Whirlpool GY399LXUB0 User manual

COOKTOP PARTS
1
6−08 Litho in U.S.A. (cre) (mek) Part No. W10204125 Rev. B
30" Slide−In
Electric Range
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10203741 Use & Care Guide
W10203740 Installation
Instructions
2 Cooktop
W10170209 White
W10170210 Black
W10170211 Biscuit
W10170212 S.Steel
3 12001676 Kit, Hardware
4 74008897 Element (LR)
5 74008568 Element (LF,RR)
6 74005759 Tube, Vent Upper
7
W10116760 Screw
8 74003072 Support,Element
9 74011799 Light, Indicator
10 74008919 Element (RF)
For Models: GY399LXUQ0, GY399LXUB0, GY399LXUT0, GY399LXUS0
(White) (Black) (Biscuit) (S.Steel)

CONTROL PANEL PARTS
2W10204125
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
For Models: GY399LXUQ0, GY399LXUB0, GY399LXUT0, GY399LXUS0
(White) (Black) (Biscuit) (S.Steel)
1 74005769 Lens
2 Panel, Control
7720P535−60 Black
7720P536−60 White
7720P537−60 Biscuit
W10182766 S.Steel
3
7101P309−60 Screw
4 Switch, Infinte
74010824 8" (RF,LR)
7403P238−60 6" (LF,RR)
5
W10203701 Control
6 Panel,Control(lwr)
W10185606 Black
W10185607 White
W10185609 Biscuit
7 Knob (LF,RR)
7737P414−60 Black
7737P415−60 White
7737P416−60 Biscuit
8 Switch, Membrane
7450P117−60 Black
W10177224 White
W10177226 Biscuit
9 Knob (RF,LR)
7737P417−60 Black
7737P418−60 White
7737P419−60 Biscuit
10
W10203695 Support,
Control Panel
11 Y700502 Screw
12 74004153 Light, Indicator
13
W10187161 Overlay
(S.Steel Mdl Only)

CHASSIS PARTS
3
W10204125
For Models: GY399LXUQ0, GY399LXUB0, GY399LXUT0, GY399LXUS0
(White) (Black) (Biscuit) (S.Steel)

CHASSIS PARTS
4W10204125
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Panel, Shield
74010821 Left
74010822 Right
2 74010819 Latch Assembly
3 74010807 Cover, Front
4 74011465 Main Back
5
W10203736 Cover, Main Wire
6 74010815 Extension, Back
7 Y700502 Screw
8 74006364 Insulator, Cord
9 74010814 Retainer, Insul.
10
W10177095 Shield, Warmer
11 74010823 Fan, Cooling
12 74010812 Support,Oven Btm
13
7101P124−60 Screw
14 74003040 Element, Broil
15 74004943 Sensor, Oven
16
W10165722 Tube, Vent Lower
17 74010816 Tube, Vent Upper
18
W10116760 Screw
19 74010817 Holder, Vent Tube
20 74008597 Smoke Eliminator
21 74010809 Plate, Smoke Elm.
22 74010885 Light Assembly
23 74004180 Bracket,Pwr Supply
24
7407P103−60 Bulb, Oven
25 Trim, Side
74010832 White (2)
74010831 Black (2)
26 71001394 Screw
27 74010811 Element, Bake
28 74010884 Support, Oven Rear
29 71001394 Screw
30 74011142 Hinge (2)
31 4159193 Screw, Hinge (4)
32 74010818 Switch, Hi−Limit
33 74005564 Bracket,Anti−Tip
34 74010820 Extention, Shield
35 74003386 Support, Element
36 74010805 Leg, Leveling
37 74010899 Pedestal, Bottom
38 74010882 Pedestal, Front
39 74007129 Support
40 74003565 Runner, Drawer (2)
41 74004078 Roller, Drawer (2)
42 74005231 Shaft, Roller (2)
43 74005230 Nut, Lock (2)
44 74006522 Retainer, Bottom
45
W10116760 Screw
46 74008315 Cover,Conv.Fan
47
W10159823 Trim, Front
48
W10116760 Screw
49
W10171550 Switch, Light
50 74011094 Fan, Convect
INSULATION
74010987 Insulation, Wrap
W10165725 Insulation, Back
74010986 Insulation,
Oven Bottom
For Models: GY399LXUQ0, GY399LXUB0, GY399LXUT0, GY399LXUS0
(White) (Black) (Biscuit) (S.Steel)

