Wen TC1318 User manual

18-INCH
ELECTRIC TILLER
Instruction Manual
IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use
your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
TECHSUPPOR[email protected]1-800-232-1195 (M-F 8AM-5PM CST)
For replacement parts and the most up-to-date instruction manuals, visit WENPRODUCTS.COM
MODEL TC1318

2
CONTENTS
WELCOME 3
Introduction ..................................................................................................... 3
Specifications................................................................................................... 3
SAFETY 4
General Safety Rules........................................................................................ 4
Electrical Information....................................................................................... 6
Electric Tiller Safety Warnings ......................................................................... 7
BEFORE OPERATING 9
Unpacking & Packing List.................................................................................9
Know Your Electric Tiller .................................................................................10
Assembly & Adjustment................................................................................. 11
OPERATION & MAINTENANCE 12
Operation ....................................................................................................... 12
Maintenance................................................................................................... 14
Troubleshooting Guide....................................................................................16
Exploded View & Parts List.............................................................................17
Warranty Statement ....................................................................................... 20
To purchase accessories for your tool, visit WENPRODUCTS.COM
50 ft. Extension Cord (Model PC5124)
100 ft. Extension Cord (Model PC1123)

3
SPECIFICATIONS
Model Number TC1318
Motor 120V, 60 Hz, 13.5A
Blade Speed 360 RPM
Working Width 18 Inches
Blade Diameter 8 Inches
Working Depth 8.7 Inches
Product Weight 24.0 Pounds
Product Dimensions Folded: 50-1/2 in. x 18 in. x 15 in.
Unfolded: 39 in. x 18 in. x 40-1/2 in.
INTRODUCTION
Thanks for purchasing the WEN Electric Tiller. We know you are excited to put your tool to work, but first, please
take a moment to read through the manual. Safe operation of this tool requires that you read and understand this
operator’s manual and all the labels affixed to the tool. This manual provides information regarding potential safety
concerns, as well as helpful assembly and operating instructions for your tool.
NOTE: The following safety information is not meant to cover all possible conditions and situations that may occur.
WEN reserves the right to change this product and specifications at any time without prior notice.
At WEN, we are continuously improving our products. If you find that your tool does not exactly match this manual,
please visit wenproducts.com for the most up-to-date manual or contact our customer service at 1-800-232-1195.
Keep this manual available to all users during the entire life of the tool and review it frequently to maximize
safety for both yourself and others.
SAFETY ALERT SYMBOL: Indicates danger, warning, or caution. The safety symbols and the explanations
with them deserve your careful attention and understanding. Always follow the safety precautions to reduce the
risk of fire, electric shock or personal injury. However, please note that these instructions and warnings are not
substitutes for proper accident prevention measures.

4
GENERAL SAFETY RULES
WORK AREA SAFETY
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable liquids,
gases or dust. Power tools create sparks which may ig-
nite the dust or fumes.
3. Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
1. Power tool plugs must match the outlet. Never mod-
ify the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric shock.
2. Avoid body contact with earthed or grounded surfac-
es such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body
is earthed or grounded.
3. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of elec-
tric shock.
4. Do not abuse the cord. Never use the cord for car-
rying, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric
shock.
5. When operating a power tool outdoors, use an ex-
tension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric
shock.
6. If operating a power tool in a damp location is un-
avoidable, use a ground fault circuit interrupter (GFCI)
protected supply. Use of a GFCI reduces the risk of elec-
tric shock.
PERSONAL SAFETY
1. Stay alert, watch what you are doing and use com-
mon sense when operating a power tool. Do not use a
power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inatten-
tion while operating power tools may result in serious
personal injury.
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such as a respira-
tory mask, non-skid safety shoes and hearing protection
used for appropriate conditions will reduce the risk of
personal injury.
3. Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or
energizing power tools that have the switch on invites
accidents.
4. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or jew-
elry. Keep your hair and clothing away from moving
parts. Loose clothes, jewelry or long hair can be caught
in moving parts.
Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool”
in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
SAVE THESE SAFETY INSTRUCTIONS.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.

