Westinghouse Unplug UM100WH User manual

Wireless Bluetooth®Sound System
User Guide
UM100WH /UM100BK /UM100RD /UM100GY

What's Included:
·unplug-100 Wireless Bluetooth Sound System
·Travel Pouch(Option)
·USB Charging Cable
·USB Power Adaptor
·3.5mm Headphone Mini Jack Cable
General Specifications
·Bluetooth v2.1 includes profiles: A2DP, AVRCP, HFP, HSP
·Advanced Audio Distribution Profile (A2DP) for wireless music streaming
·Audio Video Remote Control Profile (AVRCP) for wireless audio
and video playback control
·Hands-free Audio (HF) and Headset Profiles(HSP)for hands-free
calling capability with echo and noise cancellation technology
·Range up to 33FT (10M)
1

Features and Benefits
·Bluetooth 2.1 with Westinghouse audio digital signal processing
Technology for clean, best-in-class wireless stereo sound reproduction
·Built-in mic with advanced noise-cancellation enables clear wireless
hands-free calling and conferencing
·Two 40mm full range drivers deliver superb music fidelity
·Ultra Bass Booster Passive Radiator Subwoofer
·Convenient charging with included micro USB charging cable
·Rechargeable Lithium lon battery for up to 10 hours of playtime
·Connects to iPod or any device with a 3.5mm headphone port using
a mini jack cable
·Auto-search and auto-reconnect with compatible device
2

3
Micro USB
Charging Input
3.5mm Audio
In Port
Main Power
Switch
Hands-free Calling
Answer / End Button
Play / Pause / Pairing Volume Up
Volume Down
LED Indicator

Compatibility
Wireless: Devices with Bluetooth 2.0 or above (See General Specifications
for profiles), Bluetooth equipped PCs and most Bluetooth equipped
smart phones or computers.
Wired: Devices with a standard 3.5mm headphone output port via 3.5mm
mini jack cable.
WARNING
1. Do not leave the product exposed to a heat source or high temperatures.
2. Do not remove or attempt to remove the non-user-replaceable battery.
When disposing of the product, take it to a waste electronics service.
4

LED Indicator and Tone Sound
There is an LED light in the middle of the front Bluetooth Sound System.
Below are what the LED's various displays indicate and Tone Sound.
LED OFF - Power OFF / Sleep mode (10 minutes if no music input from
Bluetooth device) / Full charge
BLUE - Power ON (Bluetooth not paired / connector)
Flashing BLUE / RED - Pairing mode
Quick Flashing Red with Tone Sound - Low Battery Level
Flashing RED - When Charging
Flashing BLUE - Device Paired(OFF after 3 mins for power saving
Touch any key to wake up the Blue light)
BLUE alway ON - AUX IN
BLUE OFF after 10 mins - Power Saving mode, Touch any key to wake up.
Set - UP and Pairing via Bluetooth For Music Playback
and Hands - free Calling
5

Bluetooth 2.0 devices. Pairing may vary by device.
Consult your Bluetooth device's manual for pairing instructions.
Pairing with Bluetooth devices
Pairing occurs when two Bludtooth devices communicate with each other
and establish a connection. A record of information about this connection
is then stored in the memory of each device. Once you pair a device with
the unplug-100 speaker, you should not have to pair it again.
The unplug-100 speaker can pair with up to six Bluetooth devices.
However, it can only connect to, and play audio from one device at a time.
To begin pairing with a Bluetooth device
1. With the Bluetooth device and the unplug-100 speaker
both turned on, Touch and hold the button (Fig.1)
NOTE: unplug-100 Wireless Bluetooth Sound System can pair with most
6
(Fig.1)

on the speaker for four seconds to make the speaker discoverable. The LED
indicator on the unplug-100 speaker LED indicator Flashing Red and Blue.
approximately once every second to show that the speaker is discoverable.
2. Set your Bluetooth device to discover the unplug-100 speaker ,
then locate the Bluetooth Device list.
3. From the Bluetooth device list ,select the device named "unplug-100".
4. If your device asks for a passkey, enter digits 0000 (four zeros) and press
OK. Some devices Also ask you to accept the connection.
Your Bluetooth device indicates when pairing is complete. The unplug-100
speaker indicates pairing is complete when the LED indicator turn flashing
Blue with tone sound.
To connect a device
To connect a previously paired device ,touch the Bluetooth button on the
unplug-100 speaker . The Bluetooth indicator on the speaker flashing Blue
and Red until the device connects.
" "
7

