Wexiodisk WD-11 User manual

TUNNEL DISHWASHER
WD-11
touch
(original documentation)
Read the manual before using the machine!
Installation and user manual
S/N: (En) Valid from: 202310 Rev.: 00 (202310)

1. General instructions ........................................................................ 1
1.1 Symbols used .................................................................................................. 2
1.2 Machine rating ................................................................................................. 3
1.3 Checking that the machine and manual correspond ........................................ 3
1.4 EU Declaration of Conformity .......................................................................... 4
2. Safety instructions ........................................................................... 5
2.1 General information ......................................................................................... 5
2.2 Transport .......................................................................................................... 6
2.3 Installation ........................................................................................................ 6
2.4 Detergent and drying agent ............................................................................. 6
2.5 Operation ......................................................................................................... 7
2.5.1 High temperatures .................................................................................... 7
2.5.2 Risk of crushing ........................................................................................ 7
2.5.3 Risk of slipping .......................................................................................... 7
2.5.4 Sounds ...................................................................................................... 7
2.6 Cleaning the machine ...................................................................................... 7
3. Installation instructions ................................................................... 8
3.1 General information ......................................................................................... 8
3.1.1 Rust on industrial dishwashers ................................................................. 9
3.2 Requirements for the installation site ............................................................. 10
3.2.1 Lighting ................................................................................................... 10
3.2.2 Ventilation and ambient temperature ...................................................... 10
3.2.3 Power supply .......................................................................................... 10
3.2.4 Water ...................................................................................................... 10
3.2.5 Drain/waste pipe ..................................................................................... 10
3.2.6 Space for servicing ................................................................................. 10
3.3 Transport and storage .................................................................................... 11
3.3.1 Unpacking ............................................................................................... 11
3.4 Installation ...................................................................................................... 12
3.4.1 Preparing for the installation ................................................................... 12
3.4.2 Positioning the machine .......................................................................... 12
3.5 Connections ................................................................................................... 13
3.5.1 Electrical connection ............................................................................... 14
3.5.2 Water connection, regardless of any options .......................................... 14
3.5.3 Ventilation ............................................................................................... 14
3.5.4 Drain/waste pipe ..................................................................................... 15
3.5.5 Detergent and drying agent .................................................................... 15
WD-11 Rev. 00 (202310)
touch

3.6 Installation and connection of auxiliary equipment and options ..................... 20
3.6.1 Limit switch ............................................................................................. 20
3.6.2 Conveyors ............................................................................................... 20
3.6.3 Emergency stop ...................................................................................... 20
3.7 Trial operation ................................................................................................ 21
3.7.1 Start-up schedule .................................................................................... 21
3.8 Documentation ............................................................................................... 22
4. Operating instructions ................................................................... 23
4.1 Before washing .............................................................................................. 24
4.1.1 Machine design ....................................................................................... 24
4.1.2 Preparations before filling ....................................................................... 26
4.1.3 Touch panel ............................................................................................ 28
4.1.4 Filling and heating the machine .............................................................. 32
4.1.5 Positioning of dishware in baskets .......................................................... 34
4.2 Washing ......................................................................................................... 36
4.2.1 Feeding loads into the machine .............................................................. 36
4.2.2 Washing with Automatic operation ......................................................... 37
4.2.3 Washing with manual operation .............................................................. 37
4.2.4 Cancelling washing ................................................................................. 37
4.2.5 Emergency stop function ........................................................................ 37
4.2.6 Guaranteed final rinse ............................................................................ 38
4.2.7 Changing the water ................................................................................. 38
4.2.8 Checking the wash result ........................................................................ 39
4.3 After use – Cleaning ...................................................................................... 40
4.3.1 Incorrect cleaning methods ..................................................................... 40
4.3.2 Emptying and daily cleaning ................................................................... 41
4.3.3 Cleaning and checking each week or as required .................................. 43
4.3.4 Operating problems ................................................................................ 44
5. Technical specifications ................................................................ 50
WD-11 Rev. 00 (202310)
touch

