Wen 4225 User manual

Model # 4225
6-Ton Electric Log
Splitter
bit.ly/WENvideo
Your new tool has been engineered and manufactured to WEN’s highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
[email protected]
WENPRODUCTS.COM
(M-F 8AM-5PM CST)

TABLE OF CONTENTS
2
3
4
5
6
9
10
11
12
15
18
21
Safety Information
Electrical Information
Know Your Log Splitter
Package Contents
Assembly
Maintenance and Troubleshooting
Exploded View and Parts List
Product Specifications
Model Number:
Splitting Force:
Cycle Time:
Motor:
Motor Speed:
Log Capacity:
Hydraulic Pressure:
Hydraulic Fluid:
Hydraulic Tank Capacity:
Cylinder Stroke:
Tire Size:
Dimensions (LxWxH):
Weight:
56206
6 Tons
25 Seconds
120 V AC, 60 Hz, 15 A, 2 HP, 1500 W
3400 RPM
10 inch diameter
20.5 inch length
3000psi
AW32 Hydraulic Fluid (for operation at
or above 40 degrees Farenheit)
Dexron Automatic Transmission Fluid
(for operation below 40 degrees Faren-
heit)
2.8 Quarts
18 Inch
6 Inch
38-1/4x11x18 Inches
99 Pounds
2
Operation
Product Specifications
General Safety Rules
Log Splitter Safety
Warranty

SAFETY INFORMATION
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or
install the product. These safety instructions are not meant to cover every possible condition
that could occur. If you have any questions regarding the product please call customer service
at 1-800-232-1195, 8:00 a.m.-5:00 p.m., CST, Monday-Friday.
Safety Signals
The purpose of safety signal statements and symbols is to attract your attention to possible
danger. Read them carefully to understand and practice proper accident prevention.
DANGER Signals an EXTREME hazard.
Failure to obey a safety DANGER signal WILL result in serious injury or death to yourself
or to others. Always follow the safety precautions to reduce the risk of fire, electric shock, and
personal injury.
WARNING Signals a serious hazard.
Failure to obey a safety WARNING signal CAN result in serious injury to yourself and to oth-
ers. Always follow the safety precautions to reduce the risk of fire, electric shock, and personal
injury.
CAUTION Signals a moderate hazard.
Failure to obey a safety CAUTION signal MAY result in property damage or personal injury
to yourself or to others. Always follow the safety precautions to reduce the risk of fire, electric
shock, and personal injury.
NOTE: Signals additional important general information.

4
GENERAL SAFETY RULES
Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE
SAFETY INSTRUCTIONS.
WARNING: To avoid mistakes and serious injury, do not plug in your tool until the following
steps have been read and understood.
1. READ and become familiar with this entire instruction manual. LEARN the tool’s applications, limitations,
and possible hazards.
2. AVOID DANGEROUS CONDITIONS. Do not use power tools in wet or damp areas or expose them to
rain. Keep work areas well lit.
3. DO NOT use power tools in the presence of flammable liquids or gases.
4. ALWAYS keep your work area clean, uncluttered, and well lit. DO NOT work on floor surfaces that are
slippery with sawdust or wax.
5. KEEP BYSTANDERS AT A SAFE DISTANCE from the work area, especially when the tool is operating.
NEVER allow children or pets near the tool.
6. DO NOT FORCE THE TOOL to do a job for which it was not designed.
7. DRESS FOR SAFETY. Do not wear loose clothing, gloves, neckties, or jewelry (rings, watches, etc.) when
operating the tool. Inappropriate clothing and items can get caught in moving parts and draw you in. ALWAYS
wear non-slip footwear and tie back long hair.
8. WEAR A FACE MASK OR DUST MASK to fight the dust produced by sawing operations.
WARNING: Dust generated from certain materials can be hazardous to your health. Always
operate the tool in a well-ventilated area and provide for proper dust removal. Use dust collection
systems whenever possible.
9. ALWAYS remove the power cord plug from the electrical outlet when making adjustments, changing parts,
cleaning, or working on the tool.
10. KEEP GUARDS IN PLACE AND IN WORKING ORDER.
11. AVOID ACCIDENTAL START-UPS. Make sure the power switch is in the OFF position before plugging
in the power cord.
12. REMOVE ADJUSTMENT TOOLS. Always make sure all adjustment tools are removed from the saw
before turning it on.
13. NEVER LEAVE A RUNNING TOOL UNATTENDED. Turn the power switch to OFF. Do not leave
the tool until it has come to a complete stop.

