DL-HD2A-RX Quick Install Guide
This guide is for quick installaon only.
For complete owners manual go to www.libav.com or use a QR reader to access the
manual via QR code below.
Scan QR Code with your Smart-phone or Tablet

DL-HD2A-RX Quick Guide
2
The DigitaLinx DL-HD2A-RX is an HDBaseT 2.0 receiver designed to work with the DL-1H1V1U-WP-W,
DL-3H1U-WP-W and the DL-2H1V1U-WP-W wall plate transmier (sold separately). The DL-HD2A-RX
will reliably extend HDMI or VGA video, mulchannel audio, USB 2.0 High Speed and RS232 up to
100m / 330’. The receiver is also 4K compable with a max resoluon of 4K@60Hz / 4:2:0 8bit deep
color. With an integrated PSE module built in, the DL-HD2A-RX can power the compable HDBT 2.0
transmiers via HDBaseT transmission. There are two 3.5mm analog audio outputs on the DL-HD2A-
RX, one that de-embeds 2 channel stereo audio from the embedded HDMI stream from the selected
HDMI input on the wall plate transmier and one for the isolated and dedicated analog audio signal
from the HDBT 2.0 wall plate as well.
The DL-HD2A-RX is ideal for situaons where USB must be extended alongside HDMI or VGA for display
interacvity for items such as interacve whiteboards or projectors.
NOTE: The DL-HD2A-RX HDBaseT receiver can be used with the DL-1H1V1U-WP-W, DL-3H1U-WP-W or
the DL-2H1V1U-WP-W HDBaseT 2.0 transmier (sold separately) to complete the circuit.
Product Overview
Package Contents
• DL-HD2A-RX HDBaseT Receiver
• (1) Quick Install Guide
• (1) 3 pin Phoenix Male Connector
• (1) DC12V Power Supply with US, UK, EU and AU adapter plugs
• (2) Mounng Brackets

DL-HD2A-RX Quick Guide
3
Front / Back Panel View
1. DC12V Power Input
2. HDBaseT Input
3. RS232 Pass Through
4. HDMI Output
5. Audio Out
• De-embed - De-embeds the embedded HDMI 2 channel stereo audio stream from selected
HDMI input from the connected HDBaseT 2.0 transmier
• Pass Through - Passes through the analog 2 channel stereo audio signal from analog 3.5mm
input from the connected HDBaseT 2.0 transmier
6. USB Device Hub
7. Power LED
• When ON; The receiver is powered on
• When OFF; The receiver is powered o
8. Status LED
• When BLINKING SLOWLY; The receiver is working properly
• When OFF; The receiver is not working properly
9. HDCP LED
• When ON; HDCP protected content is being transmied
• When BLINKING; Non-HDCP protected content is being transmied
• When OFF; No content is being transmied
10. Link LED
• When ON; HDBaseT link is working properly
• When BLINKING or OFF; HDBaseT transmission is abnormal or no link
1 2 3 4 5 6
7 8 9 10

DL-HD2A-RX Quick Guide
4
Connecvity Instrucons
1. Verify all components included with the extender set are present before installaon.
2. Turn o power and disconnect the audio/video equipment by following the manufacturer’s
instrucons.
3. Connect Category 6 or greater twisted pair cable with RJ45 connectors between the
transmier (DL-1H1V1U-WP-W, DL-3H1U-WP-W or the DL-2H1V1U-WP-W sold separately) and the
DL-HD2A-RX receivers HDBaseT ports. TIA/EIA-568B straight-through wiring connecons must be used
with all HDBaseT extenders.
4. Connect an HDMI cable between the display device and the DL-HD2A-RX receiver.
5. Connect USB cables between the USB hub to USB devices (oponal).
6. Connect an RS232 cable between the DL-HD2A-RX and the RS232 port of a display device (oponal).
7. Connect the power supply adapter to the DL-HD2A-RX receiver locking input port and plug into an
AC outlet.
8. Power on aached audio/video and USB devices.

DL-HD2A-RX Quick Guide
5
Cabling Wiring Requirements
Twisted Pair Wiring
Use TIA/EIA-568B wiring for Category 6
connecon between send and receive
units.
HDBaseT Cabling
To ensure proper performance of the DL-HD2A-RX, it is recommended that you use solid
core, shielded Category 6 F/UTP cabling at a minimum. Category 5e F/UTP may perform
well but may not support power over HDBaseT reliably over longer distances.
For opmized HDBaseT performance use the following Liberty Wire and Cable branded
cabling;
Category 6 plenum; 24-4P-P-L6SH
Category 6A plenum; 24-4P-P-L6ASH
Category 6 NON-plenum; 24-4P-L6SH
Category 6A NON -plenum; 24-4P-L6ASH
When using shielded category cabling ALWAYS...
....use shielded connectors
....properly ground the category cable
RS232 Wiring
Connect the display device RX signal to TX
on the DL-HD2A-RX extender. Connect
the display device TX signal to RX on the
DL-HD2A-RX extender.
TX G RX
RX G TX
DL-HD2A-RX
RS232 PORT
DISPLAY
RS232
PINOUT
Connecng to
TV Display

DL-HD2A-RX Quick Guide
6
Technical Specicaons
Video
Video Inputs (1) HDBaseT
Video Input Connector (1) RJ45
Output Video Signal HDMI
Input / Output Resoluons
Supported
VESA: 1920 x 1200@60; 1680 x 1050@60; 1600 x 1200@60; 1600
x 900@60; 1440 x 990@60; 1366 x 768@60; 1360 x 768; 1280 x
1024@60; 1280 x 960@60; 1024 x 768@60; 800 x 600@60
SMPTE: 4096 x 2160@24/25/30/50/60 YUV4:2:0; 3840 x
2160@ 24/25/30/50/60 YUV 4:2:0; 1920x1080@30/60; 1280
x720@50/60; 720 x 576@50; 720 x 480@60
Standards Compliant with HDMI 2.0 & HDCP2.2
USB
Supported USB Standard Up to USB 2.0 High Speed up to 190Mbps
USB Port Type (4) USB A
Audio
Supported audio formats HDMI: PCM 2.0, LPCM 5.1, LPCM 7.1, Dolby TrueHD, DTS-HD Mas-
ter Audio
Unbalanced 3.5.mm: 2 Channel Stereo
Control
RS232 Up to 115200 baud rate
RS232 Port Type 3 pin phoenix
General
System Bandwidth 10.2Gbps
Transmission Distance 100m or less when using Cat6A F/UTP, 70m or less when using
Cat6 F/UTP
Operang Temperature 0 ~ +45 C (32 F to +113 F)
Storage Temperature -20 - +70 C (-4 - +158 F)
Humidity 10% ~ 90%
Power Supply DC12V
Power Consumpon 8 was (maximum)
Dimension (W*H*D) 210mm*25mm*90mm / 8.2”*1”*3.5”
Weight 0.46kg, 1lbs
Warranty 5 years
Cercaon CE, FCC, RoHS

Thank you for your purchase.
For Technical Support please call our toll free number at
800-530-8998 or email us at supportlibav@libav.com
www.libav.com