WD-11 Rev. 00 (202310)
General instructions touch
1
1. General instructions
Read the instructions in this manual carefully as they contain important informa-
tion regarding the correct, effective and safe installation, use and servicing of the
machine. Service personnel should have access to all documentation for the ma-
chine.
Keep this manual in a safe place so that it can and should be used by other op-
erators of the machine.
• The machine is intended to be used for washing dishware that is found in
the general catering and restaurant trade. Other uses are NOT recom-
mended!
• The machine can be equipped with a number of different options. Certain
options may be standard in a number of countries. Check what your ma-
chine is equipped with.
• Use auxiliary equipment where possible to avoid heavy lifting.
• The machine’s display indicates what the machine is doing. The machine’s
various temperatures and any alarms are also shown.
• The capacity requirements of the machine can be found in the TECHNICAL
DATA chapter.
• The electronics in the machine are RoHS compatible.
Before the machine is started up and used, the following points should be ob-
served:
• The SAFETY INSTRUCTIONS chapter must be studied carefully before
commissioning the machine.
• Installation of the machine must be performed in accordance with the re-
quirements and instructions indicated in the INSTALLATION INSTRUC-
TIONS and TECHNICAL SPECIFICATIONS chapters.
• Any personnel who may at some point use the machine must be trained in
its operation, use and care.
• The machine should not be used by anyone suffering from a physical or
mental illness.
• A close eye should be kept on any children in the vicinity of the machine to
ensure they do not tamper with it.
• All cover plates must be fitted during use.
The machine and equipment requires an annual service. Contact one of our au-
thorised and trained service companies for such a service.

WD-11 Rev. 00 (202310)
General instructions touch
2
1.1 Symbols used
This symbol warns of situations where a safety risk may arise. The instructions
given should be followed in order to prevent injury and dangerous situations.
This symbol on a machine part warns of electrical equipment. The machine must
be entirely non-live during servicing, turn off the power at the power switch and if
required, the switch should be locked to prevent unintentional operation. The
component may only be removed by a qualified electrician.
This symbol warns that the machine’s electronics are sensitive to electrostatic
discharge (ESD), which is why a static electricity wristband must be used when
handling the electronics at all times.
This symbol explains the right way to perform a task in order to prevent poor re-
sults and/or damage to the machine.
This symbol identifies recommendations and hints to help you get the best results
when washing, to increase the machine’s lifespan and reduce the risk of emer-
gency shutdown.
This symbol explains the importance of careful and regular cleaning of the ma-
chine to meet hygiene requirements.
This symbol warns of the importance to read the manual before using the ma-
chine.
This symbol warns that local regulations must be followed for recycling of pack-
aging etc. as well as the destruction of the machine.
This symbol shows where any earth cable for potential equalisation can be con-
nected. The earth bolt is placed on the machine’s stand.

WD-11 Rev. 00 (202310)
General instructions touch
3
1.2 Machine rating
The machine has two rating plates, one of which is placed at the bottom of one
side of the machine and the other in the electrical cabinet. The technical informa-
tion on the plates is also included on the machine’s wiring diagram. The various
rating fields show:
1. Machine type
2. Machine serial number
3. Year of manufacture
4. Enclosure protection class
5. Voltage
6. Number of phases with or without neutral
7. Frequency
8. Main fuse
9. Motor output
10. Electrical heating output
11. Max. output
1.3 Checking that the machine and manual correspond
Check that the type description on the rating plate corresponds with the type de-
scription on manual cover page. If manuals are missing, it is possible to order new
ones from the manufacturer or the local distributor. When ordering new manuals,
it is important to quote the machine number found on the rating plate.

