Whirlpool RF263LXTB2 User manual

COOKTOP PARTS
1
For Models: RF263LXTW2, RF263LXTQ2, RF263LXTT2, RF263LXTB2, RF263LXTS2
(White) (White on White) (Biscuit) (Black) (S.Steel)
12−07 Litho in U.S.A. (mo) Part No. W10174141 Rev. A
30" ELECTRIC FREESTANDING
SELF CLEAN RANGE
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature
W10141166 Instructions
Installations
Template, Anti−Tip
9757142 English/Spanish
9757143 English/French
W10162204 Owners Manual
W10115599 Tech Sheet
9762761 Safer Cooking Tips
2 Bowl, Drip
3195208 6" Chrome (2)
3195209 8" Chrome (2)
3 Cooktop
3186231 White
8272527 Biscuit
3186233 Black
4 3195060 Hinge, Cooktop (2)
5 3196178 Screw (2)
6 308605 Relief, Strain
7 3195812 Rod, Support (2)
8 3196154 Screw
9 Element, Surface
9761347 6" (2)
9761345 8" (2)

CONTROL PANEL PARTS
2
For Models: RF263LXTW2, RF263LXTQ2, RF263LXTT2, RF263LXTB2, RF263LXTS2
(White) (White on White) (Biscuit) (Black) (S.Steel)
W10174141
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Endcap
W10009040 White Left Hand
W10009050 White Right Hand
W10009060 Biscuit Left Hand
W10009070 Biscuit Right Hand
W10009080 Black Left Hand
W10009090 Black Right Hand
2 9757609 Nameplate
3 Panel, Control
9762015 White
9762016 Biscuit
9762017 Black
W10117592 S.Steel
4 Switch, Infinite
3148954 LF/RR
3148952 LR/RF
5 Light, Indicator
8523265 Surface Unit (2)
6 3196068 Lens, Light (3)
7 Knob, Infinite (4)
9761962 White
9761963 Biscuit
9761964 Black
8 8053912 Shield, Heat
9 Screw
3196166 White
8281194 Biscuit
3196168 Black
10 8272473 Cover, Upper
11 8273564 Clip
12 Control, Range
W10108090 White
W10108110 Biscuit
W10108100 Black
W10108100 S.Steel
13 3196178 Screw
14 9762078 Brkt−Mntg, EOC
15 9762095 Brkt−Mntg, Console
16 3400882 Screw
17 3196200 Clip, Spring (2)

CHASSIS PARTS
3
For Models: RF263LXTW2, RF263LXTQ2, RF263LXTT2, RF263LXTB2, RF263LXTS2
(White) (White on White) (Biscuit) (Black) (S.Steel)
W10174141

CHASSIS PARTS
4
For Models: RF263LXTW2, RF263LXTQ2, RF263LXTT2, RF263LXTB2, RF263LXTS2
(White) (White on White) (Biscuit) (Black) (S.Steel)
W10174141
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 9760407 Brkt − Mounting
2 3186144 Box, Burner
3 Panel, Side (2)
Incl Side Foil #45
8053830 White
8272519 Biscuit
8053832 Black
4
W10067840 Screw (6)
5 8522416 Seal, Oven Door
6 9757340 Element, Broil
7 9758541 Element, Bake
8 3195809 Bumper (2)
9 9757239 Rod − Dr Switch
10
W10114344 Glide, Drawer Frnt
11 3196037 Foot, Front (2)
12 9761512 Clip, Mounting
13 8054068 Tray, Insulation
14 3196576 Clip, Panel (6)
15 9760314 Rail, Base (2)
16
W10058460 Foot, Rear (2)
17 3196548 Thermal, Fuse
18 3196172 Screw
19 3186116 Support, Oven (2)
20 3186034 Bracket, Service
21 9761958 Block, Terminal
22 8274034 Back, Main
23 9757262 Switch, Door
24 3196701 Light Socket Assy
25 311255 Bulb, Oven Light
26 9758701 Spacer − Door
27 8273902 Sensor, Oven
28 3196169 Screw
29 3196179 Screw
30 3196178 Screw
31 3400016 Screw
32 9758283 Cover, Box
33 9761517 Clip,Door Mntg (2)
34
W10031780 Screw
35 3196567 Screw
36 3196168 Screw
37 3196174 Screw
38 9758238 Retainer, Insul(2)
39 3196560 Screw (2)
40 9755804 Tube, Vent
41 9761013 Latch, Door
42
W10078380 Rod, Latch
43
W10107820 Latch Asy, Rear
44 112432 Nut
45 9761490 Insulation, Side
INSULATION
8272616 Insulation, Wrap
8272612 Insulation, Back

