Westone Bluetooth Cable V2 User manual

User Guide
CableV2

Get the most from your new Bluetooth
Cable V2 by following these helpful tips:
• Avoid exposing the Bluetooth cable to extreme
temperatures and prolonged exposure
to direct sunlight.
• Do not immerse the cable and cable modules into
water or liquids of any kind. The cable and cable
modules are water resistant not water proof.
• Please avoid any shock damage or strong impacts
to the cable or cable modules, as this can aect the
performance of the cable.
• When installing or removing earphones/earpieces
from the Bluetooth cable, always grasp the cable
connectors and not the cable. Failure to do so could
aect the performance of the cable.
THANK YOU
for purchasing the Westone®
Bluetooth® Cable V2
Please register your product to receive information on new
product releases, promotions, and all of the latest updates
from Westone Audio.
» Register at: www.westone.com/productregistration
The warranty covers defects in materials and workmanship
for ONE YEAR after the original date of purchase. Product
must be purchased from a Westone authorized dealer,
proof of purchase is required to verify eligibility.
PRODUCT TIPS

R
BLUETOOTH CABLE V2
PRODUCT OVERVIEW
+ Volume Up
MMCX Audio
™ Connector
L = Left R = Right
Cable Management Slider
Battery Module
Control Module
Charging Ports
Microphone
Power
- Volume Down
PORTABLE CHARGING DOCK
CHARGING CABLE
Cover Open
Charging
Prongs
Cover Closed
Cover
Release
Cover
Mini USB
Port
USB Mini USB

CONNECTING EARPHONES DISCONNECTING EARPHONES
How to attach earphones to the cable:
1. Identify the right and left MMCX connectors,
each connector is marked “R” for right and “L”for left.
2. Identify the right and left earphones/earpieces. Match
the appropriate earphone to the correct cable,
right + right or left + left.
3. Grasp the MMCX connector and insert it into the
earphone/earpiece by pushing it into the female
MMCX
connector until it clicks into place.
4. Repeat for the other side.
How to disconnect earphones from the cable:
1. Hold the earphone/earpiece rmly with one hand,
and the MMCX connector with the other hand.
2. Pull the MMCX connector straight out of the
earphone/earpiece. Do Not pull at an angle, or the
connector will become harder to remove from the
female socket.
CAUTION: Never try to remove the cable from the
earphone/earpiece by pulling directly on the cable.
This could damage or destroy the cable.

PAIRING THE CABLE TO A DEVICE
How to pair the cable to the device:
1. Hold down the power button for ve seconds. The
indicator light located next to the power button
will begin ashing red and blue to indicate the
pairing process has begun. The voice prompt will
indicate “Pairing”.
2. To complete pairing the cable with the device
follow these steps:
• iPhone: Go to Settings/General/
Bluetooth/On*
• Android: Go to Settings/Bluetooth/On/
Scan for devices*
• Windows: Go to Settings/Bluetooth/On*
*Pairing procedure can vary per device.
3. Select “Westone BT V2”
4. If the device asks for a passcode, enter four zeros
(0000) for the passcode or accept the connection.
5. Once the device is successfully paired the indicator
light will ash blue three times every two seconds.
The voice prompt will indicate “Connected”.
Power Button
Indicator Light

CONTROL MODULE FUNCTIONS LED INDICATIONS
CHARGING DOCK FUNCTIONS
Power/Center Button Action
Power On Press and Hold (1 sec)
Press and Hold (3 secs)
Press and Hold (1 sec)
Press and Hold (1 sec)
Press and Release
Press and Release
Press and Hold (5 secs)
Press and Hold (1 sec)
Press and Release
Press and Release
Double Press and Release
Press and Release
Press and Release
Press and Hold (5 secs)
Power O
Enter Pairing Mode
Play/Pause Music
Receive Incoming Call
Decline Incoming Call
End Active Call
Reconnect to Last Device
Voice Search / Siri
Volume Up (+) / Right Button
Volume Up
Next Track
Volume Down (-) / Left Button
Volume Down
Previous Track
Clear Paired Device List (PDL)
Volume Up(+) & Volume Down(-)
Red + Blue
Red + Blue
Red + Blue
Red
Blue
Red
Red + Blue
Power On
Power O
Pairing Mode
Searching
Connected “Connected”
Battery Low
Clear Paired
Device List
“Power On”
LEDs Flash Once
LEDs Flash Once
LEDs Flash Twice
LED Flashes Twice Every 2 secs
LED Flashes Three Times Every 2 secs
LED Flashes Twice Every Second
LEDs Flash Alternately
“Power O”
“Pairing”
“Battery Low”
Tone
Event LED Indication Prompt
Status
LED Indication
Battery Dock is Charging Red LED
Blue LED
Blue LED
Red + Blue LEDs
Battery Dock is Charged
Dock and Bluetooth Cable are Charging
Dock and Bluetooth Cable are Charged