5
14. NEVER STAND ON A TOOL. Serious injury could result if the tool tips or is accidentally hit. DO NOT store
anything above or near the tool.
15. DO NOT OVERREACH. Keep proper footing and balance at all times. Wear oil-resistant rubber-soled foot-
wear. Keep the floor clear of oil, scrap, and other debris.
16. MAINTAIN TOOLS PROPERLY. ALWAYS keep tools clean and in good working order. Follow instruc-
tions for lubricating and changing accessories.
17. CHECK FOR DAMAGED PARTS. Check for alignment of moving parts, jamming, breakage, improper
mounting, or any other conditions that may affect the tool’s operation. Any part that is damaged should be properly
repaired or replaced before use.
18. MAKE THE WORKSHOP CHILDPROOF. Use padlocks and master switches and ALWAYS remove start-
er keys.
19. DO NOT operate the tool if you are under the influence of drugs, alcohol, or medication that may affect your
ability to properly use the tool.
20. USE SAFETY GOGGLES AT ALL TIMES that comply with ANSI Z87.1. Normal safety glasses only have
impact resistant lenses and are not designed for safety. Wear a face or dust mask when working in a dusty environ-
ment. Use ear protection such as plugs or muffs during extended periods of operation.
GENERAL SAFETY RULES
WARNING: Do not operate this tool until it is completely assembled and installed according to
the instructions.
1. IF YOU ARE NOT thoroughly familiar with the operation of the log splitter, obtain instruction from a qualified
person.
2. MAKE SURE wiring codes and recommended electrical connections are followed. When servicing, use only
identical replacement parts. Disconnect Log Splitter from its power source before making adjustments or repairs.
3. Place the Log Splitter on a stable, flat, and level work surface where there is plenty of room for handling logs.
4. INSPECT THE LOG SPLITTER before each use. Keep guards in place and in working order. Replace dam-
aged, missing, or failed parts beofore using.
5. Do not alter the Log Splitter. Altering the tool and exceeding its design capabilities or capacities could result in
serious injury or fatality and will void the warranty.
6. MAKE SURE THE EXTENSION CORD is no longer than 25 ft. if 14 gauge. Ensure that the power cord
is rated for outdoor use. Ground the log splitter and avoid contact with grounded surfaces during operation (See
“Electrical Information” for details).
LOG SPLITTER SAFETY

