Wexiodisk WD-B 500 User manual

FLIGHT-TYPE DISHWASHER
WD-B 500 - WD-B 900
(translation of the original documentation)
Installation and user manual
S/N: Validfrom:2012-08-01Rev.:4.0

WD-B500-WD-B900Rev.4.0 (201208)
1. General information ......................................................................... 1
1.1 Symbols used in this manual ........................................................................... 1
1.2 Symbols on the dishwasher ............................................................................. 1
1.2.1 Machine marking ...................................................................................... 2
1.3 RoHS compatible ............................................................................................. 2
1.4 Checking that the machine and the manual correspond .................................. 2
2. Safety instructions ........................................................................... 3
2.1 General information ......................................................................................... 3
2.2 Transport .......................................................................................................... 3
2.3 Installation ........................................................................................................ 3
2.4 Detergent and drying agent ............................................................................. 4
2.5 Operation ......................................................................................................... 4
2.5.1 Crushing risk ............................................................................................. 4
2.5.2 Risk of slipping .......................................................................................... 4
2.6 Safety instructions if the machine is not functioning ........................................ 4
2.7 Cleaning ........................................................................................................... 5
2.7.1 Pressure washing ..................................................................................... 5
2.7.2 The outside of the machine ...................................................................... 5
2.7.3 Cleaning the floor ...................................................................................... 5
2.8 Repairing and servicing the dishwasher .......................................................... 5
2.9 Recycling the machine ..................................................................................... 5
3. Installation ........................................................................................ 6
3.1 General information ......................................................................................... 6
3.2 Requirements for the installation site ............................................................... 6
3.2.1 Lighting ..................................................................................................... 6
3.2.2 Ventilation ................................................................................................. 6
3.2.3 Drains ....................................................................................................... 6
3.2.4 Space for servicing ................................................................................... 7
3.3 Transport and storage ...................................................................................... 7
3.4 Marking of sections .......................................................................................... 8
3.5 Unpacking ........................................................................................................ 9
3.6 Installation ...................................................................................................... 10
3.6.1 General information ................................................................................ 10
3.6.2 Assembly of sections .............................................................................. 11
3.6.3 Pipes ....................................................................................................... 13
3.6.4 Assembling the track and conveyor belt ................................................. 13
3.6.5 Other assembly ....................................................................................... 14
3.6.6 Placement against a wall ........................................................................ 14

WD-B500-WD-B900Rev.4.0 (201208)
3.7 Connections ................................................................................................... 15
3.7.1 Water connection .................................................................................... 16
3.7.2 Steam connection (option) ...................................................................... 16
3.7.3 Condensation water connection (option) ................................................ 16
3.7.4 Drain connection ..................................................................................... 17
3.7.5 Detergent and drying agent .................................................................... 17
3.7.6 Ventilation ............................................................................................... 17
3.7.7 Electrical connection ............................................................................... 18
3.8 Checking and setting the final rinse flow ........................................................ 19
3.9 Filling booster heater 3 with R/O water (option) ............................................. 20
3.10 Adjusting the air flow in the drying zone ...................................................... 21
3.10.1 WD-B 500, electrically heated, one drying zone ................................... 22
3.10.2 WD-B 600, electrically heated, one drying zone ................................... 22
3.10.3 WD-B 700, electrically heated, one drying zone ................................... 22
3.10.4 WD-B 800, electrically heated, two drying zones ................................. 22
3.10.5 WD-B 900, electrically heated, two drying zones ................................. 22
3.11 Cleaning the exterior .................................................................................... 23
3.12 Trial run ........................................................................................................ 24
3.12.1 Start-up schedule .................................................................................. 24
3.13 Technical documentation ............................................................................. 26
4. Instructions for use ........................................................................ 27
4.1 Preparations ................................................................................................... 28
4.1.1 The machine's design ............................................................................. 28
4.1.2 Preparations before filling ....................................................................... 30
4.1.3 Filling and heating the machine .............................................................. 30
4.2 Using the machine ......................................................................................... 31
4.2.1 Washing .................................................................................................. 31
4.2.2 Emergency stop ...................................................................................... 32
4.2.3 Lights which indicate alarms (option) ...................................................... 33
4.2.4 Changing the water ................................................................................. 33
4.3 After use ......................................................................................................... 33
4.3.1 End of wash, cleaning ............................................................................. 33
4.3.2 Daily cleaning ......................................................................................... 34
4.3.3 Cleaning and checking each week or as required .................................. 36
4.3.4 Operating problems ................................................................................ 37
5. Technical specifications ................................................................ 43