5
GENERAL SAFETY RULES
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
POWER TOOL USE AND CARE
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
2. Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained us-
ers.
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s opera-
tion. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained
power tools.
6. Keep cutting tools sharp and clean. Properly main-
tained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits, etc.
in accordance with these instructions, taking into ac-
count the working conditions and the work to be per-
formed. Use of the power tool for operations different
from those intended could result in a hazardous situa-
tion.
8. Use clamps to secure your workpiece to a stable
surface. Holding a workpiece by hand or using your
body to support it may lead to loss of control.
9. KEEP GUARDS IN PLACE and in working order.
SERVICE
1. Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is main-
tained.
CALIFORNIA PROPOSITION 65 WARNING
Some dust created by power sanding, sawing, grinding,
drilling, and other construction activities may contain
chemicals, including lead, known to the State of Califor-
nia to cause cancer, birth defects, or other reproductive
harm. Wash hands after handling. Some examples of
these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement, and other
masonry products.
• Arsenic and chromium from chemically treated
lumber.
Your risk from these exposures varies depending on
how often you do this type of work. To reduce your ex-
posure to these chemicals, work in a well-ventilated area
with approved safety equipment such as dust masks
specially designed to filter out microscopic particles.
Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool”
in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
SAVE THESE SAFETY INSTRUCTIONS.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.

ELECTRIC TILLER SAFETY
1. GROUND FAULT CIRCUIT INTERRUPTER (GFCI) pro-
tection should be provided on the circuit or outlet to be
used for the tiller/cultivator. Receptacles are available
having built-in GFCI protection and may be used.
2. DISCONNECT UNIT from the power supply when not
in use or when servicing or cleaning. Do not leave unat-
tended.
3. DON’T ABUSE CORD - Never carry this product by the
cord or yank the cord to disconnect from the receptacle.
Keep cord away from heat, oil, and sharp edges.
4. USE RIGHT APPLIANCE - Do not use this product for
any job except that for which it is intended.
5. DON’T OVERREACH - Guide the tiller/cultivator at a
walking pace only. Keep proper footing and balance at
all times.
6. LIGHTING - Only operate your tiller/cultivator in day-
light or good artificial light.
7. STORE IDLE UNIT INDOORS - When not in use, the
tiller/cultivator should be stored indoors in a dry area out
of children’s reach.
8. MAINTAIN UNIT WITH CARE - Keep clean for best
performance and to reduce the risk of injury. Inspect ex-
tension cord periodically and replace if damaged. Keep
handles dry, clean and free from oil.
9. POLARIZED PLUGS - To reduce the risk of elec-
tric shock, this product has a polarized plug. Polar-
ized connections will fit together only one way. Make
sure that the receptacle end of the extension cord has
large and small blade slot widths. If the plug does not fit
fully into extension cord, reverse the plug. If i still does
not fit, obtain a suitable extension cord. If the extension
cord does not fit fully into the outlet, contact a qualified
electrician to install the proper outlet. Do not change the
plug on the tool or the extension cord in any way.
10. Do not operate the tiller on a slope that is too steep
for safe operation. When on slopes, slow down and
make sure you have stable footing.
11. Before starting the tiller make sure the tines are not
touching any object and are free to move.
12. Grip the guide bar firmly with both hands. Never op-
erate the tiller/cultivator with one hand.
13. STAY ALERT - Watch what you are doing. Use com-
mon sense. Do not operate the tiller/cultivator when you
are tired or under the influence of drugs, alcohol, or
medication
14. If the tiller strikes a foreign body, turn it off immedi-
ately, wait for the tines to stop and check for damage. If
necessary, repair before restarting.
15. If the tiller starts to vibrate abnormally, turn it off im-
mediately and check for the cause. Excessive vibration is
generally a sign of a malfunction or damaged part.
16. Before carrying out any maintenance or repairs, al-
ways turn off the tiller/cultivator, disconnect from the
power supply and wait until the tines come to a complete
stop before carrying out any maintenance or repairs.
ELECTRIC TILLER SAFETY WARNINGS
WARNING! Do not operate the power tool until you have read and understood the following instructions and
the warning labels.
CAUTION! The electric tiller may bounce
upward or jump forward if the tines strike extremely
hard packed soil, frozen ground, or buried obstacles
such as large stones, roots or stumps.
WARNING! Do not operate the tiller near
underground electrical cables, telephone lines, pipes
or hoses.
DANGER! RISK OF CUT - Wear gloves and use
caution when cleaning or performing maintenance
on the tiller/cultivator.
6

