Whirlpool 8053373A User manual

TO THE INSTALLER: PLEASE LEAVE THIS INSTRUCTION
BOOK WITH THE UNIT.
TO THE CONSUMER: PLEASE READ AND KEEP THIS
BOOK FOR FUTURE REFERENCE.
4.65 Cubic Foot Oven
MODEL SF325PEG
8053373A
with ACCUBAKE®System
A Note to You ............2
Range Safety .............3
Parts and Features....5
Using Your Range......6
Caring for Your
Range.......................20
Troubleshooting.......26
Requesting
Assistance or
Service .....................28
Index ........................31
Warranty...................32
1-800-253-1301
Call our Consumer Assistance Center
with questions or comments.
Standard-Cleaning
Gas Range

2
A NOTE TO YOU
Thank you for buying a WHIRLPOOL®appliance.
The Whirlpool Brand is committed to designing quality products that consistently perform for you to make your
life easier. To ensure that you enjoy years of trouble-free operation, we developed this Use and Care Guide.
It is full of valuable information about how to operate and maintain your appliance properly and safely. Please
read it carefully.
Also, please complete and mail the Product Registration Card provided with your appliance. The card helps us
notify you about any new information on your appliance.
Please record your model’s information.
Whenever you call to request service for your appliance,
you need to know your complete model number and
serial number. You can find this information on the
model and serial number label/plate (see diagram in
the “Parts and Features” section).
Please also record the purchase date of your appliance
and your dealer’s name, address, and telephone number.
Keep this book and the sales slip together in a safe place for future reference. It is important
for you to save your sales receipt showing the date of purchase. Proof of purchase will as-
sure you of in-warranty service.
Our Consumer Assistance Center number is toll free. 1-800-253-1301
Model Number
Serial Number
Purchase Date
Dealer Name
Dealer Address
Dealer Phone
To find detailed product information, the location of the nearest Whirlpool dealer or designated servicer, to
purchase an accessory item, or register your appliance on-line, please visit our Web site at
www.whirlpool.com
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
– Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
•Do not try to light any appliance.
•Do not touch any electrical switch.
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor’s phone. Follow the gas
supplier’s instructions.
•If you cannot reach your gas supplier, call the fire department.
– Installation and service must be performed by a qualified installer, service agency
or the gas supplier.

3
RANGE SAFETY
continued on next page
You will be killed or seriously injured if you don’t
follow instructions.
You can be killed or seriously injured if you don’t
follow instructions.
Your safety and the safety of others is very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards that can kill or hurt you and others.
All safety messages will be preceded by the safety alert symbol and the word “DANGER” or
“WARNING.” These words mean:
wDANGER
wWARNING
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
wWARNING
Tip Over Hazard
A child or adult can tip the range and be killed.
Connect anti-tip bracket to rear range foot.
Reconnect the anti-tip bracket, if the range is moved.
See the installation instructions for details.
Failure to follow these instructions can result in death or serious burns
to children and adults.
Making sure the anti-tip bracket is installed:
•Slide range forward.
•Look for the anti-tip bracket securely attached to floor.
•Slide range back so rear range foot is under anti-tip bracket.
Anti-Tip Bracket
Range Foot
THE ANTI-TIP BRACKET
The range will not tip during normal use. However, the range can tip if you apply too much force or weight
to the open door without the anti-tip bracket fastened down properly.

