Whirlpool G32026PELB12 User manual

CABINET PARTS
1
For Models: G32026PELB12
(Black)
2−09 Litho In U.S.A. (mat) (psw) Part No. W10247058 Rev.A
REFRIGERATOR

CABINET PARTS
2
For Models: G32026PELB12
(Black)
W10247058
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
12827959 Tech Sheet
12828189 Owners Manual
3 67003405 Block, Pivot
4 B5759649 Gasket
5
12626907ED Hinge, Top Right
6 A3076901 Plug, Button
9 67006521 Screw
11 67006380 Screw (6)
13 Cover, Left Hinge
W10175447 Black
14 67006303 Screw (6)
15
12655102ED Center Hinge
17 Cover, Corner
67003485 Black
18
12626908ED Hinge, Top Left
19 Bracket, Foot (2)
W10137532 Left
W10137533 Right
20 67006564 Screw
21 8208257 Shim, Hinge
22 Grille, Toe
W10131134 Black
23 67001067 Clip, Drain Tube
25 67006425 Screw (10)
27 12479808 Cover, Water Valve
28 67006669 Screw (2)
30 67002230 Cover, Unit
31 67001066 Tube, Drain
33 67003796 Insulation, Sound
34
W10141622 Foot Brake
35 Cover, Right Hinge
8170765 Black
36 Cabinet (Not a
Servicable Part)

FREEZER LINER PARTS
3
For Models: G32026PELB12
(Black)
W10247058

FREEZER LINER PARTS
4
For Models: G32026PELB12
(Black)
W10247058
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 A3189392 Gasket, Foam
3 12002497 Gear
(Includes LH & RH)
4 67003905 Cover, Light
5 67004017 Shaft
6
W10134763 Socket, Light
7 67005874 Guide, Fill Tube
8 67006473 Screw (8)
9 67002552 Bulb, Light
10 67001035 Housing, Light
11 12226114 Cover, Evaporator
12 67006425 Screw (4)
13 Bracket, Door
W10119064 Left
W10119295 Right
14 67003906 Module, Light
15 10623002 Clip, Evap Motor
16 67005653 Switch, Light
17 67006287 Screw (2)
18 Cradle, Basket
67004728 Left
67004729 Right
19
W10180420 Slide, Drawer (2)
20 67003731 Gasket, Bottom
21 Adapter, Slide
67004971 Left
67004972 Right
22
W10175909 Grille, Fz Air
23
W10167023 Shroud, Evap Fan
24 2169142 Blade, Fan
(Evaporator)
25
W10121318 Grommet
26 67005023 Motor, Evaporator
27 D7753903 Funnel, Drain
28 M0500703 Seal
29 B8381501 Gasket
30 12002355 Thermistor
31 67003924 Cover, Thermistor
32 67006406 Screw (6)
33 67006530 Screw
Following Parts Not Illustrated
13065802 Harness, Fz Module

REFRIGERATOR LINER PARTS
5
For Models: G32026PELB12
(Black)
W10247058

REFRIGERATOR LINER PARTS
6
For Models: G32026PELB12
(Black)
W10247058
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 67004078 Bracket, Control
and Lights
3 67005055 Keyboard
4 67003898 Housing, Control
5 12784416 Board, Control
6 C3680310 Switch, Light (2)
7 67003897 Cover, Light
8 67003901 Housing, Light
9 67002552 Bulb, Light (2)
10
W10134763 Socket, Light (2)
11 67003900 Insert,
Damper Cover
12 67006602 Screw (2)
13 67003899 Cover, Damper
14 67006604 Insulation
15
W10127430 Control, Damper
(Incl. Harness)
16 12002355 Thermistor
Following Parts Not Illustrated
12973603 Harness, Control
(Refrigerator)

REFRIGERATOR DOOR PARTS
7
For Models: G32026PELB12
(Black)
W10247058

REFRIGERATOR DOOR PARTS
8
For Models: G32026PELB12
(Black)
W10247058
Illus. Part
No. No. DESCRIPTION
1 Door, Left
12732428BQ Black
2 Door, Right
12732422BQ Black
3 67003637 Door, Dairy
4 67001279 Tray, Dairy
5 67003766 Bin, Shelf (3)
(Medium)
6 Mullion, Door
12722811B Black
7 67006786 Screw
8 Gasket, Door (2)
12723206B Black
9 Handle, Door
W10119668 Left Door
W10119665 Right Door
10 67006287 Screw
11 Stop, Door
67003780 Black
12 61002504 Nameplate
13 12992902 Mount, Handle
15 Closure, Door
67003639 Black
16 67005054 Bin, Shelf (2)
(Gallon)