7
17. WATCH FOR CORD - Be aware of the extension cord
while using the tiller. Make sure not to trip over the cord
and keep it out of the path of the tiller. Always guide the
cord away from the tool during operation.
18. KEEP AWAY FROM WATER - Do not expose the tiller
to wet or rainy conditions. Never operate the tiller with
wet hands. Either of these can increase the risk of shock,
personal injury, or tool damage.
Your risk from exposure to these chemicals varies, de-
pending on how often you do this type of work. To re-
duce your exposure, work in a well-ventilated area and
with approved safety equipment such as dust masks that
are specially designed to filler out microscopic particles.
ELECTRIC TILLER SAFETY WARNINGS
WARNING! Do not operate the power tool until you have read and understood the following instructions and
the warning labels.
WARNING! Some dust and debris created by
the use of this tool could contain chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm. Some examples
of these chemicals are:
• Chemicals in fertilizers.
• Compounds in insecticides and pesticides.
• Arsenic & chromium from treated lumber
CAUTION! Tines do not stop immediately after
the lD tiller/cultivator is turned off.
CAUTION! Risk of injury. Do not put hands, feet
or any body part or clothing near the rotating tines.
CAUTION! The electrical cords on this product
may contain chemicals known to the State of
California to cause cancer and birth defects or other
reproductive harm. Wash hands after handling.

8
ELECTRICAL INFORMATION
AMPERAGE REQUIRED GAUGE FOR EXTENSION CORDS
25 ft. 50 ft. 100 ft. 150 ft.
13.5A 14 gauge 12 gauge Not Recommended by UL
IMPORTANT: Servicing a double-insulated product requires extreme care and knowledge of the system, and
should be done only by qualified service personnel using identical replacement parts. Always use original factory
replacement parts when servicing.
1. Polarized Plugs. To reduce the risk of electric shock, this equipment has a polarized plug (one blade is wider than
the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician to install a proper outlet. Do not modify the machine plug
or the extension cord in any way.
2. Ground fault circuit interrupter protection (GFCI) should be provided on the circuit or outlet used for this power
tool to reduce the risk of electric shock.
3. Service and repair. To avoid danger, electrical appliances must only be repaired by a qualified service technician
using original replacement parts.
GUIDELINES AND RECOMMENDATIONS FOR EXTENSION CORDS
When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. An
undersized cord will cause a drop in line voltage, resulting in loss of power and overheating. The table below shows
the correct size to be used according to cord length and ampere rating. When in doubt, use a heavier cord. The
smaller the gauge number, the heavier the cord.
DOUBLE-INSULATED TOOLS
The tool’s electrical system is double-insulated where two systems of insulation are provided. This
eliminates the need for the usual three-wire grounded power cord. Double-insulated tools do not need
to be grounded, nor should a means for grounding be added to the product. All exposed metal parts are
isolated from the internal metal motor components with protecting insulation.
1. Examine extension cord before use. Make sure your extension cord is properly wired and in good condition.
Always replace a damaged extension cord or have it repaired by a qualified person before using it.
2. Do not abuse extension cord. Do not pull on cord to disconnect from receptacle; always disconnect by pulling on
plug. Disconnect the extension cord from the receptacle before disconnecting the product from the extension cord.
Protect your extension cords from sharp objects, excessive heat and damp/wet areas.
3. Use a separate electrical circuit for your tool. This circuit must not be less than a 12-gauge wire and should be
protected with a 15A time-delayed fuse. Before connecting the motor to the power line, make sure the switch is in
the OFF position and the electric current is rated the same as the current stamped on the motor nameplate. Running
at a lower voltage will damage the motor.

