Whirlpool GHW9300P User manual

FRONT-LOADING
AUTOMATIC WASHER
Use & Care Guide
For questions about features, operation/performance,
parts, accessories or service call: 1-800-253-1301
In Canada, call: 1-800-807-6777
or visit our website at
www.whirlpool.com or www.whirlpool.ca
LAVADORA AUTOMÁTICA
DE CARGA FRONTAL
Manual de Uso y Cuidado
Si tiene preguntas respecto a las características, funcionamiento,
rendimiento, partes, accesorios o servicio técnico, llame al:
1-800-253-1301
o visite nuestro sitio web en
www.whirlpool.com o www.whirlpool.ca
LAVEUSE
AUTOMATIQUE À
CHARGEMENT FRONTAL
Guide d’utilisation et d’entretien
Au Canada, pour assistance, installation ou service, composez le :
1-800-807-6777
ou visitez notre site internet à
www.whirlpool.ca
Table of Contents/Índice/Table des matières ....... 2
461970229021
✔8182749
®
Designed to use only HE
High Efficiency Detergent
Diseñado para utilizar
solamente detergente de
alto rendimiento (HE)
Conçu pour l’utilisation
d’un détergent haute
seulement efficacité

2
TABLE OF CONTENTS
WASHER SAFETY ..........................................................................3
INSTALLATION REQUIREMENTS................................................4
Tools and Parts ............................................................................4
Options.........................................................................................4
Location Requirements................................................................5
Drain System................................................................................6
Electrical Requirements ...............................................................7
INSTALLATION INSTRUCTIONS..................................................7
Remove Transport System ..........................................................7
Connect the Inlet Hoses...............................................................8
Route the Drain Hose...................................................................8
Secure the Drain Hose .................................................................9
Level the Washer..........................................................................9
Complete Installation ...................................................................9
FEATURES AND BENEFITS ........................................................10
WASHER USE...............................................................................11
Starting Your Washer.................................................................11
Using the Proper Detergent .......................................................11
Using the Dispenser...................................................................12
Pausing or Restarting.................................................................13
Changing Cycles, Options and Modifiers..................................13
Status Lights ..............................................................................13
Cycles.........................................................................................14
Options.......................................................................................15
Modifiers.....................................................................................15
Laundry Guide............................................................................16
LAUNDRY TIPS ............................................................................16
Loading.......................................................................................17
WASHER CARE ............................................................................17
Cleaning Your Washer ...............................................................17
Water Inlet Hoses.......................................................................18
Vacation, Storage, and Moving Care.........................................18
TROUBLESHOOTING ..................................................................19
ASSISTANCE OR SERVICE.........................................................22
In the U.S.A. ...............................................................................22
In Canada ...................................................................................22
WARRANTY ..................................................................................23
ÍNDICE
SEGURIDAD DE LA LAVADORA.................................................25
REQUISITOS DE INSTALACIÓN.................................................26
Herramientas y piezas................................................................26
Opciones ....................................................................................26
Requisitos de ubicación.............................................................27
Sistema de desagüe ..................................................................28
Requisitos eléctricos..................................................................29
INSTRUCCIONES DE INSTALACIÓN.........................................29
Eliminación del sistema de transporte.......................................29
Conexión de las mangueras de entrada....................................30
Tendido de la manguera de desagüe ........................................30
Fijación de la manguera de desagüe.........................................31
Nivelación de la lavadora...........................................................31
Complete la instalación..............................................................31
CARACTERÍSTICAS Y BENEFICIOS..........................................32
USO DE LA LAVADORA...............................................................33
Puesta en marcha de la lavadora ..............................................33
Uso de detergente adecuado ....................................................33
Uso del depósito........................................................................34
Pausa o reanudación de la marcha ...........................................35
Cambio de ciclos, opciones y modificadores ...........................35
Luces de estado.........................................................................36
Ciclos..........................................................................................36
Opciones ....................................................................................38
Modificadores.............................................................................38
Guía para el lavado.....................................................................39
CONSEJOS DE LAVANDERÍA.....................................................39
Cómo cargar...............................................................................40
CUIDADO DE LA LAVADORA .....................................................40
Cómo limpiar su lavadora ..........................................................40
Mangueras de entrada de agua.................................................41
Cuidado para las vacaciones,
el almacenaje o en caso de mudanza .......................................42
SOLUCIÓN DE PROBLEMAS......................................................43
AYUDA O SERVICIO TÉCNICO...................................................46
En los EE.UU. .............................................................................46
En Canadá..................................................................................46
GARANTÍA.....................................................................................47
TABLE DES MATIÈRES
SÉCURITÉ DE LA LAVEUSE........................................................49
EXIGENCES D’INSTALLATION...................................................50
Outillage et pièces......................................................................50
Options .......................................................................................50
Exigences d’emplacement.........................................................51
Système de vidange...................................................................52
Spécifications électriques ..........................................................53
INSTRUCTIONS D’INSTALLATION.............................................53
Enlèvement du système de transport........................................53
Raccordement des tuyaux d'alimentation.................................54
Acheminement du tuyau de vidange .........................................54
Immobilisation du tuyau de vidange ..........................................55
Réglage de l’aplomb de la laveuse ............................................55
Achever l’installation ..................................................................55
CARACTÉRISTIQUES ET AVANTAGES .....................................56
UTILISATION DE LA LAVEUSE...................................................57
Mise en marche de la laveuse....................................................57
Utilisation du détergent approprié .............................................57
Utilisation du distributeur ...........................................................58
Pause ou remise en marche.......................................................59
Changement de programmes, options et modificateurs...........59
Témoins de l’état d’avancement................................................60
Programmes...............................................................................60
Options .......................................................................................62
Modificateurs..............................................................................62
Guide de lessivage.....................................................................63
CONSEILS DE LESSIVAGE..........................................................63
Chargement................................................................................64
ENTRETIEN DE LA LAVEUSE .....................................................64
Nettoyage de la laveuse.............................................................64
Tuyaux d’alimentation de la laveuse..........................................65
Préparation avant des vacances,
un entreposage ou un déménagement......................................66
DÉPANNAGE.................................................................................67
ASSISTANCE OU SERVICE.........................................................70
Aux États-Unis............................................................................70
Au Canada..................................................................................70
GARANTIE.....................................................................................71
®

3
WASHER SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER”or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
■ Read all instructions before using the washer.
■ Do not wash articles that have been previously cleaned
in, washed in, soaked in, or spotted with gasoline,
dry-cleaning solvents, other flammable, or explosive
substances as they give off vapors that could ignite or
explode.
■ Do not add gasoline, dry-cleaning solvents, or other
flammable, or explosive substances to the wash water.
These substances give off vapors that could ignite or
explode.
■Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been used
for 2 weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has not been
used for such a period, before using the washing
machine, turn on all hot water faucets and let the water
flow from each for several minutes. This will release
any accumulated hydrogen gas. As the gas is
flammable, do not smoke or use an open flame during
this time.
■ Do not allow children to play on or in the washer. Close
supervision of children is necessary when the washer is used
near children.
■Before the washer is removed from service or discarded,
remove the door or lid.
■Do not reach into the washer if the drum, tub or agitator is
moving.
■Do not install or store the washer where it will be exposed to
the weather.
■Do not tamper with controls.
■Do not repair or replace any part of the washer or attempt any
servicing unless specifically recommended in this manual or in
published user-repair instructions that you understand and
have the skills to carry out.
■See “Electrical Requirements”for grounding instructions.
WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic precautions,
including the following:

