts or allow objects to be thrown. Frequently check
components and replace with manufacturer's recom-
mended parts, when necessary.
Mower blades are sharp and can cut. Wrap the blade(s)
or wear gloves, and use extra caution when servicing
them.
Check brake operation frequently. Adjust and service
as required.

SAFETY RULES
'_ SAFE OPERATION PRACTICES FOR RIDE-ON MOWERS
Be sure the area isclear ofother people before mowing. Stop
machine if anyone enters the area.
Never carry passengers or children even with the blades
off.
Do not mow in reverse unless absolutely necessary. AJways
look down and behind before and while backing.
Never carry children.They may fall off and be seriously injured
or interfere with safe machine operation.
Keep children out of the mowing area and under the watchful
care of another responsible adult.
Be alert and turn machine off if children enter the area.
Before and when backing, look behind and down for small
children.
Mow up and down slopes (15°Max), not across.
Remove obstacles such as rocks, tree limbs, etc.
Watch for holes, ruts, or bumps. Uneven terrain could overturn
the machine. Tall grass can hide obstacles.
Use slow speed. Choose a low gear so that you will not have
1ostop or shift while on the slope.
Avoid starting or stopping on a slope. If tires lose traction,
disengage the blades and proceed slowly straight down the
slope.
If machine stops while going uphill, disengage blades, shift
into reverse and back down slowly.
Do not turn on slopes unless necessary, and then, turn slowly
and gradually downhill, if possible.
&
I&
WARNING: in order to prevent ac-
cidental starting when setting up,
transporting, adjusting or making re-
pairs, always disconnect spark plug
wire and place wire where it cannot
contact spark plug.
I
WARNING: Do not coast down a hill I
in neutral, you may lose control of the I
tractor.
&WARNING: Tow only the attachments
that are recommended by and com-
ply with specifications of the manu-
facturer of your tractor. Use common
sense when towing. Operate only at
the lowest possible speed when on a
slope. Too heavy of a load, while on
a slope, is dangerous. Tires can lose
traction with the ground and cause you
to lose control of your tractor.
WARNING
Engine exhaust, some of its constituents, and cer-
tain vehicle components contain or emit chemicals
known to the State of California to ca use cancer and
birth defects or other reproductive harm.
WARNING
Battery posts, terminals and related accessories
contain lead and lead compounds, chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm. Wash hands
after handling.
3

PRODUCT SPECIFICATIONS
GASOLINE CAPACITY
AND TYPE:
OIL TYPE (API-SF-SJ):
OIL CAPACITY:
SPARK PLUG:
(GAP: .030")
GROUND SPEED (MPH):
TIRE PRESSURE:
CHARGING SYSTEM:
BATTERY:
3LADE BOLT TORQUE:
1.25 GALLONS
UNLEADED REGULAR
SAE 30 (above 32°F)
SAE 5W-30 (below 32°F)
W/FiLter 3.9 Pints
W/O Filter 3.4 Pints
CHAMPION RN4C
FORWARD:
1st 1.1
2nd 1.4
3rd 2.2
4th 3.3
5th 4.4
6th 4.9
REVERSE: 1.4
FRONT: 14 PSI
REAR: 12 PSI
3 AMPS BATTERY
5 AMPS HEADLIGHTS
AMP/HR: 28
MIN. CCA: 230
CASE SIZE: U1R
27-35 FT. LBS.
CONGRATULATIONS on your purchase of a new tractor.
It has been designed, engineered and manufactured to give
you the best possible dependability and performance.
Should you experience any problem you cannot easily rem-
edy, please contact your nearest authorized service center/
department. We have competent, well-trained technicians
and the proper tools to service or repair this tractor.
Please read and retain this manual. The instructions will
enable you to assemble and maintain your tractor properly.
Always observe the "SAFETY RULES".
CUSTOMER RESPONSIBILITIES
•Read and observe the safety rules.
Follow a regular schedule in maintaining, caring for
and using your tractor.
Follow the instructions under "Maintenance" and "Stor-
age" sections of this owner's manual.
WARNING: This tractor isequipped with an internal com-
bustion engine and should not be used on or near any
unimproved forest-covered, brush-covered or grass-covered
land unless the engine's exhaust system is equipped with
a spark arrester meeting applicable local or state laws (if
any). If a spark arrester is used, it should be maintained
in effective working order by the operator.
A spark arrester for the muffler is available through your
nearest authorized service center/department (See REPAIR
PARTS section of this manual).
TABLE OF CONTENTS
SAFETY RULES ......................................................... 2-3
PRODUCT SPECIFICATIONS ....................................... 4
CUSTOMER RESPONSIBILITIES ................................. 4
ASSEMBLY ................................................................. 6-8
OPERATION ............................................................. 9-13
MAINTENANCE SCHEDULE ...................................... 14
MAINTENANCE ..................................................... 14-17
SERVICE AND ADJUSTMENTS ............................ 18-23
STORAGE .................................................................... 24
TROUBLESHOOTING ............................................ 25-26
REPAIR PARTS ...................................................... 28-43
WARRANTY ................................................................. 45
4

CONTENTS OF HARDWARE PACK
Steering Wheel
Steering
Wheel
Insert
Steering Wheel
Adapter
Steering
Boot
Steering
Extension
Shaft
(
(1) Large Flat Washer (1) Locknut 1/4-28
(1) Hex Bolt 1/4-28x 1-1/4
Seat
(1) Washer (_
17/32 x 1-3/16 x 12 Gauge
(1) Lock
Washer 1/2
(1) Bolt
(1) Oil Drain Tube
Keys
(2) Keys
Slope Sheet
5

