Whirlpool W10600816A User manual

W10600816A
Whi I°
GAS DOUBLE
OVEN RANGE
For questions about features, operation/performance, parts,
accessories or service, call: 1-800-253-1301 or visit our website
at...www.whirlpool.eom
In Canada, call for assistance, installation or service, call:
1-800-807-6777 or visit our website at...
www.whirlpool.ca
CUISINIERE A GAZ
A DOUBLE FOUR
Au Canada, pour assistance, installation ou service, composez le
1-800-807-6777
ou visitez notre site web
www.whirlpool.ca
Table of Contents/Table des matieres .................. 2

TABLE OF CONTENTS
RANGE SAFETY ............................................................................. 3
The Anti-Tip Bracket .................................................................... 4
COOKTOP USE .............................................................................. 5
Cooktop Controls ......................................................................... 5
Sealed Surface Burners ............................................................... 5
Home Canning ............................................................................. 6
Coo kware ..................................................................................... 6
ELECTRONIC OVEN CONTROLS ................................................. 7
Display .......................................................................................... 7
Cancel .......................................................................................... 7
Oven Lights .................................................................................. 7
Oven Timer ................................................................................... 7
Energy Save ................................................................................. 7
Clock ............................................................................................ 7
Settings ........................................................................................ 8
Oven Temperature Control .......................................................... 9
Control Lockout ............................................................................ 9
OVEN USE ....................................................................................... 9
Aluminum Foil............................................................................... 9
Positioning Racks and Bakeware ................................................ 9
Bakeware .................................................................................... 11
Meat Thermometer ..................................................................... 11
Oven Vents ................................................................................. 11
Baking ......................................................................................... 11
Broiling ........................................................................................ 12
Convection Cooking - Lower Oven Only ................................... 13
Keep Warm Feature ................................................................... 14
Sabbath Mode ............................................................................ 14
Timed/Delay Cooking ................................................................. 15
RANGE CARE ............................................................................... 16
Self-Cleaning Cycle .................................................................... 16
General Cleaning ........................................................................ 17
Oven Light .................................................................................. 18
Oven Door .................................................................................. 18
TROUBLESHOOTING .................................................................. 19
ASSISTANCE OR SERVICE ......................................................... 21
In the U.S.A................................................................................ 21
Accessories ................................................................................ 21
In Canada ................................................................................... 21
WAR RANTY .................................................................................. 22
TABLE DES MATII RES
SI_CURITI_ DE LA CUISINII=RE ................................................... 23
La bride antibasculement ........................................................... 24
UTILISATION DE LA TABLE DE CUlSSON ................................ 26
Commandes de latable de cuisson .......................................... 26
BrQleurs de surface scelles ........................................................ 27
Preparation de conserves & la maison ....................................... 27
Ustensiles de cuisson ................................................................ 27
COMMANDES I_LECTRONIQUES DU FOUR ............................ 28
€:cran........................................................................................... 28
Annulation ................................................................................... 28
Lampes du four .......................................................................... 29
Minuterie de four ........................................................................ 29
12conomie d'energie ................................................................... 29
Horloge ....................................................................................... 29
Reglages ..................................................................................... 29
Commande de la temperature du four ...................................... 31
Verrouillage des commandes ..................................................... 31
UTILISATION DU FOUR ............................................................... 31
Papier d'aluminium ..................................................................... 31
Positionnement des grilles et des ustensiles
de cuisson au four ...................................................................... 31
Ustensiles de cuisson au four .................................................... 33
Thermometre &viande ............................................................... 33
12ventsdu four ............................................................................ 33
Cuisson au four .......................................................................... 33
Cuisson au gril ............................................................................ 34
Cuisson par convection - Four inferieur uniquement ................ 35
Caracteristique Keep Warm (garder au chaud) ......................... 36
Mode Sabbat .............................................................................. 37
Cuisson minut6e/a mise en marche diff6r6e ............................. 38
ENTRETIEN DE LA CUlSINII_RE ................................................. 39
Programme d'autonettoyage ..................................................... 39
Nettoyage gen6ral ...................................................................... 40
Lampe du four ............................................................................ 41
Porte du four ............................................................................... 42
DI_PANNAGE ................................................................................. 43
ASSISTANCE OU SERVICE ......................................................... 45
Au Canada .................................................................................. 45
Accessoires ................................................................................ 45
GARANTIE ..................................................................................... 46
2

RANGE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
WARNING: If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or death,
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance,
-WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electrical switch.
