Wen DW5084 User manual

DUAL-HEAD
DRYWALL SANDER
Instruction Manual
IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use
your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
TECHSUPPOR[email protected]1-800-232-1195 (M-F 8AM-5PM CST)
For replacement parts and the most up-to-date instruction manuals, visit WENPRODUCTS.COM
MODEL DW5084

CONTENTS
WELCOME 3
Introduction ..................................................................................................... 3
Specifications................................................................................................... 3
SAFETY 4
General Safety Rules........................................................................................ 4
Drywall Sander Safety Warnings...................................................................... 6
Electrical Information....................................................................................... 8
BEFORE OPERATING 9
Know Your Drywall Sander ...............................................................................9
Assembly & Adjustments............................................................................... 10
OPERATION & MAINTENANCE 12
Operation ....................................................................................................... 12
Maintenance....................................................................................................13
Troubleshooting Guide....................................................................................14
Exploded View & Parts List.............................................................................15
Warranty Statement ........................................................................................19
To purchase replacement sandpaper for your tool, visit WENPRODUCTS.COM
Round Drywall Sandpaper, 10 Pack (Model DW60SP, DW80SP, DW120SP, DW150SP, DW180SP, DW240SP)
Triangular Drywall Sandpaper, 10 Pack
(Model 6377SP60, 6377SP80, 6377SP120, 6377SP150, 6377SP180, 6377SP240)
15-Feet Dust Hose (Part Number 6369-103)
2

SPECIFICATIONS
INTRODUCTION
Thanks for purchasing the WEN Drywall Sander. We know you are excited to put your tool to work, but first, please
take a moment to read through the manual. Safe operation of this tool requires that you read and understand this
operator’s manual and all the labels affixed to the tool. This manual provides information regarding potential safety
concerns, as well as helpful assembly and operating instructions for your tool.
NOTE: The following safety information is not meant to cover all possible conditions and situations that may occur.
WEN reserves the right to change this product and specifications at any time without prior notice.
At WEN, we are continuously improving our products. If you find that your tool does not exactly match this manual,
please visit wenproducts.com for the most up-to-date manual or contact our customer service at 1-800-232-1195.
Keep this manual available to all users during the entire life of the tool and review it frequently to maximize
safety for both yourself and others.
Indicates danger, warning, or caution. The safety symbols and the explanations with them deserve your
careful attention and understanding. Always follow the safety precautions to reduce the risk of fire, electric shock
or personal injury. However, please note that these instructions and warnings are not substitutes for proper ac-
cident prevention measures.
Model Number DW5084
Motor 120V, 60 Hz, 5A
Speed 600 to 1500 RPM (No Load)
Triangular Pad Size (Along One Edge) 11-1/4 Inches
Triangular Sandpaper Size (Along One Edge) 11-1/4 Inches
Triangular Sandpaper Model Number 6377SP60, 6377SP80, 6377SP120, 6377SP150, 6377SP180,
6377SP240
Round Pad Diameter 8-1/2 Inches
Round Sandpaper Diameter 9 Inches
Round Sandpaper Model Numbers DW60SP, DW80SP, DW120SP, DW150SP, DW180SP, DW240SP
Sandpaper Grits 60, 80, 120, 150, 180, and 240
Tube Diameter 1-1/4 Inches
Product Weight 17.4 Pounds
3

