Whirlpool SF336PER User manual

G033~uous-Cleaning
SF336PER
and
Model SF3lGPER(Shown)
wave Ovens. Trash Compactors. Room AM Condltloners. Oehumldiflers. Automatic Washers, Clothes Oryen. Freezers. Refrigerator-Freezers

Contents
Page Page
Before You Use Your Range . . . 2 Lift-Up Cooktop . . . 12
Important Safety Instruclions. 3 Surface Burners . . . 13
Parts and Features. . . . . . . . . . . 5 OvenDoor , . . . . . . . . . . . 13
Using your Range. . . . . . . . . . . . 6 Continuous-Cleaning Oven . 14
Using the Surface Burners 6 Standard Oven Cleaning . 15
Setting the Clock . . . . . 7 Cleaning Chart . . . . . . . . . . . . .
Using the Minute Tlmer . . 8 Changing the Cooktop Light i;
Using the Oven Controls . . . B Changing the Oven Light . . . . 18
Baking . . . . . . . . . . 8 If You Need Servlce or
Broiling . . . . . . . . . . . . 9 Assistance . . . . . . . . . . . . . . . 18
Using the Cooking Hours 1. Before Calling for
Control . . . . . . . . . . . . . . . . . . 10 Assistance.. . . . . . . . . . 18
OvenUent . . . . . . . . . . . . . . . . . . 11 2. IfYou Need Assistance . . . 19
Caring for Your Range . . . . . . . . 11 3. IfYou Need Service . . . . . 19
Control Panels . . . . . . . . . . . . . 11 4. IfYou Have a Problem . . . . . 19
Surface Burner Grates and
Reflector Pans . . . . . . . . . . . . . 12
01986 Whlrlpool Corporation
Before you use your range
Read and carefully follow the “INSYAUATION INSTRUCTIONS”
packed wlth your mnge.
Read ihls Use 6 Care Oulde and the Cooklng Oulde ior Important safety
lnformallon.

You are personally responsible for:
l Reading and following all safety precautions in this Use & Care Guide and
the Cooking Guide.
l Having your range installed by a qualified installer.
l Installing the range where it is protected from the elements, and on a level
floor strong enough to hold itsweight.
l Having your range properly connected to electrical supply and grounded.
(See “Installation Instructions”.)
l Having your range properly connected to the proper gas supply and
checked for leaks. (See “Installation Instructionsl’)
l Making sure the range is not used by children or anyone unable to operate
it properly.
l Properly maintaining your range.
l Using the range only for jobs expected of a home range.
See “Cooking Guide” for important safety and use information.
IMPORTANT
SAFETY INSTRUCTIONS
1. DO NOT allow children to use or 6. KEEP pan handles turned in, but
play with any part of the range, not over another surface burner
or leave them unattended near to prevent burns, injury and to
it.They could be burned or help prevent the utensil from
injured. being pushed off the cooktop.
2. DO NOT store things children 7.
DO NOT use water on grease
might want above the range. fires. The fire will spread. Cover
Children could be burned fire with large lid or smother with
or injured while climbing on it. baking soda or salt.
3. DO NOT allow anyone to touch
8. DO NOT wear loose or hanging
a hot surface burner, oven garments when using the range.
burner or areas around them. Garments could ignite if they
They could be hot enough to touch a hot burner or surround-
burn severely. ing area and you could be
4. KEEP children away from the burned.
range when it is on. The cooktop, 9. DO NOT heat unopened con-
oven walls, racks and door can tainers. They could explode. The
be hot enough to cause burns. hot contents could burn and
5. DO NOT use a range to heat a container particles could cause
room. Persons in the room could injury
be burned or injured, or a fire IO. When adding or removing food,
could start.
MAKE SURE to open the oven
door all the way to prevent burns.
conttnued on next page

11. DO NOT use a wet pot holder.
14. GREASE is flammable and
Steam burns can result. DO NOT
should be handled carefully. Let
use a towel or bulky cloth as a fat cool before attempting to
pot holder. They could catch fire handle it.
Do not allow grease to
and burn you.
collect around range or in
12. MAKE SURE the utensils you use
vents. Wipe spill-overs
are large enough to contain immediately.
food and avoid boil-overs and
15. NEVER use a match or other
spill-avers. This will help prevent flame to look for a gas leak. Ex-
hazardous build-ups of food. plosion and injury could result.
Heavy splattering or spill-overs
left on a range can ignite and
16. DO NOT repair or replace any
burn you. Pan size isespecially parts unless specifically recom-
important in deep fat frying. mended in this manual. All other
13. DO NOT leave surface burners on servicing should be referred to a
qualified service technician.
high heat settings. Boil-overs and
greasy spillovers could cause 17. DO NOT use Oven for storage,
steam, smoke and could ignite Stored items and range could
and burn you. be damaged if oven isturned
on accidentally.
l FOR YOUR SAFETY l
DO NOT STOREOR USEGASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS
IN THEVICINITY OF THIS OR ANY OTHER APPLIANCE. THEYCOULD IGNITE
CAUSING EXPLOSION AND/OR FIRE.
- SAW THESE INSTRUCTIONS -
L
Copy your Model and Serial Numbers here...
Ifyou need service, or call with a
question, have this information
ready:
1. Complete Model and Serial
Model Number
Numbers (from the plate located
as shown).
Serial Number
2. Purchase date from sales slip.
Copy this information in these
Purchase Date
spaces. Keep this book, your war-
ranty and sales slip together in a
handy place.
Service Company Phone Number
Please complete and mail the Owner Registration Card
furnlshed with this product.
4

