Westinghouse WWT1154DCWA User manual

Model: WWT8040
Washing Machine
WWT1020A
WWT1154DCWA
WWT1254LCWA

CONTENTS
CUSTOMER CARE AND SERVICE
SAFETY INFORMATION
2
SAFETY INFORMATION
PRODUCT DESCRIPTION
CONTROL PANEL
WASHING INSTRUCTIONS
DAILY USE
CARING FOR YOUR WASHING MACHINE
HELPFUL HINTS IN DEALING WITH WASHING PROBLEMS
A GUIDE TO STAIN REMOVAL
TROUBLE SHOOTING
................................................................................... 2
................................................................................ 5
............................................................................................ 9
............................................................................ 17
..................................................................................................... 19
..................................................... 24
......................... 27
....................................................................... 29
.................................................................................... 31
1.
2.
3.
4.
5.
6.
7.
8.
9.
ENVIRONMENT CONCERNS ....................................................................... 3310.
WARRANTY ...................................................................................................3511.
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.
In the interest of your safety and to
ensure the correct use, before
installing and first using the appliance,
read this user manual carefully,
including its hints and warnings.
This appliance is intended to be used
in household and similar applications
such as:
Farm houses
By clients in serviced apartments,
holiday apartments and residential
type environments.
CONDITIONS OF USE
To avoid unnecessary mistakes and
accidents, it is important to ensure
that all people using the appliance are
thoroughly familiar with its operation
and safety features.
Save these instructions and make
sure that they remain with the
appliance if it is moved or sold, so
that everyone using it through its life
will be properly informed on
appliance use and safety.
Warning / Caution-Safety information.
General information and tips.
Environmental information.
Subject to change without notice.
1.
-
-Use the hose supplied with the
washing machine.
DO NOT USE OLD HOSES.

GENERAL SAFETY
It is dangerous to alter the specifica-
tions or attempt to modify this
product in anyway.
Only use the advised quantities of
fabric softener and detergent.
Damage to the fabric can ensue if
you overfill. Refer to the
manufacturer’s recommendations of
quantities.
This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible
for their safety.
Wash small items such as socks,
laces, washable belts etc in a
washing bag or pillow case as it is
possible for such items to slip down
between the tub and the agitator.
Do not use your washing machine
to wash articles with whale bones,
material without hems or torn
material.
Always unplug the appliance and
turn off the water supply after use,
clean and maintenance.
Under no circumstances should you
attempt to repair the machine
yourself. Repairs carried out by
inexperienced persons may cause
injury or serious malfunctioning.
Contact your local Service Centre.
Always insist on genuine spare parts.
When unpacking the appliance,
check that it is not damaged. If in
doubt, do not use it and contact
the Service Centre.
After having installed the appliance,
check that it is not standing on the
inlet and drain hose.
Appliance should not be installed in
a humid place.
Always be sure, that there is no
water leakage from hoses and their
connections after the installation.
INSTALLATION
Any objects such as coins, safety
pins, nails, screws, stones or any
other hard, sharp material can cause
extensive damage and must not be
placed into the machine.
Make sure that small pets do not
climb into the washbowl. To avoid
this, please check into the wash-
bowl before using the appliance.
3
1.1
1.2
If the supply cord is damaged,
should the appliance power supply
cable need to be replaced, this shall
be carried out by our Service Centre.
If the machine is situated on a
carpeted floor, please adjust the
feet in order to allow air to circulate
freely.