4
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation.
The parts supplied are in the washer drum.
Tools needed for connecting the water inlet hoses
■Pliers (that open to 1⁹⁄₁₆" [39.5 mm])
■Flashlight (optional)
Tools needed for installation
■Open end wrench 17 mm and 13 mm
■Level
■Wood block
■Ruler or measuring tape
Parts supplied:
Alternate Parts
Your installation may require additional parts. If you are interested
in purchasing one of the items listed here, call the toll-free
number on the cover or in the “Assistance or Service” section.
Options
Pedestal
You may order a pedestal separately for this washer. This
pedestal will add about 13" (33 cm) to the height of your unit for a
total height of approximately 51" (130 cm).
Optional pedestal
To order, call the dealer from whom you purchased your washer
or refer to the “Assistance or Service” section of this manual.
13" (33 cm) Pedestals
Stack Kit
Are you planning to stack your washer and dryer? To do so you
will need to purchase a Stack Kit.
To order, call the dealer from whom you purchased your dryer or
refer to the “Assistance or Service” section of this manual. Ask
for Part Number 8541503.
A. Drain hose form
B. Inlet hose (2)
C. Inlet hose washer (4)
D. Transport bolt hole plug (4)
E. Beaded strap
If You Have You Will Need to Buy
Laundry tub or
standpipe taller
than 96" (2.4 m)
Sump pump system (if not already
available)
Overhead sewer Standard 20 gal. (76 L), 30" (76.2 cm)
tall drain tub or utility sink and sump
pump (available from local plumbing
suppliers)
Floor drain Siphon break, Part Number 285834;
additional drain hose
Part Number 8318155; and connector
kit, Part Number 285835
Drain hose too
short 4 ft (1.2 m) drain hose extension kit, Part Number 285863
Water faucets
beyond reach of
fill hoses
2 longer water fill hoses:
6 ft (1.8 m) Part Number 76314,
10 ft (3.0 m) Part Number 350008
AB
C
DE
Color Part Number
White LAB2700MQ
Biscuit LAB2700MT
Pewter LAB2700ML

5
Location Requirements
Selecting the proper location for your washer improves
performance and minimizes noise and possible washer “walk.”
Your washer can be installed under a custom counter, or in a
basement, laundry room, closet, or recessed area. See “Drain
System.”
Companion appliance location requirements should also be
considered. Proper installation is your responsibility.
You will need
■A water heater set to deliver 120°F (49°C) water to the
washer.
■A grounded electrical outlet located within 6 ft (1.8 m) of
where the power cord is attached to the back of the washer.
See “Electrical Requirements.”
■Hot and cold water faucets located within 4 ft (1.2 m) of the
hot and cold water fill valves, and water pressure of
20-100 psi (137.9-689.6 kPa).
■A level floor with a maximum slope of 1" (2.5 cm) under
entire washer. Installing the washer on soft floor surfaces,
such as carpets or surfaces with foam backing, is not
recommended.
■A sturdy and solid floor to support the washer with a total
weight (water and load) of 400 lbs (180 kg).
Do not operate your washer in temperatures below 32°F (0°C).
Some water can remain in the washer and can cause damage in
low temperatures.
Installation clearances
■The location must be large enough to allow the washer door
to be fully opened.
■Additional spacing should be considered for ease of
installation and servicing.
■Additional clearances might be required for wall, door, and
floor moldings.
■Additional spacing of 1" (2.5 cm) on all sides of the washer is
recommended to reduce noise transfer.
■Companion appliance spacing should also be considered.
Washer Dimensions
Recommended installation spacing for custom
undercounter installation
The dimensions shown are for the recommended spacing.
Custom undercounter installation - Washer only
Recommended installation spacing for recessed or
closet installation, with or without a pedestal
The dimensions shown are for the recommended spacing.
Recessed area or closet installation
*Min. top and bottom air openings for closet door.
Recessed or closet installation - Washer on pedestal
27"
(68.6 cm)
50¹⁄₂"
(128.3 cm)
38"
(96.5 cm)
31¹⁄₂"
(80.0 cm)
A. Side view - closet or confined area
B. Closet door with vents
A. Recessed area
B. Side view - closet or confined area
1"
(2.5 cm )
1"
(2.5 cm)
39" min.
(99.0 cm)
27"
(68.6 cm)
34"
(86.4 cm)
AB
3"
(7.6 cm)
3"
(7.6 cm)
48 in.
2
*
(310 cm
2
)
24 in.
2
*
(155 cm
2
)
1"
(2.5 cm) 4"
(10.2 cm)
31¹⁄₂"
(80 cm)
1"
(2.5 cm) 31¹⁄₂"
(80 cm)
1"
(2.5 cm) 1"
(2.5 cm)
27"
(68.6 cm) 4" (10.2 cm)
18" min.
(45.7 cm)
AB

6
Recommended installation spacing for recessed or
closet installation, with stacked washer and dryer
The dimensions shown are for the recommended spacing.
*Min. top and bottom air openings for closet door.
**External exhaust elbow requires additional space.
***Wall, door and floor molding may require additional spacing.
Recommended installation spacing for cabinet
installation
■The dimensions shown are for the recommended spacing.
■For cabinet installation, with a door, the minimum ventilation
openings in the top are required.
Drain System
The washer can be installed using the standpipe drain system
(floor or wall), the laundry tub drain system, or the floor drain
system. Select the drain hose installation method you need. See
“Tools and Parts.”
Standpipe drain system - wall or floor (views A & B)
The standpipe drain requires a minimum diameter standpipe of
2" (5 cm). The minimum carry-away capacity can be no less than
17 gal. (64 L) per minute.
The top of the standpipe must be at least 30" (76.2 cm) high and
no higher than 96" (2.4 m) from the bottom of the washer.
Laundry tub drain system (view A)
The laundry tub needs a minimum 20 gal. (76 L) capacity. The top
of the laundry tub must be at least 30" (76.2 cm) above the floor.
Floor drain system (view B)
The floor drain system requires a siphon break that may be
purchased separately. See “Tools and Parts.”
The siphon break must be a minimum of 28" (71 cm) from the
bottom of the washer. Additional hoses might be needed.
48 in.
2
*
(310 cm
2
)
3" (7.6 cm)
6" (15.2 cm)
76"
(193 cm)
27"
(68.6 cm)
3" (7.6 cm)
1" (2.5 cm)
5½"**
(14 cm) 1"***
(2.5 cm) 1"***
(2.5 cm)
24 in.
2
*
(155 cm
2
)
7" (17.8 cm)
9"
(22.9 cm)
7" (17.8 cm)
4"
(10.2 cm) 31½" (80.0 cm) 27" (68.6 cm)
1"
(2.5 cm) 1" (2.5 cm) 1" (2.5 cm)
30" min.
(76.2 cm)
AB
AB
30" min.
(76.2 cm)
28" min.
(71 cm)

