Operating Instructions
Automatic sauna splash system
Type Sauna Plus 8 Basic

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 2 of 36
Table of contents
1 About these instructions / general......................................................................................................... 4
1.1 Scope of applicability.................................................................................................................................4
1.2 Target group ..............................................................................................................................................4
1.3 Symbols used.............................................................................................................................................4
1.4 Warranty.................................................................................................................................................... 5
1.5 Further information...................................................................................................................................5
2 Safety...................................................................................................................................................... 6
2.1 Intended use.............................................................................................................................................. 6
2.2 Safety notices ............................................................................................................................................ 6
2.2.1 Handling of chemicals, risks to humans and the environment ................................................................. 6
2.2.2 Protective measures and rules of conduct ................................................................................................7
3 Product description - scope of delivery.................................................................................................. 8
3.1 Scope of delivery/accessories.................................................................................................................... 8
3.2 Product description ................................................................................................................................... 8
3.2.1 The dosing unit .......................................................................................................................................... 9
3.2.2 Control unit.............................................................................................................................................. 10
3.2.3 Piping and fittings....................................................................................................................................10
3.2.4 Oven shower head (series) ......................................................................................................................10
3.2.5 Wall bushing (option) ..............................................................................................................................10
3.2.6 Extension (option) ...................................................................................................................................10
3.2.7 Safety combination pipe separator/system separator............................................................................ 11
3.2.8 Connection set (option)........................................................................................................................... 11
3.3 Identification of the device/identification plate......................................................................................11
3.4 Technical data..........................................................................................................................................12
3.5 Transport/storage.................................................................................................................................... 12
4 Installation............................................................................................................................................ 13
4.1 Select the installation site .......................................................................................................................13
4.2 Installation instructions (assembly suggestion).......................................................................................13
4.3 Mechanical installation............................................................................................................................14
4.4 Hydraulic installation...............................................................................................................................15
4.5 Electrical installation................................................................................................................................16
5 Commissioning ..................................................................................................................................... 17
5.1 Commissioning –remarks .......................................................................................................................17
5.2 Commissioning works.............................................................................................................................. 17
6 Operation/service................................................................................................................................. 19
6.1 General ....................................................................................................................................................19
6.2 Control unit - software ............................................................................................................................19
6.2.1 Flow charts of the control unit ................................................................................................................20
6.3 The menu.................................................................................................................................................21
6.3.1 Operation modes..................................................................................................................................... 21
6.3.2 Pause time/Locking time .........................................................................................................................22
6.3.3 Water quantity ........................................................................................................................................22
6.3.4 Fragrance quantity................................................................................................................................... 22
6.3.5 Switch-on delay .......................................................................................................................................22
6.3.6 Pump test ................................................................................................................................................22
6.3.7 MV test ....................................................................................................................................................23
6.3.8 Pressure test............................................................................................................................................ 23
6.3.9 Splash test................................................................................................................................................ 23
6.3.10 Contrast ...................................................................................................................................................23
6.3.11 Language.................................................................................................................................................. 23
6.3.12 Info........................................................................................................................................................... 23
6.4 Replenish consumables ...........................................................................................................................23
7 Maintenance, care, faults..................................................................................................................... 24
7.1 Device maintenance ................................................................................................................................ 24
7.1.1 Check/change hose kit............................................................................................................................. 24
7.1.2 Checking dosing valve..............................................................................................................................25