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
•If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or
the gas supplier,
WARNING: Gas leaks cannot always be detected by smell.
Gas suppliers recommend that you use a gas detector approved by UL or CSA.
For more information, contact your gas supplier.
If a gas leak is detected, follow the "What to do if you smell gas" instructions.
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.

....[ he AntioTip Bracket
The range will not tip during normal use. However, the range can tip if you apply too much force or weight to the open door without the
anti-tip bracket fastened down properly.
Tip Over Hazard
A child or adult can tip the range and be killed.
Verify the anti-tip bracket has been properly installed and engaged per installation instructions.
Re-engage anti-tip bracket if range is moved.
Do not operate range without anti-tip bracket installed and engaged.
Failure to follow these instructions can result in death or serious burns to children and adults.
Anti-Tip
""Bracket
Ra
To verify the anti-tip bracket is installed and engaged:
• Slide range forward.
•Look for the anti-tip bracket securely attached to floor or wall.
•Slide range back so rear range foot is under anti-tip bracket.
•See installation instructions for details.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electrical shock,
injury to persons, or damage when using the range, follow
basic precautions, including the following:
•WARNING: TO REDUCE THE RISK OF TIPPING OF
THE RANGE, THE RANGE MUST BE SECURED BY
PROPERLY INSTALLED ANTI-TIP DEVICES. TO CHECK
IF THE DEVICES ARE INSTALLED PROPERLY, SLIDE
RANGE FORWARD, LOOK FOR ANTI-TIP BRACKET
SECURELY ATTACHED TO FLOOR OR WALL, AND
SLIDE RANGE BACK SO REAR RANGE FOOT IS UNDER
ANTI-TIP BRACKET.
•WARNING: NEVER use this appliance as a space
heater to heat or warm the room. Doing so may result in
carbon monoxide poisoning and overheating of the oven.
•WARNING: NEVER cover any slots, holes or passages
in the oven bottom or cover an entire rack with materials
such as aluminum foil. Doing so blocks air flow through the
oven and may cause carbon monoxide poisoning.
Aluminum foil linings may also trap heat, causing a fire
hazard.
•CAUTION: Do not store items of interest to children in
cabinets above a range or on the backguard of a range -
children climbing on the range to reach items could be
seriously injured.
• Proper Installation - The range, when installed, must be
electrically grounded in accordance with local codes or, in
the absence of local codes, with the National Electrical
Code, ANSI/NFPA 70. In Canada, the range must be
electrically grounded in accordance with Canadian
Electrical Code. Be sure the range is properly installed and
grounded by a qualified technician.
• This range is equipped with a three-prong grounding plug
for your protection against shock hazard and should be
plugged directly into a properly grounded receptacle. Do
not cut or remove the grounding prong from this plug.
• Disconnect power before servicing.
• Injuries may result from the misuse of appliance doors or
drawers such as stepping, leaning, or sitting on the doors
or drawers.
• Maintenance - Keep range area clear and free from
combustible materials, gasoline, and other flammable
vapors and liquids.
• Storage in or on the Range - Flammable materials should
not be stored in an oven or near surface units.
• Top burner flame size should be adjusted so it does not
extend beyond the edge of the cooking utensil.
For self-cleaning ranges -
• Before Self-Cleaning the Oven - Remove broiler pan and
other utensils. Wipe off all excessive spillage before
initiating the cleaning cycle.
SAVE THESE INSTRUCTIONS

COOKTOP USE
This manual covers different models. The range you have purchased may have some or all of the items listed. The locations and
appearances of the items shown here may not match those of your model.
