Instruction Sheet
Subject: Replacing the Infinite Switch, from old
Robertshaw to the new EGO.
Product: Garland S680 Sentry Series Electric Range
1 of 2
 DocumentNumber:GAR_IS_4603400 4/18
GARLAND
1177 KAMATO ROAD, MISSISSAUGA, ONTARIO, CANADA, L4W1X4
844-724-CARE
WWW.GARLAND-GROUP.COM
THESE INSTRUCTIONS SHOULD BE USED IN FULL
nWarning
Disconnect electrical supplies before opening panels for
servicing.
Risk of burns from high temperatures. Use extreme
caution to avoid coming in contact with hot surfaces.
Wear personal protective equipment.
nCaution
Maintenance and servicing work must be done by
authorized service personnel.
1. Ensure that all the parts are present in the kit, (as
shown in figure below).
CKG03185-2 INFINITE SWITCH 240 VOLT KIT
include:
Description Qty
1 INFINITE SWITCH 240VOLT - E.G.O. 1
23 CONDUCTOR LEVER CONNECTOR
WAGO 4
3 Red wires ¼” FEM - 3/8” strip 2
4 Black wires ¼”FEM - 3/8” strip 2
5INSTR SHEET INFINITE SWITCH
REPLACEMENT 1
6 SCREW-8-32 X 3/16”TRUSS COMB. 2
2. Turn the oven OFF
and un-plug its
power cord from the
power outlet.
3. Remove the knobs and place them in a safe
place.
4. Remove the front panel then remove the old
switch from the panel by removing the 2 screws
which secures it to the panel.
5. Disconnect the wires one at a time and mark
them as they are disconnected - before they will
be re-connected to the new switch.
6. Some applications may have ring terminals
connected to the old switch, as in the photo
above.

2 of 2
DocumentNumber:GAR_IS_4603400 4/18
Subject: Replacing the Infinite Switch, from old Robertshaw to the new EGO
NOTE: In order to connect the same wire to the new
switch, as per the above diagram of equivalence,
follow the steps below:
7. Cut the wire from the old switch.
8. On the piece of wire
remaining on the
harness, strip its end
3/8”.
9. Insert the stripped end of the wire into the
WAGO connector (corresponding the activation
lever lifted of the WAGO connector)
10. Lock the stripped
end of the wire into
the WAGO connector
by lowering its
corresponding
activation lever tab.
11. Insert and lock
one of the wires
provided in the kit
into the same WAGO
connector.
12. Connect the newly installed wire onto its proper
terminal of the new switch provided with the kit,
as per the schematic of equivalence
13. Repeat all the steps above to complete the
whole wiring transfer from the old switch to the
new.
14. Install and secure back the new infinite switch to
the panel and also re-install the panel.
15. Plug in and test the unit.