Components Handle Assembly
Hardware & ToolsWheel Assembly
UNPACKING & PACKING LIST
UNPACKING
With the help of a friend or trustworthy foe, such as one of your in-laws, carefully remove the electric tiller from the
packaging and place it on a sturdy, flat surface. Make sure to take out all contents and accessories. Do not discard
the packaging until everything is removed. Check the packing list below to make sure you have all of the parts and
accessories. If any part is missing or broken, please contact customer service at 1-800-232-1195 (M-F 8-5 CST),
or email [email protected].
9
Motor
Housing
Upper
Handle
Center
Handle
Wheel (2)
Hub Cap (2) Cable Clip (1) Handle Knob & M6x40
Carriage Bolts (4)

KNOW YOUR ELECTRIC TILLER
TOOL PURPOSE
Tackle the toughest of yards and gardens with your WEN Electric Tiller. Refer to the following diagrams to become
familiarized with all the parts and controls of your Electric Tiller. The components will be referred to later in the
manual for assembly and operation instructions.
10
Trigger Safety Lock
Cord Restraint Hook
Cord
Cord Hook
Handle Knob
Upper Handle
Lower Handle
Center Handle
Motor Housing
Tine Guard
Steel Tines Wheels

11
ASSEMBLY & ADJUSTMENTS
ASSEMBLING THE WHEELS
1. Remove the cotter pin (Fig. 4 - 1) from each side of the wheel axle. Slide the wheels (Fig. 4 - 2) onto the axle, with
the washer (Fig. 4 - 3) between the wheel and the axle bracket. Slide the cotter pin back through the axle hole and
bend one prong back so it sits securely in the hole.
2. Press the two hub caps (Fig. 4 - 4) into each of the two wheels.
3. Pull the wheel support bracket release pin (Fig. 5 - 1), then swing the wheel bracket down. Release the pin, and
make sure it clicks into place in the lower hole in the wheel support bracket. Wiggle the bracket to be sure it is se-
curely locked in place before moving the tiller.
ASSEMBLING THE HANDLE
1. Attach the center handle section (Fig. 1 - 1) to the lower handle sections (Fig. 1 - 2) with two M6x40 bolts and
the handle knobs.
2. Fasten upper handle section (Fig. 2 - 1) to center handle section using two M6x40 bolts and handle knobs.
3. Secure the cable along the handle tubes with the supplied cable clip (Fig. 3 - 1).
Fig. 1
2
1
Fig. 2
1
Fig. 3
1
BEFORE EACH USE:
1. Check the product, its power cord
and plug, and any other accessories
for damage. Do not use the product if
it is damaged or shows wear.
2. Double check that the accessories
and attachments are properly fitted.
3. Ensure that the handles are dry to
ensure a secure grip. Always hold
the product by its handles.
4. Ensure that the air vents are always
unobstructed and clear. Blocked air
vents may lead to overheating and
damage the product.
Fig. 5
1
Fig. 4
1
2
3
4