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 3 of 36
7.1.3 Clean oven shower head ......................................................................................................................... 25
7.1.4 Clean the dirt filter .................................................................................................................................. 25
7.2 Regular water check ................................................................................................................................ 25
7.3 Fault removal........................................................................................................................................... 26
8 Decommissioning –Storage –Disposal.................................................................................................28
8.1 General.................................................................................................................................................... 28
8.2 Decommissioning .................................................................................................................................... 28
9 Documents ............................................................................................................................................29
9.1 Declaration of conformity ....................................................................................................................... 29
9.2 Wiring Diagram ....................................................................................................................................... 30
9.3 Commissioning protocol / instruction..................................................................................................... 31
9.4 Operation data sheet .............................................................................................................................. 32
9.5 Maintenance protocol............................................................................................................................. 34
9.6 Spare parts list, wear parts list, list of consumables ............................................................................... 35
10 Appendices............................................................................................................................................36
Imprint:
All rights reserved
© Copyright by WDT –Werner Dosiertechnik GmbH & Co KG
Edition: see footer
Reproduction of any kind and translation into other languages, even in excerpts, is only permitted with the express
authorisation of the company WDT - Werner Dosiertechnik GmbH & Co. KG.
These operating instructions are an English translation of the original German version by the company WDT.
Responsible for the content:
Co. WDT - Werner Dosiertechnik GmbH & Co. KG
Hettlinger Str. 17
D-86637 Wertingen - Geratshofen
Phone: [phone] / 9 86 97 –0
Fax: [phone]
Email: [e-mail]

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 4 of 36
1About these instructions / general
1.1 Scope of applicability
These instructions describe the functioning, installation, commissioning and operation of the SAUNA PLUS
8 Basic automatic sauna splash system along with the corresponding accessories.
The Operating Instructions must be read carefully prior to use or any maintenance work, and must be
kept in close proximity to the device!
1.2 Target group
Only our authorised partners and persons who have been trained in the functioning of the device are
permitted to work on the system, provided that they have read and understood these operating instruc-
tions.
Electrical connection work may only be carried out by appropriately trained specialists!
1.3 Symbols used
This document uses the following types of safety notices as well as general notices:
DANGER!
“DANGER” denotes a safety notice which, if disregarded, may lead to death or serious
personal injury!
CAUTION!
“CAUTION” denotes a safety notice which, if disregarded, may lead to minor or mod-
erate personal injury!
ESD SENSITIVE!
“ESD SENSITIVE” denotes electronic components that may be damaged by electro-
static discharges. The generally accepted safety precautions for ESD-sensitive devices
must be observed when handling the devices!
ATTENTION!
“ATTENTION” denotes a safety notice which, if disregarded, may lead to material dam-
age or malfunctions!
HIGHLY FLAMMABLE!
"HIGHLY FLAMMABLE" denotes substances with a low flashpoint, under 21°C.
NOTICE!
A notice denotes information which, if disregarded, may lead to malfunctions.
Tip!
A tip denotes information that may result in improvements in the operating process.

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 5 of 36
1.4 Warranty
All devices and systems of the Co. WDT are manufactured using state-of-the-art manufacturing methods
and are subject to a comprehensive quality control. However, should there be a reason for complaint, any
compensation claims shall be directed to the company WDT in accordance with the general terms and
conditions of warranty (see below).
General terms and conditions of warranty
The company WDT assumes a 2-year warranty, starting with the commissioning, up to 27 months after
delivery; subject to correct installation and commissioning with a completed and signed commissioning
protocol.
Exempt from this are wear parts such as seals, hoses, diaphragms, dosing screws, electrodes, roller carri-
ers and other parts that are subject to mechanical or chemical wear and tear. For these we assume a
warranty of 1/2 year.
Our merchandise management programme requires an invoice for each delivery (including warranty ser-
vices). When returning a defective component, upon review you will receive a corresponding credit, if
applicable. We request a return within 14 days.
The costs for subsequent damage and for the processing of warranty claims are excluded.
There are no warranty claims for damage caused by frost, water and electrical overvoltage or by improper
handling.
Tip!
In order to protect the warranty claims, please mail the completed commissioning pro-
tocol, along with the defective component, to the company WDT. Without the com-
missioning protocol, we reserve the right to assert a warranty regulation.
ATTENTION!
It is not permitted to make any modifications to the device. If this specification is not
observed, the warranty obligation and product liability will expire!
1.5 Further information
Further information about special topics, e.g., description of the operating parameters, as well as addi-
tional support is available from your specialist dealer.