4
Any plumbing work required to
install this appliance should be
carried out by a qualified plumber.
Any electrical work required to
install this appliance should be
carried out by a qualified electrician.
This appliance is designed for
domestic use. It must not be used
for purposes other than those for
which it was designed.
Only wash fabrics which are
designed to be machine washed.
Follow the instructions on each
garment label.
Do not overload the appliance. See
the relevant section in the user
manual.
Before washing, ensure that all
pockets are empty and buttons and
zips are fastened. Avoid washing
frayed or torn articles and treat
stains such as paint, ink, rust, and
grass before washing.
Garments which have been in
contact with volatile petroleum
products should not be machine
washed. If volatile cleaning fluids are
used, care should be taken to
ensure that the fluid is removed from
the garment before placing in the
machine.
Never pull the power supply cable
to remove the plug from the socket,
always take hold of the plug itself.
Never use the washing machine if
the power supply cable, the control
panel, the working surface or the
base are damaged so that the
inside of the washing machine is
accessible.
This washing machine is not
intended for use by young children
or infirm persons without supervi-
sion.
Children should be supervised to
ensure that they do not play with
the appliance.
The packaging components (e.g.
plastic film, polystyrene) can be
dangerous to children - danger of
suffocation! Keep them out of
children’s reach.
Keep all detergents in a safe place
out of children’s reach.
Make sure that children or pets do
not climb into the washbowl.
USE
CHILD SAFETY
If this appliance is supplied from a
cord extension set or electrical
portable outlet device, the cord
extension set or electrical portable
device must be positioned so that it
is not subject to splashing or
ingress of moisture.
Water pressures between minimum
50kPa and maximum 800kPa are
acceptable.
Connect the machine to an
earthed socket outlet.
1.3
1.4

5
PRODUCT DESCRIPTION2.
FRONT VIEW BACK VIEW
1
2
3
1
2
Control Panel
PARTS LIST INSIDE VIEW
3
Machine Lid
4
Front Feet
6
5
7
Water Inlet Hose
- RED fittings (Hot Water)
- BLUE fittings (Cold Water)
Mains Cable
8
Outlet Hose/Drain Hose (See installation
instructions to fit & position drain hose)
Back Feet
9
Bleach Dispenser,See Page 21
Detergent Dispenser Drawer
See Page 19
10
11
Wash Bowl
Cap Agitator
12
Frame Filter
13
Lint Filter See page 24
14
Agitator
10
11
9
11
12
13
14
WASHING MACHINE PARTS **WWT8040 / WWT1154DCWA
4
5
6
7
8

PRODUCT DESCRIPTION2.
FRONT VIEW
1
2
3
1
2
Control Panel
PARTS LIST
INSIDE VIEW
3
Machine Lid
4
Front Feet
6
5
7
Water Inlet Hose
- RED fittings (Hot Water)
- BLUE fittings (Cold Water)
Mains Cable
8
Outlet Hose/Drain Hose (See installation
instructions to fit & position drain hose)
Back Feet
9
Bleach Dispenser,See Page 21
Detergent Dispenser Drawer
See Page 19
10
11
Wash Bowl
Gentle Wash Agitator
(Low Profile Agitator)
10
11
9
8
WASHING MACHINE PARTS **WWT1020A / WWT1254LCWA
6
BACK VIEW
4
5
6
7

The out of balance has 2 level which are low
level and high level.
The high level: Machine will be stopped,
caused by an uneven distribution of clothes in
the wash bowl. To rectify the out of balance
condition, open the lid and redistribute the
clothes evenly in the wash bowl. Closing the
spin stage of the wash.
The low level: The washing machine try to
optimize by reduce spin speed to avoid out of
balance to finish the cycle.
If you have frequent out of balance
interruptions, it may be due to your
washing machine not standing firm and level
on the floor. This can be corrected by adjust
the washing machine legs as described
in the Installation Instructions supplied with
your machines.
7
ABOUT YOUR WASHING MACHINE
Out of Balance Interruption
Watch the lights on the control panel to see
the effect pressing a touchpad or turning a
program selector knob has, and listen for
“BEEPS”.
When you press a touchpad you will get a
short “BEEP” to acknowledge the entry.
If the option is not available at the time, the
machine will not allow you to select it. After
the machine has started, the entire wash
option touchpad will be disabled and machine
will give three short beeps to indicate the
touchpad is disabled. The Star/Pause To
Pause touchpad is still active but you need
to press and hold the touchpad for
minimum 1.2 seconds to pause machine.
This is to confirm that you really want to pause
the machine.
NOTE: All functions of the washing machine
will stop when the lid is open.
ActiveMix
This product features the new ActiveMix
Wash System that uses less amount of water,
and is more energy efficient,during the washing
process. It achieves this with just the right
amount of water needed, and by a detergent
pre-mixing system that minimizes detergent
residue even during cold wash to give you a
cleaner wash result.
Water at 35 C is combined with detergent
to dissolve and activate it. Depending on
model, this concentrated solution is then
circulated or showered over the clothes in
combination with unique bowl and agitator
rotations to provide wash action at the selected
wash temperature.
After the wash operation is completed, the
bowl is filled with more water. The low profile
agitator or agitator then moves in an energy
efficient mode, generating additional
mechanical actions.
(WWT1020A)
(Only for WWT1020A)
Your washing machine has selectable
“Auto” sensing water level option as well
as allowing you to choose a manual
water level if you wish. We recommend
you to use the Auto water level option to
ensure there is just the right amount of
water for the wash load in the machine.
In other words, it will usually give you the
best wash while also being the most
efficient in terms of water usage.
Auto Water Level Feature
Wash Operation
Agitation
water spraying
pump on
drain hose
Touchpad Response and Lights
Always press touchpads gently.
o