A B C D
A. Left front control knob
B. Left rear control knob C. Center burner (on some models) D. Right rear control knob
E. Right front control knob
Cooktop Cont o)s
Fire Hazard
Do not let the burner flame extend beyond the edge of
the pan.
Turn off all controls when not cooking.
Failure to follow these instructions can result in death
or fire.
IMPORTANT: Your range is factory-set for use with Natural gas. If
you wish to use LP gas, an LP Gas Conversion Kit is included
with your new range. See the "Gas Conversions" section of the
Installation Instructions for details on making this conversion.
Electric igniters automatically light the surface burners when
control knobs are turned to IGNITE.
The large burners (16,000, 14,000 and 12,500 Btu/h [British
Thermal Units]) provide the highest heat setting, and are ideal for
cooking large quantities of food or liquid, using large pots and
pans. The small burners (9,200 and 5,000 Btu/h) allow more
accurate simmer control at the lowest setting, and are ideal for
cooking smaller quantities of food, using smaller pots and pans.
Before setting a control knob, place filled cookware on the grate.
Do not operate a burner while using empty cookware or without
any cookware on the grate.
NOTE: Visually check that the burner has lit. If the burner does
not ignite, listen for a clicking sound. Ifyou do not hear the igniter
click, turn the burner off. Check for a tripped circuit breaker or
blown household fuse.
Check that the control knob is pressed completely down on the
valve shaft. If the spark igniter still does not operate, call a trained
repair specialist.
To Set:
1. Push in and turn knob counterclockwise to IGNITE.
All the surface burners will click. Only the burner with the
control knob turned to Ignite will produce a flame.
2. Turn knob anywhere between HIGH and LOW. Use the
following chart as a guide when setting heat levels.
SETTING RECOMMENDED USE
IGNITE • Light the burner.
HIGH • Start food cooking.
• Bring liquid to a boil.
Medium • Hold a rapid boil.
• Quickly brown or sear food.
• Fry or saute foods.
• Cook soups, sauces and gravies.
• Stew or steam foods.
LOW • Keep food warm.
• Simmer.
REMEMBER: When range is in use or (on some models)
during the Self-Cleaning cycle, the entire cooktop area may
become hot.
A--
A. Burner cap C.Alignment pins
B. Burner base D. Igniter
E.Gas tube opening
IMPORTANT: Do not obstruct the flow of combustion and
ventilation air around the burner grate edges.

Burnercap:Alwayskeeptheburnercapinplacewhenusinga
surfaceburner.Acleanburnercapwillhelpavoidpoorignition
andunevenflames.Alwayscleantheburnercapafteraspillover
androutinelyremoveandcleanthecapsaccordingtothe
"GeneralCleaning"section.
Gas tube opening: Gas must flow freely throughout the gas tube
opening for the burner to light properly. Keep this area free of soil
and do not allow spills, food, cleaning agents or any other
material to enter the gas tube opening. Keep spillovers out of the
gas tube by always using a burner cap.
Home Canning
When canning for long periods, alternate the use of surface
burners between batches. This allows time for the most recently
used areas to cool.
• Center the canner on the grate above the burner.
• Do not place canner on 2 surface burners at the same time.
• For more information, contact your local agricultural
department. Companies that manufacture home canning
products can also offer assistance.
B
A. 1-11/2'' (2.5-3.8 cm)
B. Burner ports
Burner ports: Check burner flames occasionally for proper size
and shape as shown in the previous illustration. A good flame is
blue in color, not yellow. Keep this area free of soil and do not
allow spills, food, cleaning agents or any other material to enter
the burner ports.
To Clean:
IMPORTANT: Before cleaning, make sure all controls are off and
the oven and cooktop are cool. Do not use oven cleaners, bleach
or rust removers.
1. Remove the burner cap from the burner base and clean
according to "General Cleaning" section.