Charging the cable using the charging dock:
1. Open the charging dock
cover by sliding the lock
release to the right.
2. Place the battery module
into the charging dock
with the logo face up.
3. Close the charging dock
cover to begin charging
the cable.
The Bluetooth cable is shipped partially charged
so it can be used immediately.
PLEASE NOTE: The portable charging dock will
need to be fully charged before the Bluetooth
cable can be charged.
Charging the portable charging dock:
1. To charge the dock, plug
the included USB cable
into a USB port on any
device.
2. Plug the Mini USB end
of the charging cable
into the Mini USB port
located on the bottom
of the charging dock.
PORTABLE CHARGING DOCK
PLEASE NOTE:
The Bluetooth cable can be
charged with or without the
charging dock plugged in.

WEARING THE CHARGING DOCK
PLEASE NOTE:
The charging dock can be
worn with the Bluetooth
cable to increase the
battery life, increasing
total use time.
WARNING!
Never charge the charging
dock when it is attached
to the battery module and
the Bluetooth cable
is being worn.
NO
WEARING THE CABLE
There are two ways to
wear your cable:
1. Wear the cable around
the front of your neck for
normal everyday activities:
• traveling • listening to music
• phone calls • watching media
2. Wear the cable around the
back of your neck when
participating in activities
such as:
• exercising • hiking
• running • biking

TROUBLESHOOTING
If you are experiencing these commonly
reported problems, please try the following
suggestions:
Unstable Connection:
• Move the device closer to the control module on
the Bluetooth cable, also ensure that there are no
obstructions between the device and the cable; if
exercising or doing physical activity, we
recommend the use of an armband.
• Move away from devices such as a Wi-Fi routers or
computers that could be interfering with the signal,
or turn the Bluetooth on those devices off.
• Ensure that the Bluetooth cable and the device
you are using are compatible.
• Ensure that the Bluetooth cable battery is fully charged.
• Change the location of the cable and control
module, to determine which is better, either
behind the head or in front of the neck.
Short Battery Life:
• Ensure that the Bluetooth cable battery is fully
charged.
• Ensure that the portable charging dock is fully
charged before charging the Bluetooth cable.
• Listen at a lower volume.
• Move away from an area with a large amount
of external wireless signals.
• Change the type of earphones connected to
the Bluetooth cable if using a brand other than
Westone.

Unable to Hear Any Sound:
• Make sure that the Bluetooth cable is charged and
turned on.
• Confirm that the Bluetooth cable is paired
to the chosen device.
• Ensure that the earphone/earpiece is functioning
properly.
• If one side is not working properly try switching
the right and left sides.
• Check the volume on both the device and on the
Bluetooth cable.
• Move the device closer to the headphones and
away from any interference or obstructions.
•
Try pairing the Bluetooth cable to a different device.
TROUBLESHOOTING (cont’d)
Cable Does Not Pair With Device:
• Turn the Bluetooth® feature on your device off and
then on again.
• Delete the “Westone BT V2 ” cable from the Bluetooth list
on the device. Then try and pair to the device again.
• Move the device closer to the control module, and away
from the source of any interference or obstructions.
• Try pairing the Bluetooth cable to a different device.
• Clear the paired device list (PDL) and then enter
pairing mode:
Press and hold the volume up (+) and the volume
down (-) button together for five seconds, the indicator
lights on the control module will flash blue/red twice
and a tone will sound. Try pairing to the device again.

Bluetooth Cable is Not Charging:
• Ensure that the USB charging cable is securely
inserted into both the portable charging dock
and the charging device.
• Ensure that the Bluetooth cable in securely seated
into the portable charging dock, and that no foreign
material is preventing a secure connection between
battery module and the charging prongs.
• Plug the USB side of the USB charging cable into
a 120v wall adapter (sold separately).
• If the cable has been exposed to extremely high or
low temperatures, allow the cable to return to normal
room temperature before trying to charge again.
TROUBLESHOOTING (cont’d)
BATTERY WARNING:
This device contains an internal, rechargeable
battery that is not replaceable. Battery life
can vary with usage. Mistreated rechargeable
batteries may present a risk of fire or chemical
burn. Do not use the product if the battery
module appears to be leaking, is discolored, or
deformed in anyway. Non-operational product
should be disposed of according to local laws,
if no such laws exist in your area dispose of the
product in a waste bin designated for electronics.