6
LOG SPLITTER SAFETY
7. MAKE all adjustments with the switch in the “OFF” position and the Log Splitter disconnected from the power
source.
8. Never use the log splitter for any purpose other than splitting wood. Any other use can result in injury. Use ex-
treme caution at all times.
9. PREPARE LOGS FOR SPLITTING. Make sure the log ends are cut square and cut off any branches flush with
the trunk.
10. INSPECT EACH LOG BEFORE SPLITTING. Make sure there are no nails or foreign objects in the log.
11. Only a single operator should load and operate the log splitter. Keep all others, including children and pets, a
minimum of 20 feet away from the work area.
12. NEVER TRY TO SPLIT LOGS larger than the rated capacity of the tool. Attempting to do so could result in
personal injury and damage to the tool.
13. Split only one log at a time. Do not attempt to split two logs on top of each other.
14. DO NOT put your hands or feet in between the log and the splitting wedge or between the log and the push
rod while the tool is in operation.
WARNING: KEEP HANDS AWAY FROM SPLITS AND CRACKS WHICH
OPEN IN THE LOG. THEY MAY CLOSE SUDDENLY AND CRUSH OR AMPUTATE
YOUR HANDS.
15. Do not attempt to load a log while the push rod is in motion. When loading, place your hands on the sides of
the log, not on the ends.
16. WAIT FOR THE PUSH ROD TO STOP MOVING before loading another log onto the log splitter. Do not
try to remove a split log until the entire splitting cycle is completed.
17. Use only your hands to operate the control lever. Never use your foot, knee, rope, or extension device.
18. Never use your hands to remove a jammed log. If a jam should occur, release the ON/OFF push button. Follow
the instructions in this manual for removing a jammed log.
19. Stack logs as you work. This will provide a safer, less cluttered work area.
ELECTRICAL INFORMATION
WARNING: To avoid electrical hazards, fire hazards, and damage to the tool, use proper circuit pro-
tection. The Log Splitter is wired at the factory for 120 V operation. Connect to a 120 V, 15-A circuit
and use a 15-A time delayed fuse or circuit breaker. To avoid shock or fire, immediately replace the
power cord if it is worn, cut, or damaged in any way.

GROUNDING INSTRUCTIONS
IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding
provides the path of least resistance for an electric current and reduces the risk
of electric shock. This tool is equipped with an electric cord that has an equip-
ment grounding conductor and a grounding plug. The plug MUST be plugged
into a matching outlet that is properly installed and grounded in accordance
with ALL local codes and ordinances.
This Log Splitter has a 3-prong plug that is intended for use on a circuit that has
a receptacle like the one pictured in Figure A.
DO NOT MODIFY THE PLUG PROVIDED. If it will not fit the outlet, have the proper outlet installed by a
licensed electrician.
IMPROPER CONNECTION of the equipment grounding conductor can result in electric shock. The conduc-
tor with the green insulation (with or without yellow stripes) is the equipment grounding conductor. If repair or
replacement of the electric cord or plug is necessary, DO NOT connect the equipment grounding conductor to a
live terminal.
WARNING: To avoid injury, use only identical replacement parts when servicing the log splitter.
WARNING: Do not touch the metal blades on the power cord plug when removing or installing the
plug into an electrical outlet or extension cord.
WARNING: To avoid electrocution, do not use in wet or damp areas or expose to rain.
CAUTION: In all cases, make certain the receptacle in question is properly grounded. If you are not
sure, have a certified electrician check the receptacle.
GUIDELINES FOR USING EXTENSION CORDS
WARNING: Improper use of extension cords may cause inefficient operation, which can result in
overheating. Use an extension cord rated for outdoor operation.
Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy
enough to carry the current your product will draw. An undersized cord will cause a drop in line voltage resulting in
loss of power and overheating. The table on the next page shows the correct size to be used according to cord length
and nameplate ampere rating. When in doubt, use a heavier cord. The smaller the gauge number, the heavier the
cord.
7
ELECTRICAL INFORMATION
FIGURE A

Ampere Rating Total Length of Cord in feet
More Than Not More Than 25 50 100 150
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not Recommended
Protect your extension cords from sharp objects, excessive heat and damp/wet areas.
Use a separate electrical circuit for your tools. This circuit must not be less than a #12 wire and should be protected
with a 15 A time-delayed fuse. Before connecting the motor to the power line, make sure the switch is in the OFF
position and the electric current is rated the same as the current stamped on the motor nameplate. Running at a
lower voltage will damage the motor.
WARNING: The extension cord and receptacle must be grounded when in use to protect the opera-
tor from electric shock.