GENERAL SAFETY RULES
WORK AREA SAFETY
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable liquids,
gases or dust. Power tools create sparks which may ig-
nite the dust or fumes.
3. Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
1. Power tool plugs must match the outlet. Never mod-
ify the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric shock.
2. Avoid body contact with earthed or grounded surfac-
es such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body
is earthed or grounded.
3. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of elec-
tric shock.
4. Do not abuse the cord. Never use the cord for car-
rying, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric
shock.
5. When operating a power tool outdoors, use an ex-
tension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric
shock.
6. If operating a power tool in a damp location is un-
avoidable, use a ground fault circuit interrupter (GFCI)
protected supply. Use of a GFCI reduces the risk of elec-
tric shock.
PERSONAL SAFETY
1. Stay alert, watch what you are doing and use com-
mon sense when operating a power tool. Do not use a
power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inatten-
tion while operating power tools may result in serious
personal injury.
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such as a respira-
tory mask, non-skid safety shoes and hearing protection
used for appropriate conditions will reduce the risk of
personal injury.
3. Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or
energizing power tools that have the switch on invites
accidents.
4. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or jew-
elry. Keep your hair and clothing away from moving
parts. Loose clothes, jewelry or long hair can be caught
in moving parts.
Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool”
in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
SAVE THESE SAFETY INSTRUCTIONS.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
4

GENERAL SAFETY RULES
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
POWER TOOL USE AND CARE
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
2. Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained us-
ers.
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s opera-
tion. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained
power tools.
6. Keep cutting tools sharp and clean. Properly main-
tained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits, etc.
in accordance with these instructions, taking into ac-
count the working conditions and the work to be per-
formed. Use of the power tool for operations different
from those intended could result in a hazardous situa-
tion.
8. Use clamps to secure your workpiece to a stable
surface. Holding a workpiece by hand or using your
body to support it may lead to loss of control.
9. KEEP GUARDS IN PLACE and in working order.
SERVICE
1. Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is main-
tained.
CALIFORNIA PROPOSITION 65 WARNING
Some dust created by power sanding, sawing, grinding,
drilling, and other construction activities may contain
chemicals, including lead, known to the State of Califor-
nia to cause cancer, birth defects, or other reproductive
harm. Wash hands after handling. Some examples of
these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement, and other
masonry products.
• Arsenic and chromium from chemically treated
lumber.
Your risk from these exposures varies depending on
how often you do this type of work. To reduce your ex-
posure to these chemicals, work in a well-ventilated area
with approved safety equipment such as dust masks
specially designed to filter out microscopic particles.
Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool”
in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
SAVE THESE SAFETY INSTRUCTIONS.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
5

DRYWALL SANDER SAFETY WARNINGS
DRYWALL SANDER SAFETY
1. This power tool is intended for sanding drywall for
home use only. Using this tool for professional purposes
will reduce the tool’s lifespan and cause parts to wear
down sooner. Do not force the machine to do other jobs,
such as grinding, cutting off, grooming, etc. Operations
for which the tool was not designed, including modifica-
tion of the machine, may cause machine damage, per-
sonal injuries, and invalidate the warranty.
2. Keep bystanders and all other living creatures, includ-
ing children and pets, away from the work area.
3. Do not operate the tool in the presence of flammable
liquids or gases. Do not operate the tool in wet or damp
conditions; doing so significantly increases the risk of
electrical shock.
4. The following personal protective equipment
must be used to reduce the risk of personal injuries:
• ANSI Z87.1-approved impact-resistant safety goggles
with side shields. Safety goggles should be worn during
operation, assembly or maintenance of the tool.
• Ear protection such as plugs or muffs. Failure to use
adequate ear protectors when the noise level is high can
result in hearing loss and other problems, such as tin-
nitus (ringing, whistling or buzzing in the ear).
• Face mask or dust mask to fight the debris produced by
operation. The dust generated during may carry health
risks (e.g. cancer, birth defects, asthma and/or derma-
titis). Work in a well-ventilated environment and wear a
dust masks specially designed to filter out microscopic
particles.
• Heavy-duty work gloves to protect your hands.
• Safety non-slip work boots.
• Safety helmet if any work is being carried out above
your head.
5. The rated speed of the accessories must be great-
er than or equal to the tool’s maximum speed of 1500
RPM. Do not use accessories rated at speeds below the
machine’s maximum RPM.
6. Do not use sanding discs larger than the recommend-
ed size of 9 inches in diameter. Incorrectly sized acces-
sories will not get along with your sander.
7. Always hold your tool firmly with both hands to main-
tain control and to avoid kickback.
8. Position the power cord clear of the rotating acces-
sory to avoid accidentally damaging the cord.
9. Do not run the power tool while carrying it at your
side. Accidental contact with the rotating accessory
could snag your clothing, pulling the accessory into your
body.
10. Never lay the power tool down until the accessory
has come to a complete stop. The rotating accessory
may grab the surface and pull the sander out of your
control.
11. Always turn the tool OFF and disconnect the power
before making adjustments or performing maintenance.
12. Maintain the tool properly. Keep your machine’s ven-
tilation slots and dust port clean. Keep the tool and ac-
cessories clean and in good working order. Have your
tool serviced by a qualified repair person using only
identical replacement parts.
WARNING! Do not let comfort or familiarity with the product replace strict adherence to product safety rules.
Failure to follow the safety instructions may result in serious personal injury.
6

