Whirlpool 3RAWZ481EML2 User manual

TOP AND CONSOLE PARTS
1
For Model: 3RAWZ481EML2
(Pewter)
6−05 Printed in U.S.A. (LT) Part No. 8180715
ELECTRIC DRYER

TOP AND CONSOLE PARTS
2
For Model: 3RAWZ481EML2
(Pewter)
8180715
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
8545902 Label,
Wiring Diagram
8577079 Use & Care Guide
8563878 Installation
Instructions
8315975 Installation
& User Guide
2 3980096 Top
3 8543289 Harness, Main
4 3979740 Panel, Console
(Includes
Illus. 13, 14
15, 17, 18 & 19)
5 3394427 Clip, Harness
6 3980123 Bracket, Console
7 353424 Connector, Sensor
8 94614 Terminal
9 3936144 Plug, Terminal
10 94613 Terminal
11 3390647 Screw, 8−18 x 1/2
12 488886 Screw, 8−18 x 1/2
13 3980121 Button,
Push−To−Start
14 3979738 Bracket, Timer
15 3979743 Bracket,
Switch Mounting
16 8281225 Screw, 8−18 x 1/2
17 8543319 Medallion
18 3956540 Console, Center
19 3400238 Screw, 2−28 x 1/2
20 3980205 Timer
21 3951198 Fuse
22 3390646 Screw, 8−18 x 5/16
23 3980421 Spacer Plate
(Timer)
24 8316076 Switch,
Wrinkle Guard
25 8522378 Buzzer, Mini
26 8562100 Switch,
Push−To−Start
27 3399642 Switch,
Temperature
28 8543291 Harness, Console
29 3347243 Connector,
6−Circuit
30 3397269 Connector, Timer
31 3401144 Connector
(PTS Relay)
32 692997 Connector
33 3980218 Knob,
Timer Assembly
34 3980129 Knob, Control (2)
35 3980339 Shield, Drip

CABINET PARTS
3
For Model: 3RAWZ481EML2
(Pewter)
8180715

CABINET PARTS
4
For Model: 3RAWZ481EML2
(Pewter)
8180715
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8317342 Cover,
Terminal Block
2 98139 Screw, 8−32 x 5/16
3 697776 Screw, 10−32 x 5/8
(Ground)
4 3397659 Block, Terminal
5 8318457 Switch, Broken
Belt
6 8521947 Dry Rack
(Top)
7 8519216 Panel, Side (L.H.)
8 3392100 Foot, Dryer
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
9 660658 Clamp, Motor (2)
10 3387374 Spring, Idler
11 3389420 Retainer, Idler
12 3979261 Plug, Multivent
13 3388672 Pulley Assembly
14 279318 Terminal, Brass
& Tinned (3)
(Includes Illus. 33)
15 8066120 Lever, Snap
Switch
16 3394081 Wire, Belt Switch
17 8564132 Sound Panel
18 233520 Washer, Thrust
19 8543119 Wire, Jumper
(Includes
Illus. #41)
20 690997 Tri Ring
21 8066115 Cover−Plate
22 8529053 Ramp, Door
23 8521961 Dry Rack
Support
24 8519217 Panel, Side (R.H.)
25 8521950 Dry Rack
Assembly
26 3393657 Restrainer, Belt
27 3404470 Motor, Assembly
50 HZ.
29 3402548 Pulley 50 HZ.
30 3387610 Belt, Drive
31 8541503 Kit,
Stack Assembly
32 3387118 Bracket, Motor
33 279393 Terminal Block
Screw Kit (For
Terminal Block)
34 49026 4" − 90 Elbow
35 8316644 Clip,
Strain Relief
36 3395532 Exhaust Pipe
& Bracket
37 3395534 Exhaust Pipe
(Short)
38 3395535 Exhaust Pipe
(Long)
39 3388674 Idler Bracket
41 8541808 Switch, Door
42 3400934 Screw,
6−20 x 1 1/16
43 3390647 Screw, 8−18 x 1/2
44 3387242 Seal, Front Panel
45 3393008 Screw, 10−16 x 1/2
46 8519459 Clip, Toe Panel
47 340025 Wire, Ground
50 8519207 Base, Cabinet
51 8562170 Front Panel
52 696144 Strike, Door (2)
53 90767 Screw, 8−18 x 3/8
56 8519273 Bracket, Control
61 3980095 Toe, Panel
62 8543118 Panel, Rear
63 692400 Nut, Push−In
64 3400097 Screw, 10−24 x 3/8
Optional Parts Not Included
Dryer Exhaust Kit
(For Side & Bottom Venting)
66 279969 Grey

