1
TOP AND CABINET PARTS
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
05−04 Litho in U.S.A. (drd) Part No. 8180378
AUTOMATIC
WASHER

TOP AND CABINET PARTS
2
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
LIT3956025 Installation
Instructions
LIT3955869 Use & Care Guide
LIT3955907 Feature Sheet
LIT3956910 Energy Guide
LIT8541944 Wiring Diagram
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
LIT4313896 Manual, Washer
2 Top
8318064 White
8318066 Biscuit
3 62750 Spacer, Cabinet To
Top (4)
4 357213 Nut, Push−In (2)
5 Cabinet
63424 White
3954357 Biscuit
6 62780 Clip, Top & Cabinet
& Rear Panel (2)
7 3362952 Dispenser, Bleach
8 3351614 Screw, Ground
9 3357011 Screw, 10−16 x 1/2
11 8318084 Switch, Lid
13 3351355 Screw, Lid Hinge
Mounting (4)
15 8318088 Hinge, Lid (L.H.)
16 54583 Hinge, Lid (R.H.)
17 19119 Bumper, Lid Hinge
18 21258 Bearing, Lid
Hinge (2)
19 Lid
8542387 White
8542384 Biscuit
22 9724509 Bumper, Lid (2)
28 3390631 Screw, 10−16 x 3/8

CONTROLS AND REAR PANEL PARTS
3
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378

4
CONTROLS AND REAR PANEL PARTS
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 3976300 Washer, Water
Inlet Hose (4)
(1−1/16 x 5/8)
2 3400073 Screw, Ground
3 Hose, Water
Inlet (2)
3949374 Blue Coupler
3949375 Red Coupler
4 9740848 Screw, 8−18 x 1/2
5 8318255 Strap, Console (2)
6 3357978 Panel, Rear
7 62747 Pad, Rear Panel
8 3951609 Hose, Drain
(4 ft.)
661577 Hose, Drain
(9 ft.)
(Not Included)
3357090 Extension
Drain−Hose
(21 Inches)
(Not Included)
9 8541942 Timer, Control
(60 Hz.)
(Motor Not A
Service Part)
10 3351614 Screw, Ground
11 90767 Screw, 8−18 x 3/8
12 3366847 Switch, Water Level
13 3948608 Bracket, Control
14 661661 Cord, Power
(Includes Item 15)
15 3952821 Strain Relief,
Power Cord
16 Cap, End (L.H.)
8271365 White
8271368 Biscuit
17 661606 Capacitor,
Motor Start
18 3952164 Valve, Water
Mixing
19 694419 Mini−Buzzer
20 8318046 Clip, Capacitor
21 301958 Clamp, Hose
22 8541607 Hose, Vacuum
Break
23 370450 Clamp, Hose
24 387606 Break, Vacuum
25 303294 Edge Protector
26 8317940 Hose−Corrugated
Assembly
27 3366912 Clamp, Hose
28 3976395 Clamp, Hose
30 3363366 Clamp, Hose
31 8317496 Clamp, Hose
32 3951449 Hose, Pump To Tub
33 8055003 Clip, Harness
& Pressure Hose
34 8317975 Retainer, Harness
35 661612 Switch, Water
Temperature
36 3400818 Screw, Timer
Mounting
37 3949180 Switch, Rotary
39 Panel, Console
3956559 White
3956560 Biscuit
44 Knob, Timer
8544943 White
8544944 Biscuit
45 Dial, Timer
8544947 White
8544948 Biscuit
46 8536939 Clip, Knob
47 Knob, Control
8544935 White
8544936 Biscuit
49 388326 Screw, 8−18 x 1.25
(Panel to Top)
50 62863 Screw, 10−16 x 3/8
51 Cap, End (R.H.)
8271359 White
8271362 Biscuit
58 3366913 Clamp, Drain
Hose
59 8539874 Shield, Suds
60 3357027 Nozzle−Drain
Hose
61 3957015 Wiring Harness
(For Detail See
Pages 9 & 10)

AGITATOR, BASKET AND TUB PARTS
5
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378

