Westermann Cleanmeleon 2 PRO User manual

1
Cleanmeleon 2 PRO
agile | powerful | exible to use
Operating instruction

2
Table of contents
1 EC Declaration of Conformity........................................................... 5
2 Legal information......................................................................... 7
3 Important basic information ............................................................ 8
3.1 Scope of supply.................................................................. 8
3.2 Conventions...................................................................... 9
3.2.1 Symbols and signal words ............................................. 9
3.2.2 Pictogram overview.................................................. 10
3.3 Marking on the machine ..................................................... 11
3.4 Ordering spare parts.......................................................... 11
4 Safety.............. ....................................................................... 12
4.1 Intended use of the machine................................................ 12
4.2 Machine naming information ................................................ 12
4.3 Requirements for the operator ............................................. 13
4.4 Danger zone.................................................................... 14
4.5 Foreseeable misuse |
Reasonably foreseeable misuse ............................................. 15
4.6 Behaviour in case of emergency ............................................ 15
4.6.1 Personal injury ....................................................... 15
4.6.2 Case of re............................................................ 15
4.6.3 Technical complications............................................. 15
4.7 Application..................................................................... 16
4.7.1 Local requirements .................................................. 16
4.7.2 Disposal................................................................ 16
4.8 Responsibility of the operator .............................................. 17
4.8.1 Obligations of the operator......................................... 17
4.9 Personal responsibility ....................................................... 18
4.10 Observance of the operating manual ...................................... 19
4.11 Residual hazards and protective measures ............................... 19
4.12 Safety marking on the machine............................................. 19
4.13 Personal protection........................................................... 20
5 Safety instructions for the operator/user .......................................... 21
6 Technical data........................................................................... 22
6.1 General technical data of CM2 PRO........................................ 22
6.2 Design variant of CM2 PRO .................................................. 23
6.2.1 Machine type GXV 340............................................... 23
6.2.2 Machine type Vanguard 2 cylinder................................. 24
6.2.3 Additional information .............................................. 25
7 Assembly, rst start-up ................................................................ 26
7.1 Safety....... .................................................................... 26
7.2 Assembly........................................................................ 26
7.3 First start-up................................................................... 26
8 Product description..................................................................... 27
9 Control............ ....................................................................... 28
9.1 Controls .. ...................................................................... 28

3
10 Start-up ....................................................................................29
10.1 Checking the engine before start-up ...................................... 29
11 Operation............. ................................................................... 30
11.1 Start | stop the CM2 PRO B&S engine ..................................... 30
11.1.1 Cold start ............................................................ 30
11.1.2 After the cold start................................................. 30
11.1.3 Starting at operating temperature............................... 30
11.1.4 Stopping the machine.............................................. 30
11.2 Start | stop the CM2 PRO GXV engine ..................................... 31
11.2.1 Starting the engine ................................................. 31
11.2.2 Starter cord.......................................................... 31
11.3 Running-in period ............................................................. 32
11.4 Short engine running time ................................................... 32
11.5 Functional overview .......................................................... 33
12 Attachments..... ........................................................................ 36
12.1 Attachment of the equipment .............................................. 37
12.1.1 Regular lubrication of the equipment lock ..................... 38
12.1.2 Floating position .................................................... 38
13 Maintenance and servicing ............................................................ 39
13.1 General.. ....................................................................... 39
13.2 Table of regular servicing.................................................... 41
13.3 Screw connections ............................................................ 42
13.4 Tensioning/loosening the steering roller chain........................... 43
13.4.1 Version with turnbuckle ........................................... 43
13.4.2 Version with rollers................................................. 43
13.5 Tensioning/loosening the engine V-belt ................................... 44
13.6 Changing the gear oil. ........................................................ 45
13.7 Procedures after maintenance .............................................. 47
13.8 Notes regarding maintenance work ........................................ 47
13.9 Documentary list .............................................................. 47
14 Residual risks........ .................................................................... 48
15 Storage conditions...................................................................... 50
16 Troubleshooting....... .................................................................. 51
17 After operation.. ....................................................................... 52
17.1 Dismantling / Disposal........................................................ 52
18 Warranty policy.. ....................................................................... 53
19 Overview of wear parts ................................................................ 56
20 Spare part lists.... ...................................................................... 57
20.1 CM2 PRO Honda GXV 340 .................................................... 57
20.1.1 Overview of lters and spark plugs .............................. 58
20.1.2 Engine plate assembly ............................................. 59
20.1.3 Hydraulic pump assembly ......................................... 61
20.1.4 Throttle linkage assembly......................................... 62
20.1.5 Transmission assembly ............................................. 63
Inhaltsverzeichnis