2. Clean the gas tube opening with a damp cloth.
3. Clean clogged burner ports with a straight pin as shown. Do
not enlarge or distort the port. Do not use a wooden
toothpick. If the burner needs to be adjusted, contact a
trained repair specialist.
4. Replace the burner cap, making sure the alignment pins are
properly aligned with the burner cap.
5=
A. Incorrect
B. Correct
Turn on the burner. If the burner does not light, check cap
alignment. If the burner still does not light, do not service the
sealed burner yourself. Contact a trained repair specialist.
IMPORTANT: Do not leave empty cookware on a hot surface
cooking area, element or surface burner.
Ideal cookware should have a flat bottom, straight sides and a
well-fitting lid, and the material should be of medium-to-heavy
thickness.
Rough finishes may scratch the cooktop or grates. Aluminum and
copper may be used as a core or base in cookware. However,
when used as a base they can leave permanent marks on the
cooktop or grates.
Cookware material is a factor in how quickly and evenly heat is
transferred, which affects cooking results. A nonstick finish has
the same characteristics as its base material. For example,
aluminum cookware with a nonstick finish will take on the
properties of aluminum.
Cookware with nonstick surfaces should not be used under the
broiler.
Use the following chart as a guide for cookware material
characteristics.
COOKWARE CHARACTERISTICS
Aluminum • Heats quickly and evenly.
• Suitable for all types of cooking.
• Medium or heavy thickness is best for
most cooking tasks.
Cast iron • Heats slowly and evenly.
• Good for browning and frying.
• Maintains heat for slow cooking.
Ceramic or • Follow manufacturer's instructions.
Ceramic glass • Heats slowly, but unevenly.
• Ideal results on low to medium heat
settings.
Copper • Heats very quickly and evenly.
Earthenware • Follow manufacturer's instructions.
• Use on low heat settings.
Porcelain • See stainless steel or cast iron.
enamel-on-steel
or cast iron
Stainless steel • Heats quickly, but unevenly.
• A core or base of aluminum or copper on
stainless steel provides even heating.
6

ELECTRONIC OVEN CONTROLS
This manual covers different models. The range you have purchased may have some or all of the items listed. The locations and
appearances of the items shown here may not match those of your model.
A B C D
.........D PI ..............
Upper ( Keep 1
Oven Bake Broil Warm
D
Lower ..;"..................................................... _
Oven i Bake WarmKeepConvect i
i
0 N
A. Upper oven settings E. Number keypad
B. Cook time F. Upper oven start
C. Start time G. Timer set/off
D. Oven display H. Settings
E
12
4 5
7 8
G o
M
I.Upper oven cancel
J. Lower oven cancel
K. Lower oven start/
control lock
:G H I
/
/
Start Cancel
%...°._J %.....J
9
Start Cancel
_,., ...- _.. ,...
_.._:;;,,.-.:..
s sec
L K J
L.Oven light
M. Clock
N. Precise Clean
O. Lower oven settings
When power is first supplied to the range, or if a power failure has
occurred, 12:00 will appear on the display. See the "Clock"
section to set time of day.
When the oven is not in use, the display shows the time of day,
unless the oven is in Energy Save mode.
Cancel stops any function except the Clock, Timer and Control
Lock.
Oven Lights
While the oven doors are closed, press the Oven Light icon on
the keypad to turn the lights on and off. Both oven lights will
come on when either door is open. The oven lights will not come
on during the Self-Clean cycle.
Energy Save
The Energy Save mode deactivates the display to reduce energy
consumption.
To Activate the Energy Save Mode:
1. Press and hold SE-I-I-INGS for 3 seconds. "Energy saver on."
will appear in the upper text area.
2. The setting will be activated after 5 minutes.
Any mode may be used with the range in Energy Save by
simply selecting the desired mode.
To Deactivate the Energy Save Mode:
1. Press and hold SE-I-I-INGS for 3 seconds. "Energy saver off."
will appear in the upper text area.
2. The clock will reappear in the display, and the range can be
operated as usual.
Oven Timer
The Oven Timer can be set in hours or minutes up to 9 hours and
59 minutes, and counts down the set time. The Oven Timer does
not start or stop the oven.