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 6 of 36
2Safety
2.1 Intended use
The automatic sauna splash system type PLUS 8 Basic may only be used for the purposes indicated in
Chapter 3.2, Product description! Also pay attention to the locally applicable regulations concerning acci-
dent prevention, occupational safety and drinking water protection!
2.2 Safety notices
Carefully read and pay attention to the operating instructions prior to installation and use of the device!
Work on the device and changes in the settings may only be carried out by properly trained and instructed
persons! It is of particular importance to comply with the rules for occupational safety and accident pre-
vention and to wear protective clothing.
Pay attention to the warning notices on the device
2.2.1 Handling of chemicals, risks to humans and the environment
Important information concerning the handling of chemicals and fragrances can be
found in the safety data sheets provided by the fragrance manufacturers!
With the automatic sauna splash system, a fragrance is added to the water and dosed on the sauna heater.
The fragrance concentration in the water is so low that there is no danger for people.
DANGER! IRRITATION!
The undiluted fragrances may cause irritation and allergic reactions.
HIGHLY FLAMMABLE!
The undiluted fragrances may be highly flammable. This may cause injuries and pose
a danger to personnel and the environment. For this reason, the greatest possible care
must be taken during all work!
CAUTION!
In high concentrations, the fragrances may be harmful to health!
In the event of an emergency when handling chemicals, you can contact the
Emergency Poison Centre!
Emergency number:
Munich Emergency Poison Centre (or any other Poison Centre)
Phone: [phone]
Each time the fragrance is refilled,
check the pump's dosing hose and
renew it, if necessary.
(see Operating Instructions)

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 7 of 36
2.2.2 Protective measures and rules of conduct
CAUTION!
The automatic sauna splash system is supplied with water from the drinking water
network.
The safety combination integrated in the device is a safety device in accordance with
DIN EN 1717 (Germany and EU) for non-toxic liquids with free outlet, for the protec-
tion of the water network. For this purpose, the splash line from the device to the
oven shower head must be laid in such a way that the line can drain itself (at a decline,
without water trap, without non-return valve).
If the splash line cannot drain (e.g., installed at an incline, or water trap in the line), a
system separation unit in accordance with DIN EN 1717 for non-toxic liquids without
free outlet must be installed in the inlet of the automatic sauna splash system. In ad-
dition, a sauna splash connection set must be used. The connection set is available in
the following lengths: 5 m, 10 m, 15 m, 20 m
Pay attention to the locally applicable regulations!
ATTENTION!
It is not permitted to make any modifications to the device. If this specification is not
observed, the warranty obligation and product liability will expire!