4
Inhaltsverzeichnis
20.1.6 Base frame assembly ............................................. 64
20.1.7 Steering console assembly....................................... 65
20.1.8 Control valve with hydraulic hoses............................. 66
20.1.9 Rear axle assembly ............................................... 67
20.1.10 Lifting assembly ................................................... 68
20.1.11 Seat console assembly............................................ 69
20.1.12 Accelerator pedal ................................................. 70
20.2 CM2 Briggs & Stratton 2-cylinder ........................................... 71
20.2.1 Overview of lters and spark plugs ............................ 72
20.2.2 Engine panel assembly ........................................... 73
20.2.3 Hydraulic pump assembly........................................ 75
20.2.4 Briggs exhaust assembly ......................................... 76
20.2.5 Transmission assembly ........................................... 77
20.2.6 Base frame assembly ............................................. 78
20.2.7 Steering bracket assembly....................................... 79
20.2.8 Control valve with hydraulic hoses............................. 80
20.2.9 Rear axle assembly ............................................... 81
20.2.10 Lifting assembly ................................................... 82
20.2.11 Engine hood assembly ............................................ 83
20.2.12 Accelerator pedal assembly ..................................... 84
21 Plans and other informations ......................................................... 85
21.1 Hydraulic plan ................................................................. 85
22 List of guere..... ...................................................................... 86
23 Overview maintenance ................................................................ 87

5
1 EC Declaration of Conformity
EC declaration of conformity in accordance with
Machinery Directive 2006/42/EC Annex II 1.A
The manufacturer / distributor::
Westermann GmbH & Co. KG
Schützenhof 23
D – 49716 Meppen
hereby declares that the following product
Product name: Cleanmeleon 2 PRO
Make: Westermann GmbH & Co. KG
Serial number: 59 _ _ _ _ Model / type description: CM2 PRO
Description: The Cleanmeleon 2 PRO is a self-propelled compact
work machine that does not fully comply with road
trac regulations. The machine allows the attachment
and use of various hydraulic implements.
The following additional EU directives have been applied:
The protection objectives of the EC Directive
Machinery Directive 2006/42/EC
EMC Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
have been complied with.

6
1 EG-Konformitätserklärung
The following harmonised standards were applied:
EN ISO 12100:2010 Safety of machinery - General principles for design -
Risk assessment and risk reduction
(ISO 12100:2010)
The following other technical specications were applied:
Name and address of the person authorised to compile the technical documen-
tation:
Westermann GmbH & CO. KG
Mr. Alfons Westermann Tel.: 05931 | 496 90 0
Schützenhof 23 E-Mail: [email protected]
49716 Meppen URL: www.westermann-radialbesen.de
Location: 49716 Meppen
Date: 18 January 2018
_______________________________
(Signature))
Alfons Westermann Managing director

7
2 Legal information
Issuer: Westermann GmbH & Co.KG
Publisher:
Westermann GmbH & CO. KG
Mr Alfons Westermann Phone: [phone] | 496 90 0
Schützenhof 23 Fax: [phone] | 496 90 99
49716 Meppen E-Mail: [email protected]
Internet: http://www.westermann-radialbesen.de
Managing Director: Alfons Westermann
Form of organisation: Limited partnership
Location: 49716 Meppen
Commercial Register Osnabrück, HRA 100274
Personally liable partner:
Westermann Beteiligungs-GmbH,
HRB Osnabrück no. 100562,
UST-ID no.: 193643718,
Copyright notice:
The contents of this document are protected by copyright under German copyright law and inter-
national treaties.
All copyrights to the contents of this document are owned by UPAS GmbH unless and to the extent
that another author is expressly indicated or obviously recognisable.
The user is not granted or reserved any industrial property rights, rights of use or other rights by the
provision of the contents. The user is prohibited from registering rights of any kind for the know-how
or parts thereof.
The passing on, transfer and other dissemination of the contents of this document to third parties,
the making of copies, duplicates and other reproductions as well as the utilization and other use –
even in part – are prohibited without the prior, express and written consent of the author, unless and
insofar as mandatory statutory provisions permit such use.
Infringements against copyright are illegal, according to §§ 106 . Copyright Act and grant the hol-
ders of copyrights claims for injunctive relief and damages.
Subject to change:
The Westermann GmbH & Co. KG reserves the right to change this document and the subject matter
described therein at any time without prior notice, in particular to improve and expand it, provided
and insofar as contractual agreements or legal requirements do not conict with this.

