Whirlpool MWO 165/NB User manual

SERVICE Whirlpool Europe
Customer Services
Model MWO 165/NB
Version 8538 424 18492 Page
Introduction safety 2
Technical data 3
Spare part list 4
Exploded view 5
Wiring diagram 6 - 7
Program diagram 8 - 9
Service Manual
Microwave oven
MWO 165/NB
AVM 424
MWO 165/NB
This documentation is only intended for qualified technicians who are aware of the respec-
tive safety regulations.
Date: 26.03.1999 Subject to modification
Document-No.: 4812 714 12672

SERVICE
26.03.1999 / Page 2 MWO 165/NB Whirlpool Europe
Doc. No: 4812 714 12672 8538 424 18492 Customer Service
Introduction safety
INTRODUCTION
Before leaving the factory each oven is carefully checked.
It must, however, be installed and used correctly.
Despite all the steps taken to make the oven safe, the safety is dependent on the correct installation and the fact
the user understands how to use and maintain the oven.
The information in this section should be used as a reminder that the oven is safe and that anyone who uses it must
first read the instructions for use in order to be able to use the oven correctly and obtain best results.
SAFETY
To avoid injury to yourself and damage to the appliance always work to the following rules when servicing an oven.
Always disconnect the plug from the mains before starting work.
If there is no plug switch off the electric supply at the control box.
When you have finished servicing an oven before you reconnect it to the mains, make sure that:
- all the internal connections are correct
- the wires are insulated and not touching the door or the cabinet or anything sharp
- all the earth connections are electrically and mechanically sound
- do not modify or anyway interfere with the safety devices built-in to the oven
- make sure that each replacement part you use conforms to the manufacturer´s specifications
Do not start a repair if you have any doubt as to your ability to complete it.
CAUTION - MICROWAVE RADIATION
PERSONNEL SHOULD NOT BE EXPOSED TO THE MICROWAVE ENERGY WHICH MAY RADIATE FROM THE MAGNETRON,
WAVEGUIDE OR ANTENNA IF THEY ARE IMPROPERLY USED OR CONNECTED. ALL INPUT
AND OUTPUT MICROWAVE CONNECTIONS, WAVEGUIDES, FLANGES AND GASKETS MUST BE SECURE.
NEVER OPERATE THE DEVICE WITHOUT A MICROWAVE ENERGY ABSORBING LOAD ATTACHED.
NEVER LOOK INTO AN OPEN WAVEGUIDE OR ANTENNA WHILE THE DEVICE IS ENERGIZED.
NEVER OPERATE AN OVEN WITH CABINET OFF WITHOUT MEASURING THE MICROWAVE LEAKAGE
AROUND MAGNETRON AND VISIBLE MICROWAVE CONNECTIONS (WELDING JOINTS).
Do not operate the oven if the following conditions exist:
- the door does not close firmly against the door support because of the door being warped or the hinges damaged.
- The door trims or seals are damaged.
- If there is any visible damage to the oven.
- if the door does not close properly.
Avoid operating the oven if known components in the interlock system, oven door or microwave
generating assembly are known defective. They must be replaced.
WARNING - HIGH VOLTAGE
IT IS POSSIBLE TO COME IN CONTACT WITH LETHAL HIGH VOLTAGE WHEN WORKING WITH
HV TRANSFORMER, HV CAPACITOR AND MAGNETRON. THEREFORE NEVER TRY TO MEASURE
THE HIGH VOLTAGE. ALWAYS TAKE UTMOST CARE WHEN PERFORMING ELECTRIC
MEASUREMENTS INSIDE THE OVEN.

SERVICE Whirlpool Europe MWO 165/NB 26.03.1999 / Page 3
Customer Service 8538 424 18492 Doc. No: 4812 714 12672
Technical data
Dimensions of cabinet
Height 277 mm
Width 525 mm
Depth 338 mm
Dimensions of cavity
Height 185 mm
Width 335 mm
Depth 290 mm
Cavity volume 20 l
Turntable 280 mm
Weight
Gross 18 kg
Net 16.5 kg
Electrical
Voltage 230-240 V
Frequency 50 Hz
Total consumption 2300 W
Microwave 1500 W
Power
Output power Microwave 900 W
Output power Grill 1000 W
Microwave frequency 2450 MHz
Accessories
Built-in kit AKB 697 (optional)
Features
- Easytronic controls
- Quarz grill
- Combination Microwave + Grill
- Jet start
- Timed defrost
- Child lock
- 7 power levels
- 24 hour clock
- 90 minute timer