8
SAVING WATER AND ENERGY
This washing machine features water and
energy saving options.
Your machine is most water efficient when
Eco Rinse is used as the rinse option.
To save energy, the wash time can be shortened
for a load of less dirty clothes by selecting the
appropriate wash program e.g. Fast Wash.
The washing machine is energy efficient and most
water efficient when used with a full load of clothes
and with Eco Rinse selected. You should use
Eco Rinse (where available) instead of Deep Rinse
to reduce the amount of water used for
rinsing clothes.
Each time you switch on your washing machine the
machine will select most suitable rinse option for
the selected program. You can change rinse option
if you wish. The difference between Deep rinse and
Eco rinse is explained on the page 13.
POWER FAILURE RECOVERY
When there is power failure while
machine is washing or rinsing or
spinning. The machine tries to save
the settings at which stage the
machine is doing and then when
the power returns back the machine
will starts washing from the stage
where it is left off.

9
3. CONTROL PANEL
8 kg. WWT8040 / 11 kg. WWT1154DCWA / 12 kg. WWT1254LCWA
176 89 10 11 2345
1
2
3
4
5
6
Program Selection Knob
Spin Selection Touchpad
Temperature Selection Touchpad
Water Level Selection Touchpad
Rinse Selection Touchpad
LED Display
7
8
9
10
11
Time Adjust Touchpad
Child Lock Touchpad
Start/Pause Touchpad
Delay End Touchpad
Save Favourite Program Touchpad

10 kg. WWT1020A
10
1
2
3
4
5
6
On/Off Button
Temperature Selection Touchpad
Water Level Selection Touchpad
Program Selection Knob
Spin Selection Touchpad
Child Lock Option
7
Rinse Selection Touchpad
8
9
10
11
12
Start/Pause Touchpad
LCD Display
Save Favourite 1 Program Touchpad
Save Favourite 2 Program Touchpad
Time Adjust Touchpad
13
Delay End Touchpad
21 7
1211 13
8 9 10
3 4 5 6

Turn the Program Selector knob to
choose the wash program you
want. The table “Your Program
Guide” shown on page 16 will help
you in selecting the right program.
The Program Selector knob is not a
timer. Once you select a wash
program, the Program Selector
knob will stay at that position for
the whole wash cycle.
3.1
PROGRAM SELECTOR
KNOB
For each wash program your
washing machine automatically
selects a suitable fill water
temperature. If you want to use a
different wash water temperature,
press the Temperature button
repeatedly.
The temperature of warm water will
depend on the temperature and
pressure of your hot and cold water
supplies. The recommended
temperature for warm is 35°C.
You have four
temperatures to
choose from Very
Hot, Hot, Warm
and Cold.
The water temp
lights will tell you
the temperature
for each press of
the button.
3.2
WATER TEMPERATURES
BUTTON
Always check your label for the
washing temperature symbols
which the International Care
Labelling Code now uses
You can adjust the flow rate of the
water supplies to adjust the Warm
temperature. All rinse water
temperatures are cold.
Cold, Warm, Hot.
NOTE:
If you have a cold water connection
ONLY and the hot inlet valve is
capped off (refer installation
instructions) you must select Cold
washes only. To fill detergent, you
must follow steps as below:
1. Measure the correct amount of
powder detergent by following
the recommendations on the
package.
2. Mix powder detergent in one
litre of hot or warm water.
3. Add the pre-mixed detergent to
the wash load.
11
move around
agitator