12
OPERATION
CONNECTING TO POWER SUPPLY
NOTE: For safety reasons, this product is equipped with a short power cord. Do not connect the electric tiller directly
to a power supply using this power cord. A proper extension cord is required for operation. Observe the technical
requirements for this product when purchasing an extension cord.
WARNING! For your safety, it is required that the extension cord be rated for outdoor use, with all sockets
protected against water slash. Always use a residual-current device (RCD) or residual-current circuit breaker
(RCCB) protected power supply.
WARNING! Check the voltage to ensure it complies with the information on the rating label.
CONNECTING THE EXTENSION CORD
1. Make sure that the power is OFF.
2. Select the correct extension cord using the chart on p. 6.
3. Make a knot with the power and extension cords (Fig. 6).
Secure the connection.
POWERING ON & OFF
WARNING! Rotating tines may cause serious injury.
The tines will continue to turn for a few seconds after the
tool has been switched OFF. Do not touch the rotating
tines. Contact with hot components (i.e. motor housing,
gear box, etc.) on the machine may cause burns. Allow
the machine to cool before handling.
1. Connect the tiller to a working 120V outlet using a heavy-
duty, outdoor rated extension cord.
2. To turn the tool ON, push and hold the safety lock button
(Fig. 7 - 1) with your thumb and then squeeze the trigger
switch (Fig. 7 - 2) with your fingers. Once the tool is run-
ning, release the safety lock button.
3. To switch OFF, release the trigger switch (Fig. 7 - 2).
TILLING
1. Move tiller to desired work area prior to starting motor.
2. Pull the wheel support bracket release pin (Fig. 8 - 1),
then swing the wheel bracket up and out of the way. Release
the pin, and make sure it clicks into place in the upper hole
in the wheel support bracket. Wiggle the bracket to be sure
it is securely locked in place before beginning to till.
Tilling instructions continue on the next page.
Fig. 8
1
Fig. 7
2
1
Fig. 6
Extension
Cord
Appliance
Cord

OPERATION
13
TILLING (CONT.)
3. Connect to the power supply and hold the tiller firmly
when starting. The tines will pull the tiller forward during
operation (Fig. 9).
4. To start the tiller, press the safety lock button (Fig. 7 - 1)
and then pull the trigger lever (Fig. 7 - 2) up and against the
handle bar. The motor will start and the tines will begin to
rotate.
5. When finished tilling, pull the wheel support bracket re-
lease pin (Fig. 8 - 1), then swing the wheel bracket down.
Release the pin, and make sure it clicks into place in the
lower hole in the wheel support bracket. Wiggle the bracket
to be sure it is securely locked in place before moving the
tiller.
NOTE: For breaking sod or deep tilling, allow the tines to
pull the tiller forward to the end of your arm’s reach, then
firmly pull it back towards yourself. Best results will be
achieved by repeatedly allowing the tiller to move forward
and pulling it back.
CAUTION! Take extra precautions when moving backwards and when pulling the tiller back towards
yourself to avoid tripping.
NOTE: If tiller digs deep enough that is gets stuck, gently rock from side to side until it starts to move forward again.
WARNING! Never pass the tiller over the extension cord. Make sure the cord is always in a safe position
away from the tines.
CAUTION! When working on inclines, always stand diagonally to the incline to retain a firm, safe footing.
Do not work on extremely steep slopes.
For preparing seed beds, we recommend using one of the following tilling patterns:
Tilling Pattern A: Make two passes over the area to be
tilled, the second perpendicular to the first (Fig. 10).
Tilling Pattern B: Make two passes over the area to
be tilled, the second overlapping the first (Fig. 11).
Fig. 9
Fig. 10 Fig. 11