8
3 Important general information
3.1 Scope of supply
The operating manual is part of the working equipment and must be
kept accessible in the immediate vicinity of the machine at all times.
The operating manual contains important information for safe and ef-
fective operation of the machine. Therefore, the operator must read
and understand this operating manual carefully.
The basic requirement for safe working is compliance with all safety
instructions and operating procedures given in this operating manual.
The local accident prevention regulations and general safety regulati-
ons for the specific application must also be observed.
The provided supplier documentation for the installed components
must also be observed.
The illustrations are provided for basic understanding and may deviate
from the actual design.
The manufacturer assumes no liability for damage due to non-obser-
vance of the operating manual, improper use, improperly performed
maintenance or repairs, unauthorised modifications, technical modi-
fications and use of unauthorised spare parts.

9
3 Important general information
3.2 Conventions
3.2.1 Symbols and signal words
Symbol / signal word Meaning
Indicates the handling and eects of the safety
information.
Alerts you to a dangerous situation that, if not
avoided, will result in death or serious injury.
Alerts you to a dangerous situation that, if not
avoided, may result in death or serious injury.
Alerts you to a dangerous situation that, if not
avoided, may result in minor or moderate injury.
Indicates possible damage to property and other
important information.
DANGER
!
NOTICE
WARNING
!
CAUTION
!

10
3 Important general information
3.2.2 Pictogram overview
The safety notes within these operating instructions, which may endanger
persons and the machine if not observed, are specically marked by the
following pictograms.
Pictogram Meaning
General warning sign
Warning of danger of falling
Warning of automatic startup
Warning of counter-rotating rollers (danger of
being drawn in)
Warning of harmful or irritating substances
Warning of toxic substances
Warning of hand injury
Warning of hot surface
Warning of danger of crushing
Warning of danger of slipping
Warning of electrical voltage
Warning of obstacles on the ground

11
3 Important general information
3.3 Marking on the machine
The Cleanmeleon 2 PRO has a nameplate that contains all basic data.
Components and accessories from suppliers have their own nameplates.
3.4 Ordering spare parts
When ordering spare parts or accessories, state the
type designation, machine number and year of
manufacture. The use of accessories and spare parts from
other manufacturers is only permitted after consultation
with the manufacturer.
Original accessories and manufacturer-authorised acces-
sories help to ensure safe use. Use of other accessories
may void liability for consequential damages.
NOTE
Seite 6von 68
6
Wichtige grundlegende Informationen
3.2.2 Piktogrammübersicht
Die in dieser Betriebsanleitung enthaltenden Sicherheitshinweise, die bei
Nichtbeachtung Gefährdungen für Personen und die Maschine hervorrufen können,
sind mit den nachfolgenden Piktogrammen besonders gekennzeichnet.
Piktogramm
Bedeutung
Allgemeines Warnzeichen
Warnung vor Absturzgefahr
Warnung vor automatischem Anlauf
Warnung vor gegenläufigen Rollen (Einzugsgefahr)
Warnung vor gesundheitsschädlichen oder
reizenden Stoffen
Warnung vor giftigen Stoffen
Warnung vor Handverletzungen
Warnung vor heißer Oberfläche
Warnung vor Quetschgefahr
Warnung vor Rutschgefahr
Warnung vor elektrischer Spannung
Warnung vor Hindernissen am Boden
Seite 7von 68
7
Wichtige grundlegende Informationen
3.3 Kennzeichnung an der Maschine
Am Cleanmeleon 2 PRO ist ein Typenschild angebracht, dass alle Grunddaten
enthält. Komponenten und Zubehör von Zulieferern tragen eigene Typenschilder.
3.4 Ersatzteilbestellung
Bei der Bestellung von Ersatzteilen oder Zubehör ist die Typenbezeichnung, die
Maschinennummer und das Baujahr anzugeben. Die Verwendung von Zubehör und
Ersatzteilen anderer Hersteller ist nur nach Absprache mit dem Hersteller zulässig.
Originalzubehör und vom Hersteller autorisiertes Zubehör dienen der Sicherheit. Die
Verwendung anderen Zubehörs kann die Haftung für die daraus hervorgehenden
Schäden aufheben.
Westermann GmbH & Co. KG
Schützenhof 23
D- 49716 Meppen
Type: Cleanmeleon 2 PRO
Jahr: 20_ _
Ser. - Nr.: 59_ _ _
Made in Germany