These safety instructions can’t possibly warn of every scenario that may arise with this tool,
so always make sure to stay alert and use common sense during operation.
DRYWALL SANDER SAFETY WARNINGS
WARNING! Do not let comfort or familiarity with the product replace strict adherence to product safety rules.
Failure to follow the safety instructions may result in serious personal injury.
KICKBACK AND RELATED WARNINGS
Kickback is a sudden reaction to a pinched or snagged
rotating wheel, backing pad, brush or any other acces-
sory. Pinching or snagging causes rapid stalling of the
rotating accessory which in turn causes the uncontrolled
power tool to be forced in the direction opposite of the
accessory’s rotation at the point of the binding.
Kickback is the result of power tool misuse and/or in-
correct operating procedures or conditions and can be
avoided by taking proper precautions as given below.
1. Maintain a firm grip on the power tool and position
your body and arm to allow you to resist kickback forces.
Always use auxiliary handle, if provided, for maximum
control over kickback or torque reaction during start-up.
The operator can control torque reactions or kickback
forces, if proper precautions are taken.
2. Never place your hand near the rotating accessory.
The accessory may kickback over your hand.
3. Do not position your body in the area where power
tool will move if kickback occurs. Kickback will propel
the tool in the direction opposite to the wheel’s move-
ment at the point of snagging.
4. Use special care when working corners, sharp edges
etc. Avoid bouncing and snagging the accessory. Cor-
ners, sharp edges or bouncing have a tendency to snag
the rotating accessory and cause loss of control or kick-
back.
VIBRATION SAFETY
This tool vibrates during use. Repeated or long-term
exposure to vibration may cause temporary or perma-
nent physical injury, particularly to the hands, arms and
shoulders. To reduce the risk of vibration-related inju-
ries:
1. First be examined by a doctor and then have regular
medical check-ups to ensure medical problems are not
being caused or worsened from using this tool. People
who are pregnant, have impaired blood circulation to the
hand, past hand injuries, nervous system disorders, dia-
betes, or Raynaud’s disease should NOT use this tool.
2. If you feel any symptoms related to vibration (such
as tingling, numbness, and white or blue fingers), stop
working and seek medical advice as soon as possible.
3. Wear suitable work gloves to reduce the effects of
vibration.
4. Hold the tool firmly enough to keep safe control of it,
but NOT too tightly. The risk associated with vibration is
increased when the gripping force is high. Let the tool
do the work.
5. Take vibration-free breaks during each day of work.
7