7
Electrical Requirements
■A 120 volt, 60 Hz., AC only, 15- or 20-amp, fused electrical
supply is required. A time-delay fuse or circuit breaker is
recommended. It is recommended that a separate circuit
serving only this appliance be provided.
■This washer is equipped with a power supply cord having a
3 prong ground plug.
■To minimize possible shock hazard, the cord must be
plugged into a mating, 3 prong, ground-type outlet, grounded
in accordance with local codes and ordinances. If a mating
outlet is not available, it is the personal responsibility and
obligation of the customer to have the properly grounded
outlet installed by a qualified electrician.
■If codes permit and a separate ground wire is used, it is
recommended that a qualified electrician determine that the
ground path is adequate.
■Do not ground to a gas pipe.
■Check with a qualified electrician if you are not sure the
washer is properly grounded.
■Do not have a fuse in the neutral or ground circuit.
INSTALLATION INSTRUCTIONS
Remove Transport System
IMPORTANT: Position the washer so that the rear of the unit is
within approximately 3 ft (90 cm) of its final location.
There are 4 bolts in the rear panel of the washer that support the
suspension system during transportation. These bolts also retain
the power cord inside the washer until the bolts are removed. 1. Using a 13 mm wrench, loosen each of the bolts.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
GROUNDING INSTRUCTIONS
For a grounded, cord-connected washer:
This washer must be grounded. In the event of a malfunction
or breakdown, grounding will reduce the risk of electrical
shock by providing a path of least resistance for electric
current. This washer is equipped with a cord having an
equipment-grounding conductor and a grounding plug. The
plug must be plugged into an appropriate outlet that is
properly installed and grounded in accordance with all local
codes and ordinances.
WARNING: Improper connection of the equipment-
grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or serviceman if you are in
doubt as to whether the appliance is properly grounded.
Do not modify the plug provided with the appliance –if it will
not fit the outlet, have a proper outlet installed by a qualified
electrician.
For a permanently connected washer:
This washer must be connected to a grounded metal,
permanent wiring system, or an equipment grounding
conductor must be run with the circuit conductors and
connected to the equipment-grounding terminal or lead on
the appliance.
WARNING
Excessive Weight Hazard
Use two or more people to move and install washer.
Failure to do so can result in back or other injury.

8
2. Once the bolt is loose, move it to the center of the hole and
completely pull out the bolt, including the plastic spacer
covering the bolt.
3. Once all 4 bolts are removed discard bolt and spacers. Then
pull the power cord through the opening of the rear panel and
close the hole with the attached cap.
4. Close the bolt holes with the 4 transport bolt hole plugs.
NOTE: If the washer is to be transported at a later date, call your
local service center. To avoid suspension and structural damage
to your washer, it must be properly set up for relocation by a
certified technician.
Connect the Inlet Hoses
Make sure the washer drum is empty.
1. Attach the hose with the red color indicator to the Hot (left)
inlet valve. Attaching the red coupling first makes it easier to
tighten connection with pliers. Screw on coupling by hand
until it is seated on the washer.
2. Attach the hose with the blue color indicator to the Cold
(right) water inlet valve. Screw on coupling by hand until it is
seated on the washer.
3. Using pliers, check the tightness of the hose couplings
already attached to the washer.
NOTE: Do not overtighten. Damage to the coupling can
result.
4. Attach the hose with the red color indicator to the hot water
faucet. Screw on coupling by hand until it is seated on the
washer.
5. Attach the hose with the blue color indicator to the cold water
faucet. Screw on coupling by hand until it is seated on the
washer.
6. Using pliers, tighten the couplings with an additional
two-thirds turn.
NOTE: Do not overtighten. Damage to the coupling can result.
7. Turn on the water faucets and check for leaks.
NOTE: Replace inlet hoses after 5 years of use to reduce the
risk of hose failure. Record hose installation or replacement
dates on the hoses for future reference.
Periodically inspect and replace hoses if bulges, kinks, cuts,
wear, or leaks are found.
Route the Drain Hose
Proper routing of the drain hose protects your floors from damage
due to water leakage. Read and follow these instructions.
Remove drain hose from washer cabinet
Gently pull the corrugated drain hose from the shipping clips.
Laundry tub drain or standpipe drain
Connect the drain hose form to the corrugated drain hose.
To keep drain water from going back into the washer:
■Do not straighten the drain hose, and do not force excess
drain hose into standpipe. Hose should be secure, but loose
enough to provide a gap for air.
■Do not lay excess hose on the bottom of the laundry tub.
Floor drain
You may need additional parts. See Floor drain under “Tools and
Parts.”
H. Hot water inlet
C. Cold water inlet
HC
A. Snap either end of the drain hose form to the drain hose at
the point where the corrugation begins.
B. Bend drain hose over drain hose form and snap into place.
AB

9
Secure the Drain Hose
1. Drape the power cord over the washer top.
2. Secure the drain hose to the laundry tub leg or standpipe with
the beaded strap provided. (See illustrations A and B.)
If the washer faucets and the drain standpipe are recessed
(see illustration C), put the hooked end of the drain hose in
the standpipe. Tightly wrap the beaded strap around the
water inlet hoses and the drain hose.
Do not force excess drain hose into the standpipe.
Level the Washer
Properly leveling your washer avoids excessive noise and
vibration.
1. Check the levelness of the washer by placing a level on the
top edge of the washer, first side to side, then front to back.
If the washer is against a wall, move the washer out slightly
before tipping back. If the washer is not level, first prop the
front with a wood block and adjust the feet as necessary;
then prop the back and adjust feet as necessary. Repeat this
step until washer is level.
2. Make sure all four feet are stable and resting on the floor.
Then check that the appliance is perfectly level (use a level).
3. After the washer is level, use a 17 mm open-end wrench to
turn the nuts on the feet tightly against the washer cabinet.
IMPORTANT: All 4 feet must be tightened. If the nuts are not
tight against the washer cabinet, the washer may vibrate.
4. The washer should not move front to back, side to side, or
diagonally when pushed on its top edges.
5. Slide the washer to its final location.
6. Confirm the levelness of the washer.
Complete Installation
1. Check the electrical requirements. Be sure that you have the
correct electrical supply and the recommended grounding
method. See “Electrical Requirements.”
2. Check that all parts are now installed. If there is an extra part,
go back through the steps to see which step was skipped.
3. Check that you have all of your tools.
4. Dispose of/recycle all packaging materials.
5. Check that the water faucets are on.
6. Check for leaks around faucets and inlet hoses.
7. Plug into a grounded 3 prong outlet.
8. Read “Washer Use.”
9. To test and to clean your washer, measure ¹⁄₂ the detergent
manufacturer's recommended amount of HE High Efficiency
detergent for a medium size loads. Pour the detergent into
the detergent dispenser. Select NORMAL/CASUAL, and then
select HOLD TO START. Allow the washer to complete one
whole cycle.
AB C
Use only HE High Efficiency detergent.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

