USER MANUAL
90cm, 5 burners Gas hob
AKC 950C/IX

For your safety
These instructions have been drawn up for your safety and that of others. You are
therefore requested to read them carefully before installing and using the appliance.
Keep this instruction manual for future reference as necessary. If the appliance is
sold or moved, make sure that the manual is handed over to the new user.
Installation
·Installation of the appliance and its connection to the electrical mains must only be
carried out by QUALIFIED PERSONEL. Before doing any servicing, it is
important to check that the appliance is DISCONNECTED from the electrical
mails.
·It is risky to modify or attempt to modify the characteristics of this product.
·After removing the appliance from the packaging, make sure that it is not damaged
and that the electrical lead is in perfect condition. Otherwise, contact your dealer
before putting the appliance into operation.
·The Manufacturer declines all responsibility in case of failure to comply with the
accident prevention regulations.
·Make sure that air circulates freely around the appliance. Poor ventilation creates a
shortage of oxygen
·Use of a gas cooking appliance produces heat and moisture in the room
in which it is installed. Ensure that the room is well ventilated by keeping the air
intakes open and in good working order or by installing an extractor hood with
discharge pipe.
·If the appliance is used intensively for a long time the effectiveness of the
ventilation will have to be increased, for example by opening a window or
increasing the power of any electric extractor fan.
During use
·This product is designed to cook food inside ordinary homes and for
non-professional purposes. It should not be used for any other purpose.
·After using the appliance, make sure that all controls are in “CLOSED”or “OFF”
position.
·If you use an electrical socket close to this appliance, take care that the cables of the
appliances you are using are far away from the hot parts of this appliance.
·Never leave plastic, oil or any other flammable material around the hob when
cooking.
·If the Hob fails to light at the first time, then you should wait for I minute before you
try again.

Children’s safety
·This appliance must only be used by adults. Make sure that children do not touch
the controls or play with the appliance.
·The exposed parts of this appliance heat up during cooking and remain hot for some
time even after it is switched off. Keep children well away until the appliance has
cooled down.
Environmental protection advice
·All the materials used are environmentally compatible and recyclable. Please make
your contribution to conserving the environment by using the separate waste
collection channels available.
Decommissioned appliances
·Appliances which are no longer used or usable are not worthless waste. Through
environment-friendly disposal, a number of materials used in the production of
your appliance can be recovered.
·Find out about the current disposal options from your specialist dealer, or your
local authority.
·Before scrapping the appliances, cut the power supply lead and make it unusable.

Contents
For your safety ..........................................................................................2
Installation.................................................................................................................................2
During use.................................................................................................................................2
Children’s safety .......................................................................................................................3
Environmental protection advice ..............................................................................................3
Decommissioned appliances.....................................................................................................3
Technical Data...........................................................................................5
Instructions for the installation technician ............................................6
Installation premises .................................................................................................................6
Discharge of flue gases .............................................................................................................6
Connection to the gas supply ....................................................................................................7
Connection................................................................................................................................7
Electrical connection ................................................................................7
Replacing the power supply lead ..............................................................................................8
Building into fitted kitchen units.............................................................8
Insertion and fixing...................................................................................................................9
On base cabinet with door.........................................................................................................9
On base cabinet with oven........................................................................................................9
Instructions for use.................................................................................10
The hob control knobs.............................................................................................................10
Dual triple flame version.........................................................................................................11
Lighting the burners................................................................................................................11
For correct use of the hob ......................................................................11
Cleaning and maintenance.....................................................................12
General cleaning .....................................................................................................................12
Hob..........................................................................................................................................12
Ignition plug............................................................................................................................12
Routine maintenance...............................................................................................................13
Warranty conditions................................................................................................................13