Limited Product Warranty
Westone warrants this product to be free of defects in material or workmanship for
a period of one (1) year from the date of original retail purchase.This warranty is
available only to the original purchaser, and only if purchased from an authorized
Westone distributor or dealer. If the product is found to be defective during the
warranty period,Westone will, at its sole discretion, either repair the product
or replace the product with a new or factory reconditioned or substantially
equivalent model.This limited warranty does not apply to loss, theft, or any defects
attributable to damage beyond the reasonable control ofWestone including
damage caused by abuse, misuse, misapplication or modications performed by
anyone other thanWestone.This warranty applies only to the external shell of the
product, the internal components and cable.
Repair/Replacement Warranty
This LimitedWarranty shall apply to any repair, replacement part or replacement
product for the remainder of the original warranty period or for ninety (90) days,
whichever period of time is greater. Any parts or product replaced under warranty
will become the property of Westone.
Requesting Warranty Support
Valid warranty claims are generally processed through the point of purchase
during the rst thirty (30) days after retail purchase.
United States & Canada
I f it is necessary to return the product toWestone for warranty or post-warranty service,
contactWestone to request a return merchandise authorization (RMA) number. Go
to westoneaudio.com to submit a Product Return Request Form. Please note you
will be required to submit reasonable proof of purchase date, ownership, and that
the product was purchased from an authorizedWestone retailer. Once you receive an
RMA number, package the product securely to prevent damage in transit, include the
documentation, and send prepaid and insured through a trackable shipping carrier to:
Westone Laboratories, Inc.
Attn: Music Returns Dept.
2260 Executive Circle, Colorado Springs, CO 80906 USA
Westone will be responsible for shipping the product back to the consumer after
warranty repair/replacement only.The customer is responsible for all shipping/
handling charges related to returning the product toWestone.
WARRANTY INFORMATION

FCC
International
The warranty on this product if it is sold to a consumer outside of the United States
and Canada shall comply with all applicable law.To obtain warranty service, contact
the dealer from which the product was purchased or the distributor that supplied
this product. Additional charges and limitations may apply. If purchased through
an authorizedWestone retailer, but not through the local distributor or distributor’s
network, contactWestone directly (see United States & Canada instructions above). If
purchased in an international location without aWestone distributor, contactWestone
directly (see United States & Canada instructions above).
Limitation of Liability
Westone disclaims any and all implied warranties, warranties of merchantability and
tness for a particular purpose to the maximum extent permissible by law.Westone
shall not be liable for any special, incidental or consequential damages caused by
the use, misuse, or inability to use this product. If purchased under a government
contract, those contract terms supersede terms stated herein. In some locations,
implied warranties cannot be limited. Under certain conditions, these limitations or
exclusions may therefore not apply to you.This warranty replaces all other warranties
for this product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation. Changes or modications not expressly approved by
the party responsible for compliance could void the user’s authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide
reasonable protection against harmful interference in a residential installation.This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARRANTY INFORMATION (cont’d)

SRRC CONTACT US
Westone values your satisfaction.
If you have any questions or comments about
our products or service, please contact us:
Phone: [phone]
Email: [e-mail]
Westone® Laboratories, Inc.
2235 Executive Circle, Colorado Springs, CO 80906
Westone Bluetooth Cable V2

Designed in Colorado, USA
©2018 Westone Laboratories, Inc. | The “Bluetooth®” wordmark and logos are registered
trademarks of Bluetooth SIG, Inc. any use of such marks is under license. | Qualcomm aptX
is a trademark of Qualcomm Technologies International, Ltd. Qualcomm is a registered
trademark of Qualcomm Incorporated, registered in the United States and other countries,
used with permission. aptX is a trademark of Qualcomm Technologies International, Ltd.,
registered in the United States and other countries, used with permission. Other trademarks
and trade names are those of their respective owners.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
westoneaudio.com
Complies with IMDA Standards DA105282 Made in China | PN 78397-M 7/18
