Wellue VisualBeat User manual

VisualBeat™
Heart Rate Monitor
User Manual

Contents
User Manual…….…............….........English 1-14
Benutzerhandbuch...........….........Deutsch 15-30
Manuale d'uso........…..…....…........Italiano 31-46
Manual de usuario…………...........Español 47-61
Manuel de l'utilisateur.......….........Français 62-78

1
User Manual
Contents
1. The Basics ............................................................. 2
1.1 Safety ............................................................. 2
2. Introduction ............................................................ 3
2.1 Overview ........................................................ 3
2.2 Unpacking ...................................................... 4
2.3 Symbols.......................................................... 4
3. Using the Monitor .................................................. 6
3.1 Before Use ..................................................... 6
3.2 Wearing the Monitor ....................................... 7
3.3 Recording the Heart Rate ............................... 9
3.4 Linking to ANT+ Fitness Equipment ............. 10
3.5 Factory Reset ............................................... 10
4. Maintenance ......................................................... 11
5. Troubleshooting ................................................... 12
6. Specifications ...................................................... 13

2
1. The Basics
Disclaimer
The heart rate monitor is not a medical device and
should not be used for any medical purpose or under
any medical conditions. It is intended only for general
wellness use.
Only use the heart rate monitor as described in this
instruction manual. Any other use is considered
improper and may result in damage to property or even
personal injury.
The manufacturer or vendor cannot be held liable for
damages incurred through improper or incorrect use.
1.1 Safety
Warnings and Cautionary Advice
⚫ Before using this device, please read this manual
carefully and fully understand the corresponding
warnings and risks.
⚫ This device is not intended to replace medical
diagnosis from a professional doctor.
⚫ This device is not suitable for people wearing a
pacemaker.
⚫ Do not swim or submerge the device in water or
other liquids.
⚫ Do not forcefully collide or crush the device. If the
casing is broken, cease using it.
⚫ Do not twist the device.
⚫ Keep this device away from children or pets.

3
⚫ This device should not be used on people with
sensitive skin or allergies.
⚫ This device cannot be placed in the following
environments: direct sunlight, high temperature,
high humidity or sources of open flame.
⚫ Users should inspect loosened electrodes, which
may affect performance or cause other problems.
2. Introduction
VisualBeat is a wearable heart rate monitor for
continuous measuring and recording of heart rates
while exercising.
The free ViHealth app allows you to review the data and
monitor the ECG in real-time.
2.1 Overview
1. Right side marking
The "R" mark should face the right side of the wearer
when wearing the monitor.
2. LED indicators
⚫ OFF: The device is inactive, or the battery has run

4
out.
⚫ Steady Green: Start working
⚫ Blinking Green: Same frequency as heartbeat.
⚫ Slow Blinking Green: Standby/Charging completed
⚫ Steady Orange: Charging.
⚫ Blinking Orange: Same frequency as heartbeat and
battery is low
⚫ Slow Blinking Orange: Low Battery
3. Charging contacts
Used to connect the charging cables.
4. Electrode buckles
Used to connect chest straps, disposable ECG
electrodes.
2.2 Unpacking
Main Unit;
Chest Strap;
Disposable ECG Electrodes;
Charging Cable;
User Manual;
2.3 Symbols
Symbol
Description
Manufacturer
Date of manufacture
SN
Serial number
Indicates a medical device that is not to be
disposed of as unsorted municipal waste.

5
Follow Instructions for Use.
Type CF Applied Part
MRI unsafe. Presents hazards in all MR
environments as device contains strongly
ferromagnetic materials.
IP22
Resistant to liquid ingress
CE marking
Authorized representative in the European
community
UKCA marking
Authorized Representative in the United
Kingdom
This product complies with the rules and
regulations of the Federal Communication
Commission.
Non-ionizing radiation
Our products and packaging can be
recycled, don't throw them away!
Find where to drop them off on the
www.quefairedemesdechets.fr site
(Only applicable for French market).

6
3. Using the Monitor
3.1 Before Use
Activation
The monitor must be activated by charging it before the
first use.
Note: The monitor will not work without being activated.
Charging
1. Connect the main unit with the power/data
cable, as shown in the picture.
2. Connect the other end of the cable to the
power source of 5V output/USB
connector, like a laptop or power adapter.
Note:
⚫Clean and dry the charging contacts after use if
you sweat while using the device. Wipe the
contacts with a damp cloth, then wipe them dry.
⚫If it fails to charge, clean the charging contacts and
wipe them dry.
Setting the Date and Time
Date and time on the monitor are automatically
synchronized each time it is connected to the ViHealth
app.
For connecting the app, scan the QR code in 3.1 to
check the quick guide for ViHealth.
Note: To record the data with the proper date and time,
we recommend connecting the monitor to the ViHealth
app before initial use.