WD-11 Rev. 00 (202310)
General instructions touch
4
1.4 EU Declaration of Conformity
A so-called EU Declaration of Conformity is provided on delivery of the machine.
1. Contact details of the manufacturer (Wexiödisk AB, Mårdvägen 4, SE-
35245 Växjö, SWEDEN, Tel.: [phone], E-mail: wexiodisk@wexio-
disk.com).
2. Representatives of Wexiödisk AB.
3. Person responsible for the product’s documentation.
4. Year of manufacture of the product.
5. The EU Directives with applicable provisions to which all the machines,
special machines and accessories comply.
6. Harmonised standards for the Directives specified, and which the ma-
chines, special machines and accessories meet, wherever relevant.
7. Model designation and serial number of the machines, special machines
and accessories the document applies to.
8. Place and date with signature and name (in block letters) of the person re-
sponsible for ensuring compliance with legislation and regulations.

WD-11 Rev. 00 (202310)
Safety instructions touch
5
2. Safety instructions
Read the chapter GENERAL INSTRUCTIONS carefully before starting work.
2.1 General information
The machine is CE marked, which means that it complies with the requirements
of the EU Machinery Directive with regard to product safety. Product safety
means that the design of the machine will prevent personal injury or damage to
property. The CE mark is only valid for an unmodified machine. Any damage to
the machine arising from failure to follow the instructions will invalidate the sup-
plier’s warranty and product liability.
Installation, repairs and servicing must be performed by an authorised engineer
in accordance with local and national rules in effect for such work with water and
drainage systems, electricity, ventilation and steam. To ensure electrical safety,
components must only be tested when fitted in their normal place in the machine.
We recommend that the work is performed by the manufacturer or one of the
manufacturer’s authorised service companies.
To further improve safety during installation, operation and servicing, the operator
and the personnel responsible for installing and servicing the machine should
read the safety instructions carefully.
The machine’s electronics are sensitive to electrostatic discharge (ESD), which is
why a static electricity wristband must be used when handling the electronics at
all times.
Before the machine enters service, ensure that the personnel are given the nec-
essary training in handling and looking after the machine.

WD-11 Rev. 00 (202310)
Safety instructions touch
6
In order to avoid dangerous situations, the following must be followed:
• Switch off the machine immediately in the event of failure or malfunction.
• Make sure the machine is non-live before removing the cover plate. Turn
off the power using the power switch. If required, the switch must be locked
to prevent unintentional operation.
• Shut off the tap for incoming water and drain the machine’s tank(s) before
starting work. Let the machine cool down as pipes for water, washing
pumps, booster heaters and valves become very hot when the machine is
in operation.
• The machine and equipment requires an annual service. The machine
should be serviced by a person authorised or trained to do so by us. Use
original spare parts.
• Warranty repairs must be performed by an authorised company. Contact
an authorised service company to draw up a programme of preventive care
and maintenance. For authorised service companies, please see
www.wexiodisk.com or contact Wexiödisk AB.
• The regular checks described in the manual must be carried out in accord-
ance with the instructions.
2.2 Transport
Handle the machine with care during unloading and transport; there is a risk of it
tipping over. Never lift or move the machine without using the wooden packaging
to support the stand.
2.3 Installation
• The machine is designed for quick electrical installation.
• The machine must be connected to a lockable power switch.
• Make sure that the mains voltage is the same as that indicated on the ma-
chine’s rating plate.
For increased safety, it is recommended to equip the installation with a ground
fault circuit breaker.
2.4 Detergent and drying agent
Be aware of the risks involved in handling detergents and drying agents. Protec-
tive gloves and safety glasses should be used when handling, and an eyebath
should be within easy access. Read the warning text on the detergent and drying
agent containers as well as the detergent supplier’s instructions.

