ON PREMISE NON METERED COMMERCIAL WASHER
WHIRLPOOL BRAND
COMMERCIAL WASHERS
DIRECT DRIVE SYSTEM
27" heavy-duty
commercial washers
feature the
Direct-Drive, No-Belt
washing system for
greater reliability, reduced down
time and increased profits.
LARGE CAPACITY WASH BASKET
Ideal for handling family size loads!
POWDERED PAINT FINISH
Powdered paint top, lid and cabinet
finish to resist chipping and
scratching.
HIGH AND LOW
WATER LEVEL
Reduce water
consumption to 25.22
gallons per cycle!*
*Based on low water level, 3 lb. load
TRIPOD SUSPENSION
Sturdy tripod-suspension
with active liquid filled
balance ring reduces
product weight while balancing
commercial size laundry loads.
SEALED HIDDEN
LID SWITCH
To help ensure safe
operation, Whirlpool®
commercial washers feature a lid
switch that is truly hidden. Not
only does this prevent tampering,
it ensures that the washer will not
operate when the lid is open.
GCAM2792TQ —27" 2-Speed
On Premise Non Metered Washer
EXCLUSIVE 90 DAY FACTORY
LABOR WARRANTY!!
• 3.2Cu.Ft.WashBasket,18Lbs.UL
• PushButtonControls
• HighEfficiency,LowWaterFactor
• 8Cycles:Regular/Super,Regular/Heavy,Regular/
Normal, Regular/Light, Permanent Press/Normal,
Permanent Press/Light, Gentle, Extra Rinse
• TwoWaterLevels
• BleachandFabricSoftenerDispensers
• Two-SpeedAdvantagewithTrueGentleWash,
High Speed Only!
• DeepRinseSystem
• PowderedPaintTopandLid,StainlessSteel
Hinges and Plated Console Screws
• HighSpeedSpin640RPM(Approx.)
• Galvanized,HeavyGaugeCabinetBack,
Side and Front Panels, Removable Front Service
Panel
• HeavyDuty Motor Coupler Isolator Tested
to 20,000 Cycles!*
• 1⁄2-HPMotorwithBuilt-InOverloadProtector:
120-Volt, 60 Hz., A.C. Agitation Speed 180 SPM/
High 120 SPM/Low
• Reliable,Direct-DriveNO-BELTSDriveSystem,Front
and Bottom Serviceable
• ExtraLongPowerCord,WaterInletHoseswithBrass
Couplings and Corrugated Drain Hose Included!
• 25.22GallonsMinimumWaterUsageperCycle
(LowWaterLevel,3Lbs.Load)
• 2YearLimitedPartsOnlyWarranty**
* Testing completed 11/12/2001
** Call 1-800-NO-BELTS for warranty details
Featuring Mechanical Controls
4
To locate a distributor near you, please visit
www.whirlpoolcommerciallaundry.com/distributor, or call 1–800–NO–BELTS.

To locate a distributor near you, please visit www.whirlpoolcommerciallaundry.com/distributor, or call 1–800–NO–BELTS.
5
Dimensions are for planning purposes only.
For complete information, see installation
instructions packed with product.
WASHER FRONT VIEW
WASHER BACK VIEW
WASHER SPECIFICATIONS
MODEL NUMBER GCAM2792TQ
GENERAL INFORMATION
Stainless steel look push button console,
powdered paint finish cabinet, top and lid
galvanized, extra thick back panel, reliable
dual agitator inlet hoses and corrugated
drain hoes included.
8Cycles:Regular/Super,Regular/
Heavy, Regular/Normal, Regular/
Light, Permanent Press/Normal,
Permanent Press/Light, Gentle,
Extra Rinse
MOTOR
120-Volt 1⁄2-HP Direct-Drive with Built-In
Overload Protector
Two-Speed
AGITATION STROKES PER
MINUTE/AMPERAGE
Maximum Rated Amperage
180 SPM/High
(5.0AmpsNoLoad)
9.8Amps(120-Volt)
MOTOR RPM 1725 High
SPIN RPM 640 High
ELECTRICAL REQUIREMENTS 120V, 60 Hz., A.C.
Standard 15 Amp Breaker/Fuse
Branch Circuit
forEachWasher(SubjecttoLocal
Codes)
DIMENSIONS
See Illustrations
43"H(atMetercaseTop),35"H
(atLid),27"W,25.5"D
SHIPPING WEIGHT (EST.) 124 Lbs.
BASKET VOLUME 3.2 Cu. Ft.
COMMERCIAL WASHER SPECIFICATIONS
Energy information is available online at www.whirlpoolcommerciallaundry.com/products,
WP literature part #CWXL077B
WASHER WARRANTY
2-YearLimited(partsonly)
WARRANTIES
EXCLUSIVE 90 DAY FACTORY LABOR WARRANTY!!
For important information regarding warranty inclusions, exclusions
and limitations, please call 1-800-NO-BELTS