9
KNOW YOUR LOG SPLITTER
8
7
9
10
11
5
12
6
1
2
3
4
COMPONENTS
1 Motor
2 Handle
3 Fluid Drain/Dipstick
4 Bleed Screw
5 Wedge
6 Work Table Guards
7 Hydraulic Control Lever
8 Wheel
9 Circuit Breaker
10 ON/OFF Power Switch
11 Ram
12 Beam

1010
ASSEMBLY
UNPACKING
This Log Splitter requires the wheel assembly to be attached to the base. See wheel assembly directions below.
NOTE: Do not discard box or any packing material until all parts are examined and accounted for.
This Log Splitter has been filled with AW32 oil during the manufacturing process. Refer to the photo below and
the parts list should it be necessary to disassemble the unit for repair or replacement of parts. Inspect the unit for
shipping damage.
IF ANY PART OF THE LOG SPLITTER IS MISSING OR DAMAGED, DO NOT PLUG IN UNTIL THE
DAMAGED PART IS REPAIRED OR REPLACED. PLEASE CALL 1-800-232-1195 FOR ASSISTANCE.
Item List:
1 Log Splitter
2 Wheels
1 Wheel Shaft
1 Cotter Pin
2 Washers and 2 Nuts

11
ASSEMBLY
Cotter
Pin
Washer
Nut
WHEEL ASSEMBLY
1. Insert the wheel shaft into the motor end
of the log splitter and secure with the cotter
pin.
2. Secure the wheels to the wheel shaft using
the nut and washer on the outside end of
both wheels.

12
OPERATION
WARNING: Read and thoroughly understand all instructions and safety information before op-
erating this log splitter. Failure to do so may cause serious injury or death. Do not allow anyone to
operate this log splitter who has not read this manual. As with all power equipment, a log splitter can
be dangerous if assembled or used improperly. Do not operate this log splitter if you have doubts or questions
concerning safe operation. Call our customer service department at 1-800-232-1195 to address these concerns.
WARNING: Always wear safety glasses, safety gloves, safety shoes and suitable work clothing when
operating this log splitter. Do not wear jewelry, neckties or other loose clothing which could get
caught in moving parts.
WARNING: Keep hands and feet clear of the ram and wedge at all times.
WARNING: Do not start or operate this machine in the presence of flammable liquids or gases.
Before operating, select a suitable work area and check the level of hydraulic fluid.
A safe work area will contain a flat surface on which to place the log splitter, as well as ample room to stack both
split and unsplit logs. Make sure there is a safe electrical connection no more than 25 feet from the workspace.
WARNING: Lifting the log splitter is a two person operation. Once raised, make sure the log split-
ter is stable before performing any maintenance. 2
To check the level of hydraulic fluid:
1. Lift up on the handle of the Log Splitter. Make certain the Log Splitter
is stable and will not fall.
2. Loosen the fluid drain knob (1).
3. Pull out the bolt with attached dipstick and wipe the dipstick.
4. Put the dipstick back in the tank and pull it out again.
5. Check the fluid level on the dipstick. It should be between the two
notches on the end of the dipstick (2).
6. Add fluid if needed. Replace dipstick and tighten the fluid drain knob.
Remember to use AW32 fluid for operation at temperatures above 40 degrees Farenheit, and Dexron® automat-
ic transmission fluid for operation below 40 degrees Farenheit. The Log Splitter is pre-loaded with AW32 fluid
during the manufacturing process.
1

13
OPERATION
1
WARNING: Always loosen the bleed
screw prior to operation. This will remove
any air trapped in the hydraulic system.
Failure to release air from the hydraulic system may
damage the hydraulic seals, permanently damaging the
Log Splitter.
To loosen the bleed screw:
1. Turn the bleed screw (1) counterclockwise one or
two turns to allow air to be released from the hydraulic
system.
NOTE: While the Log Splitter is in use, there should
be a detectable flow of air through the bleed screw.
2. Close the bleed screw after operation.
NOTE: Check the bleed screw and make sure it is
closed before and during transporting the log splitter to
and from the jobsite and storage area. Hydraulic fluid
may leak through the bleed screw opening if the bleed
screw is not fully tightened.
WARNING: Never try to split logs larger than the rated capacity of the tool. Attempting to do so
could result in personal injury and damage to the tool.
To place and split a log on the Log Splitter:
1. Make sure the log is prepared and suitable for use with this machine. There should be no nails or foreign ob-
jects in the log, the ends should be cut square, any branches should be cut flush with the trunk, and the log should
be no longer than 21 inches with a diameter less than or equal to 10 inches.
2. Ensure the equipment is in safe working condition. Operate the unit without loading to make sure it is working
normally. Check all nuts, bolts and hydraulic fittings are tight. Check the switch, power cable and plug for damage
to avoid electric shock.
3. Plug in the power cable. NEVER use an extension cord longer than 25 feet. Minimum cord gauge must be 16.
The power supply for this log splitter must have a protection device (circuit breaker) for over or under voltage.
4. Place a log on the beam against the ram. Make sure that the log is securely on the beam and up against the ram.
Logs should be cut with square ends and to a maximum length of 20.5 inch in advance. Always use extra care
when splitting logs with unsquare ends.