ASSEMBLY
Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes.
To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use
the correct tools as necessary to insure proper tightness.
TOOLS REQUIRED FOR ASSEMBLY
A socket wrench set will make assembly easier. Standard
wrench sizes are listed.
(2) 7/16" wrenches Utility knife
(2) 3/4" wrench Tire pressure gauge
Pliers
When right or left hand is mentioned in this manual, itmeans
when you are in the operating position (seated behind the
steering wheel).
TO REMOVE TRACTOR FROM
CARTON
UNPACK CARTON
•Remove all accessible loose parts and parts cartons
from carton.
• Cut along dotted lines on all four panels of carton.
Remove end panels and lay side panels flat.
Check for any additional loose parts or cartons and
remove.
BEFORE REMOVING TRACTOR FROM
SKID
ATTACH STEERING WHEEL (See Fig. 1)
ASSEMBLE EXTENSION SHAFT AND BOOT
Slide extension shaft onto lower steering shaft. Align
mounting holes in extension and lower shafts and install
1/4 hex bolt and Iocknut. Tighten securely.
IMPORTANT:TIGHTEN BOLTAND NUT SECURELYTO 10-12
FT.LBS TORQUE.
Place tabs of steering boot over tab slots in dash and push
down to secure.
INSTALL STEERING WHEEL
• Positionfrontwheelsofthetractorsotheyare pointingstraight
forward.
• Remove steering wheel adapter from steering wheel and
slide adapter onto steering shaft extension.
Position steering wheel so cross bars are horizontal (left to
right)and slide inside boot and onto adapter.
Assemble large flat washer, 1/2 hex nut and tighten se-
curely.
• Snap steering wheel insert into center of steering wheel.
Removeprotective materials from tractor hood and grill.
IMPORTANT: CHECK FOR AND REMOVE ANY STAPLES
IN SKID THAT MAY PUNCTURE TIRES WHERE TRACTOR
ISTO ROLL OFF SKID.
INSERTr
_---'-- 1/2 HEX NUT
@---_LARGE FLAT
WASHER
STEERING
WHEEL
ADAPTER_
_IA EERING
OOT
BS
SHAFT
_'_ _'_L
LOWER t,_ . I
STEERING _._7 _ J I
SHAFT I"_ ,_ ,'_ _
_-_._,_ _ ,//" SLOTS
FIG. 1
6

ASSEMBLY
HOW TO SET UP YOUR TRACTOR
INSTALL SEAT (See Fig. 2)
Adjust seat before tightening adjustment bolt.
Remove adjustment bolt, lock washer and flat washer
securing seat to cardboard packing and set aside for
assembly of seat to tractor.
Pivot seat upward and remove from the cardboard pack-
ing. Remove the cardboard packing and discard.
• Place seat on seat pan so head of shoulder bolt is
positioned over large slotted hole in pan.
• Push down on seat to engage shoulder bolt in slot and
pull seat towards rear of tractor.
Pivot seat and pan fonNard and assemble adjust-
ment bolt, Iockwasher and flat washer loosely. Do not
tighten
• Lower seat into operating position and sit on seat.
Slide seat until a comfortable position is reached
which allows you to press clutch/brake pedal all the
way down.
• Get off seat without moving its adjusted position.
Raise seat and tighten adjustment bolt securely.
SEAT PAN _!'
FLATWASHER
ADJUSTMENT
BOLT
SHOULDER
BOLT
FIG. 2
CHECK BATTERY (See Fig. 3)
•Lift seat pan to raised position.
If this battery is put into service after month and year
indicated on label (label located between terminals)
charge battery for minimum of one hour at 6-10 amps.
(See "BATTERY" in MAINTENANCE section of this
manual for charging instructions),
SEAT PAN
LABEL
FIG. 3
NOTE: You may now roll or drive your tractor off the skid.
Follow the appropriate instruction below to remove the
tractor from the skid.
TO ROLLTRACTOR OFF SKID (See Op-
eration section for location and function of
controls)
Press lift lever plunger and raise attachment lift lever
to its .highest position.
Release parking brake by depressing clutch/brake
pedal.
Place gearshift lever in neutral (N) position.
• Roll tractor forward off skid.
Remove banding holding deflector shield up against
tractor.
TO DRIVE TRACTOR OFF SKID (See Op-
eration section for location and function of
controls)
_WARNING: Before starting, read, understand and follow
all instructions in the Operation section of this manual. Be
sure tractor is in a well-ventilated area. Be sure the area in
front of tractor is clear of other people and objects.
Be sure all the above assembly steps have been com-
pleted.
• Check engine oil level and fill fuel tank with gasoline.
• Sit on seat in operating position, depress clutch/brake
pedal and set the parking brake.
Place gear shift lever in neutral (N) position.
• Press lift lever plunger and raise attachment lift lever
to its highest position.
• Start the engine.After engine has started, move throttle
control to idle position.
• Depress clutch/brake pedal into full "BRAKE" position
and hold. Move gearshift lever to 1st gear.
• Slowly release clutch/brake pedal and slowly drive
tractor off skid.
Apply brake to stop tractor, set parking brake and place
gearshift lever in neutral position.
• Turn ignition key to "OFF" position.
Continue with the instructions that follow.
7

ASSEMBLY
CHECKTIRE PRESSURE
The tires on your tractor were overinflated at the factory
for shipping purposes. Correct tire pressure is important
for best cutting performance.
Reduce tire pressure to PSI shown in "PRODUCT
SPECIFICATIONS" section of this manual.
CHECK DECK LEVELNESS
Forbest cutting results, mower housing should be properly
leveled. See"TO LEVEL MOWER HOUSING"in the Service
and Adjustments section of this manual.
CHECK FOR PROPER POSITION OF ALL
BELTS
See the figures that are shown for replacing motion and
mower blade drive belts in the Servic_ and Adjustments
section of this manual. Verify that the belts are routed
correctly.
CHECK BRAKE SYSTEM
After you learn how to operate your tractor, chock tosee that
the brake is properly adjusted. See "TO ADJUST BRAKE"
in the Service and Adjustments section of this manual.
,/CHECKLIST
BEFORE YOU OPERATE AND ENJOY YOUR NEW TRAC-
TOR, WE WISH TO ASSURE THAT YOU RECEIVE THE
BESTPERFORMANCEAND SATISFACTION FROMTHIS
QUALITY PRODUCT
PLEASE REVIEW THE FOLLOWING CHECKLIST"
,/ All assembly instructions have been completed.
,/ No remaining loose parts in carton.
,/ Battery is properly prepared and charged. (Minimum
1 hour at 6 amps).
,/ Seat is adjusted comfortably and tightened securely.
,/ All tires are properly inflated. (For shipping purposes,
the tires were overinflated at the factory).
,/ Be sure mower deck is properly leveled side-to-side/
front-to-rear for best cutting results. (Tires must be
properly inflated for leveling).
,/ Check mower and drive belts. Be sure they are routed
properly around pulleys and inside all belt keepers.
/Check wiring. See that all connections are still secure
and wires are properly clamped.
WHILE LEARNING HOW TO USE YOUR TRACTOR, PAY
EXTRA ATTENTION TO THE FOLLOWING IMPORTANT
ITEMS:
,/ Engine oil is at proper level.
,/ Fuel tank is filled with fresh, clean, regular unleaded
gasoline.
,/ Become familiar with all controls - their location and
function. Operate them before you start the engine.
,Z Be sure brake system is in safe operating condition.
8