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
General information
1
1. General information
Read the instructions in this manual carefully as they contain important informa-
tion regarding the correct, effective and safe installation, use and servicing of the
dishwasher.
Keep this manual in a safe place so that it can be used by other operators of the
dishwasher.
1.1 Symbols used in this manual
This symbol warns of situations where a safety risk may arise. The instructions
given should be followed in order to prevent injury.
This symbol on a machine component warns of the presence of electrical equip-
ment. The machine is sensitive to electrostatic discharge (ESD), and a static elec-
tricity bracelet must therefore be used when handling the electronics.
This symbol explains the correct way to perform a task in order to prevent poor
results, damage to the dishwasher or hazardous situations.
This symbol identifies recommendations and hints to help you to get the best per-
formance from the machine.
This symbol explains the importance of careful and regular cleaning of the ma-
chine to meet hygiene requirements.
1.2 Symbols on the dishwasher
This symbol on a machine component warns of the presence of electrical equip-
ment. The component may only be removed by a qualified electrician. The ma-
chine is sensitive to electrostatic discharge (ESD), and a static electricity bracelet
must therefore be used when handling the electronics.

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
General information
2
1.2.1 Machine marking
The rating plates are located at the bottom of the outfeed side and in the electrical
cabinet. The technical information on the plates is also included on the machine's
wiring diagram. The various rating fields show:
1. Machine type
2. Machine serial number
3. Year of manufacture
4. Enclosure protection class
5. Voltage
6. Number of phases, with or without zero
7. Frequency
8. Main fuse
9. Motor output
10. Electrical heating output
11. Max. output
1.3 RoHS compatible
The machine is RoHS compatible, which means that it meets the requirements of
the RoHS directive concerning substances in electrical and electronic products
which are hazardous and harmful to the environment.
1.4 Checking that the machine and the manual correspond
Check that the type description on the rating plate corresponds with the type de-
scription on the front of the manual. If manuals are missing, it is possible to order
new ones from the manufacturer or the local distributor. When ordering new man-
uals, it is important to quote the machine number found on the rating plates.
S/N:
VHz A
kW kW kW
Type
Mårdvägen 4, S-352 45 VÄXJÖ SWEDEN
M
IP
1
marks_SAP
2
5
9
6
4
8
11
3
7
10

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Safety instructions
3
2. Safety instructions
2.1 General information
The machine is CE marked, which means that it complies with the requirements
of the EU machinery directive with regard to product safety. Product safety means
that the design of the machine will prevent personal injury or damage to property.
Modifying the equipment without the approval of the manufacturer invalidates the
manufacturer’s product liability.
To further improve safety during installation, operation and servicing, the operator
and the personnel responsible for installing and servicing the machine should
read the safety instructions carefully.
Switch off the machine immediately in the event of a fault or malfunction. The ma-
chine must only be serviced by trained engineers. The regular checks described
in the manual must be carried out in accordance with the instructions. The ma-
chine must be serviced by a person authorised to do so by the manufacturer. Use
original spare parts. Contact an authorised service company to draw up a pro-
gramme of preventative maintenance. Hazardous situations may arise if the in-
structions above are not followed.
Before using the machine, ensure that personnel are given the necessary training
in operating and maintaining the machine.
2.2 Transport
Handle the machine with care during unloading and transport to avoid the risk of
it tipping over. Never lift or move the machine without using the wooden packag-
ing to support the stand.
2.3 Installation
The electrical cabinet must only be opened by an authorised electrician. The ma-
chine is sensitive to electrostatic discharge (ESD), and a static electricity bracelet
must therefore be used when handling the electronics.
Water and steam pipes must only be connected by authorised personnel.
Water pipes must be connected in a way that complies with the current regula-
tions of the local water supply authority. Check the tightness of the water and
steam connections before operating the machine.
Make sure that the mains voltage is the same as that indicated on the machine's
rating plate.