7
Using the App
The ViHealth app allows you to transmit data after
wearing the monitor, and supports real-time monitoring
of your heart rate and ECG.
Scan the QR code below to download the ViHealth App.
For more software-related information, visit the website
https://assets.lepudev.com/manual/VisualBeat.pdf or
scan the QR code below for use instruction.
Standby Mode
When the monitor is not working, it will automatically
switch to standby mode.
Note: the monitor will switch to work mode when being
worn.
3.2 Wearing the Monitor
The monitor supports two wearing methods, and you
can choose which one suits you.

8
3.2.1 Wearing with Chest Strap
1. Attach the monitor to the chest strap.
2. Dampen both electrodes on the back of the chest
strap.
3. Position the monitor across the front of your chest,
just below your pectoral (chest) muscles.
Note: Ensure the "R" is facing to the right.
4. Adjust the length of the strap and tighten the strap
to ensure the device remains in place while
moving.
Note: Ensure the electrodes on the chest strap are
placed snugly on the skin.

9
electrodes.
2. Remove the packaging from the disposable ECG
electrodes.
3. Place the disposable ECG electrodes on the upper
chest in the position shown below.
Note:
⚫Ensure the "R" mark is facing up.
⚫If you sweat a lot, to avoiding the electrodes falling
off, we recommend you to use the strap
measurement.
3.3 Recording the Heart Rate
Once you are wearing the monitor appropriately, the
monitor switches to work mode and automatically starts
measuring and recording your heart rate.
3.2.2 Wearing with Electrodes
1. Attach the monitor to the disposable ECG

10
The monitor only stores heart rate data in the built-in
memory. The total recording time allotted to all records
is 30 hours. For a single record, the recording time
can be up to 24 hours.
If the total recording time exceeds 30 hours, the oldest
data will be overwritten by the most recent data.
After stopping measuring, you can review the resulting
data on the app. Scan the QR code in 3.1 to check the
quick guide for ViHealth..
3.4 Linking to ANT+ Fitness
Equipment
The monitor can be linked to fitness
equipment via ANT+ technology, so you can
view your heart rate on the ANT+ compatible equipment
console.
Search VisualBeat on your ANT+ compatible
equipment. It will send heart rate data to your
equipment.
3.5 Factory Reset
You can restore factory settings on the monitor in the
app.
Caution: all user-defined settings and measurement
data will be deleted from the monitor after factory
settings have been restored.

11
4. Maintenance
By following the directions below, you can maximize the
life span of your monitor.
⚫ Never attempt to disassemble or repair the monitor.
⚫ Protect the monitor from sharp objects, extreme
heat or prolonged exposure to direct sunlight.
⚫ Store the monitor in a clean, dry environment at
room temperature.
⚫ When putting on or taking off the monitor, do not
excessively twist, bend or stretch it.
⚫ To clean the monitor, wipe it with a soft, dry cloth,
or with a cloth that has been moistened in a weak
solution of water and a mild, neutral detergent.
⚫ Remove the monitor from the strap and rinse the
strap after every use.
⚫ Hand wash the strap every week in cold water with
a mild detergent.
⚫ Do not put the strap in a dryer or a washing
machine.
Note: Accumulation of sweat and salt on the strap
decreases the device’s ability to provide accurate data.

12
5. Troubleshooting
Problem
Possible Cause
Solution
The monitor
does not
connect
with the
app.
Your smart device is
not compatible.
Check whether your
smart device is
compatible.
The distance
between the monitor
and your smart
device is too great.
Keep your smart
device near the
monitor.
The monitor is
connected to another
device.
Check the other
smart devices
around you and
turn off their
Bluetooth settings.
The device
cannot
perform
normal
acquisitions.
The battery is low.
Charge the device
The equipment is
damaged.
Contact your local
retailer
Abnormal
heart rate
readings.
Poor contact
between the skin and
the monitor
electrodes.
Moisten the
electrode areas on
the monitor.
The chest strap is
loose.
Tighten the chest
strap.
ECG
waveform is
disordered,
and
significantly
cluttered.
Measurement
method is incorrect.
Refer to the manual
and ensure you're
wearing it properly.
Poor contact with
ECG electrodes.
Please clean the
ECG electrode
according to the
method described
in the manual.
The ECG
Hand or body may
Try to keep your

13
Problem
Possible Cause
Solution
waveform
drifts.
be moving.
body perfectly still.
When using
electrodes,
the signal is
poor or the
waveform is
disordered
The electrodes is
expired.
Make sure the
electrodes are
within the warranty
period.
The skin may be
dirty.
Clean the skin or
hair with water and
dry it.
The electrode hasn't
stick on the skin
closely.
Make sure the
electrode are well
stick to the skin.
6. Specifications
Dimensions
100×23×8.3 mm (main unit)
Weight
18g (main unit)
Wireless
Bluetooth 5.0, compatible with 4.0
Battery type
Rechargeable lithium-polymer battery
Battery run time
48 hours for typical use
Charge time
2-3 hours
Heart rate range
30 to 250 BPM
In-app Storage
Unlimited
In-app ECG
Recordings
Up to 30 minutes for each session
Heart rate
recording in device
up to 10 sessions / 30 hours, up to 24
hours for each session.