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 8 of 36
3Product description - scope of delivery
3.1 Scope of delivery/accessories
The automatic sauna splash system type Plus 8 Basic essentially consists of the following components:
Micro-processor controller NT 35-R + HMI
Peristaltic pump SA-Vi for fragrance concentrate
Mounting plate with console for fragrance container
Inlet with ball valve ½” IG
Fine sieve 0.3 mm MS
Safety combination/pipe aerator in accordance with DIN EN1717 for draining splash line
1 Solenoid valve VA ¼”
Pressure monitoring
Dosing pipe with dosing valve 3/8” VA
Outflow 3/8” IG
Splash shower head: Perforated pipe with interior thread 3/8”
The following optional accessories are available:
1. Wall bushing sauna VA for oven shower head: Item No.: 15214
2. Special versions of the wall bushing on request
3. Special versions of the splash shower head on request
4. Extension for oven shower head 3/8”, various lengths
5. Sauna splash connection set, comprising:
a) PTFE hose 6x1 mm, (5 m Item no. 20101-1; 10 m Item no. 20101; 15 m Item no. 20101-2; 20 m
Item no. 20101-3)
b) Hose connection automatic splash system 3/8” AG x6x1 mm
c) Hose connection wall bushing 3/8” IG x6x1 mm
d) 3/8” bracket IG AG
6. Button plate made of wood, incl. illuminated push button for operation in the cabin
7. System separation unit ½” for automatic sauna splash system (for non-draining splash line), Item no.:
24321
8. Hose connection Ms nickel-plated 3/8” IG for PTFE hose 6x1 mm, Item no.: 19282
3.2 Product description
The automatic sauna splash system Sauna Plus 8 Basic is a dosing system for a fully automated splash on
the sauna heater. During the splash, a fragrance is automatically dosed into the splash water.
The pause time, the quantity of water (= splash quantity) and the fragrance quantity (= scent intensity)
can be set individually via the control unit.
The device can be operated via an internal cyclic programme or via an optional push button. The splash
system can also be activated externally via the “button input”.
Function
For a splash, the solenoid valve (4) opens and the splash water flows to the sauna heater. The water is
backed up at the washer installed downstream of the pressure switch (5), leading to a pressure build-up.
Once the pressure rises above 1.2 barg, fragrance dosing is released. The dosing pump (10) doses the set
fragrance quantity from the fragrance container (16) via the dosing valve (7) into the water that is flowing
toward the sauna heater. The splash occurs. At the end of the splash, the solenoid valve closes again. The
pressure switch monitors the pressure reduction in the splash line, which must take place within 3 seconds
after the solenoid valve closes.
If the pressure of 1.2 barg is not reached, or the pressure drops during splash, the message “Water pres-
sure fault” appears, a safety shutdown for the fragrance takes place and the solenoid valve remains open
(see Chapter 7.3, Fault removal). This ensures that the fragrance concentrate can only be dosed when the

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 9 of 36
necessary water pressure is present in the device. This is important because no undiluted fragrance con-
centrate must get onto the sauna heater. This can be flammable!
The built-in safety combination (3) in accordance with DIN EN 1717 (non-return valve + aerator) addition-
ally ensures that no splash water can be sucked back into the piping network in the event of a pressure
drop. The safety combination (3) is preceded by a dirt filter (8) and a ½” shut-off ball valve (9).
ATTENTION!
To avoid dosing on the cold heater, the automatic sauna splash system must be inter-
locked with the sauna control unit on site! If the internal switch-on delay (adjustable)
is activated, it prevents the first splash after the mains connection. If needed, this
switch-on delay can be deactivated.
Overview automatic sauna splash system dosing type: Sauna Plus 8 Basic
Key
1. Display with 3 operating buttons
2. Control housing
3. Safety combination in accordance with
DIN EN 1717(non-return valve + aera-
tor)
4. Solenoid valve
5. Pressure switch
6. Pipe bracket
7. Fragrance dosing valve
8. Dirt filter
9. Shut-off ball valve
10. Peristaltic pump
11. Mounting plate
12. Power socket for push button
13. Fragrance pressure line
14. Fragrance suction line
15. Warning notices
16. Fragrance container
17. Console for fragrance container
18. Earth connection
24. Main switch (covered, see Figure 17,
Control unit with display)
3.2.1 The dosing unit
Fragrance dosing is performed using a peristaltic pump, which can also
reliably transport the smallest dosing quantities, even when air or gas
bubbles are trapped in the suction line. The rotating rollers press the dos-
ing hose against the wall, which pushes the liquid in the hose out in front
of the rollers while simultaneously sucking more liquid in behind them. It
is exceptionally reliable and also very easy to operate.
Fragrance concentrations may be exceptionally aggressive. The dosing
hose used is resistant to most commercially available concentrates.
Figure 2, Peristaltic pump
function
Figure 1, Automatic splash system Sauna Plus 8 Basic
10
4
3
2
1
5
7
6
8
9
11
13
12
24
16
18
17
15
14