OPERATION
CAUTION! Before moving the tiller from one area to another, switch off the motor and wait for the tines to
come to a complete stop. Be careful not to let the tines touch the ground while moving the tiller. The tines, as
well as the unit itself, may be damaged even if the motor is switched off.
CLEARING FOREIGN OBJECTS
During operation, a stone or root could become lodged in the tines, or or tall plants may become wrapped around
the tine shaft.
To clear the tines or tine shaft, release the trigger lever, wait for the tines to come to a complete stop and unplug the
tiller. Carefully dislodge or remove the foreign matter from the tines or tine shaft. To simplify removal of tall grass
or weeds from the tine shaft, remove one or more of the tines.
NOTE: Always wear gloves when clearing the tines or tine shaft.
14
MAINTENANCE
ROUTINE INSPECTION
Before each use, inspect the tool. If any of these following conditions exist, do not use until parts are replaced.
Check for:
• Loose hardware or improper mounting
• Misalignment
• Cracked or broken parts
• Any other condition that may affect its safe operation
Once per season, lubricate the tines and shaft. At the end of the season, check the tiller for damage prior to storing.
Repair or replace damaged or broken parts.
CLEANING
Clean the underside of the tine guard and motor housing around the tines using a scrubbing brush and a soft cloth
dampened with a mild soap and water mixture.
To remove soil and debris from the transmission and tines, use a stiff brush or a dampened cloth.
Clean the vents on the motor housing and remove any remaining grass or dirt.
Once cleaned, wipe the tines and shaft dry and apply a light coat of oil to prevent rust.
CAUTION! Always clean the tiller after each use. Failure to carry out proper cleaning can result in damage
to the tiller or result in poor performance.
CAUTION! Never use a water hose to clean the tiller.

TINES REMOVAL AND INSTALLATION
Worn tines result in poor performance and can
overload the motor.
Check tines before each use. Sharpen or replace the
tine assemblies with new ones when necessary.
To remove complete tine assembly from the shaft,
remove the M8x40 hex bolt from the shaft. Pull off
the tine assembly from the shaft. Follow the above
steps in reverse to install tines. (Fig. 12)
15
MAINTENANCE
WARNING! Injury can occur while working
on the tines. Always wear protective gloves.
STORAGE
Store this tool carefully in a secure, dry place, out of reach of children.
During extended periods of storage, ensure that the tool is protected against corrosion and frost.
At the end of the season, or if the tool is not being used for longer than a month, wipe over metal surfaces with an
oil covered cloth or spray a fine coat of oil to protect the tiller from corrosion.
Fold the handle bar down and store the tool in a suitable place, out of the reach of children.
PRODUCT DISPOSAL
Used power tools should not be disposed of together with household waste. If the product contains electrical com-
ponents they should be recycled. Please take this product to your local recycling facility for responsible disposal and
to minimize its environmental impact.
Please recycle the packaging and electronic components where facilities exist. Please contact your
local auto garage or recycling facility to properly dispose of oil/fuel.
Fig. 12

TROUBLESHOOTING GUIDE
WARNING! Stop using the tiller immediately if any of the following problems occur or risk serious personal
injury. If you have any questions, please contact customer service at 1-800-232-1195 (M-F 8-5 CST), or email
[email protected].
Problem Possible Cause Solution
Motor Does Not Start
The outlet that the tiller is connected to is
faulty or has tripped.
Ensure that the unit is plugged into a working
outlet and the tool is switched on.
The power cord or extension cord is
damaged or not properly plugged in.
Check the power cord, extension cord, power
plug and the power outlet. Do not use if any
cord is damaged.
Motor is overloaded and circuit breaker
trips.
Wait 15 minutes and try to use the tiller again.
Avoid using the tiller in soil with lots of hard
objects or when the soil is wet or frozen.
Carbon brushes worn down. Contact customer service at 1-800-232-1195
Abnormal Noise
Tines are worn or damaged. Replace the tines.
Working depth is too shallow. Work slower and deeper with the tiller.
Excessive Vibrations Loose components. Tighten all bolts. If noises continue contact
customer service at 1-800-232-1195
Unsatisfactory Performance
Tines are worn or damaged. Replace the tines.
Working depth is too shallow. Work slower and deeper with the tiller.
Tool Overheating
Motor is overloaded and circuit breaker
trips.
Reduce load on motor - work slower and shal-
lower. Avoid using the tiller in soil with lots of
hard objects or when the soil is wet or frozen.
Extension cord too long with an insuf-
ficient gauge.
Utilize an extension cord of appropriate gauge
and length.
16

