Westinghouse W32001 User manual

20.1" LCD Display
nextgen-nt2001 Page 1 Tuesday, July 8, 2003 9:08 AM

nextgen-nt2001 Page 2 Tuesday, July 8, 2003 9:08 AM

i
Preface
About this Manual
This manual is designed to assist you in setting up and using your LCD display. Information in this
document has been carefully checked for accuracy; however, no guarantee is given to the correctness
of the contents. The information in this document is subject to change without notice. This document
contains proprietary information protected by copyright. All rights are reserved. No part of this man-
ual may be reproduced by any mechanical, electronic or other means, in any form, without prior writ-
ten permission of the manufacturer.
Copyright
© Copyright 2003. All Rights Reserved.
Trademarks
VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC are
trademarks of VESA.
ENERGY STAR
®
is a registered trademark of the U.S. Environmental Protection Agency. As an
ENERGY STAR
®
partner, the manufacturer has determined that this product meets the ENERGY
STAR
®
guidelines for energy efficiency.
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two condi-
tions: (1) this device may not cause harmful interference, and (2) this device must accept any interfer-
ence received, including interference that may cause undesired operation.
Note : This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
Caution: To comply with the limits for an FCC Class B computing device, always use the signal cord
and power cord supplied with this unit. The Federal Communications Commission warns that
changes or modifications to the unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
nextgen-nt2001 Page i Tuesday, July 8, 2003 9:08 AM

ii
Important Safety Instructions
Read the following instructions carefully. Follow all instructions and heed all warnings to prevent personal injury
or damage to the product. Keep these instructions in a safe place for future reference.
• To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Do not place
your LCD display near water. Exposing the apparatus to rain, water, moisture or sunlight can severely
damage it.
• Clean only with a dry cloth.
• Do not block ventilation openings. Increased temperature may cause fire or device failure.
• Install in accordance with the manufacturer's instructions.
• Do not place the apparatus near any heat sources such as radiators, heat registers, stoves, or other appara-
tus (including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
• Only use the attachments and accessories that were included with the apparatus.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
• Unplug the apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualified service personnel. Servicing is required when the appara-
tus has been damaged in any way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or mois-
ture, does not operate normally, or has been dropped.
• When unplugging the power cord, do not pull on the cable. Grasp the plug to safely unplug the apparatus.
• If you notice smoke or any other odor or noise coming from the apparatus, stop using the product imme-
diately and unplug the power cord. Contact a qualified service technician.
• Keep the apparatus at least four (4) inches away from the wall. Make sure there is sufficient airflow to
ventilate the unit.
• Hold the apparatus with two hands at the base of the panel when moving it.
• Apparatus shall not be exposed to dripping or splashing and no object filled with liquids, shall not be
placed on the apparatus.
.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALI-
FIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
nextgen-nt2001 Page ii Tuesday, July 8, 2003 9:08 AM

Table of Contents
iii
ENGLISH ENGLISH
Table of Contents
Preface .......................................................................................................i
Introduction
Unpacking .............................................................................................1
Getting to Know Your LCD Display
Front View ............................................................................................2
Side View ..............................................................................................2
Rear View ..............................................................................................3
Cables and Connectors ..........................................................................4
Control Panel Keys ...............................................................................5
Remote Control .....................................................................................6
Remote Control Key Index ..............................................................7
Replacing the Remote Control Battery ............................................8
Adjusting the Viewing Angle ................................................................9
Setting up the Optional Wall Mount .....................................................9
Built-in Speakers .................................................................................10
Connecting the AC Power Adapter .....................................................10
Turning On the LCD Display ..............................................................10
Adjusting Settings
Controlling the OSD ...........................................................................11
Setting the Main Display Mode ..........................................................12
Setting the Picture-in-Picture Display Mode ......................................12
Adjusting the Display ..........................................................................14
Television Settings ..............................................................................15
Setting Channels ............................................................................15
Using Quick Channels ...................................................................16
Closed Captioning .........................................................................17
Using the V-Chip (North America only) .......................................17
nextgen-nt2001 Page iii Tuesday, July 8, 2003 9:08 AM

iv
VGA (PC) Settings ..............................................................................19
Adjusting the VGA Display Automatically ..................................19
Adjusting the VGA Display Manually ..........................................19
Adjusting Geometric Settings ........................................................20
Adjusting Volume ...............................................................................20
Miscellaneous Settings ........................................................................21
Setting the OSD Timer ..................................................................21
Setting the OSD Language ............................................................21
Changing the PIP Size ...................................................................21
Setting the PIP Position .................................................................21
Setting the Sleep Timer .................................................................21
Troubleshooting
Specifications
Index
nextgen-nt2001 Page iv Tuesday, July 8, 2003 9:08 AM