12
CHOOSE THE SPIN
TOUCH THE OPTIONS BUTTON TO SELECT THE SPIN OPTION.
Regular, Cold, Bedding,Heavy Duty,Rinse+Spin,Spin,Quick 20,
Daily 45,Heavy Duty,Denim(*WWT1020A),Hand Wash,
Sportswear (*WWT1020A) : Can select all spin options
Delicates : Can select Medium, Low and No Spin
Note: No spin is effect only to final spin by spin at gentle
speed 1 minute only to prevent water drop to floor when
moving the clothes out of the drum.
Spin
Water Level
3.4
3.3
Choose the water level by pressing Water Level touchpad.
You can select:
Use only the amount of water you need for the wash load.
(Auto level: the exact water level required to wash your clothes
effectively is determined and set for you automatically, ensuring
no water is wasted.)
1.
2.
Auto, Full, Medium and Low
CHOOSE THE WATER LEVEL
Choose the water level by pressing Water Level button. Use only the amount of
water you need for the wash load.
WATER LEVEL BUTTON
Flood diagnostic is explained on page 32. You should refer to this if you have water pouring
onto the floorThe display will show “ ” and you will hear rapid short beep continuously to
remind you about this problem.
IMPORTANT: Components in the washing machine are designed to be used
with water no hotter than 70°C. If your water supply is too hot,
you should have a temperature limiting valve fitted by a qualified
plumber.
Very Hot
Temp.
Water Temperatures
Descriptions
Hot & Cold water usage
propertion
Hot valve Cold valve
Hot
Warm
Cold
for normally soiled, colourfast garments
(e.g. shirts, night dresses, pyjamas....) in linen,
cotton or synthetic fibres and for lightly soiled
for delicate items (e.g. net curtains), mixed laundry
including synthetic fibres and
machine washable,
for normally soiled white cottons and linen
(e.g. teaclothes, towels, tableclothes, sheets...). 100 %
67 % 33 %
50 % 50 %
0 % 100 %
white cotton (e.g.underwear).
non-shrink.

NOTE:
Pressing the “Rinse Option” touchpad
allows you to change the rinse type.
For most washes the machine
automatically selects “Deep Rinse” for you
3.5
RINSE OPTION BUTTON
When Eco rinse is used, rinse water
is sprayed into the washbowl in pulses.
After each pulse the washbowl will spin
to remove detergent laden water from
the clothes.
How does Eco Rinse work ?
There are four rinses to choose from...
Fast rinse, Eco rinse, Deep rinse and
Extra rinse.
Extra : Extra rinse, the
machine fills twice, giving
you two deep rinses.
Deep : Deep rinse the
machine fills once, giving
you one deep rinse.
Eco : Eco rinse is a spray
rinse giving you maximum
water saving.
Fast : Fast rinse uses less
time then Eco rinse by
performing only 3 Eco sprays
but the amount of water in
each spray is increased.
The machine will go through a series of
maximum four pulses spray and short spin
cycles in this manner, depending on
program selection, followed by a final long
spin that removes the water from the clothes
to complete the full wash program.
Compare this with Deep rinse where
much more water is used.
Deep rinse, water enters the machine
filling up to the wash water level selected.
The washer agitates and finally empties
the rinse water through the drain hose.
Extra rinse, this is special option for those
people who suffer from allergies, this extra
rinse will provide two deep rinses to ensure
all detergent residue has been removed.
Eco Rinse and Fast Rinse
Daily program rinse is fixed with
Deep rinse only
Quick20 program rinse is fixed with
Fast rinse only
CANNOT be
selected with Bedding program.
We strongly recommend you use Eco
rinse for your washes whenever you can.
There is considerable saving of water
when Eco is used instead of Deep or
Extra to rinse clothes.
Eco and Fast rinse is not designed
to be used with fabric softener.
Select Deep or Extra rinse if you are
going to use fabric softener.
Deep rinse ensures the fabric
softener is correctly dispensed and
thoroughly removed from your clothes
during rinsing.
Pulse spray of rinse water
Spin up Spin down Final long spin
13
Rinse