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 10 of 36
The installation of a combined spring-loaded non-return and dosing valve
reliably prevents water from being pushed back or the dosing line from
draining. The valve body is completely made of stainless steel, hose con-
nection 4x1 mm (angular shape) - thread 3/8” AG.
The opening pressure is 0.69 barg.
ATTENTION!
The composition of fragrances varies. This may reduce the service life of the hose in
the fragrance pumps. The fragrance pump must therefore be checked regularly in ac-
cordance with the maintenance schedule, and each time the fragrance is refilled.
3.2.2 Control unit
The control unit consists of a housing with protection class IP44. The electronic components are installed
in the housing. The operating parameters can be set at the control unit.
3.2.3 Piping and fittings
The piping of the automatic sauna splash system consists of a shut-off ball valve (9), a dirt filter (8) and a
safety combination (3), which complies with the DIN EN 1717 regulation when the splash line is draining,
so that no water can be sucked back into the water supply. Furthermore, the piping consists of a shut-off
solenoid valve (4), the splash pipe with integrated washer, a pressure switch (5) for pressure monitoring
and the dosing valve.
3.2.4 Oven shower head (series)
The standard scope of delivery includes a oven shower head consisting
of a stainless steel pipe d 18x200 mm with drill holes that distribute the
water over the heater stones. The oven shower head has a 3/8” interior
thread connection.
3.2.5 Wall bushing (option)
For the installation and secure fastening of the oven shower head, we
offer different wall bushings with 3/8” AG thread connection made of
stainless steel; see Chapter 3.1 Scope of delivery/accessories.
Standard dimensions:
Length before the flange: 190 mm
Length behind the flange: 90 mm
Flange diameter: 60 mm
Other dimensions on request, special versions are possible
3.2.6 Extension (option)
For the installation and secure fastening of the oven shower head, we
offer different extensions with 3/8” x120mm IG-AG thread connection
made of stainless steel; see Chapter 3.1 Scope of delivery/accessories.
Figure 3, Non-return and dos-
ing valve
Figure 4, Oven shower head (se-
ries)
Figure 5, Example of a wall bush-
ing for the oven shower head
Figure 6, Extension

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 11 of 36
3.2.7 Safety combination pipe separator/system separator
Safety combination (3) in accordance with DIN EN 1717 (non-return
valve + aerator)
3.2.8 Connection set (option)
The sauna splash connection set for connecting the automatic sauna
splash system to the wall bushing.
The connection set is available with various hose lengths:
5 m Item no. 20101-1
10 m Item no. 20101
15 m Item no. 20101-2
20 m Item no. 20101-3
3.3 Identification of the device/identification plate
Enter the data from your device’s identification plate here.
Field 1: Enter serial number
Field 2: Enter date of manufacturing
Figure 9, Identification plate
Figure 7, Safety combination
Figure 8, Connection set

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 12 of 36
3.4 Technical data
Sauna Plus 8 Basic
Dimensions and weights:
External dimensions
0.70x0.40x0.23 m; HxWxD
Space requirement
0.90x0.50x0.30 m; HxWxD
Space requirement, including operation and maintenance
2.00x0.60x1.00 m; HxWxD
Empty weight/operating weight
10 kg/15 kg
Connection data
Water inlet
1/2” IG (up to 2.5 l/min)
Splash line outflow
3/8” IG
Oven shower head connection
3/8” IG
Electrical connection
230 VAC/50 Hz, 50 W, safety plug
Fuse F500
2A slow, D8, 3x8
Nominal pressure/operating pressure (flow pressure)
1.5-6 barg/1.5-6 barg
Operating data:
Splash water at 4 barg flow pressure
max. 1200 ml per splash at 100%
Fragrance
max. 24 ml per splash at 100%
Cycle time/pause time
1-90 minutes
Fragrance pump
24 VDC
Solenoid valves
1/4” IG, 230 VAC
Control unit for automatic splash system
230V AC
Medium temperature
5-30°C
Ambient temperature technical room
5-30°C
Humidity technical room
max. 70%
Ventilation (in and out)
Recommended in the technical room
Software version
V 2.1
Hardware version
NT 35-R + HMI
3.5 Transport/storage
Please check the device immediately upon receipt for potential transport damage.
ATTENTION!
The device may be damaged by frost or high temperatures. Avoid exposure to frost
during transport and storage! Do not store systems and devices next to objects with
strong heat emission or in direct sunlight. The device may only be transported and
stored in its original packaging. Please ensure careful handling.
For transport and storage purposes, the roller carrier of the dosing pump is not mounted. This prevents
the hose from becoming deformed.
Storage of fragrances/chemicals
DANGER!
The safety data sheets provided by the fragrance manufacturer must be observed dur-
ing storage!
These are some of the points that must be observed:
The fragrances must only be stored in the appropriately identified original plastic containers.
Larger quantities of fragrances must be stored in a separate storage room.
The ambient temperature must not exceed 20°C.
See also Chapter 2.2.1 Handling of chemicals.
ATTENTION!
Pay attention to the locally applicable regulations for handling chemicals!