Introduction
1
ENGLISH
1 Introduction
Congratulations on your purchase of the 20.1-inch LCD display.
Your LCD display is designed to be versatile, ergonomic, and easy to use.
The display is capable of displaying most standard video signals, with VGA
resolution supported up to 1024x768 with a native resolution of 640x480.
A convenient control panel located on the top of the front panel and a handy
remote control allow you to easily adjust display parameters, change chan-
nels, and adjust the volume. The LCD display’s stereo speakers provide full
rich sound and a convenient audio output port lets you connect to an external
audio system.
The LCD display supports VGA, TV (NTSC, PAL, and SECAM), S-Video,
AV, Component, and YPbPr (480i/p & 576i/p) input devices. The Picture in
Picture (PIP) function lets you view two video sources at the same time
while an integrated V-chip allows you to block selected broadcasts.
1.1 Unpacking
After unpacking your LCD display, make sure the following items are
included in the box and are in good condition:
• LCD display (LCD panel and display base)
• AC power cord and 100-240 VAC/60W power adapter
• Remote control (3-volt lithium battery included)
• Cables:
• 15-pin D-sub VGA cable
• RCA video cable
• RCA stereo audio cable
• 3.5 mm stereo audio cable
• AC power cord
• Warranty Card
• Quick Installation Guide
If you find that any of these items are missing or appear damaged, contact
your dealer immediately. Do not throw away the packing materials or ship-
ping carton in case you need to ship or store the LCD display in the future.
nextgen-nt2001 Page 1 Tuesday, July 8, 2003 9:08 AM

Getting to Know Your LCD Display
2
2 Getting to Know Your LCD Display
The LCD display is designed to provide easy access to all controls and con-
nections. The following figures identify the LCD display’s components, con-
trols, and ports.
2.1 Front View
2.2 Side View
Speaker
Speaker
Stand
Power LED
IR Remote Receiver
LCD Panel
Note:
A
ppearance varies
according to model.
Speaker
Stand
nextgen-nt2001 Page 2 Tuesday, July 8, 2003 9:08 AM

Getting to Know Your LCD Display
3
ENGLISH
2.3 Rear View
A
B
Connectors
nextgen-nt2001 Page 3 Tuesday, July 8, 2003 9:08 AM

Getting to Know Your LCD Display
4
2.4 Cables and Connectors
The LCD display is equipped with the following types of connectors that are
used to connect to external devices including VCRs, DVD players, camcord-
ers, and computers.
The LCD display comes with the following cables:
No. Function Type
1
Cable TV/Antenna 75Ω F-Connector
2
Audio In (Right) RCA (red)
3
Audio In (Left) RCA (white)
4
Composite Video In RCA (yellow)
5
S-Video In 4-pin Mini-DIN
6
Audio In Left
(Component Video) RCA (white)
7
Audio In Right
(Component Video) RCA (red)
8 Component Video In RCA (Red, Green, Blue)
9 VGA In (RGB) 15-pin D-Sub
10 Audio Line In 3.5 mm stereo
11 Audio Line Out 3.5 mm stereo
12 DC Power In 2-pin DC plug
2
1
3
4
5
6
7
8
9
10
11
12
15-pin D-sub VGA cable
RCA video cable
RCA stereo audio cable
3.5 mm stereo audio cable
AC power cord
nextgen-nt2001 Page 4 Tuesday, July 8, 2003 9:08 AM

Getting to Know Your LCD Display
5
ENGLISH
2.5 Control Panel Keys
The control panel keys located at the top of the LCD display can be used to
adjust all available settings. The remote control keys (see “Remote Control”
on page 6) have the same functionality.
Display Mode
Key TV VGA
AV
S-Video
YPbPr
OSD
1 Power Turns the power on or off.
2 Source Selects the source signal to display on the main screen.
3 Menu Turns the on screen display (OSD)
menus on or off. Turns the OSD off.
4Program
Up
Increases
the channel
number.
N/A N/A Moves to the previous
sub menu item.
5Program
Down
Decreases
the channel
number.
N/A N/A Moves to the next sub
menu item.
6Volume
Decrease Decreases the volume.
Moves to the previous
menu item or
decreases the value
of the selected set-
ting.
7Volume
Increase Increases the volume.
Moves to the next
menu item or
increases the value of
the selected setting.
POWER SOURCE MENU PRG VOL
1234567
nextgen-nt2001 Page 5 Tuesday, July 8, 2003 9:08 AM