UNIT PARTS
9
For Models: G32026PELB12
(Black)
W10247058

UNIT PARTS
10
For Models: G32026PELB12
(Black)
W10247058
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 67006433 Screw
2
W10162928 Blade, Fan
3 67005889 Basepan
4 67006425 Screw (2)
5 67004954 Screw (3)
6 12049773 Compressor
(Includes items
11,12,17,27, &
30)
7
W10169651 Harness, Evap
Heater
8 67007176 Pan, Drain
9 61004743 Grommet (3)
10 12729120 Heater, Defrost
11 67007162 Capacitor
12 Overload/Relay
67006453 (Production)
2303344 (Service)
13 61003210 Gasket
14
12639322SP Thermostat, Def.
15 67005680 Grommet (2)
16 67006661 Shroud
17 67007052 Clip, Capacitor
18 67006131 Condenser
19 12866903 Tube, Discharge
20 67002490 Tray, Drip
21 10623002 Clip, Evaporator
22 12002041 Evaporator Kit
(Inc. Evap., Heat
Shield, & Instr.
Sheet)
23 Dam
67001084 Right Side
67001083 Left Side
24
W10211284 Motor, Fan
25 10428101 Clip, Heater
26
W10169658 Harness, MC
27
W10143759 Drier
28 10547003 Clip, Drier
29 67004953 Bracket, Fan Motor
30 67003493 Grommet (4)
31 67006432 Screw (3)
32 67006573 Screw (4)
40 67006118 Roller (2)
41 M1205302 Axle (2)
42
W10137529 Grommet (4)
43 67002235 Block, Condenser
44 67006737 Screw
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.25 Ozs.
(R−134A)

SHELF PARTS
11
For Models: G32026PELB12
(Black)
W10247058

SHELF PARTS
12
For Models: G32026PELB12
(Black)
W10247058
Illus. Part
No. No. DESCRIPTION
1 67002332 Glass, Pantry
2 67004801 Shelf, Glide Out
3 67006608 Screw
4 67006010 Extr, Glass
Support (2)
5
12227305WD Brace, Pantry (2)
6 67001719 Track, Pantry
8 67004127 Divider,
Upper Basket
9 67002329 Gasket, Pantry
10 67005625 Housing, Control
12 67003793 Slide, Temperature
14 67007026 Glide, Drawer(2)
16 Endcap, Pantry
67005862 Left
67005857 Right
17 67002659 Pan, Crisper (2)
18
12227304WD Brace, Crisper
19 67004852 Trim, Crisper
20 67003132 Frame, Crisper
21 67006655 Glass, Crisper
Cover
22 67001073 Ladder, Center
23 67002489 Ladder, Side
24 67006400 Screw (6)
25 67006360 Screw (2)
26 67006415 Screw (4)
27 67005864 Slide, Humidity
Control
28 67003794 Rod, Temperature
Control
29 67003530 Drawer, Pantry
30 67003791 Knob, Temperature
Control
31 67005910 Door,
Pantry Drawer
32 67006026 Basket, Freezer
(Lower)
33 67004812 Divider,
Lower Basket
34 67004988 Basket, Freezer
(Upper)
35 67002321 Divider,
Pantry Drawer
36 67006287 Screw (4)
39 12646501 Rack, Ice Tray
40 10972101 Spacer, Ice Rack
41 67006908 Screw, Ice Rack
42 67001747 Ice Cube Tray

FREEZER DOOR PARTS
13
For Models: G32026PELB12
(Black)
W10247058
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
13092221BQ Black
2 Handle
W10119668 Black
3 Gasket, Door
W10131754 Black
5 12992902 Mount, Handle

OPTIONAL PARTS (NOT INCLUDED)
14
For Models: G32026PELB12
(Black)
W10247058
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
Customer Touch−Up Material
350942 Primer, White
(13 Oz. Spray Can)
350939 Enamel, Black
(13 Oz. Spray Can)
350930 Enamel, White
(13 Oz. Spray Can)
72017 Brush Touch−Up Kit
(White)
72032 Brush Touch−up kit
(Black)
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
Refinishing Material
799340 Enamel, Black
(1 Qt. Uncut)
799344 Enamel, White
(1 Qt. Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
876370 Kit, Insulation
(2 Pcs. x 3" x 24"
X 48")
876305 Kit, Insulation
(14 Pcs. x 3"
x 24" x 48")
978941 Insulation,
Fiberglass
(63−1/2" x 35−1/2"
X 2−5/8)
876029 Kit, Foam Slab
(30" x 32−1/2"
x 1−1/2")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
20000008 Cleaner,
Stnls Steel Magic
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
606755 Bag, Insulation
(36−5/8" x 46")
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
833938 Kit, Terminal
Connector
TORX SCREW WRENCH
1117510 Torx Key
FIELD INSTALLABLE
ICE MAKER
67001740 Complete Icemaker