Guide to reading the instructions
The following symbols will help you
When reading the instructions:
Safety information
“Step by step”instructions
Suggestions and Advice
Information concerning environmental protection
This appliance complies with the following EEC Directives:
-73/23 and 90/683 (relating to Low Voltage);
-89/336 (relating to Electromagnetic Compatibility);
-90/396 (relating to Gas Appliances);
-93/68 (relating to the General Standards )
Technical Data
BURNER TYPE
MAX
OUTPUT
MIN
OUTPUT
G20
20mbar
G30
28-30mbar
KW
KW
Nozzle
（mm）
Cons
M3/h
Nozzle
（mm）
Cons
g/h
Small
Auxiliary
burner
1.00
0.35
0.72
0.095
0.50
73
Medium
Semi-rapid
Burner
1.75
0.65
0.97
0.167
0.65
127
Large rapid burner
3.0
1.0
1.15
0.286
0.85
218
Triple flame burner
3.80
1.9
1.35
0.362
0.98
277
Gas intake connection G1/2″
Electricity supply 220-240v~50/60Hz

Instructions for the installation technician
CAUTION: This appliance must only be installed and used in rooms with
permanent ventilation to local standards.
Installation of the appliance and its connection to the electrical mains must
only be carried out by QUALIFIED PERSONEL.
Before doing any servicing, it is important to check that the
appliance is DISCONNECTED from the electrical mains.
The Manufacturer declines all responsibility for any damage
arising from installation in breach of the regulations in force
or from failure to comply with the accident prevention
regulations.
Installation premises
For proper operation of a gas appliance, the air necessary for the
combustion of the gas must be able to flow into the room naturally.
The air must flow into the room directly through openings in the
outside walls. These openings must have an unobstructed cross-section
not less than 2m3/hfor each kw of power (see total power in kw on the
appliance nameplate).
This opening must be constructed so that it will not be obstructed from
inside or outside, or constructed close to the floor. The opening is
recommended to be on the side opposite to that on which the flue
gases are discharged. If it is not feasible to provide these openings in
the room where the appliance is installed, the necessary air may be
taken from an adjacent room, provided that:
·this room is not a bedroom or a hazardous environment;
·this room has ventilation;
·the ventilation between the room where the appliance is installed and the adjacent
room has openings.
Discharge of flue gases
Gas cooking appliances must discharge their flue gases through hoods connected
directly to flues or the outdoors. If it is not possible to install the hood (fig. B) an
electric fan must be installed on the outside wall or the window of the room, provided
it is possible for the ventilation opening
to be increased in proportion to the delivery rate of the fan (fig. C). For a kitchen, the
delivery rate of this electric fan must guarantee an hourly air exchange of 3-5 times its
volume. In both instances, the use of flues already used by other appliances to
discharge the flue gases is forbidden.

Connection to the gas supply
The gas Connection must be made in accordance with the
local standards. When installing, fit a safety tap at the end
of the pipeline. The appliance leaves the factory tested and
set for the type of gas indicated on the plate inside the
bottom guard, close to the gas connection pipe. Make sure
that the type of gas to be supplied to the appliance is the
same as that shown on the plate. Otherwise, follow the
instructions provided in the “Adapting to different types of
gas”section.
For maximum efficiency and minimum consumption, make
sure that the gas supply pressure complies with the values
shown in the gas used is different from that specified (or
variable).a suitable pressure regulator must be installed on
the supply pipeline.
The union must be fitted on the end of the gas train. Complete with GJ1/2” other
places refer to G1/2” threaded nut, fitting the gasket between the components as
shown in the illustration. The gaskets must comply with the local standards. Screw the
parts together without forcing, fit the union so that it points in the direction required
then tighten all parts.
Connection
Make the connection to the gas system using a rigid metal pipe and regulation unions,
or with a stainless steel hose complying with the local standard. If metal hoses are
used, take care that they do not come into contact with mobile parts and are not
crushed. This must also be checked if the hob is to be combined with an oven.
The gas intake connection of the appliance has a “male thread.”
When making the connection, take care not to apply stresses of any kind to the
appliance.
When the installation is complete, always check that all the unions are
absolutely tight using a soapy solution.
Never use a flame to make this
check.
Electrical connection
The appliance is profited to operate with a power
supply voltage of 230Vsingle-phase. The connection
must be made in accordance with the regulations and