Parts and features
Models SF336PERand SF316PER
\wrrn
LIGHT SWITCH
SURFACE BURNER
AND
OVEN CONTROLS
OVEN RACK F-IM=
/
MODEL AND
SERIAL NUMBER
PLATE
STANDARD
OVEN (SF316PER)
CONTINUOUS-
CLEANING OVEN
(SF336PER)
5

Using your range
TOP LIGHT OVEN TEMP RIGHT FRONT OVEN LIGHT
SWITCH CONTROL KNOB CONTROL ,KNOB SWITc\H
/ \
SURFACE RIGHT REAR
LEFT FRONT LEFT REAR BURNER CONTROL KNOB
CONTROL KNOB CONTROL KNOB INDICATORS
Using the Surface Burners
This range is equipped with electronic ignitors. Electronic ignitors
automatically light the burners each time they are used.
Control knobs must be pushed In,
then turned to LITEposition. The click-
lng sound isthe ignition sparking.
Tostop the clicking sound after the
burner lights, turn the control knob
back to a desired setting. The control
knob has stops for HI,and LO,
however it can be set anywhere be-
tween HI and LO. Do not cook with
the control In the LITE positlon.
In Case of a Prolonged Power Failure
Surface burners with electronic ignitors can be manually lighted. Hold a lit
match near the burner and turn the control to the LITEposition. After the burner
lights, turn the control to the desired setting.
6

See the “Cooklng Guide” for Important utensil lnformatfon.
Until you get used to the settlngs, us? the followlng as a gulde.
Use LITEto light
the burner. After
the burner lights,
turn control
back to a de-
sired setting to
stop the clicking
of the ignltion.
Do not cook
wlth the control
In the LITEposl-
tlon.
Use HI to start
foods cooking
or to bring liq-
uids to a boil.
Use a medlum
setting to start
cooking or to fry
chicken or pan-
cakes; for gravy,
puddings and
icing or to cook
large amounts
of vegetables.
use LO to
keep foods
warm until
ready to serve.
Setting the Clock
Push In and turn the Minute Timer Knob to set the Clock.
1. Push In Minute llmer Knob and
turn In elfher dlrectlon until clock
shows the right time of day.
2. Let the Minute Timer Knob pop
out. Turn in either direction until
Minute Timer hand points to OFF.
The clock sefflng will change If
you push In the knob when
tumlng.

Using the Minute Tiier
The Minute Timer does not start or stop the oven. Itworks like a kitchen timer.
Set it in minutes up to an hour. You will hear a buzzer when the set time is up.
DO NOT PUSH IN THE KNOB when setting the Minute Timer.
1. Wlfhout pushlng It In, turn the
Minute Timer Knob until the hand
passes the setting you want.
2. Without pushing In, turn the knob
back to the setting you want.
When the time Is up, a buzzer will
sound. Tostop the buzzer, turn the
Minute Timer hand to OFF.
PUSHING IN AND TURNING THE MINUTE TIMER KNOB CHANGES THE CLOCK
SETTING.
Using the Oven Temp Control
Baking
Racks should be placed so the top
of the food will be centered in the
oven. Always leave at IeastlM to 2
inches (4-5 cm) between the sides
of the pan and the oven walls and
other pans. For more information,
see the “Cooking Guide:’
I. Position the racks properly before
turning on the oven. To change
rack posltlon, pull rack out to
stop, raise front edge and lift out.

2. Setthe Oven Temp control knob to
the baking temperature you want.
The oven burner will automati-
cally light in 50-60 seconds.
4. During baking, the oven burner
will turn on and off to maintain the
temperature setting.
1. Preheat the oven for10 minutes
before adding food. NOTE: Oven
racks, walls and door will be hot.
Do not place food directly on
oven bottom.
5. When baking is done, turn the
Oven Temp control knob to OFF.
Broiling
The Broiler Drawer is located below the oven door. Always broil with the
drawer and oven door completely closed.
1. Pull the broiler drawer open and
tilt the door panel down. 2. Place broiler pan grid so grease
can drain down sides into lower
pari of broiler pan. See picture.

3. Place food on broiler pan and 4. Setthe Oven Temp control knob
position the broiler pan before
to BROIL.The broiler will automati-
turning on the broiler. See pan tally light in 50-60 seconds.
placement chart in the “Cooking
Guide” for recommended pan 5. When broiling is done, turn the
positions. Oven Temp control knob to OFF.
DO NOT PREHEAT THE BROILER BEFORE USING. COMPLETELY CLOSE
THE BROILER DRAWER DURING BROILING.
Using the Cooking Hours Control
The Cooking Time Dial is designed to time a set baking period, then
automatically lower the oven temperature to hold and keep food warm.
The oven will operate at this warm holding temperature until the Cooking
Time Dial isturned to OFF
1. Position the oven racks properly,
and place the food in the oven. 2. Turn the Cooking Time Knob to set
the dial to the amount of hours you
want the food to bake.
3. Setthe Oven Temp control knob to
the baking temperature you want.
The oven burner will automati-
cally light in 5040 seconds.
10
4. When the cooking time ends, the
oven cooking temperature auto-
matically IOWWSto a warm hold-
ing temperature. To shut off fhe
oven, turn the Cooking Time Dial
and the Oven Temp control knob
to OFF.