To Set:
1. Press TIMER SET/OFF.
2. Press the number keypads to set the length of time in hr-hr-
min-min. Leading zeroes do not have to be entered. For
example, for 2 minutes, enter "2."
3. Press TIMER SET/OFF to begin the countdown. If enabled,
end-of-cycle tones will sound at end of countdown.
4. Press TIMER SET/OFF twice to cancel the Oven Timer and
return to the time of day. Do not press Cancel because the
oven will turn off.
5. If the Oven Timer is running, but not in the display, press
TIMER SET/OFF to display the countdown for 5 seconds.
To Cancel:
Press the TIMER SET/OFFpad.
To change the clock between 12-hour and 24-hour format, see
"12/24 HOUR (Adjusting the Clock Format)" in the "Settings"
section.
To Set the Time of Day:
Before setting, make sure the oven and Oven Timer are off.
1. Press the Clock icon. "Clock: Press 3 for AM and Press 6 for
PM" will scroll.
2. Use the number keypad to select AM or PM.
"Set Time" will display.
3. Use the number keypad to enter the current time.
4. Press the Clock icon or press START. "Time Set" will display
in the upper text area for 5 seconds. Once it disappears, the
time is set.

TheSettingsfunctionenablesyoutopersonalizeaudibletones
andovenoperationtosuityourneeds.Aftercompletingyour
adjustments,pressCANCELorwait30secondsforthedisplayto
showthetimeofday.Tochangeanyofthefollowingsettings,
pressSETTINGSuntilthecorrectdisplaytextappears,andthen
followtheinstructionsintheappropriatesection.Seethe
following"SettingsQuickReferenceChart."
Settings Quick Reference Chart
Display Text Default Setting To change Setting
TEMP UNIT Fahrenheit Press (1) for Celsius
SOUND On Press (1) for OFF
SOUND VOLUME High Press (1) for LOW
END TONE On Press (1) for OFF
KEYPRESS TONE On Press (1) for OFF
REMINDER TONE On Press (1) for OFF
12/24 HOUR 12 Hr Press (1) for 24 HR
SABBATH Off Press (1) for ON
12Hr AUTO_OFF On Press (1) for OFF
LANGUAGE English Press (1) for French
Press (2) for Spanish
TEMP CALIB Upper Calibrate Press (1) for LOWER
CALIBRATE
Temp Unit (Fahrenheit and Celsius)
The temperature is preset at Fahrenheit, but can be changed to
Celsius.
1. Press SETTINGS until "TEMP UNIT" is displayed.
2. Press the "1" keypad to adjust the setting.
3. Press any START or CANCEL to save the setting and exit.
Sound (Tones)
Tones are audible signals, indicating the following:
Basic Functions
One tone
• Valid pad press
• End of Oven Timer (long tone)
• Function has been entered
• Oven is preheated
Three tones
• Invalid pad press
Four tones
• End of cycle
Sound (Adjust On or Off)
The oven sound is factory set for On but can be changed to Off.
1. Press SETTINGS until "SOUND" is displayed.
2. Press the "1" keypad to adjust the setting.
3. Press any START or CANCEL to save the setting and exit.
Sound Volume (Adjusting Sound Volume)
The oven sound is factory set for High but can be changed to Low.
1. Press SE-i-i-INGS until "SOUND VOLUME" is displayed.
2. Press the "1" keypad to adjust the setting.
3. Press any START or CANCEL to save the setting and exit.
End Tone (Adjusting End Tone On or Off)
The end tone is factory set for On but can be changed to Off.
1. Press SE-i-i-INGS until "END TONE" is displayed.
2. Press the "1" keypad to adjust the setting.
3. Press any START or CANCEL to save the setting and exit.
Keypress Tone (Adjusting Keypress Tone On or Off)
The keypress tone is factory set for On but can be changed to Off.