Getting to Know Your LCD Display
6
2.6 Remote Control
MUTE POWER
MTS SLEEP
MEM.
123
456
789
100
0R
SOURCE
SWAP
PIP
CH
CH
VOL
CH
MENU AUDIO
VIDEO
i
DEL.
QUICK CH
1
3
4
5
6
9
11
13
14
15
2
10
8
16
12
7
nextgen-nt2001 Page 6 Tuesday, July 8, 2003 9:08 AM

Getting to Know Your LCD Display
7
ENGLISH
2.6.1 Remote Control Key Index
Key Description
1 Mute
Turns the volume off completely.
2 MTS Selector
Multi-channel Television Sound for full stereo
and bilingual broadcasts.
3Numeric Keys
(0 to 9, and 100)
Used to directly key in channel numbers.
4
OSD Navigation
Navigates through the on screen display
(OSD) menus (up, down, left, right).
Channel Up/Down
Increases or decreases the channel number.
Volume
Increase/Decrease
Increases or decreases the volume.
5 Information
Turns the on screen information display on
or off.
6 Power
Turns the LCD display on and off.
7 Sleep
Automatically turns off the LCD display after
a preset period of time (30, 60, or 90 min-
utes).
8Quick Channel Memory
Up/Down
Increases or decreases the favorite channel
number.
9Quick Channel Memory
Set
Sets the quick channel number (between 0
and 9).
10 Quick Channel Memory
Delete
Deletes the selected quick channel number.
11 Return
Switches to the previous channel.
12 Main Source
Selects the video source for the main
screen.
13 Picture-in-Picture (PIP)
Source
Selects the picture-in-picture video source.
Audio source remains with the main source.
nextgen-nt2001 Page 7 Tuesday, July 8, 2003 9:08 AM

Getting to Know Your LCD Display
8
Note:
• Using the remote control in direct sunlight reduces the func-
tional distance at which it can be used.
• Aim the remote control at the IR receiver on the LCD display
and ensure there are no object in the line of sight.
2.6.2 Replacing the Remote Control Battery
Refer to the following illustration for instructions on replacing the
remote control battery (CR2025 3V).
1 Slide the battery tray out (A).
2
Place the battery into the tray with
the positive polarity as shown (B).
3
Push the battery tray in.
Caution:
• Remove and store the battery in a cool dry place if the remote
control is not used for long periods of time.
• Handle damaged or leaking batteries with care. Wash hands
with soap if they come in contact with leaked chemical fluids.
• Refer to your local recycling or waste disposal guidelines for
information on disposing of used batteries.
14 Video
Exchanges the Main and PIP video screens
(PIP appears on Main, Main appears in PIP).
15 Audio
Exchanges the Main and PIP audio (listen to
either the Main or PIP sources).
16 Menu
Turns the screen display menu on.
A
B
nextgen-nt2001 Page 8 Tuesday, July 8, 2003 9:08 AM

Getting to Know Your LCD Display
9
ENGLISH
2.7 Adjusting the Viewing Angle
When used on a desktop or other flat surface, you can
tilt the LCD display back to achieve a more comfort-
able viewing angle.
You can adjust the LCD display viewing angle from an
upright position to a back-tilted angle of up to 7
degrees and a forward-tilted angle of 4 degrees.
Warning:
Forcing the LCD display past its maximum
extension point will damage the unit.
Do not hold the screen by the top edge when
tilting it back. Hold the sides of the screen
firmly with both hands and tilt the screen back.
2.8 Setting Up the Optional Wall Mount
Purchase a standard wall mount kit (100 mm x 100 mm screw mount area,
minimum 35 kg load-carrying weight) from a third-party vendor if you want
to attach the LCD display to a wall or other fixed surface.
1
Prepare a flat, stable working area with a soft cloth or foam pad to
place the LCD display on.
2
Turn the LCD display power off, disconnect it from the power
adapter, and gently lay the display on its front.
3 Remove the four
screws located at the
rear of the LCD display
as illustrated. Remove
the LCD display stand.
4
Refer to and follow the
instructions included
with the wall mount kit that you purchased.
4Ɯ7Ɯ
nextgen-nt2001 Page 9 Tuesday, July 8, 2003 9:08 AM