ELECTRICAL INFORMATION
AMPERAGE REQUIRED GAUGE FOR EXTENSION CORDS
25 ft. 50 ft. 100 ft. 150 ft.
5A 18 gauge 16 gauge 16 gauge 14 gauge
IMPORTANT: Servicing a double-insulated product requires extreme care and knowledge of the system, and
should be done only by qualified service personnel using identical replacement parts. Always use original factory
replacement parts when servicing.
1. Polarized Plugs. To reduce the risk of electric shock, this equipment has a polarized plug (one blade is wider than
the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician to install a proper outlet. Do not modify the machine plug
or the extension cord in any way.
2. Ground fault circuit interrupter protection (GFCI) should be provided on the circuit or outlet used for this power
tool to reduce the risk of electric shock.
3. Service and repair. To avoid danger, electrical appliances must only be repaired by a qualified service technician
using original replacement parts.
GUIDELINES AND RECOMMENDATIONS FOR EXTENSION CORDS
When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. An
undersized cord will cause a drop in line voltage, resulting in loss of power and overheating. The table below shows
the correct size to be used according to cord length and ampere rating. When in doubt, use a heavier cord. The
smaller the gauge number, the heavier the cord.
DOUBLE-INSULATED TOOLS
The tool’s electrical system is double-insulated where two systems of insulation are provided. This
eliminates the need for the usual three-wire grounded power cord. Double-insulated tools do not need
to be grounded, nor should a means for grounding be added to the product. All exposed metal parts
are isolated from the internal metal motor components with protecting insulation.
1. Examine extension cord before use. Make sure your extension cord is properly wired and in good condition.
Always replace a damaged extension cord or have it repaired by a qualified person before using it.
2. Do not abuse extension cord. Do not pull on cord to disconnect from receptacle; always disconnect by pulling on
plug. Disconnect the extension cord from the receptacle before disconnecting the product from the extension cord.
Protect your extension cords from sharp objects, excessive heat and damp/wet areas.
3. Use a separate electrical circuit for your tool. This circuit must not be less than a 12-gauge wire and should be
protected with a 15A time-delayed fuse. Before connecting the motor to the power line, make sure the switch is in
the OFF position and the electric current is rated the same as the current stamped on the motor nameplate. Running
at a lower voltage will damage the motor.
8

UNPACKING
With the help of a friend or trustworthy foe, such as one of your in-laws, carefully remove the drywall sander from
the packaging and place it on a sturdy, flat surface. Make sure to take out all contents and accessories. Do not dis-
card the packaging until everything is removed. Check the packing list below to make sure you have all of the parts
and accessories. If any part is missing or broken, please contact customer service at 1-800-232-1195 (M-F 8-5
CST), or email [email protected].
KNOW YOUR DRYWALL SANDER
Motor
Power Switch
5mm Hex Wrench
Dust Hose
Dust Port Connector
47mm Adapter
Shoulder Strap
Round Sanding Discs (6)
• 60 Grit (1)
• 80 Grit (1)
• 120 Grit (1)
• 150 Grit (1)
• 180 Grit (1)
• 240 Grit (1)
Round Hook & Loop Base Pad
Locking Clasp
Variable Speed Adjustment Wheel
Extension Locking Nut
Handle Extension
(Needs Assembly)
Hose Connection Adapter
(Needs Assembly)
Triangular Hook & Loop
Base Pad
Triangular Sanding Discs (6)
• 60 Grit (1)
• 80 Grit (1)
• 120 Grit (1)
• 150 Grit (1)
• 180 Grit (1)
• 240 Grit (1)
9

ASSEMBLY & ADJUSTMENTS
ASSEMBLING THE DRYWALL SANDER
1. Unfold the front and back of the drywall sander. Push
the locking clasp (Fig. 1 - 1) fully into the closed posi-
tion.
2. Attach the base pad. The shaft on the back of the base
pad (Fig. 2 - 1) needs to match the hole aligment of the
drywall sander head (Fig. 2 - 2) to be installed.
3. Adjust the angle of the base pad until it has been fit-
ted onto the drywall sander head. Press the base pad to
secure it onto the drywall sander.
4. Pull the knob (Fig. 3 - 1) on the side of the head and
slide it upward to secure the base pad in place. Check to
make sure the base pad is securely aligned and attached.
5. Attach the sanding disc (Fig. 4 - 1) of your choice
to the face of the hook and loop base pad (Fig. 4 - 2).
Ensure the holes are aligned on the bottom of the pad.
WARNING! To prevent injury from accidental operation, make sure the tool is switched OFF and unplugged
from the power source before assembling the tool or making any adjustments.
Fig. 1
1
Fig. 2
1 2
Fig. 3
1
Fig. 4
2
1
10