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Safety instructions
4
2.4 Detergent and drying agent
Only detergent and drying agent intended for industrial dishwashing machines
must be used. Ordinary washing-up liquid must not be used in the machine or for
pre-treating items (soaking, pre-washing, etc.). Contact your detergent supplier
regarding the choice of a suitable detergent
Be aware of the risk of handling washing and drying agents. Protective gloves and
safety glasses should be used when handling dishwasher detergent. Read the
warning text on the detergent and drying agent containers as well as the deter-
gent supplier's regulations.
2.5 Operation
2.5.1 Crushing risk
Avoid contact with the conveyor belt during use. The movement of the belt can
cause crushing injuries at the inlet and outlet of the machine. When servicing the
machine, avoid contact with the conveyor belt’s drive system during use. Crush-
ing injuries can occur between the drive motor’s chain and the chainwheel.
2.5.2 Risk of slipping
Keep the floor dry to eliminate any risk of slipping. Mop up any water which has
been spilled.
2.6 Safety instructions if the machine is not functioning
Check the following:
• Does the display show any error messages?
• Has the machine been used according to the instructions?
• Are all the removable parts in the correct place?
• Is the main switch in the ON position?
• Are the fuses in the electrical cabinet undamaged? Ask the service person-
nel to check the fuses.
If this does not solve the problem, ask authorised service personnel to check the
machine.

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Safety instructions
5
2.7 Cleaning
The water in the chemical wash tank is at a temperature of approx. 60°C and con-
tains detergent. Be careful when emptying and cleaning the tanks. Use protective
gloves.
2.7.1 Pressure washing
The machine must not be cleaned with a pressure washer, either inside or out.
In order to satisfy current requirements, electrical components of approved enclo-
sure classes are used. No enclosure classes are designed to withstand pressu-
rised water.
2.7.2 The outside of the machine
Pressure washers and hoses must not be used to wash the outside of the ma-
chine. Water can penetrate into the electrical cabinet and the control panel and
damage the equipment, which may affect the safety of the machine.
2.7.3 Cleaning the floor
When the floor is washed, water can splash up under the machine and damage
the components. These have not been designed to withstand being washed with
water. Do not wash the floor within 1 metre of the dishwasher. Pressure washers
have special protective cases which can be fitted to prevent water splashing.
Problems with splashing can also occur when using ordinary hoses.
2.8 Repairing and servicing the dishwasher
Disconnect the power supply before removing the front panels. Avoid touching
hot pipes and the booster heaters.
2.9 Recycling the machine
When the dishwasher has reached the end of its service life, it must be recycled
in accordance with current regulations. Contact professionals who specialise in
recycling.

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Installation
6
3. Installation
3.1 General information
The machine must be installed by authorised personnel only.
Read these instructions carefully, as they contain important information regarding
the correct installation method.
The instructions should be used together with the machine drawing, wiring dia-
gram and flow diagram.
he machine is CE marked. The CE mark is only valid for machines that have not
been modified. If the machine is damaged as a result of the instructions not being
followed, this invalidates the supplier's guarantee and the product liability.
3.2 Requirements for the installation site
3.2.1 Lighting
In order to ensure the best possible working conditions during installation, opera-
tion, servicing and maintenance, make sure that the machine is installed in a well-
lit room.
3.2.2 Ventilation
The machine produces heat and steam when in operation. In order to ensure the
best possible working conditions, a certain air change rate is required in the dish-
washing room. The ventilation requirements for the room should be calculated on
the basis of current standards.
3.2.3 Drains
There must be a floor drain with an effective trap for the machine's waste water
and for water used for cleaning. The drain should be located under the machine's
loading bench. The floor drain capacity can be found in the TECHNICAL SPECI-
FICATIONS.

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Installation
7
3.2.4 Space for servicing
The area above the machine must not contain any equipment which could pre-
vent the fitting, servicing and replacement of parts. A free height of at least 2.8
metres is required in order to remove the inspection doors.
A 1-metre free space should be allowed in front of the machine and around the
infeed and outfeed ends for service purposes.
3.3 Transport and storage
Check that there is sufficient height available to transport the machine to its instal-
lation site.
The machine is supplied in sections with a pallet under each section. Transport
each section to the installation site using a handtruck.
The sections are transported transversely with the forks of the truck inserted from
the long side. (The side marked “FRONT”). If the space available does not permit
transverse transport, each section should be transported using two handtrucks,
one at each short end. Do not lift the machine by its legs. These are indicated by
labels on the outside of the packaging.
Label which marks the position of the legs
Take care during transport, as there is a risk of the equipment tipping over.
NOTE: The machine must not be transported without a pallet or other support,
Some form of support beam must always be used along the sides of the machine
during transport. otherwise the machine may become damaged. When transport-
ing the machine without an ordinary pallet, always check that none of the compo-
nents underneath the machine can be damaged.
f the machine is not to be installed immediately, it must be stored in a frost-free
area where the air is dry.
Lyftanvisn