10
FEATURES AND BENEFITS
Electronic Controls
Flexible electronic controls are easy to use whether you are a
beginner or an expert.
Smart Dispensers
The smart dispensers make your washer truly automatic. This
washer provides a three-compartment dispenser which includes
separate compartments for detergent, fabric softener, and
bleach. The dispenser has large pour zones, is self-cleaning, and
can be easily removed. Laundry products are diluted with fresh
water and added to the load at the proper time in the wash cycle.
Auto Water Level
This washer automatically adjusts water level for best cleaning
and rinsing performance. Two sensors determine load size, load
composition, and suds level, then the sensors adjust the water
level to the proper setting. This eliminates guesswork. The water
level is just right for every wash load size.
Larger Load Size
Since there is no agitator, you can wash larger, bulkier items such
as a king-sized bedspread. You are also able to wash more
clothes at one time, which means fewer loads.
Suspension System
To reduce washer “walk”and “off-balance”conditions, your new
washer combines:
■2 Springs to isolate vibration
■4 Shock absorbers at the washer base to minimize movement
Stainless Steel Drum
The stainless steel drum eliminates corrosion and enables higher
spin speeds for more water extraction, reducing drying time.
High-Efficiency Wash System
Your new front-loading, high-efficiency washer saves time with
fewer, larger loads, and lowers your water and energy bills by
helping conserve resources.
Spin Speeds
This washer automatically selects the spin speed based on the
cycle selected. This factory setting can be changed, however.
This washer offers up to four different spin speed choices.
ACCUWASH™Automatic Temperature Control
The ACCUWASH™control electronically senses and maintains a
uniform water temperature. ACCUWASH control regulates
incoming hot and cold water. ACCUWASH control is
automatically turned On when a cycle is selected.
Add A Garment
When this option is available at the beginning of the cycle, the
Add A Garment Status Light will glow for the first 8 minutes. This
washer allows an 8-minute period in which forgotten garments
may be added to a load.
CATALYST®Cleaning Action with Direct Injection
This washer channels 100% of the water through the dispensers
to assure thorough rinse-out and mixture of all the additives
before they touch any garments. The water is then sprayed from
the top front onto the center of the load, providing even
distribution and optimum cleaning performance. It is normal for
small amounts of water to remain in the dispensers when the
wash cycle is complete.
Efficient Detergent System
This washer has a specially designed valve that closes during the
wash portion of the cycle so that 100% of the water and
detergent mixture is used on the load. The Efficient Detergent
System ensures that no water or detergent is wasted.
Dynamic Off-Balance Detection
This washer uses two sensors to detect load size and the amount
of off-balance within the load. The suspension system and
controls are specially designed to redistribute the load
automatically.

11
WASHER USE
NOTE: The panel shown above may be different from that of your model.
Starting Your Washer
WARNING: To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.
The following is a guide to using your washer. Please refer to
specific sections of this manual for more detailed information.
Do not store laundry products on the top surface of this washer.
Vibration is normal during operation.
Using the Proper Detergent
Use only High Efficiency detergents. The package for this type of
detergent will be marked “HE”or “High Efficiency.”This wash
system, along with less water, will create too much sudsing with a
regular non-HE detergent. Using regular detergent will likely result in
washer errors, longer cycle times and reduced rinsing performance.
It may also result in component failures and noticeable mold or
mildew. HE detergents are made to produce the right amount of
suds for the best performance. Follow the manufacturer's
instructions to determine the amount of detergent to use.
First Wash Cycle Without Laundry
Before washing clothes for the first time, select the NORMAL/
CASUAL cycle and run the washer without clothes. Measure ¹⁄₂
the manufacturer’s recommended amount of HE High Efficiency
detergent for a medium size loads. This initial cycle serves to
ensure the interior is clean before washing clothes.
1. To load washer
Open the washer door by pulling on the handle. Sort laundry
according to color and type of fabric. Place a load of sorted
clothes in the washer. Do not overload washer. Overloading
can cause poor cleaning.
■The washer can be fully loaded, but not tightly packed.
Washer door should close easily.
■Mix large and small items and avoid washing single items.
Load evenly.
■Wash small items such as infant socks in mesh garment
bags. It is recommended that more than one garment bag
be used and that each garment bag be filled with equal
amounts of material.
■When unloading garments, occasionally check under the
rubber rim at the front of the tub for small items.
2. Close the washer door by pushing it firmly until the lock
clicks. The washer door will remain locked during the wash
cycle.
NOTE: After any wash cycle is completed, the door must be
opened and then closed before a new cycle can begin. The
door can be opened only if PAUSE/CANCEL is selected while
the ADD A GARMENT light is glowing or if the cycle has been
canceled. See “To cancel a cycle" in "Changing Cycles,
Options and Modifiers" section.
3. Open the dispenser drawer and add laundry products to the
detergent, bleach, or fabric softener compartments. Close
drawer slowly to avoid spills. See “Using the Dispenser.”
4. Turn on the washer by selecting CONTROL ON. Select one of
the cycles by turning the cycle selector. The indicator light for
the selected cycle will glow. When selecting a wash cycle, the
preset cycle, Water Temp, Spin Speed, and soil level for the
selected cycle will glow. The display shows the estimated
time remaining. The preset settings provide the
recommended fabric care for the selected cycle. See
“Cycles.”
Use only HE High Efficiency Detergent.
Fire Hazard
Never place items in the washer that are dampened
with gasoline or other flammable fluids.
No washer can completely remove oil.
Do not dry anything that has ever had any type of oil on
it (including cooking oils).
Doing so can result in death, explosion, or fire.
WARNING

12
5. Select the desired OPTIONS. Not all options are available
with all cycles. See “Options.”
6. Select the desired MODIFIERS. Not all modifiers are available
with all cycles and options. See “Modifiers.”
7. If desired, select the END OF CYCLE SIGNAL. The signal is
helpful when you are washing items that should be removed
from the washer as soon as it stops. Select LOUDER or
SOFTER.
8. To begin the wash cycle
Select HOLD TO START.
■If you do not select HOLD TO START within 5 minutes of
choosing a cycle, the washer automatically shuts off.
■When the wash cycle is complete, the CYCLE
COMPLETE status light glows, the door unlocks, and the
wash load can be removed from the washer. The washer
powers down automatically 5 minutes after the cycle is
complete and the CYCLE COMPLETE light goes off. To
power down the washer manually after the wash cycle is
complete, select PAUSE/CANCEL once.
9. To begin the wash cycle later
Select DELAY WASH until the desired delay time (in hours)
shows in the Estimated Time Remaining display. Select
START. The countdown to the wash cycle will show in the
display window.
■When delaying a cycle, use only powdered detergents in
the main wash compartment since liquid detergents may
seep out of the compartment during Delay, before the
wash cycle begins.
Using the Dispenser
Your new washer has a dispenser drawer with three separate
compartments for your laundry products—one is for detergent,
one is for liquid chlorine bleach, and one is for liquid fabric
softener. Laundry products are diluted and dispensed
automatically at the proper time during the wash cycle, making it
unnecessary for you to return to the washer during the cycle to
add them.
It is normal for small amounts of water to remain in the
dispensers when the wash cycle is complete.
Do not put laundry additives directly into the wash tub. Always
use the proper dispensers when adding laundry products.
Choosing the Right Detergent
Use only High Efficiency detergents. The package for this type of
detergent will be marked “HE”or “High Efficiency.”This wash
system, along with less water, will create too much sudsing with a
regular non-HE detergent. Using regular detergent will likely result in
washer errors, longer cycle times and reduced rinsing performance.
It may also result in component failures and noticeable mold or
mildew. HE detergents are made to produce the right amount of
suds for the best performance. Follow the manufacturer's
instructions to determine the amount of detergent to use.
To fill dispenser compartments
1. Pull out the dispenser drawer.
2. Add the desired laundry product to the proper compartment.
3. Push in the dispenser drawer slowly and completely (to avoid
a spill).
Main wash detergent compartment
(Letter C in Dispenser Illustration)
Add liquid or powdered HE detergent to this compartment for
your wash cycle. The detergent separator must always be in
place, either in the front or back position.
■Do not fill beyond the “MAX”level. Use detergent
manufacturer’s recommended amount for load size.
■Liquid or powdered color-safe bleach may be added to the
Main Wash compartment along with the same type of
detergent, liquid or powdered.
■Liquid detergent: Put the separator in the front position,
between the guides, as shown following. There will be no gap
between the bottom of the wash cycle detergent
compartment and the bottom of the separator.
Use only HE High Efficiency detergent.
Dispenser
A. Dispenser release lever
B. Separator
C. Main wash detergent compartment
D. Chlorine bleach compartment
E. Fabric softener compartment
Separator in front position, between guides
A. Separator
B. Guide
A
B
D
C
E
LIQUI
SO
A
B