ASSEMBLY & ADJUSTMENTS
ASSEMBLING THE DRYWALL SANDER (CONT.)
5. Attach the optional handle extension (Fig. 5 - 1).
Rotate the locking nut (Fig. 5 - 2) counterclockwise to
loosen it. Insert the extension tube with the connection
adapter into the main drywall sander. Slide the extension
tube to the ideal length.
NOTE: The connection adapter cannot be below the max-
imum length indication line on the extension tube, oth-
erwise the handle extension will not be tightened. Rotate
the locking nut clockwise to lock the handle extension
in place. Check that the handle extension is securely at-
tached.
6. If you would like to use a dust collection device, insert
the hose connection port (Fig. 6 - 1) into the end of the
additional handle extension, or directly into the end of
the main drywall sander assembly if you choose not to
use the handle extension.
NOTE: A dust collection device is recommended to cut
down on mess and the potentially harmful particulates in
the air produced from sanding.
7. Connect one end of the dust hose to the end of the
hose connection port and the other to the dust extraction
device of your choice.
WARNING! To prevent injury from accidental operation, make sure the tool is switched OFF and unplugged
from the power source before assembling the tool or making any adjustments.
Fig. 5
2
1
Fig. 6
1
11

OPERATION
OPERATING THE DRYWALL SANDER
1. Hold the machine firmly with both hands. DO NOT
hold the machine by the machine’s head to avoid injury.
2. Before operation, make sure every fastener and nut
has been properly engaged and that the sanding pad has
been properly installed and aligned.
3. Before switching on the machine, keep the sanding
head slightly away from the work surface.
5. During sanding operation, do not press down too hard
in order to avoid overloading the sander. Use proper
pressure for better sanding effects. If the machine slows
or bogs down, immediately lessen the applied pres-
sure. The quality of the results are mainly determined by
choosing the right abrasive material for the job.
WARNING! This tool is for indoor use only. DO NOT expose to rain or use in damp locations.
6. Once the sanding task has been completed, turn off the machine. Wait for the pad to stop rotating before setting
down the machine.
VARIABLE SPEED CONTROL
Use the variable speed adjustment wheel (Fig. 7 - 1) to adjust anywhere from 600 to 1500 RPM. This drywall sander
is equipped with constant speed control to keep the pad running at a consistent rate despite changes in applied
load.
TURNING ON THE DRYWALL SANDER
After setting the variable speed to your desired RPM, power the machine by pressing forward on the power switch
(Fig. 7 - 2).
Fig. 7
1
2
12

MAINTENANCE
CLEANING AND MAINTAINING YOUR DRYWALL SANDER
Clean the unit immediately after using it. Regularly clean the unit with a damp cloth and a little soft soap. Do not use
cleaners or solvents as they will attack the plastic of the unit. Make sure water does not get into the unit.
Your drywall sander requires no additional lubrication or maintenance. Always store your sander in a dry place away
from children.
If the supply cord is damaged, it must be replaced by the manufacturer or a similarly qualified technician. DO NOT
USE A DAMAGED TOOL. If excessive sparking occurs, have the carbon brushes checked by a qualified electrician.
Only a qualified technician should change the carbon brushes.
REPLACING THE SANDING PAD
1. Detach the sanding disc from the sanding pad.
For the triangular sanding pad:
2. Unscrew the three screws (Fig. 8 - 1) located on the
outer corners of the sanding pad and the three screws
(Fig. 8 - 2) on the flange. Replace the pad with an identi-
cal part suited for this particular model of drywall sander.
Attach firmly in place with the screws.
For the round sanding pad:
2. Insert the hex wrench into the hexagonal screw (Fig.
9 - 1) located in the center of the hook and loop sand-
ing pad. Hold the pad firmly while turning the wrench to
unscrew the center hex screw. Replace the pad with an
identical part suited for this particular model of drywall
sander. Attach firmly in place using the hexagonal screw.
Fig. 8
1
11
2
1
13
Fig. 9