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Installation
8
3.4 Marking of sections
The machine is normally divided into two sections. In some cases the machine
can be delivered in more than two sections. The installation instructions describe
the assembly of a machine that has been split into two sections. Regardless of
the number of sections, the assembly of all sections is undertaken in the same
way. The sections are marked on the outside of the packaging with the following
information.
• Numbering 1-2. Section 1=infeed section with washing zones, Section
2=outfeed section with final rinse and drying zone.
• Arrows which indicate the feed direction of the machine.
• Marking of the front. FRONT=Front.
Section marking on the packaging
1 2
FRONT FRONT
sektmärkn

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Installation
9
3.5 Unpacking
• Check against the delivery note that all the units have been delivered.
• Remove the packaging, but leave the pallet and any transport supports in
place.
• Inspect the machine for any transport damage.
• Lift the section at both ends using a handtruck. Screw down the legs (B) so
that they extend below the bottom of the pallet (C). Lower the section. Split
the pallet and take it away.
• If the section should need to be lifted again from the short sides, a wooden
runner should be placed under the cross-bar (A) on the section stand.
A=Stand cross-bar
B=Leg
C=Pallet
D=Handtruck
Packaging must be disposed of or recycled in accordance with local regulations.
Uppackn
AA
B C D

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Installation
10
3.6 Installation
3.6.1 General information
Parts which must be assembled are prepacked inside each machine section to-
gether with the necessary bolts, nuts, etc.
Remove all lower cover plates (5).
The final position of the machine is either free-standing in the room or placed with
the back against a wall. If the machine is to be placed against a wall, the assembly
should be carried out with sufficient space behind the machine for access during
the fitting of components on the back of the machine. The fully assembled ma-
chine is then pushed into position.
The picture below shows a machine with the feed direction from left to right. The
picture shows parts which must be assembled during the installation and the ad-
justing device for tensioning the conveyor belt. The length of the infeed and out-
feed section and the number of zones vary depending on the specific machine.
For this reason, the illustration below shows the approximate position of the com-
ponents in the machine.
1. Adjusting screws for the conveyor belt
2. Tension wheel
3. Upper track
4. Chain
5. Coverplate
6. Drainage plate
7. Lower track
8. Belt tensioner
9. Coverplate
10. Overflow pipe
WDB-07
1 2
3
45
6
7
8
9
10

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Installation
11
3.6.2 Assembly of sections
• Remove any transport supports.
• Place section 2 in the appropriate place at the right height. Check that the
section is horizontal using a spirit level (on the tank body). Adjust the ma-
chine using the legs.
• Fit the joining tube to the stand on section 2.
Assembling the joining tube
A=Leg
B=Stand
C=Joining tube
D=M6x10 Bolts
• Place section 1 next to section 2 so that the rectangular metal pieces on
the stands of both sections are in line with each other. Check that section
1 is horizontal using a spirit level (on the tank body). Adjust using the legs.
• Push section 1 against section 2 until the rectangular metal pieces on the
stand are pushed close to each other, but do not push the sections com-
pletely together. There should still be a distance between them in order to
apply the silicon around the openings.
• Apply plenty of silicon around the openings of both sections and around all
bolt holes. Place two strands of silicon along the lower edge.
• Push the sections together. Hold them together with a screw clamp and fit
the bolts that hold the hoods together. Lock the stand on the front and back
of the machine using two M6x10 bolts. Check that the machine is horizontal
using a spirit level (on the tank body).
Application of silicon
A=Bolt hole
B=Silicon
Skarvrör
A
D
B
C
Silikon
A
B
B

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Installation
12
Locking the stand
A=Leg
B=Joint on the stand
C=Stand
D=M6x10 Bolts
E=Joining tube
Assembly of clamp strips and upper cover plates
• When the sections have been fitted together, the clamp strips (A) should
be fitted inside the joint. Fit the upper clamp strip first. Apply a small amount
of silicon to the strips before fitting them into place.
• Seal the joint between the sections on the outside of the machine (back and
top) using silicon. Attach masking tape to both sides of the joint and fill the
joint with silicon.
• Fit the upper cover plate (9) between the sections.
Assembling the clamp strips
A=Clamp strip
Skarv
A
D
B
C E
Kl ämlist
A
A