DRAWER & BROILER PARTS
5
For Models: RF263LXTW2, RF263LXTQ2, RF263LXTT2, RF263LXTB2, RF263LXTS2
(White) (White on White) (Biscuit) (Black) (S.Steel)
W10174141
Illus. Part
No. No. DESCRIPTION
1 W10138079 Rack, Oven (2)
2 9761031 Drawer, Storage
3 9758200 Bracket, Drawer(2)
4 Rivet, Push (2)
3196814 White
3196813 Black
5 Panel, Drawer Frnt
8053339 White
8272501 Biscuit
8053341 Black
6 8053334 Glide, Drawer (2)
7 3196168 Screw
8
W10031790 Screw(Stls. Model)
9 9755798 Panel(Stls. Model)
10 9757219 Handle(Stls. Modl)
11 9781235 Clip(Stls. Model)

DOOR PARTS
6
For Models: RF263LXTW2, RF263LXTQ2, RF263LXTT2, RF263LXTB2, RF263LXTS2
(White) (White on White) (Biscuit) (Black) (S.Steel)
W10174141
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Trim, Top
9761975 White
9761976 Biscuit
9762391 Black
9762394 S.Steel
2 3196164 Screw
3 Handle, Door
9761982 White
9761984 Biscuit
9761983 Black
4 9761344 Liner, Door
5
W10031790 Screw
6 9758162 Window, Inner
7 9761357 Retainer, Insul.
8 Hinge, Door (2)
9761493 WH,BT,BL Models
9761496 S.Steel Model
9 Glass, Outer
W10075980 White
W10076000 Biscuit
W10075990 Black
W10154806 SS Model
10 Trim, Side
8523172 White Left Hand
8523166 White Right Hand
8523173 Biscuit Left Hand
8523167 Biscuit Right Hand
8523171 Black Left Hand
8523165 Black Right Hand
11 3196160 Screw
12 Trim, Lower
8523175 White
8523178 Biscuit
8523177 Black
8523180 Black (Used on
S.Steel Model)
13 8272618 Insulation
14 3186289 Frame, Window
15
W10031780 Screw
16 8522414 Seal, Window
17
W10113759 Strap, Door
18 3196794 Bracket, Window
19 3196165 Screw

OPTIONAL PARTS (NOT INCLUDED)
7
For Models: RF263LXTW2, RF263LXTQ2, RF263LXTT2, RF263LXTB2, RF263LXTS2
(White) (White on White) (Biscuit) (Black) (S.Steel)
W10174141
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Following Parts Not Illustrated
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 c
242821 Wire, Blue
14 Ga. 150 c
242822 Wire, Brown
14 Ga. 150 c
242830 Wire, Brown
14 Ga. 200 c
242823 Wire, Green
14 Ga. 150 c
242824 Wire, Orange
14 Ga. 150 c
242825 Wire, Red
14 Ga. 150 c
242831 Wire, Red
14 Ga. 200 c
242827 Wire, Yellow
14 Ga. 150 c
REFINISHING MATERIAL
799832 Kit, Porcelain
Repair (White)
242756 Touch−Up
Self−Clean(1/2 Pt)
261582 Grease
INSULATION
261514 Insulation,
Fiberglass (1−1/2"
x 24" x 120")
240132 Insulation,
Fiberglass (2−1/2"
x 22" x 120")
PAINT, TOUCH−UP (1/2oz.)
72017 White
4392899 Biscuit
511873 White Porcelain
(2 Oz.)
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
4392901 Biscuit
285006 Superior Black
206922 Primer (White)
PAINT, BULK (1 qt.)
799344 White (Uncut)
4392900 Biscuit(Uncut)
ACCESSORY PARTS
241430 Foil, Aluminum
Oven (18" x 25’)
3191048 Cleaner, Glass
4396923 Pan, Broiler
ANTI−TIP KIT
W10017440 Anti−Tip Kit
WIRING HARNESS PARTS
W10084660 Harness, Wire
(Sensor/Dr Switch)
9761476 Harness, Surface
Unit
311227 Wire, Ground
3196154 Screw
W10114335 Harness, Wire
(Main)
313660 Clip, Wire Ground
3196173 Screw
308605 Relief, Strain
3196174 Screw
(Grnd Wire / Back)