4
RANGE SAFETY
SAVE THESE INSTRUCTIONS
WARNING: To reduce the risk of fire, electrical
shock, injury to persons, or damage when using the
range, follow basic precautions, including the
following:
•WARNING:TO REDUCE THE RISK OF
TIPPING OF THE RANGE, THE RANGE MUST
BE SECURED BY PROPERLY INSTALLED
ANTI-TIP DEVICES. TO CHECK IF THE DEVICES
ARE INSTALLED PROPERLY, SLIDE RANGE
FORWARD, LOOK FOR ANTI-TIP BRACKET
SECURELY ATTACHED TO FLOOR, AND SLIDE
RANGE BACK SO REAR RANGE FOOT IS
UNDER ANTI-TIP BRACKET.
•CAUTION: Do not store items of interest to
children in cabinets above a range or on the
backguard of a range –children climbing on the
range to reach items could be seriously injured.
•Proper Installation – The range, when installed,
must be electrically grounded in accordance with
local codes or, in the absence of local codes, with
the National Electrical Code, ANSI/NFPA 70. Be
sure the range is properly installed and grounded
by a qualified technician.
•This range is equipped with a three-prong
grounding plug for your protection against shock
hazard and should be plugged directly into a
properly grounded receptacle. Do not cut or
remove the grounding prong from this plug.
IMPORTANT SAFETY INSTRUCTIONS
•Disconnect the electrical supply before servicing
the appliance.
•Never Use the Range for Warming or Heating
the Room.
•Injuries may result from the misuse of appliance
doors or drawers such as stepping, leaning, or
sitting on the doors or drawers.
•Maintenance – Keep range area clear and free
from combustible materials, gasoline, and other
flammable vapors and liquids.
•Storage in or on the Range – Flammable
materials should not be stored in an oven or
near surface units.
•Top burner flame size should be adjusted so it
does not extend beyond the edge of the
cooking utensil.
For self-cleaning ranges –
•Before Self-Cleaning the Oven – Remove broiler
pan and other utensils. Wipe off all excessive
spillage before initiating the cleaning cycle.
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to
publish a list of substances known to the State of California to cause cancer, birth defects, or other
reproductive harm, and requires businesses to warn of potential exposure to such substances.
WARNING: This product contains a chemical known to the State of California to cause cancer, birth
defects, or other reproductive harm.
This appliance can cause low-level exposure to some of the substances listed, including benzene,
formaldehyde, carbon monoxide, and toluene.

5
Electronic
oven control
(p. 10-18)
Control panel
(pp. 5, 19)
Automatic oven
light switch
(p. 25)
Oven vent
(p. 18)
Surface burners
and grates
(pp.6-7, 19, 21-22)
Anti-tip bracket
(p. 3)
Door stop clip
(pp. 22-24)
Model and
serial number
plate
(behind left side
of broiler door)
Broiler door
(p. 16)
Surface burner marker
(shows which burner
you are setting)
PARTS AND FEATURES
Right front
control knob
Right rear
control knob
(ACCUSIMMER™
setting)
Left front
control knob
(POWER™Burner)
Left rear
control knob
CONTROL PANEL

6
USING YOUR RANGE
USING THE SURFACE BURNERS
NOTE: Do not leave empty cookware, or cookware
which has boiled dry, on a hot surface burner. The
cookware could overheat, causing damage to the
cookware or cooking product.
Using POWER Burner
POWER Burner is an adjustable setting for the left
front burner which provides an ultra-high heat setting.
It can be used to rapidly bring liquid to a boil and to
cook large quantities of food.
Using ACCUSIMMER
ACCUSIMMER is an adjustable setting for the right
rear burner. It allows more accurate simmer control at
the lowest setting.
Easy ways to save energy
•To help shorten your cooking time, use the least
amount of liquid possible.
•Preheat your pots and pans only when
recommended and for the shortest time possible.
•Start your food on a higher heat setting, then turn
the control to a lower setting to finish cooking.
wWARNING
Fire Hazard
Do not let the burner flame extend beyond
the edge of the pan.
Turn off all controls when not cooking.
Failure to follow these instructions can
result in death or fire.
RECOMMENDED USE
•To light the burner.
•To provide highest heat
setting.
•To start food cooking.
•To bring liquid to a boil.
•To hold a boil.
•To fry chicken or pancakes.
•For gravy, pudding, and icing.
•To cook large amounts of
vegetables.
•To keep food warm.
•To simmer.
•To provide lowest
simmer/heat setting.
•To melt chocolate or butter.
SETTING
LIGHT
POWER™Burner
(left front burner)
HIGH
Mid-range
(between HIGH
and LOW)
LOW
ACCUSIMMER™
setting
(right rear burner)
Burner heat settings
Use the following chart as a guide.
Using the control knobs
Your range comes with electric ignitors. Electric
ignitors automatically light the burners each time
you turn the control knobs to LIGHT.
•Place a filled pan on the burner grate before
turning on the surface burner. Do not operate a
burner for extended periods of time without
having cookware on the grate.
•Push in the control knob and turn it counter-
clockwise to the
LIGHT position. The
clicking sound is the
ignitor sparking. Make
sure the burner has lit.
•To stop the clicking
sound after the burner
lights, turn the control
knob to the cook
setting you want. You
can set the control knob
anywhere between HIGH and LOW.
NOTE: All four electric ignitors will click at the same
time. However, the burner with the control knob
turned to LIGHT is the one that will ignite.