PROBLEM CAUSE SOLUTION
Motor is not
working.
1. Wires in the main plug or in the
socket are loose.
2. The switch is faulty.
1. Have the socket and plug checked by an autho-
rized technician.
2) Have the switch replaced by an authorized tech-
nician.
Unusual noises
occur during
operation.
Motor is not
working
properly.
1. Switch contact has failed.
2. Components have jammed.
3. Too high of load has been applied.
1. Have the switch replaced by an authorized tech-
nician.
2. Have the tool checked and repaired.
3. Use less pressure during sanding operations.
Motor gets hot.
1. Foreign substances have gotten inside
the motor.
2. Too high of load has been applied.
1. Have the foreign substances removed.
2. Use less pressure during sanding operations.
Frequent
sparks occur on
the
commutator.
1. There is a short circuit in the motor
(armature).
2. Carbon brushes are worn out or
jammed.
1. Have the armature replaced.
2. Have the carbon brushes checked.
TROUBLESHOOTING GUIDE
WARNING! Stop using the tool immediately if any of the following problems occur or risk serious personal
injury. If you have any questions, please contact customer service at 1-800-232-1195 (M-F 8-5 CST), or email
[email protected].
14

EXPLODED VIEW & PARTS LIST
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
15
143 144
145
142

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 DW5084-001 Connecting Shaft 1
2 DW5084-002 Semi-circular Key 1
3 DW5084-003 Oil Seal 3
4 DW5084-004 Seal Ring 1
5 DW5084-005 Collar 1
6 DW5084-006 Cross Tapping
Screw M4x12 3
7 DW5084-007 Small Bearing
Cover 1
8 DW5084-008 Deep Groove Ball
Bearing 1
9 DW5084-009 Tapered Gear 1
10 DW5084-010 Seal Ring 1
11 DW5084-011 Bearing 3
12 DW5084-012 Locking Shaft 3
13 DW5084-013 Seal Ring 1
14 6377-015A Gear Box 1
15 DW5084-015 Rotor Coil 1
16 DW5084-016 Wool Cap 1
17 DW5084-017 Middle Cover 1
18 DW5084-018 Anti-Dust Washer 1
19A DW5084-019 Rotor 1
20 DW5084-020 Anti-Dust Ring 1
21 DW5084-021 Ball Bearing 1
22 DW5084-022 Anti-Wind Ring 1
23 DW5084-023 Screw ST4x55 2
24 DW5084-024 Washer 1
25A DW5084-025A Stator 1
26 DW5084-026 Sleeve 1
27 DW5084-027 Logo Label 1
28 DW5084-028 Motor Housing 1
29 DW5084-029 Specification Label 1
30 DW5084-030 Screw M4x20 4
31 DW5084-031 Brush Holder 2
32 DW5084-032 Carbon Brush 2
33 DW5084-033 Screw ST3x10 2
34 DW5084-034 Coil Spring 2
35 DW5084-035 Pressing Block On
Motor Housing 1
No. Part No. Description Qty.
36 DW5084-036 Screw ST4x12 2
37 DW5084-037 Screw ST4x14 40
38 DW5084-038 Back Cover 1
39 DW5084-039 Vibration Damping 2
40 DW5084-040 Rubber Sleeve 2
41 DW5084-041 Screw Pin 2
42 DW5084-042 Flexible Sleeve 1
43 DW5084-043 Cross Screw M4x8 3
44 6377-070 Triangular Sanding
Pad 1
45 DW5084-045 Aluminum Cover 1
46 DW5084-046 Circlip 1
47 DW5084-047 Deep Groove Ball
Bearing 1
48 DW5084-048 Eccentric Shaft 1
49 DW5084-049 Flat Key 1
50 DW5084-050 Eccentric Shaft 1
51 DW5084-051 Circlip 1
52 DW5084-052 Outer Dust Seal 3
53 DW5084-053 Head Footings 3
54 DW5084-054A Upper Triangular
Head 1
55 DW5084-055 Cross Head Screw
M4*10 3
56 DW5084-056 Cross Screw
ST4x12 12
57 DW5084-057 Seal Ring 4
58 DW5084-058 Washer 4
59 DW5084-059 Triangular Head Base 1
60 DW5084-060 Collar 2
61 DW5084-061 Locking Plate 2
62 DW5084-062 Compression
Spring 2
63 DW5084-063 Locking Pull Knob 2
64 DW5084-064 Pin 1
65 DW5084-065 Compression
Spring 10
66 DW5084-066 Pin Cover 1
67 DW5084-067 Locking Plate 2
68 DW5084-068 Locknut M4 2
16