DOOR PARTS
5
W10204125
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Trim, Door Top
W10165729 Black
W10165726 White
W10177497 Biscuit
W10168887 S.Steel
2
W10163951 Screw, Handle (2)
3 74011457 Baffel, Retainer
4 74001530 Screw 8AB 1/2
5 74003645 Glass, Inner (2)
6 74005546 Spacer, Rubber
7 74001574 Nut, Snap (4)
8 74011456 Lining, Door
9 74011458 Bracket, Glass (2)
10 74003647 Insulation, Door
11 Y700502 Screw
12 Bracket, Handle
74009699 Left
74009698 Right
13 74004224 Tape, White
14 Trim, Door Side
74009693 Black, Left
74009695 White, Left
74009697 Biscuit, Left
74009692 Black, Right
74009694 White, Right
74009696 Biscuit, Right
15 Tape, Double Sided
74009014 White
74009025 Black
16 Trim, Door Bottom
74009687 White
74009686 Black
74009688 Biscuit
17 Screw, Trim
74009540 White
74009539 Black
74009541 Biscuit
74009268 S.Steel
18
W10162384 Seal, Door
19 Glass, Door
W10170228 White
W10170229 Black
W10170230 Biscuit
W10170231 S.Steel
(Order Items 13 &
21 When Replacing
Door Glass)
20 Handle, Door
W10118430 White
W10118431 Black
W10118432 Biscuit
W10144883 S.Steel
21 74003664 Tape, Foil
22 8303810 Nameplate, Logo
23 74010267 Spacer, Rubber
For Models: GY399LXUQ0, GY399LXUB0, GY399LXUT0, GY399LXUS0
(White) (Black) (Biscuit) (S.Steel)

DRAWER AND RACK PARTS
6W10204125
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 74011813 Rack, Oven (2)
2 74008333 Drawer, Storage
3 74004310 Screw, Panel
4 74010896 Bracket, Drawer
5 Panel, Drawer
74003407 White
74003701 Black
74004966 Biscuit
W10160943 S.Steel
6 Screw, Panel
74009540 White
74009539 Black
74009541 Biscuit
74009538 S.Steel
7 74005230 Nut, Lock
8
2404F030−51 Lining, Drawer
9 74005546 Spacer, Rubber
10 74004078 Roller, Drawer (2)
11 74005231 Shaft, Roller (2)
12
7103P082−60 Nut
13 74009589 Rack, Half
14 74009587 Insert, Rack
For Models: GY399LXUQ0, GY399LXUB0, GY399LXUT0, GY399LXUS0
(White) (Black) (Biscuit) (S.Steel)

OPTIONAL PARTS (NOT INCLUDED)
7
W10204125
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 c
242821 Wire, Blue
14 Ga. 150 c
242822 Wire, Brown
14 Ga. 150 c
242830 Wire, Brown
14 Ga. 200 c
242823 Wire, Green
14 Ga. 150 c
242824 Wire, Orange
14 Ga. 150 c
242825 Wire, Red
14 Ga. 150 c
242831 Wire, Red
14 Ga. 200 c
242827 Wire, Yellow
14 Ga. 150 c
REFINISHING MATERIAL
799832 Kit, Porcelain
Repair (White)
242756 Touch−Up
Self−Clean(1/2 Pt)
261582 Grease
INSULATION
261514 Insulation,
Fiberglass (1−1/2"
x 24" x 120")
240132 Insulation,
Fiberglass (2−1/2"
x 22" x 120")
PAINT, TOUCH−UP (1/2oz.)
72017 White
4392899 Biscuit
511873 White Porcelain
(2 Oz.)
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
4392901 Biscuit
285006 Superior Black
206922 Primer (White)
PAINT, BULK (1 qt.)
799344 White (Uncut)
4392900 Biscuit(Uncut)
ACCESSORY PARTS
241430 Foil, Aluminum
Oven (18" x 25’)
3191048 Cleaner, Glass
WIRING HARNESS PARTS
74010849 Harness, Sensor
W10204629 Harness, Top
74011549 U3, Harness (RT)
74011572 Coil,Harness (Lt)
5171P976−60 Harness, Main
74006811 Clip, Wire
For Models: GY399LXUQ0, GY399LXUB0, GY399LXUT0, GY399LXUS0
(White) (Black) (Biscuit) (S.Steel)