12
4 Safety
4.1 Intended use of the machine
The Westermann Cleanmeleon 2 PRO is to be used exclusively for
the intended use described here.
Areas of application of the working machine are the cleaning of
slatted floors, sweeping of paved areas such as courtyards, paths,
car parks, silo plates and stables, clearing snow, breaking up fod-
der, littering stables or similar work.
The Cleanmeleon 2 PRO has no attachment in its basic version. The
approved implements can be found under the accessories chapter.
Any use over and above this is considered improper. The manufac-
turer is not liable for damage resulting therefrom. The risk is borne
by the user alone. Proper use also includes compliance with the
operating, maintenance and service conditions prescribed by the
manufacturer.
4.2 Machine naming information
The Cleanmeleon 2 PRO is referred to below simply as machine or CM2 PRO.

13
4 Safety
4.3 Operator requirements
Danger due to misuse!
Misuse can lead to dangerous situations.
Therefore:
P Any use beyond or dierent from the intended use must be avoided.
P Strictly adhere to all information in this operating manual and, if
applicable, associated documents.
PSwitching operations on the control elements should only be carried
out by instructed persons.
PMaintenance and servicing should only be carried out by trained
maintenance personnel.
PRefrain from modifying, retrotting or altering the design or individual
pieces of equipment with the aim of changing the area of application
or usability.
PUse the operating resources only with the aids specied in the opera-
ting instructions.
POnly use the operating resources when they are in a technically
perfect condition.
PUse in areas with explosive atmospheres is prohibited.
PDo not exceed the load capacity of the equipment.
PRefrain from transporting persons with the equipment.
Maintenance and repair
Maintenance and repair work are part of the intended
use and must be carried out according to the mainte-
nance intervals.
NOTICE
WARNING
!

14
4 Safety
4.4 Danger zone
Danger while within the danger zone!
Being in the danger zone involves risks that unauthori-
sed persons can not assess.
Therefore:
  P Always monitor the danger zone during the work
process and ensure that no persons are present
there.
  P If an unauthorised person enters the danger zone,
warn the person and stop operating immediately.
The area surrounding the machine with a safety distance of 1.5 meter is
declared a danger zone. This area must be free of unauthorised persons
during the work process in order to protect them and not to aect the
work process. Attachments can increase the danger zone of the machine
depending on their size.
(Fig. 1: Danger zone)
WARNING
!

15
4 Safety
4.5 Foreseeable misuse|
Reasonably foreseeable misuse
All use deviating from the intended use are regarded as misuse and are
not permitted. This includes, e.g.
• transport of people and animals
• use as a climbing aid
• use outside the permissible operating limits
4.6 Behaviour in case of an emergency
4.6.1 Personal injury
If, during use, an incident occurs that results in personal
injury, the reaction must correspond to the severity of
the injury.
4.6.2 Fire
If a re occurs, immediate actions must be taken.
• Protect people
• Fight the re
• Repair the damage
4.6.3 Technical complications
If, during use, technical complications occur, they must be corrected by
qualied personnel before further use.
inform
rst aiders
save
people
keep
calm
CAUTION
!
re extinguisher

16
4 Safety
4.7 Range of application
The range of application includes all sites worldwide that allow for
the safe use of the machine. The application must be in accordance
with the specified intended use.
4.7.1 Local requirements
The range of application includes all sites worldwide that allow for
the safe use of the machine. The following criteria must be met.
PSafe assembly of the machine
PTemperature range between max. -10°C and +40°C
PSuitable area of use for safe use of the WKB 660.
4.7.2 Disposal
The hazardous substances must be disposed of separately to ensure an
environmentally acceptable disposal. All other materials must be sorted
by their material quality and disposed of accordingly.