Getting to Know Your LCD Display
10
2.9 Built-in Speakers
The LCD display comes with a pair of built-in stereo speakers located at the
front of the unit.
2.10 Connecting the AC Power Adapter
You must use the 100-240 VAC/60W power adapter that is included with
the LCD display.
Caution:
• Make sure you have read and understood the safety notes
before connecting the LCD display to the power adapter and
electrical outlet.
• Do not use any other AC power adapter except the adapter that
was included with your LCD display.
• Contact your dealer if you need a replacement adapter.
1
Connect the power cord to
the AC adapter.
2 Plug the power cord into an
electrical outlet. Contact your
dealer or a qualified service
technician if the plug does
not fit into the outlet.
3
Insert the small end of the
adapter cord into the DC-in
connector at the back of the
LCD display. The power
LED on the front panel glows
orange.
2.11 Turning On the LCD Display
1
Press the Power key on the LCD display control panel or remote con-
trol to turn the LCD display on. The power LED on the front panel
glows green.
2 Press either Power key again to turn the LCD display off. The power
LED on the front panel glows orange.
nextgen-nt2001 Page 10 Tuesday, July 8, 2003 9:08 AM

Adjusting Settings
11
ENGLISH
3 Adjusting Settings
This chapter explains the LCD display’s On-Screen Display (OSD) menus.
These are used to adjust settings related to picture and audio quality, as well
as other features.
Using the OSD you can adjust the contrast, brightness, OSD position, color
temperature, stereo speaker volume, and other settings.
The OSD Menus can be accessed using either the remote control or the dis-
play control panel located on the top of the LCD display.
3.1 Controlling the OSD
Press the MENU button to turn the OSD on or off.
LCD Control
Panel
Remote
Control Description
MENU
• turns on the OSD menu
• confirms a selection
OFF/BACK
• turns off the OSD menu
• exits a menu without
making any changes
/ arrow keys
• navigates through the
OSD menus
• adjusts value
/ arrow keys
• navigates through the
second level of the OSD
menus
MENU
CH
CH
VOL
MENU
i
MENU
CH
CH
VOL
MENU
i
VOL CH
CH
VOL
MENU
i
PRG
CH
CH
VOL
MENU
i
nextgen-nt2001 Page 11 Tuesday, July 8, 2003 9:08 AM

Adjusting Settings
12
3.2 Setting the Main Display Mode
You can switch between input sources and display them on the main screen
in sequence by repeatedly pressing either:
• the SOURCE key on the remote control
• the SOURCE key on the LCD control panel
The Main display mode rotates between:
•TV
•AV
• S-Video
• YPbPr
•VGA
The OSD menus for each display mode allow you to set options that are spe-
cific to the selected video signal format. Refer to “Adjusting Settings” on
page 11 for information on adjusting settings for each display mode.
3.3 Setting the Picture-in-Picture Display Mode
The LCD display is capable of displaying a second video input signal on the
LCD screen at the same time as the main signal. This second signal, or
source, is shown on the LCD screen in a box over top of the main image -
this is referred to as “Picture-in-Picture” (PIP).
1 : TV 2 : OFF VGA YPbPr
Main display mode indicator
1 : TV 2 : OFF VGA YPbPr
PIP display mode indicator
nextgen-nt2001 Page 12 Tuesday, July 8, 2003 9:08 AM

Adjusting Settings
13
ENGLISH
Select the PIP source by pressing the PIP key on the remote control. There is
no equivalent key on the LCD control panel.
Sub signal options vary according to the selected Main signal as shown in
the following table.
PIP (Picture-in-Picture)
Main OFF TV AV S-Video YPbPr VGA
TV √− − − √ √
AV √− − − √ √
S-Video √− − − √ √
YPbPr √√ √ √ − −
VGA √√ √ √ − −
Main
PIP
nextgen-nt2001 Page 13 Tuesday, July 8, 2003 9:08 AM

Adjusting Settings
14
3.4 Adjusting the Display
The following table indicates the display settings that are available for each
Main display mode.
NOTE:
To return all DISPLAY settings to their factory defaults, select
“Recall” from the menu and press the key.
Setting TV AV S-Video YPbPr VGA
Contrast √√ √ √ √
Brightness √√ √ √ √
Color √√ √ √ −
Hue √√ √ √ −
Sharpness √√ √ √ −
Focus −− − √ −
Auto −− − − √
Color −− − − √
Red −− − − √
Green −− − − √
Blue −− − − √
White Balance −− − − √
Contrast: enables you to adjust the difference between the lightest and darkest
areas of the LCD display screen. Contrast should be adjusted in conjunction with
the brightness item.
Brightness: enables you to adjust the light level of the LCD display’s screen. It
should be adjusted in conjunction with the contrast setting.
Color: lets you make changes to the LCD display’s color display. The available
options are User, Low, Middle and High. Select “User” to set a custom color tem-
perature.
Hue: allows you to adjust the display hue. Hue is a measure of the saturation of a
color.
Sharpness: enables you to adjust the sharpness of the image.
Focus: allows you to adjust the focus of the image.
Recall: returns all display settings to their factory-set default values.
nextgen-nt2001 Page 14 Tuesday, July 8, 2003 9:08 AM
