Whirlpool LGR4624BW0 User manual

TOP AND CONSOLE PARTS
For Models: LGR4624BW0, LGR4624BN0
(White) (Almond)
GAS DRYER
1
3−94 Litho in U.S.A. (tpm) Part No. 4377133

TOP AND CONSOLE PARTS
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
LITERATURE AND OPTIONAL PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
For Models: LGR4624BW0, LGR4624BN0
(White) (Almond)
24377133
1 3397545 Panel, Rear
Console
2 693994 Screw, Hex
Washer Head
3 693995 Screw, Hex Head
4 Cap, End (L.H.)
3358531 White
3358532 Almond
5 689180 Clip, Retainer
6 688805 Clip
7 Cap, End (R.H.)
3358516 White
3358517 Almond
8 357213 Nut, Push−In (2)
9 3397269 Connector, Timer
10 339392 Screen, Lint
11 Cover, Lint Screen
688150 White
689310 Almond
12 339229 Hinge, R.H.
339230 Hinge, L.H.
13 688983 Screw, 8−18 x 5/8
14 3353145 Screw, Console
16 Top
3396022 White
3396023 Almond
18 94614 Terminal
21 3392250 Timer Assembly,
60 Hz.
23 3396647 Harness, Wiring
29 3390646 Screw, 8−18 x 5/16
39 660936 Switch,
Push−To−Start
692021 (Alt.)
48 3396145 Timer Knob
& Dial
53 3396293 Bracket, Control
54 Panel, Control
3397192 White
3397193 Almond
72 690853 Wire, Ground
75 691707 Receptacle,
Latching (3−Way)
(Uses Terminal
94614)
81 3396160 Knob,
Push−To−Start
LITERATURE PARTS
LIT3396303 Guide, Use & Care
LIT3395332 Instructions,
Installation
LIT3399125 Label, Wiring
Diagram
OPTIONAL PARTS NOT INCLUDED
PAINT, TOUCH−UP (1/2oz.)
72017 White
72107 Almond
PAINT, PRESSURIZED SPRAY
(13 oz.)
350930 White
350956 Almond
350938 Primer, Gray
350941 Leveler (Thinner)
PAINT, BULK (1 qt.)
799344 White (Uncut)
978883 Almond (Uncut)
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
LIT677818 Dryer

CABINET PARTS
For Models: LGR4624BW0, LGR4624BN0
(White) (Almond)
3
4377133

CABINET PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
For Models: LGR4624BW0, LGR4624BN0
(White) (Almond)
44377133
1 697776 Screw, 10−16 x 1/2
2 343641 Screw, 10−16 x 1/2
3 693995 Screw, Hex Head
4 3393657 Restrainer, Belt
5 690893 Cover, Block
6 Plug, Front Panel
3394975 White
3394976 Almond
7 347736 Panel, Rear
8 688160 Screw, 8−15 x 1/2
9 691581 Clip, Door Switch
10 347207 Switch, Door
11 98129 Screw,
6−20 x 7/8 (2)
12 337182 Guide, Cable(L.H.)
337183 Guide, Cable(R.H.)
13 339493 Screw
14 230131 Cable, Door (2)
15 3394083 Clip, Front Panel
16 3392100 Foot, Dryer (4)
17 337186 Spring, Door
18 Cabinet
3394109 White
3394110 Almond
19 98234 Clip, Ground (2)
20 690363 Lock, Front Top (2)
21 Front Panel
Assembly
3394890 White
3394891 Almond
23 685203 Clip, Felt Pad
24 690081 Catch, Door
25 693994 Screw, Hex Head
28 238456 Hinge, Door(R.H.)
238460 Hinge, Door(L.H.)
29 660975 Plug
31 98997 Clip, Harness
32 694091 Screw
33 696144 Strike, Door
35 695953 Door, Rear
36 Door, Front
348737 White
689485 Almond
37 Handle, Door
690270 White
690271 Almond
38 349462 Seal & Bearing
Assembly
42 3390734 Seal, Door
45 344020 Cord, Power
51 238088 Hinge, Top (2)
53 691366 Idler & Pulley
Assembly
56 660996 Belt, Drive
57 348780 Base, Motor
58 172455 Bolt,
5/16−18 x 3/4
59 3389627 Pulley, 60 Hz.
61 3388235 Switch, Motor
62 3391886 Motor, 60 Hz.
(Pulley Not
Included With
Motor)
63 660658 Clamp, Motor (2)
343481 (Alt.)
685441 (Alt.)
64 690236 Wire, Ground
(Motor)
67 694670 Burner Assembly,
60 Hz.
(Refer To Pages
5 & 6 For Further
Breakdown)
68 341029 Clamp, Pipe
69 694572 Kit, Conversion
(Type 1, 2 & 3
To Type 4)
85 694054 Valve, Gas
60 Hz.
(Complete)
86 686590 Ignitor
87 3393909 Screw & Washer
88 694539 Coil, 60 Hz.
(Split)
(3 Terminal)
(Pilot Position)
89 694540 Coil, 60 Hz.
(2 Terminal)
(Main)
90 694421 Screw, Bracket
Mounting
(8−32 x 1/2)
91 694538 Bracket, Coil
92 694426 Harness, Wiring
93 694424 Leak Limiter
94 694423 Screw, Regulator
Adjustment
95 694422 Spring, Regulator
96 694510 Clip, Harness
97 239822 Plug, Pipe

