TOP AND CONSOLE PARTS
1
For Model: 3RLEC8646KQ0
(Designer White)
7−02 Litho in U.S.A. (djc) Part No. 4320281 Rev. A
27"ELECTRIC DRYER

TOP AND CONSOLE PARTS
2
For Model: 3RLEC8646KQ0
(Designer White)
4320281
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
LIT8299807 Label, Wiring
Diagram
LIT8318343 Guide, Use & Care
LIT8528094 Instructions,
Installation
LIT8315975 Guide, User &
Installation (UK)
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
LIT677818 Manual, Do−It−
Yourself Repair
(Dryer)
2 8317305 Panel, Rear Console
3 8299769 Timer
4 8316077 Switch, Clean Touch
5 8318447 Switch,
Push−To−Start
6 693995 Screw, 8−18 x 3/8
7 Wire, Jumper
3393815 Blue
3401703 Violet
3401704 White
3401705 Yellow/Black
8 8271363 Cap, End (R.H.)
9 8271318 Bracket, Control
10 3390646 Screw, 8−18 x 5/16
11 8317342 Cover,
Terminal Block
12 388326 Screw, Console
13 8522378 Mini Buzzer
(Non−Adjustable)
14 3391018 Tie, Cable
16 3397269 Connector, Timer
19 8283163 Harness, Wiring
20 8312687 Timer Knob
Assembly
21 8271339 Knob,
Push−To−Start
22 8318255 Strap, Console
23 357213 Nut, Push−In (2)
24 8271399 Top
26 8271369 Cap, End (L.H.)
27 3936144 Connector
31 8318387 Panel, Control
33 3398893 Wire, Ground
35 3390647 Screw, 8−18 x 1/2
36 98139 Screw, 8−32 x 5/16
37 357572 Clip, Grounding
40 3401144 Connector,
(PTS Relay)
41 3394427 Clip, Harness
44 94614 Terminal

CABINET PARTS
3
For Model: 3RLEC8646KQ0
(Designer White)
4320281

CABINET PARTS
4
OPTIONAL PARTS (NOT INCLUDED)
For Model: 3RLEC8646KQ0
(Designer White)
4320281
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
2 98139 Screw, 8−32 x 5/16
3 694091 Screw, 8−18 x 3/8
4 3394331 Plate, Cover
5 8318457 Switch, Broken
Belt
7 8310656 Cabinet
8 3392100 Foot, Dryer
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
9 660658 Clamp, Motor (2)
10 3387374 Spring, Idler
11 3389420 Retainer, Idler
12 697750 Plug, Multivent
13 3388672 Pulley Assembly
14 3393008 Screw, 10−16 x 1/2
15 3400934 Screw,
6−20 x 1 1/16
16 340025 Wire, Ground
17 3395532 Exhaust Pipe
& Bracket
18 233520 Washer, Thrust
19 697776 Screw, 10−32 x 5/8
20 690997 Tri Ring
21 3387560 Hinge, Door (R.H.)
3387559 Hinge, Door (L.H.)
22 3387565 Spring, Door (2)
23 3391408 Lever, Snap
Switch
24 3394081 Wire, Belt Switch
25 49026 4" − 90 Elbow
26 3393657 Restrainer, Belt
27 3404470 Motor, Assembly
50 HZ.
28 3395534 Exhaust Pipe
(Short)
29 3402548 Pulley 50 HZ.
30 3387610 Belt, Drive
32 3387118 Bracket, Motor
33 3395535 Exhaust Pipe
(Long)
34 3388600 Clip, Lint Duct
35 697773 Screw, 6−20 x 7/8
36 693995 Screw, 8−18 x 3/8
37 8318396 Seal, Foam
39 3388674 Idler Bracket
40 297092 Clip (2)
41 3406109 Door Switch
Assembly
42 3397659 Block, Terminal
43 279318 Terminal, Brass
& Tinned (3)
Includes Illus. 45
44 3387242 Seal, Front Panel
45 279393 Terminal Block
Screw Kit ( For
Terminal Block)
46 3388229 Retainer
47 8066045 Door, Rear
48 3406911 Dry Rack
Assembly
49 697221 Door, Front
50 3406910 Rack, Top Dry
51 697227 Upper Front Panel
52 696144 Strike, Door
53 3387230 Screw, 10−16 x 1
54 3357011 Screw, 10−16 x 1/2
55 3406908 Rack, Dry
(Bottom)
56 8316644 Clip, Strain
Relief
57 3390736 Seal, Door
58 690081 Catch, Door
Assembly
60 690270 Handle, Door
61 697215 Toe, Panel
Optional Parts Not Included
Dryer Exhaust Kit
(For Side & Bottom Venting)
62 279818 White
Illus. Part
No. No. DESCRIPTION
ACCESSORY PARTS
4392067 Kit,
Dryer Repair
8522199 Kit, Dryer
Vent Testing
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)

BULKHEAD PARTS
5
For Model: 3RLEC8646KQ0
(Designer White)
4320281

BULKHEAD PARTS
6
For Model: 3RLEC8646KQ0
(Designer White)
4320281
Illus. Part
No. No. DESCRIPTION
1 3399508 Shaft, R.H. Thread
2 3390647 Screw, 8−18 x 1/2
3 90767 Screw, 8−18 x 3/8
4 3394986 Spring, Lint
Screen Door
5 697354 Air Duct Assembly
6 697813 Seal, Outlet
Housing
7 697814 Seal, Drum Front
8 3359452 Nut,3/8 x 16(R.H.)
9 8066086 Drum Hole
Plug
10 3390646 Screw, 8−18 x 5/16
11 8318409 Exhaust Duct
(Corrugated)
12 696302 Shield, Exhaust
13 3387230 Screw, 10−16 x 3/4
14 3394984 Door, Lint
Screen
15 8318486 Exhaust Pipe
16 3387709 Nut, 3/8−16 (L.H.)
17 3387809 Bulkhead, Rear
18 3387459 Washer, Support
19 3399509 Shaft, L.H. Thread
20 690997 Ring, Tri
21 8536973 Roller, Support
22 3387749 Heater Element
23 3394985 Outlet Housing
Assembly
24 697699 Shield, Heat
25 8528998 Complete Drum
Assembly
26 97787 Screw, 11−16 x 3/4
27 697694 Seal, Drum
28 697700 Bracket, Heater
29 3390291 Thermostat
250 F (121C)
30 3388229 Clip, Exhaust
31 3977394 Thermal Cut−Off
(Includes
Illus. 29)
32 487909 Screw, 8−15 x 1/2
33 8066099 Bracket, Heater
37 697772 Wheel, Blower
42 3387137 Thermostat
Internal Bias
44 8530038 Housing, Blower
45 8530036 Lint Duct Assembly
46 3392537 Heater Box
51 3357011 Screw, 10−16 x 1/2
52 697771 Cover, Blower
(IncludesIllus. 62)
53 8528122 Baffle, Drum
54 697557 Bulkhead, Front
58 8299979 Grill, Outlet
59 3390719 Thermal Fuse
60 697770 Seal, Cover Plate
62 697769 Seal, Lint Duct
64 3390721 Lint, Screen