17
EXPLODED VIEW & PARTS LIST

EXPLODED VIEW & PARTS LIST
18
NO. PART NO. DESCRIPTION QTY.
1 TC1318-001 Blade Subassembly
(Right) 1
2 TC1014-002 Hex Bolt, M8x40 2
3 TC1318-003 Blade Subassembly
(Right) 1
4 TC1014-004 Lock Nut, M8 2
5Hex Socket Flat-head Self-
Tapping Screw, ST6x25 4
6Phillips Flat-head Self-
tapping Screw, ST4x16 15
7 Blade Guard 1
8 Connecting Shaft 1
9 Cover 1
10 Housing 1
11 Housing Cover 1
12 Cable Clamp 1
13 Sponge 1 1
14 TC1014-014 Knob 4
15 TC1014-015 Flanged Carriage Bolt,
M6x45 4
16 TC1318-016 Handle Frame 1
17 TC1014-017 Cord Clamp 2
18 TC1318-018 Frame Plug 2
19 TC1318-019 Lower Handle Frame 2
20 TC1318-020 Lock Nut, M6 6
21 TC1318-021 Wavy Washer, 6mm 6
22 TC1318-022 Carriage Bolt, M6x32 4
23 TC1318-023 Lower Handle Frame with
Bracket 1
100 TC1318-
100ASM Gearbox Assembly 1
101 Gearbox Cover, Right 1
102 Sealing Ring Baffle 2
103 Sealing Ring 2
104 Oil Bearing 2
105 Washer 2
106 Worm Gear Shaft 1
107 Flat Key, 4x4x15mm 1
108 Worm Gear 1 1
NO. PART NO. DESCRIPTION QTY.
109 Ball Bearing, 608Z 1
110 Worm Gear 2 1
111 Gearbox Baffle 1
112 Gearbox Cover, Left 1
113 O-ring 1
114 Grease Port Screw,
M10x20 1
115 Screw with Washer,
M6x18 8
116 Sealing Ring 1
117 Splined Hub 1
118 Ball Bearing, 16100Z 1
119 Ball Bearing, 6000Z 1
200 Motor Assembly 1
6Phillips Flat-head Self-
tapping Screw, ST4x16 4
117 Splined Hub 1
201 Lower Motor Housing 1
202 Sponge 2 1
119 Ball Bearing, 6000Z 1
203 Rotor Assembly 1
109 Ball Bearing, 608Z 1
204 Wavy Washer, 22mm 1
205 Phillips Pan-head Self-
tapping Screw, ST4x70 2
206 Washer, 4mm 2
207 Stator Assembly 1
208 Inductor, 50 uH 2
209 TC1318-209 Thermal Breaker 1
210 Upper Motor Housing 1
211 TC1014-212 Capacitor, 0.22 uF 1
212 Carbon Brush Holder 2
213 TC1014-214 Carbon Brush 2
214 Phillips Pan-head Self-
tapping Screw, ST3x12 2
300 TC1318-
300ASM Upper Handle Assembly 1
301 Right Handle Cover, Right 1
302 Trigger Spring 1
303 Trigger 1

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
304 Handle Button Spring 1
305 Switch Button 1
306 Right Handle Cover, Left 1
307 Rod 1
308 Handle Cover Plate 1
6Phillips Flat-head Self-
tapping Screw, ST4x16 20
309 Phillips Pan-head Self-
tapping Screw, ST4x20 2
310 Left Handle Cover, Right 1
311 Left Handle Cover, Left 1
312 Power Cord 1
313 Power Cord Connector 1
314 Power Cord Sleeve 1
12 Cable Clamp 2
315 Phillips Pan-head Self-
tapping Screw, ST4x18 4
316 Switch 1
NO. PART NO. DESCRIPTION QTY.
214 Phillips Pan-head Self-
tapping Screw, ST3x12 1
400 TC1318-
400ASM Wheel & Axle Assembly
401 TC1014-403 Wheel Cover 2
402 TC1014-404 R-clip 2
403 Flat Washer, 10mm 2
404 TC0714-080 Wheel 2
405 Flat Washer, 6mm 1
406 Wheel Bracket Assembly 1
407 Release Ring 1
408 Wheel Adjustment Knob 1
409 Wheel Adjustment Spring 1
410 Wheel Adjustment Shaft 1
411 Phillips Countersunk Self-
tapping Screw, ST4x16 2
412 Wheel Bracket Bushing 2
413 Hex Bolt, M6x35 2
19
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.