WD-11 Rev. 00 (202310)
Safety instructions touch
7
2.5 Operation
Be very careful around the machine when it is in operation.
2.5.1 High temperatures
• The temperature of the washing and rinsing water is 60°C and 85°C. Do
not open the machine until the washing and rinsing phases have finished.
The steam that comes out of the machine after the wash has been com-
pleted is hot.
• Avoid touching hot pipes and booster heaters. The machine’s outer jacket
can also become hot during operation.
2.5.2 Risk of crushing
The machine, and any equipment, has moving parts before, during and after
washing. Be careful therefore to avoid crush injuries. In connection with service
or repairs that require the doors to be open, these must be secured by means of
a prop for example.
2.5.3 Risk of slipping
The floor should be kept clean and dry to eliminate any risk of slipping. Mop up
any water and leftover food that has been spilt.
2.5.4 Sounds
The machine is not silent during operation, see TECHNICAL SPECIFICATIONS.
Hearing protection may therefore need to be used.
2.6 Cleaning the machine
The water in the tank has a temperature of approximately 60°C and contains de-
tergent. Be careful when draining and cleaning the wash tank. Wear protective
gloves and safety glasses and have an eyebath within easy access.

WD-11 Rev. 00 (202310)
Installation instructions touch
8
3. Installation instructions
Read the chapters GENERAL INSTRUCTIONS and SAFETY INSTRUCTIONS
carefully before starting work.
3.1 General information
Read these instructions carefully, as they contain important information regarding
the correct installation method.
• The instructions should be used together with the machine's wiring dia-
gram and flow diagram. These can be found behind the cover plate for the
chemical wash zone.
• The machine can be equipped with a number of different options. Certain
options may be standard in a number of countries. Check what your ma-
chine is equipped with.
• If holes need to be drilled in the machine, the holes must be fitted with an
edge strip or similar protection.

WD-11 Rev. 00 (202310)
Installation instructions touch
9
3.1.1 Rust on industrial dishwashers
• Large-scale industrial dishwashers in general as well as our dishwashers
are made of stainless materials, but despite this, there are still situations
where rust can occur on “stainless” materials.
• We are going to describe a few reasons for this here, so that you, as a user,
service engineer or other type of personnel, can avoid this.
• Rust usually occurs due to the fact that something that is not stainless finds
its way onto the stainless surface. The non-stainless particles will soon
start to rust, and then contaminate the stainless material, which also starts
to rust. If no action is taken at this point, serious damage such as a hole in
the material can occur.
N.B.! If rust spots have developed, they must be dealt with immediately by a per-
son authorised to do so!
RISK SITUATION CAUSE DECLARATION / ACTION
Drilling holes when installing a
detergent device.
Using a drill or hole saw that has pre-
viously been used for ordinary non-
stainless materials.
“Contaminated” hole-drilling tools
can cause enormous damage in the
form of pores in stainless plates.
Never use a cutting tool that has pre-
viously been used on other materials
or blackplate.
Using blunt tools when drilling holes. Stainless plate, which has overheat-
ed during hole drilling, may lose its
“stainless” properties.
This can show up as rust around the
hole for the detergent cell.
Shavings from hole drilling. The shavings from drilling or hole
sawing are usually heated so much
that they lose their stainless proper-
ties.
They must always be removed by
hand! Washing after hole drilling is
not enough!
Rust spots that occur during nor-
mal operation and use.
Minerals, e.g. ferrous gravel or
earth, from dishware or food (vege-
tables and root vegetables) that has
been lying in crates, find their way
onto the stainless surface. Minerals
(gravel) can also be found on the
wheels of catering trolleys.
Daily cleaning is always important.
Use a suitable brush for “mechani-
cal” cleaning, e.g. in the wash tanks,
on the wash trays and filters.
Steel wool. Ordinary steel wool is not
stainless, and can cause serious
damage to stainless surfaces and
plates.
Use stainless cleaning pads. Re-
move all ordinary steel wool from the
catering facility / restaurant.