3.6
DISPLAY
The display shows the following information:
14
ENABLING/DISABLING END OF
WASH BEEP
User can also disable the buzzer by pressing
the [Water Level] button + [Spin] button
down for 3 sec and release.
The volume level is set in the factory and
cannot be adjusted by the user.
MACHINE IN PAUSE MODE
User needs to touch [Start / Pause] button
once to pause the appliance.
Under the remaining time is show text <PAUSE>
3.7
START/PAUSE BUTTON
TO START THE WASH CYCLE /
PROGRAM
WASH CYCLE IN PROGRESS
END OF PROGRAM
WWT1020A WWT8040
WWT1020A WWT8040
WWT1020A WWT8040
After selecting a program, the duration is
displayed in hours and minutes
(for example 2:34 which means 2 hour
and 34 minutes)
The duration is calculated automatically on the
basis of themaximum recommended load
for each type of fabric.
After the program has started, the time
remaining is updated every minute.
When the wash program is completed,
the display shows text <FINISHED> or
<END> .
The Start/Pause button LED will
turn Off.
The Start/Pause button LED will always light
(not blink) to indicate that now machine is in
executing mode.
LID LOCK FEATURE
This is a safety feature so as to prevent
anyone from opening the door lid when
(Except WWT8040)
the drum is spinning.
To unlock the lid, user needs to tap
[Start / Pause] button once to pause the
appliance and the display will turn Off the lid
lock icon.
The mechanical lock unlocks when the
The Lid Lock indicator will light up when
the feature activate
drum stops spinning.
Press the Start/Pause button to Pause.
Start/Pause to Pause is used to Start,
Stop and Continue the wash.
If you have started your wash and you
wish to stop it for some reason, press the
Start/PauseTo Pause touchpad and
hold it for 1.2 secounds to enter
pause mode.
The Start/Pause button LED will blink.
Start/Pause LED
Start/Pause LED
it will disable power on sound also.

When child lock is activated, the door will be locked all the time during the machine is working.
CHILD LOCK
FAVOURITE
TIME ADJUST
You can set your washing machine to finish your wash at a later
time you specify, choosing a delay of between 1 to 19 hours in
1-hour increments. The hour displayed indicates the time when
the cycle will finish. After selecting the wash program, tapping on
either the [-] or [+] button once will start the delay end and set the
Tapping [+] button increases the end time.
1-19 hours of the end time of the entire wash cycle.
Tapping [-] button decreases the end time.
Press the Start / Pause button
The Delay end indicator will light up and the clock will begin
counting down until it reaches the set time.
DELAY END
15
The Favourite indicator will light up when this feature
is activated.
3.8
FAVOURITE , CHILD LOCK , TIME ADJUST , DELAY END BUTTON
FIG A.
FIG A.
WWT1020A
WWT1020A WWT8040
WWT1154DCWA
WWT1254LCWA
FIG B.
FIG B.
To Activate the child lock :
FIG A : Hold down the “Spin” and “Rinse” at the same time
for 3 seconds.
FIG B : Hold down the “Lock” for 3 seconds.
The child lock indicator will light up when this feature is
activated.
Knob Dial
The favourite function is the ability to tailor individual wash features
and save them as a custom programme until the next time.
FIG A : Select the Favourite 1 or 2, choose wash method, spin ,
temperature ,Rinse, then touch and hold the Favourite button for
>1.5 seconds .“Beep sound”is activated and the programme is
stored for later use with a single button press.
FIG B : Select the Save Favourite, choose wash method, spin ,
temperature ,Rinse, then touch and hold the Favourite button for
>1.5 seconds .“Beep sound”is activated and the programme is
stored for later use with select Favourite program on Knob Dial.
Your appliance is provided with CHILD SAFETY LOCK which
permits you to leave the appliance unsupervised with the door
closed without having to worry that children might be injured by
or cause damage to the appliance.
This option allows you to increase/decrease washing time by
changing the 3 different levels.
: medium > maximum > minimum
To Deactivate the child lock :
FIG A : Hold down the “Spin” and “Rinse” at the same time
for 3 seconds.
FIG B : Hold down the “Lock” for 3 seconds,
The child lock indicator will disappear when this feature is
deactivated.
WWT8040
WWT1154DCWA
WWT1254LCWA