OPERATION
These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their mean-
ing. R N H L I\1
REVERSE NEUTRAL HIGH LOW CHOKE FAST SLOW IGNITION
6
ENGINE OFF LIGHTS ON ENGINE ON
OVER TEMP FUEL OIL PRESSURE
LIGHT
ATTACHMENT ATTACHMENT
CLUTCH ENGAGED CLUTCH DISENGAGED
FREE WHEEL
(Automatic Models only)
&
Failure to follow instructions
could result in serious injury or
death. The safety alert symbol
is used to identify safety inform-
ation about hazards which can
result in death, serious injury
and/or property damage.
ENGINE START PARKING BRAKE PARKING BRAKE PARKING BRAKE
LOCKED UNLOCKED
BATTERY REVERSE FORWARD MOWER HEIGHT MOWER LIFT
DANGER, KEEP HANDS
AND FEET AWAY
®@@®@
KEEP AREA CLEAR SLOPE HAZARDS
(SEE SAFETY RULES SECTION)
&
&
&
DANGER indicates a hazard which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazard which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazard which, if not avoided,
might result in minor or moderate injury.
CAUTION when used without the alert symbol,
indicates a situation that could result in damage
to the tractor and/or engine.
_HOT SURFACES indicates a hazard which,
,,_,{llt_l,l_,,,if not avoided, could result in death, serious injury
and/or property damage.
FIRE indicates a hazard which, if not avoided,
could result in death, serious injury and/or
property damage.
9

OPERATION
KNOW YOUR TRACTOR
READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR
Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and adjustments.
Save this manual for future reference.
IGNITION
ATTACHMENT SWITCH
CLUTCH LEVER
THROTTLE/ ,"
CHOKE PLUNGER
CONTROL
ATTACHMENT
LIFT LEVER
i
ADJUSTMENT
LEVER
I
GEAR SHIFT
LEVER
PARKING
BRAKE
FIG. 4
Our tractors conform to the safety standards of the American National Standards Institute.
ATTACHMENT CLUTCH LEVER: Used to engage the
mower blades, or other attachments mounted to your
tractor.
LIGHT SWITCH POSITION: Turns the headlights on and
off.
THROTTLE/CHOKE CONTROL: Used for starting and
controllingengine speed.
CLUTCH/BRAKE PEDAL: Used for declutching and brak-
ing the tractor and starting the engine.
PARKING BRAKE: Locksclutch/brake pedal intothe brake
position.
GEARSHIFT LEVER - Selects the speed and direction
of the tractor.
ATTACHMENT LIFT LEVER: Used to raise, lower, and
adjust the mower deck or other attachments mounted to
your tractor.
LIFT LEVER PLUNGER: Used to release attachment lift
lever when changing itsposition.
IGNITION SWITCH: Used for starting and stopping the
engine.
10

OPERATION
HOW TO USE YOUR TRACTOR
TO SET PARKING BRAKE (See Fig. 5)
Yourtractor is equipped with an operator presence sens-
ing switch. When engine is running, any attempt by the
operator to leave the seat without first setting the parking
brake will shut off the engine.
Depress clutch/brake pedal intofull "BRAKE" position
and hold.
•Place parking brake lever in"ENGAGED" position and
release pressurefrom clutch/brake pedal. Pedal should
remain in"BRAKE" position. Make sure parking brake
will hold tractor secure.
I
The operation of any tractor can result in foreign objects thrown into the eyes, which can result I
in severe eye damage. Always wear safety glasses or eye shields while operating your tractor or I
performing any adjustments or repairs, We recommend a wide vision safety mask over spectacles
or standard safety glasses.
NOTE: Under certain conditions when tractor is standing
idlewiththe engine running,hot engine exhaust gases may
cause "browning" ofgrass. To eliminate this possibility,al-
ways stop engine when stopping tractor on grass areas.
ATTACHMENT CLUTCH
LEVER "ENGAGED"
__OSITION
TRROI-rLE/ _/_( ._ _ IGNITION KEY
CHOKE ___
CONTROL _ -" _,_'F"OISENGAGEO"
,,.ARK,NGB.AKE
"BRA,E" 711ENGAGED
POSIT,ON PosmoN
CLUTCWBRAKE PARKING BRAKE
PEDAL "DRIVE" "DISENGAGED"
POSITION POSITION
FIG. 5
STOPPING (See Fig. 5)
MOWER BLADES -
• To stop mower blades,move attachment clutch lever
to "DISENGAGED" position.
GROUND DRIVE -
• To stop ground drive, depress clutch/brake pedal into
full "BRAKE" position.
• Move gearshift lever to neutral (N) position.
ENGINE -
• Move throttle control to slow position.
NOTE: Failureto move throttlecontrol to slow position and
allowing engine to idle before stopping may cause engine
to "backfire".
•Turn ignition key to "OFF" position and remove key.
Always remove key when leaving tractor to prevent
unauthorized use.
Never use choke to stop engine.
IMPORTANT: LEAVING THE IGNITION SWITCH IN ANY
POSITION OTHER THAN "OFF"WILL CAUSETHE BATrERY
TO BE DISCHARGED,(DEAD).
LCAUTION: Always stop tractor com-
pletely, as described above, before leav-
ing the operator's position; to empty
grass catcher, etc.
TO USETHROTTLE CONTROL (See Fig. 5)
Always operate engine at full throttle.
Operating engine at less than full throttle reduces the
battery charging rate.
Full throttle offers the best bagging and mower perfor-
mance.
TO MOVE FORWARD AND BACKWARD (See
Fig. 5)
The direction and speed of movement iscontrolled bythe
gearshift lever.
Start tractor with clutch/brake pedal depressed and
gearshift lever in neutral (N) position.
Move gearshift lever to desired position,
•Slowly release clutch/brake pedal to start move-
ment.
IMPORTANT: BRING TRACTOR TO A COMPLETE STOP
BEFORE SHIFTING OR CHANGING GEARS, FAILURE
TO DO SO WILL SHORTEN THE USEFUL LIFE OF YOUR
TRANSAXLE.
TO ADJUST MOWER CUTTING HEIGHT (See
Fig. 5)
The position of the attachment lift lever determines the
cutting height.
Grasp lift lever.
Press plunger with thumb and move lever to desired
position.
The cutting height range is approximately 1-1/2 to 4".
The heights are measured from the ground to the blade tip
with the engine not running. These heights are approximate
and may vary depending upon soil conditions, height of
grass and types of grass being mowed.
• The average lawn should be cut to approximately 2-1/2
inches during the cool season and to over 3 inches
during hot months. For healthier and better looking
lawns, mow often and after moderate growth.
For best cutting performance,'grass over 6 inches
in height should be mowed twice. Make the first cut
relatively high; the second to desired height.
TO ADJUST GAUGE WHEELS (See Fig. 6)
Gauge wheels are properly adjusted when theyare slightly
off the ground when mower is at the desired cutting height
in operating position. Gauge wheels then keep the deck
in proper position to help prevent scalping in most terrain
11 conditions.