WD-11 Rev. 00 (202310)
Installation instructions touch
10
3.2 Requirements for the installation site
3.2.1 Lighting
In order to ensure the best possible working conditions during installation, opera-
tion, servicing and maintenance, make sure that the machine is installed in a well-
lit room.
3.2.2 Ventilation and ambient temperature
The machine is intended to be used in an indoor environment at normal room tem-
perature. The machine produces heat and steam when in operation. In order to
ensure the best possible working conditions, a certain air renewal rate is required
in the dishwashing room. The ventilation requirements for the dishwashing room
are to be dimensioned on the basis of the applicable standards.
3.2.3 Power supply
Power supply connections are made by qualified personnel in a way that complies
with local and national regulations. The machine’s capacity requirements are stip-
ulated in TECHNICAL SPECIFICATIONS.
3.2.4 Water
Water connections are made by qualified personnel in a way that complies with
local and national regulations. The machine’s capacity requirements are stipulat-
ed in TECHNICAL SPECIFICATIONS.
3.2.5 Drain/waste pipe
There must be a waste pipe with an effective trap for the machine’s waste water
and for water used for rinse cleaning. The machine’s capacity requirements for
drainage are stipulated in TECHNICAL SPECIFICATIONS.
3.2.6 Space for servicing
A 1-metre area should be left clear in front of the machine for servicing purposes.
Depending on if the machine has different accessories, there may also be such a
requirement at the infeed and outfeed ends as well as above the machine.

WD-11 Rev. 00 (202310)
Installation instructions touch
11
3.3 Transport and storage
Always transport the machine in an upright position.
Take care during transport, as there is a risk of tipping. N.B.! The machine must
not be transported without a pallet or other support. Some form of support beam
must always be used along the sides of the machine during transport. Otherwise
the machine may become damaged. When transporting the machine without a
normal wooden pallet, always check that none of the components underneath the
machine can be damaged.
A=Pumps
B=Spacers
If the machine is not being installed immediately, it must be stored in a frost-free
area where the air is dry.
3.3.1 Unpacking
Check that all parts have been delivered by comparing them with the delivery
note.
Remove the packing material. Inspect the machine for any transport damage.
Recycling
• The machine is manufactured from stainless steel plate, among other
things, and also contains electronic components. Recycling of the appli-
ance when its economic lifetime has been reached must be carried out in
accordance with current rules and regulations.
• Packaging must be sent for destruction or recycling in accordance with lo-
cal regulations.
A AB B

WD-11 Rev. 00 (202310)
Installation instructions touch
12
3.4 Installation
3.4.1 Preparing for the installation
Check that there is sufficient room for the machine at the installation location.
• Check that correct connections are available for water, electricity, drainage
and possibly steam at the installation location. See TECHNICAL SPECIFI-
CATIONS.
• Check that the overheating protection device is reset.
3.4.2 Positioning the machine
Check the following points before the machine is placed in position:
• Check that the fuse for the machine at the site is off, blocked and that out-
going electrical circuits from the machine are non-live.
• Remove the protective plastic on the sides which are to be stood against a
wall.
• The distance between the wall and machine should be at least 30 mm.
Place the machine in position and check that it, and any accessories, are horizon-
tally level. Place the spirit level on the join between the machine tank and the up-
per part. Adjust the height with the legs.
The machine must be evenly balanced on three sides:
• On the cover edge of the front side (a) (tank body).
• On the cover of the infeed (b).
• On the cover of the outfeed (c).
Once the machine has been filled with water, do another check to make sure the
machine is horizontal.
11t_plac
a
cb

WD-11 Rev. 00 (202310)
Installation instructions touch
13
3.5 Connections
1. Electrical connection
2. Hot water connection, (cold water connection (option))
3. Drain/waste pipe connection
4. Floor drain
5. Ventilation connection, outfeed
6. Alternative electrical connection
7. Alternative hot water connection, (cold water connection (option))
8. Alternative drain connection
9. Non-return valve
10. Vacuum valve
11. Detergent dosage outlet
12. Ventilation connection, infeed
3
43
12 17
2
5
6
3
11 10 92
6
8
7
min.30
7
21
313155