BULKHEAD PARTS
5
For Model: 3RAWZ481EML2
(Pewter)
8180715

BULKHEAD PARTS
6
For Model: 3RAWZ481EML2
(Pewter)
8180715
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 3399508 Shaft, R.H. Thread
2 3390647 Screw, 8−18 x 1/2
3 3394984 Door, Lint
Screen
4 98139 Screw, 8−32 x 5/16
5 697354 Air Duct Assembly
6 697813 Seal, Outlet
Housing
7 697814 Seal, Drum Front
8 3359452 Nut,3/8 x 16(R.H.)
9 8066086 Drum Hole
Plug
10 696302 Shield, Exhaust
12 3388229 Clip, Exhaust
Pipe
13 3390646 Screw, 8−18 x 5/16
14 3387749 Heater Element
15 279457 Terminal Wire
Kit (For Heater
Element Wiring
Harness Repair)
16 3387709 Nut, 3/8−16 (L.H.)
17 3387809 Bulkhead, Rear
18 3387459 Washer, Support
19 3399509 Shaft, L.H. Thread
20 690997 Ring, Tri
21 8536973 Roller, Support
22 3402715 Exhaust Pipe
23 3394985 Housing, Outlet
24 8529007 Plug,
Rear Bulkhead
25 8543082 Complete Drum
Assembly
26 97787 Screw, 11−16 x 3/4
27 697694 Seal, Drum
28 695240 Screw, 8−18 x 1/2
29 90767 Screw, 8−18 x 3/8
30 8519221 Channel Bracket,
Rear Bulkhead (2)
31 8519275 Bracket, Upper
Rear Bulkhead
34 3357011 Screw, 10−16 x 1/2
37 697772 Wheel, Blower
39 3394986 Spring, Lint
Screen Door
42 3387137 Thermistor
44 8544362 Housing, Blower
45 8066168 Lint Duct Assembly
46 3392537 Heater Box
47 3977394 Thermal Cut−Off
(Includes
Illus. 48)
48 3390291 Thermostat 250 F
(121 C)
50 8066099 Bracket,
Heater Box
51 3387230 Screw, 10−16 x 1
53 697693 Baffle, Drum
54 8519245 Bulkhead, Front
58 8299979 Grill, Outlet
59 3392519 Thermal Fuse
60 697770 Seal, Cover Plate
64 8066170 Lint, Screen

DOOR PARTS
7
For Model: 3RAWZ481EML2
(Pewter)
8180715
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8563855 Plug, Strip
2 8565678 Door Hinge
Assembly
3 3980214 Cover,
Door Hinge
4 9742177 Screw, 8−18 x 5/8
5 342043 Screw, 10−32 x 3/8
7 8559752 Handle, Door
8 3400224 Screw,
1/4−20 x 1/2
9 8519374 Plug,
Door Handle (2)
10 8557500 Door Assembly
(Inner)
(Includes
Illus. 14)
11 355515 Screw,
8−18 x 11/16
12 3980213 Door, Outer
13 8545879 Window
14 3389441 Door Catch
Assembly

OPTIONAL PARTS (NOT INCLUDED)
8
For Model: 3RAWZ481EML2
(Pewter)
8180715
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
4396174 Pewter
PAINT, PRESSURIZED SPRAY
(12 oz.)
4396175 Pewter
350938 Primer, Gray
ACCESSORY PARTS
8529894 Hold Down Kit