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 13 of 36
4Installation
The tasks described here must only be performed by appropriately qualified personnel from a specialist
company.
4.1 Select the installation site
The installation site must have the following properties:
1. The installation site must be frost-proof.
2. The system must be protected from direct sunlight.
3. An electrical power connection with a safety contact is required.
4. It is recommended that the storage space be well aerated and ventilated.
5. A waste water connection must be available. (Only necessary for version with system separation)
4.2 Installation instructions (assembly suggestion)
The automatic sauna splash system is installed on a wall in the technical room. The line to the sauna
heater should be as short as possible. Pay attention to the space required for operation and maintenance
of the device, see Chapter 3.4 Technical data.
Warning and information notices must be installed in compliance with locally applicable accident pre-
vention regulations at the locations provided!
Installation plan, draining splash line
Figure 10, Installation plan 1
Technical room
Cabin
Cabin wall
Oven
shower
head
Sauna
heate
r
Gradient: 1 cm per
1 m line length
Inlet

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 14 of 36
Installation plan, non-draining splash line
4.3 Mechanical installation
Installing dosing device
With the exception of the roller carrier, the SAUNA PLUS 8 Basic dosing device is delivered ready for op-
eration. It should be installed in an easily accessible location.
The splash line to the oven shower head must be installed with a gradient of at least 1 cm per 1 m of
line length! The oven shower head, in turn, must be mounted approx. 10-15 cm above the sauna heater.
Securely attach the mounting plate on the wall with 4 screws and ensure easy accessibility.
Install wall bushing for oven shower head (option)
Tip!
For the installation and secure fastening of the oven shower head, a wall bushing with
two 3/8” AG thread connections made of stainless steel is available (see Chapter
3.2.5).
Drill a hole of approx. 18 mm in the sauna wall approx. 10-15 cm above the heater, then insert the wall
bracket with the rosette from the inside. The rosette is attached to the sauna wall with the V4A screws
supplied.
NOTICE! Underbench heaters
If the automatic sauna splash system is connected to an underbench heater, make sure
that it is professionally connected to the connection pipe prepared on the heater side!
Please pay attention to any specifications by the heater manufacturer.
Figure 11, Installation plan 2
Technical room
Cabin
Oven
shower
head
Sauna
heate
r
Cabin wall
Inlet