WD-11 Rev. 00 (202310)
Installation instructions touch
14
3.5.1 Electrical connection
Information about electrical connections is available on the machine’s wiring dia-
gram which is provided on delivery. Store these in the special plastic document
wallet.
• The machine is designed for quick electrical installation.
• The machine must be connected to a lockable power switch. This should
be placed on a wall, well-protected from water and from the steam which
escapes when the machine is opened.
• Connect the cable at (1), or alternatively the machine may have an electri-
cal connection from the floor (6). Protect the incoming cable with, e.g. Pipe
for connection cable, WD212.4102 (option).
• Check the direction of rotation of the pump motors during operation when
the tanks are full of water. The direction of rotation must conform without
exception to the direction of the arrow on the pump. Stop the dishwasher
immediately if the direction of rotation is incorrect and change two of the
incoming phases.
After completing the installation, switch on the power switch and all circuit break-
ers.
3.5.2 Water connection, regardless of any options
• A shut-off cock must be installed on the incoming pipe.
• It is important that the water supply has sufficient pressure to ensure the
correct flow of water to the machine. The required water flow and pressure
can be found in the TECHNICAL SPECIFICATIONS. If the water pressure
is too low, a booster pump must be fitted.
The water pipe is connected at (2), or alternatively at (7). If the machine is con-
nected with a hose, this should be steel braided and have an internal diameter of
at least 12 mm.
The water connection on the machine is fitted with a filter, non-return valve and
vacuum valve.
As the machine is fitted with a “break tank”, the connection is fitted with a filter and
non-return valve.
3.5.3 Ventilation
The machine’s heat load for the room is stipulated in TECHNICAL SPECIFICA-
TIONS.
Connection to the ventilation duct is done at the outfeed (5) and the infeed (12).
If a hood is fitted over the machine, it must cover the drying rack after the ma-
chine.

WD-11 Rev. 00 (202310)
Installation instructions touch
15
3.5.4 Drain/waste pipe
The waste water system connected to (3 or 8) should consist of a 50mm metal
pipe that will withstand mechanical impacts. The waste pipe must run to a floor
drain, where its opening must be above the water level.
The drain can be fitted to the right or left. Remove the perforated section of the
end plate and pull the pipe through the hole. Connect the drain and run to the floor
drain where it should flow freely above the water level.
Ensure that the drain connection is kept in place by using e.g. cable ties in the
designated areas.
3.5.5 Detergent and drying agent
• Check what your machine is equipped with, which depends on the model,
machine type and country.
• Use the same make and type of detergent and drying agent.
• With machines connected to cold water, the water pipe temperature may
be too low for use of powder or paste type detergents.
• If liquid detergent is used together with Wexiödisk’s detergent pump, the
detergent must be placed under the machine’s tank level.
If equipment for a different type of detergent is used, it should preferably be put
on the wall behind the machine to avoid holes being drilled unnecessarily in the
machine.
The process of setting the detergent and drying agent dispenser is described in
the ADJUSTMENT INSTRUCTIONS.
For information about wiring diagram, see the machine's wiring diagram.

WD-11 Rev. 00 (202310)
Installation instructions touch
16
Connection of the equipment
1. Hot water outlet
2. Alternative location of detergent equipment
3. Hole ø 25 mm for hose intended for detergent in solid form
4. Hole ø 19 mm for drying agent hose
5. Plugged connection ø 18 mm for connecting hose for detergent in solid
form
6. Drying agent dosage outlet
7. Plugged connection in the chemical wash tank ø 11 mm for liquid detergent
8. Plugged connection for measuring cell for measuring the detergent con-
centration in the chemical wash tank. The measuring cell is connected in
the junction box (10).
9. “DETERGENT” adhesive label. The label is affixed to the inside rear wall
of the chemical wash tank and indicates the alternative position of the de-
tergent opening. Drill a hole from the back of the chemical tank through the
plugged hole in the rear cover plate.
10. Junction box with connections for detergent and drying agent.
WD11t_05
9
8
7
10
65
4
3
21