OPERATION
TO OPERATE ON HILLS
NOTE:Adjust gauge wheels with tractor on a flat level
surface.
Adjust mower to desired cutting height (See "TO AD-
JUST MOWER CUTTING HEIGHT" in the Operation
section of this manual).
• With mower in desired height of cut position, gauge
wheels should be assembled so they are slightly off
the ground. Install gauge wheel in appropriate hole with
shoulder bolt, 17/32 washer, 3/8 washer, and 3/8-16
Iocknut and tighten securely.
• Repeat foropposite side installing gauge wheel in same
adjustment hole.
GAUGE
WHEEL
MOUNTING--_.
BRACKET
3/8-16
LOCKNUT
3/8 WAS SHOULDER
17/32 WASHER
FIG. 6
TO OPERATE MOWER (See Fig. 7)
Yourtractor is equipped with anoperator presence sensing
switch. Any attempt by the operator to leave the seat with
the engine running and the attachment clutch engaged will
shut off the engine.
•Select desired height of cut.
Start mower blades by engaging attachment clutch
control.
• TO STOP MOWER BLADES - disengage attachment
clutch control.
CAUTION: Do not operate the mower
without either the entire grass catcher,
on mowers so equipped,orthe deflector
shield in place.
!NT
HIGH POSITION
CLUTCH LEVER
"DISENGAGED"
POSITION
LOW
POSITION
_/_ SHIELD
FIG. 7
I_lh WARNING: Do not drive up or down
hills with slopes greater than 15°and
do not drive across any slope.
Choose the slowest speed before starting up or down
hills.
Avoid stopping or changing speed on hills.
If slowing is necessary, move throttle control lever to
slower position.
If stopping is absolutely necessary, push clutch/brake
pedal quickly to brake position and engage parking
brake.
• Move gearshift lever to 1st gear. Be sure you have
allowed room for tractor to roll slightly as you restart
movement.
To restart movement, slowly release parking brake and
clutch/brake pedal.
• Make all turns slowly.
TO TRANSPORT
• Raise attachment lift to highest position with attachment
lift control.
• When pushing or towing yourtractor, be sure gearshift
lever is in neutral (N) position.
• Do not push or tow tractor at more than five (5) MPH.
NOTE: To protect hood from damage when transporting
your tractor on a truck or a trailer, be sure hood is closed
and secured to tractor. Use an appropriate means of tying
hood to tractor (rope, cord, etc.).
TOWING CARTS AND OTHER ATTACH-
MENTS
Tow only the attachments that are recommended by and
comply with specifications of the manufacturer of your trac-
tor. Use common sense when towing. Too heavy of a load,
while on a slope, is dangerous. Tires can lose traction with
the ground and cause you to lose control of your tractor.
BEFORE STARTING THE ENGINE
CHECK ENGINE OIL LEVEL
•The engine in yourtractor has been shipped, from the
factory, already filled with summer weight oil.
• Check engine oil with tractor on level ground.
•Remove oilfill cap/dipstick and wipe clean, rainsertthe
dipstick and screw cap tight, wait for afew seconds,
remove and read oil level. If necessary, add oil until
"FULL" mark on dipstick is reached. Do not overfill.
For cold weather operation you should change oil for
easier starting (See "OIL VISCOSITY CHART" in the
Maintenance section ofthis manual).
To change engine oil, see the Maintenance section in
this manual.
12