13
■Powdered detergent: Put the separator in the back position,
behind the guides, as shown following. There will be a gap
between the bottom of the wash cycle detergent
compartment and the bottom of the separator.
NOTE: The separator will be in the POWDER (back) position
when shipped from the factory.
Chlorine bleach compartment
(Letter D in Dispenser Illustration)
Add no more than ¹⁄₃ cup (80 mL) liquid chlorine bleach to this
compartment. The bleach will be automatically diluted and
dispensed at the optimum time during the first rinse after the
wash cycle. This compartment cannot dilute powdered bleach.
■Always measure liquid chlorine bleach. Use a measuring cup
with a pour spout; do not guess.
■Do not fill beyond the “MAX”level. Overfilling could cause
severe garment damage.
Fabric softener compartment
(Letter E in Dispenser Illustration)
Add ¼cup (60 mL) liquid fabric softener to this compartment.
Fabric softener will be automatically dispensed in the final rinse.
■Do not fill beyond the “MAX”level.
Pausing or Restarting
1. To pause the washer at any time, select PAUSE/CANCEL.
2. To continue the cycle, select HOLD TO START (for
approximately 1 second).
Changing Cycles, Options and Modifiers
Not all Options and Modifiers are available with all cycles. Cycles,
Options and Modifiers can be changed anytime before HOLD TO
START is selected.
Options and Modifiers can be changed anytime after HOLD TO
START is selected and before the start of the selected Option or
Modifier.
To cancel a cycle and select a new cycle
1. Select PAUSE/CANCEL twice.
2. Select desired cycle.
3. Select the desired OPTIONS or MODIFIERS.
4. Select HOLD TO START (for approximately 1 second) to
restart the washer at the beginning of the new cycle.
To cancel a cycle
1. Select PAUSE/CANCEL twice.
2. The washer powers down, the door unlocks, and clothes can
be removed.
NOTE: If the water level or the temperature is too high, the
washer will drain automatically before the door unlocks.
To change Options or Modifiers after the cycle has started
1. Select PAUSE/CANCEL.
2. Select the desired OPTIONS or MODIFIERS.
3. Select HOLD TO START (for approximately 1 second) to
continue the cycle.
To drain the washer manually
1. Select PAUSE/CANCEL.
2. Select DRAIN/SPIN.
3. Select HOLD TO START (for approximately 1 second) to
begin the drain.
4. When the spin is complete, the door unlocks. Items can be
removed from the washer.
Status Lights
These lights show which portion of the cycle the washer is
operating. They also indicate when you can add an additional
item to the wash cycle and when the controls are locked.
Adding items
This washer allows an 8-minute period in which forgotten
garments may be added to the load. You can add items to the
washer if the Add a Garment status light is glowing.
To add items
1. Select PAUSE/CANCEL. The washer door unlocks, and items
can be added.
2. To continue the cycle, close the door and select HOLD TO
START (for approximately 1 second).
3. To unlock the door after the Add a Garment period, press
PAUSE/CANCEL twice. This will cancel the Wash Cycle.
Cycle Complete
The cycle complete light stays on for 5 minutes after the cycle is
complete, and then the washer shuts off.
Locking controls
The Control Lock avoids unintended use of the washer. You can
also use the control lock feature to avoid unintended cycle or
option changes during a cycle. When CONTROL LOCKED is lit,
all buttons are disabled except for PAUSE/CANCEL and START.
You can lock the controls while the washer is operating.
To lock the controls
Select and hold END OF CYCLE SIGNAL for 3 seconds.
The CONTROL LOCKED status light glows.
Separator in back position, behind guides
A. Separator
B. Guide
LIQUI
SO
A
B