16
YOUR PROGRAM GUIDE (KNOB DIAL)
Water
Temp Spin Rinse
Auto Warm High Deep/Eco*
Auto Warm
Warm
High Deep
Auto Warm High Deep
Auto Warm
Warm
Warm
High Deep
Low Warm High Fast
Full Cold High Deep
- Hot - -
- -- -
- - High -
Auto Cold High Deep
Auto High Deep
Auto High Deep
Auto Deep
Auto Cold Medium
Medium
Deep
Auto Hot High Deep
For normally soiled cotton load at rated load
capacity.
For synthetic or mixed fabrics, underwear,
coloured garments, non-shirnk shirts,
blouses.
For lingerie, lace, trimmed and embroidered
items.
For bedding fabrics labelled “Machine
Washable”
For a heavily soiled cotton wash load.
For normally soiled cotton load.
Clean the tub.
For items that you want to rinse and spin eg.
clothes items you have hand washed in
a wash tub.
For very wet clothes to remove the water.
For a heavily soiled Denim/Jeans wash load.
For a Sport ware fabrics labelled “Machine
Washable”
For wool fabric and Hand Wash labelled
“Machine Washable”
For a very small load of mixed fabrics.
For a small load of mixed fabrics.
For using favourite program.
Regular * O O
O X
O O
O O
O X
O X
X
O O
O O
O O
O
WWT1020A
WWT8040
WWT1154DCWA
WWT1254LCWA
Cold O O
Delicates O O
Bedding O O
Heavy Duty O O
Soak & Wash
Tub Cleaning
Rinse+Spin
Spin
Denim
Sports Wear
Hand Wash
Quick 20
Favourite
Daily 45
Program Select this program
Recommended
Model
O X
3.9
* “Regular wash, Auto level, Warm, High spin, Eco rinse, Max Time Adjust”
is recommended for a full load of normally soiled cottons.
NOTE: When indication appears and blinks after
appropriate number of wash cycles are finished,
this is to remind user to clean the lint filters.
See page 24.
To clear this indication turn the knob to Off
position for WWT8040

17
4.1
SORT YOUR WASHING
INTO SEPARATE WASH
LOADS
Each load of washing should
contain clothing which needs the
same washing conditions. For
example, you should not wash
delicate clothes with very dirty
work clothes.
Colour fast and non-colourfast
fabrics should be separated.
Knowing the type of fabrics you
have and how dirty they are will
help when you make selections
from the wash program options.
Some fabrics are lint collectors
and can pick up lint, dirt and
colour from other fabrics which
are lint producers. Some
examples are listed below:
Lint collectors Lint producers
- Corduroy
- Synthetics
- Permanent
press fabrics
- Towels
- Nappies
- Chenille/
Candlewick
Make sure that you wash lint
collectors separately from lint
producers.
WASHING INSTRUCTIONS4.
NOTE:
IMPORTANT!
However, due to the variables of fabric
types, soil levels, detergent types and
available program settings you may find
some combinations of these which do
not always result in the perfect wash.
If for example you see residuals of
detergent or soils on some items,
please read the section Residues on
washed items paragraph.
Over time you will learn what is the best
set-up of programs, detergent and load
sorting for different load types and soils.
These Washing Instructions are of a
general nature and you should get good
wash results by following them.
Rub particularly soiled areas with
a special detergent or detergent
paste.
Treat curtains with special care.
Never wash whites and coloureds
together. Whites may lose their
“whiteness” in the wash.
New coloured items may run in
the first wash; they should
therefore be washed separately
the first time.
Button up pillowcases, close zip
fasteners, hooks and poppers.
Tie any belts or long tapes.
Remove persistent stains before
washing.
Make sure that no metal objects
are left in the laundry (e.g. hair
clips, safety pins, pins).

