Well REP-HDMI1.4/35M-WL User manual

HDMI 4K Repeater
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
USER MANUAL
Table of Contents
1.0 Introduction.........................................................................01
2.0 Feature.................................................................................01
3.0 Specification........................................................................02
4.0 Package Content.................................................................02
5.0 Panel Descriptio..................................................................03
6.0 Connection and Operation.................................................03

HDMI 4K Repeater
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
HDMI 4K Repeater
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this
manual for future reference.
1.0 Introduction
The HDMI Repeater enables to boost the HDMI signal via HDMI cable up to 35m at 4K@30Hz.
The special design allows the active circuitry to be powered by the HDMI cable itself that has
5-volts of power running through the HDMI cable. Plus the gold-plated connectors help improve
signal and reduce interference.
2.0 Feature
* Integrated signal amplifier for extending HDMI cables up to 35m at 4K@30Hz
* Self-powered active circuitry for fast, easy, elegant installation
* Support Full 3D and 4K@30Hz resolution
* Support 340MHz/3.4Gbps per channel (10.2Gbps all channels) bandwidth
* Support 12bit per channel (36bit all channels) deep color
*Support HDCP pass through
* Support Consumer Electronics Control function
* Support uncompressed audio such as LPCM7.1
* Support compressed audio such as DTS, Dolby Digital (including DTS-HD Master Audio and
Dolby TrueHD).
* Ultra slim design
Note: Dolby is a trademark of Dolby Laboratories.
1

HDMI 4K Repeater
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
3.0 Specification
Signal Input
HDMI Signal
HDMI Input /Output Connector
HDMI Type A 19 pin
Output Video
HDMI Signal
Vertical Frequency Range
50/60Hz
Video. Amplifier Bandwidth
3.4Gbps/340MHz
Interlaced Resolutions(50&60Hz)
480i,576i,1080i
Progressive Resolutions(50&60Hz)
480p,576p,720p,1080p, 4K@30Hz
Limited Warranty
1 Year Parts and Labor
Operating Temperature
0℃to 70℃
Operating Humidity
10% to 85% RH (no condensation)
Storage Temperature
-10℃to +80℃
Storage Humidity
5% to 90% RH (no condensation)
Power Supply
Micro USB Power Cable
Power Consumption(Max)
1.5W
Repeater Unit Cert
FCC,CE, RoHS
User Manual
English Version
Note:
1. Specification is subject to change without notice.
2. We recommend to add the Micro USB Power cable (included) for 4PETRTN when the HDMI
cable can’t draw enough power from the video source.
4.0 Package Content
1) Main Unit
2) Micro USB Power Cable
3) User Manual
2

HDMI 4K Repeater
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
5.0 Panel Description
6.0 Connection and Operation
1) Connect the output of the video source into the input of HDMI Repeater and connect the output
to the HDMI display via HDMI Cable. We recommend 4PETRTN locates close to the display.
2) Insert the Micro USB Power Cable.(Optional)
Attention: Insert / Extract cable gently.
6.1 Connection Diagram
3