14
To unlock the controls
Select and hold END OF CYCLE SIGNAL for 3 seconds until the
CONTROL LOCKED Status light turns off.
Door Locked
When the status light glows, the door is locked.
Estimated time remaining
The cycle times vary automatically based on your water pressure,
water temperature, detergent, and clothes load. The cycle time
will be extended if oversudsing occurs or the load is unbalanced.
The SUDs routine removes extra suds and assures proper rinsing
of your garments. During the unbalance routine the time
displayed may pause until this activity is complete, then resume
with the remainder of the cycle. These routines may add up to a
half-hour to the default cycle time.
Cycles
Cycles can be selected by turning the Cycle control knob to the
desired cycle. Each cycle is designed for different types of fabric
and soil levels.
■Each cycle has a preset Soil Level (cycle time), Water
Temperature and Spin Speed, and may have preset options.
The preset settings provide the recommended fabric care for
the selected cycle.
■The preset settings can be changed anytime before HOLD TO
START is pressed. Not all options and modifiers are available
with all cycles. (To change settings after the cycle has started,
press PAUSE/CANCEL, then select the desired settings.
Press HOLD TO START to continue the cycle.)
Sanitary
Use this cycle to clean heavily soiled, colorfast fabrics. This cycle
combines a super hot water temperature and fast speed tumbling
to help ensure the removal of heavy soils and stains. It is
recommended that you set your hot water heater to 120ºF (49ºC)
to ensure proper performance during this cycle. The Sanitary
cycle also helps eliminate 99.999% of 3 common infectious
bacteria, even when no bleach is used. Extra high speed spin
helps shorten drying time.
Whitest Whites
This cycle is especially designed for cleaning loads of soiled
white fabrics with the addition of bleach. Hot washing
temperatures assure optimal bleach activity. An additional rinse
provides optimal rinse performance to avoid chlorine residues on
your laundry. This cycle combines fast-speed tumbling, longer
wash time and high-speed spin to shorten drying times.
Heavy Duty
Use this cycle to wash loads of sturdy, colorfast fabrics and heavily
soiled garments. This cycle combines fast-speed tumbling, longer
wash time, and high-speed spin to shorten drying times.
Normal/Casual
Use this cycle to wash loads of no-iron fabrics, such as sport
shirts, blouses, casual business clothes, permanent press
blends, cottons and linens, and synthetic fabrics. This cycle
combines medium-speed tumbling, high-speed spin, and a load
cooling process to reduce wrinkling.
Delicate/ Hand Washables
Use this cycle to clean hand washable and special-care
garments. Similar to the way garments are handwashed in a sink,
the wash action of this cycle combines periods of low speed
tumbling and soaking. Low speed spin reduces wrinkling.
Soak
Use the Soak cycle to remove small spots of set-in stains on
fabrics. This cycle provides a soak time with warm or cold water
followed by drain. Extra water, a short tumbling phase for equal
distribution of the laundry, and a soaking time without drum
movement, improve the removal of set-in stains. Drain without
spin assures gentle treatment, even for delicate articles.
Rinse/Spin
Use this cycle to get a rinse and spin only. This cycle combines
fast-speed tumbling and high-speed spin. If desired, you can
reduce the spin speed by selecting the speed you want from the
SPIN SPEED modifier.
A Rinse/Spin cycle is useful for
■Loads that need rinsing only.
■Adding fabric softener to a load.
Drain/Spin
Use this cycle to drain your washer or to drain and spin your
wash load. The spin speed is preset to high. If desired, you can
reduce the spin speed by selecting the speed you want from the
SPIN SPEED modifier.
NOTE: Loads of synthetics, delicate fabrics, handwashables, and
woolens should be drained with no spin or low spin speed to
avoid fabric stress.
Preset cycle settings
Each cycle has a preset Soil Level (cycle time), Water
Temperature, and Spin Speed. The preset settings provide the
recommended fabric care for the selected cycle. See chart.
To change the preset cycle settings
Press the selector of each setting until the desired setting glows.
Cycle Soil Level
(cycle time) Water Temp Spin Speed
Sanitary Normal
(1:55) Super Hot/Cold High
Whitest
Whites Normal (1:00) Hot/Cold High
Heavy Duty Normal
(0:50) Hot/Cold High
Normal/
Casual Normal (0:40) Warm/Cold High
Delicate/
Hand
Washables
Normal
(0:30) Cold/Cold Low
Soak Normal
(0:30) Warm/Cold No Spin
Rinse/Spin Normal
(0:21) Cold/Cold High
Drain/Spin Normal
(0:11) N/A High

15
Normal Washer Sounds
As with any new product, you will hear sounds that you are not
accustomed to. You may hear various sounds when the door is
locked and unlocked, and during the washing, rinsing, and
spinning process. Between changes in wash actions, there will
be momentary pauses. You will hear water spraying and
splashing during the wash and rinse cycles. These new sounds
and pauses are part of normal washer operation.
Options
You can customize your wash by adding options to your cycle
selections. You can add or change an option after starting a cycle
anytime before the selected option begins. Not all options are
available with all cycles.
■See the “Laundry Guide”for an overview of possible options
for each Wash Cycle selection.
■You can select more than one option for a cycle. Some
options cannot be added to some cycles.
■If an option is available with a selected cycle, the light for that
option will glow when selected.
■If an option is unavailable with a selected cycle, there will be a
short tone, and the light for that option will not glow when
selected.
Delay Wash
Use this to begin the wash cycle later.
■Select Delay Wash until the desired time (in hours) shows in
the Estimated Time Remaining display.
■Select START. The countdown to the wash cycle will show in
the display window.
■When delaying a cycle, use only powdered detergents in the
main wash compartment since liquid detergents may seep
out of the compartment during Delay, before the wash cycle
begins.
Extra Rinse
An extra rinse can be used to ensure the removal of detergent or
bleach residue from garments. This option provides an additional
rinse with the same water temperature as the first rinse.
Modifiers
Preset cycle settings of Water Temperature, Spin Speed, and
Cycle Time can be changed. You can change a modifier after
starting a cycle anytime before the selected modifier begins. Not
all modifiers are available with all cycles and options.
■To change the water temperature, select the WATER TEMP
button until the desired setting glows.
■To change the spin speed, select the SPIN SPEED button
until the desired setting glows.
■To change the loudness of the End of Cycle Signal, select
END OF CYCLE SIGNAL.
■To change cycle time, select SOIL LEVEL button.
Wash/Rinse Temp
Select a water temperature based on the type of load you are
washing. Use the warmest wash water safe for fabrics. Follow
garment label instructions.
Warm rinses leave the loads dryer than cold rinses. Warm rinses
increase wrinkling. In cold climates, a warm rinse makes the load
more comfortable to handle. Cold rinses save energy.
Temperature Guide
In wash water temperatures colder than 60°F (15.6°C), detergents
do not dissolve well. Soils may be difficult to remove.
ACCUWASH™Automatic Temperature Control
The ACCUWASH™control electronically senses and maintains a
uniform water temperature. ACCUWASH control regulates
incoming hot and cold water. ACCUWASH control is
automatically turned On when a cycle is selected. (See “Preset
cycle settings”in “Cycles.”)
■ACCUWASH™control ensures consistent cleaning.
■ACCUWASH™control works for all wash and rinse
temperature settings.
Wash Water Temperature Suggested Fabrics
SUPER HOT Sturdy colorfast fabrics
Heavy soils
HOT Whites and pastels
Heavy soils
WARM Bright colors
Moderate to light soils
COLD Colors that bleed or fade
Light soils

16
Laundry Guide
Refer to this chart for suggested load types and their corresponding cycles. Listed to the right are the options available to each of these
washer cycles.
LAUNDRY TIPS
Preparing clothes for washing
Follow these recommendations to help you prolong the life of
your garments.
■Use only High Efficiency detergents. The package for this
type of detergent will be marked “HE”or “High Efficiency.”
This wash system, along with less water, will create too much
sudsing with a regular non-HE detergent. Using regular
detergent will likely result in washer errors, longer cycle times
and reduced rinsing performance. It may also result in
component failures and noticeable mold or mildew. HE
detergents are made to produce the right amount of suds for
the best performance. Follow the manufacturer's instructions
to determine the amount of detergent to use.
■Close zippers, snaps, and hooks to avoid snagging other
items. Remove pins, buckles, and other hard objects to avoid
scratching the washer interior. Remove non-washable trim
and ornaments.
■Empty pockets and turn them inside-out.
■Turn down cuffs; brush away lint and dirt.
■Turn synthetic knits inside-out to avoid pilling.
■Tie strings and sashes so they will not tangle.
■Mend tears, loose hems, and seams.
■Treat spots and stains.
■Stained or wet garments should be washed promptly for best
results.
■Mix large and small items, avoid washing single items, and
load evenly.
■Wash small items, such as infant socks, in a mesh garment
bags. To create a balanced load it is recommend that more
than one garment bag be used, and that each garment bag
be filled with equal amounts of material.
NOTE: If only washing garments in mesh bags, it is
recommend that more than one garment bag be used, and
that each garment bag be filled with equal amounts of
material.
CYCLE SUGGESTED LOAD TYPE DELAY WASH EXTRA RINSE
Sanitary Heavily soiled underwear, towels, work clothes, diapers, etc. ✔✔
Whitest Whites Heavily soiled white fabrics ✔✔
Heavy Duty Heavily soiled underwear, towels, shirts, etc. ✔✔
Normal/Casual Normally soiled blouses, shirts, overalls, etc., made of
polyester, nylon, cotton, linen, or cotton blends
✔✔
Delicate/Hand Washables Curtains & delicate clothing, special-care items labeled
“Handwashable”
✔✔
Soak Fabrics made of cotton, linen, polyester or nylon ✔
Rinse/Spin Fabrics made of cotton, linen, polyester or nylon ✔✔
Drain/Spin Fabrics made of cotton, linen, polyester or nylon ✔
Use only HE High Efficiency detergent.