OPERATION
14
MAINTENANCE
5. Loosen the bleed screw one or two turns.
6. Two controls must be activated to operate the log splitter. The hy-
draulic control lever (1) and the ON/OFF push button (2) must be held
during the splitting process. If either control is released, the log splitter
will stop operating.
7. Depress and hold the ON/OFF push button (2) with your right hand.
Allow enough time for the motor to cycle up to speed.
8. Push down on the hydraulic control lever (1).
9. Release the ON/OFF button and the control lever when the log is
split. The push rod will then retract.
WARNING: If the log does not begin to split after 5
seconds of operation, release both controls. The motor or
hydraulic fluid may overheat and damage the machine.
WARNING: Do not attempt to remove a jammed log with your hands or try to knock it off the
worktable. Doing so may cause injury and may also damage the splitting wedge. Knock off the log
with a hammer.
WARNING: When finished splitting the logs, unplug the power cord and lock the bleed screw.
WARNING: Disconnect the Log Splitter from the power source before performing any mainte-
nance.
Check the hydraulic fluid level at the beginning of each season and if the fluid level is low.
To check the hydraulic fluid level:
1. Lift up on the handle of the Log Splitter. Make certain the Log Splitter is stable and will not fall.
2. Loosen the fluid drain knob (1).
3. Pull out the bolt with attached dipstick and wipe the dipstick.
4. Put the dipstick back in the tank and pull it out again.
5. Check the fluid level on the dipstick. It should be between the two notches on the end of the dipstick (2).
12

15
6. Add fluid if needed. Replace dipstick and tighten the fluid drain knob.
Remember to use AW32 fluid for operation at temperatures above 40 degrees Faren-
heit, and Dexron® automatic transmission fluid for operation below 40
degrees Farenheit. The Log Splitter is pre-loaded with AW32 fluid dur-
ing the manufacturing process. Do not mix AW32 and Dexron® fluid.
WARNING: Lifting the Log Splitter is a two person op-
eration. Once raised, make sure the Log Splitter is stable
before performing any maintenance.
To replace the hydraulic fluid:
1. Place a one gallon (or larger) pan (3) under the splitting wedge end of
the log splitter.
2. Loosen the fluid drain knob (1) and remove it.
3. Raise motor end of the log splitter to allow the fluid to drain into the pan. Lower motor end of the splitter when
it is empty. Dispose of the collected fluid properly.
4. Raise the splitting edge end and make sure it is secure.
5. Pour approximately 0.85 Gallon of approved hydraulic fluid (AW32 hydraulic fluid for operation over 40°F or
Dexron automatic transmission fluid for operation below 40°F) into the tank.
6. Check the fluid level with the dipstick. Add more fluid if needed.
7. Replace the fluid drain knob (1) and tighten securely. Lower the Log Split-
ter.
Sometimes after prolonged use, the splitting wedge may need to be sharp-
ened to ensure optimal operation. Use a fine-toothed file or rasp to remove
burrs or refresh crushed areas.
12
31
MAINTENANCE