1. Press SE-i-i-INGS until "KEYPRESS TONE" is displayed.
2. Press the "1" keypad to adjust the setting.
3. Press any START or CANCEL to save the setting and exit.
Reminder Tone (Adjusting Reminder Tone On or Off)
The reminder tone isfactory set for On but can be changed to Off.
1. Press SE-i-i-INGS until "REMINDER TONE" is displayed.
2. Press the "1" keypad to adjust the setting.
3. Press any START or CANCEL to save the setting and exit.
12/24 Hour (Adjusting the Clock Format)
The clock can be set to display time in a 12-hour or 24-hour
format. The clock is set at the factory for the 12-hour format.
1. Press SE-i-i-INGS until "12/24 HOUR" is displayed.
2. Press the "1" keypad to adjust the setting.
3. Press any START or CANCEL to save the setting and exit.
Sabbath (Sabbath Mode)
Sabbath Mode configures the range to conform to Star-K Jewish
Sabbath requirements for a Bake cycle, including Timed Bake or
Delayed Bake functions. Refer to the "Sabbath Mode" section for
a full description of this feature. Sabbath Mode is factory set for
disabled, but can be changed to enabled.
1. Press SE-i-i-INGS until "SABBATH" is displayed.
2. Press the "1" keypad to adjust the setting.
3. Press any START or CANCEL to save the setting and exit.
12 Hr Auto Off (Adjust On or Off)
The oven control is set to automatically shut off the oven
12 hours after the oven turns on. This will not interfere with any
timed or delayed cook function.
1. Press SE-i-i-INGS until "12Hr AUTO OFF" is displayed.
2. Press the "1" keypad to adjust the setting.
3. Press any START or CANCEL to save the setting and exit.
Language (Change Language Options)
The Language is factory preset to English but can be changed to
French or Spanish.
1. Press SE-i-i-INGS until "LANGUAGE" is displayed.
2. Press the "1" keypad to select French, or press the "2"
keypad to select Spanish.
In French, press the "1" keypad to select Spanish, or press the
"2" keypad to select English. In Spanish, press the "1" keypad
to select English, or press the "2" keypad to select French.
3. Press any START or CANCEL to save the setting and exit.
8

Oven "")"bmpe ature Oontro)
The oven provides accurate temperatures; however, it may cook
faster or slower than your previous oven, so the temperature
calibration can be adjusted. It can be changed in Fahrenheit or
Celsius.
Temperature adjustment applies to upper or lower ovens.
A minus sign means the oven will be cooler by the displayed
amount. The absence of a minus sign means the oven will be
warmer by the displayed amount. Use the following chart as a
guide.
ADJUSTMENT °F COOKS FOOD
(ADJUSTMENT °C)
10°F (6°C) ...a little more
20°F (12°C) ...moderately more
30°F (17°C) ...much more
-10°F (-6°C) ...a little less
-20°F (-12°C) ...moderately less
-30°F (-17°C) ...much less
Temp Calib (Adjust Oven Temperature Calibration)
IMPORTANT: Do not use a thermometer to measure oven
temperature because opening the oven door may cause element
cycling to give incorrect readings.
1. Press SE-n-INGS until "TEMP CALIB" is displayed.
2. The range is factory set to UPPER CALIBRATE. Press the "1"
keypad to change the selected oven.
3. Press the "3" keypad to increase the temperature in 5°F (3°C)
increments, or press the "6" keypad to decrease the
temperature in 5°F (3°C) increments. The range is from -30°F
to +30°F (-18°C to 18°C).
4. Press any START or CANCEL to save the setting and exit.
Centre) Lockout
The oven controls can be locked out to avoid unintended use of
the oven.
The oven controls cannot be locked if the oven is in use.
The current time of day will remain in the display when the
controls are locked.
To Lock Controls:
1. Press and hold START for 3 seconds. "Control Locked" will
scroll in the upper text area. "Control Locked" will scroll while
the control is locking, then "Locked" is displayed.
"Locked" and time of day remain lit in the display
To Unlock Controls:
1. Press and hold START for 3 seconds.
"Unlocking" will scroll in the display for 3 seconds while the
controls are unlocking, and the time of day is displayed.