AGITATOR, BASKET AND TUB PARTS
6
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378
Illus. Part
No. No. DESCRIPTION
1 63580 Dispenser,
Fabric Softener
2 358237 Screw & Washer
(5/16−24 x 1)
3 3348752 Clothes Mover
4 3347288 Agitator
5 8528150 Tub Ring & Gasket
6 3976308 Gasket, Tub Ring
7 3354845 Clip, Agitator
8 3355921 Washer, Agitator
9 3363663 Cam, Driven
10 3366877 Dog, Agitator
Clutch
11 3363661 Bearing, Cam
Driven
12 21366 Nut, Spanner
13 8526016 Basket & Balance
Ring
14 2219077 Clip, Pressure
Switch Hose
15 8519788 Balance Ring
16 63849 Tub
17 389140 Block, Basket
Drive
18 383727 Gasket, Centerpost
19 3347780 Hose, Pressure
Switch
20 3348117 Agitator
(Complete)
22 3350389 Spacer, Thrust
23 3354733 Cap, Barrier
24 3348855 Seal, Inner Cap
26 3949550 Washer

BRAKE, CLUTCH, GEARCASE, MOTOR AND PUMP PARTS
7
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 388952 Brake & Drive
Tube (Complete)
(Refer to Page 11
For Further
Breakdown)
2 63292 Washer, Spin
Tube Thrust
3 62697 Ring, Spin
Tube Support
4 63283 Ring, Retainer
5 3951311 Clutch (Complete)
6 3951308 Band & Lining,
Clutch (Includes
Illus. 7 & 8)
7 62646 Cap, Clutch
Spring (2)
8 3946792 Spring, Clutch
9 3360630 Gearcase
(Complete)
(Refer To Page 12
For Further
Breakdown)
10 3357334 Screw, Gearcase
To Base (3)
11 62611 Plate, Motor
Mount To
Gearcase
12 62691 Grommet, Motor (4)
13 285753 Coupling, Motor
& Isolation
15 3355454 Clip,
Anti−Rattle
16 3400516 Screw
17 3349637 Retainer, Motor (2)
18 3362089 Shield, Tub
To Motor
19 8528157 Motor, Main
Drive
20 3952056 Switch, Main
Drive Motor
21 8546127 Retainer, Pump (2)
22 3363394 Pump (Complete)
23 3387485 Screw, 10−16 x 5/8
24 3946532 Shield, Motor

MACHINE BASE PARTS
8
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378
Illus. Part
No. No. DESCRIPTION
1 3400076 Screw, Bracket
Mounting
(10−32 x 5/8)
2 64067 Bracket, Spring
Outer (2)
3 63907 Spring
Suspension,(3)
4 3362087 Support & Brake,
Tub
5 64065 Bracket, Spring
Outer (L.F.)
6 63466 Link, Leveling
Mechanism (2)
7 62597 Spring, Leveling
Mechanism
8 62837 Pin, Knurled
9 62596 Foot, Rear (2)
13 3347047 Bearing,
Centerpost (2)
14 357409 Seal, Centerpost (3)
15 388492 Spring,
Counterweight
16 62568 Pad, Plate
17 3946509 Plate, Suspension
(Includes Illus. 16)
18 3363660 Pad, Base
19 3946512 Base Assembly
(Includes Illus, 6,
7, 8, 9, 16, 17
18 & 26)
21 3359452 Nut, Lock (2)
(3/8−16)
22 389102 Foot, Front (2)
23 356934 Seal, Centerpost (2)
24 285203 Centerpost
Bearing Kit
(Includes Illus.
13, 14 & 23)
25 63134 Ring, Sound
Deadening
26 63806 Retainer,
Suspension Spring

WIRING HARNESS PARTS
9
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378

WIRING HARNESS PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 3349557 Clip, Harness
2 388498 Clip, Harness
3 3347812 Clip, Harness
4 3352501 Clip, Harness
5 90016 Clip, Harness
6 3390496 Clip, Harness
7 389379 Retainer,
(Suds Models)
8 3948614 Timer, Block
Disconnect
(White)
9 352089 Timer, Block
Disconnect
(Black)
10 62889 Receptacle,
Terminal
(3−Way)
(Lid Switch)
(Use Term.94613)
Or 94614.)
11 353424 Plug, Terminal
(3−Way)
(Power Cord)
(Use Term.94613)
12 62505 Block, Disconnect
(Motor 2 Speed)
(Use Term.352088)
13 3347243 Block, Disconnect
(Use Term. 352088)
14 63523 Protector
15 717252 Connector
(2−Way)
(Use Term.94614)
16 3352944 Clip, Harness
17 3390423 Block, Disconnect
(12−Way)
(Timer)
(Use Term. 94613)
18 3347730 Receptacle
(6−Way)
(Use Term. 94613)
19 3349494 Connector, Etc
20 3407125 E.T.C. Control
21 3948617 Connector (T.P.A.)
(3−Circuit)
(Lid Switch)
22 3360056 Connector (T.P.A)
(3−Circuit)
(Pressure Switch)
23 3354925 Block, Connector
(Cold Valve)
24 3354926 Block, Connector
(Hot Valve)
10
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378