16
TROUBLESHOOTING
Problem
Cause
Action
Extension cord is too long or
gauge is too low
Check extension cord to ensure the gauge
of the cord is 12or 14 AWG and that the
cord length does not exceed 25 ft.
Incorrect positioning of the log. Make sure the log is properly positioned
on the worktable (See page 13, "Place a
log on the log splitter ")
The size or hardness, or density
of the log may exceed the
capacity of the splitter.
Reduce the log size before placing it on
the splitter.
Splitting wedge cutting edge is
blunt or dull
Sharpen the wedge (See page 16,
"Sharpen the splitting wedge")
The bleed screw was not
loosened and air is trapped in the
hydraulic tank
Loosen the bleed screw one or two turns
The hydraulic fluid is low and
may need to be replenished
Check the hydraulic fluid level and refill
if needed
Logs will not
split
The maximum pressure limiting
adjustment setting has changed
Contact a trained service Technician at 1-
800-232-1195
The bleed screw may not have
been tightened before
transporting the splitter
Tighten the bleed screw
The bleed screw may not have
been loosened before operation
and air is trapped in the
hydraulic system
Loosen the bleed screw one or two turns.
The fluid drain knob may be
loose.
Tighten the knob
Hydraulic fluid
leaks
The hydraulic control valve
assembly and/or seals may be
worn.
Contact a trained service Technician at 1-
800-232-1195
Push rod The hydraulic fluid level may be Check the fluid level and refill, if needed.

17
EXPLODED VIEW AND PARTS LIST

18
EXPLODED VIEW AND PARTS LIST
Item Stock # Description Item Stock # Description
1 56206-001 Motor 31 56206-031 Bracket
2 56206-002 Nut M6 32 56206-032 Bolt
3 56206-003 Rubber foot 33 56206-033 Rubber sleeve
4 56206-004 Right rubber foot 34 56206-034 Hydraulic control lever
5 56206-005 bolt M6×12 35 56206-035 Nut M10
6 56206-006 Left rubber foot 36 56206-036 Nut M10
7 56206-007 Nut M8 37 56206-037 Spring washer 10
8 56206-008 Washer 38 56206-038 Oil seal 9.5×2.65G
9 56206-009 Bearing bush 39 56206-039 Plastic cover
10 56206-010 Claboard 40 56206-040 BoltM6×20
11 56206-011 Steel ring10 41 56206-041 Hexagon nut
12 56206-012 Gear 42 56206-042 Bush for shaft
13 56206-013 Gear shaft 43 56206-043 Oil seal 4.87×1.8G
14 56206-014 Steel ball 2.5 44 56206-044 Shaft
15 56206-015 Round pin 2.5×4 45 56206-045 Adjustment spring
16 56206-016 Bolt M8×30 46 56206-046 Cone valve
17 56206-017 Spring washer 8 47 56206-047 Oil valve
18 56206-018 Flat washer 8 48 56206-048 Screw
19 56206-019 Bolt M8×55 49 56206-049 Oil seal 11.8×2.2G
20 56206-020 Shaft 50 56206-050 Hexagon bolt
21 56206-021 Cover 51 56206-051 Bolt
22 56206-022 Oil seal 10×2.65G 52 56206-052 Washer16×t1
23 56206-023 Bolt M6×12 53 56206-053 Oil seal 14×1.8G
24 56206-024 Spring washer 6 54 56206-054 spring
25 56206-025 Flat washer 6 55 56206-055 Front cover
26 56206-026 Locking nut M10 56 56206-056 Control valve
27 56206-027 Flat washer 10 57 56206-057 Oil seal 11.2×1.8G
28 56206-028 Wheel 58 56206-058 Journey valve
29 56206-029 Wheel shaft 59 56206-059 Oil seal 5.6×1.8G
30 56206-030 Pin3.2×20 60 56206-060 Spring