OVEN USE
Odors and smoke are normal when the oven is used the first few
times, or when it is heavily soiled.
IMPORTANT: The health of some birds is extremely sensitive to
the fumes given off. Exposure to the fumes may result in death to
certain birds. Always move birds to another closed and well-
ventilated room.
Preheating
The upper and lower ovens have Rapid and standard preheat
options. When only one oven is used (either upper or lower) the
oven in use will default to the Rapid preheat option. The Rapid
preheat option is only recommended for single-rack baking.
When both ovens are used simultaneously, the ovens will default
to the standard preheat option. The standard preheat option is
recommended for multi-rack baking in the lower oven. The upper
oven is used only for single-rack cooking.
When the lower oven is used independently, the oven will default
to the Rapid preheat option to be used for single-rack baking
only. To use the standard preheat option for multi-rack baking in
the lower oven, make the appropriate selection during Bake or
Convection Bake operation setup. Unused racks should be
removed prior to preheating oven.
To toggle between single or multi-rack baking, press START for
the desired oven after beginning the Bake or Convection Bake
mode.
A)um)num Foi)
IMPORTANT: To avoid permanent damage to the oven bottom
finish, do not line the oven bottom with any type of foil, liner or
cookware.
• For best cooking results, do not cover entire rack with foil
because air must be able to move freely.
• To catch spills, place foil on rack below dish. Make sure foil is
at least 1/2"(1.3 cm) larger than the dish and that it is turned
up at the edges.
Position)rig Racks and Bakeware
IMPORTANT: To avoid permanent damage to the porcelain
finish, do not place food or bakeware directly on the oven door or
bottom.
Racks
• Position racks before turning on the oven.
• Do not position racks with bakeware on them.
• Make sure racks are level.
• The upper oven is equipped with 1 flat rack.
• The lower oven is equipped with 2 flat racks.
• Place food so it will not rise into the broil element. Allow at
least 1/2"(1.3 cm) between pans and the broil burner.

To Remove Oven Racks:
Flat Racks: Pull rack out to the stop position, raise the front edge,
and then lift out.
To Replace Oven Racks:
Flat Rack: Place rack on the rack support in the oven. Tilt the
front edge up slightly, and slide rack back until it clears the stop
position. Lower front and slide back into the oven.
Rack Positions - Upper Oven
Baking
FOOD RACK POSITION
All foods 1
Broiling
FOOD RACK POSITION
Broiling 1
Convection Cooking
FUNCTION NUMBER OF RACK
RACKS USED POSITION(S)
Convection baking 1 3
Convection baking 2 2 and 4
Convection roasting 1 1 or 2
Multiple Rack Cooking
2-rack: Use rack positions 2 and 4 when baking 2 racks of pizza.
Stagger pizza so that the pizza on rack position 2 is toward the
right side of the oven and the pizza on rack position 4 is toward
the left side of the oven.
Baking Layer Cakes on 2 Racks
For best results when baking cakes on 2 racks, use rack
positions 2 and 4. Place the cakes on the racks as shown.
Cook function Rack position
Convect bake 2 and 4
Bake 2 and 4
Rack Positions -Lower Oven
Traditional Cooking
FOOD RACK POSITION
Large roasts, turkeys 1 or 2
Yeast breads, quick breads, muffins, 2
tube cakes, small cuts of meat and
poultry and 2-rack baking
Cookies, biscuits, casseroles, muffins, 3
cakes, 1-rack baking
2-rack baking 4 and 5, or 2 and 4, or
2 and 5
BAKEWARE
To cook food evenly, hot air must be able to circulate. Allow
2" (5.0 cm) of space around bakeware and oven walls. Use the
following chart as a guide.
NUMBER POSITION ON RACK
OF PAN(S)
1 Center of rack.
2 Side by side or slightly staggered.
3 or 4 Make sure that no bakeware piece is directly
over another. See illustrations for placement of
layer cakes.
10