7
USING YOUR RANGE
USING THE SURFACE BURNERS (CONT.)
In case of a prolonged power failure
You can manually light surface burners. Hold a lit
match near a burner and turn the control knob to
the LIGHT position. After the burner lights, turn the
control knob to the setting you want.
Home canning information
The large diameter of most water-bath or pressure
canners combined with high heat settings for long
periods of time can cause damage to the cooktop.
To protect your range:
•For best results, use a canner which can be
centered over the surface burner.
•Do not place your canner on 2 surface burners
at the same time.
•Start with hot water. This reduces the time
the control is set on high. Reduce the heat
setting to the lowest position needed to maintain
a boil or required pressure levels in a pressure
canner.
•
Refer to your canner manual for specific
instructions.
For up-to-date information on canning, contact
your local U.S. Government Agricultural
Department Extension Office or companies who
manufacture home canning products.
Using the right cookware makes a
big difference
•The pan should have a flat bottom, straight sides,
and a well-fitting lid.
•Choose medium to heavy gauge (thickness)
cookware.
•The pan material (metal or glass) affects how
quickly and evenly the pan heats.
•When using glass or ceramic cookware, check to
make sure it is suitable for use on surface burners.
•To avoid tipping, make sure pots and pans are
centered on the grates.
The pan material affects how fast heat transfers from the surface cooking area through the pan material and how
evenly heat spreads over the pan bottom. Choose pans that provide the best cooking results.
Aluminum • Heats quickly and evenly.
• Use for all types of cooking.
• Medium or heavy thickness is best for most cooking.
• Used as a core or base in cookware to provide even heating.
Cast iron • Heats slowly and evenly.
• Good for browning and frying.
• Maintains heat for slow cooking.
• Can be coated with porcelain enamel.
Ceramic or
ceramic glass • Heats slowly and unevenly.
• Use on low to medium settings.
• Follow manufacturer’s instructions.
Copper • Heats very quickly and evenly.
• Used as a core or base in cookware to provide even heating.
Earthenware • Can be used for cooktop cooking if recommended by the
manufacturer.
• Use on low settings.
Porcelain enamel-on-steel or
enamel-on-cast iron • See cast iron and stainless steel.
Stainless steel • Heats quickly but unevenly.
•
A core or base of aluminum or copper on the cookware provides
even heating.
• Can be coated with porcelain enamel.
CHARACTERISTICS OF COOKWARE MATERIALS