14
FCC Statement
FCC ID: 2ADXK-3613
This device complies with section 15 of the FCC Rules.
Its operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and
(2) this device must accept any interference received,
including interference that may cause undesired
operations.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to section 15 of the FCC Rules. These limits
are designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur due to a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference with one or more of the following
measures:
⚫ Reorient or relocate the receiving antenna.
⚫ Increase separation between the equipment and
receiver.
⚫ Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected.
⚫ Consult the retailer or an experienced radio/TV
technician for assistance.
The device has been evaluated to meet general RF
exposure requirements. The device can be used in
portable exposure conditions without restriction.

15
Benutzerhandbuch
Inhalt
1. Die Grundlagen....................................................... 16
1.1 Sicherheit....................................................... 16
2. Einweisung ............................................................. 17
2.1 Übersicht ....................................................... 18
2.2 Entpacken...................................................... 19
2.3 Symbole......................................................... 19
3. Die Verwendung des Monitors ................................ 21
3.1 Vor der Verwendung ...................................... 21
3.2 Tragen des Monitors ...................................... 23
3.3 Aufzeichnung der Herzfrequenz .................... 25
3.4 Verknüpfung mit ANT+ Fitnessgeräten .......... 25
3.5 Werksrückstellung ......................................... 26
4. Wartung .................................................................. 26
5. Fehlerbehebung...................................................... 27
6. Spezifikationen ....................................................... 29

16
1. Die Grundlagen
Haftungsausschluss
Beim Herzfrequenzmonitor handelt es sich nicht um ein
medizinisches Gerät und es sollte nicht für medizinische
Zwecke oder unter medizinischen Bedingungen
verwendet werden. Es ist nur für den allgemeinen
Wellness-Gebrauch bestimmt.
Verwenden Sie den Herzfrequenzmonitor nur wie in
dieser Gebrauchsanweisung beschrieben. Jegliche
anderweitige Verwendung gilt als unsachgemäß und
kann Sach- oder sogar Personenschäden verursachen.
Der Hersteller oder Verkäufer kann nicht für Schäden
haftbar gemacht werden, die aufgrund der
unsachgemäßen oder fehlerhaften Verwendung
entstehen.
1.1 Sicherheit
Warnungen und Warnhinweise
⚫ Bevor Sie dieses Gerät verwenden, lesen Sie bitte
dieses Handbuch sorgfältig durch und machen Sie
sich mit den entsprechenden Warnhinweisen und
Risiken vertraut.
⚫ Dieses Gerät ist nicht dazu bestimmt, die
medizinische Diagnose eines professionellen
Arztes zu ersetzen.
⚫ Dieses Gerät ist nicht geeignet für Personen, die
einen Herzschrittmacher tragen.

17
⚫ Tauchen Sie das Gerät nicht in Wasser oder
anderen Flüssigkeiten.
⚫ Lassen Sie das Gerät nicht gewaltsam kollidieren
oder zerdrücken. Stellen Sie die Verwendung ein,
falls das Gehäuse beschädigt ist.
⚫ Verdrehen Sie das Gerät nicht.
⚫ Halten Sie dieses Gerät von Kindern oder
Haustieren fern.
⚫ Dieses Gerät sollte nicht an Personen mit
empfindlicher Haut oder Allergien verwendet
werden.
⚫ Dieses Gerät darf nicht in den folgenden
Umgebungen platziert werden: direkte
Sonneneinstrahlung, hohe Temperatur, hohe
Luftfeuchtigkeit oder Quellen offener Flammen.
⚫ Die Anwender sollten das Gerät auf lose
Elektroden überprüfen, die die Leistung
beeinträchtigen oder andere Probleme verursachen
können.
2. Einweisung
VisualBeat ist ein tragbarer Herzfrequenzmonitor zur
kontinuierlichen Messung und Aufzeichnung von
Herzfrequenzen während des Trainings.
Die kostenlose ViHealth App ermöglicht es Ihnen, die
Daten einzusehen und das EKG in Echtzeit zu
überwachen.

18
2.1 Übersicht
1. Rechte Seitenmarkierung
Die „R“-Markierung sollte beim Tragen des Monitors
zur rechten Seite des Trägers ausgerichtet sein.
2. LED-Anzeigen
⚫ AUS: Das Gerät ist inaktiv, oder die Batterie ist leer.
⚫ Ständig grün: Betriebsbereit
⚫ Grün blinkend: Die gleiche Frequenz wie der
Herzschlag.
⚫ Langsam grün blinkend: Standby/Aufladen beendet
⚫ Ständiges Orange: Wird aufgeladen.
⚫ Orange-Blinkend: Die gleiche Frequenz wie der
Herzschlag und die Batterie ist schwach
⚫ Langsam Orange-Blinkend: Batterie schwach
3. Kontakte zum Aufladen
Dient zum Anschluss der Ladekabel.
4. Elektroden-Schnallen
Dient zum Anschluss von Brustgurten, Einweg-EKG-
Elektroden.
