Whirlpool AKM274/IX User manual

AKM 274 PRODUCT DESCRIPTION SHEET
GB
5019 319 01424
Operation of burners with safety
device and electric ignition
To light one of the burners:
• Press the relative knob and turn it anti-
clockwise to the large flame and star
setting .
• At the same time, keep the knob pressed
against the control panel until the burners
ignites.
• After the burner has ignited, keep the knob
pressed for about 10 seconds.
• Release the knob.
If the burner does not ignite, repeat the operations
described above.
Note:
—Should particular local conditions of the
delivered gas make the ignition of the burner
difficult,itisadvisabletorepeattheoperation
with the knob turned to the small flame
setting .
—The safety device of the burner shuts off the
gas supply to the burner if its flame goes out
accidentally (because of a sudden gust of
wind, an interruption in the gas delivery, the
overflowing of liquids, etc.).
1. Removable panstand grids
2-3. Medium burners
4. Large burner
5. Small burner
6. Medium burner control knob
7. Medium burner control knob
8. Large burner control knob
9. Small burner control knob
10. Electric ignition button
Symbols
Shaded circle Tap closed
Large flame Maximum opening
delivery
Small flame Minimum opening or
reduced delivery
DIMENSIONS OF COOKING HOB AND WORKTOP (mm)
NOTE: In case of installation of a hood above the cooktop, please refer to the hood
instructions for the correct distance.
INJECTORS TABLE CATEGORY II2H3+
ELECTRIC SUPPLY: 230 V ~ 50 Hz
Type of gas used Type of
burner Injector
marking
Rated
heat
capacity
kW
Rated
consumption
Reduced
heat
capacity
kW
Gas pressure
mbar
min. rat. max.
NATURAL GAS
(Methane) G20
large
medium
small
Y 115
H2 98
X 72
3.00
1.65
1.00
286 l/h
157 l/h
95 l/h
0.60
0.35
0.30 17 20 25
LIQUID
PETROLEUM GAS
(Cylinder) G30
large
medium
small
87
65
50
3.00
1.65
1.00
218 l/h
120 l/h
73 l/h
0.60
0.35
0.30 20 28-30 35
LIQUID
PETROLEUM GAS
(Cylinder) G31
large
medium
small
87
65
50
3.00
1.65
1.00
214 l/h
118 l/h
71 l/h
0.60
0.35
0.30 25 37 45
Type of gas used Appliance
model
Total rated heat
capacity
kW
Total rated
consumption
Air necessary (m3) for
the combustion of 1
m3of gas
G20 20 mbar 4 gas 7.30 695 l/h 9.52
G25 28-30 mbar 4 gas 7.30 531 g/h 30.94
G31 37 mbar 4 gas 7.30 521 g/h 23.80

This manual suits for next models

1

Other Whirlpool Hob manuals

Whirlpool AKT 466/NB/01 User manual

Whirlpool

Whirlpool AKT 466/NB/01 User manual

Whirlpool PK 741 RQO GH/HA User manual

Whirlpool

Whirlpool PK 741 RQO GH/HA User manual

Whirlpool AKT 464 User manual

Whirlpool

Whirlpool AKT 464 User manual

Whirlpool AKT 300 User manual

Whirlpool

Whirlpool AKT 300 User manual

Whirlpool WHGOF7523SB User manual

Whirlpool

Whirlpool WHGOF7523SB User manual

Whirlpool AKA 6422/IX User manual

Whirlpool

Whirlpool AKA 6422/IX User manual

Whirlpool WVH92K W User manual

Whirlpool

Whirlpool WVH92K W User manual

Whirlpool AKT 466/WH User manual

Whirlpool

Whirlpool AKT 466/WH User manual

Whirlpool GMA 7522 User manual

Whirlpool

Whirlpool GMA 7522 User manual

Whirlpool GMWL 728/IXL User manual

Whirlpool

Whirlpool GMWL 728/IXL User manual

Whirlpool AKR 021 User manual

Whirlpool

Whirlpool AKR 021 User manual

Whirlpool WS Q4860 NE User manual

Whirlpool

Whirlpool WS Q4860 NE User manual

Whirlpool AKT 905/IX User manual

Whirlpool

Whirlpool AKT 905/IX User manual

Whirlpool GOFL 629/NB1 User manual

Whirlpool

Whirlpool GOFL 629/NB1 User manual

Whirlpool AKT 351 User manual

Whirlpool

Whirlpool AKT 351 User manual

Whirlpool PC 750 T X/HA User manual

Whirlpool

Whirlpool PC 750 T X/HA User manual

Whirlpool ACM 868/BA/IXL User manual

Whirlpool

Whirlpool ACM 868/BA/IXL User manual

Whirlpool AKR 311/IX User manual

Whirlpool

Whirlpool AKR 311/IX User manual

Whirlpool AKT 315 IX User manual

Whirlpool

Whirlpool AKT 315 IX User manual

Whirlpool AKT 476 User manual

Whirlpool

Whirlpool AKT 476 User manual

Whirlpool WL B6860 NE/S User manual

Whirlpool

Whirlpool WL B6860 NE/S User manual

Whirlpool AKC 830C/BLM User manual

Whirlpool

Whirlpool AKC 830C/BLM User manual

Whirlpool AKM 613 User manual

Whirlpool

Whirlpool AKM 613 User manual

Whirlpool GMA 6422/IX User manual

Whirlpool

Whirlpool GMA 6422/IX User manual

Popular Hob manuals by other brands

Siemens ET8 Series instruction manual

Siemens

Siemens ET8 Series instruction manual

Electrolux EIL83443BW user manual

Electrolux

Electrolux EIL83443BW user manual

Electrolux ETIH3022EMB instruction manual

Electrolux

Electrolux ETIH3022EMB instruction manual

DeDietrich DPI7572G user guide

DeDietrich

DeDietrich DPI7572G user guide

Baumatic BHI609 instruction manual

Baumatic

Baumatic BHI609 instruction manual

Zanussi ZGG96624 user manual

Zanussi

Zanussi ZGG96624 user manual

CDA HCG 730 Users operating instructions Operating & installation instructions

CDA

CDA HCG 730 Users operating instructions Operating & installation instructions

steel GP6I-4 Guide for installation and use

steel

steel GP6I-4 Guide for installation and use

Electrolux HOI623S user manual

Electrolux

Electrolux HOI623S user manual

elvita CIH4330S user manual

elvita

elvita CIH4330S user manual

MPM MPM-45-IM-07 manual

MPM

MPM MPM-45-IM-07 manual

AEG HGB64301UM user manual

AEG

AEG HGB64301UM user manual

Bosch PKD975N14Q instruction manual

Bosch

Bosch PKD975N14Q instruction manual

Russell Hobbs RH75GH602B instruction manual