19
EXPLODED VIEW AND PARTS LIST
Item Stock # Description Item Stock # Description
61 56206-061 Washer 6 79 56206-079 Bolt M8×50
62 56206-062 Washer 80 56206-080 Cylinder
63 56206-063 Oil seal 48.7×3.55G 81 56206-081 Ring58×52.5×4
64 56206-064 Nut M6 82 56206-082 Oil seal43.7×3.55G
65 56206-065 Front bracket 83 56206-083 Piston
66 56206-066 Upper pad 84 56206-084 stud
67 56206-067 Push rod 85 56206-085 stud
68 56206-068 Tine plate 86 56206-086 Spring
69 56206-069 Bolt M4×6 87 56206-087 Rear cover
70 56206-070 Down pad 88 56206-088 Oil seal 3.6×1.8G
71 56206-071 Nut M14 89 56206-089 Bleed screw
72 56206-072 Rubber plug 90 56206-090 Oil seal30×2.65G
73 56206-073 Work table guard 91 56206-091 Washer FC30×38×5
74 56206-074 Back bracket 92 56206-092 Dipstick
75 56206-075 Beam 93 56206-093 Oil seal 11.8×2.65G
76 56206-076 Step bolt M6×50 94 56206-094 Knob
77 56206-077 Work table guard 95 56206-095 Piston rod
78 56206-078 Rubber handle 96 56206-096 lock nut M14

WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with
this commitment and our dedication to quality.
LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE
GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con-
sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of
purchase. Ninety days for all WEN products, if the tool is used for professional use.
SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Limited Warranty and, to
the extent permitted by law, any warranty or condition implied by law, shall be the repair or replacement of parts,
without charge, which are defective in material or workmanship and which have not been misused, carelessly
handled, or misrepaired by persons other than Seller or Authorized Service Center. To make a claim under this
Limited Warranty, you must make sure to keep a copy of your proof of purchase that clearly defines the Date of
Purchase (month and year) and the Place of Purchase. Place of purchase must be a direct vendor of Great Lakes
Technologies, LLC. Third party vendors such as garage sales, pawn shops, resale shops, or any other secondhand
merchant void the warranty included with this product. Contact [email protected] or 1-800-232-
1195 to make arrangements for repairs and transportation.
When returning a product for warranty service, the shipping charges must be prepaid by the purchaser. The prod-
uct must be shipped in its original container (or an equivalent), properly packed to withstand the hazards of ship-
ment. The product must be fully insured with a copy of the warranty card and/or the proof of purchase enclosed.
There must also be a description of the problem in order to help our repairs department diagnose and fix the
issue. Repairs will be made and the product will be returned and shipped back to the purchaser at no charge.
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY ITEMS THAT WEAR OUT FROM
REGULAR USAGE OVER TIME INCLUDING BELTS, BRUSHES, BLADES, ETC.
ANY IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO TWO (2) YEARS FROM
DATE OF PURCHASE. SOME STATES IN THE U.S., SOME CANADIAN PROVINCES DO NOT AL-
LOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITA-
TION MAY NOT APPLY TO YOU.
IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAM-
AGES (INCLUDING BUT NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS) ARISING FROM
THE SALE OR USE OF THIS PRODUCT. SOME STATES IN THE U.S. AND SOME CANADIAN
PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CON-
SEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO
YOU.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE
OTHER RIGHTS WHICH VARY FROM STATE TO STATE IN THE U.S., PROVINCE TO PROVINCE
IN CANADA AND FROM COUNTRY TO COUNTRY.
THIS LIMITED WARRANTY APPLIES ONLY TO PORTABLE ELECTRIC TOOLS, BENCH POW-
ER TOOLS, OUTDOOR POWER EQUIPMENT AND PNEUMATIC TOOLS SOLD WITHIN THE
UNITED STATES OF AMERICA, CANADA AND THE COMMONWEALTH OF PUERTO RICO. FOR
WARRANTY COVERAGE WITHIN OTHER COUNTRIES, CONTACT THE WEN CUSTOMER SUP-
PORT LINE.
LIMITED TWO YEAR WARRANTY
20