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
69 DW5084-069 Circlip 2
70 DW5084-070 Deep Groove Ball
Bearing 2
71 DW5084-071 Front Cover 2
72 DW5084-072 Needle Bearing 2
73 DW5084-073 Steel Ball 2
74 DW5084-074 Gear #2 1
75 DW5084-075 Gear #1 1
76 DW5084-076 Connecting Gear
Shaft 1
77 DW5084-077 Ball Bearing 2
78 DW5084-078 Gasket 2
80 DW5084-079 Bearing Cover 2
81 DW5084-080 Screw M4x12 10
82 DW5084-081 Screw M6x15 1
83 DW5084-082 Ø6 Washer 1
84 DW5062-003 Circular Sanding
Pad 1
85 DW5084-085 Output Shaft 1
87 DW5084-087 Brush Segment 1
88 DW5084-088A Sanding Pad Cover 1
89 DW5084-089 End Gear 1
90 DW5084-090 Connecting Gear
Shaft 1
91 DW5084-091 Pressign Plate 1
92 DW5084-092 Dust Collection
Cover 1
93 DW5084-093 Cross Head Screw
M4x12 2
94 6369-054 Hose Clamp 25-38 1
95 6369-055 350 Hose 1
96 6369-057 Small Rubber
Cover 2
97 6369-062 Left Handle Stand 1
98 6369-059 Ø28 Connector 1
99 6369-060 Plastic Soft Pipe
Ø28 1
100 6369-056 Cable Sleeve 1
101 6369-061 Ellipticle Connector 1
102 6369-083 Aluminium Pipe 1
No. Part No. Description Qty.
103 6369-080 Ø5 Clinch Bolt 2
104 6369-082 Front Hinge 1
105 6369-081 Ø1.2 Sealed Ring 1
106 6369-079 Ø5x45 Pin 1
107 6369-078 Back Hinge 1
108 6369-085 Pin Ø5x30 1
109 6369-086 Pin Ø5x6.8 1
110 6369-066 Cable Plate 2
111 6369-073 Left Main Handle 1
112 6369-075 Cable Pressing
Plate 1
113A 6369-068 Potentiometer 1
114 6369-070 Speed Button 1
115 DW5084-115 Leading Cable 1
116 6369-072 Cable Sleeve 1
117 6369-071 Cable 1
118 6369-093 Switch 1
119 6369-094 Switch Pushing
Lever 1
120 6369-097 Circular Pin
Ø1.5x11.8 1
121 6369-095 Switch Button 1
122 6369-098 Back Screw Nut 2
123 6369-077 Aluminium Pipe 1
124 6369-076 Left Sub-Handle 1
125 6369-090 Latch Pivot 1
126 6369-091 Fixed Plate 1
127 6369-084 Supporting Arm 1
128 6369-087 Sleeve 2
129 6369-089 Spring 1
130 6369-088 Front Latch 1
131 6369-058 Right Handle Stand 1
132 6369-074 Aluminium Pipe
Insert 1
133 6369-092 Aluminium Pipe 1
134 6369-099 Right Main Handle 1
135 6369-092 Right Sub-Handle 1
136 6369-100 Hose Connection
Adapter 1
137 6369-101 Adjustable Ring 1
17