BA−110−D
694670 BURNER ASSEMBLY
USE WITH TYPE 1 − NATURAL, TYPE 2 − MIXED, TYPE 3 − MANUFACTURED
AND TYPE 4 − LIQUEFIED PROPANE AND BUTANE GASES
For Models: LGR4624BW0, LGR4624BN0
(White) (Almond)
5
4377133

Illus. Part
No. No. DESCRIPTION
694670 BURNER ASSEMBLY
1 694670 Burner Assembly
60 Hz.
(Type 1, 2 & 3)
(White Rodgers)
2 688617 Tube, Burner
3 694298 Bracket, Ignitor
4 660991 Ignitor
686590 (Alt.)
5 686953 Screw & Washer
(8−32 x 5/8)
6 343641 Screw, 10−16 x 1/2
7 693986 Base, Burner
8 339527 Screw,
8−32 x 3/8 (2)
9 Orifice, Burner
3394361 Type 1
15775 Type 2
15419 Type 3
229742 Type 4 (Butane)
234868 Type 4 (Propane)
10 694054 Valve, 60 Hz.
11 694421 Screw,
8−32 x 1/2 (2)
12 694538 Bracket, Coil
13 694540 Coil, 60 Hz.
(2 Terminal)
(Main)
14 694539 Coil, 60 Hz.
(Split)
(3 Terminal)
(Pilot Position)
15 694424 Leak Limiter
16 694423 Screw, Regulator
Adjustment
17 694422 Spring, Regulator
18 694426 Harness, Wiring
(Complete)
19 694510 Clip, Harness
20 239822 Plug, Pipe
21 233273 Pipe, Gas Supply
22 345062 Valve & Union,
Shut−Off
23 3393767 Pipe, Tail
24 233076 Nut, Compression
25 341029 Clamp, Pipe
694572 Conversion Kit
(Type 1, 2 & 3)
to Type (4) L.P.G.
Following Parts Not Illustrated
BA−110−D
USE WITH TYPE 1 − NATURAL, TYPE 2 − MIXED, TYPE 3 − MANUFACTURED
AND TYPE 4 − LIQUEFIED PROPANE AND BUTANE GASES
For Models: LGR4624BW0, LGR4624BN0
(White) (Almond)
64377133

BULKHEAD PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
For Models: LGR4624BW0, LGR4624BN0
(White) (Almond)
7
4377133
1 694283 Lint Chute
Assembly
2 343641 Screw, 10−16 x 1/2
3 98460 Nut, Push−In
4 3388703 Washer, Support
5 90767 Screw, 8A x 3/8
6 3392519 Fuse, Thermal
7 347139 Seal, Lint
Chute
8 660039 Thermostat,
150 F / 66C
9 339554 Screw
10 694089 Wheel, Blower
11 695081 Housing, Blower
12 337272 Clip
13 687128 Screw, 10−16 x 1/2
14 685458 Box, Heater
15 3388697 Thermostat,
205 F (96C)
16 337445 Support, Heater
Box (2)
17 337450 Collar, Funnel
18 347389 Funnel, Burner
23 695239 Screw, 8−18 x 3/8
24 696302 Shield, Exhaust
25 686889 Pad, Cabinet
26 3392247 Pad, Blower
Housing
27 3392123 Seal, Blower
Shaft
41 690997 Ring, Tri
42 347364 Shaft, L.H.
43 339489 Shaft, R.H.
44 3397588 Roller, Support
46 348197 Washer, Support
47 3359452 Nut, 3/8−16
48 685775 Bulkhead
49 338906 Sensor, Radiant
62 3394508 Ring, Bearing
63 97787 Screw, 11−16 x 7/8
66 337449 Seal, Rear Drum
67 3396775 Drum Assembly
68 342847 Baffle, Drum
69 348945 Bracket, Support
70 90296 Clip
73 339956 Seal