laws in force.
Before making the connection, make sure that:
1) the safety circuit-breaker and the electrical system are able to withstand the load
of the appliance(see nameplate).
2) The power supply system has an earth connection in good working order in
accordance with the regulations in force;
3) The socket or omni polar switch used is easily accessible with the appliance
installed.
Fit a plug suitable for the load on the power lead and connect it to a suitable safety
socket.
If you wish to make a direct connection to the mains, an omni polar switch with a gap
between the contacts of at least 3 mm, of suitable rating for the load and complying
with the regulations in force, must be installed between the appliance and the mains.
The switch must not break a contact in the yellow/green earth wire.
The brown live wire (connected to the “L”terminal of the terminal board) must
always be connected to the live wire of the power supply mains.
In all cases, the power supply lead must be positioned so that it does not reach a
temperature 50oC above the room temperature at any point.
One example of an ideal route is shown in the illustration. The cable is guided by
means of band clamps fixed to the side of the cabinet, in order to avoid any contact
with the appliance underneath the hob.
Replacing the power supply lead
If the lead has to be replaced, only HO5RR-F or
HO5RN-F type cables suitable for the load and the
operating temperature must be used. In addition, the
yellow/green earth wire must be about 2 cm longer than
the live and neutral wires.
Building into fitted kitchen units
These hobs are designed for installation in fitted kitchen units up to 600mm deep with

suitable characteristics.
Any cabinet side panels taller than the height of the hob itself must be at least 150mm
away from the opening into which the hob is inserted.
The dimensions of the hob and the installation opening are shown in the illustration.
Insertion and fixing
Before inserting the hob in the installation
opening, place the special gasket around the
bottom edge of the hob.
It is important to fix this gasket evenly,
without gaps or overlapping, to prevent liquid
from seeping underneath the hob.
1) Remove the pan stands and the burner
caps and turn the hob upside down, taking
care not to damage the ignition plugs and
the thermocouples.
2) Place the gasket around the bottom edge
of the hob as shown in the illustration on
the right.
3) Place the hob in the installation opening
and push it down so that the hob is resting
firmly on the cabinet, as show in the
illustration. The side springs will hold it in
place.
Installation options
On base cabinet with door
When constructing the cabinet, suitable precautions must be taken to prevent contact
with the casing of the hob, which becomes very hot during operation. The
recommended method for overcoming this problem is illustrated in Fig.1
The panel underneath the hob must be easily removable to allow the hob to be locked
in position and released in case of servicing work
On base cabinet with oven
The installation compartment must have the dimensions shown in Fig.2 and Fig.3 and
must have supports to allow satisfactory ventilation.
Two possible methods for avoiding overheating are illustrated in Fig.4 and Fig.5. The

electrical connections of the hob and oven must be made separately both for electrical
reasons and to simplify removal of the oven through the front of the cabinet.
Wall cabinets or extractor hoods must be at least 650 mm above the hob.
Fig.1 Fig.2 Fig.3
Fig.4 Fig.5
Instructions for use
The hob control knobs
The symbols on the control knobs mean the following:
●no gas flow
maximum gas flow
Minimum gas flow
All operating positions must be set between the
maximum and minimum flow settings, and never
between the maximum setting and the closed
position.

(Symbol present on version with lighting
integrated in the Control knob)
Dual triple flame version
●no gas flow
maximum gas flow from central burner
minimum gas flow from central burner
maximum gas flow from outer and central burners simultaneously
minimum gas flow from outer and central burners simultaneously
Lighting the burners
To obtain a flame more easily, light the burner before placing a cooking
utensil on the pan stand
To light a burner, proceed as follow: for Version with lighting integrated in
the control knob push the knob of the burner fully down and turn it
anticlockwise to the “maximum flow”setting symbol, or press the button
if the appliance has individual lighting.
●After lighting the flame, keep the knob pressed for about 10 seconds: this
time is necessary to heat up the “thermocouple” (Fig.1-C) and activate the safety
valve, which would otherwise cut off the gas flow.
Then check that the flame is even and turn the control knob to adjust the
flame as required
In the instance of a power cut, place a flame near the burner and proceed as
already described.
If the flame does not light after a few attempts, check that the “burner cap”and
“flame cap”are correctly positioned.
To turn off the flame, turn the control knob clockwise to the ●symbol.
Before removing pans from the burners, always lower or turn off the flame.
For correct use of the hob
For lower gas consumption and better efficiency: Use only flat-bottomed pans of
dimensions suitable for the burners, as shown in the table on the right. Also, as soon
as a liquid comes to the boil take care to turn the flame down to a level that will just
keep it boiling.
Burner minimum diameter maximum diameter
Large (rapid) 180mm 220mm