OPERATION
ADD GASOLINE
Fill fuel tank to bottom of filler neck. Do not overfill.
Use fresh, clean, regular unleaded gasoline with a
minimum of 87 octane. (Use of leaded gasoline will
increase carbon and lead oxide deposits and reduce
valve life). Do not mix oil with gasoline. Purchase fuel
in quantities that can be used within 30 days to assure
fuel freshness.
J_ CAUTION: Wipe off any spilled oil or I
I
fuel. Do not store, spill or use gasoline I
near an open flame.
IMPORTANT: WHEN OPERATING IN TEMPERATURES
BELOW32°F(0°C), USE FRESH, CLEAN WINTER GRADE
GASOLINE TO HELP INSURE GOOD COLD WEATHER
STARTING.
CAUTION: Alcohol blended fuels (called
gasohol or using ethanol or methanol) can at-
tract moisture which leads to separation and
formation of acids during storage. Acidic gas
can damage the fuel system of an engine while
in storage. To avoid engine problems, the fuel
system should be emptied before storage of
30 days or longer. Drain the gas tank, start
the engine and let it run until the fuel lines
and carburetor are empty. Use fresh fuel next
season. See Storage Instructions for additional
information. Never use engine or carburetor
cleaner products in the fuel tank or permanent
damage may occur.
COLD WEATHER STARTING ( 50° F and below)
When engine starts, allow engine to run withthe throttle
control in the choke (1\1)position until the engine runs
roughly, then move throttle control to fast position. This
may require an engine warm-up period from several
seconds to several minutes, depending on the tem-
perature.
• The attachments can also be used during the engine
warm-up period.
NOTE: If at a high altitude (above 3000 feet) or in cold
temperatures (below 32 F) the carburetor fuel mixture may
need to be adjusted for best engine performance. See "TO
ADJUST CARBURETOR" in the Service and Adjustments
section of this manual.
MOWING TIPS
Mower should beproperly leveled for best mowing per-
formance. See "TO LEVEL MOWER HOUSING" inthe
Service and Adjustments section of this manual.
The left hand side of mower should be used for trim-
ming.
Drive so that clippings are discharged onto the area
that has been cut. Have the cut area tothe rightofthe
machine. This will result in amore even distributionof
clippings and more uniform cutting.
•When mowinglargeareas, start bytumingtotherightso
that clippingswilldischarge away from shrubs, fences,
driveways, etc. After one or two rounds, mow in the
opposite direction making left hand turns untilfinished
(See Fig. 8).
TO START ENGINE (See Fig. 5)
When starting the engine for the first time or ifthe engine
has run out of fuel, it will take extra cranking time to move
fuel from the tank to the engine.
Sit on seat in operating position,depress clutch/brake
pedal and set parking brake
Place gear shift lever in neutral (N) position.
•Move attachment clutch to "DISENGAGED" position
Move throttle control to choke (1\1)position.
NOTE: Before starting, read the warm and cold starting
procedures below.
• Insert key into ignition and turn key clockwise to"START"
position and release key as soon as engine starts.
Do not run starter continuously for more than fifteen
seconds per minute. If the engine does not start after
several attempts, move throttle control to fast position,
wait a few minutes and try again. If engine still does
not start, move the throttle control back to the choke (
I\1)position and retry.
WARM WEATHER STARTING (50° F and above)
When engine starts, move the throttle control to the
fast position.
The attachments and ground drive can now be used. If
the engine does not accept the load, restart the engine
and allow itto warm up for one minute using the choke
as described above.
f]D
FIG. 8
• If grass is extremely tall, it should be mowed twice to
reduce load and possible fire hazard from dried clip-
pings. Make first cut relatively high;the second to the
desired height.
Do not mow grass when it is wet. Wet grass will plug
mower and leave undesirable clumps. Allow grass to
dry before mowing.
Always operate engine at fuli throttle when mow-
ing to assure better mowing performance and proper
discharge of material. Regulate ground speed by se-
lecting a low enough gear to give the mower cutting
performance as well as the quality of cut desired.
•When operating attachments, select aground speed
that will suit the terrain and give best performance of
the attachment being used.
13

MAINTENANCE
MAINTENANCE SCHEDULE _,_;_,_ _'_ a__ _o_o_ o_-_
AS YOU COMPLETE
REGULARSERV,CE / TSERV'CE DATES
II _//m
Check Brake Operation _
Check Tire Pressure
Check Operator Presence and
m Interlock Systems
Check for Loose Fasteners i_ _5 If
ASharpen/Replace Mower Blades i_
Lubrication Chart
TCheck Battery Level
aClean Battery and Terminals V'
Check Transaxle Cooling
Check V-Belts Vw
Check Engine Oil Level _Vw
IChange Engine Od (with oil filter) I_1,; If
EChange Engine Oil (without oil filter) 1_21 If
NClean Air Filler _z i
GClean Air Screen V'z
Inspect Muffler/Spark Arrester I_
EReplace Oil Filter (If equipped) _.2
Clean Engine Cooling Fins _2
Replace Spark Plug _2 ll_
Replace Air Filter Paper Cartridge
Replace Fuel Filter I1_
1-Change more often when operating under aheavy load or
in high ambient temperatures.
2 - Service more often when operating in dirty or dusty conditions
3 - Replace blades more often when mowing in sandy sod.
4- Not required if equipped with maintenance-free battery
5 - Tighten lront axle pivot bolt to 35 ft -Ibs. maximum.
Do not overtighten.
GENERAL RECOMMENDATIONS
The warranty on this tractor does not cover items that have
been subjected to operator abuse or negligence. To receive
full value from the warranty, operator must maintain tractor
as instructed in this manual.
Some adjustments wilt need to be made periodically to
properly maintain your tractor.
All adjustments in the Service and Adjustments section
of this manual should be checked at least once each
season.
•Once a year you should replace the spark plug, clean
or replace air filter, and check blades and belts for wear.
A new spark plug and clean air filter assure proper air-
fuel mixture and help your engine run better and last
longer.
BEFORE EACH USE
Check engine oil level.
• Check brake operation.
Check tire pressure.
• Check operator presence and
interlock systems for proper operation.
• Check for loose fasteners.
LUBRICATION CHART
OSPINDLE ZERK .---_.
FRONT __.._.._.
WHEEL =m
BEARING <_
ZERK
--SPINDLE ZERK (_
FRONT @
............. HEEL
ZERK
-_
:======, ENGINE (_)
(_ General Purpose Grease
Refer to Maintenance "ENGINE" Section
IMPORTANT: DO NOT OIL OR GREASE THE PIVOT POINTS
WHICH HAVE SPECIAL NYLON BEARINGS. VISCOUS
LUBRICANTS WILL ATFRACT DUST AND DIRT THAT WILL
SHORTEN THE LIFE OFTH E SELF-LUBRICATING BEARINGS.
IFYOU FEELTHEY MUST BE LUBRICATED, USE ONLY A DRY,
POWDERED GRAPHITE TYPE LUBRICANT SPARINGLY.
14