17
4 Safety
4.8 Responsibility of the operator
If the machine is to be used commercially, the operator is subject to the
statutory provisions on work safety.
4.8.1 Obligations of the operator
The operator is responsible for the perfect condition of the machine.
PThe operator must regularly check all safety devices for their functio-
nality and completeness.
PThe operator must ensure that the scheduled maintenance work is
carried out as scheduled.
PThe operator must inform the manufacturer immediately of any
damage found.
PThe operator must provide the personnel with the necessary protective
equipment and check, maintain and replace defective parts accor-
ding to the regulations.
PThe operator must request a new copy of the operating instructions if
they are in poor condition or if parts are missing.
PThe operator must immediately replace all markings, signs or labels
that are in poorly legible condition or that have been lost
PThe operator must keep the working areas and escape routes free and
in perfect condition.

18
4 Safety
4.9 Personnel responsibility
Preconditions
P Only persons who are expected to observe the safety regulations and
perform their work reliably may enter the danger area.
P Persons whose ability to act is inuenced by drugs, alcohol, medicines,
etc. are not permitted.
P When selecting personnel, the age and occupation-specic regulations
applicable at the location of use must be observed.
P The user must be at least 16 years old!
Qualications
As a rule, all personnel may only carry out actions for which they have
the necessary qualications.
Qualied personnel for installation and commissioning
Due to their professional training, knowledge and experience as well
as knowledge of the relevant regulations, they are able to perform the
work assigned to them and to recognize and avoid dangerous situati-
ons independently.
Service personnel for maintenance and commissioning
Due to their professional training, knowledge and experience as well as
knowledge of the relevant regulations, they are able to perform the work
assigned to them and to recognize and avoid possible dangers independ-
ently.
Electrically qualied people for maintenance, installation and
commissioning
Due to their professional training, knowledge and experience as well
as knowledge of the relevant standards and regulations, they are able
to perform work on the electrical components and to recognize and
avoid possible dangers independently. The electrically qualified per-
son is trained for the specific site at which he works and knows the
relevant standards and regulations.
Instructed operating personnel for operation
Has been instructed by the operating company on the tasks assigned to
him and possible dangers in the event of improper behaviour.

19
4 Safety
4.10 Observance of the operating instructions
The operating instructions are supplied by the manu-
facturer or supplier of the product in order to impart
essential knowledge to the user for the proper and
safe use, and to point out dangers in handling the
machine.
Before commissioning the machine, the operating instructions must be
read through; they must be strictly observed during commissioning. We
would like to point out that we accept no liability for damage or mal-
functions resulting from non-observance of the operating instructions.
We reserve the right to make technical changes, which are necessary for
the improvement of the machine, to the illustrations and information in
these operating instructions.
4.11 Residual dangers and safety measures
The knowledge and technical implementation of the safety notes within
this documentation is a prerequisite for a faultless product. However,
this documentation cannot cover every detail of every conceivable case
of machine application. Therefore, as in any other case, a residual risk in
particular due to human error remains. This documentation is intended
to minimise this residual risk.
4.12 Safety markings on the machine
Danger and warning points as well as important information
must be clearly marked on the machine and must be
cleaned or replaced if they become dirty or unrecognisable.
NOTICE

20
4 Safety
4.13 Personal protective equipment
Personal protective equipment (PPE) is not included in the scope of
delivery. Responsibility for the presence, inspection and correct use of
PPE therefore lies with the operator.
PWear PPE according to the following instructions.
PDo not enter the danger area without PPE.
PFollow the instructions on the PPE attached to the equipment.
Use foot protection
Protection of the feet against heavy falling objects,
slipping, stepping on sharp objects lying around.
Use protective clothing
Tight working clothes with low tensile strength, narrow
sleeves and no protruding parts. Mainly protection
against being drawn into rotating machine parts. When
working on electrics, use working clothes with arc
protection.
Use hand protection
Protection of the hands against friction, abrasions,
stabs and cuts and contact to hot surfaces. When working
on live parts, use insulated protective gloves.
Use hearing protection
Protection of the auditory system against harmful
sound frequencies.