4.2
4.3
If you use pre-treatment sprays or
stain removers, apply them to the
clothing well away from your
washing machine.
PRE-TREATMENT SPRAYS
AND STAIN REMOVERS
Pre-treatment sprays and stain
remover can damage plastic
components on your washing
machine.
DETERGENT
Wash bras, pantyhose and other
delicates in a mesh laundry bag,
which you can purchase from
your supermarket.
WARNING!
Don’t use the wrong type of detergent.
You must use a low sudsing detergent
designed for front load washing
machines or high efficiency top
loaders, such as Cold Power for Front
Loaders and High Efficiency Top
Loaders or detergents labelled “Matic”.
Don’t use soap-based products in
your washing machine.
Don’t use too much detergent. This
can result in excessive suds that can
cause low spin speeds, poor rinsing
and overloading the motor during spin
stages of the wash program.
Don’t use too little detergent because
you will get a poor wash. If you think
you need more, increase dosages by
only small amounts to avoid excessive
suds.
Quantity of detergent to be used
Good washing results also depend
on the choice of detergent and use
of the correct quantities to avoid
waste and protect the environment.
Although biodegradable, deter-
gents contain substances which, in
large quantities, can upset the
delicate balance of nature.
The choice of detergent will
depend on the type of fabric
(delicates, cottons, etc.),
the colour, washing temperature
and degree of soiling.
The type and quantity of detergent will
depend on the type of fabric, load size,
degree of soiling and hardness of the
water used.
Information on hardness of the water in
your area can be obtained from the
relevant water supply company, or from
your local authority.
Follow the product manufacturers’
instructions on quantities to use.
Not enough washing powder causes:
the washload to turn grey, greasy
clothes.
Too much washing powder causes:
sudsing, reduced washing effect,
inadequate rinsing.
Use less detergent if: you are washing
a small load, the laundry is lightly
soiled, large amounts of foam form
during washing.
Water hardness is classified in so-called
“degrees” of hardness.
Remove hooks or tie them up in
a bag or net.
18

19
LOAD THE WASHING MACHINE
STARTING YOUR WASHING MACHINE
When loading the clothes into your
washing machine, there are four things
to remember:
Clothes must be loaded evenly around the
agitator.
For best result load small items first, followed
by large items.
1.
1.
Clothes must not be wrapped around
the agitator.
For example, a typical load should be loaded
using the following sequence : handkerchiefs,
wash cloths, undershorts, pillow cases,
T-shirts, business shirts, tablecloths, sheets,
bath towels.
2.
The washing machine must not be overloaded.
Clothes must be able to move during wash.
3.
The load should contain only three or four large
items, for example sheets. The rest of the load
should be small items. A mixed load of large
and small items will wash cleaner than a load of
all large items.
4.
DAILY USE5.
Connect the mains plug to the mains socket.
2.
Turn the water tap on.
ADD THE DETERGENT
When using the washing machine for
the first time,check that the dispenser
is set for the type of detergent you will
use. To do this, proceed as follows:
Pull the dispenser drawer forward
until it stops.
1.
Lift the front of the drawer up and
forward to
remove it from the runners.
2.
Check the position of the flap at the
rear of the detergent compartment in
the dispenser drawer.
(Factory setting is flap up for powder.)
3.
Clip the flap down if you intend to
use liquid detergent.
Remember: If you change the type
of detergent you use, the position
of the flap will need changing.
See picture.
4.
Refit the dispenser back into its runners.
5.
clip flap down for
liquid
You are now ready to add detergent.
Measure the amount required and pour
it into the detergent compartment of
the dispenser drawer.
6.
add detergent
clip flap up for
powder
5.1
5.2
5.3

Don’t do these things:
20
5.4
When using liquid detergent, some may leadk
out of the dispenser into the wash load earlier
than expected through small openings in the
back of the dispenser.
The openings are to help flushing out of
detergent.
7. If you want to use fabric softener, see
“Add fabric softener”.
8. Close the drawer by pushing it backwards
into the top panel of the washing machine
when you have finished adding detergent.
Using too little detergent will give you a poor
wash result.
Using excessive detergent will create too
much suds and may cause overloading of the
motor during the spin stage of the wash
cycle.
To avoid excessive suds, reduce the amount
of detergent you use. It is best to use
detergent labelled low susing. Good quality,
front load detergent will perforn will in this
machine.
Use soap based products in your washing
machine.
Before adding softener to the dispenser,
make sure the siphon cap is pushed firmly
down onto the spigot in the drawer.
The softener will not siphon out if the cap is
incorrectly fitted, is missing or blocked with
residue. You are now ready to add fabric
softener.
Measure the correct amount as recommend-
ed on the softener package into a cup and
then pour it into the softener compartment of
the dispenser drawer.
Overfilling and then siphoning out too early
can cause softener and detergent to mix
resulting in staining problems.
The softener dispenser holds 90ml when filled
up to the MAX marker. Any level lower than
MAX will function correctly.
Caution: Only use the detergent
compartment for detergent and
the fabric softener compartment
for fabric softener.
ADD FABRIC SOFTENER
Caution: Do not overfill the fabric
softener dispenser.
MAX - Do not fill above
this height
siphon cap
siphon cap
pushed down
add fabric
softener