MAINTENANCE
TRACTOR
Always observe safety rules when performing any main-
tenance.
BRAKE OPERATION
If tractor requires more than six (6) feet stopping distance
at high speed in highest gear, then brake must be adjusted.
(See"TO ADJUST BRAKE"in the Service and Adjustments
section of this manual).
TIRES
• Maintainproperairpressureinalltires(See"PRODUCT
SPECIFICATIONS" section of this manual).
Keep tires free of gasoline, oil, or insect control chemi-
cals which can harm rubber.
•Avoid stumps, stones, deep ruts, sharp objects and
other hazards that may cause tire damage.
NOTE: To seal tire punctures and prevent flat tires due to
slow leaks, tire sealant may be purchased from your local
parts dealer. Tire sealant also prevents tire dry rot and
corrosion.
OPERATOR PRESENCE SYSTEM
Be sure operator presence and interlock systems are work-
ingproperly. Ifyour tractor does not function as described,
repair the problem immediately.
• The engine should not start unless the clutch/brake
pedal isfully depressed and attachement clutch control
is in the disengaged position.
When the engine is running, any attempt by the operator
to leave the seat without first setting the parking brake
should shut off the engine.
•When the engine is running and the attachment clutch
is engaged, any attempt by the operator to leave the
seat should shut off the engine.
•The attachment clutch should never operate unless
the operator is in the seat.
BLADE CARE
For best results mower blades must be kept sharp. Replace
bent or damaged blades.
BLADE REMOVAL (See Fig. 9)
Raise mower to highest position to allow access to
blades.
•Remove blade bolt, Iockwasher and flat washer securing
blade.
•Install new or resharpened blade with trailing edge up
towards deck as shown.
IMPORTANT: TO ENSURE PROPER ASSEMBLY, CENTER
HOLE IN BLADE MUST ALIGN WITH STAR ON MANDREL
ASSEMBLY.
Reassemble blade bolt, lock washer and flat washer
in exact order as shown.
Tighten blade bolt securely (27-35 Ft. Lbs. torque).
IMPORTANT: BLADE BOLT tS GRADE 8 HEAT TREATED.
TRAILING
EDGE UP BLADE MANDREL
ASSEMBLY
FLAT WASHER
LOCK WASHER STAR
J
_""_BLADE BOLT (GRADE 8)*
*A GRADE 8 HEATTBEATED BOLT CAN BE
IDENTIFIED BY SIX LINES ON THE BOLT HEAD,
FIG. 9
TO SHARPEN BLADE (See Fig. 10)
NOTE: We do not recommend sharpening blade -but if
you do, be sure the blade is balanced.
Care should be taken to keep the blade balanced. An un-
balanced blade will cause excessive vibration and eventual
damage to mower and engine.
The blade can be sharpened with a file or on a grind-
ing wheel. Do not attempt to sharpen while on the
mower.
Tocheck blade balance, you will need a 5/8" diameter
steel bolt, pin, or a cone balancer. (When using a
cone balancer, follow the instructions supplied with
balancer.)
NOTE: Do not use a nail for balancing blade. The lobes of
the center hole may appear to be centered, but are not.
•Slide blade on to an unthreaded portion of the steel bolt
or pin and hold the bolt or pin parallel with the ground.
If blade is balanced, it should remain in a horizontal
position. If either end of the blade moves downward,
sharpen the heavy end until the blade is balanced.
/
/
CENTER HOLE /
5/8" BOLT
OR PIN
BLADE
15
FIG. 10
BATTERY
Your tractorhasa batterycharging systemwhichis sufficient
for normal use. However, periodic charging of the battery
with an automotive charger will extend its life.
•Keep battery and terminals clean.
•Keep battery bolts tight.
Keep small vent holes open.
•Recharge at 6-10 amperes for 1 hour.
NOTE: The original equipment battery on your tractor is
maintenance free. Do not attempt to open or remove caps
or covers. Adding or checking level of electrolyte is not
necessary.

MAINTENANCE
OIL DRAIN VALVE
TO CLEAN BATTERY AND TERMINALS
Corrosion and dirt on the battery and terminals can cause
the battery to "leak" power.
• Disconnect BLACK battery cable first then RED bat-
tery cable and remove battery from tractor.
Rinse the battery with plain water and dry.
Clean terminals and battery cable ends with wire brush
until bright.
Coat terminals with grease or petroleum jelly.
Reinstall battery (See "REPLACING BATFERY" in the
Service and Adjustment section of this manual).
V-BELTS
Check V-belts for deterioration and wear after 100 hou rsand
replace if necessary. The belts are not adjustable. Replace
belts if they begin to slip from wear.
TRANSAXLE COOLING
Keep transaxle free from build-up of dirt and chaff which
can restrict cooling.
ENGINE
LUBRICATION
Only use high quality detergent oil rated with API service
classification SF-SJ. Select the oil's SAE viscosity grade
according to your expected operating temperature.
SAE VISCOSITY GRADES
F -20 0 30 32 40 60 80 100
c -30 -20 -10 ;0 20 3o
TEMPERATURE RANGE ANTICIPATED BEFORE NEXT OIL CHANGE
FIG. 11
NOTE: Although multi-viscosity oils (5W30, 10W30 etc.)
improve starting in cold weather, these multi-viscosity oils
will result in increased oil consumption when used above
32°E Check your engine oil level more frequently to avoid
possible engine damage from running low on oil.
Change the oil after every 50 hours of operation or at least
once a year if the tractor is not used for 50 hours in one
year.
Check the crankcase oil level before starting the engine
and after each eight (8) hours of operation. Tighten oil fill
cap/dipstick securely each time you check the oil level.
TO CHANGE ENGINE OIL (See Figs. 11 and 12)
Determine temperature range expected before oil change.
All oil must meet API service classification SF-SJ.
Be sure tractor is on level surface.
Oil will drain more freely when warm.
Catch oil in a suitable container.
Remove oil fill cap/dipstick. Be careful not to allow dirt
to enter the engine when changing oil.
• Remove yellow cap from end of drain valve and install
the drain tube onto the fitting.
CLOSED
OR,,.
YELLOW CAP_ __ TUBE
FIG. 12
• Unlock drain valve by pushing inward and turning
counterclockwise.
To open, pull out on the drain valve.
• After oil has drained completely, close and lock the
drain valve by pushing inward and turning clockwise
until the pin is in the locked position as shown.
• Remove the drain tube and replace the cap onto to the
bottom fitting ofthe drain valve.
• Refill engine with oil through oil fill dipstick tube. Pour
slowly. Do not overfill. For approximate capacity see
"PRODUCT SPECIFICATIONS" section of this man-
ual.
Use gauge on oil fill cap/dipstick for checking level.
Be sure dipstick cap is tightened securely for accurate
reading. Keep oil at "FULU' line on dipstick.
CLEAN AIR SCREEN
Air screen must be kept free of dirt and chaff to prevent
engine damage from overheating. Clean with a wire brush
or compressed air to remove dirt and stubborn dried gum
fibers.
AIR FILTER (See Fig. 13)
Your engine will not run properly using a dirty air filter.
Remove cartridge every 25 hours of operation and tap to
clean. Replace paper cartridge once a year or after every
100 hours of operation, more often if used in very dusty,
dirty conditions.
•Remove knobs and cover.
Remove foam pre-cleaner element by sliding it off of
the paper cartridge.
NOTE: Do not attempt to clean or oil the paper cartridge.
Replace paper cartridge once a year or after every 100
hours of operation; more often if used in very dusty or dirty
conditions.
Wash foam pre-cleaner in liquid detergent and water.
Wrap foam pre-cleaner in cloth and squeeze dry.
Lightly coat foam pre-cleaner with clean engine oil.
Squeeze in towel to remove excess oil. Do not sat-
urate.
Install foam pre-cleaner over paper cartridge.
Reassemble cover and tighten knobs securely.
16