8
Then the blue indicator start flashing and Tone Sound, When the speaker
and device have successfully connected.
To pair additional devices
With the Bluetooth device and the unplug-100 speaker both turned on ,
touch the button on the speaker for four seconds to make the speaker
discoverable again . Then follow steps 2-4 on page 7.
The unplug-100 memory can hold up to six paired devices.
You can pair more than six devices, but the memory will never contain more
than six. When the memory is full with six devices and an additional device is
paired, the least recently used is deleted from memory and replaced the
newly paired device.
Clearing memory
To clear the unplug-100 Speaker memory of all devices,
touch and hold both-Vol. Up and Vol. Down (fig.2) button (fig.2)

on the speaker (about 5 seconds) until LED indicator flashing Red and Blue
to Pairing mode(start Pairing for new device ).The unplug-100 speaker clears
all Bluetooth devices from its memory and then becomes discoverable.
Reconnection in Event of Bluetooth Disconnection
If by any reason your device and unplug-100 Wireless Bluetooth Sound System
are disconnected, such as out connection distance or powering off,
they can be re-connected by:
Select "unplug-100 " from your device for reconnection.
NOTE : After pairing, unplug-100 Wireless Bluetooth Sound System
will also " auto-connect" with compatible devices that auto-search
and re-connect with the last connecting device if disconnection should occur.
Pairing with Bluetooth Equipped PC(Windows 7)
You can pair unplug-100 Wireless Bluetooth Sound System with most
9

Bluetooth equipped PCs to music or for use as a speaker phone with Skype
and other online video/voice chat clients.
NOTE: Not all PCs support all Bluetooth profiles needed for full functionality
with unplug-100 Wireless Bluetooth Sound System. Your PC may need
additional Bluetooth drivers or profiles installed. Please consult your owner's
manual. If your PC does not support needed Bluetooth profiles, you can
connect with a 3.5mm to 3.5mm minijack cable and listen to music through
unplug-100 Wireless Bluetooth Sound System.
See section Connecting to a device via 3.5mm "AUX IN" input.
1. Put unplug-100 Wireless Bluetooth Sound System into pairing mode.
2. On you PC, click "Start" then click "Control Panel".
3. Under "Hardware and Sound" click "Add a device".
4.The Add a Device Wizard will pop up. You should see an icon for
"unplug-100 " Click on if and then click "Next".
10

5. Windows 7 will guide you through set-up. If Prompted, the Pass code
is 0000.
6. Be sure your PC's audio output and Mic input are set to unplug-100 Music
then click "Continue".
Your PC is now ready to use unplug-100 Wireless Bluetooth Sound System
to play music and for hands-free online chat.
If you have a Bluetooth equipped Mac, please consult your owner's manual
for pairing instructions.
NOTE: Some audio delay may occur when watching video playback, causing
audio on video to be"out of sync" when connected via Bluetooth.
Use a 3.5mm mini jack cable for optimal performance with video playback.
See section Connecting to device via 3.5mm"AUX"input.
NOTE: Always be sure to switch unplug-100 Wireless Bluetooth Sound System
to the “OFF” position when not in use to save battery charge.
11