8
USING YOUR RANGE
Positioning racks and pans
Place the oven racks where you need them before
turning on the oven.
•To move a rack, pull it out to the stop position,
raise the front edge and lift it out.
•Be sure the rack(s) is level.
•Use pot holders or oven mitts to protect your hands
if rack(s) must be moved while the oven is hot.
•For best performance, cook on one rack. Place
the rack so the top of the food will be centered in
the oven.
•When cooking with two racks, arrange the racks
on the 2nd and 4th rack guides. Two sheets of
cookies may be baked if sheets are switched at
approximately three quarters of the total bake time.
Increase baking time, if necessary.
•For best results allow 2 inches (5 cm) of space
around each pan and between pans and oven walls.
Extra oven rack position (roasting rack)
Use this rack position when roasting food too large
to be placed on the first
rack position.
For proper roasting,
follow these
guidelines:
•To avoid spillage,
remove food before
pulling out the rack.
•Tilt the rack up at the
front before pulling it
over the door.
•Use an adequate amount of liquid in the pan (meat
juices or water) so your food does not get overdone.
USING THE OVEN
Extra oven rack position
Where to place pans:
WHEN YOU HAVE
1 pan
2 pans
3 or 4 pans
PLACE
In center of the oven rack.
Side by side or slightly
staggered.
In opposite corners on
each oven rack. Stagger
pans so no pan is directly
over another.
Rack placement for specific foods:
FOOD
Frozen pies, large
roasts, turkeys, angel
food cakes
Bundt cakes, most
quick breads, yeast
breads, casseroles,
meats
Cookies, biscuits,
muffins, cakes,
nonfrozen pies
RACK POSITION
1st or 2nd rack
guide from bottom
2nd rack guide
from bottom
2nd or 3rd rack
guide from bottom
NOTE: For information on where to place your rack
when broiling, see “Broiling guidelines” later in this
section.

9
USING YOUR RANGE
BAKEWARE CHOICES
Baking performance is affected by the type of bakeware used. Use the bakeware size recommended in the recipe.
BAKEWARE TYPE
Light colored aluminum • Light golden crusts
• Even browning • Use temperature and time recommended
in recipe.
Dark aluminum and other
bakeware with dark, dull,
and/or non-stick finish
• Brown, crisp crusts • May reduce baking temperature 25°F.
• Use suggested baking time.
• Use temperature and time recommended in recipe
for pies, breads, and casseroles.
• Place rack in center of oven.
Ovenproof glassware,
ceramic glass, or ceramic • Brown, crisp crusts • May reduce baking temperature 25°F.
Insulated cookie sheets or
baking pans • Little or no bottom browning • Place in the bottom third of oven. • May need to increase baking time.
Stainless steel • May need to increase baking time.
• Crisp crustsStoneware • Follow manufacturer's instructions.
• Light, golden crusts
• Uneven browning
BEST USED FOR GUIDELINES
•Do not line the oven bottom with any type of
foil, liners, or cookware. Permanent damage
will occur to the oven bottom finish.
•Do not block the oven bottom vents.
•Do not cover the entire rack with aluminum foil.
Doing so will reduce air
circulation and overall
oven performance.
•To catch spillovers
from pies or casseroles
place foil on the oven
rack below. Foil should
be turned up at edges
and be at least 1 inch
larger than dish.
•Place tent-shaped foil loosely over meat or
poultry to slow down surface browning for long
term roasting. Remove foil for the last 30 minutes.
•Use narrow strips of foil to shield piecrust edges
if browning too quickly.
USING ALUMINUM FOIL