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
138 6369-103 Flexible Hose 1
139 6362-054 Middle Connector 1
140 DW5062-102 Ø47 Vacuum
Adapter 1
142 DW5062-108 Hex Wrench S5 1
No. Part No. Description Qty.
143 DW5062-104 Shoulder Strap
with hook 1
144 DW5062-105 Hook Seat 1
145 DW5062-106 Nut M5 1
146 DW5062-107 Bolt M5*18 1
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
18

WARRANTY STATEMENT
WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this
commitment and our dedication to qualit
y.
LIMITED WARRANTY OF WEN PRODUCTS FOR HOME USE
GRE
AT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN
consumer
power tools will be free from defects in material or workmanship during personal use for a period of two (2) years
used
for professional or commercial use. Purchaser has 30 days from the date of purchase to report missing or
damaged parts.
SELLER’S
SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Limited Warranty and, to the extent per-
mitted
by law, any warranty or condition implied by law, shall be the replacement of parts, without charge, which a
re
defective
in material or workmanship and which have not been subjected to misuse, alteration, careless handling,
misrepai
r, abuse, neglect, normal wear and tear,
improper maintenance, or other conditions adversely affecting the
Product
or the component of the Product, whether by accident or intentionally, by persons other than Seller. To
make
a claim under this Limited Warranty, you must make sure to keep a copy of your proof of purchase that
clearly
-
dor
of Great Lakes Technologies, LLC. Purchasing through third party vendors, including but not limited to garage
sales,
pawn shops, resale shops, or any other secondhand merchant, voids the warranty included with this
product.
Contact [email protected] or 1-800-232-1195 with the following information to make arrangements:
your
shipping address, phone number, serial number, required part numbers, and proof of purchase. Damaged
or
defective parts and products may need to be sent to WEN before the replacements can be shipped out.
-
turning
a product for warranty service, the shipping charges must be prepaid by the purchaser. The product
must
be
shipped in its original container (or an equivalent), properly packed to withstand the hazards of shipment. The
product
must be fully insured with a copy of the proof of purchase enclosed. There must also be a description of
the
will be returned and shipped back to the pur
chaser at no charge for addresses within the contiguous United States.
THIS
LIMITED WARRANTY DOES NOT APPLY TO ITEMS THAT WEAR OUT FROM REGULAR USAGE OVER TIME,
INCLUDING
BELTS, BRUSHES, BLADES, BATTERIES, ETC. ANY IMPLIED WARRANTIES SHALL BE LIMITED IN
DUR
ATION TO TWO (2) YEARS FROM DATE OF PURCHASE. SOME STATES IN THE U.S. AND SOME CANADIAN
PROVINCES
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMI-
TAT
ION MAY NOT APPLY TO YOU.
IN
NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING
BUT
NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS) ARISING FROM THE SALE OR USE OF THIS PRODUCT.
SOME ST
ATES IN THE U.S. AND SOME CANADIAN PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITAT
ION
OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY
TO YOU.
THIS
LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
WHICH
VARY FROM STATE TO STATE IN THE U.S., PROVINCE TO PROVINCE IN CANADA AND FROM COUNTRY
TO COUNT
RY.
THIS
LIMITED WARRANTY APPLIES ONLY TO ITEMS SOLD WITHIN THE UNITED STATES OF AMERICA, CANA-
DA
AND THE COMMONWEALTH OF PUERTO RICO. FOR WARRANTY COVERAGE WITHIN OTHER
COUNTRIES,
CONT
ACT THE WEN CUSTOMER SUPPORT LINE. FOR WARRANTY PARTS OR PRODUCTS REPAIRED UNDER
W
ARRANTY SHIPPING TO ADDRESSES OUTSIDE OF THE CONTIGUOUS UNITED STATES, ADDITIONAL
SHIPPING
CHARGES MAY APPLY.
19

THANKS FOR
REMEMBERING
V. 2022.09.13