17
Sorting
■Separate heavily soiled items from lightly soiled ones, even if
they would normally be washed together. Separate lint-givers
(towels, chenille) from lint-takers (corduroy, synthetics,
permanent press). When possible, turn lint-givers inside-out.
■Separate dark colors from light colors, colorfast items from
noncolorfast items.
■Sort by fabric and construction (sturdy cottons, knits, delicate
items).
Unloading
■Remove clothes from washer after the cycle is completed.
Metal objects such as zippers, snaps, and buckles may rust if
left in the washer basket for a long time.
■When unloading garments, occasionally check under the
rubber rim at the front of the tub for small items.
Loading
WASHER CARE
Cleaning Your Washer
Cleaning the door seal
1. Open the washer door and remove any clothing or items from
the washer.
2. Inspect the gray colored seal between the door opening and
the basket for stained areas. Pull back the seal to inspect
areas under the seal.
3. If stained areas are found, wipe down these areas of the seal,
using the procedure that follows.
a) Mix a dilute solution, using ³₄ cup (177.4 mL) of liquid
chlorine bleach, and 1 gal. (3.8 L) of warm tap water.
b) Wipe the seal area with the dilute solution, using a damp cloth.
c) Let stand 5 minutes.
d) Wipe down area thoroughly with a dry cloth and let the
washer interior air dry.
IMPORTANT:
■Wear rubber gloves when cleaning for prolonged periods.
■ Refer to the bleach manufacturer’s instructions for proper use.
Washer Monthly Maintenance Procedure
Your washer has a special cycle stored within the machine’s
programming. Pressing a specific combination of buttons will
access this cleaning cycle. This cycle uses higher water volumes
in combination with liquid chlorine bleach to thoroughly clean the
inside of your washing machine.
NOTES:
■Read these instructions completely before beginning the
cleaning process.
■If necessary, the cleaning cycle may be interrupted by
pressing the PAUSE/CANCEL button. However, this will not
immediately stop the cycle. The machine will display “int”
(interrupt) and continue with several rinse and drain steps to
ensure that all remaining bleach is rinsed from the unit.
Begin procedure
1. Open the washer door and remove any clothing or items from
the washer.
2. Be sure the door is closed.
3. Open the dispenser drawer and remove the detergent divider
from the Main Wash detergent compartment. See “Using the
Dispenser”for instructions. No laundry products will be
added at this time; you will be required to add only liquid
chlorine bleach, at a later step.
4. To enter the cycle, a specific combination of buttons must be
pressed.
■Select the POWER button.
■Select the RINSE/SPIN button.
■Select LOW SPIN Speed.
■Select Warm/Cold WATER TEMPERATURE.
■Set the End of Cycle Signal to Softer.
■Push EXTRA RINSE button 4 times within 5 seconds to
start the cycle. The door will lock, and filling will begin.
NOTE: The water in the unit will dispense for a moment,
then the door will unlock, lock again, and then the cycle
will continue.
■The machine will fill and run a short cycle to determine
whether any items have been left in the washer. This will
take approximately 3 minutes.
Loading suggestions (maximum size loads).
Heavy Work Clothes
4 jeans
4 workpants
4 workshirts
2 sweatpants
2 sweatshirts
Towels
10 bath towels
10 hand towels 14 washcloths
Mixed Load
3 sheets (1 king, 2 twin)
4 pillowcases
3 shirts
3 blouses
9 T-shirts
9 shorts
10 handkerchiefs
A. Seal
A

18
5. The washer will provide 4 short tones. Check the Estimated
Time Remaining display for the codes indicated below.
6. Add liquid chlorine bleach.
7. Once the cleaning cycle has begun, allow the cycle to
complete. An estimated cycle time will appear on the display.
8. After the cleaning cycle is complete, leave the door open,
slightly, to allow for better ventilation and drying of washer
interior.
9. Replace the detergent compartment divider.
Always do the following to maintain washer freshness
■Use only HE High Efficiency detergent.
■Leave the door slightly open after each cycle to allow for
better ventilation and drying of washer interior.
■Run this procedure using ¹⁄₃ cup (78.8 mL) of liquid chlorine
bleach, if necessary.
■If the procedure does not sufficiently improve the machine
freshness, evaluate your installation and usage conditions for
other causes.
Cleaning the exterior
Use a soft damp cloth or sponge to wipe up any spills.
Occasionally wipe the outside of your washer to keep it looking
new. Use mild soap and water. Do not use abrasive products.
Cleaning the dispenser drawer
The dispenser drawer is removable for easy cleaning.
1. Unlock the dispenser drawer by pressing the Release Lever in
the Prewash compartment. See “Using the Dispenser.”
Remove the drawer.
2. Remove the inserts (the siphon from the softener and bleach
compartments and the separator).
3. Wash the parts under running water.
4. Replace the inserts and return the dispenser to the drawer.
Water Inlet Hoses
Replace inlet hoses after five years of use to reduce the risk of
hose failure. Periodically inspect and replace inlet hoses if
bulges, kinks, cuts, wear or leaks are found.
When replacing your inlet hoses, record the date of replacement.
Vacation, Storage, and Moving Care
Install and store your washer where it will not freeze. Because
some water may stay in the hoses, freezing can damage your
washer. If storing or moving your washer during freezing weather,
winterize it.
Non-use or vacation care:
Operate your washer only when you are at home. If you will be on
vacation or not using your washer for an extended period of time,
you should:
■Unplug washer or disconnect power.
■Turn off the water supply to the washer. This helps avoid
unintended flooding (due to a water pressure surge) while you
are away.
■Slightly open door to provide ventilation.
To winterize washer:
1. Put 1 qt (1 L) of R.V.-type antifreeze in the drum.
2. Run washer on a DRAIN/SPIN cycle.
3. Unplug washer or disconnect power.
4. Shut off both water faucets.
5. Disconnect water inlet hoses from faucets and drain.
To use washer again:
1. Flush water pipes. Reconnect water inlet hoses to faucets.
Turn on both water faucets.
2. Plug in washer or reconnect power.
a)
b)
If the washer displays the letters “Ab”(Add Bleach) in the
Estimated Time Remaining display, you will hear 4 short
tones. Proceed to Step 6.
If the washer displays the letters “rL”(Remove Load) in
the Estimated Time Remaining display, an error tone will
sound. The door will unlock.
■ Open the door and remove the items from the washer.
■Continue the cycle by pressing the START button.
NOTE: The water in the unit will dispense for a
moment, then the door will unlock, lock again, and
then the cycle will continue with another check for
items in the washer.
■The machine will fill and run a short cycle to
determine whether any items have been left in the
washer. This will take approximately 3 minutes.
■The washer will repeat Step 5 until it can determine
that there are no items in the washer and will display
“Ab”(Add Bleach).
a)
b)
If using the maintenance procedure for the first time,
open the dispenser drawer and immediately add 1 cup
(236.6 mL) liquid chlorine bleach to the Main Wash
detergent compartment. The liquid chlorine bleach
should immediately flow out of the dispenser.
If doing a monthly maintenance procedure, open the
dispenser drawer and immediately add ¹⁄₃ cup (78.8 mL)
liquid chlorine bleach to the Main Wash detergent
compartment. The liquid chlorine bleach should
immediately flow out of the dispenser.
NOTES:
■Water will be flowing into the dispenser drawer when
the bleach is added. This is normal.
■Do not add any detergent to this cleaning cycle. Use
of more than 1 cup (236.6 mL) of bleach will cause
product damage over time.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