10
USING YOUR RANGE
HR MIN
TIMER
SET
TIMER
OFF
BAKEBAKE
CUSTOM
TEMP
START
ENTER
OFF
CANCEL
CLOCK LIGHTLIGHT
AUTO
CLEAN
HEAT BAKE BROIL LOCK'D TIMER
O N
BROIL
5 SEC
THE ELECTRONIC OVEN CONTROL
Start/enter
pad
(pp. 10, 11,
12, 14, 15, 17)
Hour
pads
(p. 11)
Minute
pads
(p. 11)
Off/cancel
pad
(pp. 12,
14, 17)
Display/clock
•When you first plug in the range, everything on
the display will light up for 1 to 2 seconds, then
a time of day and “PF” will appear on the
temperature display. Press the off/cancel pad to
clear “PF” from the display. If, after you set the
clock (see “Setting the clock” later in this
section), “PF” again appears on the display, your
electricity was off for a while. Reset the clock, if
needed.
•When you are not using the oven, the display will
show the time of day.
•When you are using the oven or minute timer,
the display will show times, temperature settings,
and what command pads have been pressed.
•When showing the time of day, the display will
show the hour and minutes.
•When you are using the minute timer, the display
will show minutes and seconds in the following
sequence:
– For settings from 1-59 minutes, the display will
count down each second.
– For settings 1 hour or over, the display will
count down hours and minutes.
Oven selector
pads
(pp. 13, 15, 17)
Electronic
display
Temperature
pad
(pp. 13, 15, 17)
Clock
pad
(p. 11)
Minute
timer set
and off
pads
(pp. 11, 12)
Oven
light
pad
(p. 25)
Using the control lock
The control lock lets you shut down the control
panel command pads. The control lock comes in
handy when you want to prevent others from
using the oven.
NOTES:
•You can only use the control lock when the oven
is not in use or the control has not been set.
•Set the control lock when cleaning the control
panel to prevent yourself from accidentally turn-
ing on the oven.
•The control lock will stay on even after a power
failure.
To lock the control panel:
Press and hold the start/enter pad for 5 seconds.
You will hear a single tone and “Loc” and
“LOCK’D” will appear on the temperature
display.
To unlock the control panel:
Press and hold START/ENTER for 5 seconds. You
will hear 3 tones followed by a single tone.
“Loc” and “LOCK’D” will disappear from
the temperature display.
START
ENTER
5 SEC
START
ENTER
5 SEC

11
1. Press CLOCK.
2. Set the time.
Press the “up” (s) or “down” (t) pad(s) until
the correct time shows on the display.
3. Start the clock.
SETTING THE CLOCK
PRESS YOU SEE
TIME
CLOCK
PRESS YOU SEE
TIME
(example for 5:30)
HR MIN
PRESS YOU SEE
START
ENTER
5 SEC
CLOCK
OR
USING THE ELECTRONIC MINUTE TIMER
The minute timer does not start or stop the oven.
It works like a kitchen timer. It can be set in hours
and minutes up to 12 hours, 59 minutes. The
minute timer will display minutes and seconds for
settings under 1 hour. You will hear four 1-second
tones when the set time is up.
1. Press TIMER SET.
2. Set the time.
Press the “up” (s) or “down” (t) pad(s) until
the correct time shows on the display.
HR MIN
TIMER
(example for ten minutes)
PRESS YOU SEE
TIMER
TIMER
SET
PRESS YOU SEE
USING YOUR RANGE

12
USING YOUR RANGE
3. Start the minute timer.
The minute timer will begin counting down
immediately after the timer is started.
When the time is up:
You will hear four 1-second tones, then four
1-second reminder tones every minute until
you press TIMER OFF.
NOTE: To display the time of day while the
minute timer is counting down, press CLOCK.
4. Turn off the minute timer.
To cancel the minute timer:
Press TIMER OFF.
USING THE ELECTRONIC MINUTE TIMER (CONT.)
START
ENTER
5 SEC
PRESS YOU SEE
(display counts down)
TIMER
TIMER
YOU SEE
PRESS YOU SEE
TIMER
OFF
(time of day)
PRESS YOU SEE
TIMER
OFF
(time of day)
STARTING/CANCELING A FUNCTION
After setting a function, you must press
START/ENTER to start the function. OFF/CANCEL will cancel any function except
for the clock, timer, or control lock. When
you press OFF/CANCEL, the display
will show the time of day or, if the minute
timer is also being used, the time remaining.
START
ENTER
5 SEC
OFF
CANCEL