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 15 of 36
4.4 Hydraulic installation
ATTENTION!
Rinse the supply line to the automatic splash system and then connect the automatic
splash system's inlet to the supply line.
Splash line to the oven shower head/wall bushing
There are 2 different variants for connecting the splash line to the oven shower head:
Variant a: The splash line is installed in such a way that it can drain completely.
Variant b: The splash line is installed in such a way that it cannot drain completely (e.g., water trap, in-
stalled at an incline).
For variant a) The line can drain
Use a pipe with a maximum interior diameter of 13 mm.
ATTENTION!
If the splash line drains on its own, the safety combination installed as a standard ac-
cording to DIN EN 1717 (for Germany and EU) is sufficient for non-toxic liquids with
free outlet.
Connection of the splash line 3/8” interior thread to the wall bushing (option) 3/8” AG. Screw the oven
shower head hand-tight onto the wall bushing. Only use Teflon tape for sealing to keep the shower head
cleaning as simple as possible.
For variant b The line cannot drain
DANGER!
If the splash line cannot drain (e.g., installed at an incline, or water trap in the line), an
additional system separation unit in accordance with DIN EN 1717 (for Germany and
the EU) for non-toxic liquids without free outlet must be installed in the inlet of the
automatic sauna splash system. This prevents any fragrance from being sucked back
into the drinking water line! (see Chapter 3.1 Scope of delivery/accessories)
Use a pipe or hose with a maximum interior diameter of 6 mm.
Connection of the splash line 3/8” interior thread to the wall bushing (option) 3/8” AG. Screw the oven
shower head hand-tight onto the wall bushing. Only use Teflon tape for sealing to keep the shower head
cleaning as simple as possible.
ATTENTION!
For non-draining splash line only use the WDT connection set!
The optional sauna splash connection set from WDT is used to connect the automatic
sauna splash system to the wall bushing.

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 16 of 36
4.5 Electrical installation
DANGER DUE TO ELECTRICAL VOLTAGE!
Electrical installation must only be carried out by appropriately qualified personnel!
Before any electrical work is carried out, the automatic sauna splash system must be
switched off and secured against being reactivated!
Connect the earth connection (Pos 18 ) to the on-site earthing cable.
Open/close the housing
Unlock the locking knob with a screwdriver
Press down on both recessed grips until the housing snaps open. Ro-
tate the cover to the side.
To close the housing, follow the procedure in reverse sequence
ATTENTION!
Connect the automatic sauna splash system to the sauna control unit so that the au-
tomatic splash system is only supplied with power when the sauna heater is turned
on. If fragrance collects on the cold sauna heater, the fragrance may ignite during heat-
ing.
Figure 12, Open control housing

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 17 of 36
5Commissioning
5.1 Commissioning –remarks
The tasks described here must only be performed by appropriately qualified personnel from a specialist
company. Alternatively, the work can be carried out by persons who have read and understood the entire
Operating Instructions. Prior to commissioning, the installed systems must be checked for proper instal-
lation and leaks.
Please use the commissioning protocol from Chapter 9.3 for commissioning.
The device comes loaded with ex works settings. During the commissioning, adjust the control parameters
to the desired operating mode and enter them in the operation data sheet in Chapter 9.4.
5.2 Commissioning works
Filling and starting the automatic sauna splash system
1. Please ensure that the device has been correctly installed and connected.
2. Unscrew the cover of the fragrance delivery container and drill a hole with a diameter of 7 mm in
the cover. Screw the cover back on and place the delivery container on the console of the auto-
matic sauna splash system.
3. Secure the fragrance container with the Velcro tape.
CAUTION!
The console is designed for loads up to 5 kg. If this load is exceeded, place the fragrance
containers on a separate shelf.
Most fragrances are highly flammable!
4. Connect the fragrance container to the fragrance pump. Push the suction hose so far into the con-
tainer that the end of the suction hose comes into contact with the container base.
Insert the roller carrier at the fragrance pump
1. Remove the clipped-in, transparent pump cover and the safety disc (32). Pull the hose bracket (33)
out of the guide in the housing. (During initial commissioning, the parts are not installed, but can be
found in the accessory bag)
Key
31. Transparent pump cover (not shown)
32. Safety disc
33. Hose bracket with dosing hose made of Viton (hose kit)
34. Roller carrier (not visible)
35. Pump casing
41. Suction connection
42. Pressure connection
Figure 13, Peristaltic pump
32
35
34
33
41
42