19
3. Run the washer through the NORMAL/CASUAL cycle.
Measure ¹⁄₄ the manufacturer's recommended amount of HE
High Efficiency detergent for a medium size loads.
To transport the washer:
1. If washer will be moved during freezing weather, put in
1 qt (1 L) of R.V.-type antifreeze in the drum. Run washer on
a DRAIN/SPIN cycle.
2. Unplug the power cord.
3. Disconnect the drain hose from the drain system and attach
to rear panel clips.
4. Shut off both water faucets.
5. Disconnect the water inlet hoses from faucets, then drain the
hoses and clip them to the rear panel of the washer.
IMPORTANT: Call service. Do not reuse transport bolts. Unit
must be transported in the upright position. To avoid suspension
and structural damage to your washer, it must be properly set up
for relocation by a certified technician.
Reinstalling the washer
1. Follow the “Installation Instructions”to locate, level and
connect the washer.
2. Run the washer through the NORMAL/CASUAL cycle.
Measure ¹⁄₄ the manufacturer's recommended amount of HE
High Efficiency detergent for a medium size loads.
TROUBLESHOOTING
First try the solutions suggested here to possibly avoid the cost of a service call...
Washer displaying code message and tone sounds
■“FH”(Water Inlet Problem—no or insufficient water
supply)
Select PAUSE/CANCEL twice to cancel the cycle. Unplug
washer or disconnect power.
Check the following:
Are water faucets completely turned on?
Are screens at inlet hose connection to washer clogged?
Are water inlet hoses kinked?
Are water inlet hoses frozen?
Plug in washer or reconnect power. Re-select cycle and press
HOLD TO START. If the problem remains, call for service.
■“F02”(Drain Problem)
Select PAUSE/CANCEL twice to cancel the cycle. Unplug
washer or disconnect power.
Check the following:
Is the drain hose kinked?
Is the drain hose frozen?
Is the drain hose clogged?
Is the drain hose more than 96" (2.4 m) above the floor?
■“SUD”(Suds Routine)
When excessive suds are detected, a suds routine
automatically starts. This routine removes extra suds and
assures proper rinsing of your garments. “SUD”is displayed
during rinsing and at the end of the cycle to inform you that
Suds Routine was activated. Use only HE (High Efficiency)
detergents.
■“F”Variables [other than FH, F02, and SUD] (Electrical
Problem)
Select PAUSE/CANCEL twice to cancel the cycle. Select
DRAIN/SPIN if there is excessive water in the washer.
Re-select cycle and select HOLD TO START. If the problem
remains, call for service.
Washer won’t start
■Check the following:
Is the power cord plugged into a grounded 3 prong outlet?
Is the washer door firmly closed?
Has a cycle been selected, but HOLD TO START has not
been selected and held for 1 second?
Was the door open after completion of last cycle?
Washer won’t fill, wash or rinse
■Check the following:
Is the power cord plugged into a grounded 3 prong outlet?
Is there power at the plug? Check electrical source or call
electrician.
Are the hot and cold water faucets turned on?
Is the water inlet hose kinked?
Are the water inlet valve screens clogged?
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

20
Washer stops
■Check the following:
Is the power cord plugged into a grounded 3 prong outlet?
Is there power at the plug?
Check electrical source or call electrician.
Has a household fuse blown, or has a circuit breaker tripped?
Replace the fuse or reset the circuit breaker. If the problem
continues, call electrician.
Are you using an extension cord?
Do not use an extension cord.
Washer won’t drain or spin
■Is the drain hose clogged, or the end of the drain hose
more than 96" (2.4 m) above the floor?
■Is your voltage low?
Check electrical source or call electrician. Do not use an
extension cord.
■Is the “SUD”routine active?
Cycle will complete once extra suds are removed.
■Is the load balanced?
A single or bulky item may cause imbalance. Add more items
or redistribute the load.
Washer makes noise or vibrates
■Is the washer level?
The washer must be level. The four feet should be properly
installed, and the nuts should be tightened against the
washer cabinet.
As water is drained from the washer, you may hear air being
pulled through the pump. This happens during the end of
draining. It is normal.
■Are you washing items with metal snaps, buckles or
zippers?
You may hear metal items touching the washer drum. This is
normal.
■Is washer installed on a sturdy and solid floor?
Refer to the “Installation Instructions”for flooring
requirements. Noise and vibration may be reduced by placing
a piece of ¾" (19.1 mm) plywood underneath your washer.
The plywood may extend underneath both washer and dryer
to keep them at equal heights.
Washer leaks
■Check household plumbing for leaks.
Dispensers clogged or leaking
■Are the laundry products in the correct dispenser
compartment?
Add the correct amounts of HE detergent, fabric softener or
liquid chlorine bleach to the correct compartments. Add
powdered or color-safe bleach to the detergent compartment.
■Is the detergent separator in the correct position?
Separator should be in the front position when using liquid
detergent and in the back position when using powdered
detergent. Be sure to match powdered color-safe bleach with
powdered detergent or match liquid color-safe bleach with
liquid detergent.
Washer odor
■See “Cleaning Your Washer.”
■Are you using HE detergent?
Use of non-HE detergent can cause a film residue which can
result in odor.
■Did you leave the door open after use?
This washer has a tight seal to avoid water leaks. To avoid
odors leave the door open to allow the washer to dry
between uses.
Load too wet
■Did you use the right cycle for the load being washed?
Select a cycle with a higher spin speed.
■Did you wash a single item or bulky items or have you
overloaded the washer?
A single item, bulky items, or overloading may cause
imbalance. Add items or try to evenly distribute your wet
laundry in the drum, and start a DRAIN/SPIN cycle. If the
laundry is still wet, take half of the load out of the washer and
try again.
Residue or lint on load
■Did you add detergent to the dispenser?
For best results, add detergent to the detergent
compartment. Do not add detergent to the washer drum.
■Did you sort properly?
Sort lint givers (towels, chenille) from lint takers (corduroy,
synthetics). Also, sort by color.
■Did you overload the washer?
Do not overload the washer. The washer can be fully loaded,
but not tightly packed. The wash load must be balanced. Lint
can be trapped in the load if overloaded.
■Check the following:
Was paper or tissue left in pockets?