13
Your oven is designed with the ACCUBAKE®
temperature management system to constantly
monitor oven temperature. The burner element will
cycle, as needed, to maintain the desired
temperature. This feature is automatically activated
when the oven is in operation.
1. Place the racks where you need them in the
oven. For more
information, see
“Positioning racks and
pans” under “Using the
Oven”, earlier in this
section.
2. Choose the bake setting.
3. Set the temperature (optional).
Do this step if you want to set a temperature
other than 350°F. Press ▲to raise the
temperature or ▼to lower the temperature in
5°F amounts. Use these pads until the desired
temperature shows on the small display.
4. When roasting, put your food in the oven.
You do not have to
preheat the oven when
roasting, unless your
recipe recommends it.
BAKING/ROASTING
Rear
Front
PRESS YOU SEE
BAKE
BAKE
PRESS YOU SEE
(example for bake at 375°F)
TEMP
BAKE
Roasting meats and poultry
•For even cooking, place the meat on a rack in a
shallow pan. This keeps the meat out of the
drippings and allows the heat to circulate better.
•Use a meat thermometer for the most accurate
doneness. Insert it so the tip is in the center of
the largest muscle or thickest portion of the meat
or poultry. Make sure the thermometer is not
touching bone, fat, or the bottom of the pan.
USING YOUR RANGE
IMPORTANT: Do not try to light the oven burner
during a power failure. Never place food or
cookware directly on the oven door or the oven
bottom.

14
USING YOUR RANGE
PRESS YOU SEE
OFF
CANCEL
(time of day)
5. Press START/ENTER.
A preheat conditioning time counts down
the approximate preheat time after the oven
temperature has been set and START has been
pressed. The oven control automatically sets
preheating times based on the oven
temperature you select:
•For 245°F and less, the preheating time is
4 minutes.
•For 250°F-445°F, the preheating time is
10 minutes.
•For above 450°F, the preheating time is
15 minutes.
As the preheat conditioning ends, the selected
oven temperature replaces “PrE” on the display
and the time of day reappears. You will hear a
1-second tone, indicating the oven is ready to use.
The ACCUBAKE®system electronically regulates
the preheat time and temperature to maintain a
precise temperature range for the best cooking
results. The preheat and set temperatures may
be different at the end of the countdown. This is
normal.
NOTES:
•When the oven temperature is greater than
170°F, no preheating time will be shown on the
display.
•You can change the temperature setting any
time after pressing START/ENTER. You do not
have to press START/ENTER again.
6. When baking, put your food in the oven after the
preheat conditioning
time ends. During
baking/roasting, the
oven burner will turn on
and off to keep the
oven temperature at
the setting.
7. After cooking, turn off the oven.
YOU SEE
HEAT BAKE
O N
START
ENTER
5 SEC
(example for set temperature
of 350°F)
PRESS YOU SEE
HEAT BAKE
O N
BAKING/ROASTING (CONT.)
•The preheating time will not change if you reset
the temperature before the countdown time ends.
•If you are baking/roasting while the minute timer
is counting down, you can see the set baking/
roasting temperature for 5 seconds by pressing
BAKE.
Saving energy
•To avoid loss of heat, open the oven door as little
as possible.
•Use a timer to keep track of cooking time.
•Plan your meals for the most efficient use of the
oven by cooking more than one food at a time, or
baking while the oven is still hot after cooking a
meal.

15
USING YOUR RANGE
Although your new oven is properly adjusted to
provide accurate temperatures, it may cook faster
or slower than your old oven.
If you are not satisfied with the baking/roasting
results, you can change the offset temperature by
following the steps below.
NOTE: DO NOT measure the oven temperature with
a thermometer. Opening the oven door will lower
the oven temperature and give you an incorrect
reading. Also, the thermometer temperature reading
will change as your oven cycles.
1. Press and hold BAKE for 5 seconds.
The display will show the current offset
temperature, for example “0,” if you have not
already adjusted the temperature.
2. Set the new offset temperature.
Press ▲to raise the temperature or ▼to lower
the temperature in 10°F amounts. You can set
the temperature change to as low as -30°F or as
high as +30°F. A minus (-) sign will appear before
the number when decreasing the temperature
setting. The minus sign shows the oven will be
cooler by the displayed amount. There is no sign
in front of the number when increasing the
temperature setting.
3. Enter the adjustment.
NOTE: The oven control will stay adjusted even
after a power failure.
How to determine the amount of
adjustment needed
The chart at the right tells you how much to adjust
the offset temperature to get the cooking results
you want. You can figure out cooking results by the
amount of browning, moistness, and rising times for
baked foods.
ADJUSTING THE OVEN TEMPERATURE CONTROL
PRESS YOU SEE
BAKE
(factory setting of “0”)
PRESS YOU SEE
TEMP
(example when making oven
10°F cooler)
PRESS YOU SEE
START
ENTER
5 SEC
(time of day)
TO COOK
FOOD ...
A little more
Moderately more
Much more
A little less
Moderately less
Much less
ADJUST BY
THIS NUMBER
OF DEGREES
(FAHRENHEIT)
+10
+20
+30
-10
-20
-30

