Whirlpool G2IXEFMW - 2-20-09 User instructions

Top Mount R frig rator
®
PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS
G2IXEFMW
G9IXEFMW
El ctrical: A 115-Volt, 60-Hz, AC-only, 15- or
20-amp fused, grounded electrical supply is
required. It is recommended that a separate circuit
serving only your refrigerator e provided. Use an
outlet that cannot e turned off y a switch. Do not
use an extension cord.
Wat r: A cold water supply with water pressure of
etween 30 and 120 psi (207 and 827 kPa) is
required to operate the water dispenser and ice
maker. If you have questions a out your water
pressure, call a licensed, qualified plum er.
If a reverse osmosis water filtration system is
connected to your cold water supply, the water
pressure to the system needs to e a minimum of
40 to 60 psi (276 to 414 kPa).
IMPORTANT: The pressure of the water supply
coming out of a reverse osmosis system going to
the water inlet valve of the refrigerator needs to e
etween 30 and 120 psi (207 and 827 kPa).
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications su ject to change without notice.
Ref. W10208844
02-20-09
1/2" (1.25 cm)
2" (5.08 cm)
C
D
top of
cabin t
B
A
E
ov rall
Depth Cab. Width Door Width Cab. Height Overall Height
Model “A” “B” “C” “D” “E”
19 u.ft. 31-1/2" 29-1/2" 30-1/8" 65-1/2" 66-1/2"
(80 m) (74.9 m) (76.5 m) (166.4 m) (168.9 m)
22 u.ft. 31-1/2" 32-1/2" 33-1/8" 65-1/2" 66-1/2"
(80 m) (82.6 m) (84.1 m) (166.4 m) (168.9 m)
To ensure proper ventilation for your refrigerator, allow for a 1⁄2" (1.25 cm) space
on each side and at the top. When installing your refrigerator next to a fixed wall,
leave 2" (5.08 cm) minimum on the hinge side (some models require more) to allow
for the door to swing open. If your refrigerator has an ice maker, allow extra space
at the ack for the water line connections.
NOTE: Do not install the refrigerator near an oven, radiator, or other heat source, nor
in a location where the temperature will fall elow 55°F (13°C).
Dim nsions “D” and “E” includ roll rs
xt nd d 3/4" (1.9 cm)
LOCATION REQUIREMENTS