Taking Calls on a Mobile Phone Connected to
unplug-100 Wireless Bluetooth Sound System
When you receive an incoming call, ring tone will sound from
Wireless Bluetooth Sound System. If you are listening to music through your
Mobile Phone the music will automatically pause.
To accept a call: You can accept a call as you usually do, using your
Mobile Phone controls or touch the on the top of unplug-100 Wireless
Bluetooth Sound System. Speak normally. Your call will come through the
speakers and you voice picked up through the built-in mic.
To end a call: Use you Mobile Phone controls or touch the button.
To reject a call: Use your mobile Phone controls or touch and hold the button.
To use call waiting: Use you Mobile Phone controls or touch and release
the button twice in succession to put the first call on hold and answer the
incoming call. Repeat to switch back to the first call.
unplug-100
12

Controlling iPod or Bluetooth PC or music phone's music
Playback on unplug-100 Wireless Bluetooth Sound System
In Addition to using the playback control on your iPod or Bluetooth
equipped PC or music phone as you normally would, you can control music
playback from unplug-100 Wireless Bluetooth Sound System using the touch
buttons.
NOTE : Your device must support AVRCP (Audio Video Remote Control
Profile) to control your device's from unplug-100 Wireless Bluetooth Sound
System. Please check your device's owner's manual. At this time,
Apple devices equipped with Bluetooth, like iPhone, iPad and Macs,
do not support AVRCP.
Play / Pause: Touch and release the button to play/pause.
13

Volume control : Touch the(+) to increase volume and the (-) button
to decrease volume.
NOTE : When connected to a Mobile Phone, if you touch the ,
the first track in your music library will begin to play. This function is
disabled during an incoming call.
Connecting to a Device via 3.5mm AUX IN Input
" "
You can use unplug-100 Wireless Bluetoth Sound Sytstem for music
playback with and device that has 3.5mm headphone port.
You will need a 3.5mm to 3.5mm mini jack cable.
Simply plug one end of the cable into your device, as you would to a pair
of headphones. Plug the other end of the cable into the 3.5mm port
marked "AUX" on the back of unplug-100 Wireless Bluetooth Sound System
Play music.
14

Controlling Volume When Connected via 3.5mm AUX Input:
NOTE: Volume cannot be controlled with the volume control
on unplug-100 Wireless Bluetooth Sound System when
connected via the 3.5mm "AUDIO IN" input.
Use the volume control on you device as you normally would.
Recharging Battery
Make sure the power switch is set to "ON". Plug the
Micro USB end of the included USB cable into USB mini port,
Marked "USB " on the back of unplug-100 Wireless Bluetooth
Sound System. Plug the other end into a USB port on your computer
or Power adaptor. Charge time is 4hrs from an empty battery.
NOTE: Always be sure to switch unplug-100 Wireless
Bluetooth Sound System Speaker to the "OFF" position
when not in to use to save battery charge.
" "
15

Trouble Shooting
16
Sound is very low
or no sound
·Please check
or Bluetooth device Volume Level
·If using 3.5mm port, be sure the
mini jack cable is securely inserted
into
and your device
unplug-100
Wireless Bluetooth Sound System
unplug-100 Wireless Bluetooth
Sound System
Music is playing on a device
but isn't transferring to
unplug-100 Wireless
Bluetooth Sound System
·Make sure your Bluetooth device
has A2DP(check your device's
owner's manual)
·Be sure the device is paired
·If using 3.5mm port, be sure the
mini jack cable is securely inserted
into
and you device
unplug-100 Wireless Bluetooth
Sound System

Trouble Shooting
17
LED light not ON ·Make sure unplug-100
main
switch is ON
·Make sure unplug-100
is
charged
·Battery already full charged
Wireless
Bluetooth Sound System
Wireless
Bluetooth Sound System
Hands-free calling is not
working with iPod or
mobile phone
·Make sure your mobile device
has HSP / HFP
·Be sure your mobile phone
is paired
·Check volume on unplug-100
Wireless Bluetooth Sound System

www.westinghousedigital.com
Westinghouse Digital, LLC
Orange, CA SE-UM-0201-1201