16
USING YOUR RANGE
BROILING
3. Before the broiler is turned on, place your food
on the broiler pan. Then
place the pan on the
broiler bottom (Ledge 0)
or one of the two ledges
and roll the broiler pan
and grid into the broiler.
4. Close the broiler door.
Position 2
Position 0
Position 1
Broiler pan and grid
The broiler is located below the oven door. The
broiler pan and grid roll out for easy access. Always
broil with the broiler and oven doors closed.
NOTES:
•Do not step on or apply weight to the broiler door
when it is open. This could damage the door.
•Do not preheat the broiler before using it.
Completely close the broiler door during broiling.
1. Open the broiler door and roll out the broiler pan
and grid.
2. Place the broiler pan and grid so grease can
drain down into the
lower part of the broiler
pan.

5. Press CUSTOM BROIL.
6. Start oven.
You can change the temperature setting any
time after pressing START/ENTER. To change
the setting, see “To custom broil at a lower
temperature” below. After changing the setting,
you do not have to press START/ENTER again.
7. After broiling, turn off the oven.
To custom broil at a lower temperature:
•If food is cooking too fast, press the ▼temp pad
until “325°F” shows on the small display.
•If you want food to broil slower from the start,
press CUSTOM BROIL and press the ▼ temp pad
so a temperature between 300°F and 520°F shows
on the small display. Press START/ENTER.
Lower temperature settings let the broil burner
cycle and slow cooking results. The lower the tem-
perature, the slower the cooking.
NOTE: Fish and chicken are some foods that may
cook better if you use lower broiling temperatures.
17
BROILING (CONT.)
PRESS YOU SEE
PRESS YOU SEE
START
ENTER
5 SEC
HEAT BROIL
O N
CUSTOM
BROIL
BROIL
PRESS YOU SEE
(time of day)
OFF
CANCEL
HEAT BROIL
O N
(example shows broil at 325°F)
PRESS YOU SEE
TEMP
CUSTOM
BROIL
PRESS YOU SEE
TEMP
(example shows broil at 400°F)
BROIL
O N
START
ENTER
5 SEC
HEAT BROIL
O N
YOU SEE
USING YOUR RANGE

18
Broiling guidelines
Recommended pan positions are numbered from bottom (0) to top (2) (see “Broiler pan and grid” earlier in
this section.) You should rotate the broiler pan back to the front at the same time you turn the foods.
BROILING (CONT.)
MEAT
Steak, 1" thick
medium-rare
medium
well-done
Ground Meat Patties, 3⁄4" thick, well-done
Pork Chops, 1" thick
Ham Slice, 1⁄2" thick-precooked
Frankfurters
Chicken
bone-in pieces
boneless breasts
Fish, 1⁄2-3⁄4" thick fillets
SIDE 2
5-6
6-7
8-9
6-7
9-10
3-4
2-3
15-17
11-13
3-4
SIDE 1
10-12
12-14
16-17
11-13
19-21
6-8
5-6
15-17
11-13
7-8
PAN
POSITION
1
1
0
1
1
0
1
1
APPROXIMATE TIME
(MINUTES)
Times are guidelines only and may need to be adjusted to individual tastes.
Very thin cuts, such as fish fillets, may not need to be turned.
Hot air and moisture escape from the oven through
a vent that is near the middle of the backguard.
The vent lets air circulate properly. Be careful not to
block the vent, or you will get poor baking/roasting
results.
NOTE: Never store plastics, paper, or other items
that could melt or burn near the oven vent, or any
of the surface burners.
THE OVEN VENT
Oven vent
USING YOUR RANGE