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 18 of 36
2. Push the yellow roller carrier onto the axle.
3. Insert the hose bracket into the housing's guides until it firmly snaps
into place.
4. Turn the roller carrier clockwise while carefully pushing the hose into
the housing until the entire hose is contained in the housing.
Now replace the safety disc and the transparent pump cover. This com-
pletes the installation of the roller carrier.
For dismantling the roller carrier and the hose bracket, please proceed in the reverse sequence.
Plug the safety plug in a corresponding power socket and turn on the device at the main switch.
If the switch-on delay is activated, the first splash can be delayed between 0-120 minutes after switching
on the voltage. This prevents the splash from being made on the cold sauna heater. After that, the
splashes take place according to the set cycle or after a push button prompt.
Ensure that all installation tasks have been completed. Observe the sequence of the commissioning works.
The device is now ready for operation.
Figure 14,
Insert roller carrier
Figure 15,
Insert the hose bracket
Figure 16,
Turn the roller carrier

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 19 of 36
6Operation/service
6.1 General
The tasks described here may only be carried out by appropriately trained and instructed personnel. Al-
ternatively, the work may be done by operating personnel who have read and understood the entire op-
erating instructions.
Once all preparations for the commissioning have been completed, the operation can be started. Turn on
the device at the main switch (unless this has already been done).
6.2 Control unit - software
The automatic sauna splash system is operated via the control unit on the front of the device.
Pressing any key switches the display to the main menu.
ATTENTION!
A splash cycle only starts when the display shows the start display. If the sub-menus
are displayed, the splash cycle is blocked.
Use the 3 operating buttons to navigate in the menu.
The control unit's main menu is simply structured and easy to operate. It consists of an operating level
with the following menu items:
1. Pause time (with cyclic operation)/locking time (with but-
ton operation)
2. Water quantity
3. Fragrance quantity
4. Operation mode
5. Switch-on delay
6. Pump test
7. MV test
8. Pressure test
9. Splash test
10. Contrast
11. Language
12. Info
A start button can be plugged in at
the control housing.
Overview control unit
Key
22. Display
23. 3 operating buttons for operation
24. Main switch
25. Dosing pump
Operating the display
The device is operated via 3 operating buttons next to the display.
Use the arrow keys to navigate up or down or to set numerical values.
Use the Enter key to navigate to the selected sub-menu and back.
Figure 18, Display operation
Figure 17, Control unit with display
22
23
24
25

Automatic sauna splash system, type Sauna Plus 8 Basic
Index: 02 Date modified: 22/02/2022 OI No.: BA DW 010-02 Sauna Plus 8 Basic EN.docx Page 20 of 36
6.2.1 Flow charts of the control unit
Example with start by means of Cyclic operation operation mode
Example with start by means of Button operation operation mode delivery state SL 6/1+3
Example with start by means of Button operation operation mode option SL 6/4+6
Figure 19, Flow chart button operation SL 6/1+3
Voltage circuit entering
switch on delay
Push button activation Splash
Blocking time
wait for push button activation
Push button activation Splash
Blocking time
wait for push button activation
Push button activation Splash
Blocking time
wait for push button activation
Push button activation Splash
Blocking time
wait for push button activation
Push button activation Splash
Blocking time
wait for push button activation
Push button activation Splash
Blocking time
Voltage circuit switiching off
Solenoid valve splash
Schema Sauna Plus 8 Basic = button mode menu
Delivery status, button illumination on SL 6/1+3
Button illumination 100%
Button illumination dimmed
Frangrance pump
Figure 20, Flow chart cyclic operation
In the Cyclic operation operation mode, an additional splash can be called up via a connected push button. After a push button prompt, the pause
time starts from the beginning.
Figure 21, Flow chart button operation SL 6/4+6
Voltage circuit entering
switch on delay
Push button activation Splash
Blocking time
wait for push button activation
Push button activation Splash
Blocking time
wait for push button activation
Push button activation Splash
Blocking time
wait for push button activation
Push button activation Splash
Blocking time
wait for push button activation
Push button activation Splash
Blocking time
wait for push button activation
Push button activation Splash
Blocking time
Voltage circuit switiching off
Schema Sauna Plus 8 Basic = button mode menu
Option, button illumination on SL 6/4+6
Solenoid valve splash
Frangrance pump
Button illumination 100%
Button illumination dimmed