20 V. 2021.12.13
EXPLODED VIEW & PARTS LISTWARRANTY STATEMENT
WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this
commitment and our dedication to quality.
LIMITED WARRANTY OF WEN PRODUCTS FOR HOME USE
GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN consumer power
tools will be free from defects in material or workmanship during personal use for a period of two (2) years from date
of purchase or 500 hours of use; whichever comes first. Ninety days for all WEN products if the tool is used for pro-
fessional or commercial use. Purchaser has 30 days from the date of purchase to report missing or damaged parts.
SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Limited Warranty and, to the extent per-
mitted by law, any warranty or condition implied by law, shall be the replacement of parts, without charge, which are
defective in material or workmanship and which have not been subjected to misuse, alteration, careless handling,
misrepair, abuse, neglect, normal wear and tear, improper maintenance, or other conditions adversely affecting the
Product or the component of the Product, whether by accident or intentionally, by persons other than Seller. To make
a claim under this Limited Warranty, you must make sure to keep a copy of your proof of purchase that clearly defines
the Date of Purchase (month and year) and the Place of Purchase. Place of Purchase must be a direct vendor of Great
Lakes Technologies, LLC. Purchasing through third party vendors, including but not limited to garage sales, pawn
shops, resale shops, or any other secondhand merchant, voids the warranty included with this product. Contact tech-
[email protected] or 1-800-232-1195 with the following information to make arrangements: your shipping
address, phone number, serial number, required part numbers, and proof of purchase. Damaged or defective parts and
products may need to be sent to WEN before the replacements can be shipped out.
Upon the confirmation of a WEN representative, your product may qualify for repairs and service work. When returning
a product for warranty service, the shipping charges must be prepaid by the purchaser. The product must be shipped
in its original container (or an equivalent), properly packed to withstand the hazards of shipment. The product must be
fully insured with a copy of the proof of purchase enclosed. There must also be a description of the problem in order
to help our repairs department diagnose and fix the issue. Repairs will be made and the product will be returned and
shipped back to the purchaser at no charge for addresses within the contiguous United States.
THIS LIMITED WARRANTY DOES NOT APPLY TO ITEMS THAT WEAR OUT FROM REGULAR USAGE OVER TIME, IN-
CLUDING BELTS, BRUSHES, BLADES, BATTERIES, ETC. ANY IMPLIED WARRANTIES SHALL BE LIMITED IN DURA-
TION TO TWO (2) YEARS FROM DATE OF PURCHASE. SOME STATES IN THE U.S. AND SOME CANADIAN PROVINCES
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY
NOT APPLY TO YOU.
IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING BUT
NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS) ARISING FROM THE SALE OR USE OF THIS PRODUCT. SOME
STATES IN THE U.S. AND SOME CANADIAN PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF IN-
CIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH
VARY FROM STATE TO STATE IN THE U.S., PROVINCE TO PROVINCE IN CANADA AND FROM COUNTRY TO COUN-
TRY.
THIS LIMITED WARRANTY APPLIES ONLY TO ITEMS SOLD WITHIN THE UNITED STATES OF AMERICA, CANADA
AND THE COMMONWEALTH OF PUERTO RICO. FOR WARRANTY COVERAGE WITHIN OTHER COUNTRIES, CONTACT
THE WEN CUSTOMER SUPPORT LINE. FOR WARRANTY PARTS OR PRODUCTS REPAIRED UNDER WARRANTY
SHIPPING TO ADDRESSES OUTSIDE OF THE CONTIGUOUS UNITED STATES, ADDITIONAL SHIPPING CHARGES MAY
APPLY.