Illus. Part
No. No. DESCRIPTION
BRAKE AND DRIVE TUBE PARTS
1 388952 Brake And Drive
Tube (Complete)
2 62658 Ring, Thrust
3 91939 Seal, Oil
4 356427 Seal, Drive Tube
5 356937 Spacer, Drive
Tube
6 64027 Tube, Basket
Drive (Includes
Illus. 3, 4, 5 & 9)
7 64035 Ring, Retaining
8 64232 Shoe, Brake
9 62703 "T" Bearing,
Spin Tube
10 62648 Cap, Brake
Spring (2)
11 387806 Spring, Brake
12 62909 Sleeve, Brake
Spring
13 63023 Cam, Brake
Release
14 63022 Sleeve, Cam
15 64194 Driver, Brake
Cam
16 90368 Ring, Retaining
FOLLOWING PARTS
NOT ILLUSTRATED
285208 Lubricant
(Use Only In
Brake Shoe
Assembly On
Roller & Pin)
11
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378

GEARCASE PARTS
Illus. Part
No. No. DESCRIPTION
1 3360630 Gearcase
(Complete)
2 285202 Cover, Gearcase
3 3349985 Seal, Gearcase
Cover
4 285195 Sealer, Gasket
(.20 Fl. Oz.) (6 ml)
5 63320 Pinion, Spin
(Includes Illus. 25)
6 356427 Seal, Spin
Pinion
7 389387 Shaft, Agitator
(Complete)
8 90369 Ring, Retaining (2)
9 62677 Retainer, Spring
10 62676 Spring, Agitate
11 63273 Gear, Agitate
(Includes 15 and 29)
12 62619 Washer, Agitate
Gear
13 62580 Cam Follower
(Includes 14)
14 62581 Cam, Agitate
(Includes 13)
15 285509 Shaft, Agitator
(Includes 11 and 29)
16 62618 Washer, Cam Thrust
17 16018 Bearing, Thrust
18 85529 Ball, Bearing
19 389230 Bottom and Pinion,
Gearcase
21 285352 Seal, Thrust Plug
22 3351614 Screw, Gearcase
Cover, Mounting (8)
(10−24 x 3/8)
23 3362552 Ring, Retaining
24 285735 Washer Kit,
Thrust
25 62570 Gear, Spin
26 388253 Neutral Assembly
27 3349296 Rack, Connecting
28 62621 Actuator, Shift
29 388815 Washer,
Intermediate
12
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378

WATER SYSTEM PARTS
1 285442 Connector Kit,
Plastic Drain
Hose
2 285321 Sleeve Kit,
(Contains 2
Sleeves)
3 370447 Clamp, Hose
4 16272 Connector,
Straight
5 285320 Siphon Break
Kit
(Not Included)
6 65349 Clamp, Hose
7 367031 Drain Protector
(Not Included)
Illus. Part
No. No. DESCRIPTION
13
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378

MISCELLANEOUS PARTS
OPTIONAL PARTS (NOT INCLUDED)
14
For Models: LSR9434PQ0, LSR9434PT0
(Designer White) (Biscuit)
8180378
Illus. Part
No. No. DESCRIPTION
1 3976263 Miscellaneous
Parts Bag
2 3976300 Washer, Inlet
Hose (4)
(1−1/16 x 5/8)
3 3366912 Clamp, Hose
4 3359452 Nut, Lock (2)
(3/8−16)
5 389102 Foot, Front (2)
6 3366913 Clamp, Hose
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
4392899 Biscuit
PAINT, PRESSURIZED SPRAY
(12 oz.)
350938 Primer, Gray
350930 White
4392901 Biscuit
PAINT, BULK (1 qt.)
799344 White (Uncut)
4392900 Biscuit (Uncut)
OIL
350572 Oil, Gearcase
(16 Oz.)
LUBRICANT
285208 Lubricant (Use
Only in Brake
Shoe Assembly
On Roller and
Pin)
SEALER
285195 Sealer, Gasket
(.20 Fl. Oz.) (6 ml)
ACCESSORY PARTS
367031 Drain Protector
285320 Siphon Break Kit