MAINTENANCE
COVER _MUFFLER
KNOBS _"-_._"'_ AIR Inspect and replace corroded muffler and spark arrester
_-__ CLEANER
.-, covER <ifequippedascou,dcreateafirehazardand ordam-
L | age.
' PAPER
,___AAP_TRIOGE SPARK PLUGS
Replace spark plugs at the beginning of each mowing sea-
FOAM son or after every 100 hours of use, whichever comes first.
_.__RE-CLEANER Spark plug type and gap setting is shown in "PRODUCT
SPECIFICATIONS" section of this manual.
AIR IN-LINE FUEL FILTER (See Fig. 15)
_ __AcI_ EANER The fuel filter should be replaced once each season. Iffuel
_l_.l_e J_ /BODY
__ filter becomes clogged, obstructing fuel flow to carburetor,
replacement is required.
With engine cool, remove filter and plug fuel line sec-
tions.
Place new fuel filter in position in fuel line with arrow
FIG. 13
ENGINE COOLING FINS (See Fig.14)
Remove any dust, dirt or oil from engine cooling fins to
prevent engine damage from overheating. Hood and
engine blower housing must be removed to clean engine
cooling fins.
•Remove hood (See"TO REMOVE HOOD AND GRILL
ASSEMBLY" in the Service and Adjustments section
of this manual).
•Removescrewssecuringaircleanerbodyandremove.
(Cover carburetor opening to prevent entry ofdirt).
•Remove oil fill dipstick and cover opening to prevent
entry of dirt.
•Remove screws from blower housing and lift housing
off engine.
•Use compressed air or stiff bristle brush to thoroughly
clean engine cooling fins.
•To reassemble, reverse above procedure.
•Be certain carburetor tube, breather tube and gaskets
are in place.
AIR CLEANER
SCREW_ TCOVER "--_/
. _ J. SCREWS
.oOS.NO ., j
GASKETS
CYUNDER
HEAD
COVER
TUBE
SPARK
PLUG
CARBURETOR
TUBE
pointing towards carburetor.
Be sure there are no fuel Fineleaks and clamps are
properly positioned.
Immediately wipe up any spilled gasoline.
CLAMP CLAMP
FUEL
FILTER
FIG. 15
CLEANING
•Clean engine, battery, seat, finish, etc. of all foreign
matter.
Keep finished surfaces and wheels free of all gasoline,
oil, etc.
• Protect painted surfaces with automotive type wax.
We do not recommend using a garden hose or pressure
washer to clean your tractor unless the engine and trans-
mission are covered to keep water out. Water in engine or
transmission will shorten the useful life of your tractor. Use
compressed air or a leaf blower to remove grass, leaves
and trash from tractor and mower.
FIG. 14 17

SERVICE AND ADJUSTMENTS
_ARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SERVICE OR ADJUST-
MENTS: r k II n
Depress clutch/b a e pedal fu y a d set parking brake.
• Place gearshift lever in neutral (N) position_
•Place attachment clutch in"DISENGAGED" position.
•Turn ignition key to"STOP" and remove key.
Make sure the blades and all moving parts have completely stopped.
Disconnect spark plug wire from spark plug and place wire where it cannot come in contact
with plug.
TRACTOR
TO REMOVE MOWER (See Fig. 16)
Mower will be easier to remove from the right side of trac-
tor. Place attachment clutch in "DISENGAGED" position.
• Move attachment lift lever forward to lower mower to
its lowest position.
• Roll belt off engine pulley.
• Remove small retainer spring, and remove clutch spring
off pulley bolt.
• Remove large retainer spring, slide collar off and push
housing guide out of bracket.
• Disconnect anti-swaybar from chassis bracket by re-
moving retainer spring.
• Disconnect suspension arms from rear deck brackets
by removing retainer springs.
• Disconnect front links from deck by removing retainer
springs.
• Raise lift lever to raise suspension arms. Stide mower
out from under tractor.
IMPORTANT: IF AN ATTACHMENTOTHERTHAN THE MOWER
DECK ISTO BE MOUNTED ON THE TRACTOR, REMOVE THE
FRONT LINKSAND HOOKTHE CLUTCH SPRING INTO SQUARE
HOLE IN FRAME.
TO INSTALL MOWER (See Fig. 16)
Raise attachment lift lever to its highest position.
• Slide mower under tractor with deflector shield to right
side of tractor.
• Lower lift lever to its lowest position.
Connect front links to mower deck and secure with
retainer springs..
• Connect suspension arms to rear deck brackets and
secure with retainer springs.
• Connect anti-swaybar to chassis bracket and secure
with retainer spring.
Push clutch cable housing guide into bracket, slide col-
lar onto guide and secure with large retainer spring.
Place flat washer and clutch spring on idler pulley bolt
and secure with small retainer spring.
Install belt onto engine pulley.
CLUTCH SPRING
CLUTCH SPRING
RETAINER
FRONT LINK
RETAINER SPRINGS
(BOTH SLOES)
HOUSING GUIDE RETAINER
SPRING BRACKET DEFLECTOR SHIELD
FIG. 16
18

