WELLSOUND AUDIO-VISUAL CO.,LTD W-200BT User manual

User Guide
BLUETOOTH SPEAKER
Model No.: W-200BT
Manufacturer: WELLSOUND AUDIO-VISUAL CO.,LTD
Address: 4/F, NO.3, 2nd Road,Yantian Bulong Industrial Park, Fenggang Town,
Dongguan City, China

W-200BT Technical Parameter:
1.Functions: Support AUX IN USB flash to play (MP3/WMA) Hand free Calling;
The USB slot support the output 5V/2Ato charge the other devices;
2.Input /Output function:
AUX 口: To connect 3.5 audio cable with external audio device .It support priority function.
DC5V 口: External DC 5V to charge the device
USB 口: Insert U disk can be read the audio signal
Insert USB cable can be charged the external devices
The product shall only be connected to a USB interface of version USB2.0
3.Button Functions:
Power ON/OFF: Press and hold
press and hold (5second) play /pause ;Quick click-skip to change the “ mode”
+ : In the “Aux-in/Bluetooth mode” Vol+ ,press and hold to next track ;Quick click-skip
adjust volume up
- : In the “Aux-in/Bluetooth mode” Vol-, Press and hold to previous; Quick click –skip to
adjust volume down；
Play/Pause button: In the “Aux-in/Bluetooth mode” Quick click (during play back 0-pause /play
audio
Phone Button: Press and hold –Unpair Bluetooth from your device
Quick click-answer or hang up calls
４．Operation:
Power ON/OFF:
Turn on :press and hold (5second) play /pause button until you hear the “music play mode”
Quick click-skip to change the “ mode”
Turn off : press and hold (5second) play /pause button then light off
Pairing Bluetooth
Please make sure that the “Bluetooth” setting of your handheld device(ie. phone /mp3 player0 is
turned on before attempting to pair your speaker with it ,Generally your handheld device will
display a list of Bluetooth devices that it’s able to connect to your speaker will display on the list
under “W-200BT”(note :if your device requires a password to connect ,enter “0000”)
Turn the speaker on and it will immediately go into pairing mode you will hear “The Bluetooth
device ready to pairing and become “discoverable” by other devices ,while it waits for a device to
connect to it ,the indicator light will quickly blink red and blue.

Once connected ,you will see the light will blink a slow ,steady blue.
After it is connected any audio that normally plays through your device will now play through
the speaker
Unpairing Bluetooth :
Method 1,
In the Bluetooth settings menu of your handheld device choose to disconnect from the speaker
Method 2
Press and hold the “Phone” button on the speaker until you hear the disconnect prompt;
ＵDisk play: Plug the Ｕdisk and short press 2 times “POWER” ;Once connected ,you will
hear a USB disk mode prompt ;
Line-in: In addition to connecting via Bluetooth ,you can connect directly using the included
Aux cable .Plug one end of the Aux cable into your device and the other end into the speaker,
short press 1 times “POWER” you will hear “Aux input mode” ,you will hear other device music.
Hands free calling (Built-in-microphone)
You can listen and talk through the speaker in place of your mobile phone.
Answer incoming calls –While connected to your mobile phone, incoming calls will ring
through the speaker, to answer a call press the “phone button. ”to hang up ,press the “phone
button”
Make outbound calls-While connected to your mobile phone ,dial the number you want to call
on our mobile phone and press call.
Charging:
Before using your speaker it is recommended that you fully charge it using the supplied USB
charging cable.
Initial charging will take up to 6 hours (It’s recommended not to charge past 12
hours).Additional charges should last 3-4 hours.
Charging is indicated by a solid red LED light on the front of the speaker (It illuminated
through the mesh speaker front)
Charging is complete when the red light is no longer illuminated.
If unused for long periods of time ,make sure to charge the speaker fully before using it again.
Charge through a computers USB port or USB wall charger (Charger must be =5V&≥1000mA
output)

INDICATIOR LIGHT :
Charging /Battery life
Charging :steady red
Charging full: Light off
Bluetooth
zBluetooth searching :fast red/blue blink
zBluetooth connected :Slow blue blink
Accessory:
1- W-200BT speaker
1- USB charge cable
2- AUX CABLE
1- Instruction book 5.Products Specification:
Speaker Dimensions 2x40mm 2.5”
Weight
Sensitivity(S/N) 80Db+/-2
Speaker Resistance 4Ω
Battery ：Li Polymer battery 3.7V/3000mAh
Frequency Response 150Hz-20KHz
RMS 2*3W
Direct Input Aux Input
USB Input Play USB Flash
Powermode Battery/USB
Output DC5V
CAUTION:RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE.DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
Extreme Temperature: +45℃max.

FCC Warning:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer
could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