Medium (semi-rapid) 120mm 200mm
Small (Auxiliary) 100mm 160mm
Triple Flame 220mm 260mm
During cooking processes involving fats or oils, watch your foods
carefully because these substances may catch fire if brought to high
temperatures.
Cleaning and maintenance
Before each operation, disconnect the appliance from the electrical mains and allow it
to cool down.
General cleaning
Wash enameled parts with lukewarm water and detergent: do not use abrasive
products which might damage them.
Wash the flame caps and burner caps often with boiling water and detergent, taking
care to remove all deposits
The hob pan stands can also be washed in a dishwasher
For stubborn dirt, use ordinary non-abrasive detergents or specific commercial
products. We strongly advise you not to use scouring pads——steel wool or acids.
Hob
Clean the hob regularly with a soft cloth wet with lukewarm water and a little liquid
detergent. Do not use the following products:
- household detergents or bleaches;
-alcohol or other flammable liquid;
- soaped scouring pads not suitable for non-stick utensils;
- steel wool scouring pads;
- stain removers for baths or sinks.
If the hob gets very dirty, use specific commercial products.
Ignition plug

Automatic burner ignition is provided (when installed) by a ceramic “plug”and a
metal electrode. Periodically clean these parts of the hob thoroughly. In addition, to
avoid ignition difficulties, check that the cavities in the burner are not obstructed.
To remove deposits from the burner cavities, remove the cap and separate the two
parts. After cleaning, put the two parts back together and return them correctly to their
position. After washing, replace the hob pan stands, checking that they are correctly
positioned.
Routine maintenance
Have the condition and efficiency of the gas pipe and the pressure regulator (if
installed) checked periodically. If anomalies are found, do not repairs but have the
faulty part replaced.
To ensure good performance and safety, the gas regulator taps must be greased
periodically.
Periodic lubrication of the taps must only be carried out by qualified personel,
who must also be contacted if the appliance malfunctions.
Keep plastic, oil or any other flammable material away from the hob.
Warranty conditions
Your new appliance is covered by a warranty. The warranty conditions are provided
in full in the “Warranty conditions-Service centers”leaflet which you will find inside
the appliance.
Keep the fiscal receipt or delivery note, either of which documents your purchase of
the appliance and provides proof of date of purchase, in a safe place together with the
leaflet.
If the After-Sales Service is call in, show these documents to the staff. If this
procedure is not followed, the Service-Centre will have no option but to charge for
any repairs.
If necessary, you may find your nearest Centre by consulting the”Warranty conditions
–Service centers”.

FAQs and Troubleshooting
FAQs
Possible Reasons
Solutions
Spark pin can’t
make fire.
Electrical
supply
The electrical wires
or the plug are not
connected well.
Connect with electrical
power again.
burner
The burner is not
installed correctly.
Install the burner again.
Spark pin
Ignition electrode
and the hole are
not placed well.
Adjust the distance for
3- 4m m
The spark pin is
broken.
Replace the broken
spark pin.
The fire goes out
once release the
knob.
Safety valve
The time of press is
not long enough.
Press and turn the knob
again and keep 3 to 5
seconds after the burner
has fire.
The ignition
can’t make fire
or it is hard to
make fire.
Gas valve
The valve is not
open or totally open.
Make sure the valve is
totally open.
Gas pipe
There may be air in
the gas pipe.
Make ignition repeatedly
until it catches fire.
Burner cap.
The burner cap is not
placed correctly.
Replace the burner cap.
Some holes in the lid
are stocked.
Clean the holes of the
lid.
Spark pin
The spark pin is wet
or contaminated by
the food.
Dry the spark pin and
clear away the food.
Gas connecting
pipes.
The gas connecting
pipes are stocked or
squashed.
Adjust or change the
connecting pipes.
The fire go out
during operation.
Thermocouple
The safety device is
contaminated.
Clean the thermocouple.
The fire is so little
that it can’t touch the
thermocouple.
Adjust the flame a little
bigger.
Strange smell.
Gas leaking.
The gas supply pipe
is old and broken.
Change the gas supply
pipe.
The main burner is
not on fire.
Make ignition again
after there is no strange
smell.