SERVICE AND ADJUSTMENTS
TO LEVEL MOWER HOUSING
Adjust the mower while tractor is parked on level ground
or driveway. Make sure tires are properly inflated (See
"PRODUCT SPECIFICATIONS" section of this manual). If
tires are over or underinflated, you will not properly adjust
your mower.
SIDE-TO-SIDE ADJUSTMENT (See Figs. 17 and 18)
Raise mower to its highest position.
At the midpoint of both sides of mower, measure height
from bottom edge of mower to ground. Distance "A"
on both sides of mower should be the same or within
1/4" of each other.
• If adjustment is necessary, make adjustment on one
side of mower only.
• To raise one side of mower, tighten lift link adjustment
nut on that side.
• To lower one side of mower, loosen lift link adjustment
nut on that side.
NOTE: Each full turn of adjustment nut will change mower
height about 1/8".
• Recheck measurements after adjusting.
BOTTOM EDGE BoTroM EDGE
OF MOWER TO OF MOWER TO
FIG. 17
SUSPENSION ARM
LIFT LINK NUT
FIG. 18
FRONT-TO-BACK ADJUSTMENT (See Figs. 19 and 20)
IMPORTANT: DECK MUST BE LEVEL SIDE-TO-SIDE. IFTHE
FOLLOWING FRONT-TO-BACKADJUSTMENT IS NECESSARY,
RE SURE TO ADJUST BOTH FRONT LINKS EQUALLY SO
MOWER WILL STAY LEVEL SIDE-TO-SIDE.
To obtain the best cutting results, the mower housing
should be adjusted so that the front is approximately 1/8"
to 1/2" lower than the rear when the mower is in its high-
est position.
Check adjustment on right side oftractor. Measure distance
=D"directly in front and behind the mandrel at bottom edge
of mower housing as shown.
• Before making any necessary adjustments, check that
both front links are equal in length.
• If links are not equal in length, adjust one link to same
length as other link.
• To lower front of mower loosen nut "E" on both front
links an equal number of turns.
When distance "D" is 1/8" to 1/2" lower at front than
rear, tighten nuts "F" against trunnion on both front
links.
To raise front of mower, loosen nut"F" from trunnion on
both front links. Tighten nut "E" on both front links an
equal number of turns.The two front links must remain
equal in length.
When distance"D"is 1/8" to 1/2" lower at front than rear,
tighten nut "F" against trunnion on both front links.
Recheck side-to-side adjustment.
MANDREL
FIG. 19
BOTHFRONT LINKS MUSTBE EQUAL IN LENGTH
TRUNNION
NUT"E"
FRONT LINKS
FIG. 20
TO REPLACE MOWER BLADE DRIVE BELT
(See Fig. 21)
The mower blade drive belt may be replaced without tools.
Park the tractor on level surface. Engage parking brake.
BELT REMOVAL -
Remove mower from tractor (See "TO REMOVE
MOWER" in this section of this manual).
• Work belt oft both mandrel pulleys and idler pulleys.
• Pull belt away from mower.
BELT INSTALLATION -
Install new belt in reverse order of removal.
Make sure belt is in all pulley grooves and inside all
belt guides.
Install mower in reverse order of removal instruc-
tions.
19

SERVICE AND ADJUSTMENTS
IDLER PULLEYS WITH PARKINGBRAKE "ENGAGED"
MANDRELPULLEYS
FIG. 21
TO CHECK AND ADJUST BRAKE (See Fig.
22)
Yourtractor is equipped with an adjustable brake system
which is mounted on the right side of the transaxle.
If tractor requires more than five (5) feet to stop at highest
speed in highest gear on a level, dry concrete or paved
surface, then brake must be checked and adjusted.
TO CHECK BRAKE
• Park tractor on a level, dry concrete or paved surface,
depress clutch/brake pedal all the way down and en-
gage parking brake.
Place gear shift lever in neutral (N) position.
The rear wheels must lock and skid when you try to manually
push the tractor forward. Ifthe rear wheels rotate, the brake
needs to be adjusted or the pads need to be replaced.
TO ADJUST BRAKE
• Depress clutch/brake pedal all the way down and en-
gage parking brake.
• Measure distance between brake operating arm and
nut "A" on brake rod.
• If distance is other than 1-1/2", loosen jam nut and turn
nut "A" until distance becomes 1-1/2'L Retighten jam
nut against nut "A".
Road test tractor for proper stopping distance as stated
above. Readjust if necessary. If stopping distance is
still greater than five (5) feet in highest gear, further
maintenance is necessary. Replace brake pads or
contact a qualified service center.
NUT"A"
JAM NUT
_OPERATING ARM
FIG. 22
TO REPLACE MOTION DRIVE BELT
(See Fig. 23)
Park the tractor on level surface. Engage parking brake.
For assistance, there is a belt installation guide decal on
bottom side of left footrest.
BELT REMOVAL -
Remove mower (See "TO REMOVE MOWER" in this
section of manual).
NOTE: Observe entire motion drive belt and position of all
belt guides and keepers.
• Remove belt from stationary idler and clutching idler.
• Remove belt downward from around engine pulley.
Pull belt slack toward rear of tractor. Remove belt
upwards from transaxle pulley by deflecting belt keep-
ers.
Remove belt from center span keeper and pull belt
away from tractor.
BELT INSTALLATION -
• Carefully work new belt down between transaxle belt
keepers and onto the input pulley.
• Slide belt into the center span keeper.
Pull belt toward front of tractor and roll around the top
groove of engine pulley.
install belt through stationary idler and clutching
idler.
• Make sure belt is in all pulley grooves and inside all
belt guides and keepers.
• Install mower (See "TO iNSTALL MOWER" in this sec-
tion of manual).
20
