Wenger GEARBOSS Mobile Kiosk Electric Kit User manual

Installation Instructions
Mobi e Kiosk E ectric Kit
NOTE: Please read and understand the obile Kiosk Electric Kit Installation Instructions before
attempting installation.
NOTE: Unpack the the obile Kiosk Electric Kit from the shipping containers.
Refer to the illustrations on the following pages. If you need additional information about your
obile Kiosk Electric Kit, contact the Wenger Corporation using the information listed below or
the manufacturer.
CONTENTS
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installing the Electric Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
IMPORTANT USER INFORMATION
OPERATION
•Personnel operating the Gearboss obile Kiosk Electric Kit must read and understand these
instructions.
•Personnel operating the Gearboss obile Kiosk Electric Kit must comply with the Warnings and
Cautions in these instructions and on the equipment.
•Always observe and comply with the manufacturer’s specifications and recommendations.
INTENDED USE
•The Gearboss obile Kiosk Electric Kit is intended to be used only as described in this manual.
©Wenger Corporation 2014 Printed in USA 06/14 Part #240B122-01
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, innesota 55060-0448
Questions? Call.....USA: 1-800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com

2
SAFETY
Throughout this manual you will find Cautions and Warnings which are defined as follows.
• Warning means that failure to follow the instruction may result in serious injury or death.
•Caution means that failure to follow the instruction may result in injury or damage to property.
Read and understand the following safety instructions before using or installing any Gearboss Accessory.
GENERAL
OPERATION
Use f the M bile Ki sk
Electric Kit must always
c mply with the inf rmati n
in the “Imp rtant User
Inf rmati n” secti n f this
manual.
!CAUTION
Always bserve and c mply
with Warnings and Cauti ns
p sted in this manual and
n the equipment.
!CAUTION
Always bserve and c mply
with the manufacturer’s
specificati ns and
rec mmendati ns.
!CAUTION
Never supply AC p wer t
the M bile Ki sk Electric Kit
if the gr und is wet r if rain
is expected.
!CAUTION
If AC p wer is supplied t the
M bile Ki sk Electric Kit,
always use an utlet that has
Gr und Fault Circuit
Interrupter (GFCI) pr tecti n.
!CAUTION
Exp sing the M bile Ki sk
Electric Kit t rain r
excessive m isture c uld
result in damage.
!CAUTION
REPLACEMENT PARTS LIST
REPLACEMENT PARTS LIST
Item Qty Description Item Qty Description
1 8 ount, Cable Tie, Black 6 1 Bracket, Outlet Strip, Kiosk
2 8 Tie, Nylon, Black, 1/8” x 6” 7 1 Track, 4’, Black
3 1 Outlet Strip, 7 Receptacle 8 1 Track Light Plug, Black
4 3 Screw, S , Phillips, Pan Head,
Zinc Plated, #10 x 5/8”
9 2 Track Light Fixture, Black
5 3 Fastener, Dual Lock, Strip
3
2
16
5
4
8
7
9

3
INSTALLING THE ELECTRIC KIT
1. Install the Track (7) into the pre-drilled holes in the roof using two Pan Head Screws (4).
2. Slide the Track Light Plug (8) onto the open end of the Track.
The plug will snap into place.
3. Secure the Track Light Cord to the roof and
back panel using the Nylon Cable ounts (1)
and Nylon Ties (2).
Track
Pan Head Screw
Track Light
P ug
Track Light
Cord
Ny on Cab e
Mount
Ny on Tie

4
INSTALLING THE ELECTRIC KIT
4. Install the two Track Light Fixtures (9) into the Track
(see Track Light Instructions).
5. Apply a piece of Dual Lock Fasterner Strip (5) to the front side of the
Outlet Strip Bracket (6) and the back side of the Outlet Strip (3).
a. Rotate the Outlet Strip Bracket back slightly to fit into the Slatwall Extrusion.
Slatwall Extrusions are located on the inside of the Back Panel and Side Doors.
b. Let the Outlet Strip Bracket drop down to be flush with the panel surface.
c. Press the Outlet Strip onto the Outlet Strip Bracket.
d. Avoid pinching the cords in the obile Kiosk.
Out et Strip
Bracket
Out et Strip
Fastener Strip
