Installation
Dimensions 65 cm
Dimensions 77 cm
Standard Installation
Full integrated installation
Electrical connection
Induction I 200

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
Installation
Dimensions 65 cm version
Induction I 200
Worktop thickness min. 30mm
Idem for 650 mm
0
560+ 2 mm
R= Min. 6.5 mm
Max. 8 mm
Min. 480mm
Max. 492mm
0
560+ 2 mm
R= Min. 11.5 mm
Min. 50mm
Min. 480mm
Max. 492mm
6mm
593+
0mm
2
0
513+ 2 mm
R= Min. 6.5mm
Max. 8 mm
R= 11.5mm
4mm
553mm
510mm
476mm
590mm
53mm

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
Installation
Dimensions 65 cm version
Induction I 200
Worktop thickness min. 30mm
Idem for 650 mm
0
560+ 2 mm
Min. 50mm
Min. 480mm
Max. 492mm
560+0mm
2
6mm
0
653+ 2 mm
0
513+ 2 mm
R= Min. 6.5 mm
Max. 8 mm
R= Min. 11.5 mm
R= Min. 6.5mm
Max. 8mm
R= 11.5mm Min. 480mm
Max. 492mm
4mm
553mm
510mm
476mm
650mm
53mm

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
Installation
Dimensions 77 cm version
Induction I 200
Worktop thickness min. 30mm
0
750+ 2 mm
Min. 50mm
Min. 480mm
Max. 492mm
750+0mm
2
6mm
0
773+ 2 mm
0
513+ 2 mm
R= Min. 6.5 mm
Max. 8 mm
R= Min. 11.5 mm
R= Min. 6.5mm
Max. 8mm
R= 11.5mm Min. 480mm
Max. 492mm
4mm
743mm
510mm
476mm
770mm
53mm

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
Installation
Standard Installation
Induction I 200
Distance “X” is specified in the hood’s documentation

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
Induction I 200
15mm
100mm
65mm
min. 45mm
min. 550mm
min.5mm
min.5mm
min. 20mm
60mm
min. 20mm
60mm
min. 20mm
min. 45mm
min. 550mm
min. 20mm
Installation
Standard Installation

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
Induction I 200
Installation
Standard Installation
21
2mm
x4
x4
3
90°C

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
Induction I 200
Installation
Standard Installation
2
1
x4

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
11.5
6 +/- 0.5
Perimetral Gasket
Silicon
COOKTOP CUT OUT
DIM.
mm
Depth Length Width Length Width
590 Vetroceramic Cooktops Flush Installation 53 590 510 593/560 513/(480
-492) -0/+2
770 Vetroceramic Cooktops Flush Installation 53 770 510 773/750 513/(480
-492) -0/+2
Induction I 200
Installation
Standard Installation

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
●Make the cut-out as described and try the fit-in of
the hob
●Before gluing the hob to the worktop remove the
6 screws, which have the screw head on the
outside.
This is important, they are not reachable after
installation!
●Put in 6 screws with the bigger head from
inside of the frame.
These ones can be loosen easier, when the hob is
installed.
The glass frame will stay in the worktop but the
metal support with the electronic can be removed
by loosing these screws
On the back side there are 2 hooks, no screws
Induction I 200
Installation
Full integrated Installation

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
A mains cable is delivered with the
cooktop.
On house side:
L1 and L2 are clamped together in one
cable end.
N1 and N2 are clamped together in one
cable end.
In order to allow using the cooktop with
1 phase 230V.
If the cooktop will be connected with 2
phase, the life connection (L1, L2) have
to be cutted and connected one by one.
Induction I 200
Installation
Electrical connection (hob)

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
Induction I 200
R=black, S=brown, T=blue (gray), =E=yellow, N=blue
220-240V
220-240V
AU-UK-IRL 220-240V3 BE 230V 2 Phase 2N
NL
380-415V3 N ~
380-415V2 N ~
Installation
Electrical connection (hob)

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
Display Description
Switch ON/OFF
Stand By Mode
Minute Minder
Residual Heat
Power On a zone
Depowering
Select and Deselect Zones
Set power level & start the cycle
The Hob is in Run
Operation
Split a Flexi Zone
Set a Timer
Set Key Lock
Set Assisted Cooking Function
Set Cooking Anywhere Function
French Plaque Setting
Pan Detection
Customize the Hob Setting
Induction I 200

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
U Button
Touch button
toggle
ON/OFF
Touch
button
Key lock
Touch
button
Dot matrix LCD (8
zones)
Touch screen
Dot matrix LCD
Touch screen
Slider for power
selection
Up to 18 levels
This UI is based on the use of two LCD touchscreens.
The user can switch on the UI, select the power level by touching directly the related position and slide the
finger on the dedicated area. He can directly go to the booster function thanks to the dedicated position on the
slider.
The start of the cooking can be done in the following way:
•manually done by touching the sensible zones on the left touchscreen
The special functions are organized by relevance in use: special functions are available and accessible by
pressing the U button shared in the middle of the interface.
When the user enters in the U button functions, he can scroll through all available functions using the right
LCD touchscreen.
Induction I 200
Operation
Display description

WHIRLPOOL CORPORATION ▪CONFIDENTIAL ▪EMEA CS&Quality Technical Training and Serviceability Team ▪By Nicola Padula and Nicola Bargagnati
SWITCH ON (by pressing On/OFF button):
The UI plays the special ON tone
The UI shows the led on the right of ON/OFF button
The UI shows the “HELLO!” welcome message on the right LCD TS for 3 seconds
After that the Hob is ready to work
SWITCH OFF (by pressing On/OFF button):
The UI plays the special OFF tone
After that the Hob goes in OFF
If any residual heat indication is recognized by the system
Induction I 200
Operation
Switch ON/OFF