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Installation
13
3.6.3 Pipes
Fit together all pipes for water, steam, condensation water and waste (pipe for
steam and condensation water on steam-heated machines only). The pipes are
split at the section join. The necessary parts for joining the pipes together are fit-
ted to the pipes at the joint. The pipes should be lubricated with a sealant before
joining.
3.6.4 Assembling the track and conveyor belt
Screw the upper and lower tracks (3, 7) of the conveyor belt together at the join
between the sections using the support plates and nuts supplied.
Locking the upper and lower tracks
A=Upper track
B=Joint
C=Flange nuts
D=Support plate
E=Lower track
• Fitting the drainage plate (6).
• Fit the overflow pipe (10) between the tanks.
• Joint the belt if it is in position in the machine.
• If the belt is not in position, the installation is carried out as follows:
• Feed in the belt on the upper track through the outfeed opening. Pull the
belt through the machine through to the infeed opening and around the ten-
sion wheel (2).
• Use a piece of rope and pull the belt back on the lower track to the outfeed
opening. Join the ends of the belt.
• Tension the belt. Undo the screws for the belt sections (8). The screws are
accessible from the inside of the infeed section. Tension the belt using the
adjusting screws (1). When the belt is sufficiently taut, it should be possible
to lift it by about 5cm at the centre of the infeed. Tighten the screws for the
belt tensioners (8).
Bana
A
B
C
D
E
C
D

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Installation
14
3.6.5 Other assembly
• Fit the chain (4) to the drive motor.
• Pull out and connect the electric cables for the pumps and other compo-
nents. The cables are located at the section joint.
• Each cable is marked with the same designation as the component to
which it must be connected. The marking for each component is on the
component itself and on the machine's stand. The cables are placed in ex-
isting cable runs.
3.6.6 Placement against a wall
If after assembly the machine is to be moved and placed with the back against a
wall, place wooden runners under the stand and push the machine into position
with the aid of a handtruck.
Using a spirit level (on the tank body) check that the machine is horizontal and
adjust the legs of the machine if necessary.

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Installation
15
3.7 Connections
The picture below shows a machine with the feed direction from right to left. The
length of the infeed and outfeed and the number of washing and drying zones
vary depending on the size of the machine. The machine can also operate in the
opposite direction. For the exact location of the various connections, see the spe-
cific diagrams for each machine which are supplied by the manufacturer.
1. Extractor 400x100 mm without damper
2. Electrical connection from ceiling
3. Alternative electrical connection from floor
4. Hot water connection 55-70°C, (Connection from floor or ceiling)
5. Cold water connection 5-12°C, (Connection from floor or ceiling)
6. Condensation water connection (Steam-heated machines)
7. Steam connection (Steam-heated machines. Connection from floor or ceil-
ing).
Steam pressure 50-140 kPa (Fully steam-heated machine).
Steam pressure 150-250 kPa (Electrically heated drying zone).
8. Floor drain 400x600 mm
Check that the overheating protection on booster heaters and tank elements is
set to zero.
21
7
6
5
4
3
8
84
5
7
6
1
200
0
1
WDB_08
2

WD-B 500 - WD-B 900 Rev. 4.0 (201208)
Installation
16
3.7.1 Water connection
The machine is supplied as standard without stopcocks for the water supply.
Stopcocks must be installed on incoming pipes.
It is important that the water supply has sufficient pressure to ensure the correct
flow of water to the machine. Water pressure: 300-600 kPa.
The hot water connection is fitted with a filter. The cold water connection has a
filter, non-return valve, safety valve and vacuum valve.
The cold water connection can be fitted with a break tank (option), which is avail-
able as extra equipment. In this case the connection has a filter and non-return
valve.
When installing a connection from the ceiling, the pipes must be fed from above
down through the cable duct behind the cover plate (A) next to the electrical cab-
inet. Remove the cover plate and break away the perforated plate on top of the
cover plate.
Connection from ceiling
A=Cover plate
3.7.2 Steam connection (option)
A steam connection is only provided on steam-heated machines. The connection
is fitted with a filter. The machines are supplied as standard without shut-off valve
for steam. A shut-off valve must be installed on the incoming pipe. When connect-
ing a pipe from the ceiling, it is taken into the same area as the water pipes behind
the cover plate next to the electrical cabinet.
3.7.3 Condensation water connection (option)
A condensation water connection is only provided on steam-heated machines.
The pipe is connected to the system’s steam boiler.
Täckplåt
A