SERVICE
26.03.1999 / Page 4 MWO 165/NB Whirlpool Europe
Doc. No: 4812 714 12672 8538 424 18492 Customer Service
Spare part list
Model MWO 165/NB
Service No. 853842418492
Version 853842418492
Pos. No. 12NC Code Description
001 0 4819 440 59471 Cabinet
001 1 4819 466 98741 Spacebar WH
001 2 4819 442 39476 Panel, rear
001 5 4819 462 79937 Plate Bottom
011 0 4819 462 79423 Foot
011 1 4819 462 79938 Foot right back
040 0 4819 417 19514 Hinge,upper
040 1 4819 417 19248 Hinge,lower
100 0 4819 442 39499 Oven door
117 0 4819 498 78366 Handle for crisp plate
120 0 4819 459 48654 Door frame inner
130 0 4819 271 38148 Unit,pushbutton
130 1 4819 404 78492 Lever for microswitch
141 0 4819 450 58328 Oven glass outer
143 0 4819 459 48898 Cabinetsurround
244 0 4819 466 98731 Stand optional
245 0 4819 458 19898 Stand high
246 0 4819 418 79764 Crisp plate small
255 0 4819 466 78218 Turntable glass
264 0 4819 535 78156 Crosspiece
301 0 4819 404 79469 Holder
320 0 4819 453 59104 Control panel
331 0 4819 412 58621 Knob timer
331 1 4819 410 29098 Button clock-set
331 2 4819 412 58747 Button power
331 3 4819 410 29094 Button stop
331 4 4819 410 29106 Button grill-crisp
332 0 4819 492 68818 Spring
333 0 4819 410 29096 Button start
352 0 4819 130 38081 Display
355 0 4819 280 18034 Buzzer
404 0 4819 131 58019 Magnetron
406 0 4819 361 18292 Motor for rotary plate
411 0 4819 148 68085 Transformer
412 0 4819 145 78197 Transformer,HT
420 0 4819 121 48016 Capacitor HT
421 0 4819 121 18197 Filter mains
426 0 4819 218 38038 Diode HV
441 0 4819 361 18313 Motor fan
443 0 4819 310 39025 Fan wheel
452 0 4819 259 98445 Tube,heating quarz
452 1 4819 404 78511 Bracket right
485 0 4819 320 28037 Cable,HT
490 0 4819 321 18136 Cable,mains 2m
500 0 4819 214 78701 Control unit
505 0 4819 209 88069 Microprocessor
531 0 4819 101 48146 Potentiometer
531 1 4819 101 48142 Potentiometer
561 0 4819 282 28725 Cut out 165 ˚C
615 0 4819 280 68363 Relay
617 0 4819 280 68321 Relay
622 0 4819 276 18273 Switch VKS
633 0 4819 276 18336 Switch, door
651 0 4819 134 88199 Lamp oven
743 0 4819 462 38841 Air guide ventilation
Pos. No. 12NC Code Description
770 0 4819 462 38839 Air guide
774 0 4819 462 88163 Cover
774 1 4819 442 38357 Plate ,lower mica plate
794 0 4819 532 68686 Gasket ring for TT
794 1 4819 502 18372 Screw for TT-Motor
900 0 4819 404 79272 Holder for capacitor
902 0 4819 404 78493 Unit,pushbutton lever
910 1 4819 502 18499 Screw
910 2 4819 502 38274 Screw for trafo M4x16St
971 0 4819 252 28125 Fuse T10A
971 1 4819 256 38016 Bracket for fuse
972 0 4819 252 28121 Fuse T100mA

SERVICE Whirlpool Europe MWO 165/NB 26.03.1999 / Page 5
Customer Service 8538 424 18492 Doc. No: 4812 714 12672
Exploded view

SERVICE
26.03.1999 / Page 6 MWO 165/NB Whirlpool Europe Doc. No: 4812 714 12672 8538 424 18492 Customer Service
Wiring diagram
4120 Oven lamp
4130 Thermostat oven
4140 Thermostat magnetron
4180 Heatingelement grill
2000 HT capacitor
5000 HT transformer
6000 HT diode
4003 Control system
4010 Magnetron
4030 Mainsfilter
4040 Secondary doorswitch
4050 Monitor doorswitch
4060 Primary doorswitch
4070 Motor fan
4080 Motor turntable

SERVICE Whirlpool Europe MWO 165/NB 26.03.1999 / Page 7
Customer Service 8538 424 18492 Doc. No: 4812 714 12672
Wiring diagram

SERVICE
26.03.1999 / Page 8 MWO 165/NB Whirlpool Europe
Doc. No: 4812 714 12672 8538 424 18492 Customer Service
Program diagram

SERVICE Whirlpool Europe MWO 165/NB 26.03.1999 / Page 9
Customer Service 8538 424 18492 Doc. No: 4812 714 12672
Program diagram