19
CLEANING CHART
Before cleaning, always make sure all controls are off and the range is cool. Refer to instructions on all
cleaning products before using them to clean your range.
wWARNING
Explosion Hazard
Do not store flammable materials such as gasoline near this appliance.
Doing so can result in death, explosion, or fire.
CARING FOR YOUR RANGE
PART CLEANING METHOD SPECIAL INSTRUCTIONS
Control Knobs •Soap and water
•Dishwasher •DO NOT use steel wool or
abrasive cleaners.
•Pull knobs straight away from
control panel.
•Wash, rinse and dry with soft
cloth.
Control Panel •Soap and water •Wash, rinse and dry with soft
cloth.
Exterior Surfaces*
(excluding control panel and
oven door glass)
•Soap and water
•Mild liquid cleaner
•Spray glass cleaner
•DO NOT use abrasive or harsh
cleaners like chlorine bleach,
ammonia or oven cleaners.
•Wash, rinse and dry with soft
cloth.
•Spray glass cleaner •Apply spray cleaner to paper
towel; do not spray directly on
panel.
•Gently clean around the model
and serial plate, too much
scrubbing could remove the
numbers.
•Non-abrasive plastic scrubbing pad
Surface burner grates and caps*
•Light to moderate soil •Soap and water
•Non-abrasive plastic scrubbing pad •Clean as soon as they become
dirty.
•Wash, rinse and dry well.
•Repeat steps of cleaning process
(with items at left) as needed,
until soil is completely removed.
•Rinse thoroughly and dry.
•NOTE: Do not reassemble caps
on burners while wet.
•Non-abrasive plastic scrubbing pad
•Mild abrasive powdered cleanser
and water
•Heavy burned on soils
•Grates only (not caps).
•Dishwasher
•NOTE: To avoid product
damage, do not remove the
cooktop.
*When the cooktop is cool, remove all spills and clean. Food spills containing acids, such as vinegar and tomato,
may affect the finish.
continued on next page

20
CARING FOR YOUR RANGE
CLEANING CHART (CONT.)
PART CLEANING METHOD SPECIAL INSTRUCTIONS
Surface burners •
See the “Sealed surface burner”
section in the “Caring for your
range” section.
Oven cavity
•Food spills containing
sugar and/or milk •Soap and water •When oven cools, wash, rinse and dry with soft cloth.
Broiler pan and grid •Soap and water
•Steel wool pad
•Dishwasher
•Wash, rinse and dry.
Oven racks •Soap and water
•Steel wool pad •Wash, rinse and dry.
•Solution of 1/2 cup ammonia to
1 gallon water
•Mild abrasive cleanser or
commercial oven cleaner
•Soak for 20 minutes, then scrub
with plastic scrubbing pad.
Oven door glass •Soap and water
•Non-abrasive plastic scrubbing pad •Wash, rinse and dry with soft
cloth.
•Spray glass cleaner •Wipe with paper towel.
•Heavily soiled areas •Steel wool pad •Wipe with clean water and dry well.
•Commercial oven cleaner •Follow the directions that come with the
oven cleaner. (Place newspaper on the
floor to protect the floor surface.) Wipe
well with clean water and dry.
NOTES:
•Use oven cleaners in a well-ventilated
room.
•Do not let commercial oven cleaners
contact the gasket, thermostat, or
exterior surfaces of the range. This
will cause damage.
•For easier cleaning, you can remove
the oven door. Carefully follow the
instructions in the “Removing the oven
door” section.
